N A N O E X P R E S S Open Access
Vertically Free-Standing Ordered
Pb(Zr 0.52 Ti 0.48 )O 3 Nanocup Arrays by Template-Assisted Ion Beam Etching
Xiaoyan Zhang1, Dan Tang1, Kangrong Huang1, Die Hu1, Fengyuan Zhang1, Xingsen Gao1, Xubing Lu1, Guofu Zhou2,3, Zhang Zhang1*and Junming Liu1,4
Abstract
In this report, vertically free-standing lead zirconate titanate Pb(Zr0.52Ti0.48)O3(PZT) nanocup arrays with good ordering and high density (1.3 × 1010cm−2) were demonstrated. By a template-assisted ion beam etching (IBE) strategy, the PZT formed in the pore-through anodic aluminum oxide (AAO) membrane on the Pt/Si substrate was with a cup-like nanostructure. The mean diameter and height of the PZT nanocups (NCs) was about 80 and 100 nm, respectively, and the wall thickness of NCs was about 20 nm with a hole depth of about 80 nm.
Uppermost, the nanocup structure with low aspect ratio realized vertically free-standing arrays when losing the mechanical support from templates, avoiding the collapse or bundling when compared to the typical nanotube arrays. X-ray diffraction (XRD) and Raman spectrum revealed that the as-prepared PZT NCs were in a perovskite phase. By the vertical piezoresponse force microscopy (VPFM) measurements, the vertically free-standing ordered ferroelectric PZT NCs showed well-defined ring-like piezoresponse phase and hysteresis loops, which indicated that the high-density PZT nanocup arrays could have potential applications in ultra-high non-volatile ferroelectric memories (NV-FRAM) or other nanoelectronic devices.
Keywords:Vertically free-standing, PZT nanocups, AAO, Ion beam etching
Background
In recent years, increasing efforts have been made to synthesize and understand ferroelectric nanostructures because of their peculiar physical properties, such as their finite size effects and unusual phase transitions [1, 2], offering a wide range of potential applications in nano- scale piezoelectric actuators [3], force and acceleration sensors [4, 5], ultrasonic transducers [6], and non-volatile ferroelectric random access memory (NV-FRAM) devices [7]. Due to the current trends of high integration and miniature in semiconductor industry, ferroelectric mem- ories have been receiving more and more attention due to their unique advantages such as high density, low power consumption, and high read/write speed [8–10].
Lead zirconium titanate Pb(Zr0.52Ti0.48)O3 (PZT), a solid solution of the perovskites lead zirconate and lead titanate, is a prominent ferroelectric material that has stimulated tremendous fundamental and applied re- searches due to its high spontaneous polarization abil- ities, piezoelectric coefficient, dielectric permittivity, and pyroelectricity [11–13]. Applications of PZT nano- structures include tunable photonic crystals, ferroelec- tric random access memory (FRAMs), terahertz emission, fluidic delivery, and nanosensors [14–16]. In addition, the significant need of miniaturization of elec- tronic devices leads to more extensive usage of PZT FRAMs based on the low-dimensional nanostructures [17]. Sol-gel process is one of the promising routes among many suitable methods for the preparation of nanostructured PZT materials, as it leads to products with high chemical homogeneity and purity at compar- ably low temperatures [18]. However, the synthesis speed of ferroelectric nanotubes (NTs) has been rela- tively slower than it has been for other materials, which
* Correspondence:[email protected]
1Institute for Advanced Materials and Guangdong Provincial Key Laboratory of Quantum Engineering and Quantum Materials, South China Academy of Advanced Optoelectronics, South China Normal University, Guangzhou 510006, China
Full list of author information is available at the end of the article
© 2016 Zhang et al.Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.
might due to the difficulties associated with the structural and stoichiometric complexity [19]. For large-scale mem- ory device, high-density ordered ferroelectric NTs with a vertically aligned integration on the substrate is one essen- tial. In recent years, high-density vertically aligned ordered ferroelectric NTs can be fabricated using template-assisted method [18]. In particular, anodic aluminum oxide (AAO) templates are with advantages of good ordering, large-area fabrication, paralleled pore arrangement, and tunable size [20]. Nevertheless, the clamping effect degrades the prop- erties with the remaining template around the nanostruc- ture [21, 22]. After getting rid of the template, however, the loss of the mechanical support from AAO and capil- lary force always resulted in the degradation of the ordered array alignment on the substrate [23, 24]. Obvi- ously, the agglomeration of the nanostructures would greatly affect the device performance. And the agglomer- ation was mainly due to the high surface tension, which was closely related to the compressive stress of the nano- structures. In order to reduce surface tension, the high- density nanostructures should be preferentially designed with low aspect ratio of height to diameter [25]. Up to now, there have been few reports addressing both the vertically free-standing ordered nanostructure arrays and the structure-property relations of the ferroelectric nanostructures.
In this work, we have successfully developed high- density and well-ordered vertically free-standing (VFS) PZT nanocup arrays on a conductive Pt/Si substrate, by a template-assisted ion beam etching (IBE) method. The low aspect ratio of height to diameter being critical to the vertically free-standing feature of PZT nanocups (NCs) could be well controlled by the ultrathin AAO templates and IBE process. X-ray diffraction (XRD) and Raman spectrum revealed that the as-prepared PZT NCs were in a perovskite phase. By the vertical piezore- sponse force microscopy (VPFM) measurements, the well-ordered ferroelectric PZT nanocup arrays showed well-defined ring-like piezoresponse phase and hysteresis loops, which indicated that the nanostructure could have potential applications in ultra-high NV-FRAMs or other oxide nanoelectronic devices.
Methods AAO Fabrication
AAO templates are fabricated by a standard two-step anodization method. Firstly, high-purity aluminum foils (99.999 %, Good fellow Cambridge Limited) were degreased and then annealed at 450 °C for 3 h under argon atmosphere. Then, the Al foils are electrochem- ically polished in a solution of mixed ethanol and HClO4
(3:1 by volume) at 20 V for 5 min to form a mirror-like surface smoothness. The first anodic oxidation process is performed in a 0.3-M oxalic acid with a constant
anodic voltage of 40 V. After 24 h, the first alumina layer is removed by a mixed aqueous solution of 6 % H3PO4
and 1.8 % H2CrO4at 45 °C for 11 h. The second anodic oxidation process is performed under the same condi- tions as the first one, with a 300-s oxidation time to grow the AAO membrane with a thickness of about 200 nm. A 5 wt.% phosphoric acid was used to widen the pore diameter to about 80 nm. In order to realize the AAO membrane bonded onto Pt/Si substrate, a polymer-assisted method was used. First, a thin layer of polystyrene (PS) (1 wt.% PS/CHCl3 solution) was spin- coated onto the top of AAO film, followed by a 90 °C solidification heating. After that, a CuCl2solution (6.8 g CuCl2+ 100 ml 37 % HCl + 200 ml distilled water) was used to remove the Al foil on the back side of the AAO.
The membrane was then immersed in 5 wt.% phos- phoric acid at 35 °C for 30 min, rinsed with distilled water, and then dried under ambient conditions to re- moval barrier layer [26]. The whole PS/AAO membrane still floating on the surface of deionized water was trans- ferred to a desired substrate. Subsequently, the van der Waals forces at the interface exhibit an excellent bond- ing which can still survive even under strong mechanical evacuation. The PS can be completely removed by a pyr- olysis process.
Template-Assisted IBE Process
A 0.3-M PZT sol-gel precursor with the molar ratio of 1:0.52:0.48 was prepared by dissolving zirconium propoxide (Zr(CH2CH2CH3O)4) and isopropyl titanate (Ti(C4H9O)4) into 2-methoxyethanol (C3H8O2), with acetic acid and propanol added as the solvents, stirring until completely dissolved. Then, 10 % excess lead acetate trihydrate (Pb(CH3CO2)2·3H2O) was added with the purpose of compensating the lead loss and preventing forming the second phase of pyrochlore-type in annealing process [27]. The precursor solution was stirred for 24 h at room temperature and then aged for 1 week.
The PZT sol was dipped into the AAO template for nearly 10 h at the room temperature for atmosphere pressure.
After infiltration, excess PZT accumulated on the surface is swept with nitrogen gas gun. The samples were then annealed at 700 °C for 20 min in air by a rapid thermal process (RTP) to experience a crystallization process.
Afterwards, in an ambient pressure of 5.6 × 10−4 mbar at room temperature, the specimen was etched by Ar IBE (MIBE-150C). The first 10-min IBE was used to remove off the residual PZT film that covered on the surface of AAO template after the annealing process. The continuous IBE reduced both the thicknesses of the AAO and inside PZT.
The total etching time was about 20 min with a vertical in- cident ion beam to the specimen. The etching energy was set to a cathode current of 11.5A, anode voltage of 55 V, plate voltage of 300 V, ion accelerating voltage of 250 V,
and neutralization current of 13A and bias current of 1.2A.
After the IBE process, the remaining AAO was completely removed off by dipping the specimen into sodium hydrox- ide solution.
Characterizations
The morphologies of nanostructure were carried out ex situ with a field-emission scanning electron microscope (FESEM ZEISS Ultra 55). The crystalline structural char- acterizations were investigated by XRD using a Philips X’Pert Pro Cu Kαdiffractometer with an x-ray wavelength of 0.15406 nm. The Raman spectra were measured at room temperature by the Renishaw inVia-Reflex Raman microscope with an excitation wavelength of 633 nm. The laser power is set to 10 % of the maximum. The ferroelec- tric nanostructures were measured by a piezoresponse force microscopy (PFM) (Cypher, Asylum Research).
Results and Discussion
PZT Nanocup Arrays by Template-Assisted IBE
The template-assisted atmosphere pressure infiltration process for PZT nanocup arrays was schematically illus- trated in Fig. 1. The synthesis process shown here mainly consists of three following steps. Firstly, the pore-through AAO template was dipped into the pre- pared PZT sol-gel precursor (detailed in Methods Sec- tion). And then, the samples were annealed in RTP to form the crystallization PZT nanostructure. By the re- ported template-assisted sol-gel method [28], the pres- ence of PZT film on the top surface of AAO would prevent the selectively chemical etching of AAO, since the AAO was completely covered by the PZT film.
Therefore, the IBE pretreatment was used to get rid of the top surface PZT film, which would effectively bare
the top surface of AAO to the chemical etching solution.
Secondly, the IBE was adopted to remove the redundant PZT located at the surface of the AAO template. Mean- while, the heights of tubular wall of the AAO and the implemented PZT were both reduced. Finally, after the AAO template being completely removed off by select- ively chemical etching, the ordered VFS PZT nanocup arrays were remained on the substrate.
The top view SEM images of the corresponding fabri- cation procedures (illustrated in Fig. 1) were presented in Fig. 2. Before the AAO was transferred to the plati- nized silicon substrate, the AAO was pretreated in the 5 wt.% phosphoric acid at 35 °C for 35 min, rinsed with distilled water, and then dried under ambient conditions, in order to get rid of the barrier layer at the bottom side.
Meanwhile, such a treatment to AAO introduced pore widening as well, and the increase of pore diameter from 40 to 60 nm can be recognized in Fig. 2a. The pore- through AAO template is also essential to keep the con- tact well between the conductive platinum substrate and the embedded PZT nanostructure to realize the lateral piezoelectric testing. After the atmosphere pressure infil- tration process of PZT sol-gel precursor, the sample was annealed in atmosphere by a RTP. Afterwards, a homo- geneously porous PZT layer accumulated at the top sur- face of AAO (as shown in Fig. 2b), which was an inevitable by-product using the atmosphere pressure in- filtration template-assisted sol-gel method [28]. And it should be realized that such a by-product will greatly hinder the selectively chemical etching of the AAO. In this report, we brought in a successive IBE process to get rid of the PZT layer to expose the underlying AAO and embedded PZT nanostructure. During the IBE, the neutral-charged Ar ion beam transmitted its kinetic en- ergy to the atoms of the specimen to sputter out. The high-energized Ar ion beam can also play as a dustman to clean the sputtering redeposition on surfaces to speed up the etching process [29]. Due to the bombarding ef- fect of Ar ion beam, the PZT layer on the top surface of AAO was first removed off. Successively, with the on- going of IBE, the tubular nanostructure of AAO and the embedded PZT nanostructure were both etched to be thinner. With a proper duration of IBE, the porous PZT layer on the top surface of AAO was etched off com- pletely, and the ring-like PZT nanostructure arrays could be distinguished to be embedded in each AAO pore by the top view SEM image (Fig. 2c). After selective etching off AAO, the VFS PZT nanocup arrays were remained on the Pt/Si substrate (Fig. 2d). The mean diameter of the PZT NCs was about 80 nm, with a wall thickness of about 20 nm. And the distance between the adjacent NCs was about 100 nm, being the same with the inter- pore distance of AAO, resulting in a higher density of PZT nanostructure arrays about 1.3 × 1010 cm−2
Fig. 1Schematic diagram of the three fabrication procedures for the ordered VFS PZT NC arrays.iDip PZT sol-gel into the AAO template.iiRemove the redundant PZT at the top surface of AAO by IBE.iiiRemove the remaining AAO template to form the ordered VFS PZT NC arrays on Pt/Si substrate
compared to the reported arrays [28, 30]. Meanwhile, the cup-like nanostructure of PZT with a small height to diameter ratio was also confirmed by a few collapsed PZT NCs on the substrate (as shown in the selected red square box of Fig. 2d).
Phase Analysis
XRD was used to investigate the phase and crystallinity of the PZT NCs. In order to get strong signals, the high- density VFS PZT NC arrays were characterized. Gener- ally, the as-deposited PZT film was amorphous, and a post deposition annealing was required to transform the film from the amorphous to the desirable ferroelectric perovskite phase. The amorphous structure will first transform into an intermediate pyrochlore phase, and then, the pyrochlore phase will transform into the per- ovskite phase at an annealing temperature higher than 650 °C [27]. The perovskite phase grew from the surface of the pyrochlore film. To avoid the pyrochlore phase, the annealing temperature was set to 700 °C and 10 % excess lead acetate trihydrate (Pb(CH3CO2)2·3H2O) was added in our experiments. Figure 3a is a typical XRD peak pattern of the PZT nanocup arrays, with an anneal- ing at 700 °C. The diffraction peak at 2θ= 31.35°,
corresponding to the PZT (110) plane, was obviously stronger than the other peaks. The strong and sharp dif- fraction peaks are coincident with the peak pattern of the PZT perovskite crystalline structure [31, 32]. In addition to peaks belonging to the perovskite phase, small Bragg reflections of a pyrochlore phase were also observed in the XRD peak pattern. The formation of an intermediate pyrochlore or fluorite phase was kinetically favored over the perovskite phase, during synthesis of lead-based ferroelectric films on substrates and free- standing PZT films, respectively [27, 33]. Therefore, the existence of a surface pyrochlore phase cannot be precluded.
To further characterize the composition, the Raman spectrum of PZT nanocup arrays was shown in Fig. 3b.
Since the PZT tetragonal space group belongs to the P4mm, the typical 3A1 + B1 + 4E mode in Raman peaks can be clearly identified, with six main peaks: 205, 275, 317, 533, 593, and 724 cm−1, corresponding to the E(2TO), E(silent) + B1, A1(2TO), E(3TO), A1(3TO), and A1(3LO) modes, respectively. With the six phonon modes found in the Raman spectrum, which is the typical one of PZT perovskite phase, it was further confirmed that the as-prepared PZT had been in its perovskite phase [3].
Fig. 2Top view SEM images of the fabrication process of VFS PZT NC arrays.aThe pore-through AAO template with an enlarged pore diameter of about 80 nm.bAAO template with PZT sol-gel infiltration after the annealing process.cAAO template with embedded PZT nanostructure after etching off the PZT top layer on the top surface of AAO by an IBE.dVFS PZT NC arrays on Pt/Si substrate after selectively chemical etching off AAO. The scale bar is 100 nm
Ferroelectric Properties
PFM can provide non-destructive high spatial resolution and uniform localization electric field at the junction between the conductive tip and ferroelectric surface, obtaining both the domain structures and the electrical properties of the nanometer scale ferroelectric structures [34]. To characterize the ferroelectric properties of the well-ordered VFS PZT nanocup arrays, VPFM measure- ments were performed and demonstrated in Fig. 4, includ- ing the atomic force microscopy (AFM) topography, cross-sectional height data, phase micrograph, and the piezoresponse amplitude of the same selected zone of PZT nanocup arrays. The surface topology (as shown in
Fig. 4a) exhibited a uniform and well-aligned ordering.
And the diameter and wall thickness of the PZT NCs was about 80 and 20 nm, respectively, which was consistent with the observation of the SEM images. In Fig. 4b, from the height data of three linear NCs (marked in Fig. 4a), we concluded that the average height of PZT NCs was about 100 nm. The dark and bright areas in the phase micro- graph (Fig. 4c) correspond to the up-polarization and down-polarization state, respectively, indicating the well- defined piezoresponse of the ordered PZT nanocup arrays.
The contrasts in amplitude piezoresponse (Fig. 4d) repre- sent the magnitudes of the piezoelectric signals, which are much higher on the NCs.
Fig. 3X-ray diffraction pattern and Raman spectrum of the ordered VFS PZT NC arrays measured at room temperature.aXRD peak pattern of annealed PZT NC arrays.bThe corresponding Raman spectrum
Fig. 4Piezoelectric response of the ordered VFS PZT NC arrays on Pt/Si substrate.aTopologically image.bHeight data for three PZT NCs along theblack linemarked ina. The correspondingcphase image anddamplitude image
Furthermore, to examine the local ferroelectric proper- ties, the piezoelectric hysteresis loops on a single PZT nanocup were measured. The square-shaped phase-voltage piezoresponse hysteresis loop and the butterfly-like amplitude-voltage loop were present in Fig. 5a, b, respect- ively. With the bias voltage increasing from−8 to +8 V, the phase change was about 175° plotted in Fig. 5a, being slightly smaller than 180°. Generally, such a phase change indicated that the low aspect ratio of nanostructure had re- sulted in an easier polarization switching [31]. Meanwhile, a well-developed butterfly-shaped amplitude loop can be observed in Fig. 5b. The coercive fields of the PZT nanocup were−2.2 and +1.3 V, indicating that the polarization rever- sal was asymmetric. Such a phenomenon could be due to the built-in fields from the work-function difference be- tween the top and bottom electrodes. The PFM conductive needlepoint acted as the top electrode was the platinum- iridium, while the bottom electrode was the platinum- silicon. Normally, the platinum and the iridium have their work functions of around 5.65 and 5.27 eV, respectively, which produces an overall theoretical built-in voltage of 0.38 eV. This breaks the equivalence of two polarization states and provides a strong tendency to alight the domains to a preferred orientation [35–37]. Additionally, the surface
charges stored at the interface between PZT and Pt elec- trode may contribute to the observed asymmetric polarization states [38]. Therefore, the PZT nanocup arrays with good polarization switching properties could poten- tially act as a memory element in NV-FRAM devices [39].
Conclusions
In summary, we have successfully fabricated well- ordered VFS PZT nanocup arrays, by the template- assisted IBE strategy. The PZT nanocup arrays show the same pattern as the AAO template, and the high density of the hexagonal close packed NCs is up to 1.3 × 1010 cm−2. XRD and Raman spectrum had been performed to demonstrate the perovskite phase of the VFS PZT NCs. The well-defined ring-like piezore- sponse phase and amplitude performances of these ordered ferroelectric PZT nanocup arrays were con- firmed by VPFM. All experimental results indicated that the ordered VFS PZT nanocup arrays could have potential applications in NV-FRAM devices.
Abbreviations
AAO:Anodic aluminum oxide; AFM: atomic force microscopy; FESEM: field- emission scanning electron microscope; FRAMs: ferroelectric random access memory; IBE: ion beam etching; NCs: nanocups; NTs: ferroelectric nanotubes;
NV-FRAM: nonvolatile ferroelectric random access memory; PS: polystyrene;
PZT: lead zirconate titanate Pb(Zr0.52Ti0.48)O3; RTP: rapid thermal process;
VFS: vertically free-standing; VPFM: vertically piezoresponse force microscopy;
XRD: X-ray diffraction.
Competing interests
The authors declare that they have no competing interests.
Authors’contributions
XY-Z designed and performed the experiment works, analyzed results and drafted the manuscript. KR-H, DT and DH participated in the sample fabrica- tion and X.R.D. measurement. FY-Z carried out the PFM and AFM measure- ment. XS-G, XB-L, GF-Z and JM-L contributed to the data interpretation. ZZ contributed to the data interpretation, manuscript writing and supervised the research. All authors read and approved the final manuscript.
Acknowledgements
We acknowledge financial support from the Natural Science Foundation of China (Grant No. 51202072), the Project for Guangdong Province Universities and Colleges Pearl River Scholar Funded Scheme (2014), the International Science &
Technology Cooperation Platform Program of Guangzhou (No. 2014 J4500016), the State Key Program for Basic Researches of China (Grant No 2015CB921202), Guangdong National Science Foundation (No.2014A030313434), and the Pearl River S&T Nova Program of Guangzhou (2015), the Science and Technology Planning Project of Guangdong Province (No. 2014B090914004), and the Program for Changjiang Scholars and Innovative Research Team in University (No.
IRT13064).
Author details
1Institute for Advanced Materials and Guangdong Provincial Key Laboratory of Quantum Engineering and Quantum Materials, South China Academy of Advanced Optoelectronics, South China Normal University, Guangzhou 510006, China.2Institute of Electronic Paper Displays, South China Academy of Advanced Optoelectronics, South China Normal University, Guangzhou, Guangdong Province 510006, China.3Academy of Shenzhen Guohua Optoelectronics, Shenzhen 518110, China.4Laboratory of Solid State Microstructures and Innovation Center of Advanced Microstructures, Nanjing University, Nanjing 210093, China.
Fig. 5Local piezoresponse hysteresis loops acquired on a single VFS PZT NCs.aPhase-voltage piezoresponse hysteresis loops.b Amplitude-voltage loop
Received: 16 December 2015 Accepted: 13 March 2016
References
1. Viehland D, Jang S, Cross LE, Wuttig M (1990) Freezing of the polarization fluctuations in lead magnesium niobate relaxors. J Appl Phys 68:2916–21 2. Zhang QM, Bharti V, Zhao X (1998) Giant electrostriction and relaxor
ferroelectric behavior in electron-irradiated poly(vinylidene fluoride- trifluoroethylene) copolymer. Science 280:2101–4
3. Scott JF, Fan HJ, Kawasaki S, Banys J, Ivanov M, Krotkus A, Macutkevic J, Blinc R, Laguta VV, Cevc P, Liu JS, Kholkin AL (2008) Terahertz emission from tubular Pb(Zr, Ti)O3nanostructures. Nano Lett 8:4404–9
4. Wang Y, Santiago-Aviles JJ (2004) Synthesis of lead zirconate titanate nanofibres and the Fourier-transform infrared characterization of their metallo-organic decomposition process. Nanotechnology 15:32 5. Kumeria T, Parkinson L, Losic D (2011) A nanoporous interferometric
micro-sensor for biomedical detection of volatile sulphur compounds.
Nanoscale Res Lett 6:1–7
6. Chu MW, Szafraniak I, Scholz R, Harnagea C, Hesse D, Alexe M, Gosele U (2004) Impact of misfit dislocations on the polarization instability of epitaxial nanostructured ferroelectric perovskites. Nat Mater 3:87–90
7. Roelofs A, Schneller I, Szot K, Waser R (2002) Piezoresponse force microscopy of lead titanate nanograins possibly reaching the limit of ferroelectricity. Appl Phys Lett 81:5231–3
8. Scott JF (2007) Applications of modern ferroelectrics. Science 315:954–9 9. Wang ZL (2007) Ubiquitous transference of a free-standing polysaccharide
nanosheet with the development of a nano-adhesive plaster. Adv Mat 19:889–92 10. Lieber CM, Wang ZL (2007) Functional nanowires. MRS Bull 32:99–108 11. Liu X, Kitamura K, Terabe K (2006) Surface potential imaging of nanoscale
LiNbO3domains investigated by electrostatic force microscopy. Appl Phys Lett 89:2905
12. Junquera J, Ghosez P (2003) Critical thickness for ferroelectricity in perovskite ultrathin films. Nature 422:506–9
13. Abplanalp M, Fousek J, Gunter P (2001) Higher order ferroic switching induced by scanning force microscopy. Phys Rev Lett 86:5799
14. Scott JF, De Araujo CAP (1989) Ferroelectric memories. Science 246:1400–5 15. Tagentsev AK, Sherman VO, Astafiev KF, Venkatesh J, Setter N (2003) Ferroelectric
materials for microwave tunable applications. J Electroceram 11:5–66 16. Vrejoiu I, Alexe M, Hesse D, Gösele U (2008) Functional perovskites—from
epitaxial films to nanostructured arrays. Adv Funct Mat 18:3892–906 17. Roger WW (2004) Pyroelectric arrays: ceramics and thin films. J Electroceram
13:139–47
18. Hernandez BA, Chang K-S, Fisher ER, Dorhout PK (2002) Sol-gel template synthesis and characterization of BaTiO3and PbTiO3nanotubes. Chem Mater 14:480–2
19. Rorvik PM, Grande T, Einarsrud MA (2011) One-dimensional nanostructures of ferroelectric perovskites. Adv Mater 23:4007–34
20. Lee W, Park SJ (2014) Porous anodic aluminum oxide: anodization and templated synthesis of functional nanostructures. Chem Rev 114:7487–556 21. Griggio F, Jesse S, Kumar A, Ovchinnikov O, Kim H, Jackson TN, Damjanovic
D, Kalinin SV, Trolier-Mckinstry S (2012) Substrate clamping effects on irreversible domain wall dynamics in lead zirconate titanate thin films. Phys Rev Lett 108:157604
22. Lefki K, Dormans GJM (1994) Measurement of piezoelectric coefficients of ferroelectric thin films. J Appl Phys 76:1764
23. Tanaka T, Morigami M, Atoda N (1993) Mechanism of resist pattern collapse during development process. J J Appl Phys 32:6059
24. Zhu K, Vinzant TB, Neale NR, Frank AJ (2007) Removing structural disorder from oriented TiO2nanotube arrays: reducing the dimensionality of transport and recombination in dye-sensitized solar cells. Nano Lett 7:3739–46
25. Namatsu H, Kurihara K, Nagase M, Iwadate K, Murase K (1995) Dimensional limitations of silicon nanolines resulting from pattern distortion due to surface tension of rinse water. Appl Phys Lett 66:2655
26. Han CY, Willing GA, Xiao Z, Wang HH (2007) Control of the anodic aluminum oxide barrier layer opening process by wet chemical etching.
Langmuir 23:1564–8
27. Kwok CK, Desu SB (1992) Empirical fit to band discontinuities and barrier heights in III–V alloy systems. Appl Phys Lett 60:1430–2
28. Alexe M, Hesse D (2012) One-dimensional ferroelectrics: nanowires and nanotubes. Ferroelectrics 433:53–64
29. Tseng AA (2004) Recent developments in micromilling using focused ion beam technology. J Micromecha Microeng 14:R15–34
30. Bernal A, Tselev A, Kalinin S, Bassiri-Gharb N (2012) Free-standing ferroelectric nanotubes processed via soft-template infiltration. Adv Mater 24:1160–5 31. Zhang X, Zhao X, Lai C, Wang J, Tang X, Dai JY (2004) Synthesis and
piezoresponse of highly ordered Pb(Zr0.53Ti0.47)O3nanowire arrays. Appl Phys Lett 85:4190–2
32. Yang SC, Sanghadasa M, Priya S (2013) Highly ordered Pb(Zr0.52Ti0.48)O3
piezoelectric nanorod arrays. Nanotechnology 24:225303
33. Bursill LA, Brooks KG (1994) Measurement of piezoelectric coefficients of ferroelectric thin films. J Appl Phys 75:4501–9
34. Han H, Kim Y, Alexe M, Hesse D, Lee W (2011) Nanostructured ferroelectrics:
fabrication and structure-property relations. Adv Mater 23:4599–613 35. Zhao L, Lu Z, Zhang F, Tian G, Song X, Li Z, Huang K, Zhang Z, Qin M, Wu S,
Lu X, Zeng M, Gao X, Dai J, Liu J (2015) Current rectifying and resistive switching in high density BiFeO3nanocapacitor arrays on Nb-SrTiO3
substrates. Sci Rep 5:9680
36. Miao Q, Zeng M, Zhang Z, Lu X, Dai J, Gao X, Liu J (2014) Self-assembled nanoscale capacitor cells based on ultrathin BiFeO3films. Appl Phys Lett 104:182903
37. Gao X, Rodriguez BJ, Liu L, Birajdar B, Pantel D, Ziese M, Alexe M, Hesse D (2010) Microstructure and properties of well-ordered multiferroic Pb (Zr, Ti) O3/CoFe2O4nanocomposites. ACS Nano 4:1099–107
38. Hong S, Woo J, Shin H, Jeon JU, Pak YE, Colla EL, Setter N, Kim E, No K (2001) Principle of ferroelectric domain imaging using atomic force microscope. J Appl Phys 89:1377
39. Lee W, Alexe M, Nielsch K, Gösele U (2005) Metal membranes with hierarchically organized nanotube arrays. Chem Mater 17:3325–7
