Visual Tracking Using Learned Linear Subspaces

Jeffrey Ho^‡ Kuang-Chih Lee^† Ming-Hsuan Yang^⋆ David Kriegman^‡ jho@cs.ucsd.edu klee10@uiuc.edu myang@honda-ri.com kriegman@cs.ucsd.edu

‡Computer Science & Engineering ^†Computer Science ^⋆Honda Research Institute University of California, San Diego University of Illinois, Urbana-Champaign 800 California Street

La Jolla, CA 92093 Urbana, IL 61801 Mountain View, CA 94041

Abstract

This paper presents a simple but robust visual tracking al- gorithm based on representing the appearances of objects using affine warps of learned linear subspaces of the image space. The tracker adaptively updates this subspace while tracking by finding a linear subspace that best approximates the observations made in the previous frames. Instead of the traditionalL²-reconstruction error norm which leads to subsapce estimation using PCA or SVD, we argue that a variant of it, the uniformL²-reconstruction error norm, is the right one for tracking. Under this framework, we pro- vide a simple and a computationally inexpensive algorithm for finding a subspace whose uniformL²-reconstruction er- ror norm for a given collection of data samples is below some threshold, and a simple tracking algorithm is an im- mediate consequence. We show experimental results on a variety of image sequences of people and man-made objects moving under challenging imaging conditions, which in- clude drastic illumination variation, partial occlusion and extreme pose variation.

1 Introduction

The main challenge in designing a robust visual tracking algorithm is the inevitable variation in the images of the tracked object over time. Various factors can be responsible for such variation, e.g., changes in the viewpoint, changes in illumination, changes to the shape (deformations, articu- lations) or reflectance of the object, or partial occlusion of the target. Therefore, an important theme in visual tracking research is the design of a flexible model or representation which can adapt to appearance changes.

Typically, this requires the problem to be formulated in probabilistic terms, and the most recent and successful works on visual tracking, e.g., [12, 14, 7, 15], are all along this line. Various pixel statistics (e.g., using color or intensity values) are computed from the image sequence according to the probabilistic model deemed appropriated for the problem (commonly a Gaussian model). The dynamic evo- lution of the model is reflected by the different probability densities estimated from each frame. The CONDENSA- TION technique [11] is widely-used in visual tracking for

tackling probability density estimation of this sort. Robust head tracking was demonstrated to be feasible in [2, 15] by using the aforementioned probabilistic techniques. Some- what differently, appearance-based techniques offer another approach with less recourse to probability theory. In these approaches [10, 3], the appearance of the target is modelled using a linear subspace. The subspace is usually computed by applying Principal Component Analysis (PCA) to a collection of training images. Modelling images using a subspace has been shown to be effective in many different prob- lems in computer vision [13]. However, comparing with the probabilistic approaches, subspace-based techniques are more rigid in the sense that they generally allow only lim- ited number of ways to update its appearance model [4, 9], e.g. updating the covariance matrix.

This paper proposes a robust and adaptive appearance model for tracking complex natural objects based on the subspace technique. Within the subspace framework, updating the model becomes how to define a subspaceL that best approximates a given set of data{x1, · · · , xN}, the observations from the previous frames. What constitute a good approximation depends on the underlying metric one uses to define the quality of the approximation. The traditional L²reconstruction error norm (whered²(L, xi) is the usual squaredL²distance betweenxiand the subspaceL)

Error²(L, {x1, · · · , xN}) = XN i=1

d²(L, xi) (1)

leads immediately to the well-known linear techniques of Principle Component Analysis (PCA) and Singular Value Decomposition (SVD), and a (point-based) tracking algorithm based on updating linear subspaces using this technique has appeared in [4]. Our main contribution is the observation that for appearance-based tracking, the uniform L²reconstruction error norm

Error^∞(L, {x1, · · · , xN}) = max

i d²(L, xi) (2) may be a more appropriate metric in defining linear approximations. We show that, based on this error norm, a simple algorithm can be designed to update the linear subspace.

(2)

Our algorithm is entirely appearance-based in that no any other values besides the image intensity values entered into the computation. Nor is there any complicated probabilistic estimation or non-linear optimization in the algorithm. The unexpected surprise is how robust the tracker can be made against illumination variation, pose changes and partial occlusion starting with such a simple principle. Except the two-frame based tracker, which is not known to be robust, it is difficult to imagine another tracker that is simpler, both conceptually and implementation-wise. One of the main foci of this paper is to explain in detail how such a simple tracker can work at all.

This paper is organized as follows. In the next section, we detail our tracking algorithm. Our main focus will be on the algorithmic aspect of updating the linear subspace.

In the third section, we compare our algorithm with several well-known subspace-based tracking algorithms in the literature. The experimental results are reported in section four.

We conclude this paper with a short summary and remark on future work.

2 Tracking Algorithm

In this section, we detail our tracking algorithm. Schemat- ically, our algorithm is very simple. We assume that the tracking window has been initialized in the first frame. At each frame, the tracker maintains an up-to-date appearance model, and the tracking task becomes a detection problem.

To estimate the location of the target in the current frame, we sample S windows {w1, · · · , wS} of different sizes and orientations near the target’s location in the previous frame¹. The image content of each window is rectified to an image of fixed size. By rasterizing the rectified images in the usual way, theS windows can be viewed as a collection of points{x1, · · · , xS} in some vector space IR^K. Henceforth, we call this vector spaceIR^Kthe image space

2. At any frame, the tracker’s appearance model is represented as a linear subspaceL in IR^K. TheL²-distance between eachxiandL is computed and the state of the target at current frame is defined to be the windowwi such that its correspondingximinimizes the distance toL among all {x1, · · · , xs}. The main focus of this paper is to study how should the subspaceL adapt to change as time goes on, and to this we will turn our attention next.

2.1 Subspace Update

Under the subspace framework, the most reasonable update strategy is to search for a linear subspaceL that best approx-

1Assuming rectangular windows, there are five parameters that define any windows in the image : the location of its center, its width and height and angular orientation. Based on the window configuration in the previous frame, we sample the current collection of windows using a Gaussian distribution.

2In our experiment, the images are rectified to size 19x19 with K = 361

imates a collection of data samples{x1, · · · , xN}. The data samples are the observations (tracking results) from the previous frames. To define the quality of approximation, we use the uniform reconstruction error normError^∞ introduced in Equation 2. Suppose a pair of input parameters (N, δ) has been specified. Here N denote the number of previous frames whose tracking results we retain, andδ > 0 is a threshold parameter. We define the subspaceL to be any subspace such that the uniform reconstruction error norm betweenL and {x1, · · · , xN} is less than the threshold δ³:

Error^∞(L, {x1, · · · , xN}) < δ. (3) This definition ofL is exceedingly general and the solution is generally not unique. However, one immediate consequence is that as along asδ is greater than zero, there ex- ists at least oneL that satisfies the inequality in Equation 3, namely, the subspaceL spanned by the entire collection of samples{x1, · · · , xN}. In particular, the magnitude of δ will generally determine the minimal possible dimensionL with smallerδ requiring larger dimension of L. The non- uniqueness of the solution appears troubling at first; however, the great advantage of this is that we only need to find one suchL, and it is precisely the non-uniqueness of the so- lutions that allows us to design a simple and computationally inexpensive algorithm to find just one suchL. Having a computationally inexpensive update algorithm is necessary if the tracking algorithm is expected to run in real-time.

Clearly, Equation 3 is very different from a typi- cal approach where the data samples are almost always linearly fitted with the least reconstruction error norm Error²(L, {x1, · · · , xN}), and the unique optimal sub- spaceL is define as:

arg min

L Error²(L, {x1, · · · , xN}). (4) There are three reasons why we prefer Equation 3 to Equa- tion 4. First, the major difference between the two equations is that Equation 3 allows for explicit control on the approximation quality of the subspaceL for each xi while Equa- tion 4 does not. In particular, an optimal solutionL may be computed using PCA or SVD techniques, but one does not know how well it approximates each sample. For instance, when the external environment (lighting, pose variation or occlusion) starts to change significantly, the first few frames of such change will invariably be considered as outliers for the approximation using Equation 4. An optimalL computed via Equation 4 may not approximate these samples well and one immediately runs into the serious danger of losing the target. However, Equation 3 will in effect for the dimension ofL to increase in order to preserve the inequality. In this way, the tracker reacts to environmental changes

3One important point we do not address in this paper is the ‘noisy component’ of L introduced by enforcing the inequality. This will be the topic of a forthcoming paper.

(3)

more swiftly than the solution based on Equation 4. Second, the uniqueness of the solution for Equation 4 may seem to be a blessing at first. However, PCA or SVD require finding eigenvalues and eigenvectors, and this can be expensive when the image space turns out to be large. With the free- dom provided by Equation 3, the non-uniqueness of the so- lutions allows us to design a fast and inexpensive algorithm for finding just one such subspace. Finally, Equation 3 naturally lends itself to a simple (approximate) solution, and this we will describe next.

Because of the natural temporal coherence among the neighboring frames, one expects that for each batch ofk- consecutive frames{x1, · · · , xk} in the video sequence, the target images will not deviate from the mean of the observations from thesek-frames by more than an amount δ for someδ (if not, just subdivide the k-consecutive frames into two smaller batches). If the mean is taken as one of the basis vector ofL, it is clear that, for this batch of k consecutive frames,L satisfies Equation 3. The general construction is then straightforward. For a givenN observations from the previous frames,{x1, · · · , xN} and a positive integer k, we form a D = N/k dimensional vector space by breaking the sequence ofN images into D batches of size k. See Figure 3A. For each batchi, we compute its mean mi and the subspaceL is defined as the subspace spanned by these batch means,{m1, · · · , mD}. In this modified form, our algorithm takes in the two integral parameters(N, k) with N the number of previous frames retained in the tracker’s memory andk is the size of the batch whose mean is used to form the basis vector ofL⁴. Note that the basis vectors {m1, · · · , mD} are not orthonormal and in order to compute the distance betweenL and xi, we need to have an orthonormal basis ofL. Therefore, the computationally non- trivial part of our update algorithm becomes updating the orthonormal basis or an incremental Gramm-Schmidt process. Note also that only the batch means are retained in the memory. All previous observations can be discarded.

2.2 Updating Orthogonal Basis

The problem is the following. Suppose the current subspace L kept by the tracker has a basis of batch means {m1, · · · , mD}. Let U denote an orthonormal basis of L. The update consists of computing a batch mean mD+1, adding this newly computed mean to the collection {m1, · · · , mD}, and deleting the oldest mean m1 to form the new collection of batch means{m2, · · · , mD, mD+1}.

The updated subspaceL^′is spanned by these new collection of means and an orthonormal basisU^′ofL^′has to be computed.U^′can be computed from{m2, · · · , mD, mD+1} by applying the Gramm-Schmidt process. The most expensive part of the Gramm-Schmidt process is the computations of

4Henceforth, N and k will always denote the two parameters of our tracking algorithm. The dimension of L will be denoted by D.

the inner product between the ^D(D+1)₂ pairs of vectors in {m2, · · · , mD, mD+1}. Any other coefficient appearing in the Gramm-Schmidt process is a suitable linear combina- tion of some of these inner products. Note that the two sets {m1, · · · , mD} and {m2, · · · , mD, mD+1} differ by only two elements, namelym1andmD+1. Therefore, the inner products computed for{m1, · · · , mD} can be retained for the next update computation. The only new inner-products we need to evaluate are theD inner products between the new batch mean mD+1 and{m2, · · · , mD} and between mD+1and itself.

This shows that this part of the update can be made computationally inexpensive. In fact, with today’s processor speed, a full Gramm-Schmidt{m1, · · · , mD}, with small D (say D < 25, which is always the case for our experiments reported below), does not produce any noticeable effect on the tracker’s performance. For the reader’s conve- nience, we summarize both the tracking and subspace update algorithms in Figures 1 and 2.

Update Algorithm: Input (M , {x1, · · · , xk}, D)

M is the collection of local means {m1, · · · , ms} main- tained by the tracker and{x1, · · · , xk} is the most recent batch of observations (tracking results). D is the maximal allowable dimension of the subspace.

Output :U , an orthonormal basis of the subspace L and a newM

1. Compute the new local meanms+1of the new batch of observations{x1, · · · , xk}.

2. Ifs 6= D, (i.e. at the beginning stage of the tracking), form the new setM = {m1, · · · , ms, ms+1} by appendingms+1 toM . Otherwise, delete the oldest elementm1fromM = {m2, · · · , ms+1}.

3. Apply Gramm-Schmidt to the set of vectors inM to obtain a new orthonormal basisU .

Figure 1: Subspace Updating Algorithm

2.3 Illumination, Pose and Occlusion

The main difficulty facing a visual tracking algorithm is the inevitable variation in the images of the tracked object over time. The three most important variations are the external illumination variation, pose variation and the partial occlusion of the target. The tracking task becomes challenging when one or more of these three variations develops simultaneously. In this subsection, we provide some geometric reasons and motivations that support our claim that the proposed tracking algorithm can be made robust against these three sources of variations.

A clear explanation is offered by a direct sum decomposition of the subspaceL = L1⊕ L2. Consider Figure 3B.

(4)

Tracking Algorithm: Input Parameter (Ω, N , k, S) Ω = {ωx, ωy, ωw, ωh, ωθ} is the set of five parameters for sampling windows on the screen andS is the number of windows sampled for each frame. N is the number of previous frames retained by the tracker andk is the batch size.

Output :t, current state of the tracked object.

Internal Variable: D = ^N_k is the (maximal) dimension of the subspace L. U is an orthonormal basis of L, m a local mean and is set to be the mean of previous 30 observations. M is the set of batch means, and it is set to be empty at beginning. t = (x, y, w, h, θ) the location of the target, which is represented by a rectangular box on the image at location(x, y) and of size (w, h) with (angular) orientationθ. Initialization: The tracker is initialized by some method. Letx1be the observation at the first frame.

U is set to the unit vector _kx^x¹

1k. The initialization also specifies the initialt.

1. Sample Windows: Draw S samples of windows {W1, · · · , WS} at various location of different orientations and sizes according to a Gaussian distribution centered att with diagonal variance specified by Ω.

2. Tracking: Rectified each windowWito a19-by-19 image and rasterize it to form a vectorxiinIR³⁶¹. 3. Compute theL²distance between eachxiand the lo-

cal meanm. Choose half of {xi} which has smaller L² distance tom. Among these ^S₂ vectors, evaluate their distance to the subspaceL using the orthonormal basisU . This rejects half of the samples and therefore, increases the speed of the tracker.

4. letxibe the vector in the previous step that gives the minimal distance toL. The corresponding window Wi

is then the estimate of the target for the current frame.

t is set Wi.

5. Subspace Update: For the interval ofk frames, col- lect the observations{x1, · · · , xk} from the k previous frames and apply the Subspace Update Algorithm.

This updates bothM and U .

Figure 2: Tracking Algorithm

Each green circle represents the various batch means that we used to constructL. For simplicity, we assume that as current frame, the algorithm retains three batch means to computeL, as illustrated in the figure. In the decomposition L = L1⊕ L2,L1is the one dimensional subspace formed by the ‘radial vector’ that passes through the mean m (of these three batch means), andL2is the linear subspace that models the affine space generated by the three batch means.

A basis ofL2 is represented by the two red arrows. The key observation is in realizing that although it is not a real image, each batch mi approximates well the real images that make up its batch. In particular, the ray generated by each batch mean approximates well the rays generated by the neighboring real images. These rays are some of the rays that make up the various illumination cones [1] of the target. Note that by definition, a illumination cone is associated only with one particular pose and therefore, the rays generated by a sequence of observations from consecutive frames swept through a cross-section of a collection of illumination cones. This cross section can be approximated well by the subspaceL because it contains the rays generated by the batch means. The subspaceL1 in the decomposition ofL represents the average of these rays, and we can identifyL1 as the component ofL that is relevant for illumination variation.

On the other hand, by going to its complement,L2, we immediately see thatL2 models the pose variation. Using the idea of appearance manifold [13], the local linearity that can model small pose variation is precisely represented by the affine space generated by the three batch means. For instance, to model local linearity, one can compute the principle components for the set of three batches shown in Fig- ure 3B. Note that the affine space generated by these principle components will always be contained in the affine space generated by the batch means. In particular, theL2compo- nent ofL which models this affine space, can be considered as relevant for pose variation. Although our discussion is rather informal, these simple geometric reasons do provide some validity for expecting our tracking algorithm to be robust against pose and illumination variation.

The idea of dealing with occlusion does not seem to have a straightforward explanation using the geometry of the image space. However, the important issue in dealing with the development of occlusions using our framework is how quickly the model can adjust itself to the occlusion. One can reason that, again using the idea of appearance manifold, when the occlusion starts developing, the trajectory of the tracking sequence jumps from one appearance manifold to another. If the model does not adapt swiftly and its linearity is still modelling the local linearity of the previous appearance manifold, then one can expect the tracker to lose its target quickly. As we explained before, under our framework, it is the metric normError^∞that is responsible for

(5)

Origin

Image Space

Basis Vectors

m

2

Origin

Radial Component Lighting Variation

Pose Variation

Figure 3: Left(A) Each batch is represented by a yellow oval and the corresponding batch mean is denoted by the red arrow. Right(B) Each circle represents a batch mean and currently the subspaceL is spanned by the three batch means which are denoted by the three vertices of the triangle in the figure. The two red arrows represent a basis of the affine space generated by the three batch means.

the swift adaptation of our appearance model.

2.4 Remarks and Discussion

The computational complexity of the algorithm is domi- nated by the number of windows generated from the Gaus- sian sampling. Using200 to 300 samples, our tracker runs comfortably in real-time on a1.8-GHz Pentium machine in the experiments we reported below. The most prominent feature of our algorithm is its simplicity: the tracking algorithm simply takes the means of the tracking results over a constant interval and uses these batch means to form the linear subspace. No prior model learned off-lined is used by the algorithm. The algorithm operates on the pixel intensity values only, and there is no sophisticated probability estimates, non-linear optimization or filtering of images as frequently seen in the tracking literature. The unexpected surprise is the robustness of the tracking algorithm given its simplicity and parsimonious starting representation (the single first frame).

One criticism with the proposed tracker concerns the usual problem of drift. In fact, without any prior model and learning everything on-line, it is impossible to guaran- tee a drift-less tracking algorithm. Our point is clear. We adhere our appearance model as close to the current observation as possible. This makes the use of the uniform norm particularly apparent. In this way, we are locally greedy and hope that the drift can be prevented as much as possible. One possible method for enhancing the tracker’s ability against drift is to always include the observation made in the first frame in the appearance model. Among all the tracking results made along the video sequence, only the first observation is unquestionably the appearance of the tracked object. Observations made in the subsequent frames will in-

variably be associated with non-zero probabilities that they are not the tracked object. Therefore, it makes sense to include the only trustworthy result in the appearance model permanently. In our implementation, the orthonormal basis always contains the normalized initial image (a unit vector in the image space). Our results show that with this small enhancement, the tracker’s ability against drift can be greatly improved.

There are two important free parameters in our algorithm, N , the number of previous frames retained by the tracker andk the size of the interval used to update the subspace. In this paper, we did not address of problem of as- signing the correct values for these two parameters. In the experiments we reported below, we letk range from 3 to 6 and N range from 80 to 150. We leave the problem of adaptive determination the values ofN and k for future research. However, one fact is clear. N should not be too large as to incorporate almost all the observations made till current frame. There is an argument to be made that the best appearance model that can be used to predict the appearance of the target at the next frame should not contain the observations made way back in the sequence. Incorpo- rating too much (or too old) information will contaminate the current appearance model with useless information, and one runs into the danger of diminishing the discriminative power of the appearance model.

3 Related Work

Needless to say, there are numerous tracking algorithms proposed in the literature. The type of tracking algorithm that is most similar to our work is the subspace-based algorithm originated with the papers of Jepson and Black [3]

and Hager and Belhumeur [10]. In these pioneering papers, the subspaces are always learned off-line from some training images. In [3], a single subspace is used to provide an appearance model for tracking across different poses while in [10], the subspace is used for illumination modelling.

Subsequent works along this line (e.g. [9]) has extended these earlier works by incorporating the capability of updating the eigen-model. Staying within the eigen framework, these subsequent works invariably focus their attention on methods and ways that allow the covariance matrix to be updated efficiently.

As we explained above, the fundamental difference between these earlier works and our is the metric used to define the approximations. We mentioned that one of the possible dangers of using the usualL²reconstruction error norm is that the model may not adapt to external change sufficiently fast. In most of these earlier papers, a separate mechanism is needed to deal with occlusion. In [3], the occlusion is dealt with in a robust matching algorithm that uses a non-linear optimization technique, and in [10], it is dealt with using an iterative Re-Weighted Least Square

(6)

(IRLS) algorithm that assigns an importance weight to each pixel, which down weight the pixels corresponding to the occlusion. In our algorithm, there is no separate mechanism for dealing with occlusion. We simply let the appearance model adapt to the changing imaging condition quickly and the usual pestering problem of how to deal with occlusion for tracking ‘folds’ naturally under our appearance model.

Pixel-based algorithms (e.g. [12]) offer another approach. Here various statistics of each pixel are computed at each frame and typically they are used in the tracking algorithm through some types of EM or MAP estimation. Be- cause the statistics are gathered at pixel level, special care is needed to guard against external illumination changes. This is usually done by passing the images through illumination insensitive filters, such as the steerable filters of [8]. Here, our appearance-based algorithm clearly offers an advantage in that by incorporating illumination variation in the subspace as we explained earlier, this type of procedure can be completely avoided. Our experiments show that even under intense and drastic illumination variations, our simple tracker can still perform robustly.

Contour-based tracking algorithms (e.g. [2, 15, 6]) operate on a domain that is somewhat different from ours. Since these algorithms track the contour of the object, the actual image content of the object is less important for this type of tracker, i.e. pose variation generally does not offer too much difficulty. However, because these algorithms operate directly with pixels, special attention is always needed to guard against both the illumination change and occlusion.

4 Experiments and Results

We have implemented the proposed method in C++ under the Microsoft Windows environment. Our current implementation runs at 30 frames/sec comfortably with 320x240 video input without any code optimization on a standard Dell P4 1.8 MHz machine. The tracking area is described by a rectangle window modelled by a5 dimensional state vectorS = [x, y, w, h, θ], where (x, y) represents the position of the tracking window,(w, h) represents the width and height of the tracking window, andθ represents the 2D rotation angle of the tracking window. Currently the parameters are initialized manually. For specific classes of objects (e.g., faces), the tracker could be initialized by the results of a detector. In order to demonstrate the robustness and efficacy of our approach, we have tested the tracking algorithm on many real-world sequences. These sequences contain many difficult scenarios which a real-world tracker would likely to encounter, including changes in appearance, large pose variations, significant lighting variation and shadowing, partial occlusion, tracking object partly leaving field of view, large scale changes, cluttered back- grounds, and quick motion resulting in motion blur. We list the most difficult and representative four video sequences

in the following subsections. Figures 4-7 show several key frames from these sequences and the rectified tracking window is shown in the upper left corner. The com- plete tracking results for these four sequences and com- parisons with other tracking algorithms as well as other video tracking sequences are available for downloading at http://vision.ucsd.edu/kriegman-grp/research/.

4.1 Tracking a Woman’s Face

The first video sequence shown in Figure 4 is a young woman walking in a cluttered office environment with1750 frames. The long sequence demonstrates the stability of our proposed algorithm. The challenge of this video sequence includes large pose variation during walking, significant lighting variation and shadowing when she turns on the desk lamp, and the partial occlusion when she drinks coffee and walks behind a cubical wall. In addition, the cluttered background and shaky motion from a handheld camera also increase the tracking difficulty.

4.2 Tracking a Man’s Face

Figure 5 shows some difficult tracking frames in the Dudek Sequence from the University of Toronto, which originally appeared in [12]. The sequence contains lots of activities which cause significant appearance changes, such as a hand totally occluding the face for a short time, and taking the glasses on and off, etc..

4.3 Tracking A Man’s Face with Occlusion and Pose Variation

Figure 6 shows the result of tracking a man’s face while it is partially occluded by a book. The pose of the man’s face varies simultaneously with the development of occlusion.

4.4 Tracking a Human Face under Lighting Changes

The last video sequence shown in Figure 7 is from Boston University, where it shows the capability of our tracker in keeping good result when both pose and lighting condition varied. The sequence can be downloaded from the public website [5].

5 Summary and Conclusions

In this paper, we have introduced a technique for learning on-line a representation of the appearances of an object that is being tracked. By representing the appearances as a linear subspace and choosing to satisfy a constraint using a well- chosen metric, the resulting tracker is both simple and fast.

As demonstrated in eight challenging video sequences, the method can robustly track an object in the presence of large viewpoint changes, partial occlusion, drastic lighting variation, changes to the shape of the object (facial expressions, adding glasses), shaky cameras, and motion blur.

(7)

Face partly leaving field of view, significant lighting variation and large pose variation

Partial occlusion by the coffee mug

Partial occlusion by walking behind a wall separating two office cubicles.

Figure 4: Sequence of tracking a woman’s face. Each row represents a set of 5 key frames of a particular event. The image in the upper left corner is the first frame of the video. The upper left corner of each displayed frame shows the cropped image.

Figure 5: Demonstration of tracking a man’s face. The tracking results of some difficult frames are selected for this figure.

Figure 6: Demonstration of tracking a man’s face while it undergoes pose change and occlusion. 5 key frames are displayed.

(8)

Figure 7: Demonstration of tracking a man’s face under lighting variation. The tracking results of some difficult frames are selected in this figure. The wire loop on the head is part of the original sequence.

Within a larger context, one intermediate goal of a tracker might be to learn all appearances of an object on- line, i.e., the appearance manifold. By constructing a subspace using only some of the most recent images in a video, one basically arrives at a representation which is an embed- ding of a small neighborhood of the appearance manifold in a low dimensional linear subspace. Rather than using the neighborhood of the manifold, we instead use the linear subspace as the representation. Note that if the neighborhood were very small, the subspace would just be a subset of the tangent space to the appearance manifold, but here the neighborhood is larger, and so the dimension of the subspace must be larger. As a consequence of only learning a neighborhood of the appearance manifold, the representation does not contain all appearances of the object. Yet for tracking, the viewing parameters generally change contin- uously, and so representing a neighborhood of appearances is sufficient for effective tracking. Though not revealed in our experiments, a potential challenge remains which is a long term drift of the tracking window off the tracked object since our local representation may become corrupted with the background or occluding objects. One potential way to mitigate this problem is to enhance the representation with an approximation to the global appearance manifold cou- pled with our local representation. For example, one knows a priori that the image used to initialize the tracker is always a valid image on the appearance manifold, and like- wise a sparse sampling of representative images from the entire tracking sequence could be retained. How to effec- tively, efficiently, and quickly sample, represent, utilize and integrate such information in capturing the global appearance structure of an object remain open challenges.

Acknowledgments

We would like to thank Mei-Fang Huang for her generous effort in helping us making the video tracking sequences.

This work was funded under NSF IIS 00-85980, NSF CCR 00-86094 and the U.C. MICRO program.

References

[1] P. Belhumeur and D. Kriegman. What is the set of images of an ob- ject under all possible lighting conditions. Int’l. J. Computer Vision, 28:245–260, 1998.

[2] S. Birchfield. Elliptical head tracking using intensity gradients and color histograms. In Proc. IEEE Conf. on Computer Vision and Pat- tern Recognition, pages 232–237, 1998.

[3] M. Black and A. Jepson. Eigentracking: Robust matching and track- ing of articulated objects using a view-based representation. In Proc.

European Conf. on Computer Vision, pages 329–342, 1996.

[4] M. Brand. Incremental singular value decomposition of uncertain data with missing values. In Proc. European Conf. on Computer Vision, volume 2350, pages 707–720, 2002.

[5] M. L. Cascia, J. Isidoro, and S. Sclaroff.

Image and video computing group. In

http://www.cs.bu.edu/groups/ivc/HeadTracking/publications.html.

[6] Y. Chen, Y. Rui, and T. Huang. JPDAF based HMM for real-time contour tracking. In Proc. IEEE Conf. on Computer Vision and Pat- tern Recognition, volume 1, pages 543–550, 2001.

[7] D. Comaniciu, V. Ramesh, and P. Meer. Real-time tracking of non- rigid objects using mean shift. In Proc. IEEE Conf. on Computer Vision and Pattern Recognition, volume 2, pages 142–149, 2000.

[8] W. Freeman and E. H. Adelson. The design and use of steerable filters. In IEEE Trans. Pattern Analysis and Machine Intelligence, volume 13, pages 891–906, 1991.

[9] N. Gupta, P. Mittal, S. Roy, S. Chaudhury, and S. Banerjee.

Condensation-based predictive eigentracking. Proc. Indian Con- ference on Computer Vision, Graphics and Image Processing (ICVGIP), 2002.

[10] G. Hager and P. Belhumeur. Efficient region tracking with parametric models of geometry and illumination. In IEEE Trans. Pattern Anal- ysis and Machine Intelligence, volume 20, pages 1025–1039, 1998.

[11] M. Isard and A. Blake. Condensation - conditional density propa- gation for visual tracking. In Int’l. J. Computer Vision, volume 29, pages 5–28, 1998.

[12] A. Jepson, D. Fleet, and T. El-Maraghi. Robust online appearance models for visual tracking. In Proc. IEEE Conf. on Computer Vision and Pattern Recognition, pages 415–422, 2001.

[13] H. Murase and S. K. Nayar. Visual learning and recognition of 3-D objects from appearance. Int’l. J. Computer Vision, 14:5–24, 1995.

[14] K. Toyama and A. Blake. Probabilistic tracking in a metric space. In Proc. Int’l. Conf. on Computer Vision, volume 2, pages 50–59, 2001.

[15] Y. Wu and T. S. Huang. A co-inference approach to robust visual tracking. In Proc. Int’l. Conf. on Computer Vision, volume 2, pages 26–33, 2001.
