Determination of microamounts of iron
by hydroxamate resin colorimetry
Chuen-Ying Liu, Huan-Tsung Chang, and Liang-Jiun Uang
Department of Chemistry, National Taiwan University, Taipei, Taiwan, Republic of China
Bestimmung von Mikromengen Eisen dureh Hydroxamatharz-Colorimetrie
Summary. A new, sensitive chelating ion-exchanger colori- metric method has been developed for the determination of iron at the gg/1 level in water, based on the direct measure- ment of light absorption of iron hydroxamate resin complex. In 0.2 N perchloric acid solution, iron could be rapidly, selectively and quantitatively absorbed on the hydroxamate resin. The calibration curve for iron(III) of a 25 ml solution was linear in the concentration range 8 . 0 0 • - 6 to 5.00 X 10 -5 M. For iron(III) with larger sample volumes, the relative detection limit was increased. Most of the metals interfered negligibly, such as Ca(II), Co(II), Cu(II), Ni(II) and Zn(II), except for higher concentration of lead(II) and mercury(II) when present at up to 400 times the concentra- tion of iron(III). The effects of EDTA, glycine, thiourea, phosphate, nitrate and chloride on the retention of iron(III) were also examined. Only thiourea significantly influenced the retention of iron(III). The presence of sodium chloride even at a concentration of 3.5 x 104 times that of iron(III) did not interfere at all.
Introduction
At present, a continuous growth in demands for a quantita- tive determination of extremely low amounts of various elements in analyzed material can be observed, especially in connection with environmental and biochemical analysis, in semiconductors, extraterrestrial materials, and high-purity metals, etc.
The use of ion exchangers in extreme trace analysis is generally limited by two sources of error:
a) contamination of the eluate by the resin (traces of metals or organic material from the resin)
b) irreversible adsorption of small quantities of material. The first one can be suppressed by a thorough purifica- tion of sorbants used and the second one - an incomplete recovery of adsorbed ions - can be avoided by ashing the resin (either in air or in oxygen plasma) and by determining the trace ions in the ash or by determining the trace elements directly in the resin by the application of a suitable instru- mental method, such as X-ray fluorescence, neutron activa- tion analysis, etc. However, these methods are not so con- venient.
Offprint requests to: Chuen-Ying Liu
Hydroxamic acids, - C O N H O H , have long been recog- nized for their special ability to form complexes with heavy metals, particularly iron(III) [I - 4 ] . The intense colors and the high stabilities of many of these complexes has led to the development of various analytical procedures based upon these reactions [ 5 - 6 ] .
We have synthesized a hydroxamate resin based on the polyacrylonitrile-divinylbenzene copolymer and studied the chelating behavior of this resin towards molybdenum(VI), uranium(VI), vanadium(V) and tungsten(VI) [7]. In this pa- per, a new, sensitive, selective microdetermination method for iron(III) in water has been developed, based on direct measurement of the absorbance of the colored complex of iron-hydroxamate resin. It takes advantage of chelating resin properties, such as concentration, selective sorption and simultaneous color development on the resin phase.
Experimental
Apparatus. Spectrophotometric measurements were per-
formed with the Hitachi Digital Spectrophotometer (model 624) and a Hitachi automatic recorder (model QD 15).
The quartz cell used was the same as that used by Yoshi- mura [8].
Preparation of hydroxamate resin. Hydroxamate resin was
synthesized from Amberlite IRC-50 cation exchanger and hydrogen chloride-free hydroxylamine at p H 8 - 9 and 70 ~ C in methanol. The detailed procedure was described in the previous paper [7]. The hydrogen form of the prepared resin ( 6 0 - 1 0 0 mesh) was used.
Procedure for the determination of iron(III). To a water
sample containing 0.2 ~ 1.25 gmole of iron(III), 5 ml 1 mol/1 perchloric acid was added to make a total volume of 25 ml and the concentration of the acid approximately 0.2 tool/1. Then 0.3 g of the resin was added. The mixture was stirred for 30 min and the colored resin slurry was transferred to the cell. The absorbances at 500 nm were measured.
Distribution measurements. To two water samples containing
1.08 Ixmol of iron(II) and iron(III), respectively, 5 ml I tool/1 perchloric acid was added to each make a total volume of 25 ml and the acid concentration approximately 0.2 N and then 0.3 g of the resin was added. After a 30-min equilibra- tion, the amount of metal ion sorbed on the resin was deter- mined by chelating ion-exchanger colorimetry. The distribu- tion ratio, D, was calculated from
Fresenius Z Anal Chem (1987) 328:61 - 6 3 9 Springer-Verlag 1987
Original
papers
0 . 5 2 0 . 4 0 . 3 3~
0.2 ,.Q < 0.1 0 . 0 , ~ - 400 440 480 520 560 600 Wavelength (nmFig. 1. Absorption spectrum. 1 Hydroxamate resin; 2 iron-hydrox-
amate resin complex; 3 iron-ferroxamine B complex [9]
mmol of iron sorbed per g of resin D =
mmol of iron per ml of solution
Formation constant. F r o m I • 10 -3 to 4 • 10 -3 mmol of EDTA, the external complexing agent, and 4.9 x 10 -4 to 2.49 x 10- 3 mmol of ferric ion were mixed with 0.15 to 0.50 g of resin. The acidity of the solution was adjusted to [H +] = 0.2 N. The mixtures were equilibrated for 48 h and the samples were then filtered and washed thoroughly with deionized water. The quantity of metal ions absorbed on the resin was determined directly with the procedure described in this paper.
R e s u l t s a n d d i s c u s s i o n
Effect of p H on the recovery of iron(III). The results of the recovery of iron(III) from an aqueous solution of various p H showed that iron(III) could be quantitatively retained either from aqueous solution of p H > 3 or from 0.2 N perchloric acid solution. In this paper, the latter was used for retaining iron(III) in the sample solution, because with this acidity iron(III) could be selectively separated from the other common heavy metal ions by the hydroxamate resin. Effect of shaking time. The retention of iron(III) from 0.2 N perchloric acid solution was examined at various shaking times. The results showed that iron(III) retained rapidly on the hydroxamate resin and took only 20 min to reach completion.
Absorption spectrum. In Fig. 1, curve 1 shows the absorption spectrum of hydroxamate resin and curve 2 the absorption spectrum of iron(III) sorbed on the hydroxamate resin. Maximum absorbance of this complex was at 500 nm. Curve 3 shows the absorption spectrum of iron-ferrioxamine B complex [9]. It is seen that the iron-hydroxamate resin spec- trnm (Curve 1) is similar to that of the iron-hydroxamic acid monomer complex (Curve 3).
Calibration. The calibration curve for iron(III) of a 25-ml solution was linear in the concentration range 8.00 x 1 0 - 6
to 5.00 • 10-5 M. For five determinations, the standard de- viations were only -t- 0.003 ~ _+ 0.009.
62
Table 1. Effects of foreign ions on the determination of 0.196 Ixmole of iron(III)
Added molar ARc Fe found Relative ratio to Fe (500 nm) (pmole) error (%)
- - 0.113 0.196 0 Co(II) 510 0.118 0.197 +0.76 Ni(II) 495 0.121 0.207 + 5.47 Cu(II) 510 0.113 0.196 0 Zn(II) 510 0.113 0.196 0 Pb(II) 49.5 0.115 0.196 0 495 0.118 0.197 +0.76 Hg(II) 49.5 0.114 0.196 0 200 0.121 0.207 + 5.47 Ca(II) 128 0.112 0.196 0 PO43- 128 0.115 0.196 0 NO~ 128 0.114 0.196 0
Sensitivity. The distribution ratio for iron(III) of a 25 ml sample solution was 1250, while for iron(II) in the presence of ascorbic acid it was only 238. However, if iron(II) was present in the absence of ascorbic acid, some iron(II) might be oxidized to iron(III) and eventually all iron(II) was oxi- dized, and the distribution ratio of iron(II) was nearly equal to that of iron(III). For iron(III) with larger sample volumes such as a 1500 ml, the relative detection limit increased (the concentration that produced an absorbance equal to that of a 25 ml sample solution) to 1.31 x 10- 7 M, with 25 ml it was 7.84x 10 -6.
Formation constant. The formation constant of iron-hydrox- amate resin complex were measured by the method of Loewenschuss and Schmuckler [10]. This involved a compe- tition of the ferric ion between resin and an external E D T A solution. The equation used to determine KMR, the formation constant of the resin for the metal ion, was
log Ko .... n = log KMR -- log KMy = log [MR] [Y] _ log[R] .
[MY]
The conditional formation constant obtained was 104.44 . The dissociation constant of the hydroxamate resin mea- sured potentiometrically in the previous paper [7] was 10-6.47. In 0.2 N perchloric acid solution, ~ value of the hydroxamic acid resin could be calculated from the equation, Ka/[H +] + Ka. The formation constant for the iron-hydroxamate resin complex, 101~ , agreed fairly well with the correspon- ding constant of the hydroxamate monomer (acetohydroxa- mic acid), 10 T M [9].
Effect of various substances on the retention of iron(III). Various metal ions that might react with hydroxamate resin were examined for their effect on the absorption procedure. The results are shown in Table 1. Most of the metals did not interfere, except for higher concentrations of lead(II) and mercury(II) when present at up to 400 times the concentra- tion of iron(III).
The effects of EDTA, glycine and thiourea on the reten- tion of iron(II) were also examined. Only thiourea signifi- cantly influenced the retention of iron(III), even at 0.2 N perchloric acid solution by considerably decreasing it. When comparing the conditional constant of iron-resin complex with those of iron-EDTA and iron-glycine [11], the above phenomenon was quite obvious.
Originatarbeiten
The presence of sodium chloride even at a concentration35000 times that of iron(III) did not interfere at all. Thus, the suggested method was an excellent technique for the determination of iron(III) in high concentrations of elec- trolyte.
Application of chelating ion-exchanger colorimetry.
The me-thod was applied to the determination of iron(III) in stan- dard reference material of NBS, No. 1643b (trace elements in water) and natural water samples, such as tap water and rain water. The concentration of iron(III) in the standard was 110 ~tg/1, being somewhat higher than the true value (99 + 8 gg/1), while that of the tap water at different places was varying. The iron(III) concentration of tap water I was 205 gg/1, that of tap water II was only 14.6 lag/1. When the tap water I was passed through 0.45 gm filter before determi- nation, the concentration of iron(III) decreased to under detection level. Hence, the high concentration of iron(III) in tap water I might be due to the corrosion of tubing. The iron(III) concentration of rain water sampled in Taipei area was 22.3 gg/1. The results of five determination for each sample were highly reproducible.
Conclusion
The suggested method for the determination of micro- amounts of iron(III) in water is (1) sensitive and selective
(without any prior separation and preconcentration); (2) able to be applied in the presence of large amounts of other metal ions and sodium chloride (hence it is suitable for the determination of the iron content ofhigh-electroyte samples, such as sea water and biological samples); (3) simple and reproducible.
Acknowledgement.
This work was supported by a grant from the National Science Council of the Republic of China, to which great thanks are due.References
t. Yale HL (1943) Chem Rev 33:209 2. Mathis F (1953) Bull Soc Chim Fr D9 3. Neilands JB (1966) Struct Bonding I : 59 4. Maehr H (1971) Pure Appl Chem 28:603 5. Bass VC, Yoe JH (1966) Talanta 13:735 6. Aksnes G (1957) Acta Chem Scand 11:710
7. Liu CY, Sun PJ (1986) Fresenius Z Anal Chem 325:553 8. Yoshimura K, Ohashi S (1978) Talanta 25:103
9. Schwarzenbach G, Schwarzenbach K (1963) Helv Chim Acta 46:1390
10. Loewenschuss H, Schmuckler G (1964) Talanta 11:1399 11. Martell AE, Smith RM (1974) Critical stability constants, vol
1. Plenum Press, New York Received February 11, 1987
