Slides credited from Hsueh-I Lu, Hsu-Chun Hsiao, & Michael Tsai

Mini-HW

NTU COOL

TA hours

Course recordings

Instant feedback

Classroom (crowded, sleepy, etc.)

Homework due time

Pseudo code

Mini-HW 7 released

Due on 11/29 (Thur) 14:20

Homework 3 released soon

Due on 12/13 (Thur) 14:20 (three weeks)

**3**

Frequently check the website for the updated information!

### Graph Basics

### Graph Theory

### Graph Representations

### Graph Traversal

### Breadth-First Search (BFS)

### Depth-First Search (DFS)

### DFS Applications

### Connected Components

### Strongly Connected Components

### Topological Sorting

**5**

### A graph G is defined as

V: a finite, nonempty set of vertices

E: a set of edges / pairs of vertices

**3** **5**

**1**

**4**

**2**

### Graph type

**Undirected: edge 𝑢, 𝑣 = 𝑣, 𝑢**

**Directed: edge 𝑢, 𝑣 goes from vertex 𝑢 to vertex 𝑣; 𝑢, 𝑣 ≠ 𝑣, 𝑢**

**Weighted: edges associate with weights**

**7**

**3** **5**

**1** **4**

**2**

**3** **5**

**1** **4**

**2**

How many edges at most can a undirected (or directed) graph have?

**Adjacent (相鄰)**

### If there is an edge 𝑢, 𝑣 , then 𝑢 and 𝑣 are adjacent.

**Incident (作用)**

### If there is an edge 𝑢, 𝑣 , the edge

^{𝑢, 𝑣}

### is incident from 𝑢 and is incident to 𝑣.

**Subgraph (子圖)**

### If a graph 𝐺

^{′}

### = 𝑉

^{′}

### , 𝐸′ is a subgraph of 𝐺 = 𝑉, 𝐸 , then 𝑉

^{′}

### ⊆

### 𝑉 and 𝐸

^{′}

### ⊆ 𝐸

**Degree**

### The degree of a vertex

^{𝑢}

### is the number of edges incident on

^{𝑢}

In-degree of 𝑢: #edges 𝑥, 𝑢 in a directed graph

Out-degree of 𝑢: #edges 𝑢, 𝑥 in a directed graph

Degree = in-degree + out-degree

**Isolated vertex: degree = 0**

**9**

### 𝐸 = σ

_{𝑖}

### 𝑑

_{𝑖}

### 2

**Path**

### a sequence of edges that connect a sequence of vertices

### If there is a path from 𝑢 (source) to 𝑣 (target), there is a sequence of edges 𝑢, 𝑖

_{1}

### , 𝑖

_{1}

### , 𝑖

_{2}

### , … , 𝑖

_{𝑘−1}

### , 𝑖

_{𝑘}

### , (𝑖

_{𝑘}

### , 𝑣)

**Reachable: 𝑣 is reachable from 𝑢 if there exists a path from 𝑢 to 𝑣**

**Simple Path**

All vertices except for 𝑢 and 𝑣 are all distinct

**Cycle**

**Connected**

### Two vertices are connected if there is a path between them

### A connected graph has a path from every vertex to every other

**Tree**

### a connected, acyclic, undirected graph

**Forest**

### an acyclic, undirected but possibly disconnected graph

**11**

**3** **5**

**1** **4**

**2**

**3** **5**

**1** **4**

**2**

**3** **5**

**1** **4**

**2**

### Theorem. Let 𝐺 be an undirected graph. The following statements are equivalent:

### 𝐺 is a tree

### Any two vertices in 𝐺 are connected by a unique simple path

### 𝐺 is connected, but if any edge is removed from 𝐸, the resulting graph is disconnected.

### 𝐺 is connected and 𝐸 = 𝑉 − 1

### 𝐺 is acyclic, and 𝐸 = 𝑉 − 1

### 𝐺 is acyclic, but if any edge is added to 𝐸, the resulting graph

**13**

### How to traverse all bridges where each one can only be passed through once

**A**

**B** **C** **C**

**A**

**B**

### Euler path

Can you traverse each edge in a connected graph exactly once without lifting the pen from the paper?

### Euler tour

Can you finish where you started?

**15**

**C** **A**

**B** **D**

**C** **A**

**B** **D**

**C** **A**

**B** **D**

Euler path Euler tour

Euler path Euler tour

Euler path Euler tour

### Solved by Leonhard Euler in 1736

### 𝐺 has an Euler path iff 𝐺 has exactly 0 or 2 odd vertices

### 𝐺 has an Euler tour iff all vertices must be even vertices

*Is it possible to determine whether a graph has an Euler path or an Euler tour, *
without necessarily having to find one explicitly?

Even vertices = vertices with even degrees Odd vertices = vertices with odd degrees

### Hamiltonian Path

### A path that visits each vertex exactly once

### Hamiltonian Cycle

### A Hamiltonian path where the start and destination are the same

### Both are NP-complete

**17**

### Modeling applications using graph theory

What do the vertices represent?

What do the edges represent?

Undirected or directed?

**19**

### How to represent a graph in computer programs?

### Two standard ways to represent a graph 𝐺 = 𝑉, 𝐸

### Adjacency matrix

### Adjacency list

## Matrix

**21**

### Adjacency matrix = 𝑉 × 𝑉 matrix 𝐴 with 𝐴[𝑢][𝑣] = 1 if (𝑢, 𝑣) is an edge

1 2 3 4 5 6

1 1 1

2 1 1 1

3 1 1 1

4 1 1 1

5 1

6 1 1

1

2

3

5 4

6

• For undirected graphs, 𝐴 is symmetric; i.e., 𝐴 = 𝐴^{𝑇}

• If weighted, store weights instead of bits in 𝐴

## Matrix

### Space:

### Time for querying an edge:

### Time for inserting an edge:

### Time for deleting an edge:

### Time for listing all neighbors of a vertex:

### Time for identifying all edges:

### Time for finding in-degree and out-degree of a vertex?

## List

### Adjacency lists = vertex indexed array of lists

### One list per vertex, where for 𝑢 ∈ 𝑉, 𝐴[𝑢] consists of all vertices adjacent to 𝑢

**23**

1 2 3 4 5 6

1 4

3

2 3

2

3 2

5

1 4 6

4

6 1

2

3

5 4

6

If weighted, store weights also in adjacency lists

## List

### Space:

### Time for querying an edge:

### Time for inserting an edge:

### Time for deleting an edge:

### Time for listing all neighbors of a vertex:

### Time for identifying all edges:

### Time for finding in-degree and out-degree of a vertex?

**Matrix representation is suitable for dense graphs**

**List representation is suitable for sparse graphs**

### Besides graph density, you may also choose a data structure based on the performance of other operations

**25**

**Space** **Query an **
**edge**

**Insert an **
**edge**

**Delete an **
**edge**

**List a **
**vertex’s **
**neighbors**

**Identify **
**all edges**

Adjacency Matrix Adjacency List

Textbook Chapter 22 – Elementary Graph Algorithms

**26**

### From a source vertex, systematically follow the edges of a graph to visit all reachable vertices of the graph

### Useful to discover the structure of a graph

### Standard graph-searching algorithms

Breadth-First Search (BFS, 廣度優先搜尋)

Depth-First Search (DFS, 深度優先搜尋)

**27**

Textbook Chapter 22.2 – Breadth-first search

**28**

**29**

**Source 𝒔**

**Layer 1**

**Layer 2**

### Input: directed/undirected graph 𝐺 = (𝑉, 𝐸) and source 𝑠

**Output: a breadth-first tree with root 𝑠 (𝑇**

_{BFS}

### ) that contains all reachable vertices

### 𝑣. 𝑑: distance from 𝑠 to 𝑣, for all 𝑣 ∈ 𝑉

Distance is the length of a shortest path in G

𝑣. 𝑑 = ∞ if 𝑣 is not reachable from 𝑠

𝑣. 𝑑 is also the depth of 𝑣 in 𝑇_{BFS}

### 𝑣. 𝜋 = 𝑢 if (𝑢, 𝑣) is the last edge on shortest path to 𝑣

𝑢 is 𝑣’s predecessor in 𝑇

### Initially 𝑇

_{BFS}

### contains only 𝑠

### As 𝑣 is discovered from 𝑢, 𝑣 and (𝑢, 𝑣) are added to 𝑇

_{BFS}

𝑇_{BFS} is not explicitly stored; can be
reconstructed from 𝑣. 𝜋

### Implemented via a FIFO queue

### Color the vertices to keep track of progress:

GRAY: discovered (first time encountered)

BLACK: finished (all adjacent vertices discovered)

WHITE: undiscovered

**31**

BFS(G, s)

for each vertex u in G.V-{s}

u.color = WHITE u.d = ∞

u.pi = NIL s.color = GRAY s.d = 0

s.pi = NIL Q = {}

ENQUEUE(Q, s) while Q! = {}

u = DEQUEUE(Q)

for each v in G.Adj[u]

if v.color == WHITE v.color = GRAY v.d = u.d + 1 v.pi = u

ENQUEUE(Q,v) u.color = BLACK

𝑠 0

𝑤 𝑟

1 1

𝑟 𝑡 𝑥

1 2 2

𝑡 𝑥 𝑣

2 2 2

**33**

𝑢 𝑦

3 3

𝑦 3

**Definition of 𝛿(𝑠, 𝑣): the shortest-path distance from 𝑠 to 𝑣 = the **
minimum number of edges in any path from 𝑠 to 𝑣

If there is no path from 𝑠 to 𝑣, then 𝛿 𝑠, 𝑣 = ∞

The BFS algorithm finds the shortest-path distance to each reachable vertex in a graph 𝐺 from a given source vertex 𝑠 ∈ 𝑉.

### Proof

Case 1: 𝑢 is reachable from 𝑠

𝑠- 𝑢- 𝑣 is a path from 𝑠 to 𝑣 with length 𝛿 𝑠, 𝑢 + 1

Hence, 𝛿 𝑠, 𝑣 ≤ 𝛿 𝑠, 𝑢 + 1

Case 2: 𝑢 is unreachable from 𝑠

Then 𝑣 must be unreachable too.

Hence, the inequality still holds.

**35**

Lemma 22.1

Let 𝐺 = 𝑉, 𝐸 be a directed or undirected graph, and let 𝑠 ∈ 𝑉 be an arbitrary vertex. Then, for any edge 𝑢, 𝑣 ∈ 𝐸, 𝛿 𝑠, 𝑣 ≤ 𝛿 𝑠, 𝑢 + 1.

𝑠-𝑣的最短路徑一定會小於等於𝑠-𝑢的最短路徑距離+1

s

v

𝛿 𝑠, 𝑢 u

### Proof by induction

Holds when 𝑛 = 1: 𝑠 is in the queue and 𝑣. 𝑑 = ∞ for all 𝑣 ∈ 𝑉 𝑠

After 𝑛 + 1 ENQUEUE ops, consider a white vertex 𝑣 that is discovered during the search from a vertex 𝑢

Lemma 22.2

Let 𝐺 = 𝑉, 𝐸 be a directed or undirected graph, and suppose BFS is run on 𝐺 from a given source vertex 𝑠 ∈ 𝑉. Then upon termination, for each vertex 𝑣 ∈ 𝑉, the value 𝑣. 𝑑 computed by BFS satisfies 𝑣. 𝑑 ≥ 𝛿 𝑠, 𝑣 .

BFS算出的d值必定大於等於真正距離

Inductive hypothesis: 𝑣. 𝑑 ≥ 𝛿 𝑠, 𝑣 after 𝑛 ENQUEUE ops

### Proof by induction

Holds when 𝑄 = 𝑠 .

Consider two operations for inductive step:

Dequeue op: when 𝑄 = 𝑣_{1}, 𝑣_{2}, … , 𝑣_{𝑟} and dequeue 𝑣_{1}

Enqueue op: when 𝑄 = 𝑣_{1}, 𝑣_{2}, … , 𝑣_{𝑟} and enqueue 𝑣_{𝑟+1}

**37**

Lemma 22.3

Suppose that during the execution of BFS on a graph 𝐺 = 𝑉, 𝐸 , the
queue 𝑄 contains the vertices 𝑣_{1}, 𝑣_{2}, … , 𝑣_{𝑟} , where 𝑣_{1} is the head of 𝑄
and 𝑣_{𝑟} is the tail. Then, 𝑣_{𝑟}. 𝑑 ≤ 𝑣_{1}. 𝑑 + 1 and 𝑣_{𝑖}. 𝑑 ≤ 𝑣_{𝑖+1}. 𝑑 for 1 ≤ 𝑖 < 𝑟.

• Q中最後一個點的d值 ≤ Q中第一個點的d值+1

• Q中第i個點的d值 ≤ Q中第i+1點的d值

Inductive hypothesis:𝑣_{𝑟}. 𝑑 ≤ 𝑣_{1}. 𝑑 + 1 and 𝑣_{𝑖}. 𝑑 ≤ 𝑣_{𝑖+1}. 𝑑 after 𝑛 queue ops

### Dequeue op

### Enqueue op

Inductive hypothesis:

𝑣_{1} 𝑣_{2} … 𝑣_{𝑟−1} 𝑣_{𝑟}

𝑣_{2} … 𝑣_{𝑟−1} 𝑣_{𝑟} (induction hypothesis H2)

𝑣_{1} 𝑣_{2} … 𝑣_{𝑟−1} 𝑣_{𝑟}

(induction hypothesis H2)

𝑣 𝑣 … 𝑣 𝑣 𝑣

𝑢

Let 𝑢 be 𝑣_{𝑟+1}’s predecessor,

Since 𝑢 has been removed from 𝑄, the new head
𝑣_{1} satisfies

(induction hypothesis H1) H1

H2

H1 holds

H2 holds

𝑢

(Q中最後一個點的d值 ≤ Q中第一個點的d值+1)

(Q中第i個點的d值 ≤ Q中第i+1點的d值)

### Proof

Lemma 22.3 proves that 𝑣_{𝑖}. 𝑑 ≤ 𝑣_{𝑖+1}. 𝑑 for 1 ≤ 𝑖 < 𝑟

Each vertex receives a finite 𝑑 value at most once during the course of BFS

Hence, this is proved.

**39**

Corollary 22.4

Suppose that vertices 𝑣_{𝑖} and 𝑣_{𝑗} are enqueued during the execution of BFS,
and that 𝑣_{𝑖} is enqueued before 𝑣_{𝑗}. Then 𝑣_{𝑖}. 𝑑 ≤ 𝑣_{𝑗}. 𝑑 at the time that 𝑣_{𝑗} is
enqueued.

若𝑣_{𝑖}比𝑣_{𝑗}早加入queue 𝑣_{𝑖}. 𝑑 ≤ 𝑣_{𝑗}. 𝑑

### Proof of (1)

All vertices 𝑣 reachable from 𝑠 must be discovered; otherwise they would have 𝑣. 𝑑 = ∞ > 𝛿 𝑠, 𝑣 . (contradicting with Lemma 22.2) Theorem 22.5 – BFS Correctness

Let 𝐺 = 𝑉, 𝐸 be a directed or undirected graph, and and suppose that BFS is run on 𝐺 from a given source vertex 𝑠 ∈ 𝑉.

1) BFS discovers every vertex 𝑣 ∈ 𝑉 that is reachable from the source 𝑠 2) Upon termination, 𝑣. 𝑑 = 𝛿 𝑠, 𝑣 for all 𝑣 ∈ 𝑉

3) For any vertex 𝑣 ≠ 𝑠 that is reachable from 𝑠, one of the shortest paths from 𝑠 to 𝑣 is a shortest path from 𝑠 to 𝑣. 𝜋 followed by the edge 𝑣. 𝜋, 𝑣

(2)

### Proof of (2) by contradiction

Assume some vertices receive 𝑑 values not equal to its shortest-path distance

Let 𝑣 be the vertex with minimum 𝛿 𝑠, 𝑣 that receives such an incorrect 𝑑 value; clearly 𝑣 ≠ 𝑠

By Lemma 22.2, 𝑣. 𝑑 ≥ 𝛿 𝑠, 𝑣 , thus 𝑣. 𝑑 > 𝛿 𝑠, 𝑣 (𝑣 must be reachable)

Let 𝑢 be the vertex immediately preceding 𝑣 on a shortest path from 𝑠 to 𝑣, so 𝛿 𝑠, 𝑣 = 𝛿 𝑠, 𝑢 + 1

Because 𝛿 𝑠, 𝑢 < 𝛿 𝑠, 𝑣 and 𝑣 is the minimum 𝛿 𝑠, 𝑣 , we have 𝑢. 𝑑 = 𝛿 𝑠, 𝑢

𝑣. 𝑑 > 𝛿 𝑠, 𝑣 = 𝛿 𝑠, 𝑢 + 1 = 𝑢. 𝑑 + 1

**41**

(2)

### Proof of (2) by contradiction (cont.)

𝑣. 𝑑 > 𝛿 𝑠, 𝑣 = 𝛿 𝑠, 𝑢 + 1 = 𝑢. 𝑑 + 1

When dequeuing 𝑢 from 𝑄, vertex 𝑣 is either WHITE, GRAY, or BLACK

WHITE: 𝑣. 𝑑 = 𝑢. 𝑑 + 1, contradiction

BLACK: it was already removed from the queue

By Corollary 22.4, we have 𝑣. 𝑑 ≤ 𝑢. 𝑑, contradiction

GRAY: it was painted GRAY upon dequeuing some vertex 𝑤

Thus 𝑣. 𝑑 = 𝑤. 𝑑 + 1 (by construction)

(3) For any vertex 𝑣 ≠ 𝑠 that is reachable from 𝑠, one of the shortest paths from 𝑠 to 𝑣 is a shortest path from 𝑠 to 𝑣. 𝜋 followed by the edge 𝑣. 𝜋, 𝑣

### Proof of (3)

If 𝑣. 𝜋 = 𝑢, then 𝑣. 𝑑 = 𝑢. 𝑑 + 1. Thus, we can obtain a shortest path from 𝑠 to 𝑣 by taking a shortest path from 𝑠 to 𝑣. 𝜋 and then traversing the edge 𝑣. 𝜋, 𝑣 .

**43**

BFS(G, s) forms a BFS tree with all reachable 𝑣 from 𝑠

We can extend the algorithm to find a BFS forest that contains every vertex in 𝐺

BFS-Visit(G, s) s.color = GRAY s.d = 0

s.π = NIL Q = empty ENQUEUE(Q, s) while Q ≠ empty

u = DEQUEUE(Q) for v in G.adj[u]

if v.color == WHITE //explore full graph and builds up

a collection of BFS trees BFS(G)

for u in G.V

u.color = WHITE u.d = ∞

u.π = NIL
**for s in G.V**

if(s.color == WHITE)

Textbook Chapter 22.3 – Depth-first search

**45**

Search as deep as possible and then backtrack until finding a new path

1

2

3 4

8

9 12 13

14

5 6

7

10 11

### Implemented via recursion (stack)

### Color the vertices to keep track of progress:

GRAY: discovered (first time encountered)

BLACK: finished (all adjacent vertices discovered)

WHITE: undiscovered ^{47}

// Explore full graph and builds up a collection of DFS trees

DFS(G)

for each vertex u in G.V u.color = WHITE

u.pi = NIL

time = 0 // global timestamp for each vertex u in G.V

if u.color == WHITE DFS-VISIT(G, u)

DFS-Visit(G, u) time = time + 1

u.d = time // discover time u.color = GRAY

for each v in G.Adj[u]

if v.color == WHITE v.pi = u

DFS-VISIT(G, v) u.color = BLACK

time = time + 1

u.f = time // finish time

### Parenthesis Theorem

Parenthesis structure: represent the discovery of vertex 𝑢 with a left

parenthesis “(𝑢” and represent its finishing by a right parenthesis “𝑢)”. In DFS, the parentheses are properly nested.

### White Path Theorem

In a DFS forest of a directed or undirected graph 𝐺 = 𝑉, 𝐸 ,

vertex 𝑣 is a descendant of vertex 𝑢 in the forest at the time 𝑢. 𝑑 that the search discovers 𝑢, there is a path from 𝑢 to 𝑣 in 𝐺 consisting entirely of WHITE vertices

### Classification of Edges in 𝐺

Tree Edge

### Parenthesis Theorem

Parenthesis structure: represent the discovery of vertex 𝑢 with a left parenthesis “(𝑢” and represent its finishing by a right parenthesis

“𝑢)”. In DFS, the parentheses are properly nested.

**49**

Properly nested: (x (y y) x) Not properly nested: (x (y x) y)

Proof in textbook p. 608

### White Path Theorem

In a DFS forest of a directed or undirected graph 𝐺 = 𝑉, 𝐸 ,

vertex 𝑣 is a descendant of vertex 𝑢 in the forest at the time 𝑢. 𝑑 that the search discovers 𝑢, there is a path from 𝑢 to 𝑣 in 𝐺 consisting entirely of WHITE vertices

### Proof.

Since 𝑣 is a descendant of 𝑢, 𝑢. 𝑑 < 𝑣. 𝑑

Hence, 𝑣 is WHITE at time 𝑢. 𝑑

In fact, since 𝑣 can be any descendant of 𝑢, any vertex on the path from 𝑢

### Classification of Edges in 𝐺

Tree Edge (GRAY to WHITE)

Edges in the DFS forest

Found when encountering a new vertex 𝑣 by exploring 𝑢, 𝑣

Back Edge (GRAY to GRAY)

𝑢, 𝑣 , from descendant 𝑢 to ancestor 𝑣 in a DFS tree

Forward Edge (GRAY to BLACK)

𝑢, 𝑣 , from ancestor 𝑢 to descendant 𝑣. Not a tree edge.

Cross Edge (GRAY to BLACK)

Any other edge between trees or subtrees. Can go between vertices in same DFS tree or in different DFS trees

**51**

In an undirected graph, back edge = forward edge.

To avoid ambiguity, classify edge as the first type in the list that applies.

### Edge classification by the color of 𝑣 when visiting 𝑢, 𝑣

WHITE: tree edge

GRAY: back edge

BLACK: forward edge or cross edge

𝑢. 𝑑 < 𝑣. 𝑑 forward edge

𝑢. 𝑑 > 𝑣. 𝑑 cross edge

Theorem 22.10

In DFS of an undirected graph, there are only tree edges and back edges

### Connected Components

### Strongly Connected Components

### Topological Sort

**53**

**54**

### Input: a graph 𝐺 = 𝑉, 𝐸

### Output: a connected component of 𝐺

**a maximal subset 𝑈 of 𝑉 s.t. any two nodes in 𝑈 are connected in 𝐺**

Why must the connected components of a graph be disjoint? **55**

1

2

5

3 4

6

7

8 9

**57**

**58**

Course Website: http://ada.miulab.tw Email: ada-ta@csie.ntu.edu.tw

**59**

Important announcement will be sent to @ntu.edu.tw mailbox

& post to the course website
