Yiming Li, Member, IEEE, and Hui-Wen Cheng, Student Member, IEEE
Abstract—Application of nanogaps for electron sources is fasci-nating in surface-conduction electron-emitter display. In contrast to rather complicated fabrication processes of the focused ion beam technique for the extremely narrow fissure, nanogaps fabricated by hydrogen embrittlement (HE) have thus been proposed as novel surface-conduction electron emitters due to their low turn-ON volt-age, high emission current, high focus capability, and high emission efficiency. In this paper, we theoretically investigate effects of the separation width and the tilted angle of the nanogaps fabricated by HE method on the field emission efficiency using a 3-D finite-difference time-domain particle-in-cell simulation technique. The structure with a large tilted angle may result in a high emitted cur-rent, but the collected current on the anode is suppressed due to the strong local field around the tip. A small structure prevents the emitted electrons from spreading out, and thus, no current could be collected by the anode. Also, the structure with a wide (or a narrow) separation of gap weakens (or enhances) the field around the tip and reduces the collected electrons. For better emission ef-ficiency and focus capability, the separation width and the tilted angle of the examined structure could vary from 57 to 117 nm and 30◦to 60◦, respectively.
Index Terms—Collected electron current, emitted electron cur-rent, field emission efficiency, focus capability, Fowler–Nordheim equation, finite-difference time-domain (FDTD) particle in cell (PIC), hydrogen embrittlement, Maxwell’s equations, motion tra-jectory, nanogaps, palladium, separation width, surface conduc-tion electron emitters, tilted angle.
I. INTRODUCTION
S
URFACE-CONDUCTION electron-emitter display (SED) based upon surface-conduction electron emitters (SCEs) [1]–[6] is one of new type flat panel displays. Our recent inves-tigations have indicated that the technique involving field emis-sion properties of novel SCEs with nanogaps fabricated by hy-drogen embrittlement (HE) as field emission sources is superior to the conventional focused ion beam (FIB) technique [7]–[11]. It is known that the geometrical configuration of the nanogaps fabricated by HE method may have significant influence on theManuscript received January 3, 2009. First published June 10, 2009; current version published November 11, 2009. This work was supported in part by Taiwan National Science Council (NSC) under Contract NSC-97-2221-E-009-154-MY2. The review of this paper was arranged by Associate Editor H. Misawa.
Y. Li is with the Department of Electrical Engineering, National Chiao Tung University, Hsinchu 300, Taiwan, and also with the National Nano Device Lab-oratories, Hsinchu 300, Taiwan (e-mail: [email protected]).
H.-W. Cheng is with the Institute of Communication Engineering, National Chiao Tung University, Hsinchu 300, Taiwan (e-mail: hwcheng@mail. ymlab.org).
Color versions of one or more of the figures in this paper are available online at http://ieeexplore.ieee.org.
Digital Object Identifier 10.1109/TNANO.2009.2024535
field emission of SCEs. However, the study on optimal config-uration, such as the separation width and the tilted angle of the novel nanogaps fabricated by HE method, has not been reported to date.
To obtain better field emission property and a higher focus capability for advanced SED applications, we study the effect of the separation width and the tilted angle of cathodes on the emission efficiency of SCEs with the nanogaps fabricated by HE method. A 3-D particle-in-cell (PIC) method, coupled with the finite-difference time-domain (FDTD) scheme, is adopted to explore the optimal configuration of the novel nanogaps on the palladium (Pd) thin-film strip. However, to obtain the desired field emission properties, the designing variables are modified. The 3-D FDTD-PIC scheme includes the space charge effects automatically, which allows us to analyze the final steady-state effect of configuration on the conducting mechanism and the field emission efficiency of the Pd hydrogenation nanogap field emission emitter. The result obtained in this study shows that the nanogap fabricated by HE method on the Pd thin-film strip with a large tilted angle may result in high emitted currents, but the collected current on the anode is suppressed due to the strong local field around the tip of the nanogap. For the novel SCE with a small angle, the structure prevents the emitted electrons from spreading out, and thus, no current could be collected by the anode. In addition, the novel SCE with wide separation of gap weakens the field around the tip. Similarly, we have an enhanced local field around the tip for the structure with a narrow separation of gap. Both of them will reduce the collected electrons. According to our preliminary examinations, we thus find a tradeoff between the tilted angle and the separation width of the nanogap fabricated by HE method. For better emission efficiency and high focus capability, the gap width could range from 57 to 117 nm and the tilted angle could vary from 30◦to 60◦.
This paper is organized as follows. Section II describes the nanogaps fabricated by HE method for the SCE structure and the simulation procedure. In Section III, the emission cur-rent, the electronic trajectories, the electric field distribution near the nanogaps, and the emission efficiency are examined with respect to different tilted angle and separation width of gap. Finally, conclusions are drawn.
II. STRUCTURE ANDSIMULATIONTECHNIQUE
For the structure of SCE to be explored, a 150-nm-thick SiO2
layer was first thermally grown on the Si substrate. The Ti layer
Fig. 1. Cross-sectional illustration of the (a) FIB and (b) nanogaps fabricated by HE method within the structure of SCEs.
with 5 nm thickness was electron beam (e-beam) evaporation deposited on the oxide as an adhesion layer for the subsequently deposited Pt thin film with a thickness of 10 nm. The pattering of the Pt/Ti line electrodes with a width of 80 µm was photolitho-graphically performed using a liftoff method. The 30-nm-thick Pd thin film [12]–[14] is deposited on the Pt/Ti bottom elec-trode, and liftoff method is also used to pattern the 50-µm-long and 3-µm-wide Pd electrode line [15]–[17], where the material settings are shown in the upper right of Fig. 1. Electron emission characteristics in the nanogaps are studied using a dc voltage power supply. The measurement is carried out under a vacuum condition of 10−6 torr [18], [19]. We notice that the shape of nanogap could be controlled by two different treatments. Gaps with a right vertical angle could be formed by the focused ion beam (FIB) energy [20]–[22], and the gaps with various tilted angles are fabricated by the high-pressure hydrogen absorption treatment, as shown in Fig. 1(a) and (b), respectively [23], [24]. Details of fabrication characterization and calibration of the conventional and novel structures have been reported in our previous works [7]–[11].
To explore the effect of the tilted angle and the separation width on the emission efficiency and focus capability of the nanogap fabricated by HE method on the Pd thin-film of the SCE, starting from a specified initial state, according to [25], we solve Maxwell’s equation
∂B ∂t =− ∇ ×E ∂E ∂t =− J ε + (µε) −1 ∇ ×B ∇·E = ρ ε ∇·B = 0 (1)
and then obtain Lorentz’s force F = q(E + v ×B ) ∂x ∂t = v . (2)
We notice that E and B are the vectors of electric and
mag-netic fields, respectively, x and v the vectors of position and
velocity of electron, respectively, ε and µ are permeability and permittivity, and J and ρ are the current density vector and
charge density resulting from charge particles, respectively. For
Fig. 2. Computational scheme for field emission simulation.
each PIC procedure, the fundamentals of PIC are briefly de-scribed [26]–[28]; the full set of 3-D Maxwell’s equations is simultaneously solved using FDTD method to obtain electro-magnetic fields [26]–[30]. The electrons are moved according to the fields advanced in each time step. The obtained electron density and current density are successively used as sources for advancing the electromagnetic fields. This 3-D FDTD-PIC method forms a self-consistent simulation of the electromag-netic fields and charged particles, as shown in Fig. 2 [10]. These steps are repeated for each time step until the specified number of time steps is reached.
In the field emission process, the electron emission is calcu-lated by the Fowler–Nordheim equation [31]
J =AE 2 ϕt2 exp −Bv(y)ϕ3/2 EN (3) where the experimentally validated coefficients A and B are 1.541× 10−6A·eV/V2and 6.3408× 108eV−3/2·V·µm−1, EN
is the normal component of the electric field at the emitter sur-face, ϕ is the work function of the emission material [32]–[35],
t2 = 1.1, and v(y) = 0.95− y2, with y = 3.79× 10−5×
E1/2/ϕ being in SI unit [7]–[11].
We have previously observed that the SCEs fabricated by HE method have a higher focus capability than that of the conven-tional one fabricated by FIB method [7], [10]. To pursue the higher field emission efficiency and more focus capability, we further examine the geometrical configuration of the structure fabricated by HE method and the property of its field emission. Section III simultaneously optimizes the tilted angle, ranging from 10◦to 80◦, and the gap width, varying from 0 to 147 nm, of Pd (morphology of the emitters) to investigate the character-istics of field emission.
Fig. 3. (a) Schematic plot of the SED structure, where the SCE is fabricated by high-pressure hydrogen absorption treatment, where Va+ Vd= 2000 V and Vd= 40 V. (b) Cross-sectional plot of the SCE along the x–z plane, where the gap and θ are the separation width and the tilted angle.
III. RESULTS
Fig. 3(a) and (b) illustrates the overview of the SED struc-ture and the cross-sectional plot of nanogaps fabricated by HE method on the x–z plane. The anode voltage (Va) and cathode
voltage (Vd) are fixed at 1960 and 40 V for all of the following
calculations. We notice that the SCEs fabricated by HE method under such bias condition maintain enough voltage to turn on the emitter electrode based on our experimental characteriza-tion [7]–[11]. The gap width and the tilted angle of SED, as shown in Fig. 3(b), are two process variables to be examined for designing a high-performance SED device. We first find that the SED collects no current on the anode electrode if the sep-aration width and the tilted angle of SCE nanogap are 147 nm and 10◦. The structure with an extremely tilted angle weakens the strength of electric field around the emitter, as shown in Fig. 4(a); from the electronic trajectory perspective, which is shown in Fig. 4(b), the emitted electrons under this configura-tion are strongly blocked by the geometry.
For the case with a smaller separation width and a larger tilted angle, 0 nm and 80◦, for example, a large number of electrons are emitted from the emitters due to a strong electric field, as shown in Fig. 5(a). The narrower gap width implies the stronger electric field. The electric field between the left and right emitter electrodes is strong enough to attract more electrons due to smaller gap width, as shown in Fig. 5(b).
However, more emitted electrons are attracted, and hence, move downward along the direction of the strong electric field
Fig. 4. Plot of (a) electric field and (b) electronic trajectory. Both of them result from the structure with 147 nm separation width and 10◦tilted angle.
Fig. 5. Plot of (a) electric field and (b) electronic trajectory for the structure with 0 nm separation width and 80◦tilted angle.
Fig. 6. Plot of (a) electric field and (b) electronic trajectory for the structure with 27 nm separation width and 20◦tilted angle.
around the tip of electric field. It results in more electrons being absorbed by the cathodes because the distribution of electric filed is limited in a smaller region. Only very few emitted elec-trons could be collected by the anode. According to the earlier observations, we know that too narrow separation width or large tilted angle will decrease the collected current due to a strong electric field around the apex of cathodes. The most part of emit-ted electrons moves downward rapidly; consequently, the anode electrode could merely collect few electrons.
For example, if we further decrease the tilted angle from 80◦ to 20◦and increase the separation width of gap from 0 to 27 nm, the strength of electric field is reduced and the distribution of electric field becomes wider, as shown in Fig. 6(a). Compared with the SCE with 0 nm separation width and 80◦tilted angle, the electric field reduction is about 60% due to a wider gap. However, the gap width is still narrow that could not prevent the emitted electrons from moving downward to be absorbed, as shown in Fig. 6(b). Only fewer emitted electrons are attracted
Fig. 7. Plot of (a) electric field and (b) electronic trajectory for the structure with 87 nm separation width and 40◦tilted angle.
Fig. 8. Plot of (a) collected and (b) emitted currents for the separation width from 0 to 147 nm and the tilted angle from 10◦to 80◦. The inset of (b) is the emitted current in the log scale.
by the tip of electrode due to the weak electric field. Most of electrons are moving upward as they are attracted by the anode, and thus, result in large collected current, and a high efficiency of field emission could be expected. We know that an increased tilted angle can avoid significant reduction of the strength of electric field. For a wide gap width, only few electrons could be emitted from the electrode due to the weaker electric field. As the gap width is increased from 27 to 87 nm and the tilted angle is slightly increased from 20◦to 40◦, the gap with the larger titled angle demonstrates that the distribution of electric field is wider and extends upward from the electrode, as shown in Fig. 7(a). Thus, more emitted electrons move upward. Compared with the case of 0 nm and 80◦, the electric field reduction is about 45%. The reduction of electric field is less than that for the case of 27 nm and 20◦. We could conclude that the variation of titled angel is more sensitive than the variation of gap width in field emission. It is found that more emitted electrons move upward to the anode as the driving voltage is increased, as shown in Fig. 7(b). Consequently, there is a tradeoff between the separation width of gap and the tilted angle. According to the analyses given before, the collected and emitted currents are shown with respect to different separation width and tilted angle of SCE nanogap in Fig. 8(a) and (b), respectively. By defining the efficiency as the collected current divided by the emitted current and considering the emitted current, which is greater than 1× 10−6 A, as a criterion for the following efficiency calculation, the estimated efficiency is shown in Fig. 9, where the electric field, emitted and collected currents, and efficiency for the interesting cases of 57 and 117 nm are listed in Table I. Most of emitted electrons enter into the oxide conduction band,
Fig. 9. Efficiency versus the separation width and the tilted angle for the investigated SED.
TABLE I
ELECTRICFIELD, EMITTEDCURRENT, COLLECTEDCURRENT,AND
EFFICIENCY FOR57 nm GAP AND117 nm GAPWITHTILTED
ANGLES30◦AND60◦, RESPECTIVELY
Fig. 10. Plot of the electric field for the case of structure with (a) 87 nm gap and 30◦tilted angle and (b) 147 nm gap and 80◦tilted angle.
which results in degradation of efficiency. It is then noted that the gap width and the tilted angle have an influence on the amount of electrons that enter the oxide. The results show that the explored structure with the range of the separation width from 57 to 117 nm and the larger tilted angle from 30◦to 60◦ possess promising emission efficiency.
To investigate the focus capability, we further examine the SCE structure with 80◦ tilted angle and 147 nm gap, which is out of the suggested range. We compare it with the SCE with 30◦tilted angle and 87 nm gap, where they have similar strength of electric fields, as shown in Fig. 10(a) and (b). The distribution of electric field for the case with 30◦tilted angle and 87 nm gap is relatively small, and the emitted electrons can move upward
Fig. 11. 3-D electronic trajectories of the cases with (a) 87 nm gap and 30◦ tilted angle and (b) 147 nm gap and 80◦tilted angle.
Fig. 12. Plot of the electronic trajectories on the x–z plane of the cases with (a) 87 nm gap and 30◦tilted angle and (b) 147 nm gap and 80◦tilted angle.
Fig. 13. Plot of the electronic trajectories on the y–z plane of the cases with (a) 87 nm gap and 30◦tilted angle and (b) 147 nm gap and 80◦tilted angle.
and are localized centrally. However, the emitted electrons with a wider gap width spread out. The corresponding 3-D electronic trajectories are shown in Fig. 11(a) and (b). On the x–z plane, the electronic trajectory of the SCE with 147 nm gap and 80◦ tilted angle is wider than that of the case with 87 nm gap and 30◦ tilted angle, as shown in Fig. 12(a) and (b); on the y–z plane, it is obvious that the SCE structure with 87 nm gap and 30◦tilted angle has higher focus capability than the other one, as shown in Fig. 13(a) and (b), respectively. From a view of current density distribution on the anode, the SCE with 87 nm gap and 30◦tilted angle has a higher collected current and focus capability than that of the SCE with 147 nm gap and 80◦tilted angle, as shown in Fig. 14(a) and (b). Compared to the SCE with 87 nm gap and 30◦tilted angle, the strength of electric field in the SCE with 147 nm gap and 80◦ tilted angle is reduced by 17% and collected current is reduced by 80.4%. SCEs with a larger tilted angle have a stronger electric field, but more emitted electrons will move downward against the anode. Thus, the collected current
Fig. 14. Current density distribution on the anode for the case of structure with (a) 87 nm gap and 30◦tilted angle and (b) 147 nm gap and 80◦tilted angle.
TABLE II
LOSS(INPERCENT)OFEMITTEDCURRENTENTERING IN THEOXIDEUNDER
DIFFERENTGEOMETRYDESIGNS
will be reduced. We know that the SCE with a wider gap width absorbs fewer electrons from electrode due to the weak electric field. Therefore, for better field emission efficiency and higher focus capability, the separation width of gap varying from 57 to 117 nm and the tilted angle within 30◦–60◦are suggested.
IV. DISCUSSIONS
The current conservation law tells us that the total emitted current at the left electrode (Ie) is the sum of the current at the
right electrode (Id), the current flowing to the substrate oxide
(Iox), and the current collected by the anode (Ia). The substrate
oxide may be heated by Iox, because the entered electrons have
energies higher than the oxide conduction band edge. However, since the mechanism of how the emission rate is affected is unknown, we ignore the influence of these trajectories in the present simulation. Taking into consideration the discrepancy
Ie− (Id+ Ia), the efficiency turned out to be less than 50%,
i.e., we have more than 50% loss of emitted electrons due to the trajectories. As shown in Fig. 4(a), since the electric flux distribution of SCEs with 147 nm separation width and 10◦ tilted angle spreads widely and deeply into the oxide, most of the emitted electrons must enter the oxide conduction band along the electric flux lines. The efficiency turned out to be degraded by 97% due to Iox. As shown in Fig. 5(b), since the
gap width is too narrow for the emitted electrons to enter into the oxide, this suppresses the degradation of efficiency, which results in 87% loss of Ie. As shown in Fig. 6(a), the SCEs with
27 nm separation width and 20◦tilted angle reduce the electric field, whereas the wider gap width results in wider distribution of electric field into the oxide. We still have the 83% loss of Ie.
As shown in Fig. 7(a), the SCE with 87 nm separation width and 40◦tilted angle exhibits larger electric field, and more electrons are emitted due to larger tilted angle. For more emitted current, the amounts of both Ioxand Iaincrease. Consequently, there is a
efficiency has been optimized by varying the separation width of gap and the tilted angle. The emitter with a small tilted an-gle limits those emitted electrons to move upward to the anode and reduces the collected current. Therefore, a fixed separa-tion width of gap with a higher tilted angle has been examined. The high electric field gathered around the emitter tip induces a higher emission current. However, the high electric field around the emitter tip attracts more emitted electrons and reduces the collected current on the anode. On the other hand, a wide gap between two electrodes of cathode decreases the electric field and reduces the number of emitted electrons. Thus, a narrow space between two electrodes has been used to increase the electric field and emit a large number of electrons. The stronger electric field between two electrodes attracts electrons and re-duces the collected current. For better field emission efficiency, the separation width of gap could be varied from 57 to 117 nm, and the range of tilted angle is within 30◦–60◦ for the SED under the specified bias condition. We are currently studying the field emission property of the novel nanogap fabricated by HE method with different material and morphology. Such in-vestigation may produce higher emission current under lower supply voltage, and thus, it will benefit high-performance SED application. With regard to the current entering the oxide, we will study it in our future work.
