Kaohsiung Medical University Institutional Repository:Item 310902000/11645

Kaohsiung J Med Sci January 2005 • Vol 21 • No 1

34

D

ENGUE

V

IRUS

-

ASSOCIATED

H

EMOPHAGOCYTIC

S

YNDROME

AND

D

YSERYTHROPOIESIS

: A C

ASE

R

EPORT

Po-Liang Lu, Hui-Hwa Hsiao, Jih-Jin Tsai, Tun-Chieh Chen, Ming-Chu Feng,1 Tyen-Po Chen, and Sheng-Fung Lin

Departments of Internal Medicine and 1Nursing, Kaohsiung Medical University Hospital, Kaohsiung, Taiwan.

A 33-year-old man had dengue hemorrhagic fever with initial presentation of fever, leukocytosis, and thrombocytopenia. The cause of the subsequent rapid decline in red cell counts without evidence of intravascular hemolysis or massive bleeding was confirmed as hemophagocytosis and dyserythropoiesis by bone marrow study. The patient recovered with supportive care and the bone marrow pattern was normal on repeated bone marrow study. To our knowledge, this is the first reported case of dengue virus-associated hemophagocytosis and dyserythropoiesis in Taiwan. Clinicians should consider that the occurrence of hemophagocytosis and dyserythropoiesis could be due to dengue virus infection. That this dengue virus infection was confirmed by a positive serology result at the convalescent stage but not at the acute symptomatic stage underlines the need for a second dengue serology study, as dengue infection can be missed due to an initial negative serology result.

Key Words: hemophagocytosis, dengue fever (Kaohsiung J Med Sci 2005;21:34–9)

Received: July 1, 2004 Accepted: November 6, 2004 Address correspondence and reprint requests to: Dr. Sheng-Fung Lin, Department of Internal Medicine, Kaohsiung Medical University Hospital, 100 Tzyou 1st _{Road, Kaohsiung 807, Taiwan.}

E-mail: [email protected]

Dengue fever caused by dengue virus is an important mosquito-transmitted disease due to its increased world-wide incidence and its related complications [1]. The most common manifestations of dengue virus infection are self-limiting high fever and musculoskeletal pain. Some cases may present with severe bleeding or even shock that is classified as dengue hemorrhagic fever (DHF) [1].

Early neutropenia, with subsequent lymphocytosis and a decrease in platelet count, and markedly hypocellular marrow with abnormal megakaryocytopoiesis in the early stage are common hematologic presentations of dengue infection [2]. Several observations have been made on changes in the bone marrow of patients with dengue fe-ver and DHF [2–16]. Howefe-ver, there are few reports with

detailed studies of marrow aspirates throughout the course of the disease [6].

Hemophagocytosis is an uncommon presentation of den-gue infection. The cause of the exceptional hematopoietic response of some patients to viral infections remains obscure, but this response raises the distinct possibility of host factors of which we are not aware [2]. We describe a patient with DHF who developed hemophagocytosis and dyserythro-poiesis and recovered. We also review previously reported bone marrow findings during dengue infection.

C

P

A 33-year-old Chinese male patient had had fever and chills associated with general muscle soreness, headache, and lower back pain since November 6, 2002. He came to the emergency room of our medical center on November 10, 2002 because his fever did not subside after primary man-agement. He also had abdominal pain, poor appetite, and diarrhea for 2 days. Physical examination revealed pete-chiae over both lower legs and splenomegaly.

Laboratory examination on admission showed a white

blood cell (WBC) count of 24,820/mm3_{, red blood cell}

(RBC) count of 5,580,000/mm3, hemoglobin of 18.2 g/dL, hematocrit of 53.0%, and platelet count of 4,000/mm3. Differential leukocyte count showed a predominance of polymorphonuclear cells (segmented, 67%; band, 8%; lymphocytes, 8%; monocytes, 15%; normoblasts, 1%). The aspartate transaminase concentration was 179 U/L, alanine transaminase concentration was 88 U/L, blood urea nitrogen was 22 mg/dL, creatinine concentration was 1.0 mg/dL, glucose concentration was 115 mg/dL, C-reactive protein level was 0.4 µg/mL, prothrombin time (PT) was 12/10.9 seconds (case/control), activated partial thromboplastin time (APTT) was 50.3/30.4 seconds (case/control), hapto-globulin concentration was less than 5.83 mg/dL (nor-mal, 13–163 mg/dL), Coombs’ test (direct and indirect) was negative, and lactate dehydrogenase level was 1,243 U/L (normal, 180–460 U/L). The stool occult blood test result was 4+.

At 2 days after admission, WBC count had decreased to 16,890/mm3, hemoglobin level to 12.0 g/dL, hematocrit to 35.8%, and platelet count to 1,600/mm3_{. Over a 6-day} period (November 10–15), the WBC count dropped to

5,160/mm3, the RBC count to 4,020,000/mm3, and the

hemoglobin to 12.4 g/dL. Routine urine tests on the 6th day revealed no pyuria and no hematuria, but dipstick tests were positive for bilirubin (1+) and urine protein (1+). The reticulocyte index was 0.45%. The patient had a positive result for hepatitis B surface antigen and a negative result for hepatitis C antibody. Tests for heterophil antibody and cytomegalovirus immunoglobulin (Ig) M were negative, while that for Epstein-Barr virus nucleus antigen antibody was positive. Antinuclear antibody was absent. Blood cul-ture on admission was negative for bacteria. Abdominal sonography 7 days after admission showed bilateral pleu-ral effusion, ascites, splenomegaly, gall bladder sludge, and gall bladder wall thickening. Chest roentgenography revealed bilateral lower lung pleural effusion.

Bone marrow was examined on the 9th day after fever because of marked leukocytosis and the rapid decrease in hemoglobin and platelet count. Marrow aspiration showed normal cellularity (50%) with adequate megakaryocytes and normal myeloid differentiation. However, dyserythro-poiesis syndrome (nucleus budding, multiple nuclei, and some megaloblastic change) and hemophagocytosis were found (Figure 1).

The patient received supportive care without anti-microbial therapy. His fever subsided on the 10th day after symptoms appeared. He was discharged on the 10th

hospi-Figure 1. Initial bone marrow examination shows: (A) normal cellularity

with erythroid hyperplasia and megaloblastoid erythropoiesis (arrow); (B) hemophagocytosis (arrowhead). (C) The nuclear budding and multinucleation characteristics of dyserythropoiesis are clearly seen under high-power magnification (× 1,000).

B

A

talization day when the fever had subsided and the WBC count was 4,760/mm3_{, hemoglobin was 12 g/dL, and platelet} count was 77,000/mm3. Dengue virus serology by enzyme-linked immunosorbent assay, performed by The Center for Disease Control, Taiwan, 6 days after onset of fever and symptoms, was negative for IgG and IgM antibodies to dengue virus [17]. Convalescent serology tests on Novem-ber 23 and DecemNovem-ber 20 were positive for IgG and IgM anti-bodies to dengue virus, confirming the dengue virus infec-tion. According to his clinical manifestations, the patient was diagnosed as having DHF: his diagnostic criteria were acute febrile illness, bleeding symptoms or signs, throm-bocytopenia (< 105 cells/µL), and evidence of plasma leak-age (pleural effusion, ascites) [1].

Follow-up examination 1 month later showed no sequelae. The laboratory data were as follows: WBC,

9,820/mm3; hemoglobin, 13.6 g/dL; hematocrit, 43.4%;

platelet count, 266,000/mm3_{; PT, 11.5/12.1 seconds; and} APTT, 31.8/29.8 seconds. Repeated bone marrow aspira-tion showed recovery to a normal marrow pattern and dis-appearance of dyserythropoiesis (Figure 2).

D

Infection with dengue virus commonly produces neutro-penia with lymphocytosis and thrombocytoneutro-penia [18]. Hematocrit, hemoglobin, PT, and APTT are normal in un-complicated classical dengue fever, but they may alter in dengue fever complicated with severe hemorrhage [19].

Our case lacked the characteristic leukopenia of adult dengue. Leukopenia (< 5,000/mm3_{) is found in most} non-shock cases of dengue infection [7]. Only 16% of mild cases have leukocytosis, which appears during the recovery stage, whereas 67% of shock cases and 66% of mortality cases have pronounced leukocytosis [20]. Clinically, leukocytosis is an ominous sign for dengue infection [20]; our DHF case had this hematologic finding.

The longer survival of erythrocytes compared with platelets and granulocytes makes the hematocrit relatively insensitive to modest or temporary changes in either RBC production or survival [21]. There was no clinical evidence of intravascular hemolysis and no massive bleeding clini-cally in our case; bone marrow aspiration showed that the sudden and significant fall in RBC counts resulted from intramedullary destruction of blood cells by hemophago-cytic histiocytes.

Bone marrow aspiration is not a usual procedure for dengue infection cases, mostly due to the risk of bleeding and because most patients have classic dengue fever, where changes in blood cell counts recover.

Thrombocytopenia is often seen among dengue-infected patients. Hemophagocytosis is regarded as one of the causes of thrombocytopenia [9,22]. Other processes that interfere with platelet cells, acting successively or in combination, are: early transient marrow suppression with damage to megakaryocytes [23]; platelet aggregation with endothe-lial cells targeted by dengue viruses [24]; and immune destruction of platelets, with dengue antibody complexes found on membranes [25].

Figure 2. Bone marrow examination at follow-up: (A) nearly normal marrow with a myeloid:erythroid ratio of 3.5:1 (× 400); (B) disappearance of

the dyserythropoiesis (× 1,000).

In dengue-infected patients, bone marrow hypoplasia is typical [2]. Dengue infection of hematopoietic cells is not cytotoxic but slows cell proliferation [26]. Erythroid pro-genitor colonies from dengue-infected cultures are smaller and abnormally dispersed [26,27]. Dyserythropoiesis shows as erythroid hyperplasia with arrest of maturation [5]. Dengue-related hemophagocytosis has been described in the literature [6,9–13]. The self-limiting hemophago-cytosis syndrome with supportive care in our case follows a similar disease process to other surviving dengue-associated hemophagocytosis cases [21–23] and most reactive hemophagocytosis cases [28]. However, most re-ported cases of hemophagocytic syndrome are DHF cases and from postmortem bone marrow study [6,14,22,24]. Nelson et al proposed that hemophagocytosis was present in the terminal stage of dengue infection because seven postmortem cases and two severe cases (one with prolonged shock and one with severe epistaxis) had variable levels of hemophagocytosis [6], while no hemophagocytosis was found in another 22 bone marrow samples from dengue fever cases [7]. In contrast, two postmortem bone marrow studies in 12 and 100 DHF cases, respectively, did not find features of hemophagocytosis [14,15]. A causal relationship between hemophagocytosis and the severity of dengue infection has been suggested [6] but not fully established. Other studies on bone marrow in dengue-infected cases did not find hemophagocytosis, which shows that hemophago-cytosis is not a common presentation of dengue infection [5,2,16].

The initially negative dengue serology result and the concurrent bone marrow finding of hemophagocytosis and dyserythropoiesis might lead to a diagnosis of myelodys-plastic syndrome or hemophagocytosis, including malig-nant histiocytosis, which may require a different treatment. Our case had reactive hemophagocytosis, which may occur during dengue infection, and confirmed reversible bone marrow changes after infection. Clinicians should consider the possibility that hemophagocytosis could be a compli-cation of dengue infection, which requires bone marrow aspiration and second serology study for dengue virus at the recovery stage.

R

1. Dengue Hemorrhagic Fever: Diagnosis, Treatment, and Control. Geneva: World Health Organization, 1997.

2. Bierman HR, Nelson ER. Hematodepressive virus diseases of Thailand. Ann Intern Med 1965;62:867–84.

3. Halstead SB. Antibody, macrophages, dengue virus infection, shock, and hemorrhage: a pathogenetic cascade. Rev Infect Dis 1989;11:S830–9.

4. Kho LK, Wuler H, Himawan T. Blood and bone marrow changes in dengue haemorrhagic fever. Paediatr Indones 1972;12:31–9. 5. Na-nakorn S, Suihgdumrong A, Pootrakul S, et al.

Bone-marrow studies in Thai haemorrhagic fever. Bull WHO 1966; 35:54–5.

6. Nelson ER, Bierman HR, Chulajata R. Hematologic phagocy-tosis in postmortem bone marrows of dengue hemorrhagic fever. Am J Med Sci l966;252:68–74.

7. Nelson ER, Bierman HR, Chulajata R. Hematologic findings in the 1960 hemorrhagic fever epidemic (dengue) in Thailand.

Am J Trop Med Hyg 1964;13:642–9.

8. Nelson ER, Tuchinda S, Bierman HR, et al. Haematology of Thai haemorrhagic fever (dengue). Bull WHO 1966;35:43–4. 9. Wong KF, Chan JKC, Chan JCW, et al. Dengue virus infection

associated hemophagocytic syndrome. Am J Hematol 1991;38: 339–40.

10. Strobel M, Muller P, Lamaury I, et al. Dengue fever: a harmful disease in patients with thrombocytopenia? Clin Infect Dis 2001;33:580–1.

11. Rueda E, Mendez A, Gonzalez G. Hemophagocytic syndrome associated with dengue hemorrhagic fever. Biomedica 2002;22: 160–6.

12. Veerakul G, Sanpakit K, Tanphaichitr VS, et al. Secondary hemophagocytic lymphohistiocytosis in children: an analysis of etiology and outcome. J Med Assoc Thai 2002;85:S530–41. 13. Ramanathan M, Duraisamy G. Haemophagocytosis in dengue

haemorrhagic fever: a case report. Ann Acad Med Singapore 1991;20:803–4.

14. Burke T. Dengue hemorrhagic fever: a pathological study.

Trans R Soc Trop Med Hyg 1968;62:682–92.

15. Aung-Khin M, Ma-Ma K, Thant-Zin. Changes in the tissues of the immune system in dengue haemorrhagic fever. J Trop Med

Hyg 1975;78:256–61.

16. Lin SF, Liu HW, Chang CS, et al. Hematological aspects of dengue fever. Kaohsiung J Med Sci 1989;5:12–6.

17. Shu PY, Chen LK, Chang SF, et al. Comparison of capture immunoglobulin M (IgM) and IgG enzyme-linked immuno-sorbent assay (ELISA) and nonstructural protein NS1 serotype-specific IgG ELISA for differentiation of primary and secondary dengue virus infections. Clin Diagn Lab Immunol 2003;10: 622–30.

18. Halstead SB. Dengue: hematologic aspects. Semin Hematol 1982;19:116–31.

19. George R, Lum LCS. Clinical spectrum of dengue infection. In: Gubler DJ, Kuno G, eds. Dengue and Dengue Hemorrhagic Fever. Wallingford, UK: CAB International, 1997:89–114.

20. Nelson ER, Chulajata R. Danger signs in Thai hemorrhagic fever (dengue). J Pediatr 1965;67;463–70.

21. Baranski B, Young N. Hematologic consequences of viral in-fections. Hematol Oncol Clin North Am 1987;1:167–83. 22. Jacobs MG, Weir WR, Bannister BA. Dengue hemorrhagic

fever: a risk of returning home. BMJ 1991;302:828–9. 23. Rothwell SW, Putnak R, La Russa VF. Dengue-2 virus infection

stroma cells. Am J Trop Med Hyg 1996;4:503–10.

24. Butthep P, Bunyaratvej A, Bhamarapravati N. Dengue virus and endothelial cell: a related phenomenon to thrombocyto-penia and granulocytothrombocyto-penia in dengue hemorrhagic fever.

Southeast Asian J Trop Med Public Health 1993;24:S246–9.

25. Hathirat P, Isarangkura P, Srichaikul T, et al. Abnormal hemo-stasis in dengue hemorrhagic fever. Southeast Asian J Trop

Med Public Health 1993;24:S80–5.

26. Nakao S, Lai CJ, Young NS. Dengue virus, a flavivirus, pro-pagates in human bone marrow progenitors and hematopoietic cell lines. Blood 1989;74:1235–40.

27. Young NS. Flaviviruses and bone marrow failure. JAMA 1990; 263:3065–8.

28. Reiner AP, Spivak JL. Hematophagic histiocytosis. A report of 23 new patients and a review of the literature. Medicine 1988; 67:369–88.
