Journal of Network and Computer Applications 193 (2021) 103212

Available online 7 September 2021

Contents lists available atScienceDirect

Journal of Network and Computer Applications

journal homepage:www.elsevier.com/locate/jnca

CREME: A toolchain of automatic dataset collection for machine learning in intrusion detection

Huu-Khoi Bui

^a

, Ying-Dar Lin

^a

, Ren-Hung Hwang

^b^,∗

, Po-Ching Lin

^b

, Van-Linh Nguyen

^b^,^c

, Yuan-Cheng Lai

^d

aDepartment of Computer Science, National Chiao Tung University, Hsinchu City 300, Taiwan

bDepartment of Computer Science and Information Engineering, National Chung Cheng University, Chiayi County 621, Taiwan

cDepartment of Information Technology, TNU-University of Information and Communication Technology, Thai Nguyen, Viet Nam

dDepartment of Information Management, National Taiwan University of Science and Technology, Taipei City 106, Taiwan

A R T I C L E I N F O

Keywords:

Dataset toolchain Intrusion detection Machine learning Security dataset Dataset generation Dataset evaluation Multiple data sources

A B S T R A C T

Intrusion detection is one of the most common approaches for addressing security attacks in modern networks.

However, given the increasing diversity of attack behaviors, efficient detection becomes more challenging.

Machine learning (ML) has recently dominated as one of the most promising techniques to improve detection accuracy for intrusion detection systems(IDS). With ML-based approaches, a quality dataset for training holds the key to gain high detection performance. Unfortunately, there are few methods to assess the dataset quality, and specifically for ML training. This work presents an automated toolchain, termed CREME (Configuration, REproduction, Multi-dataset, and Evaluation), to generate a dataset and measure its quality and efficiency. CREME integrates various tools to automate all stages of configuration, attack and benign behavior reproduction, data collection, feature extraction, data labeling, and evaluation. CREME can also automatically collect and generate a dataset from multiple sources such as accounting, network traffic, and system logs. Compared with the available datasets in the same category, experiment results show that the datasets generated by CREME contribute up to 20% better performance to ML-based IDS in terms of coverage.

They also have significantly better efficiency than most other datasets. The CREME source code is available athttps://github.com/buihuukhoi/CREME.

1. Introduction

Dataset is the key to the success of a machine-learning-based intrusion detection system (ML-based IDS). Without a suitable dataset, ML-based IDS detection performance can be even worse than conventional approaches such as signature-based IDS. Choosing correct data sources when generating a dataset is vital for increasing the behavioral diversity and further enriching data inputs for ML training — which is the key to high detection performance. Data sources can broadly be classified into three types: network packets, accounting, and system logs. Several recent papers (Singh et al., 2015; Song et al., 2011;

Moustafa and Slay, 2015;Kang et al., 2019;Koroniotis et al., 2019) have proposed to generate datasets for specific training requirements and applications. For example, Zhang et al. (2019) are in favor of using system logs for host-based IDS while Shi et al. (2019) prefer network traffic for network-based IDS. Both of these approaches have their shortcomings. Given the increase in the use of secure protocols

∗ Corresponding author.

E-mail addresses: [email protected](H. Bui),[email protected](Y. Lin),[email protected](R. Hwang),[email protected](P. Lin), [email protected](V. Nguyen),[email protected](Y. Lai).

in communications, decoding encrypted packets in the network and classifying them is already a challenge (Xing and Wu,2020). On the other hand, detecting malware running in a host cannot rely only on inspecting the network packets (Hwang et al.,2020).

Combining multiple types of datasets to enhance attack detection performance is an emerging approach. The data from numerous sources can significantly contribute to exposing the entire path of an attack. For example, papers byBeer et al.(2017) andTurcotte et al.(2017) propose a simple combination of network packets and system logs for generating synthetic datasets. These authors found that a system log can record relevant information about malware activities that is impossible to find in network traffic.Moustafa(2019) collected a dataset from both network packets and accounting sources and found that accounting log entries such as resource usage statistics are critical for exposing mining and DoS attacks. Unfortunately, most of the collecting methods are

https://doi.org/10.1016/j.jnca.2021.103212

Received 20 March 2021; Received in revised form 8 August 2021; Accepted 27 August 2021

(2)

difficult to reproduce. Critically, there have also been few studies on providing a toolchain to validate the quality of the generated datasets.

This work presents our first attempt at creating an automated toolchain for generating and validating datasets from multiple sources.

The research addresses three challenges as follows. (1) Correct combina- tion of dataset types. The goal is to increase information about attacks or legitimate activities that benefit the ML-based IDS. For many available datasets, it is unclear how to quantify the amount of data per type and specify the combination order when designing a testbed. Mixed data, without a correct configuration, will probably decrease the accu- racy of ML training. (2) Reproducible Datasets. Generally, most studies evaluate the ML models with public datasets. Unfortunately, there is a disparity between a public network/host’s activities and internal sites (e.g., in enterprise companies). Reproducing a dataset from the sources of the internal networks/hosts, such as protection targets, will increase the detection accuracy of the ML and reduce the negative impact of the disparity. (3) Automation. Data collection, feature extraction, data labeling, and evaluation are often time-consuming tasks, let alone the tremendous challenge of carrying them at scale. In this case, the automation of doing such tasks is vital.

Addressing these challenges, our built-in toolchain can automatically carry out data collection, feature extraction, data labeling, and assessing a dataset’s quality from various sources. This toolchain consists of a centralized controller that collects and aggregates reports from the clients at the network branches or distributed hosts. The central server can also decode periodic messages from monitoring software and statistical programs, e.g., Atop. In a typical configuration, a testbed runs on a honeynet of virtual machines. Target servers are under many types of notorious attacks, e.g., DDoS attacks or brute force. A data logger server is then designed to collect data from all these target servers periodically. This research aims to answer the following essential questions:

(1) What is the quality of a generated dataset in terms of quantified metrics, such as coverage and efficiency? (2) Whether ML can work effectively on different data sources to detect specific security attacks?

(3) Which are the critical factors and lessons learned to build a useful dataset for ML-based IDS?

1.1. Contributions

The main contributions of this work are summarized as follows.

First, we provide an open-source automated framework for collecting multiple-sources datasets that the other researchers can use to do in their enterprise environment for specific research. Second, this work provides a basic validation to evaluate the generated datasets. The evaluation results demonstrate the advantages of our collection method in terms of coverage and efficiency, compared to several typical IoT datasets and conventional IT datasets. The datasets can partially enrich data for causality-inspired ML/DL-based IDS research. To the best of our knowledge, the toolchain is the first attempt of its kind.

1.2. Organization of the paper

The rest of the paper is organized as follows. In Section 2, we present earlier work on building a dataset for the ML-based IDS. In Sec- tion3, we describe the background of attack models and ML techniques for detection. In Sections4and5, the challenges of doing automated dataset generation and evaluation frameworks are described. In Sec- tion6, we describe our design of the toolchain and the implementation of a testbed in detail. In Section7, the experiment results are presented.

Finally, conclusions and future work are given in Section8.

2. Related work

This section discusses several datasets that have been specifically designed for ML-based IDS and the methods to validate their effective- ness. To this end, a comparison of the performance of several datasets is also given.

There are two approaches to collect datasets. The first one is to collect data packets in conventional IP-based networks. For example, the study ofSingh et al.(2015) provides a synthetic network-traffic dataset with two labeling levels for the IDSs. The dataset is generated based on NSLKDD dataset’s basic characteristics that do not contain activity- based labeling. Kyoto 2006+ dataset (Song et al., 2011) is collected with three years of real traffic data from honeypots. All traffic data are labeled by inspecting them using security software. Recently,Moustafa and Slay (2015) presented a comprehensive approach to collect a UNSW-NB15 dataset by using the IXIA PerfectStorm tool. The newer approach to collect IoT datasets where data row can be IP or non-IP traffic. For IP-based traffic, the data are collected through capturing packets at the network between the IoT gateways and the central IoT applications, e.g., from MQTT, DNS, FTP, HTTP, and SSH protocols.

5-tuple (a source IP address/port number, destination IP address/port number, and the protocol) is then used as the unique field to identify traffic from different users. For non-IP traffic, the data are often collected through capturing packets at the IoT gateways. As designing for low-cost devices, the data from these non-IP protocols (e.g., MQTT) often support several fields only, such as device address, timestamp, state, value. In this case, the device address in the IoT packets will be used as the unique field to separate the traffic from different devices.

As a typical example in the work ofAnagnostopoulos et al.(2020), the data row of a Bluetooth packet includes several simple fields (source address, destination address, data length, method of protocol, service, value (0x00000004, 0x00000001, 1570733035.823057, 43, man, 4, 62)).

For dataset collection, the authors inKang et al.(2019) present an IoT dataset that consists of various network attacks on two typical smart home devices. The Bot-IoT dataset (Koroniotis et al., 2019; Khraisat et al.,2019) combines legitimate and attack traffic from a real testbed environment. The authors present a simple approach to quantify the quality of the dataset using Correlation Coefficient and Entropy. The IoT-23 dataset (Laboratory, 2020) contains both attack behavior (20 malicious scenarios from 12 malware on Raspberry Pi) and benign activities (collected from 3 smart IoT devices). Since the studies focus on the network-based IDS, that datasets (Singh et al.,2015;Song et al., 2011; Moustafa and Slay, 2015; Koroniotis et al.,2019; Laboratory, 2020) consists of network traffic only. With recent developments of machine learning (ML) and deep learning (DL) technologies, many scholars start eyeing collecting multi-source datasets to enrich data for generative ML/DL learning models. For example, the studies inBeer et al.(2017),Turcotte et al.(2017),Hassan et al.(2020),Cinque et al.

(2020) present the methods to generate a dataset from both traffic data and system logs. In the other work,Moustafa(2019) presented a Ton_IoT dataset that combines both network traffic and accounting data.

However, researchers need to identify whether their built-in datasets are effective in specific measurements and how they are competitive with many available datasets. For this issue,Haider et al.

(2017) presents the first attempt to evaluate an NGIDS-DS dataset in terms of attack and benign coverage. The shortcoming is that the work did not assess and correlate the dataset’s quality with ML-based IDS systems.Gharib et al.(2016) andSharafaldin et al.(2018) intro- duce several more evaluation metrics such as network configuration, traffic coverage, labeled dataset, available protocols, attack diversity, anonymity, heterogeneity, feature set, and metadata.Table 1shows the existing datasets for a security domain, where nw is network traffic;

sl is syslog; ac is accounting; cov is coverage; eff is efficiency; acc

(3)

JournalofNetworkandComputerApplications193(2021)103212

3 H.Buietal.

Table 1

Comparison of various datasets and ours.

Platform Dataset Data sources Problem Solution Metrics Tool-

chain

nw sl ac cov eff acc

Traditional network

PU-IDS (Singh et al.,2015)

O X X

Labeling traffic activity

Synthetic dataset based on NSL KDD

X X X X

Kyoto 2006+ (Song et al.,2011)

Common security attacks

Real traffic from honeypots

X X X

UNSW-NB15 (Moustafa and Slay, 2015)

Mixed benign and attacks behaviors

IXIA Perfect Storm framework

X X X

NGIDS-DS (Haider et al.,2017)

Realistic dataset IXIA Perfect Storm O X X

CICIDS (Sharafaldin et al.,2018)

Assess existing datasets

Cover 11 criteria O X O

NDSec-1 (Beer

et al.,2017) O O X Find attack

composition

Framework to analyze

X X X

Unified Host and Network (Turcotte et al.,2017)

Collect enterprise networks dataset

Combination of network traffic, windows log

X X X

IoT network

IoT-NID (Kang

et al.,2019) O X X

Collect network attacks traffic

A framework to collect

X X X

Bot-IoT (Koroniotis et al.,2019)

Realistic botnet traffic dataset

Set up realistic testbed

X O O

IoT-23 (Laboratory, 2020)

Collect real malware dataset

12 malwares on raspberry PI

X X X

Ton_IoT (Moustafa, 2019)

O X O Collect

heterogeneous datasets

Build a new architectural IoT testbed (3 tiers)

X X X

Our dataset (CREME)

O O O Assess dataset

quality, multi-data sources, automated dataset generation

A automated toolchain

O O O O

X: Not supported; O: Supported.

(4)

is accuracy. The cov and eff metrics are used to evaluate a dataset’s quality, and the acc metric is used to evaluate the ML models.

For building large-scale datasets, data collection and processing automation are vital.Al-Hadhrami and Hussain(2020) proposed a dataset auto-generation platform in IoT networks. However, the platform is not open to independent validation. Another promising framework is CALDERA,¹which is open-source. CALDERA can enable data collection and processing automation. CALDERA also supports MITRE ATT&CK, a globally accessible knowledge base of adversary tactics and techniques.

But CALDERA is not designed to generate a dataset. Inspired by the CALDERA approach, this work presents an automated toolchain to support security dataset generation and validation. The toolchain enables automation for multi-tasks: data collection, attack replay, and data processing. Further, the platform also supports generating a dataset from multiple data sources, e.g., network traffic, system log, accounting.

Unlike prior work, the generated datasets are also validated in terms of coverage and efficiency in detail.

In summary, compared with the state-of-the-art studies, this work aims to collect multiple-sources datasets in heterogeneous environ- ments, which few scholars weigh in. This dataset is particularly useful for IDS in detecting several attacks. For example, network traffic may reveal little evidence of a real threat of malware spread if the attacker compresses payload or transfers malicious content in many fragments.

The abnormal behavior of the scripts (from the transferred traffic) only becomes apparent if they are active to participate in an attack, e.g., modify a specific file, open a port or send a large volume of DDoS traffic. As a result, monitoring all three data sources can benefit an IDS to figure out which data passed through the traffic filter/deep packet inspection but become malicious entities after storing in the IoT devices. Our preliminary results showed that different data source is more critical for intrusion detection at different attack stage and a combined dataset of multiple data sources can achieve the best F1 score of the intrusion detection by applying machine learning algorithms (Wang, 2021).

3. Attack model and scenarios for generating dataset

This section covers the principle concepts of advanced persistent threat attacks. Through the lens of attack models, we outline five scenarios that are used in this work to generate a dataset.

3.1. Attack model

An attack model is a combination of different attack stages to reach a specific goal. The attack model can provide a better understanding of the goal of the attacks and the behavior of adversaries before and after attacks occur. Further, understanding the attack model can benefit defenders in choosing suitable security mechanisms and identifying potential vulnerabilities in a system (Al-Mohannadi et al.,2016) There are various attack models, such as the pyramid model and graph model.

MITRE ATT&CK Matrix²one of the best model. MITRE ATT&CK uses 12 tactics: initial access, execution, persistence, privilege escalation, defense evasion, credential access, discovery, lateral movement, collection, command and control, ex-filtration, and impact. To match the matrix with practical attacks, the MITRE Corporation created adversary simulation plans.³APT3 is one of the most common plans to test security issues in IT networks. However, currently, APT3 does not support IoT networks. Based on the well-organized plan in APT3, we develop a general attack scenario for IoT networks with several components borrowed from the APT3 architecture.

1 https://github.com/mitre/caldera.

2 https://attack.mitre.org/matrices/enterprise/.

3 https://attack.mitre.org/resources/adversary-emulation-plans/.

3.2. Attack scenarios

Our attack scenario includes three attack stages: initial access, compromise and propagation, and complete mission. The initial access stage aims to get access to a system. Reconnaissance, scanning, and exploitation are common steps in this stage. Several other steps such as privilege escalation and defense evasion can be carried out in the compromise and propagation stage. We design five attack scenarios:

Mirai botnet, ransomware, disk wipe, resource hijacking, and end-point DoS. Since launching large-scale attacks from non-IP IoT devices is a challenge as a result of their simplicity and low energy, in this work, we simulate the attacks from IP-enabled devices only. The researchers can update our attack scripts to support non-IP devices in the future.

The details of the attack scenarios are as follows.

Mirai botnet: Mirai is a worm-like malware family that exploits default accounts in IoT devices via telnet and SSH services (Kolias et al., 2017;Antonakakis et al.,2017). The source code of Mirai is available on the Internet. Initially, Mirai scans all the hosts that are running a telnet service. Using a hardcoded dictionary of username/password, Mirai launches brute force attacks to find the victims’ telnet accounts.

After intruding on the devices successfully, the cracked username and password are reported to a CnC server. The information will later be used to login and update malicious programs to the injected devices.

The targets actually become zombies in the botnet, which was com- manded by the CnC server. In a volumetric attack such as DDoS, the attacker often use the CnC server to command all the live bots sending a large amount of traffic to the victim server.

Ransomware: Ransomware is one of the most damaging attacks that many cybercriminals have used to blackmail a victim. In this case, the hackers encrypt data or folders on the victim’s computers or workstations. In our testbed, a server is set up with a vulnerability in the IRC service. Ransomware can exploit the vulnerability to gain access to the server with the root privilege. In order to maintain future access, a backdoor can be installed on the server. Finally, the data of the server will be encrypted by using a Bash-ransomware open-source tool.

Disk wipe: Other than encrypting the data, an attacker can choose to destroy the data on a server. The server can consequently not provide clients services or even reboot if the boot folder is wiped. For this scenario, the setup server runs a web application that contained a Ruby on Rails vulnerability for exploitation. After compromising the target, the attacker can freely install a backdoor and access the server in the future. Note that, even if the vulnerability is patched, the attacker can still connect to the server using the backdoor and reinstall other malware to wipe out data.

Resource hijacking: Instead of destroying the system, an attacker can use the system’s resources for mining cryptocurrency. To simulate this scenario, a server is set up with a vulnerability on the Apache continuum service. A backdoor is then installed after exploiting the vulnerability successfully to establish a backdoor connection for further attacks.

End-point DoS: This attack simulates taking down all the services of a server by consuming all the server resources. In this scenario, the IRC service’s vulnerability is exploited to intrude on the server and create a hidden root account for future access. Using the root account, the attacker can remotely install and execute the malicious code.

4. Automated dataset generation and evaluation

This section covers the measurement metrics used to evaluate the quality of a generated dataset.Table 2 shows the notations used in this work, which are classified into four categories. The attack and benign category mean two types of programs used to generate abnormal and benign behavior. The category can also denote the machines that are used to represent entities in the system. There are six types of machines: vulnerable client, non-vulnerable clients, controller, data logger server, attacker servers, malicious client. Raw data, extracted data, sub-datasets, and dataset denote data types.

(5)

Journal of Network and Computer Applications 193 (2021) 103212

5 H. Bui et al.

Table 2

Notations used in this work.

Category Notation Name

Attacks and programs

𝑎_𝑛, 𝑛∈ [1, 𝑁], N : number of predefined attacks Attacks 𝑏_𝑚, 𝑚∈ [1, 𝑀], M : number of predefined benign programs Benign programs

𝑠𝑒𝑟_𝑔, 𝑔∈ [1, 𝐺], G: number of servers Servers

𝑣_ℎ, ℎ∈ [1, 𝐻], H : number of vulnerable clients Vulnerable clients 𝑛𝑣_𝑙, 𝑙∈ [1, 𝐿], L: number of non-vulnerable clients Non-vulnerable clients

𝑐 Controller

𝑑𝑙𝑠 Data logger server

𝑎𝑠𝑒𝑟 Attacker server

𝑚𝑐 Malicious client

Data types

𝑟_𝑖, 𝑖∈ [1, 𝑆], S: number of data sources Raw data

𝑒𝑡_𝑖, 𝑖∈ [1, 𝑆] Extracted data

𝑑_𝑖, 𝑖∈ [1, 𝑆] Sub-datasets

𝐷, 𝛴^𝑆_𝑖=1𝑑_𝑖,{𝑑𝑖, 𝑖∈ [1, 𝑆]} Dataset

Metrics

𝑐𝑜𝑣^𝐷 Coverage

𝑒𝑓 𝑓^𝑑^𝑖, 𝑖∈ [1, 𝑆] Efficiency

𝑎𝑐𝑐^𝑑^𝑖, 𝑖∈ [1, 𝑆] Accuracy

𝑓1𝑠𝑐𝑜𝑟𝑒^𝑑^𝑖, 𝑖∈ [1, 𝑆] F1 score

Parameters

𝑤_𝑗, 𝑗∈ [1, 𝐶], C: number of criteria Weight of criteria

𝑣_𝑗, 𝑗∈ [1, 𝐶] Value of criteria

𝑚𝑎𝑥𝑣_𝑗, 𝑗∈ [1, 𝐶] Max value of criteria

𝑛𝑖𝑓^𝑑^𝑖, 𝑖∈ [1, 𝑆] Number of important features

𝑛𝑎𝑓^𝑑^𝑖, 𝑖∈ [1, 𝑆] Number of all features

4.1. Measurement metrics for evaluating the quality of a generated dataset

There are two metrics used in this research to validate the quality of the generated dataset: coverage and efficiency. Details of the metrics are listed as follows.

Coverage. This metric aims to measure the attack diversity, traffic completion, available protocols, features, metadata, etc. The higher coverage a dataset is, the richer data or closer to the real situation the dataset supports. In fact, with an ML-based IDS, rich data for training is crucial. The dataset should include a broad range of different attack scenarios to cover real situations. Attack types, staged attack scenarios, data sources, labeled data, feature set, and metadata criteria are the main parameters for validating the coverage metric in this work. The attack typescriteria represent the number of attack types covered in a dataset. The attack type denotes the kind of security attacks such as DoS or port scanning. The staged attack scenario means a sequence of different attack types used by the attacker to achieve the intrusion target. For example, the Mirai scenario contains attack types such as scanning, brute force, backdoor, DDoS. The data sources criteria mean the number of data sources used to collect data. More data sources in consideration can give a better chance to detect sophisticated attacks.

For example, if an IDS fails to detect scanning attacks with network packets, the engine still has another chance to find out the attacks by analyzing system logs. Correct labeled data, like a ground truth, is another important criterion for validating the detection result. For an ML-based IDS, the feature sets are also crucial, and extracting them is quite time-consuming, given the diversity of large-scale raw data.

Other than the criteria mentioned above, metadata is an important tag to describe a dataset’s detail for later reference. In summary, inspired by the work ofGharib et al.(2016), the coverage metric in our work is the total of weighted criteria’s score. The coverage score is measured as follows:

𝑐𝑜𝑣^𝐷= 𝛴_𝑗=1^𝐶 𝑤_𝑗∗ 𝑣_𝑗 𝑚𝑎𝑥_𝑣

𝑗

(1)

where 𝐶 is the number of criteria; 𝑤_𝑗 a weight for each criterion, and can be set to different values based on the requirements at the running time. The sum of 𝑤_𝑗 is equal to 1. 𝑣_𝑗 the value of each criterion and a non-negative integer that is not greater than 𝑚𝑎𝑥_𝑣

𝑗; 𝑚𝑎𝑥_𝑣

𝑗 is the maximum value of each criterion; 𝐷 is the dataset as noted inTable 2.

Suppose that 𝑤_𝑗 and 𝑚𝑎𝑥_𝑣

𝑗 are the sets based on the requirement of researchers.

Let consider an example by calculating the coverage scores for two datasets Kyoto 2006+Song et al.(2011) and NDSec-1Beer et al.

(2017). As attack types and staged attack scenarios have the highest value at around ten in previous work, we set its max value to twenty to have room for more attacks. Similarly, a staged attack scenario can consist of a set of exploitation and attacks up to 20. Generally, the highest value of data sources, labeled data, and features set is set at 3 in default. However, we double the maximum value (e.g., 6) for these three metrics to enrich and open the room for future usage. The maximum value of metadata is to present a binary set, i.e., 1 (yes) or 0 (no). In summary, the considered maximum values for different criteria are [20, 20, 6, 6, 6, 1]. The weights are then calculated by the importance of criteria [0.4, 0.2, 0.1, 0.1, 0.1, 0.1]. Based on the values of two datasets fromTable 6, the coverage scores of the two datasets were calculated as follows: 𝑐𝑜𝑣^{𝐾𝑦𝑜𝑡𝑜}=^0.4∗8

20 +^0.2∗0

20 +^0.1∗1

6 +^0.1∗1

1 =

0.310; 𝑐𝑜𝑣^{𝑁 𝐷𝑆𝑒𝑐−1}= ^0.4∗9

20 +^0.2∗3

20 +^0.1∗2

6 +^0.1∗1

6 + ^0.1∗1

6 +^0.1∗1

1 = 0.377.

In this example, the NDSec-1 has a higher coverage score as a result of rich attack types and features.

Efficiency. Given a dataset with many features, it is essential to figure out which features in the dataset are useful for training. Gen- erally, the ML-based IDS can work at best by using various important features. Because of the importance of these features, any failure to remove one of them can negatively impact on the performance of the ML-based IDS (Chandrashekar and Sahin,2014). Selecting the correct features is still by far the biggest challenge. Efficiency is then a metric that quantifies the sufficiency of important features in the generated dataset. The efficiency metric is calculated as the ratio between the number of useful features and the number of all features in the dataset.

The efficiency score is measured as 𝑒𝑓 𝑓^𝑑^𝑖= 𝑛𝑖𝑓^𝑑^𝑖

𝑛𝑎𝑓^𝑑^𝑖 (2)

where 𝑛𝑖𝑓 is the number of important features; 𝑛𝑎𝑓 is the number of all features, and 𝑑_𝑖is the notation noted inTable 2.

Accuracy. The accuracy 𝑎𝑐𝑐 is defined by : 𝑎𝑐𝑐= 𝑇 𝑃+ 𝑇 𝑁

𝑇 𝑃+ 𝑇 𝑁 + 𝐹 𝑃 + 𝐹 𝑁, (3)

where 𝑇 𝑃 is true positive, 𝑇 𝑁 is true negative, 𝐹 𝑃 is false positive, 𝐹 𝑁 is false negative. Accuracy is a critical metric for measuring the efficiency of the ML-based IDS.

F1 score. F1 score is also used to examine the ML result on our generated datasets. The score 𝐹 1 is defined as:

𝑠𝑐𝑜𝑟𝑒=2 ∗ 𝑝𝑟𝑒𝑐𝑖𝑠𝑖𝑜𝑛 ∗ 𝑟𝑒𝑐𝑎𝑙𝑙

𝑝𝑟𝑒𝑐𝑖𝑠𝑖𝑜𝑛+ 𝑟𝑒𝑐𝑎𝑙𝑙 , (4)

(6)

where 𝑝𝑟𝑒𝑐𝑖𝑠𝑖𝑜𝑛 measures the percentage of 𝑇 𝑃 among the total of 𝑇 𝑃 and 𝐹 𝑃 , 𝑟𝑒𝑐𝑎𝑙𝑙 measures the percentage of 𝑇 𝑃 among the total of 𝑇 𝑃 and 𝐹 𝑁. 𝑝𝑟𝑒𝑐𝑖𝑠𝑖𝑜𝑛 and 𝑟𝑒𝑐𝑎𝑙𝑙 are defined as follows.

𝑝𝑟𝑒𝑐𝑖𝑠𝑖𝑜𝑛= 𝑇 𝑃

𝑇 𝑃+ 𝐹 𝑃 (5)

𝑟𝑒𝑐𝑎𝑙𝑙= 𝑇 𝑃

𝑇 𝑃+ 𝐹 𝑁 (6)

The accuracy metric can be used to support finding the number of useful features in a dataset or evaluate the efficiency. The idea to find the number of useful features is described as follows. Features are considered important features if they can achieve acceptable accuracy with fewer features. The acceptable accuracy is a threshold provided by the user. Let consider an example: a dataset has 100 features. We try to find the efficiency of different feature combinations (from 1–

100). Let say the acceptable accuracy is 0.98 (the user can accept to lose 0.02 of accuracy, but they want to reduce the number of used features to accelerate the training or detection speed). Then we found a combination of 40 features that can achieve at least 0.98 of accuracy.

So, the efficiency is ⁴⁰

100 = 0.4.

4.2. Data collection, assessment, and challenges

The first task of generating a dataset 𝐷 is to set up configuration parameters: vulnerable clients 𝑣_ℎ, non-vulnerable client 𝑛𝑣_𝑙, servers 𝑠𝑒𝑟_𝑔, a controller 𝑐, a data logger server 𝑑𝑙𝑠, an attacker server 𝑎𝑠𝑒𝑟, a malicious client 𝑚𝑐, a set of multiple data sources (traffic, syslog, and accounting), a set of support attacks 𝑎_𝑛 and benign programs 𝑏_𝑚. After collecting this data, the measurement metrics (coverage 𝑐𝑜𝑣 and efficiency 𝑒𝑓 𝑓 ) are used to quantify the quality of 𝐷. The dataset 𝐷 can include several sub-datasets, such as 𝑑_𝑖and ground truth. The second objective is to maximize the dataset quality in terms of two metrics:

𝑐𝑜𝑣^𝐷, 𝑒𝑓 𝑓^𝑑^𝑖. Subject to diversity constraints, the attacks 𝑎_𝑛need to be uncontrollably replayed, and the data of 𝑎_𝑛must be distinguished from the data of 𝑏_𝑚. For simplicity, we separate the collecting and measure- ment problem into various sub-problems, auto-configuration, behavior reproduction, multi-data sources, and dataset quality. The sub-problems are described as follows.

Auto-configuration. The goal of this task is to automatically con- figure for attacks 𝑎_𝑛and benign programs 𝑏_𝑚or the other information, e.g., hostname, ip, username, password about 𝑣_ℎ, 𝑛𝑣_𝑙, 𝑠𝑒𝑟_𝑔, 𝑐, 𝑑𝑙𝑠, 𝑎𝑠𝑒𝑟, and 𝑚𝑐 (defined inTable 2). Performing an auto-configuration for all the programs in distributed workstations is a challenge, particularly if doing that from a remote server.

Behavior reproduction. Given attacks 𝑎_𝑛and benign programs 𝑏_𝑚, the task determines a method to generate malicious behaviors for 𝑎_𝑛 and benign behaviors for 𝑏_𝑚, to reproduce the behaviors for 𝑎_𝑛 and 𝑏_𝑚 automatically. The challenge is to connect different attack stages and combine the collected data with building a consistent attack path or benign traffic. For this, we build a graphic interface to support adjusting system parameter configurations visually.

Multi-data sources. Given the behavior of attack 𝑎_𝑛 and benign programs 𝑏_𝑚, this phase proposes a method of generating the datasets along with the ground truth from the three data sources, network traffic, system log, and accounting statistics. The challenge is to distinguish and label the attack and benign data.

Dataset quality assessment. Given a dataset 𝐷 generated from different data sources, this phase — designs a toolchain to validate the output values of 𝑐𝑜𝑣^𝐷and 𝑒𝑓 𝑓^𝑑^𝑖, and improve the quality of the dataset 𝐷. The challenge is to calculate 𝑐𝑜𝑣^𝐷and 𝑒𝑓 𝑓^𝑑^𝑖 metrics accurately.

5. CREME - a toolchain with dataset generation and quality as- sessment

The CREME (Configuration, REproduction, Multi-dataset, and Evaluation) is a framework of multi-built-in components. The CREME can automatically generate datasets and quantify the datasets’ quality.

This section presents the principles of the framework and the key components in detail.

Fig. 1. CREME’s architecture design.

5.1. System architecture overview

Fig. 1shows CREME’s architecture. There are seven key processing steps. In the first step, the control module collects the setting configuration (𝑎_𝑛, 𝑏_𝑚, 𝑠𝑒𝑟_𝑔, 𝑣_ℎ, 𝑛𝑣_𝑙, 𝑐, 𝑑𝑙𝑠, 𝑎𝑠𝑒𝑟, and 𝑚𝑐) from the user/researcher (via website GUI). Based on the demand (setting), the control module calls to run software and service scripts (Step 2) and then launch attack scenario (Step 3). The control module is set at the central server and can connect with the service scripts/attack tools on the distributed workstation through gRPC/SCP tool. During the collection period, the data collected 𝑟_𝑖 at the workstations are then uploaded into the centralized server for storing. In the next steps, the data 𝑟_𝑖are then extracted (Step 4), labeled (Step 5), and evaluated (Step 6) to retrieve the final results 𝐷 for the performance analysis statistic in terms of the coverage and efficiency metrics (Step 7). Every step runs automatically. The modules are open-source code for customizing. A centralized controllercan remotely connect to the virtual machines and execute these modules.

5.2. Centralized controller

The centralized controller consists of two independent modules:

configuration and data reproduction. The objectives of each module are detailed as follows.

Controller configuration. The purpose of this module is to auto- mate the configuration and process flow. As illustrated in Fig. 2, a controller 𝐶 can connect to a data logger server 𝑑𝑙𝑠, non-vulnerable clients 𝑛𝑣_𝑙, vulnerable clients 𝑣_ℎ, servers 𝑠𝑒𝑟_𝑔, an attacker server 𝑎𝑠𝑒𝑟, a malicious client 𝑚𝑐 to install and configure the parameters (hostname, IP address, username, password). Theoretically, the controller 𝐶 can remotely connect to every machine to install and configure related services/programs without a privilege escalation attack. For examples, an Atop⁴ program can be installed on the machine 𝑠𝑒𝑟_𝑔, vulnerable

4 https://linux.die.net/man/1/atop.

(7)

7 H. Bui et al.

Fig. 2. The process flow of controller driven configuration.

client 𝑣_ℎ, and non-vulnerable 𝑛𝑣_𝑙to collect accounting data. After the controller 𝑐 completes the machine’s configuration, the data log server will receive and keep the reports from other machines.

Data reproduction. This module is to reproduce attack and benign behavior, given the configured testbed. The module consists of a set of scripts for launching attack scenarios and benign services. Each attack scenario’s scripts are designed to run independently but aware of what stage they are performing on, such as network or system log.Fig. 3 illustrates data reproduction for the Mirai attack scenario where the controller 𝐶 commands the machines of malicious client 𝑚_𝑐to scan all machines (non-vulnerable and vulnerable clients). The malicious client 𝑚_𝑐can report found successfully injected machines to the attack server (CnC server) for future exploitations (i.e., exploit, transfer malware, execute malware). The controller specifically runs a process on the attacker server to periodically check the number of connected bots that will trigger a DDoS attack command when reaching a certain number of bots (predefined via the configuration). The attacker server will continuously keep track of the control command and switch to new attack targets if required.

5.3. Feature extraction and data labeling

This stage details feature extraction and labeling for the raw data collected from three sources in the previous step. The top of Fig. 4 illustrates the processing flow of two modules. Initially, the controller 𝐶commands the feature extraction module (FEM), which will get raw data from data storage and extract the features. Then the attack and benign data in the dataset are also classified by data sources (network traffic, system log, accounting statistic) at this step. For network traffic data, the pcap file packets are grouped into network flows by using the 5-tuple (source IP address, source port, destination IP address, destination port, and transport protocol). With long network flows, e.g., downloading files, they can be split into multiple sub-flows using a time window. The labeling uses 5-tuple and timestamps to index.

We specifically use the timestamps for identifying the attack stage.

Fig. 3. The processing flow of Mirai attack-based scenario.

Fig. 4. The process flow of multi-dataset generation and auto-evaluation.

Labeling sub-flows is primarily based on the source and destination IP addresses. If the traffic comes from predefined legitimate machines, they are labeled as normal. In our experiment, we assume that the benign programs in vulnerable clients/injected devices will not access the target server during the attack period. As a result, we can label the abnormal traffic by filtering out the traffic flows from 5-tuple with the destination IP address of the target server. For system log data, log messages are separated into the log template and parameter list.

The machine ID or process ID is the index to separates the records of different processes or malware. Similar to network traffic, to label logs, the attack programs or machines are predefined. The log flows are then labeled with their source machine/process ID. For accounting data, the cmdname of each process is used as the reference index for labeling data.

5.4. Auto-evaluation

Auto-evaluation is to validate the dataset quality. This study uses two metrics (coverage and efficiency) for the measurement. The process flow of the module is illustrated at the bottom ofFig. 4, i.e., auto- evaluation block. As defined in Section 4.1, the coverage metric cov includes the number of attack types, the number of attack scenarios, the number of data sources, the labeled data amount, the number of feature sets, and metadata. The efficiency metric eff is measured by a pair of bound. The higher bound is the highest accuracy from the combinations of the selected features. The lower bound is the acceptable accuracy

(8)

Table 3

Open sources and tools.

Category Name Functionality

Data collection

Tcpdump capturing network packets

Rsyslog collecting logs

Atop monitor activity of processes

Features extraction

Argus extract features for packets

Drain parsing raw log messages

Atop extract accounting’s features

Attacks

Mirai emulate Mirai botnet

MySQL database service

Metasploit hacking tool

Metasploitable 3 vulnerable Linux VM

based on a given ML-based IDS and a provided threshold. If the ML- based IDS uses only a list of few features to achieve a certain accuracy as doing with all features, a number of the features in the list will contribute to calculating eff.

6. Implementation

This section covers the implementation of the dataset generation/

evaluation module, and summarizes the open source and tools used in this work. To the end, we show the configuration of the testbed and overview the setting up process.

6.1. Open sources and tools

Table 3summarizes the most important open-sources and tools used in this work. The main stages of implementation are categorized as follows.

Management and Report. We used Django (a high-level Python Web framework) to build a website that acts as a centralized GUI-based controller. The researcher can configure all the testbeds, e.g., number of machines, attack scenarios, through this portal. The website provides a dashboard and a summary report to track the launched modules’

progress and results.

Configuration. Expect⁵is the script to connect ssh to each machine and configure the tasks, e.g., installing malware, launching an attack.

Expectscripts are specified for the requirements of each machine. SCP⁶ is the main tool to support uploading/downloading configured files for the tools which do not support a remote report to the centralized server, Atop.

Attack reproduction. For easy reproduction, we open-source tools to carry out attack scenarios in this work. For example, Mirai botnet’s source code and MySQL database are collectible from the Internet.

Metasploitable and Metasploit are also the available frameworks on the Internet for downloading. Note that Metasploitable3 is different from Metasploit. Metasploitable 3 is a virtual machine containing many security vulnerabilities, while Metasploit is a security tool to perform penetration tests and vulnerability exploitation.

Data collection. In this work, we use three tools, Tcpdump,⁷ Rsys- log,⁸ Atop, to collect data from network traffic, system logs, and ac- counting. Tcpdump is a common command-line packet analyzer that many experts have used to capture a packet’s contents on a specific network interface. For specific domain, Iptables⁹is a tool for updating the routing rules and forwarding all the outgoing packets to the data log server 𝑑𝑙𝑠 where Tcpdump can capture and extract. Rsyslog is a robust and rocket-fast module for log processing. Rsyslog supports forward log

5 https://linux.die.net/man/1/expect.

6 https://linux.die.net/man/1/scp.

7 https://www.tcpdump.org/.

8 https://www.rsyslog.com/.

9 https://linux.die.net/man/8/iptables.

Table 4

Features of network traffic and accounting.

Data sources Features

Network packet flgs, pkts, bytes, state, dur, mean, sbytes, dbytes, spkts, dpkts, stddev, sum, min, max, rate, srate, drate

Accounting PID, RDDSK, WRDSK, WCANCL, DSK, CMD, MINFLT, MAJFLT, VSTEXT, VSIZE, RSIZE, VGROW, RGROW, MEM, TRUN, POLI, TSLPI, TSLPU, NICE, PRI, RTPR, CPUNR, ST, EXC, S, CPU

messages to a remote server for aggregation. For accounting statistics, Atopis a Linux-based interactive program that monitors the occupation of sharing resources on the system level, such as CPU, memory, and disk.

Feature extraction. Argus,¹⁰ Drain(He et al.,2017), and Atop are the three selected tools for extracting features from the collected raw data of network traffic, logs, and accounting. Argus, specifically, is an open-source network activity auditing tool that can process packets at the network flow level using 5-tuple. Argus consists of two agents: Argus server and Argus client. Argus server supports reading and translating pcapfiles to the sub-flow level with a particular duration time, while Argus client extracts features of the flows to a CSV file. Other than recording the raw data, Atop is a tool for extracting the accounting data features. Each process’s features can be CPU utilization, the average size of disk reading and writing, memory utilization, and so on. Features of network traffic and accounting are shown in Table 4. For the system log, Drain is used to parse the unstructured log messages to the structured format, e.g., including the timestamp, the source service, the log template, and the parameter list. Drain is the advanced version of the log parser tool demonstrated in the study (Zhu et al.,2019).

Labeling. Labeling is performed based on the prior understanding of the attack programs or injected machines defined in the configuration step. For example, a flow is labeled as an attack for the network traffic data if they come from the predefined malicious machines. Similarly, the logs from the predefined attack machines are labeled as abnormal.

Evaluation. We use the Scikit-Learn library algorithm, namely Re- cursive Feature Elimination and Cross-Validation Selection (RFECV), to eliminate irrelevant features based on validation scores. The goal is to figure out the best combinations of the extracted features. The variety of essential features is a combination with a minimum number of selected features while still achieving acceptable accuracy (with a provided threshold). The efficiency is scored by a division of the num- ber of important features 𝑛𝑖𝑓^𝑑^𝑖 and the number of all features 𝑛𝑎𝑓^𝑑^𝑖. The coverage score is provided with the ground truth information in the dataset. For further assessment, datasets are put into ML-based IDS to test and verify the detection performance.

6.2. Testbed

Fig. 5illustrates our testbed environment. The hosts running in the testbed are based on Virtual Machines (VMs). The VM hosts can run Windows (10) or Linux (Ubuntu) kernels. The benign servers and the target servers run on Metasploitable 3 with Ubuntu 14.04. The benign servers host several legitimate services such as DNS, Web, and FTP. The attack clients run on Kali Linux.Table 5shows the parameter setting of the machines. Without loss of generality, we set all the passwords to the same value. For data collection and pre-processing, both the accounting collection duration and time windows of sub-flows are set to 1 s. For filtering out redundant features, the features that have correlation scores of less than 0.1 with the label will be removed.

Fig. 6is a screenshot of the toolchain dashboard. The dashboard provides an overview of the current toolchain’s operation with seven phases. The dashboard provides a summary of the operations performed in each phase.

10 https://openargus.org/.

(9)

9 H. Bui et al.

Fig. 5. The illustration of our testbed environment. The hosts are virtual machines and can run Windows (10) or Linux (Ubuntu) kernels.

Fig. 6. The illustration of the toolchain dashboard. The dashboard has two basic parts. The upper part is a progress bar to track the steps of the toolchain. Each phase has a black color at the beginning that will change to a blue color when the toolchain run in the corresponding stage. The below part is the details of each phase.

Table 5

Configuration setting for machines in the testbed.

Hostname IP address Username Password

controller 192.168.1.200 controller qsefthuk

data-logger-server 192.168.1.164 root qsefthuk

benign-server-1 192.168.1.21 root qsefthuk

target-server-1 192.168.1.11 root qsefthuk

vul-client-1 192.168.1.111 root qsefthuk

non-vul-client-1 192.168.1.211 root qsefthuk

attacker-server 192.168.1.102 root qsefthuk

malicious-client 192.168.1.103 root qsefthuk

7. Experiment result

This section covers the evaluation performance of the generated datasets on coverage and efficiency metric.

7.1. Dataset coverage

Table 6shows main criteria covered by different datasets. These criteria are used as a basis for calculating the coverage scores. The calculation is based on Eq.(1). The weight step is set by any of the values in [0.4, 0.2, 0.1, 0.1, 0.1, 0.1] and 𝑚𝑎𝑥_𝑣

𝑗 to [20, 20, 6, 6, 6, 1] (as described in Section4.1). The training and testing ratio is 80% and 20%, respectively. 5-fold cross-validation is also used. The results of the coverage scores is presented inFig. 7.

We found that the CREME dataset has a roughly 20% higher coverage score than the others. CREME’s dataset coverage is 0.52 compared to the past average of 0.334 in the other datasets. These positive results

(10)

Table 6

Coverage evaluation comparison of various datasets and ours.

Dataset Attack types Staged attack scenarios Data

sources

Labeled data

Feature set

Metadata

Kyoto 2006+ DoS, scanning, trojan, worm, vulnerability, backscatter, phising, shell code

None Traffic Traffic Traffic Yes

UNSW-NB15 Backdoors, DoS, Exploits, spam, fuzzers, generic, port scans, reconnaissance, shellcode, worms

NGIDS-DS Backdoors, DoS, exploits, worms, generic, reconnaissance, shellcode

None Traffic,

Audit

Traffic, Audit

Audit Yes

NDSec-1 Botnet, brute force,

spoofing, DDoS, exploits, probe, XSS, SSL proxy, SQL injection

Bring your own device, watering hole, botnet

Traffic, Syslog

Traffic Syslog Yes

CICIDS Botnet (Ares), DoS, DDoS,

heartbleed, infiltration, XSS, SSH brute force, SQL injection

IoT-NID MITM, DoS, Scanning,

DDoS, brute force

Mirai Traffic Traffic None Yes

Bot-IoT Scanning, Dos, DDoS, brute force, vulnerability, data exfiltration, key logging

Data theft, keylogging Traffic Traffic Traffic Yes

Ton-IoT Scanning, DoS, DDoS,

MITM, Ransomware, Backdoor, Injection, XSS, Password

None Traffic,

Account- ing, Telemetry

Traffic, Account- ing, Telemetry

Yes

IoT-23 C&C, FileDownload, DDoS, Scanning, HeartBeat, brute force, injection

Mirai, Torii, Trojan, Gagfyt, Kenjiro, Okiru, Hakai, IRCBot, Muhsik, Hide and Seek

Traffic Traffic None Yes

CREME Scanning, brute force,

backdoor, DDoS, privilege escalation, vulnerability, resource hijacking, ransomware, end-point DoS, data destruction

Mirai, Ransomware, End-point DoS, Mining, WipeDisk

Traffic, Syslog, Account- ing

Yes

Fig. 7. The results for validating coverage score of the datasets.

come from the fact that the CREME collects data from multiple data sources (traffic, syslog, accounting) along with the optimal feature set.

If a single data source is used, the coverage score degrades to 0.4. The low score highlights the importance of having rich data for training.

Data from multiple sources can give a better chance to detect the footprint of the attacks. Also, as listed inTable 6, CREME provides a rich set of features and well-labeled data that few studies can. CREME also covers more attack scenarios than most existing datasets.

Fig. 8. The results for validating efficiency score of the datasets.

7.2. Dataset efficiency

Fig. 8 shows the efficiency score of different datasets. Similarly, we use the ratio of 80% data for training, 20% data for testing, and 5-fold cross-validation. For example, the data amount for training in Kyoto 2006+ dataset, CICIDS dataset, Bot-IoT dataset, UNSW-NB15 dataset, Ton-IoT-Windows dataset, Ton-IoT-Network dataset, CREME- accounting dataset, CREME-Syslog dataset, and CREME-traffic dataset are 7615547, 4497544, 7575629, 4467745, 21104, 461043, 231576, 5381, and 297162 data points. For the dataset with a significant

(11)

11 H. Bui et al.

Table 7

Top 14 ranked features of datasets.

Dataset Top 14 ranked features

UNSW-NB15 sttl, ct_state_ttl, service_dns, state_CON, proto_tcp, ct_dst_sport_ltm, sloss, proto_arp, dbytes, sbytes, ct_srv_dst, proto_unas, Sintpkt, synack

Ton-IoT-Network proto_tcp, dns_rejected_T, conn_state_REJ, src_pkts, dns_RA_T, dst_pkts, conn_state_OTH, conn_state_SF, dst_bytes, src_ip_bytes, dst_ip_bytes, src_bytes, conn_state_S3, duration

CICIDS Bwd Packet Length Min, Total Fwd Packets, Average Packet Size, Bwd Packet Length Std, PSH Flag Count, Init_Win_bytes_backward, Bwd Header Length, Packet Length Std, Max Packet Length, Destination Port, Fwd Packet Length Max, Idle Max, Fwd Header Length, Total Backward Packets

Bot-IoT N_IN_Conn_P_DstIP, state_number_5, state_number_2, seq, state_number_3, stddev, drate, state_number_4, state_number_1, srate, min, mean, state_number_9, N_IN_Conn_P_SrcIP

Kyoto 2006 + Service, Flag_OTH, Dst_host_same_src_port_rate, Destination_bytes, Flag_S0, Dst_host_srv_count, Flag_RSTOS0, Dst_host_count, Source_bytes, Duration, Flag_SHR, Count, Flag_REJ, Same_srv_rat

Ours-Accounting VSTEXT, DSK, TSLPI, POLI_-, EXC_1, CPUNR, RSIZE, ST_NE, ST_NS, MINFLT, MEM, VSIZE, PRI, EXC_0

Ours-Syslog apache-access, postfix/submission/smtpd, vsftpd, postfix/qmgr, avahi-daemon, in.telnetd, login_FAILED, apache-access, login_pam_unix, login_FAILED, postfix/lmtp, postfix/qmgr, login_pam_securetty, proftpd

Ours-Traffic Rate, State_INT, Dport, SrcPkts, Flgs_ e s, Sport, TotPkts, State_CON, Proto_tcp, DstRate, SrcRate, State_sSEfF, Proto_udp, DstPkts

Table 8

Examination results of datasets of each data source.

Algorithms Accounting Traffic Syslog

Accuracy F1-score Execution time (s) Accuracy F1-score Execution time (s) Accuracy F1-score Execution time (s)

Decision Tree 0.9970 0.9967 0.443 0.9998 0.9998 0.590 0.9846 0.9838 0.0139

Naive Bayes 0.9395 0.9372 0.194 0.9774 0.9781 0.212 0.9833 0.9822 0.0106

Extra Tree 0.9970 0.9967 0.144 0.9987 0.9987 0.154 0.9859 0.9851 0.0116

KNN 0.9791 0.9767 37.893 0.9976 0.9977 167.873 0.9857 0.9849 0.1419

Random Forest 0.9969 0.9966 7.496 0.9998 0.9998 12.585 0.9864 0.9857 0.2475

XGBoost 0.9968 0.9965 5.380 0.9998 0.9998 5.521 0.9853 0.9845 0.1232

imbalanced problem, the data of rare classes are increased by using repetition. CREME’s efficiency scores are 0.682 for accounting and 0.504 on average compared with the best performance at 0.654 and an average of 0.257 of other studies. The positive performance results show the significant contributions of the correlation of labeled data and the removal of redundant features in the data generation process. The evaluation results indicate that Kyoto 2006+ with an efficiency score (0.654) likely competing with ours. Unfortunately, Kyoto 2006+ only includes data from a single source (network traffic).

Fig. 9 shows the accuracy score of training the ML-based IDS (running XGBoost Classifier) with all and only important features per dataset. The results indicate that the accuracy of training a system with the important features is quite competitive with using all features. Even better, using full features can significantly cost the system in computa- tion and training time if the data is large. This fact reveals one of the best advantages of identifying important features in a dataset. The ML- based IDS can save training time substantially while still maintaining the detection accuracy at best.

Fig. 10shows the detection accuracy of selecting various combinations of features in different datasets. The system can achieve high accuracy (97% average) with only 14 features in all the datasets.

Table 7 shows these top-ranked features in our testing. An important feature means it contributes more meaningful information for the learning training. Several features may have few contributions, e.g., a flow appears once or short time in the dataset. These features can be removed without a significant impact on the prediction performance.

On the other hand, the cost to conduct those data can waste the detection system’s resources. By contrast, a lack of enough data can contribute to an imbalance in the dataset, which can negatively impact a system’s performance.

7.3. Detection accuracy performance

Table 8shows the evaluation results of the CREME dataset after testing six common ML algorithms: Decision Tree, Naive Bayes, Extra Tree,

Fig. 9. Detection accuracy of ML-based IDS for two configurations: with important features vs with all features.

Fig. 10. Accuracy performance of the system with various combinations of selected features.
