Synthesis, modification, and characterization of hyperbranched

poly(ether ketones)

C.-F. Shu*, C.-M. Leu, F.-Y. Huang

Department of Applied Chemistry, National Chiao Tung University, Hsin-Chu 30035, Taiwan Received 30 September 1998; received in revised form 4 December 1998; accepted 21 December 1998

Abstract

This report presents the synthesis and chemical modification of hyperbranched poly(ether ketones). The polymer was conveniently prepared by direct polycondensation of an AB2monomer, 3,5-diphenoxybenzoic acid, using phosphorus pentoxide/methanesulfonic acid

(PPMA) as the condensing agent and solvent. The hyperbranched poly(ether ketone) could be modified via the electrophilic aromatic substitution of the active phenoxy groups at the chain ends with a variety of carboxylic acids. The thermal properties of the hyperbranched poly(ether ketones) depend heavily on the nature of the chain end, with glass transition temperature ranging from 2 248C to 1808C. Moreover, the length of the terminal alkyl groups significantly influences the solubility of the hyperbranched poly(ether ketones). By varying the chain ends, hyperbranched poly(ether ketones) soluble in either a polar or nonpolar solvent could be obtained.q 1999 Elsevier Science Ltd. All rights reserved.

Keywords: Electrophilic aromatic substitution; Glass transition temperature; Hyperbranched poly(ether ketone)

1. Introduction

In recent years, nonlinear polymers such as dendritic or hyperbranched macromolecules have attracted considerable attention owing to the potential new properties of their highly branched, highly functionalized, three-dimension globular structure [1,2]. Dendrimers which have a well-defined and perfectly branching structure are built up by either a stepwise divergent or a convergent approach [3– 6]. The sequential synthetic scheme frequently involves isolating and purifying the product at every step of the growth process, thereby limiting the large scale preparation. As an alternative, hyperbranched polymers are prepared by a one-step polymerization process that yields a highly branched, irregular structure. Although having a less perfect structure than dendrimers, hyperbranched polymers still maintain many of the architectural features found in their more perfectly defined dendritic counterparts and are supposed to exhibit properties resembling those of dendritic ones [7].

The one-step synthesis allows hyperbranched polymers to be more readily available and prepared on a large scale for potential applications. This attractive feature has led to the

development of novel synthetic routes for the preparation of hyperbranched polymers [8–36], especially the one-step synthesis based on AB2monomers which have A and 2B

functional groups located at 1, 3, 5 positions of a benzene ring. This report concerns the use of an AB2monomer,

3,5-diphenyoxybenzoic acid, in the one-step preparation of a hyperbranched poly(ether ketone). Two methods were used to prepare traditional linear poly(ether ketones) [37, 38]. The first method is a synthesis involving nucleophilic aromatic substitution, resulting in the formation of an aryl ether linkage. The second method is a synthesis involving electrophilic aromatic substitution in which an aryl ketone linkage is obtained. The nucleophilic reaction was applied to synthesise hyperbranched/dendritic poly(ether ketones) using AB2monomers containing a phenolic group and two

aryl fluorides which were activated toward nucleophilic displacement by carbonyl moieties [16,35,39]. The synthetic procedure used herein is derived from the electro-philic substitution reaction developed by Ueda to prepare linear aromatic poly(ether ketones) [40–42]. In this proce-dure, the polymeric aryl ketone linkages are formed via direct self-polycondensation of the substituted benzoic acid containing phenyl ether structures using a mixture of phosphorus pentoxide/methanesulfonic acid (PPMA) as the condensing agent and solvent [40–43]. This one-step synth-esis leads to the formation of a hyperbranched poly(ether ketone). This polymer could be derivatized by reacting the

* Corresponding author. Tel.: 71212156544; fax: 00886-35-723764.

(2)

terminal phenoxy groups with various carboxylic acids. The physical properties of these hyperbranched poly(ether ketones) are investigated, along with the effect of changes in the nature of the chain ends which are evaluated as well.

2. Experimental section 2.1. General directions

The reagent PPMA (Eaton’s reagent) was obtained from Aldrich and used as received. Other starting materials and reagents were used as obtained from the suppliers. Nuclear magnetic resonance (NMR) spectra were recorded on a Varian Unity 300 MHz spectrometer. Differential scanning calorimetry (DSC) was performed on a SEIKO SSC 5200 DSC using a heating/cooling rate of 108C min21. Thermo-gravimetric analysis (TGA) was made on a SEIKO TG/ DTA 200 using a heating rate of 108C min21in nitrogen. Size-exclusion chromatography (SEC) was carried out on a Waters chromatography connected to a waters 410 differ-ential refractometer with DMF as the solvent. UV–VIS absorption spectra were taken on a HP 8453 UV/VIS spec-trometer. Infrared spectra were recorded on a Nicolet 520 FTIR spectrometer. Mass spectra were obtained on a JEOL JMS-HX 110 with EI ionization. Analytical TLC was performed on commercial Merck plate coated with silica gel GF254. Silica gel for column chromatography was Merck kieselgel 60 (70–230 mesh).

2.2. 1-Methyl-3,5-diphenoxybenzene (1) 2.2.1. Method A

A mixture of phenol (9.04 g, 96.1 mmol), KOH (4.4 g, 80.0 mmol), and toluene (6 ml) was stirred at 1458C for 4 h with water being collected in a Dean–Stark trap. Excess phenol and water were then removed under reduced pres-sure at 1608C for 2 h. To the dry salt was added copper powder (0.1 g), 3,5-dibromotoluene (2.0 g, 8.0 mmol), and phenol (4 ml). The reaction mixture was stirred under nitro-gen at 2108C for 3 h. The reaction mixture was poured into water (150 ml), and 5 wt.% NaOH aqueous solution was added to dissolve the excess phenol. The mixture was extracted with ethyl acetate (3 × 70 ml). The combined extracts were dried and evaporated to dryness. The crude product was purified by column chromatography, eluting with CH2Cl2/hexane 1 : 2 to give 1 (2.08 g, 94%) as a

color-less liquid.

2.2.2. Method B

A mixture of 5-methylresorcinol (10 g, 80.6 mmol), KOH (9.04 g, 161.1 mmol), and toluene (150 ml) was stirred at 1458C for 4 h with water being collected in a Dean–Stark trap. The solvent and water were then removed under reduced pressure at 1608C for 2 h. To the dry salt was added bromobenzene (63 g, 400 mmol), CuCl (3 g), and pyridine (160 ml). The mixture was stirred under nitrogen

at 1408C for 15 h. The reaction mixture was poured into water (500 ml), acidified with 4 N HClaq, and extracted

with ethyl acetate (3 × 250 ml). The combined extracts were dried and evaporated to dryness. The crude product was purified by column chromatography, eluting with CH2Cl2/hexane 1 : 2 to give 1 (15.81 g, 71%). 1H NMR

(CDCl3) d 2.26 (s, 3 H), 6.48 (t, 1 H, J 2.4 Hz), 6.53

(d, 2 H, J 2.4 Hz), 7.01 (d, 4 H, J 8.4 Hz), 7.09 (t, 2 H, J 7.2 Hz), 7.32 (dd, 4 H, J 8.4, 7.2 Hz);13C NMR (CDCl3)d 21.5, 106.5, 114.0, 119.1, 123.4, 129.7, 141.0,

156.8, 158.4; MS(m/e) 276.1150, calcd. 276.1150 for C19

H16O2.

2.3. 3,5-Diphenoxybenzoic acid (2)

To a mixture of 1 (12.0 g, 43.4 mmol), water (6 ml), and pyridine (160 ml) heated at 1008C, KMnO4 (68 g, 0.43 mmol) was added in small portions over 6 h. The reac-tion mixture was stirred at 1208C for 36 h. The manganese dioxide was filtered and extracted with hot water, and the filtrate was acidified with 4 N HCl(aq). The product was

collected by filtration and purified by column chromatogra-phy, eluting with CHCl3 and then ethyl acetate to give 2

(10.65 g, 80%).1H NMR (D6-DMSO)d 6.90 (t, 1 H, J 2.4 Hz), 7.10 (d, 4 H, J 8.4 Hz), 7.12 (d, 2 H, J 2.4 Hz), 7.21 (t, 2 H, J 7.2 Hz), 7.44 (dd, 4 H, J 8.4, 7.2 Hz), 13.29 (br, 1 H); 13C NMR (D6-DMSO) d 112.1, 112.4, 119.7, 124.6, 130.3, 133.8, 155.4, 158.7, 166.1; MS (m/e) 306.0870, calcd. 306.0892 for C19H14O4. 2.4. Methyl 3,5-diphenoxybenzoate (3)

A mixture of 2 (0.15 g, 0.49 mmol), methanol (4 ml) and concentrated H2SO4 (0.2 ml) was heated at reflux for 3 h.

The reaction mixture was poured into water (150 ml), neutralized with aqueous sodium bicarbonate solution, and extracted with ethyl acetate (3 × 30 ml). The combined extracts were dried and evaporated to dryness to give 3 (0.152 g, 97%).1H NMR (CDCl3)d 3.83 (s, 3 H), 6.86 (t, 1 H, J 2.1 Hz), 7.02 (d, 4 H, J 8.7 Hz), 7.13 (t, 2 H, J  7.8 Hz), 7.34 (d, 2 H, J 2.1 Hz), 7.35 (dd, 4 H, J 8.7, 7.8 Hz); 13C NMR (CDCl3) d 52.3, 113.3, 113.8, 119.3, 124.0, 129.9, 132.7, 156.1, 158.7, 166.0; MS (m/e) 320.1044, calcd. 320.1049 for C20H16O4. 2.5. Methyl 3,5-di(4-benzoylphenoxy)benzoate (4)

A mixture of 3 (0.2 g, 0.624 mmol), benzoic acid (0.47 g, 3.85 mmol), and PPMA (3.5 ml) was stirred under nitrogen at 808C for 4 h. The reaction mixture was poured into water (200 ml), neutralized with sodium bicarbonate, and extracted with ethyl acetate (3 × 50 ml). The combined extracts were dried over anhydrous sodium sulfate, and evaporated to dryness to give 4 (0.32 g, 97%). 1H NMR (CDCl3) d 3.88 (s, 3 H), 7.02 (t, 1 H, J 2.4 Hz), 7.08

(d, 4 H, J 8.7 Hz), 7.47 (dd, 4 H, J 7.5, 7.2 Hz), 7.53 (d, 2 H, J 2.4 Hz), 7.57 (t, 2 H, J 7.2 Hz), 7.77 (d, 4 H,

(3)

J 7.5 Hz), 7.84 (d, 4 H, J 8.7 Hz);13C NMR (CDCl3)d

52.5, 115.5, 116.1, 117.9, 128.3, 129.8, 132.3, 132.6, 133.0, 133.4, 137.6, 157.3, 160.1, 165.5, 195.3; MS (m/e) 528.1539, calcd. 528.1573 for C34H24O6.

2.6. Preparation of hyperbranched poly(ether ketone) (P1)

A solution of 2 (0.6 g) in PPMA (3.6 ml) was stirred under nitrogen at 908C for 24 h. The reaction mixture was poured into water (200 ml). The polymer was collected, washed with water, and stirred again in water (200 ml) at 708C for 12 h. The polymer was collected and dried in

vacuo. The crude product was purified by precipitating from CH2Cl2into methanol to give P1 (0.5 g, 89%). Anal.

Calcd. for C19H12O3: C, 79.16; H, 4.20. Found: C, 77.70; H,

4.19.

A solution of P1 (0.1 g) and p-toluic acid (0.66 g) in PPMA (3 ml) was heated at 908C for 6 h. The resulting solution was poured into water (300 ml). The precipitate was filtered, and washed with water and methanol, and reprecipitated from DMF into methanol to give P2 (0.12 g, 87%).

A solution of P1 (0.1 g) and 4-n-octylbenzoic acid (0.32 g) in PPMA (3 ml) was heated at 908C for 6 h. The resulting solution was poured into water (300 ml). The precipitate was filtered, and washed with water and metha-nol, and reprecipitated from THF into methanol to give P3 (0.11 g, 62%).

A solution of P1 (0.1 g) and stearic acid (0.47 g) in PPMA (4 ml) was heated at 908C for 6 h. The resulting solution was poured into water (300 ml). The precipitate was filtered and washed with water and acetone. The poly-mer was dissolved in hot toluene (100 ml). The solution was then concentrated to 2 ml, and precipitated into acetone to give P4 (0.12 g, 64%).

3. Results and discussion

3.1. Synthesis and characterization of the hyperbranched poly(ether ketone) (P1)

The AB2 monomer 3,5-diphenoxybenzoic acid, 2, was

prepared by either reacting phenol with 5-dibromotoluene or reacting 5-methylresorcinol with bromobenzene via the Ullmann reaction to form compound 1 [44, 45], followed by oxidation of the methyl group of 1 with KMnO4 [46], as

outlined in Scheme 1. The general procedure developed by Ueda for the preparation of linear aromatic poly(ether ketone)s [40–42] was applied to the one-step polymeriza-tion of the AB2 monomer. The synthesis of poly(ether

ketone) is based on the electrophilic aromatic substitution, in which an aryl ketone linkage is formed by condensing an carboxylic group with an activated phenyl group. In this synthetic procedure, PPMA was used as the condensing agent and solvent [43]. PPMA is expected to react with the carboxylic acid group to yield a highly activated mixed anhydride intermediate between the carboxylic acid and methanesulfonic acid and enable condensation to proceed under rather mild reaction conditions. To demon-strate the feasibility of using this reaction for the formation

Scheme 1.

(4)

of hyperbranched poly(ether ketones), the reaction of benzoic acid with the bis-phenoxy groups of monomer 2 in PPMA was chosen as the model reaction for the poly-merization of 2. The carboxylic group of 2 was initially protected as a methyl ester group to give compound 3, which was then reacted with an excess of benzoic acid. The model reaction proceeded at 808C in PPMA and yielded compound 4 quantitatively after 4 h. In the acylated product

4, the two benzoyl groups were exclusively at the para

position of the bis-phenoxy groups, as analyzed by NMR spectroscopy. The model reaction revealed that the acyla-tion had taken place clearly at the para posiacyla-tion. Based on the model study it seems apparent that the electrophilic aromatic substitution of 2 occurs in the yield and selectivity required for a polymer forming reaction.

The one-step polymerization of 2 was performed in PPMA to give the corresponding hyperbranched poly(ether ketone), P1. The structure of P1 and the general reaction are shown in Scheme 2. The IR spectrum of P1 exhibits char-acteristic absorptions at 1664 and 1212 cm21corresponding to the CyO and C–O–C stretching. As predicted theoreti-cally by Flory [47], the direct polymerization of AB2type

monomers would produce polymers with a highly branched, irregular structure, which prevents close packing and crys-tallization of various polymer segments. The hyperbranched

P1 was found to be highly soluble in a variety of solvents

such as CHCl3, CH2Cl2, THF, DMF, and NMP. The

enhanced solubility of P1 when compared to that of linear

poly(ether ketone)s is consistent with the highly branched structure of P1 and is in agreement with similar results obtained for other hyperbranched macromolecules [35]. Unlike dendritic macromolecules, which are essentially perfectly branched, hyperbranched macromolecules have a much more irregular structure. The concept of the degree of branching was introduced to better define the structure of the hyperbranched polymers [9]. In the AB2systems such as

1,3,5-substituted benzene, the degree of branching deter-mined by NMR is usually about 50%–60% [8,17–19,24]. However, for the hyperbranched poly(ether ketone) P1, the degree of branching could not be determined from its 1H NMR spectrum because the chemical shifts of the aromatic protons were not well resolved for this determination.

The molecular weight of the hyperbranched poly(ether ketone) was determined by SEC analysis in DMF solutions calibrated against poly(ethylene glycol) standards, and used only for a rough estimate. It was noted that SEC measure-ments, in which linear polymer standards were used to determine molecular masses for highly branched polymers, tended to underestimate the true molecular weight of the hyperbranched polymers [48]. The molecular weight of the resulting polymer was sensitive to the reaction time and the reaction temperature. As seen in Table 1, samples with a broad range of molecular weights were prepared. The molecular weight distribution of these poly(ether ketones) is broad, and broader than that of hyperbranched poly(ether ketones) prepared by nucleophilic substitution [35]. As the molecular weight increases, the molecular weight distribu-tion becomes broader. This observadistribu-tion resembles previous reports of other hyperbranched polymers [18,24,32] and is consistent with the predictions of Flory [47].

The glass transition temperature (Tg) of the

hyper-branched poly(ether ketone) was determined by DSC. Tg

of P1, which was observed to increase modestly with mole-cular weight, ranged from 1508C to 1808C, as shown in Table 1. The thermal stability of P1 was examined by TGA. A typical trace for polymer P1 is shown in Fig. 1. The polymer is stable up to 4008C, with a 10% weight loss occurring over 4608C. This result indicates that the thermal

Table 1

Polymerization of 3,5-diphenoxybenzoic acid in PPMA

Temperature (8C) Time (h) Mwa Mna Mw/Mn Tg(8C)

90 6 20 180 4890 4.12 150

90 12 31 990 5750 5.58 159

90 24 59 460 6740 8.82 168

110 6 98 500 7710 12.78 180

a_{SEC in DMF solutions calibrated against poly(ethylene glycol)}

stan-dards.

Fig. 1. TGA thermogram of hyperbranched poly(ether ketone) P1.

(5)

stability of the hyperbranched poly(ether ketone) P1 is comparable to that of the linear analog [40–42].

3.2. Chemical modification of hyperbranched poly(ether ketones) (P1)

Hyperbranched polymers based on AB2 monomers are

characterized by a large number of chain end groups, the number of which is equal to the degree of polymerization plus one. The terminal phenoxy groups in P1 are active toward electrophilic substitution and readily react with carboxylic acids to form aryl ketone linkages. As shown in Scheme 3, alkyl groups with different chain length could be introduced into the terminal positions of P1 by reacting the terminated phenoxy groups with a variety of carboxylic acids using PPMA as the condensing agent and solvent. The degree of functionalization of the derivatized polymers was estimated by comparing1H NMR integration of the alkyl peaks with that of the aromatic peaks. For P2 and P3, the1H NMR analysis showed that the functionali-zation was almost completed ( . 95%), indicating the phenoxy groups at the chain ends of P1 are readily acces-sible to reagents in solution. For P4, 1H NMR analysis in solvents such as CDCl3and THF(D4) revealed an interesting

solution state behavior. The aromatic peaks become obscure owing to the significant broadening of their 1H NMR

resonances and only the resonances associated with the heptadecyl group at the chain ends were observed. This spectroscopic observation may be attributed to the forma-tion of aggregates in soluforma-tion, with the more polar dendritric poly(ether ketone) block likely to be situated at the core and surrounded by the nonpolar, long linear alkyl chains. The aggregation might significantly increase the relaxation times for the aromatic protons of the confined aryl-ether– ketone blocks and lead to the broadening of their 1H NMR resonances. Similarly spectroscopic phenomena was observed in dendritic–linear block copolymers [49]. Further, the ratio of the 1H NMR integration of the alkyl peaks to that of the aromatic peaks is about twice larger than expected if the convertion of the formation of P4 is 100%. This may result from the broadening of1H NMR resonances caused by the aggregation or from the contamination of unreacted stearic acid in P4. Nevertheless, the latter possi-bility can be easily ruled out by DSC experiments. For a sample of P4 mixed with 0.1 equivalent of stearic acid, in addition to the endothermic curve corresponding to the glass transition of the polymer, an endothermic peak arising from the melt of stearic acid was also observed. A sample containing P4 only, however, did not show any melting point in the DSC thermogram. Therefore, we conclude that the smaller than expected integration for the aromatic protons may also be attributed to the broadening of their1H NMR resonances resulting from the aggregation.

It was shown that the nature of the chain ends markedly affects properties such as the glass transition temperature (Tg) and the solubility of hyperbranched polymer (Table

2) [29–36, 50–52]. As shown in Fig. 2, the Tgs determined

by DSC of these poly(ether ketones) heavily depend on the chain length of the terminal alkyl groups, with decreases in

Tgfollowing increases in alkyl chain length. On going from

P1, to an octyl end group, P3, the glass transition

tempera-ture of the hyperbranched poly(ether ketones) drops from 1508C to 168C. A further decrease in Tg to 2 248C is observed for the polymer P4 with heptadecyl end groups. Attempts were made to measure the Tg of P2. However,

between 08C and 3008C, no reliable endotherm correspond-ing to the glass transition of P2 was observed.

As a result of the lack of crystalline packing and complexation of the solvent in the cavities, the hyperbranched poly(ether ketone) has an enhanced

Table 2

Effect of the functionality of the chain ends on the thermal and solution properties of the hyperbranched poly(ether ketones) Polymer Tg(8C) Solubilitya Octane Toluene CH2Cl2 CHCl3 THF DMF NMP P1 150 2 2 1 1 1 1 1 P2 2 2 1 1 1 1 1 P3 16 2 ^ 1 1 1 1 1 P4 2 24 ^ ^ ^ ^ ^ 2 2 a

Solubility:1, soluble; ^, partially soluble; 2, insoluble.

Fig. 2. DSC thermograms of hyperbranched poly(ether ketones) P1, P3 and P4.

(6)

solubility in organic solvents. P1 and P2 are highly soluble in typical solvents such as CH2Cl2, THF, DMF and NMP.

However, the different chain ends led to differences in solu-bility in polar and nonpolar solvents. An increase in the chain length of the terminal alkyl groups implies a reduction in the solubility of the polymer in polar solvents, resulting in a situation in which P4 is insoluble in DMF. Conversely, the linear alkyl chains help impart solubility in nonpolar solvents. Although P1 and P2 are totally insoluble in non-polar solvents, P3 and P4 are soluble in toluene and P4 is partially soluble in octane.

4. Summary

A hyperbranched poly(ether ketone) was conveniently prepared by the self-condensation of an AB2 monomer,

3,5-diphenoxybenzoic acid, using PPMA as the condensing agent and solvent. This one-step synthesis involved electro-philic aromatic substitution, resulting in the formation of the ketone linkage. The phenoxy groups at the chain ends of the hyperbranched poly(ether ketone) are highly reactive for further electrophilic aromatic substitution and readily reacted with various carboxylic acids. In addition, the nature of the chain ends markedly affects the physical properties such as glass transition temperature and solubility of the modified hyperbranched poly(ether ketones). As the length of the terminal alkyl groups increase, the Tg of the

polymer decreases, and the solubility of the polymer in polar solvents is reduced, becoming more soluble in nonpolar solvents.
