C A S E R E P O R T
A large developing complex odontome
K. Amin1, A. Jay2& P. Ayliffe1
1Dental & Maxillofacial Department, Great Ormand Street Hospital, London, UK
2Histopathology Department, University College London Hospitals NHS Trust, London, UK
Key words:
Complex odontome, Odontogenic tumour, Odontoma
Correspondence to:
Dr K Amin
Dental & Maxillofacial Department Great Ormand Street Hospital Great Ormand Street London WC1N 3JH UK
Tel: +44(0)20 7829 8614 Fax: +44(0)20 7829 8804 email: kiranamin@nhs.net Accepted: 29 January 2016 doi:10.1111/ors.12210
Abstract
Odontomas are the most common odontogenic hamartomas, broadly classified as compound or complex of which the latter is less common.
Complex odontoma is a lesion in which all the dental hard tissues are represented but occur in a disorderly pattern. They are usually asymptomatic and diagnosed on radiographic examination. We report a rare case of a large developing complex odontoma in a young girl causing expansion of bone and facial asymmetry with the failure of eruption of several mandibular posterior teeth. The odontoma was treated by careful surgical curettage, marginal mandibular rim resection and bone grafting. Follow-up over a couple of years revealed no evidence of recurrence.
Introduction
Odontoma is a benign odontogenic hamartoma, consti- tuting 22% of all odontogenic tumours1. Based on radiographic and microscopic features, odontomas are classified into complex and compound subtypes. Com- plex odontomas are defined as malformations in which all of the dental tissues are represented, and individual tissues are well formed but occur in a disorderly pat- tern2. They tend to occur in the posterior mandible pre- senting in the second decade of life with a slight female preponderance3. Complex odontomas can be associated with pathologic changes such as impaction, malposition- ing, aplasia, malformation and devitalisation of adjacent teeth4and are usually diagnosed on routine radiological examination. The aetiology of complex odontomas is unknown but theories include local trauma, infection, family history and genetic mutation3. Management is either by serial monitoring or surgical removal followed by histological analysis. We report an unusually large expansile ‘Developing complex odontome’ in the poste- rior left mandible of a young girl with associated facial asymmetry and unerupted permanent dentition.
Case report
A 13-year-old Caucasian girl was initially seen by her dentist and referred to the Oral and Maxillofacial Surgery department at ‘Great Ormand Street Chil- dren’s Hospital’ with missing left mandibular teeth.
Extra-oral examination revealed slight facial asym- metry with enlargement of the left mandibular angle region. Intraoral examination displayed an asymp- tomatic hard, non-tender swelling in the left mand- ible with several missing left mandibular permanent teeth and overlying normal mucosa. The patient had no history of trauma or infections.
Initial Dental Panoramic Tomography (DPT) (Fig. 1) revealed a poorly-defined, mixed density lesion in the left posterior mandible. Associated were the displaced unerupted permanent left canine, both premolars and the first molar teeth. CT scan (Fig. 2) showed the expansion of the buccal and lingual cor- tical plates, with the lesion occupying a zone from the midline to the angle of the left mandible with an ill-defined transition zone. The largest area of soft tissue was on the alveolar surface of the mandible in
Oral Surgery10 (2017) 40--42.
© 2016 The British Association of Oral Surgeons and John Wiley & Sons Ltd 40
Oral Surgery ISSN 1752-2471
the molar/premolar region corresponding to the large radiolucent lytic defect on the DPT. The border of the mandible was well circumscribed except distal to the canine, where the margin was ill-defined.
A provisional diagnosis of ‘Developing complex odontome’ was made due to the degree of radiolu- cency present and partial calcification of odontogenic tissue. ‘Ameloblastic fibro-odontome’ and ‘Odonto- ameloblastoma’ were considered in the differential diagnosis.
Biopsy of the lesion suggested a ‘Developing com- plex odontome’. MDT decision was to carefully remove the lesion under general anaesthetic.
Removal also involved a left mandibular marginal rim resection, which was then secured with a plate.
The defect was filled with bone harvested from the left iliac crest. The lower left third molar was main- tained with possible future eruption potential. The specimen was sent for further histopathological examination. The patient declined immediate replacement of the lower left mandibular teeth. In the future, further bone may need to be grafted depending on the type of long-term tooth prosthetic replacement.
Histology sections of the mandibular mass showed a lobulated lesion, comprising interconnected sheets of tubular and dysplastic dentine within which were several spaces containing remnants of basophilic enamel matrix, juxtaposed to reduced enamel epithelium. Dentine was surrounded by mesenchy- mal tissue resembling dental papilla. The latter was abundant in the central parts of the lesion, where it featured frequent islands of odontogenic epithelium comprising peripheral ameloblast-like cells and cen- tral stellate reticulum-like cells. There were no mito- tic figures or any other atypical features. Figure 3 (a and b) show histology sections. Taking into consider- ation the clinical, radiographic and histological find-
Figure 1 DPT revealing mixed radiolucent/radiopaque lesion in left mandible.
Figure 2 Axial CT scan section showing the extent of the lesion anteroposteriorly.
A B
Figure 3 (a and b) Histological slides of the developing complex odontome.
Oral Surgery10 (2017) 40--42.
© 2016 The British Association of Oral Surgeons and John Wiley & Sons Ltd
41
Aminet al. A large developing complex odontome
ings, a definitive diagnosis of a ‘Developing complex odontome’ was made.
Immediate post-operative intraoral healing was good without any defects and signs of infection of the graft and donor sites. There was slight residual paraesthesia of the areas supplied by inferior alveolar nerve on the left side which was improving with time. Six-month post-operative DPT (Fig. 4) revealed good bony healing without any recurrence.
Discussion
Large ‘Developing complex odontomas’ are rare. His- tological differential diagnosis includes ‘Developing complex odontome’ and ‘Ameloblastic fibro-odon- tome’. The latter is difficult to differentiate from the immature phase of a ‘Developing odontome’ when hard tissue formation is minimal. However, in this case, the lesion showed abundant hard tissue arranged as a central mass with radiating layers of dentine and immature enamel. The soft tissue com- ponent at the periphery comprised dental papilla- like tissue with enamel organ-like epithelium;
features not compatible with ‘Ameloblastomas’. As
‘Ameloblastoma’- like areas were not seen, the rare
‘Odonto-ameloblastoma’ was also ruled out.
Early detection and investigation of delayed erup- tion of teeth by radiographic examination would have helped in early diagnosis. This may have allowed for more conservative management and reduction of damage to local structures. Monitoring at this stage may have resulted in a pathological
fracture of the mandible. Surgical intervention in this case is unlikely to have significant affect on mandibular growth with condylar growth and sur- face remodelling is still possible.
Recurrence is rare and usually only occurs in cases of incompletely excised immature odontomes5.
Conclusion
We have reported a case of a large ‘Developing com- plex odontome’ that presented as a painless swelling in the left mandible with associated unerupted per- manent teeth. The lesion was treated by surgical excision, marginal mandibular rim resection and bone grafting from the ileac crest. There was no sign of recurrence. Early detection is key for diagnosis and treatment and can help reduce damage to local structures and patient dehabilitation.
Acknowledgement
The authors thank Professor Paul Speight, Oral &
Maxillofacial Pathology, The University of Sheffield.
Conflict of Interest
The authors confirm that there are no conflicts of interest.
Ethical Approval
None required.
References
1. Bhaskar SN. Synopsis of Oral Pathology, 6th edition.
St. Louis, MO: C.V. Mosby, 1981.
2. Kramer IRH, Pindborg JJ, Shear M. The WHO histo- logical typing of odontogenic tumours. Cancer 1992;70:2988–2994.
3. Reichart AP, Philipsen HP. Odontogenic Tumors and Allied Lesions. Quintessence: London, 2004.
4. Sheehy EC, Odell EW, Al-Jaddir G. Odontomas in the primary dentition: literature review and case report. J Dent Child (Chic) 2003;71:73–76.
5. Neville BW, Damm DD, Allen CM, Bouquot JE.
Odontogenic cysts and tumors. Oral Maxillofac Pathol 2002;3:683–687.
Figure 4 Six-month post-operative DPT.
