Performance Characterization

of

the Tree Quorum Algorithm

Her-Kun Chang and Shyan-Ming Yuan

Abstruct- The tree quorum algorithm, which logically organizes the sites in a system to a tree structure, is an efficient and fault-tolerant solution for distributed mutual exclusion. In this paper, the performance characteristics of the tree quorum algorithm is analyzed. A refinement algorithm is proposed to refine a logical tree structure by eliminating nodes or subtrees which do not improve the performance. Thus the refined tree performs better than the original.

Index Term- Distributed mutual exclusion, tree quorum algorithm, availability, communication cost.

I. INTRODUCTION

A distributed system consists of a set of sites which are loosely coupled by a computer network. One advantage of distributed systems is resource sharing. That is the resources in a distributed system can be shared among the sites in the system. Examples of sharable resources are memory, peripheral, CPU, clock, etc. The sites in a distributed system may issue requests to a shared resource at arbitrary time. When two or more sites intended to access the same resource, a conflict occurs. A mechanism is required to synchronize conflicting requests so that at most one site is allowed to access the resource at any time instant. This problem is known as distributed mutual exclusion [ 11-[ 111. A survey of various algorithms for mutual exclusion can be found in [6] and a simple taxonomy for distributed mutual exclusion algorithms was reported in 171.

A central controller can be used to control mutually exclusive access to a shared resource. All requests intended to the resource are sent to the controller and scheduled by the controller. Using a central controller is simple and easy to implement. However, the controller is vulnerable to site failure. When the controller fails, no access to the resource is allowed, i.e., the entire system is hafted. It is desirable to reduce the probability that the system is halted by using more than one sites to participate the decision making. For example, majority consensus [ 111 can be used to achieve mutual exclusion wherein a site is allowed to access the resource if it can get permissions from a majority of all participating sites.

Majority consensus can tolerate at most N / 2 sites failures, where

N is the number of participating sites. On the other hand, the communication overhead is costly, since at least N messages ( N / 2

for request and N / 2 for reply) are required to be exchanged. Several algorithms try to reduce the communication overhead by imposing logical structures to the sites [l], [4]. The tree quorum algorithm [l], which logically organizes the sites to a tree structure, can reduce the number of messages exchanged to O(1og N) in the best case. In this paper, the performance characteristics of the tree quorum algorithm is analyzed.

The avaifabilify, which is defined to be the steady-state probability that the system is up (not halted), is usually used to evaluate a distributed algorithm. Another important performance measure for a distributed algorithm is its communication cost. Certainly, the purpose Manuscript received November 1, 1992; revised December 8, 1993. This

The authors are with Department of Computer and Information Science, IEEE Log Number 9411968.

work was supported in part by NSC under Grant NSC82-0408-E009-053. National Chiao Tung University, Hsinchu, Taiwan 30050.

IEEE TRANSACTIONS ON PARALLEL AND DISTRIBUTED SYSTEMS, VOL. 6, NO. 6, JUNE 1995 659

TABLE I

AVAILABILITIES OF THREE LOGICAL TREES

I

case

11

p ( X )

I AVB(L) I AVB(R) AVB(X)

]

I

1 I1 0.89 I 0.75 I 0.75 I1 0.8963

I

2

11

0.90

I

0.75

I

0.75

11

0.9000 3

11

0.91

I

0.75

I

0.75

11

0.9038

of using more than one sites to participate the decision making is to increase the availability. For a distributed algorithm, however, the communication cost will increase as the number of participating sites increases. In general, increasing availability and reducing cost are two conflicting goals, i.e., a system with higher availability usually has higher cost compared to a system with lower availability.

Can we reduce the communication cost while the availability dose not decrease? This paper shows that the answer is positive for the tree quorum algorithm. We find out that increasing the number of participating sites dose not necessarily increase the availability for the tree quorum algorithm. Giving a logical tree, we can refine the tree structure to improve its performance by eliminating nodes or subtrees that do not increase the availability. An algorithm is proposed to do such refinement. The refinement algorithm can reduce the number of nodes of the tree while the availability of the refined tree is not less than the original.

The remainder of this paper is organized as follows. The tree quorum algorithm is reviewed in the next section. In Section 111, a refinement algorithm for binary tree is proposed. Numerical results of the refinement algorithm are shown in Section IV. We extend the algorithm to arbitrary tree structures in Section V and some concluding remarks are given in the final section.

11. TREE QUORUM ALGORITHM

The tree quorum algorithm logically organizes the sites in a system as a tree structure. For a binary tree, a tree quorum (recursively) consists of

1) the root and a tree quorum of the left subtree, or 2) the root and a tree quorum of the right subtree, or

3) a tree quorum of the left subtree and a tree quorum of the right It was shown that any pair of tree quorums intersect with each other [l]. Thus mutual exclusion is ensured by requiring that an access request to get permissions from nodes which form a tree quorum.

The availability of a node is the probability that the node is operational at any time instant. For the tree quorum algorithm, the availability of a (logical) tree is the probability that at least one tree quorum can be formed from the tree. Thus the availability of a binary tree is the probability that

1) the root is operational and a tree quorum can be formed from the left subtree, or

2) the root is operational and a tree quorum can be formed from the right subtree, or

3) a tree quorum can be formed from the left subtree and a tree quorum can be formed from the right subtree.

subtree.

Every node X in a binary tree contains the following four fields:

p ( X ) : the availability of the node X,

A V B ( X ) : the availability of the subtree rooted at X,

L E F T ( X ) :

the root of the left subtree of X ( L E F T ( X ) =

R I G H T ( X ) : the root of the right subtree of If a tree consists of only one node, it degenerates to a central controller and the availability of the tree is the availability of itself,

nil if X has no left subtree),

X ( R I G H T ( X ) = nil if X has no right subtree).

i.e., A V B ( X ) = p ( X ) . For a node X having both left and right subtrees, A V B ( X )

=p(X)AVB(LEFT(X))AVB(RIGHT(X))

+

p ( X ) A V B ( L E F T ( X ) ) . (1

-

AVB( R I G H T ( X ) ) ) + p ( X ) ( 1 - A V B ( L E F T ( X ) ) ) . A V B ( R I G H T ( X ) )

+

( 1 - p ( X ) ) A V B ( L E F T ( X ) )

.

A V B ( R I G H T ( X ) ) . (1)

Let AVB(ni1) = 0, (1) is valid for any nonleaf node X. (1) can be written as following formulas:

Let Ai = A V B ( L E F T ( X ) ) and A, = A V B ( R I G H T ( X ) ) , A V B ( X ) = p ( X ) ( l - (1 - A i ) ( 1 - A , ) )

+

(1 - p ( X ) ) A r A r = A i ( l - (1 - p ( X ) ) ( l - A r ) )

+

(1 - Ai )p(X)Ar

+

(1 - A T ) p ( X ) A i . (2) = A T ( l - ( 1 - p ( X ) ) ( l - A i ) )

111. REFINEMENT ALGORITHM FOR BINARY TREES Let X be the root of a binary tree attached with left and right subtrees rooted L and

R,

respectively. We can compute AC'B(X)

from p ( X ) , A V B ( L ) , A V B ( R ) by (1).

Table I shows threes examples, which give us the motivation of refinement. In all cases, A V B ( L ) = A V B ( R ) = 0.75 (the subtrees rooted at L and R consist of one or more nodes). In cases 1, 2 and 3, p ( X ) = 0.89, 0.90 and 0.91, respectively. By ( l ) , A V B ( X ) = 0.8963, 0.9000 and 0.9038, respectively. In case 1, A V B ( X ) is higher than p ( X ) , A V B ( L ) and A V B ( R ) . That is, the availability of the whole tree is higher than any of the three parts: root, left subtree and right subtree. In case 2, A V B ( X ) = p ( X ) , i.e., the availability of the whole tree is equivalent to a single node (the root). The availability of the tree dose not increase but the cost increases. It is worse in case 3 that A V B ( X )

<

p ( X ) . The availability of the whole tree is even lower than a single node (the root). In cases 2 and 3, a larger tree structure does not increase the availability but increase the cost. It is better to eliminate the subtrees to reduce the communication cost since the availabilities are not greater than the original.

Let { a l , a2, a 3 } = { p ( X ) , A V B ( L E F T ( X ) ) , AVB(RIGHT (X))} such that a l

2

a2

2

a 3 , by (2),

A V B ( X ) = a l ( l - ( 1 - ~ 2 ) ( 1 - a 3 ) )

+

(1 - a 1 ) ~ 2 a g . (3)

From (3), A V B ( X )

>

a l if and only if the following condition is satisfied

( 1 - al)a2a3

>

a l ( 1 - a2)(1 - a 3 )

(4)

Condition

(4)

recommends that if ( l - a l ) a 2 a 3

5

a ~ ( l - a 2 ) ( l - a 3 ) , it is better to eliminate the nodes or subtrees corresponding to a2 and

a3, and replace the tree with the node or subtree corresponding to a l . The idea can be used to refine a tree to improve its performance. For example, if a2 = a3 = 0.75, as the cases in Table I, A V B ( X )

5

a1

when a1

2

0.9.

Fig. 1 is an example of refinement. The original tree and final refined tree are shown in Fig. l(a) and (c), respectively. Fig. l(b) shows a partial refinement of the original tree (partially refined tree). The original tree rooted at A is attached with left and subtrees rooted at B and C , respectively. Node B has children D , E and

660 IEEE TRANSACTIONS ON PARALLEL AND DISTRIBUTED SYSTEMS, VOL. 6, NO. 6, JUNE 1995 D E F G (a) A / \

p’

D E (b) B D E (C)

Fig. 1. Refinement example 1.

node C has children F, G. In the original tree, A V B ( B ) is higher than p ( B ) , A V B ( D ) and A V B ( E ) . On the other hand, A V B ( C )

is lower than p ( C ) . Thus it is better to eliminate nodes F and G

so that A V B ( C ) = p ( C ) . This (partial) refinement is shown in Fig. l(b).

In the partially refined tree, A V B ( A )

<

A V B ( B ) . Thus it is better to replace the tree with the subtree rooted at B , i.e., the subtree tree rooted at

B

becomes the refined tree.

The number of nodes of the trees in Fig. l(a)-(c) are 7, 5 and 3, respectively. The availability of the trees in Fig. I(a)-(c) are 0.9629, 0.9666 and 0.972, respectively. The refined tree has higher availability, less number of nodes and thus lower communication cost than the original.

Fig. 2 is another example of refinement. The tree in Fig. 2(b) is refined (partially) from the tree in Fig. 2(a) and the tree in Fig. 2(c) is refined from the tree in Fig. 2(b). As the example in Fig. 1, the refined tree has higher availability and less number of nodes compared to the original.

The refinement examples in Figs. 1 and 2 recommends that it is not necessary to construct the logical tree using all the sites in the system.

The refinement algorithm for a given binary tree rooted at X is presented in Fig. 3. Giving a logical tree, the refinement algorithm visits the nodes of the tree (recursively) from left to right subtrees and then the root (that is in postordering) and reconstructs it, if necessary, by eliminating the nodes or subtrees that do not increase the availability of the tree.

Fig. 2. Refinement example 2.

Lemma 1: AV B ( X ) is an increasing function of al , a2, a3. Pro08 Let { i l , G , i ~ } = {1,2,3}, from (I),

A V B ( X ) = a Z l ( a , , a , ,

+

a t z ( l

-

a z 3 )

+

( 1 - a z 2 ) a z 3 )

= a , , ( a , , ( l - a t , )

+

( 1

-

a z 2 ) a t 3 ) + a 2 , a Z 3

+

( 1 - a 1 1 ) a 1 2 a 1 3

which is an increasing function of a z l . Since i l can be any- one in { 1 , 2 , 3 } , thus A V B ( X ) is an increasing function of

a l , a z , a 3 . Q.E.D.

Theorem 1: The availability of a binary tree after refinement by algorithm REFINE is not less than the original.

Pro08 For any node X in the binary tree, let X’ =

R E F I N E ( X ) . We show, by induction, that A V B ( X ’ )

2

A V B ( X ) ,

1) Induction Basis: If X is a leaf node, A V B ( X ’ ) = A V B ( X ) = 2) Induction Hypothesis: If X is a nonleaf node attached with left

and right subtrees rooted at L and R , respectively. Let L’ =

R E F I N E ( L ) and R‘ = R E F I N E ( R ) . The hypothesis of the induction is that A V B ( L ‘ )

2

A V B ( L ) and A V B ( R ’ )

2

A V B ( R ) .

3 ) Induction Step: Note a node will not be refined till its both subtrees have been refined. Let A V B ( X ) be the availability of the subtree rooted at X attached with, and

R

(i.e. before L and R have been refined). Let A V B ( X ) be the availability of the subtree rooted at X attached with L‘ and R‘ (i.e., after L and R have been refined). According to Lemma 1 and the hypothesis of the induction, A V B ( X )

2

A V B ( X ) .

Let a1 ~ be the maximum in { p ( X ) , A V B ( L ’ ) , A V B ( R ’ ) } . If

A V B ( X )

>

a l , X is returned with L’ and R‘ still attached to

X ; otherwise, the node or subtree corresponding to a l is returned

IEEE TRANSACTIONS ON PARALLEL AND DISTRIBUTED SYSTEMS, VOL. 6, NO. 6, JUNE 1995 66 1

TABLE 111

COMPARISON FOR THE ORIGINAL AND REFINED TREES

Algorithm REFIN E( X) begin

if X = nil then return(X) L = REFINE(LEFT(X)) R = REFINE(RIGXT(X)) ma+ = X AVE(X) = p(X) if L

#

nil AI = AVE(L)

if AI > AVB(maz) then maz = L else

AI = 0 endif if R

#

nil

A, = AVE(R)

if A, > AVE(maz) then maz = R A, = 0

else endif

au = p(X)(1- (1 - Ai)@ -A,))

+

(1 -P(X))AIAR if au > AVE(maz) AVE(X) = au return(X) LEFT(X) = nil RIGHT(X) = nil return(maz) else endif end (REFINE) Fig. 3. Refinement algorithm.

and the others are deleted. Let X ’ = R E F I N E ( X ) . then

A V B ( X ’ )

2

AF’B(2)

2

A V B ( X ) . Q.E.D.

IV. NUMERICAL RESULTS

In this section, we show several numerical results of the refinement algorithm. The comparison is based on full binary trees of depth 4. We

choose full binary trees since the definition is well known. Otherwise, n - 1 links or an n x n matrix is required to describe an arbitrary tree of n nodes. We choose depth 4 because depth 3 is too small and depth 5 is too large for demonstration.

The availabilities of nodes, shown in Table 11, are generated randomly. The values are sequentially assigned to the nodes, starting with the root (level I ) , then nodes on level 2 and so on. Nodes on any level are assigned from left to right.

We compare the refined tree with the original tree for the avail- ability and the number of nodes of the trees. The results are shown in Table 111. In each case, ‘node saving’ shows the cost saved compared to the original. Note that, in cases I and J , there are nodes having availabilities <0.5 and the availability improvements are more significant than the other cases. The reason is that if a3

5

0.5, condition (4) is always not satisfied. It is shown that the refinement algorithm can significantly reduce the cost as well as increase the availability. Thus the refined tree performs better than the original.

V. A N EXTENSION FOR ARBITRARY TREES

In this section, an extended refinement algorithm is briefly de- scribed for arbitrary trees. For an arbitrary tree, a tree quorum (recursively) consists of

1) the root and a tree quorum of any subtree, or 2) tree quorums of all subtrees.

For a nonleaf node X having subtrees rooted at c1, CZ, . .

.

, C,

,

the availability of the subtree rooted at X can be computed by the following formula:

662 IEEE TRANSACTIONS ON PARALLEL AND DISTRIBUTED SYSTEMS, VOL. 6, NO. 6, JUNE 1995

Let a1 be the maximum in { p ( X ) , A V B ( C l ) , A V B ( C 2 ) , . . . , AVB(C,)}, the refinement algorithm can be extended in such a way that if A V B ( X )

5

a1 then the node or subtree corresponding to a1 is returned (and the others are deleted); otherwise

X

is returned with all subtrees still attached to X. An extended version of Theorem 1 for arbitrary trees can be proved in a similar way.

VI. CONCLUSIONS

A central controller can be used to solve distributed mutual exclusion. The drawback is that it is vulnerable to site failure. When the controller fails, the entire system halts. Using more than one sites to participate the decision making may reduce the probability that the system is halted. However, the communication cost usually increases as the number of participating sites increases. In general, increasing availability and reducing cost are two conflicting goals, i.e., a system with higher availability usually has higher communication cost compared to a system with lower availability. Can we reduce the communication cost while the availability dose not decrease? We find out that the answer is positive for the tree quorum algorithm.

In this paper, a refinement algorithm is proposed to refine a logical tree structure by eliminating the nodes or subtrees that do not increase the availability. Giving a tree, the refinement algorithm can reduce the number of nodes of the tree while the availability of the refined tree is not less than the original. Reducing the number of nodes can reduce the communication cost and the cost of maintaining the tree. Thus, the refined tree is preferred because it can significantly save the cost of communication and maintenance.

ACKNOWLEDGMENT

The authors would like to thank the anonymous referees for their helpful comments, which contributed to the quality of this paper significantly.

REFERENCES

D. Agrawal and A. El Abbadi, “An efficient and fault-tolerant solution for distributed mutual exclusion,” ACM Trans. Comput. Syst., vol. 9, no. I , pp. 1-20, 1991.

H. Garcia-Molina and D. Barbara, “How to assign votes in a distributed system,’’ J. ACM, vol. 32, no. 4, pp. 841-860, 1985.

T. Ibaraki and T. Kameda, “A theory of coteries: Mutual exclusion in distributed systems,” IEEE Trans. Parallel Distrib. Syst., vol. 4, pp. M. Maekawa, “A algorithm for mutual exclusion in decentralized systems,” ACM Trans. Comput. Syst., vol. 3, no. 2, pp. 145-159, 1985. M. L. Nelisen and M. Mizuno, “Coterie join algorithm,” IEEE Trans. Parallel Distrib. Syst., vol. 3, pp. 582-590, 1992.

M. Raynal, Algorithms for Mutual Exclusion. Cambridge, MA: M.I.T., 1986.

-, “A simple taxonomy for distributed mutual exclusion algorithms,” Oper. Syst. Rev., vol. 25, no. 2, pp. 47-50, 1991.

G. Ricart and A. K. Agrawala, “An optimal algorithm for mutual exclusion in computer networks,” Commun. ACM, vol. 5, no. 3, pp. 284299, 1987.

B. A. Sanders, “The information structure of distributed mutual exclu- sion algorithms,” ACM Trans. Comput. Sysr., vol. 24, no. 1, pp. 9-17, 1981.

I. Suzuki and T. Kasami, “A distributed mutual exclusion algorithm,” ACM Trans. Comput. Syst., vol. 5, no. 3, pp. 284-299, 1987. R. H. Thomas, “A majority consensus approach to concurrency control for multiple copy databases,” ACM Trans. Database Syst., vol. 4, no. 2, pp. 180-209, 1979.

779-794, 1993.
