Improving Performance of InGaN/GaN Light-Emitting Diodes

and GaAs Solar Cells Using Luminescent Gold Nanoclusters

M. D. Yang,

1, 2

_{S. W. Wu,}

1

_{G. W. Shu,}

1

_{J. S. Wang,}

1

_{J. L. Shen,}

1

_{C. H. Wu,}

2

_{C. A. J. Lin,}

3

W. H. Chang,

3

_{T. Y. Lin,}

4

_{T. C. Lu,}

5

_{and H. C. Kuo}

5

1_{Department of Physics, Center for Nanotechnology, Chung Yuan Christian University (cycu), Chung-Li 32023, Taiwan}

2_{Institute of Nuclear Energy Research, P.O. Box 3-11, Lungtan 32546, Taiwan}

3_{Department of Biomedical Engineering, Chung Yuan Christian University, Chung-Li 32023, Taiwan}

4_{Institute of Optoelectronic Sciences, National Taiwan Ocean University, Keelung 20224, Taiwan}

5_{Department of Photonics and Institute of Electro-Optical Engineering, National Chiao-Tung University, Hsin-Chu 30010, Taiwan}

Correspondence should be addressed to J. L. Shen,[email protected]

Received 20 January 2009; Accepted 26 August 2009 Recommended by Ching Ping Wong

We studied the optoelectronic properties of the InGaN/GaN multiple-quantum-well light emitting diodes (LEDs) and single-junction GaAs solar cells by introducing the luminescent Au nanoclusters. The electroluminescence intensity for InGaN/GaN LEDs increases after incorporation of the luminescent Au nanoclusters. An increase of 15.4% in energy conversion eﬃciency is obtained for the GaAs solar cells in which the luminescent Au nanoclusters have been incorporated. We suggest that the increased light coupling due to radiative scattering from nanoclusters is responsible for improving the performance of the LEDs and solar cells.

Copyright © 2009 M. D. Yang et al. This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

1. Introduction

The optical properties of metal nanoparticles are of great fundamental and technological interest due to the strong surface plasmon resonance in the visible region. Metal nanoparticles play an important role in mediating nonlin-ear processes such as surface enhanced Raman scattering, increasing the outcoupling of light from diodes, and enhanc-ing the photovoltaic conversion eﬃciency of solar cells [1–

7]. One explanation of the observed enhancement eﬀects

is the resonant light absorption in the metal nanoparticles, which may be caused by local plasmon excitation and interband transitions in the metal nanoparticles [8]. The use of enhancement eﬀects for improving the performance of optoelectronic devices, such as light emitting diodes (LEDs), solar cells, and photodectors, is very promising. It has been reported that Au nanoparticles on Si pn-junction diodes increase the photogenerated current via surface plasmon resonance on nanoparticles [9]. An increase in electroluminescence (EL) and photocurrent has also been

observed by introduction of Ag nanoparticles into silicon-on-insulator LED [4, 5]. Similarly, enhancement of the photovoltaic conversion eﬃciency of silicon solar cells and organic thin-film solar cells using Ag or Au nanoparticles has been demonstrated [6–8].

So far most of the metallic nanoparticles mentioned above have dimensions of particles about 5–100 nm. As the metal particle size decreases further to contain several hundreds down to a few tens of atoms, some special properties begin to form because their electronic bands yield to quantum confinement eﬀects and discrete electronic states develop. The metallic nanoclusters (small nanoparticles) display a strong luminescence from visible to near-infrared range, which may make them useful for applications in light emitting sources, chemical sensing, and biological labeling [10–13]. Recent studies have shown that similar enhancement in surface-enhancement Raman scattering and photoluminescence can be obtained by encapsulating metal nanoclusters [14, 15]. Also, the conversion eﬃciency of multiple-junction solar cells has been demonstrated to

(2)

p-GaN (250 nm) p-contact i-GaN (6 nm)/ i-In0.25Ga0.75N (4 nm) 5 MQWs n-contact n-GaN (3μm) i-GaN Sapphire (a)

n+ _GaAs _0.25_μm ₁_×₁₀19_cm−3_{(Si doped)}

n AI0.5In0.5P 0.06μm 2×1018cm−3(Si doped)

n GaAs 0.1μm 1×1018_cm−3_{(Si doped)}

p GaAs 3μm 2×1017_cm−3_{(Zn doped)} p In0.5Ga0.5P 0.1μm 1×1018cm−3(Zn doped) p GaAs 0.5μm 3×1018_cm−3_{(Zn doped)} p Ge 150μm ≈ ≈ (b)

Figure 1: Schematic cross-section of (a) the InGaN/GaN multiple-quantum-well LEDs and (b) InGaP/InGaAs/Ge solar cells.

increase by using Au nanoclusters [16]. In this paper, we study the influence of the luminescent Au nanoclusters on photovoltaic current-voltage (I-V ) characteristics and EL

of the InGaN/GaN multiple-quantum-well (MQW) LEDs and single-junction GaAs solar cells, respectively. We obtain increases in EL intensity of InGaN/GaN LEDs by two times and in conversion eﬃciency of the GaAs solar cells by 15.4%.

2. Experiment

The InGaN/GaN MQW LEDs employed in this study were grown on c-plane (0001) sapphire substrates with metal organic chemical vapor deposition. A nucleation GaN layer was first grown at the substrate, followed by a 3μ-m thick

n-type GaN. The active layers consist of 5 periods of MQWs with 4-nm-thick InGaN wells and 6-nm-thick GaN barriers. Finally, the MQWs were capped with a 250-nm-thick p-GaN layer. The GaAs solar cells were grown by MOCVD on p-type Ge substrates. The GaAs and InGaP buﬀer layers were first grown at the substrate, followed by a 3μm thick

p-type GaAs base layer, 100 nm n-p-type emitter layer, 60 nm AlInP window layer, and 250 nm GaAs contact layer. The schematics of the InGaN/GaN MQW LED and GaAs solar cell are shown in Figures 1(a) and1(b), respectively. The luminescent Au nanoclusters investigated were prepared according to a modified Peng reaction [17]. In brief, the gold precursor solution was prepared by dissolving AuCl3 in the

Didodecyldimethylammonium bromide (DDAB) solution. Decanoic acid was then combined with (Tetrabutylammo-nium borohydride) (TBAB) in toluence, followed by the gold precursor solution. The reduction of Au ions was realized quickly under vigorous stirring, leading to the formation of a dark-red Au colloid. The Au nanoclusters were further fragmented by adding the gold precursor solution and dodecanethiol (DDT) in toluene, leading to formation

10 nm In te nsit y (a.u.) 1.5 1.8 2.1 2.4 Energy (eV)

Figure 2: High-resolution transmission electron microscopy (HRTEM) image for the luminescent Au nanoclusters. The inset displays photoluminescence of the luminescent Au nanoclusters at room temperature.

of the luminescent Au nanoclusters. The luminescent Au nanoclusters were deposited onto the LED and solar-cell surfaces by drop casting a solution of nanoclusters, followed by drying at room temperature. In the EL measurements, the output EL intensity from the top side was collected and dispersed by a 0.75 m spectrometer and detected with a photomultiplier tube (PMT).I-V characteristics of the solar

cells were measured with a source meter (Keithley-2400) under simulated AM1.5 irradiation (100 mW/cm2_{) from a}

solar simulator (WACOM, WXS-130S-L2+).

3. Resutls and Discussion

Figure 2 shows the high-resolution transmission electron

(3)

nanoclusters deposited on an electron microscope grid from colloidal solution. A uniform distribution of well-dispersed nanoclusters is seen. The statistics of the size distribution as determined from the previous and other micrographs obtained from diﬀerent regions indicate an average size of 1.9 ± 0.2 nm. The inset of Figure 2 displays the room-temperature photoluminescence spectrum from the lumi-nescent Au nanoclusters with the 350 nm Xe-lamp excitation. A red luminescence between 1.7 and 2.1 eV is observed with a prominent peak at 1.9 eV. The luminescence from the metal nanoclusters could be viewed as a radiative recombination from an excited-state highest occupied molecular orbital (HOMO) lowest unoccupied molecular orbital (LUMO) transition or the Fermi level electrons to occupied d-band holes [18,19].

Figure 3shows theI-V characteristics of the LEDs before

(close triangles) and after (open squares) deposition of the luminescent Au nanoclusters. Basically, the forward and revised I-V characteristics of the two curves are almost

identical. Nearly zero current in the reverse-biased voltage range reveals that the leakage currents in our LEDs are low. The threshold voltages of the two I-V curves are similar;

whereas the slope of theI-V curve is steeper for the LEDs

after introduction of the luminescent Au nanoclusters. The increase of slope in theI-V curve corresponds to a reduction

in the series resistance, which is one of the factors that can determine the quality of the LED performance. To extract the series resistance of the LED, the slope of theI-V curves was

fitted by the diode equation

I=I0 exp q(V−RS) nkT , (1)

wheren is the ideality factor, k the Boltzmann constant, T

the absorption temperature,Rs the series resistance, andq

the electronic charge. By using (1), current (I) can be plotted

as a function of voltage (V ) as shown in the solid lines

of Figure 3. From the fits, Rs of the LED before and after

depositing the luminescent Au nanoclusters was found to be 41 and 35Ω, respectively, corresponding to an reduction in series resistance of 14.6%. We suggest that the reduction of series resistance in the LEDs with nanoclusters is due to the effect of surface band bending. For the Au nanocrystals passivated by thiol ligands, the outer part (the ligand) of luminescent Au nanoclusters is negatively charged originated from the charge transfer from the outmost gold atoms to the surrounding adsorbed sulfur atoms [20]. The surrounding negative charge of Au nanoclusters can lead to a decrease of the built-in potential on the GaN surface for carriers flow to the metal [21]. Thus, the decrease of series resistance in LED could be due to the effect of the surface band bending. This effect also produces a change of EL energy, which will be discussed later.

Figure 4shows the EL spectra of LEDs before (the open

squares) and after (the solid line) the deposition of the lumi-nescent Au nanoclusters onto the surface of LEDs. There is a main EL peak at around 2.82 eV for the LEDs without depo-sition, corresponding to the emission from the InGaN wells. The EL peak slightly shifts toward higher energy region after

0 5 10 15 20 Cu rr en t (m A ) −2 0 2 4 Voltage (V) Without deposition With deposition

Figure 3: I-V characteristics of the InGaN/GaN

multiple-quantum-well LEDs without (closed triangles) and with (open squares) deposition of the luminescent Au nanoclusters. The solid lines display the calculated I using (1).

0 1 2 In te nsit y (a.u.) 2.6 2.8 3 Energy (eV) Without deposition With deposition

Figure 4: Electroluminescence spectra of InGaN/GaN multiple-quantum-well LEDs without (open squares) and with (solid line) deposition of the luminescent Au nanoclusters.

deposition of the luminescent Au nanoclusters. The blue shift of EL can be explained by the eﬀect of surface band bending mentioned above. For wurtzite nitride semiconductors, the strong polarization fields produce the built-in electrostatic fields parallel to the polar c axis of [0001] oriented (Al, Ga, In)N heterostructures. These electrostatic fields tend to bend the energy band structure of quantum wells, resulting in a redshift of transition energies (quantum-confined Stark eﬀect) [22]. It has been reported that Au nanoparticles have a great influence on the surface potential of p-GaN [21]. We suggest that the luminescent Au nanoclusters reduce the surface band bending, leading to a decrease of the built-in electrostatic fields and a blueshift of EL peak, as shown

(4)

inFigure 4. The EL intensity from LEDs with deposition of clusters shows more than two times enhancement compared to that from LEDs without the luminescent Au nanoclusters. The above results (the decrease in series resistance and the enhanced EL intensity) demonstrate that performance of the LEDs can be eﬀectively improved by introduction of the luminescent Au nanoclusters.

Recently, the enhancement of the luminescence intensity for incorporation of metal nanoparticles has been related to a coupling of light to metal nanoparticles, caused by local plasmon excitation and interband transitions in the metal nanoparticles [3–5]. We suggest that the EL enhancement

in Figure 4 can be interpreted by the increased scattering

cross-section for light exciting Au nanoclusters, leading to the enhanced outcoupling of light from LEDs. For small particles with diameters well below the wavelength of light, the radiative scattering eﬃciency can be estimated from the absorption and scattering cross-sectionsCabsandCradof the individual particles [23]: Csca= 1 2π ω c 4 |α|2_, _Cabs₌ω cIm [α], (2)

whereα is the polarizability of the particle, determined by

α=3V ε(ω)/εm−1 ε(ω)/εm+ 2 , (3)

for a small spherical particle in vacuum, whereV is the the

particle volume.ε(ω) is the dielectric function of the metal

nanoclusters.εmis the dielectric function of the embedding medium. The radiative scattering eﬃciency Qrad, given by

[23]

Qrad= Csca

Csca+Cabs, (4)

represents the fraction of the extincted energy that is reradiated. According to the above Mie scattering theory,

Qradwas obtained to be 2.2, which agrees well with the EL enhancement (∼2.1) inFigure 4. The EL enhancement can thus be interpreted by the increased light scattering from Au nanoclusters.

Figure 5displays the photovoltaicI-V characteristics of

the GaAs single junction solar cells were measured under AM 1.5 solar illumination at an intensity of 100 mW/cm2

with a WACOM (WXS-130S-L2+) solar simulator. The dashed (solid) line represents the data without (with) deposition of the luminescent Au nanoclusters. The open-circuit voltage (VOC) of GaAs solar cells was almost identical after depositing the luminescent Au nanoclusters. On the other hand, the incorporation of the Au nanoclusters yields a 14% increase in short-circuit current (ISC) for the GaAs solar cells. This observation indicates that the absorption of the incident light in the active layers is enhanced, resulting in an increased photocurrent. The introduction of the luminescent Au nanoclusters may produce an increase of light scattering into the active layers in the solar cells, leading to the absor-ption enhancement of the incident light [16].

0 2 4 6 Cu rr en t (m A ) 0 0.3 0.6 0.9 Voltage (V) Without deposition With deposition

Figure 5: Photovoltaic I-V characteristics of the single-junction

GaAs solar cells without (dashed line) and with (solid line) deposition of the luminescent Au nanoclusters under AM 1.5 solar illumination.

Table 1: Photovoltaic I-V results of the GaAs single-junction solar cells without and with incorporation of the luminescent Au nanoclusters.VOCis the open-circuit voltage,ISCis the short-circuit

current,FF is fill factor , and η is conversion eﬃciency.

Sample Voc(V) Isc(mA) FF η (%)

Untreated 0.99 5.72 0.73 16.2

With Au nanoclusters 0.99 6.52 0.74 18.7

Conversion eﬃciency η of solar cells fromFigure 5was calculated according to the following equation:

η=VOC×ISC×FF

P , (5)

whereP is the incident light intensity, and fill factor (FF) is

calculated by using the following equation:

FF=(V×I)max

(VOC×I), (6)

whereI is the photocurrent. The obtained device parameters

for the GaAs solar cell without (with) the luminescent Au nanoclusters on the cell surface are shown in Table 1. The incorporation of the luminescent Au nanoclusters yields a 13.9% (from 5.72 to 6.52 mA) increase in short-circuit current for the GaAs solar cells. From this result, the increase of ISC leads to a 15.4% increase in energy conversion efficiency (η from 16.2 to 18.7%) for the GaAs solar cells. To our knowledge, an increase of 15.4% in energy conversion efficiency is better than the previous reports on similar increase in energy conversion efficiency by using the large-size metallic nanoparticles [6,7]. The increase of conversion efficiency can also be explained by the effect of light scattering from nanoclusters on GaAs surface. We deduce that the absorption of the incident light in the

(5)

absorbing layers of solar cells is enhanced due to enhanced light scattering by the luminescent Au nanoclusters. The observed increase in energy conversion eﬃciency in solar cells is thus caused by the enhanced light absorption in the absorbing layer.

4. Summary

The current-voltage characteristics and EL of the InGaN/ GaN MQW LEDs with the luminescent Au nanoclusters on the LED surface were investigated. The EL intensity and slope of theI-V curve were found to increase after incorporation

of the luminescent Au nanoclusters. In addition, a 13.9% increase in short-circuit current and a 15.4% increase in energy conversion eﬃciency (from 16.2 to 18.7%) are obtained for the GaAs solar cells where the luminescent Au nanoclusters have been incorporated. We suggest that the increase of EL intensity EL of the InGaN/GaN MQW LEDs and improvement of energy conversion eﬃciency in the InGaP solar cells are due to the increased radiative scattering by introducing the luminescent Au nanoclusters.

Acknowledgments

This project was supported in part by the National Science Council under Grant nos. NSC97-2112-M-033-004-MY3, and NSC 97-2627-B-033-002 and by the Institute of Nuclear Energy Research under Grant no. 962001INER0041.
