IEEE TRANSACTIONS ON SIGNAL PROCESSING, VOL. 48, NO. 2, FEBRUARY 2000 561
A Generalized Output Pruning Algorithm for Matrix-Vector Multiplication and Its Application to
Compute Pruning Discrete Cosine Transform Yuh-Ming Huang, Ja-Ling Wu, and Chi-Lun Chang
Abstract—In this correspondence, a generalized output pruning algo-rithm for matrix-vector multiplication is proposed. It is shown that for a given decomposition of the matrix of the transform kernel and the pruning pattern, the unnecessary operations for computing an output pruning dis-crete cosine transform (DCT) can be eliminated thoroughly by using the proposed algorithm
I. INTRODUCTION
Recently, a lot of one-dimensional (1-D) and two-dimensional (2-D) fast pruning DCT algorithms for computing only the lower frequency components have been proposed in [1]–[3]. However, to the best of our knowledge, no known generalized pruning method can be directly ap-plied to any orthogonal discrete transform (ODT), such as the DCT, the discrete Fourier transform (DFT), the discrete Hartley transform (DHT), etc. In this correspondence, a generalized output pruning al-gorithm for computing matrix-vector multiplication of any order is presented. It is shown that for a given decomposition of the matrix, the unnecessary operations can be eliminated thoroughly. An efficient pruning DCT algorithm can then be derived based on the prescribed pruning algorithm. Of course, the applicability of the proposed output pruning algorithm is not limited to the DCT; actually, it can be applied to all well-known discrete orthogonal transforms, such as the DFT, the DHT, and the discrete sine transform (DST). However, in this work, the pruning DCT algorithm is our only focus.
II. GENERALIZEDOUTPUTPRUNINGALGORITHM FOR MATRIX-VECTORMULTIPLICATION
Consider the operation of a general matrix-vector multiplication of orderN, say, DN = AN2N2 BN, and assume only partial multipli-cation outputsDN[j] (where DN[j] is the jth entry of the vector DN; 1 j N) are required. It follows that we can speed up the afore-cited computation by pruning the unnecessary operations.
To reduce the computational complexity, we decompose the matrix AN2N into a product of a sequence of more-sparse matrices of the same order, that is,AN2N = 5k01i=0 ciN2N: By the associative
prop-erty of matrix-vector multiplication,DNcan be computed recursively as B0 N = BN Bi N = CN2Nk0i 2 BNi01; 1 i k: DN = BkN (1) Since there arek stages of matrix-vector multiplication of order N in (1), no matter what kind of output pruning pattern is,k 2 N bits are required to record whether eachBNi;jhas to be computed or not, where Bi;jN is the inner product of thejth row vector of CN2Nk0i and the output
vectorBNi01of the previous stage.
Manuscript received January 19, 1999; revised June 15, 1999. The associate editor coordinating the review of this paper and approving it for publication was Dr. Xiang-Gen Xia.
Y.-M. Huang is with the Department of Information Engineering, National Chi-Nan University, Puli, Taiwan, R.O.C.
J.-L. Wu and C.-L. Chang are with Department of Computer Science and Information Engineering, National Taiwan University, Taipei, Taiwan, R.O.C.
Publisher Item Identifier S 1053-587X(00)00970-3.
In this section, a more efficient algorithm for computing output-pruning matrix-vector multiplication is presented. In this algorithm, onlydlog(k + 1)e 2 N bits are required to record whether the par-tial resultsBNi;jhas to be computed or not. In other words, we need an array, say,M of order N with each entry of dlog(k + 1)e bits in size, to record which operations are required or unnecessary.
If the computation ofDN[j] is necessary, then initially, let M[j] = 0; otherwise, let M[j] = 255 or a large integer. The final value of each entry ofM will evolve gradually through the computation of CN2N0 to that of theCN2Nk01 and will be precomputed and stored with respect to the characteristics of the concerned matrixCN2Ni described as follows.
A. Encoding Processes
LetT be a control or threshold parameter and its value is set to be zero initially.
1) IfCN2Ni is a permutation matrix, that is, for any vectorVN
of order N, the result of the matrix-vector multiplication Ci
N2N 2 VN is just a position swapping of VN: In this
case, the entries ofM are unchanged in value but permuted according to the inverse permutation matrix(CN2Ni )01;, and the value ofT is unchanged.
2) CN2Ni is a diagonal matrix, that is, all the entries ofCN2Ni are equal to zero except the diagonal components. In this case, the values of each entry ofM and T will be unchanged. 3) CN2Ni is a general diagonal matrix, that is, all the diagonal
components of it are not equal to zero, and no constraint is set to the nondiagonal components. In this case, the value ofT will be increased by one. The value ofT (which is denoted asTt) is used as a threshold for indicating the fact that in the matrix-vector multiplication stage, say,CN2Ni 2 BNk0i01= Bk0i
N , some output entryBNk0i;sis unnecessary (i.e.M[s] = 255), whereas the entry Bk0i01;s
N of the input vectorBNk0i01
is required to compute some output entryBNk0i;r: That is, the sth input entry Bk0i01;s
N has to be computed correctly
be-fore dealing with the matrix-vector multiplicationCN2Ni 2 Bk0i01
N , but after that, thesth output entry BNk0i;sis of no use
for later stages. In other words, ifM[r] < Tt; and M[s] = 255, then we set M[s] = Tt:
4) CN2Ni can be decomposed into a product of a general diagonal matrix and a permutation matrix, or vice versa. In this case, the arrayM will be processed by using the merged methodologies presented in 1) and 3).
5) The other matrix forms that do not belong to those of the above four types are categorized as type 5). Notice that those ma-trices discussed in 1)–3) are special subsets of 4). Hence, by definition, those matrices of type 5) cannot be decomposed into a product of a general diagonal matrix and a permuta-tion matrix. Moreover, according to the following corollary, we will deduce that each matrix of type 5) is a linearly depen-dent matrix.
Corollary 1: If a matrix of sizeN 2 N cannot be decomposed into
a product of a general diagonal matrix and a permutation matrix of the same size, then its determinant is equal to 0.
By corollary 1, we know that for any well-defined discrete transform matrixAN2N, which is linearly independent, it will never be catego-rized as a type 5) matrix.
For the sake of convenience, those sets composed of the matrices discussed in 1)–4) are, respectively, denoted by P, D, GD, and PGD.
As we have obtained the final values for each entry ofM through the computation ofCN2N0 to that of theCN2Nk01 , then with the help ofM, all the unnecessary operations for the computation of CN2N0 2 0018-9219/00$10.00 © 2000 IEEE
562 IEEE TRANSACTIONS ON SIGNAL PROCESSING, VOL. 48, NO. 2, FEBRUARY 2000
TABLE I
NUMBERS OFREQUIREDMULTIPLICATIONS ANDADDITIONS FOR THERESULTANTPRUNINGDCT ALGORITHMS WITHRESPECT TO DIFFERENTMATRIXDECOMPOSITIONS ANDDIFFERENTPRUNINGPATTERNS
C1
N2N21 1 12CN2Nk01 2BNcan be eliminated thoroughly. Let the final
accumulated value ofT be denoted by Tf: This means, among those
matricesCN2Ni 0 i k 0 1, there are Tfmatrices that belong to GD or PGD. In other words, after the matrix decomposition, the value Tf is precomputable.
Now, let us show how the unnecessary operations for the compu-tation ofCN2N0 2 CN2N1 2 1 1 1 2 CN2Nk01 2 BN can be eliminated thoroughly with the aid ofM and T:
B. Decoding Process
First, letT = Tf: The elimination processes for unnecessary opera-tions are deduced gradually through the computation ofCN2Nk01 2 BN
to that of theCN2N0 2 Bk01N :
1) IfCN2Ni 2 P , then the entries of M will be swapped ac-cording to the permutation pattern defined byCN2Ni : 2) IfCN2Ni 2 E, then the jth output BNk0i;jneeds to be
com-puted only whenM[j] T ; otherwise, it can be left out for pruning the unnecessary operations.
3) IfCN2Ni 2 GD, then the jth output BNk0i;jneeds to be com-puted only whenM[j] < T ; otherwise, it can be left out for pruning the unnecessary operations. Furthermore, the value of T will be decreased by one in this case.
4) IfCN2Ni 2 PGD, it follows that CN2Ni can be decomposed into a product of a general diagonal matrixDgand a permuta-tion matrixPp(or vice versa). Then, the entries ofM will be permuted according to thePpfirst, and thejth output BNk0i;j has to be computed only whenM[j] < T ; otherwise, it can be left out for pruning. Of course, the value ofT will also be decreased by one in this case.
The above statements described the detailed procedures of the proposed pruning algorithm. Because the final value ofT , i.e., Tf, will not be greater thank. Only dlog(k + 1)e 2 N bits are required to record the evolution process ofM:
Corollary 2: LetAN2N(= 5k01i=0 CN2Ni ) be a linearly
indepen-dent matrix. From the proposed algorithm, it can be deduced that in the computation ofAN2N2 BN; BN[j] is necessary only when M[j] Tf:
Lemma 1: LetAN2N(= 5k01i=0 CN2Ni ) be a linearly independent
matrix. Then, all the unnecessary operations can be eliminated thor-oughly by the above proposed pruning algorithm.
From Lemma 1, for a linearly independent matrixAN2N, we know that the unnecessary operations can be eliminated thoroughly when only the partial outputs of the matrix-vector multiplicationAN2N 2 BN are required. However, for a special pruning pattern, does there exist another scheme that can be used to further reduce the number of required operations. In the next corollary, we show that the number of required operations cannot be reduced by just utilizing the permutation technique. Moreover, forCN2Ni 2 PGD, the gain of pruning will not be changed even if we apply a different decomposition toCN2Ni : his will be shown in Lemma 2.
Corollary 3: LetAN2N be a linearly independent matrix andPC
be a permutation matrix. For any pruning pattern, on computing of the following expressionsAN2N2 BN; (AN2NPc) (Pc01BN); and Pc(Pc01AN2N)BN, the simplification gains obtained from pruning the unnecessary operations will be the same.
Lemma 2: LetAN2N be a linearly independent matrix. Based on the proposed pruning algorithm, the simplification gain will keep un-changed, even though we apply a different decomposition to the matrix Ci
N2N (2 PGD).
Therefore, more effective decomposition of the matrix AN2N is necessary if we want to obtain better simplification gain.
III. APPLICATION OF THEPROPOSEDOUTPUTPRUNINGALGORITHM TO THECOMPUTATION OFPRUNINGDCT
Since DCT is an orthogonal discrete transform, its transform kernel matrix must be a linearly independent matrix. That is, the pruning algo-rithm presented in Section II can be directly applied to derive efficient pruning DCT algorithms. Moreover, all well-known DCT algorithms (such as [4]–[6]) and pruning DCT algorithms (such as [1]–[3]) can be modeled as a matrix-vector multiplication with known decompositions of the DCT transform kernel matrix.
Since the optimism of the proposed pruning algorithm is decompo-sition dependent, we cannot only derive effective pruning DCT algo-rithms but also compare the effectiveness of matrix decomposition
IEEE TRANSACTIONS ON SIGNAL PROCESSING, VOL. 48, NO. 2, FEBRUARY 2000 563
responding to each existing fast algorithm by checking the complexities of the so-obtained pruning algorithms.
The following data are obtained by applying the proposed output pruning algorithm to derive efficient pruning DCT algorithms, based on the matrix decompositions presented in [1], [5], and [6]. For the 1-D DCT of length 64, Table I lists the numbers of required multipli-cations and additions for the corresponding pruning DCT algorithms with respect to different pruning patterns.
The most well-known pruning DCT algorithm presented in [1] gives the same complexities as listed in the first column of Table I. This fact verifies the correctness and effectiveness of the proposed pruning algo-rithm. As for the other two algorithms (or matrix decompositions), the gain obtained from pruning is less significant. The number of pruned multiplications is larger in Winograd’s approach, whereas the number of pruned additions is larger in Lee’s approach. In fact, these charac-teristics can be observed and explained from their corresponding algo-rithm structures. In Winograd’s DCT algoalgo-rithm, the required multipli-cations are post-processing oriented, whereas in Lee’s DCT algorithm, the most post-processing oriented operations are additions. That is, if the complexity of multiplication is the major concern, then the pruning gain will be more significant when the required multiplications of the algorithm are nearly post-processing oriented.
IV. CONCLUSIONS
In this correspondence, an index-registration technique is presented to establish an effective framework for developing efficient pruning al-gorithms for various ODT’s. Moreover, with the aid of the proposed technique, an automatic optimal output pruning ODT program gener-ator can be developed. This is currently under investigation.
REFERENCES
[1] Z. Wang, “Pruning the fast discrete cosine transform,” IEEE Trans.
Commun., vol. 39, pp. 640–643, May 1991.
[2] A. N. Skodras, “Fast discrete cosine transform pruning,” IEEE Trans.
Signal Processing, vol. 42, pp. 1833–1837, July 1994.
[3] C. A. Christopoulos, J. Bormans, J. Cornelis, and A. N. Skodras, “The vector-radix fast cosine transform: Pruning and complexity analysis,”
Signal Process., vol. 43, pp. 197–205, May 1998.
[4] H. S. Hou, “A fast recursive algorithm for computing the discrete co-sine transform,” IEEE Trans. Acoust., Speech Signal Processing, vol. ASSP-35, pp. 1455–1461, Oct. 1987.
[5] B. G. Lee, “A new algorithm to compute the discrete cosine transform,”
IEEE Trans. Acoust., Speech Signal Processing, vol. ASSP-32, pp.
1243–1245, 1984.
[6] E. Feig and S. Winograd, “Fast algorithms for the discrete cosine trans-form,” IEEE Trans. Signal Processing, vol. 40, pp. 2174–2193, Sept. 1992.
[7] I. W. Selesnick and C. S. Burrus, “Automatic generation of prime length FFT programs,” IEEE Trans. Signal Processing, vol. 44, pp. 14–24, Jan. 1996.
