Effects of sputtering pressure and Al buffer layer thickness on properties of AZO films grown by rf magnetron sputtering

(1)

Effects of sputtering pressure and Al buffer layer thickness on properties

of AZO

ﬁlms grown by rf magnetron sputtering

C.H. Tseng

a

, W.H. Wang

b

, H.C. Chang

b

, C.P. Chou

a

, C.Y. Hsu

b,*

a_{Department of Mechanical Engineering, National Chiao Tung University, Taiwan, ROC}

b_{Department of Mechanical Engineering, Lunghwa University of Science and Technology, Taoyuan, Taiwan, ROC}

a r t i c l e i n f o

Article history:

Received 14 October 2009 Received in revised form 17 June 2010

Accepted 22 June 2010 Keywords:

Transparent conductive oxide Al buffer layer

Rf magnetron sputtering Electrical resistivity

a b s t r a c t

Transparent and conductive Al-doped (2 wt.%) zinc oxide (AZO)films were deposited on inexpensive soda-lime glass substrates by using rf magnetron sputtering at room temperature. This study analyzed the effects of argon sputtering pressure, which varied in the range from 0.46 to 2.0 Pa, on the morphological, electrical and optical properties of AZOfilms. The only (0 0 2) diffraction peak of the film were observed at 2q～34.45_{, exhibiting that the AZO}_{films had hexagonal ZnO wurtzite structure, and}

a preferred orientation with the c-axis perpendicular to the substrate. By applying a very thin aluminum buffer layer with the thickness of 2 nm, ﬁndings show that the electrical resistivity was 9.46 104 U-cm, and the average optical transmittance in the visible part of the spectra was approximately 81%. Furthermore, as for 10 nm thick buffer layer, the electrical resistivity was lower, but the transmittance was decreased.

1. Introduction

Transparent conducting zinc oxide (ZnO) films have been studied extensively because of their good optical characteristics, high stability, excellent electrical properties and low material cost. They also have attracted attention because of their great potential for application in solar cells, surface acoustic wave devices, piezo-electric transducers and optoelectronic devices etc[1]. ZnO has a wide and direct band gap of 3.37 eV at room temperature, and is optically transparent like indium oxide and tin oxide [2]. Non-doped ZnO usually presents a high resistivity due to a low carrier concentration [3]. In order to increase its electrical and optical properties, ZnO is commonly doped with Group III elements, such as boron (B), indium (In), aluminum (A1) and gallium (Ga). Among these impurity doped zinc oxidefilms, Al-doped zinc oxide (AZO) thin film is considered an excellent candidate material [4]. Al presents a very high reactivity leading to oxidation during the growth offilms, and exhibits a wide band gap, high transparency, low resistivity, non-toxicity, low cost, and stability in hydrogen plasma compared with ITO and SnO2[5].

Several techniques have been developed in the deposition of AZO_{ﬁlms, which is the most commonly used radio frequency (rf)}

magnetron sputtering[6]. The most important deposition param-eters that should be controlled in order to develop AZOfilms with the desired properties are the substrate-to-target distance, the substrate temperature, the oxygenflow rate, the rf power, and the working pressure [7]. In this study, we examine the argon gas pressure dependence of the electrical, structural and optical properties of AZO transparent conductivefilms deposited on glass substrates. In order to improve the quality of the AZOfilms, the effects of Al buffer layers are also investigated.

2. Experimental procedures

Al-doped ZnO ﬁlms were deposited onto soda-lime glass substrates with dimensions of 20 20 1 mm by rf magnetron sputtering in an argon gas atmosphere. The glass substrates were ultrasonically cleaned in a detergent bath, and then cleaned with isopropyl alcohol, acetone and distilled water, and blow-dried with nitrogen. A commercially available hot-pressed and sintered disc of ZnO (purity, 99.99%) mixed with 2 wt.% Al2O3 (purity, 99.99%),

51.2 mm in diameter, was used as a target (Elecmat, USA). Before coating, the target was pre-sputtered for 10 min to remove any contamination.

The sputtering deposition was performed under an rf power of 100 W and thefilm thickness was 250 nm on average for all the samples. Theflow rate of the argon was controlled by a mass flow controller (MFC) from 33 sccm to 193 sccm, which corresponds to

* Corresponding author. Fax: þ886 2 82094845. E-mail address:cyhsu@mail.lhu.edu.tw(C.Y. Hsu).

Contents lists available atScienceDirect

Vacuum

j o u r n a l h o me p a g e : w w w . e l s e v i e r . c o m / l o ca t e / v a c u u m

(2)

a sputtering pressure varying from 0.46 to 2.0 Pa. The target to substrate distance was kept at 100 mm and the base pressure was 6.6 104PaTable 1lists the experimental conditions of the AZOﬁlm. In addition,Table 2lists the sputtering conditions for the Al buffer. As shown inTable 2, the rf powers were 50 W, the sputtering pressure was 0.99 Pa, and the buffer thicknesses were measured to be 2, 5, and 10 nm. The deposition rate of the Al buffer was 3.96 nm/min.

Theﬁlm thickness was measured using a surface proﬁlometer (

a

-step, AMBIOS XP-1). Aﬁeld emission scanning electron micro-scope (SEM, JEOL, JSM-6500F) analyzed the surface morphologies and an atomic force microscope (AFM, PSIA-XE-100) obtained topographic images. The structural properties were determined by X-ray diffraction (Rigaku-2000 X-ray Generator) using Cu K

a

radia-tion with an angle incidence of 1. The electrical resistivity was measured by the four-point probe method (Mitsubishi chemical MCP-T600). A UVevis spectrophotometer carried out optical trans-mittance measurement in a wavelength range of 300e800 nm.

Table 1

Experimental conditions of AZO (with and without buffer layer).

Substrate Soda-lime glass (20 20 1 mm)

Target ZnO:Al2O3(98:2 wt.%); 99.995% purity;

51.2 mm diameter

Gas argon (99.995%)

Base pressure 6.6 104_Pa

Substrate rotate vertical axis 20 rpm Substrate-to-target distance 100 mm Substrate temperature room temp.

Rf power 100 W

AZO thickness 250 nm

Sputtering pressure 0.46, 0.66, 0.99, 1.3 and 2.0 Pa

Table 2

Deposition parameters of Al buffer.

Substrate Soda-lime glass (20 20 1 mm)

Target Al; 99.99% purity; 51.2 mm diameter

Gas argon (99.995%)

Base pressure 6.6 104_Pa

Substrate rotate vertical axis 20 rpm Substrate-to-target distance 100 mm Substrate temperature room temp.

Rf power 50 W

Sputtering pressure 0.99 Pa

Deposition rate 3.96 nm/min

Buffer thickness 2, 5, 10 nm

Fig. 1. Deposition rate of AZOﬁlms as a function of sputter pressure.

Fig. 2. (a) X-ray curve, (b) variation of peak position and FWHM of the (0 0 2) peak, and (c) grain size plotted as a function of sputter pressure, for 250 nm thick AZOﬁlms grown on glass.

Fig. 3. Electrical resistivity and optical transmittance as a function of sputter pressure, for 250 nm thick AZOﬁlms grown on glass deposited at room temperature.

(3)

3. Results and discussion

The deposition rates of AZOﬁlms as a function of sputter pres-sure are plotted inFig. 1. As the deposition pressure increases, the deposition rate increases, reaching the maximum value of

Fig. 4. Electrical resistivity and optical transmittance of AZOﬁlms grown on glass as a function of AZOﬁlm thickness under the sputter pressure of 2.0 Pa.

Fig. 5. SEM micrographs of AZOﬁlms grown on glass for the sputter pressure of 2.0 Pa, and with different thicknesses (a) 250 nm, (b) 350 nm, and (c) 450 nm.

Fig. 6. Resistivity of AZOﬁlms grown on Al/glass and glass as a function of buffer thickness, when the AZOﬁlms’ thickness was 250 nm and the sputter pressure was 2.0 Pa.

Fig. 7. (a) X-ray curve, (b) variation of peak position and FWHM of the (0 0 2) peak, and (c) grain size plotted as a function of Al buffer thickness, when the AZOﬁlms’ thickness was 250 nm and the sputter pressure was 2.0 Pa.

(4)

6.306 nm/min at the deposition pressure of 0.99 Pa, and then decreases with further increase in the sputtering pressure. This is also similar to the results of Ma et al.[8].

Fig. 2 (a) shows the XRD pattern of 250 nm thick AZO films grown on glass at a 2.0 Pa sputter pressure. The experimental results show that there is no significant change in the orientation of all thefilms deposited in different sputter pressures. The (0 0 2) peak positions and the full width at half maximum (FWHM) of XRD for AZOfilms vary depending on the sputter pressure as shown in

Fig. 2(b). This reveals the diffraction peak position of 2

q

shifts from 34.25at 0.46 Pa sputter pressure up to a higher angle of 34.55at a sputter pressure of 1.3 Pa and then decreases to 34.50at a sputter pressure of 2.0 Pa. The FWHM of XRD depends on the crystalline quality of each grain and distribution of grain orientation[9]. With the increase of sputter pressure, we gradually observed a decrease in the FWHM of XRD for AZOfilms. The grain size was calculated using Scherrer’s formula. The grain sizes of the AZO thin films at different sputter pressures are shown inFig. 2. (c). The result is consistent with the result of the FWHM of XRD as shown inFig. 2. (b). This shows that the best quality crystallization of the AZOfilms should be deposited at a sputter pressure of 2.0 Pa.

Fig. 3shows the electrical resistivity and optical transmittance as a function of sputter pressure for the AZO_{ﬁlms (experimental} conditions lists inTable 1). The samples deposited at the sputter pressure increase from 0.46 to 0.66 Pa, causing a steep decrease in the electrical resistivity from 10.32 down to 4.22 102

U

-cm. The electrical resistivity then decreases slowly as the sputter pressure further increases. The average transmittance in the visible range is approximately 80% for the sputter pressure of 2.0 Pa. For compar-ison purposes, Fig. 4 shows the electrical resistivity and optical transmittance at different AZO thicknesses for the sputter pressure

Fig. 8. Cross-sectional SEM image of AZOﬁlm when the Al buffer layer thickness was 2 nm.

(5)

of 2.0 Pa. Thisﬁgure reveals that the AZO thickness increases from 250 to 450 nm, the electrical resistivity decreases from 2.22 103

to 1.61 103

U

-cm. These results are consistent with the SEM micrographs of AZO _{ﬁlms observed in} Fig. 5. It is clear that the average gain sizes of theﬁlms differ from one another. From the micrographs, an obvious increase of grain size is observed when the AZO thickness increases from 250 to 450 nm. The larger crystallite size results can cause a decrease in grain boundary scattering and an increase of carrier lifetime[10], and consequently leads to an increase of conductivity. On the other hand, with increasing AZO thickness up to a value of 450 nm, the optical transmittance decreases to a value approximately of 72% (seeFig. 4).

Fortunato et al.[11]showed that the buffer layer between the film and the substrate improved the quality of the film. In this study, the Al thinfilms were grown on glass substrates at room temperature as buffer layers. The rf power was 50 W, and the thicknesses of the Al buffers were 2, 5, and 10 nm, respectively (experimental conditions are listed inTable 2).Fig. 6presents the resistivity of the AZOfilms grown on Al/glass and glass as a function of buffer thickness, with the AZOfilm thickness of 250 nm and a sputtering pressure of 2.0 Pa. It is evident that the resistivity of the AZOfilms grown on Al/glass decreased as the Al buffer thickness increased.Fig. 7(a) shows the XRD patterns of the AZOfilms at various Al buffer thicknesses. All thefilms show that the AZO films had the hexagonal ZnO wurtzite structure with a preferential orientation along the c-axis perpendicular to the substrate surface. For buffer thicknesses of 10 nm, the diffraction peaks of AZOfilms became sharper and more intense. This is due to the increase of crystallite size and the improvement of the crystallinity of thefilms. InFig. 7(b) and (c), the variations in the grain size and the (0 0 2) peak position are plotted as a function of the Al buffer thickness.

The average grain size was the largest for the Al buffer thickness of 10 nm. The (0 0 2) peak position also showed dependence on the buffer thickness. The cross-section of thefilms was also revealed by SEM (Fig. 8). Thefilms were very compact, homogeneous, perfectly adherent to the substrate, and the AZOfilm consists of columnar-structured grains, possibly representing the oriented grains. Atomic force micrographs of the surface morphology of thefilms deposited at various buffer thicknesses are shown in Fig. 9. As mentioned above, the AZO grain size increased with increased buffer thickness, and the electrical resistivity was reduced. In addition, the thickness of the Al-metal layer was not allowed beyond a certain threshold for high transmittance. With increasing thickness of the metal layer, the transmittance decreased and the reflection increased as the_{film became a mirror}[12,13].Fig. 10shows the optical trans-mittance for AZOfilms with different Al buffer thicknesses. It can be seen that the transmittance decreases with an increase of the Al buffer thickness.

4. Conclusions

Transparent conducting Al-doped zinc oxidefilms were fabri-cated on soda-lime glass substrates by using rf magnetron sput-tering at room temperature. The sputsput-tering pressure dependence of the structural, morphological, electrical, and optical properties of thefilms was studied. As the sputtering pressure increased, the AZO thin film crystalline quality, conductivity and transmittance were promoted. All of the AZOfilms grown on Al/glass and glass under various sputtering pressures had strong c-axis (002) preferred orientation. The AZOfilms crystalline quality and resis-tivity were improved with increased Al buffer thickness but thefilm transmittance was not in good agreement with the increase in buffer thickness.
