Bisphosphonate-Associated Osteonecrosis of the Jaw: Are We Dealing with a Localized Non-Traditional Calciphylaxis?

(1)

The Open Dentistry Journal, 2012, 6, 5-7 5

1874-2106/12 2012 Bentham Open

Open Access

Bisphosphonate-Associated Osteonecrosis of the Jaw: Are We Dealing with a Localized Non-Traditional Calciphylaxis?

Meiller TF

^1,2,

Almubarak H

²

, Weikel DS

^1,2

, Brahim J

^1,3

and Scheper MA

^1,2,*

1Marlene and Stewart Greenebaum Cancer Center, University of Maryland Medical Center, Baltimore, USA

2Department of Oncology and Diagnostic Sciences, University of Maryland, Baltimore, USA

3Department of Oral and Maxillofacial Surgery, University of Maryland, Baltimore, USA

Abstract: The bisphosphonate (BP) family of drugs has been used as a vital component in cancer therapy and many other diseases. One of the main adverse effects related to (BP) is BP-associated osteonecrosis of the jaw (ONJ). Although this condition was first recognized in 2003, the pathophysiologic mechanism remains undefined. Our hypothesis is that ONJs clinical course and delayed wound healing is in part correlated to a localized non-traditional calciphylaxis. This effect is identified by the evidence of calcium deposition in the connective tissue and around small blood vessels in the soft tissues immediately adjacent to ONJ lesions. This phenomenon helps to fill gaps in the cascade of events which leads to soft tissue ischemia, necrosis, and non-healing ONJ lesions. Our finding adds to the current knowledge of the potential pathophysiologic mechanisms related to ONJ.

Keywords: Bisphosphonate, bisphosphonate-associated osteonecrosis of the jaw, calciphylaxis, oncology, onj, therapeutic complications.

INTRODUCTION

Every year, an estimated 24 million bisphosphonate (BP) prescriptions are written in the U.S. alone[1]. One of the more recently reported serious adverse effects of BP treatment is BP-associated osteonecrosis of the jaw (ONJ). This condition was first recognized in 2003 and is predicted to occur in up to 28% of IV BP patients, with an estimated weighted prevalence of 13.3% in studies with accurate fol- low-up [2].

Currently, ONJ lacks a defined pathophysiologic mechanism. Unfortunately, researchers initially ignored the cross talk between bone and oral mucosal soft tissue, as this condition is truly a chemonecrosis process. Recently, we investi- gated an oral soft tissue mechanism as a potential contributor to the initiation of ONJ and more importantly, an inhibitor of wound healing, secondary to free BP [3-5]. Now we add to this hypothesis, a potentially distinct and complementary mechanism of initiation and persistence of ONJ, secondary to a local non-traditional calciphylaxis through vascular and soft tissue calcium deposition [6] (Fig. 1).

MATERIAL AND METHODS

We reviewed the tissue archives of the University of Maryland, Baltimore, Oral Pathology Consultants from 2003 to 2011 (with IRB approval) and found 10 cases of diag- nosed ONJ which contained adjacent soft tissue. Paraffin embedded tissue sections from these 10 stage 3 (AAOMS)

*Address correspondence to this author at the 650 W Baltimore Street, 7 N, Room 2756 Baltimore, MD 21201, USA; Tel: (410)-706-7936; Fax: (410)- 706-0519; E-mail: mscheper@umaryland.edu

ONJs in cancer patients using zoledronic acid (bone and adjacent soft tissue), were first evaluated using hematoxylin and eosin stain for accurate diagnosis. Next, unstained sections were deparaffinized, immersed in ethanol 100% and 95%, washed with distilled H2O and incubated with 1% sil- ver nitrate solution under UV light for 2 hours. The sections were then washed with distilled H2O and 5% sodium thio- sulfate for 5 minutes. Next the sections were counterstained with nuclear fast red for 5 minutes. As a negative control, sections were treated with phosphate-buffered saline with omission of the von Kossa stain. Additionally, five normal archived oral mucosal tissues were used as a control. The von Kossa staining was reviewed by two independent, certi- fied Oral Pathologists (MS and NB).

RESULTS

Using von Kossa staining, we demonstrated the presence of calcium in 8 of the 10 ONJ cases within the connective tissue and surrounding blood vessels. (Fig. 1A, B) All of these cases demonstrated a significant delay in ONJ wound healing. The bone within these specimens also demonstrated the presence of calcium at their leading edge where BP would typically bind to calcium phosphate since they are considered analogs of pyrophosphate [7] (Fig. 1C). Five normal archived oral mucosal tissues were used as a control.

(Fig. 1D).

DISCUSSION

Calciphylaxis is classically defined as a multifactorial renal phenomenon, whereby microcalcification of small blood vessels leads to soft tissue ischemia, necrosis and non- healing lesions [6]. This classic presentation is frequently

(2)

6 The Open Dentistry Journal, 2012, Volume 6 Meiller et al.

fatal and is seen most often at end-stage renal failure [8].

However, in certain hypercalcemic states, such as malignancy (Breast and Multiple Myeloma), hyperparathyroidism, cirrhosis, Crohns and collagen disease conditions, a nonuremic non-traditional calciphylaxis is shown to induce vascular and tissue deposition of calcium in the submucosal tissues [6-12]. This complication must surpass a critical threshold of sensitizing conditions (e.g. hypercalcemia and inflammation of malignancy; and BP and corticosteroid use) and thrombogenic stimuli (e.g. dental trauma). Since the mandible is a primary site for BP saturation and is com- monly affected by trauma, infection and inflammation; an acidic microenvironment would release free BP from bone and secondarily release calcium from its BP bound state to induce oral mucosal apoptosis/necrosis [4, 7, 13, 14].

Clinically, ONJ is observed as a mucosal dehiscence leading to the formation of a superficial mucosal ulcer, which continues to extend with time and results in detectable bone exposure, necrosis and sequestration. Moreover, like calciphylaxis, these lesions typically present as non-healing wounds treated empirically. Once a lesion occurs, there is tremendous difficulty in treating these lesions, which leads to delayed or refusal of dental treatment and discontinuation of necessary cancer therapy. Currently, the only therapeutic regimen is antimicrobial therapy, with surgical interventions reserved only for severe cases. Therefore, a tetralogical cascade must exist, including a combination of effects on bone, vasculature, microbial biofilm and oral mucosal soft tissues, especially in wound healing.

CONCLUSION

Part of the treatment regimen for calciphylaxis includes antibiotics and rebalancing calcium and phosphate, while avoiding local tissue trauma, similar to ONJ. Interestingly, the standard therapeutic regimen for ONJ, amoxicillin, is not affected by calcium and appears to have better success than tetracyclines which lose activity in the context of high calcium levels. Perhaps balancing the calcium and phosphate

levels, and creating a neutral pH, along with the standard of care therapy of eliminating the bacterial load, may become a translational model for investigating potential pathogenesis directed therapeutics.

CONFLICT OF INTEREST

The authors declare that they have no competing inter- ests.

ACKNOWLEDGEMENTS

Grant: Supported by K12RR023250.

REFERENCES

[1] Knight RJ, Reddy C, Rtshiladze MA, Lvoff G, Sherring D, Marussi D. Bisphosphonate-related osteonecrosis of the jaw: tip of the ice- berg. J Craniofac Surg 2010; 21: 25-32.

[2] Migliorati CA, Woo SB, Hewson I, et al. A systematic review of bisphosphonate osteonecrosis (BON) in cancer. Support Care Can- cer 2010; 18: 1099-106.

[3] Scheper M, Chaisuparat R, Cullen K, Meiller T. A novel soft-tissue in vitro model for bisphosphonate-associated osteonecrosis. Fibro- genesis Tissue Repair 2010; 3: 6.

[4] Scheper MA, Badros A, Chaisuparat R, Cullen KJ, Meiller TF.

Effect of zoledronic acid on oral fibroblasts and epithelial cells: a potential mechanism of bisphosphonate-associated osteonecrosis.

Br J Haematol 2009; 144: 667-76.

[5] Scheper MA, Badros A, Salama AR, et al. A novel bioassay model to determine clinically significant bisphosphonate levels. Support Care Cancer 2009; 17(12): 1553-7.

[6] Wilmer WA, Magro CM. Calciphylaxis: emerging concepts in prevention, diagnosis, and treatment. Semin Dial 2002; 15:172-86.

[7] Li B, Ling Chau JF, Wang X, Leong WF. Bisphosphonates, spe- cific inhibitors of osteoclast function and a class of drugs for osteo- porosis therapy. J Cell Biochem 2011; 112: 1229-42.

[8] Sullivan E, Hoyle C. Calciphylaxis, occurring 10 weeks after hy- percalcaemia, in a patient with multiple myeloma. Br J Haematol 2011; 155(2): 136.

[9] Kalajian AH, Malhotra PS, Callen JP, Parker LP. Calciphylaxis with normal renal and parathyroid function: not as rare as previ- ously believed. Arch Dermatol 2009;145: 451-8.

[10] Padovan C, Bonfigli F, Ulessi B, Gottardi C, Giansante C, Trevisan G. Calciphylaxis of the breast: a rare disease in the differential diagnosis of breast cancer. Acta Dermatovenerol Croat 2008; 16:

83-6.

Fig. (1). ONJ cases with adjacent soft tissue were stained for calcium using von Kossa. A, B: ONJ staining for calcium positive in 8 of 10 cases around vessels and in the connective tissue (black/brown). C: Bone showing calcium staining at the leading edge. D: Normal oral mu- cosa control (A, C, D 400x/ B 200X).

(3)

Bisphosphonate-Associated Osteonecrosis of the Jaw The Open Dentistry Journal, 2012, Volume 6 7 [11] Crippa C, Ferrari S, Drera M, et al. Pulmonary calciphylaxis and

metastatic calcification with acute respiratory failure in multiple myeloma. J Clin Oncol 2010; 28: e133-5.

[12] Nigwekar SU, Wolf M, Sterns RH, Hix JK. Calciphylaxis from nonuremic causes:a systematic review. Clin J Am Soc Nephrol 2008; 3: 1139-43.

[13] Otto S, Pautke C, Opelz C, et al. Osteonecrosis of the jaw: effect of bisphosphonate type, local concentration, and acidic milieu on the pathomechanism. J Oral Maxillofac Surg 2010; 68: 2837-45.

[14] Kozloff KM, Volakis LI, Marini JC, Caird MS. Near-infrared fluo- rescent probe traces bisphosphonate delivery and retention in vivo.

J Bone Miner Res 2010; 25:1748-58.
