Tungstated zirconia catalyzed bromination of phenol red under nearly neutral solution

Tungstated zirconia catalyzed bromination of phenol

red under nearly neutral solution

She-Tin Wong

, Chi-Chau Hwang

, Chung-Yuan Mou

*

a_{Department of Chemistry, National Taiwan University, Taipei 106, Taiwan, ROC} b_{Center of Condensed Matter Science, National Taiwan University, Taipei 106, Taiwan, ROC}

Received 12 May 2005; received in revised form 20 July 2005; accepted 8 August 2005 Available online 13 October 2005

Abstract

The performance of tungstated zirconia catalysts prepared by co-precipitation (WZ) and impregnation (W/m-ZrO2) techniques in phenol red

bromination reaction was tested. Both types of catalysts showed excellent activity in this reaction in aqueous solution. The activity of WZ increases as the W loading decreases and the most active 0.6WZ catalyst contained highly dispersed WOxof low surface density on zirconia. The W/m-ZrO2

catalysts showed even higher activity in this reaction but maximum performance is observed for 1.3W/m-ZrO2instead. The active site for the redox

reaction is probably the monomer or dimer of WOxwith a single oxo group whereas low surface density of WOxprovides enough space on zirconia

for the adsorption of phenol red without blocking the redox sites. # 2005 Elsevier B.V. All rights reserved.

Keywords: Tungstated zirconia; Mesoporous zirconia; Phenol red; Bromination; XPS; EXAFS

1. Introduction

Bromination of aromatic compounds is a class of reactions of both laboratory and industrial importance. Often, bromina-tion of aromatic substrates is performed with elemental bromine which is difficult to handle. The substitution reaction, with the formation of hydrobromic acid as a by-product, would reduce the atom efficiency by 50%. Also the generated hydrobromic acid must be neutralized before it can be discharged. In order to overcome these problems, an env-ironmentally friendly process may involve oxidation of a bromide anion using a suitable oxidant such as hydrogen peroxide under nearly neutral solution. This concept has been inspired by the enzymes, vanadium dependent bromoperox-idases (VBPO). VBPO can be found in most marine organisms and has been used for the synthesis of halogenated compounds which may play the role of chemical defense[1]. It catalyzes the oxidation of a halide (i.e. Cl
, Br
, or I
) by hydrogen peroxide which is then used for the subsequent halogenation reactions. Many of these halogenated compounds have been used widely in pharmaceutical research due to their biological activities. However, the direct use of haloperoxidase in

large-scale synthesis may not be practical since high cost is involved in the cultivation, extraction and purification of this enzyme from its source. An alternative approach is to find a biomimetic halogenation catalyst instead.

Bromination of phenol red is often used as the test reaction for these biomimetic catalysts since it is facile and can be followed easily by UV–visible absorption technique. A proposed reaction pathway through the formation of ‘‘OBr
’’ ’’ intermediate is outlined in scheme(1) [1]:

Br
þ H2O2 ! ‘‘OBr
’’þ H2O

(1) It has been suggested that there exist an equilibrium mixture of bromine intermediates in aqueous solution such as HOBr, Br3+, Br2, and even Br species coordinated to the catalyst.

www.elsevier.com/locate/apcatb

* Corresponding author. Fax: +886 2 23660954. E-mail address: [email protected] (C.-Y. Mou).

0926-3373/$ – see front matter # 2005 Elsevier B.V. All rights reserved. doi:10.1016/j.apcatb.2005.08.001

However, for homogeneous catalyst, high concentrations of metal relative to reactants are often needed. The separation cost is a further disadvantage.

Recently, Sels et al.[3–6]have prepared a series of tungstate ion (WO42
) exchanged layered double hydroxides (LDH) and they showed the highest activity so far in phenol red bromination reaction at nearly neutral pH condition. Previous studies involving homogeneous catalysts in solution required strong acidic condition for promising results. However, tungstate ion may leach from LDH over long term. It is also known that the LDH structure would dehydroxylate or form new compound with various surface anions at high temperature. In addition, being basic in nature, LDH is not very stable in acidic medium[7]. Stucky and co-workers on the other hand have functionalized mesoporous silica MCM-48 with tungsten and molybdenum[8]. The resulting surface metal-oxo species showed catalytic peroxide activation. However, their bromina-tion activities are apparently rather low and no details on catalysis are given. It seems that silica is a poor support for tungstate to generate the necessary surface acidic and redox species for the catalysis.

Tungstated zirconia, WOx/ZrO2, is a versatile catalyst in that it can catalyze both acid and redox type of reactions. So far, this class of catalyst is only well-known for the study of acid-catalyzed reaction such as the isomerization of o-xylene and n-alkane [9,10]. However, Lewis acid can also promote oxidation reaction by coordinating with a peroxy species and enhancing dramatically the electrophilicity of these oxidizing reagents toward their reaction with weakly nucleophilic substrates such as bromide. Tungstated zirconia is known to have Lewis acid sites on their surfaces[10].

Normally, loadings higher than full monolayer coverage of WOx on zirconia are required for maximum acidic catalytic performance such as in isomerization [10]. For biomimetic bromoperoxidation reaction, the active center seems to be monomeric or dimeric species. Now, highly dispersed WOx surface sites are required for the efficient oxidation of Br
before electrophilic substitution into the hydrocarbon structure occurs. In this paper, we shall report the catalytic properties of tungstated zirconia in the bromination of phenol red. We report the preparation (co-precipitation and impregnation), character-ization (XPS, EXAFS, EPR, IR), and catalytic bromination reaction of phenol red over tungstated zirconia catalysts. Very high turn-over frequency is obtained for catalysts with highly dispersed WOxon the surface.

2. Experimental

In our study, two kinds of tungstated zirconia catalysts were used: the catalysts prepared by co-precipitation technique were denoted as WZ, whereas those prepared by impregnation technique were denoted as W/m-ZrO2. It should be noted that mesoporous zirconia (m-ZrO2) was used for the latter method.

by co-precipitation technique from a solution of zirconyl nitrate hydrate, ZrO(NO3)2xH2O, by adding dropwise a solution containing NH4OH and ammonium metatungstate hydrate (NH4)6W12O39xH2O. After hydrothermal reaction and separa-tion, the precursor was calcined in static air for 3 h at 600 or 800 8C (for 13.7WZ). The resulting catalyst is denoted as xWZ, where x is the weight percent of tungsten in WZ.

Hexadecyl trimethyl ammonium bromide (C16TAB) was used as the template for the synthesis of mesoporous zirconium oxide (designated as m-ZrO2). Mesoporous zirconia was prepared according to the method outlined in reference [11], and has been well characterized[12]. xW/m-ZrO2(x denotes weight percent of W) was prepared by impregnating (NH4)6W12O39xH2O on mesoporous zirconia and calcined at 630 8C for 4 h.

Elemental composition was analyzed with a simultaneous ICP-AES allied analytical system (Jarrel-Ash, Model ICAP 9000). X-ray diffraction (XRD) analysis was done with powdered samples on Philips Expert instrument. Nitrogen adsorption-desorption data were obtained at
196 8C on a Micromeritics ASAP 2000 apparatus and were analyzed for BET surface area and pore size distribution. Ultraviolet–visible (UV–vis) absorption spectra were taken on a Hitachi U-3010 spectrophotometer. Infrared (IR) spectra were recorded on a Nicolet Magna-IR 550 spectrometer. A Bruker EMX EPR spectrometer (X-band) was employed to measure the electron paramagnetic resonance (EPR) spectra of the sample.

The study on X-ray photoelectron spectroscopy (XPS) was carried out on a VG Scientific ESCALAB 250 XPS instrument with an incident X-ray energy of 1486.8 eV (Al Ka). The binding energy (BE) of C 1s peak (284.8 eV) in the spectrum is used as the internal reference for energy calibration. Data analysis involved smoothing, non-linear Shirley-type back-ground subtraction and curve-fitting using mixed Gaussian– Lorentzian functions.

W-LIII-edge extended X-ray absorption fine structure (EXAFS) study was performed at the National Synchrotron Radiation Research Center in Hsinchu, Taiwan. The electron storage ring was operated at about 1.5 GeV with a ring current of about 200 mA. All the experiments were done at room temperature. The resulting EXAFS data were analyzed with standard FEFF6 program. Special scanning procedure was employed for the highly dispersed 0.6WZ catalyst. It was done in the fluorescence mode and each scan took twice as long as the other catalysts. Six such scans were average to give a better spectrum.

Bromination of phenol red to bromophenol blue was carried out at room temperature and monitored using UV–vis spectroscopy. The solvent used was either water or a mixture of water, methanol and tetrahydrofuran where the volume ratio of H2O:CH3OH:C4H8O is 4:3:2 [4]. The solid catalyst was removed before each measurement. The reaction conditions for the catalysis are listed in the table of catalytic results.

3. Results 3.1. XRD study

Fig. 1compares the XRD patterns of WZ with different W loadings. No diffraction peaks due to WOx crystallites at 2u = 23.2, 23.6 and 24.48 are observed on samples with W loading <13.7 wt%. It should be pointed out that the peak at 24.38 for samples with W loading <13.7 wt% is due to monoclinic zirconia and not WOx crystallites [13]. Tetra-gonal zirconia is only observed in 13.7WZ but monoclinic zirconia becomes increasingly prominent as the W loading decreases.

3.2. IR study

The IR spectrum of 0.6WZ is shown in Fig. 2. Before dehydration, adsorbed water led to a broad band at 2800– 3700 cm
1and a sharp band at 1628 cm
1, both of which are much diminished after drying. Pure tetragonal ZrO2 would show surface hydroxyl bands between 3600 and 3800 cm
1

[14,15]. In our 0.6WZ sample, we only see a very weak bump centered at 3448 cm
1confirming surface anchoring of W. We also demonstrate that 0.6WZ adsorbs not only water but also carbon dioxide. When the spectrum was taken immediately after drying at 100 8C, absorption bands around 2353 cm
1due to adsorbed CO2appeared. It is known that zirconia possesses surface basic sites in addition to acidic sites [14,15]. Apparently, CO2 was preferentially adsorbed on some basic sites of partially exposed zirconia surface in 0.6WZ. When the 0.6WZ sample was allowed to stand for 1 h in static air, the CO2 absorption bands disappeared again. We also noted that the amount of adsorbed CO2decreases as the W loading increases.

This is understandable since the zirconia surface sites would diminish as the WOxcoverage is increased.

3.3. XPS study

We have also measured the W 4f and Zr 3d XPS spectra of WZ at different W loadings (Fig. 3). W 4f peaks becomes prominent only in the high W-loading sample (13.7WZ). The Zr 3d (and 4p) peaks shifted to higher BE as the W loading increases and this indicates the flow of electron density from zirconia phase into WOxphase through the Zr–O–W linkages. Curve-fitting analysis of the W 4f peaks in 13.7WZ showed that they can be deconvoluted into three doublets (W 4f7/2and W 4f5/2) with W 4f7/2electron BEs of 34.6 eV (76%), 35.4 eV (15%), and 35.8 eV (9%). The bracketed values are the relative concentration of these species. The BE at 34.6 eV is close to that reported for W5+. The higher BEs are close to the reported value of W6+ in similar catalyst system (35.5 eV) [16]. Similarly, curve-fitting analysis of the corresponding Zr 3d peaks in 13.7WZ showed that they can be deconvoluted into three doublets (Zr 3d5/2and Zr 3d3/2) with Zr 3d5/2electron BEs of 179.6 eV (29%), 181.2 eV (17%), and 182.4 eV (54%). The last two are close to the corresponding BE of Zr4+ in bulk zirconia (182.1 eV)[17]. The first one, however, appeared at a much lower BE than pure zirconia and indicates the presence of Zr3+species. Indeed, Zr3+species were observed in our 0.6WZ catalyst by EPR with g? = 1.980[18].

From the integrated area of the XPS peaks and taking into consideration of the atomic sensitivity factor of W and Zr, the surface W/Zr ratio of each WZ sample can be calculated. The surface W/Zr ratio increases roughly linearly as the loading of W in WZ increases (Fig. 4).

Fig. 1. XRD patterns of (a) 0.6WZ; (b) 3.3WZ; (c) 10.1WZ; (d) 13.7WZ.

Fig. 2. IR spectra of 0.6WZ (a) as-synthesized; (b) after 100 8C drying; (c) repeated scan; (d) after 1 h standing.

3.4. EXAFS study

The Fourier-transformed W-LIII-edge EXAFS radial dis-tribution function (RDF) of 0.6WZ (curve a), 13.7WZ (curve b), and WO3(curve c) are compared inFig. 5. These RDFs are not corrected for phase shifts. The three samples represent catalysts with tungstate species in three different states, that is, highly dispersed (a), monolayer (b), and bulk crystallites (c). Care should be taken in comparing intensity since their surface

tungstate species have different degree of structural disorder-ness. One should also note the low signal to noise ratio of 0.6WZ spectrum due to the very low W loading.

Subtle differences are observed among these catalysts. Firstly, we can see that bulk WO3phase is not prominent in WZ

Fig. 3. (A) W 4f XPS spectra and (B) Zr 3d XPS spectra of (a) 0.6WZ; (b) 3.3WZ; (c) 10.1WZ; (d) 13.7WZ.

Fig. 4. Surface density of WOxon WZ catalysts.

Fig. 5. Fourier-transformed W-LIII-edge EXAFS RDFs of (a) 0.6WZ; (b)

samples judging from the peak intensity due to W–O–W distance at 3.53 A˚ of curve c. The shorter W–O–W linkages observed on WZ catalysts could be due to surface WOxspecies interacting directly with zirconia surfaces[16]. One can see that the W–O–W linkage becomes shorter as W loading decreased. Secondly, the W–O peak intensity at about 1.29 A˚ increased as the W loading decreased, reflecting less W O bonding. Lastly, the peak at 2.18 A˚ also increased as W loading decreased, indicating the formation of more W–O–Zr linkages[16]when W is highly dispersed. In addition, some peaks at similar distance in WO3 have been assigned to multiple scattering

[19].

Therefore, highly dispersed 0.6WZ catalyst showed four interesting features, that is, low W–O–W peak intensity, short W–O–W bond, plenty of W–O and possibly W–O–Zr bonds. 3.5. Catalytic study

The conversion of phenol red into bromophenol blue can be followed readily by UV–vis absorption. For the 0.6WZ catalyst, the result is shown inFig. 6. As the reaction proceeds, it can be easily seen that the peak at about lmax 590 nm, correspond-ing to bromophenol blue, increases with time on stream up to 120 min. At the same time, the peak corresponding to phenol red (lmax 432.5 nm) decreases as time on stream increases. Also, the peaks at 309 and 379 nm may be ascribed to the O22
! W charge transfer in the formation of peroxotungstates upon the addition of H2O2 [4,20]. This is analogous to the peroxo form in V active site in vanadium bromoperoxidase

[21].

In addition, both the bromination reactions in water and mixed solvent showed similar spectral feature. The kinetic

profiles of bromophenol blue formation versus reaction time over 0.6WZ catalyst showed that they increase almost linearly in the region up to 50% conversion of phenol red. In addition, the concentration of bromophenol blue passes a maximum and decreases a little at longer reaction time. The loss of bromophenol blue at this later stage is possibly due to further consecutive reactions.

Table 1 compares the performance of WZ and W/m-ZrO2 catalysts with literature reported WO42
-LDH in phenol red bromination reaction. The surface area of these catalysts is also included. For the formation of one bromophenol blue molecule, four Br
are oxidized and incorporated into one phenol red molecule. The concentration of bromophenol blue was derived from the UV–vis absorbance by using an extinction coefficient (e) of 70.4 mM
1cm
1at lmax[4]. Turn-over number (TON) is defined as the number of moles of Br
oxidized per mole of tungsten per hour. We found that the bromination activity (TON) of WZ decreases with increasing W loading. The reaction activity of 0.6WZ in water and mixed solvent are comparable. By analyzing the change in the concentration of bromophenol blue in the filtered solution with time, the contribution from leached WOxspecies to the overall activity was found to be negligible. Most importantly, W/m-ZrO2has higher activity than WZ in this reaction.

Fig. 6. UV–vis absorption spectra during the course of bromination reaction over 0.6WZ catalyst. Reaction conditions are: room temperature; 32 ml 0.05 mM phenol red solution; 0.1 M NH4Br; 1.73 10
3mM W; 11.3 mM H2O2.

Table 1

Phenol red (PR) bromination over W-containing catalystsa

Catalyst PR (mM) H2O2 (mM) Solventb TONc (h
1) Surface area (m2g
1) WO42
-LDHd 0.05 10.0 Mix 109.6 – 0.6WZ 0.05 13.2 Mix 37.4 44 0.6WZ 0.05 11.3 H2O 31.3 44 Filtratee 0.05 11.3 H2O 0.09 – 3.3WZ 0.05 11.5 H2O 24.2 54 13.7WZ 0.05 11.1 H2O 0.85 78 0.7W/m-ZrO2 0.05 15.2 H2O 71.6 105

a _{Reaction is carried out at room temperature and with 0.1 M NH} 4Br. b _{For mixed solvent, the volume ratio of H}

2O:CH3OH:C4H8O = 4:3:2. c _{TON is defined as the number of moles of Br
oxidized per mole of tungsten}

per hour.

d _{Data taken from[4].}

e _{Residual activity of the filtered aqueous solution from 0.6WZ.}

Table 2

Phenol red (PR) bromination over xW/m-ZrO2catalysts

a Catalyst TON (h
1) Surface area (m2g
1) Surface density (W/nm2) Specific activity (h
1m
2g) 0.3W/m-ZrO2 57.0 121.0 0.08 0.47 0.6W/m-ZrO2 62.0 120.7 0.16 0.51 0.7W/m-ZrO2 62.3 117.8 0.19 0.53 1.1W/m-ZrO2 70.0 118.5 0.30 0.59 1.3W/m-ZrO2 83.8 119.2 0.36 0.70 1.4W/m-ZrO2 63.7 120.0 0.38 0.53 1.5W/m-ZrO2 60.9 125.4 0.39 0.49 1.6W/m-ZrO2 41.7 122.3 0.43 0.34

a _{Reaction conditions: room temperature, 0.05 mM PR, 27.7 mM H} 2O2,

Table 2compares the activity of xW/m-ZrO2catalysts. The percentage of W is calculated according to the amount of tungsten precursor added during catalyst preparation. However, they are not far from the values determined experimentally. Here, the activity of phenol red bromination does not vary inversely with W loading as in the case of WZ. A maximum is observed at 1.3 wt% of W. On the other hand, the surface area of all the catalysts is comparable in magnitude. Surprisingly, a higher concentration of H2O2 used did not result in higher activity (compared 0.7W/m-ZrO2catalysts inTables 1 and 2).

Fig. 7shows the variation of catalytic activity with time on stream over 1.3W/m-ZrO2 catalyst. Its bromination activity decays quickly after 15 min of reaction. On the other hand, the initial activity of 0.6WZ can be maintained even after 1 h of reaction.

4. Discussion

We have shown that decreasing the loading of W is an easy way of decreasing its surface density on WZ as indicated by the surface W/Zr ratio. Similar finding is also reported by Baertsch et al.[22]. However, characterizing the structure of W active site in a low surface density catalyst, such as 0.6WZ, is always faced with the problem of limiting signal intensity. To deduce its structure, higher W loaded catalysts are also studied.

The W–O–W coordination number should decrease with W loading. However, it may not be advisable to obtain this information directly by comparing the intensity of the EXAFS spectra since tungstate ion in different structural phase has different degree of structural disorderness. One thing we are sure is that W–O–W coordination number in 0.6WZ is low indicating a low degree of oligomerization. Also, the short W– O–W in 0.6WZ tells us that the tungstate ions are all dispersed

large increase in the number of W–O and W–O–Zr groups in 0.6WZ is in line with the high degree of W dispersion observed by XRD and XPS. We suggest that WOxon 0.6WZ presumably exists as monomer and dimer. A case for monomer is indicated in Eq.(3).

In the work of Sels et al. [4], it is not surprising that WO42
-LDH has very high activity in phenol red bromination reaction since the WO42
ions are atomically dispersed on LDH. In addition, the WO42
ion contains more oxo groups which withdraw electron strongly to activate the peroxo group[19]. The bromination activity of WZ decreases as the loading of W increases due to the decreased dispersion of WOxon zirconia. In addition, the very low surface density of WOx in 0.6WZ provides enough zirconia surfaces for the adsorption of bulky phenol red molecules while not blocking the WOxactive sites. Furthermore, the bromination activity of 0.6WZ (surface area = 44 m2g
1) is lower than 0.7W/m-ZrO2 (surface area = 109 m2g
1 and pore size = 36 A˚ ). The activity of the latter catalyst is at least 50% of the best catalyst (WO42
-LDH) reported in the literature. Therefore, higher degree of dispersion of WOxon the support seems to improve on its catalytic activity. Recently, Figueras et al.[23]

studied the oxidation of dibenzothiophene by H2O2 over zirconia supported W catalysts and found that catalysts containing highly dispersed W cations are more active than WO3clusters.

InTable 2, one can see that xW/m-ZrO2showed an optimum activity at 1.3 wt% of W but the reason for this is still not known. But, we note that 1.3W/m-ZrO2has roughly the same degree of dispersion as 0.6WZ due to the higher surface area in m-ZrO2. However, its activity also decays quickly and reaches a value comparable to that of WZ. The catalyst deactivation observed in xW/m-ZrO2may be due to blocking of channels either by the strongly adsorbing bromophenol blue or other products formed via consecutive reactions, thus, limits further diffusion of reactant to the internal active sites.

The adsorption sites on zirconia for phenol red are probably the coordinatively unsaturated Zr3+which have been suggested as the center of adsorption for CO2[24,25]. We have also found that 0.6WZ has the capability to adsorb CO2and the phenol red molecule probably interacts with Zr3+ site through the SO2 group. We have done surface titration study on 0.6WZ with phenol red in aqueous medium and found that the sample colour changed quickly from white to pink whereas no such change is observed on 0.5W/SiO2. This result shows that some kind of basic sites (besides Zr3+) are also present on zirconia and adsorb the phenol red molecules.

Regarding the active sites for the redox reaction, the nature of WOxsites (whether monomer or dimer) in 0.6WZ may not have significant steric effect on the catalytic activity since the Br
and H2O2 involved in the formation of the brominating agent on these sites are small molecules. Even in 3.3WZ, such monomeric or dimeric redox sites may still be the dominant

Fig. 7. Kinetic profile of phenol red bromination versus reaction time over 1.3W/m-ZrO2catalyst. Reaction conditions are the same asTable 2.

species on the surface. This probably explains why the activity of 3.3WZ (surface area = 54 m2g
1) is not much less than that of 0.6WZ. It also has enough zirconia surfaces for the adsorption of bulky phenol red molecules. In 13.7WZ (surface area = 78 m2g
1), the situation is totally different as the loading of W on zirconia is higher than monolayer coverage and large crystallites are formed on the surface (see Fig. 1). Therefore, much lower activity is observed for this sample.

It is known that one possible active site for interacting with H2O2is the isolated W O group[19,26], the OH leaving group can be generated in-situ during the addition reaction as follows:

W¼O þ H2O2! HO
W
OOH

HO
W
OOH ! WðO2Þ þ H2O

WðO2Þ þ Br
! W¼O þ OBr
(2)

W(O2) is the peroxo species.

When an –OH group is also present, it can be substituted by a hydroperoxo group facilely under an acidic condition as shown in Eq. (3). The hydroperoxo species then transforms to the peroxo species as in Eq.(4)with the regeneration of an –OH group.

(3)

O¼W
OOH ! HO
WðO2Þ (4)

HO–W(O2) can then be further attacked by bromide and the original active site is regenerated. Unfortunately, W–OH IR signal overlaps with that of Zr–OH in our sample and made its study difficult. We have not yet studied in details how the rate of reaction occurring on oxo and hydroxyl-oxo sites differs and much work is needed in this area.

The activity of our catalysts is nearly 50% of WO42
-LDH and seems to suggest that at most one oxo group per W center is involved in bromination reaction as in Eq. (3). Surface characterization study of WZ by Scheithauer et al.[27] with Raman and FTIR spectroscopies also showed no evidence on the existence of di-oxo species. It is also tempting to suggest isolated W–OH as one of the precursor site for this reaction. W– OOH can be formed by direct substitution reaction with H2O2. However, we do not know whether the hydroperoxo group can interact directly with bromide ion without prior transformation to the peroxo species.

The bromination activity of WZ seems not much affected by the solvent used in the reaction, and high catalytic activity can be obtained even in water. This finding is unlike the general trend reported in the literature that bromination activity of a catalyst is usually lower in water than organic solvent due to the instability of the peroxo-tungstate species in water[19,26]. As shown in the UV–vis absorption spectrum inFig. 6, the

peroxo-tungstate species on WZ are apparently stable in aqueous medium. Therefore, tungstated zirconia should be a good choice of catalyst when the reaction has to be done in water or acidic medium. As the surface of these catalysts is nonionic, it is likely that the coordination environment of the peroxo-tungstate species on these surfaces is different from that of ionic surfaces.

In conclusion, we have demonstrated that tungstated zirconia at high dispersion are very active bromination catalysts and can be used as biomimetic catalysts for vanadium bromoperoxidase. This will open up a new direction for the application of these well-known catalysts and there are plenty room for improvements. Although the formation of W–O–Zr linkages limits the number of W O groups participated in the bromination reaction to one, it has the advantage of anchoring the WOxactive sites firmly on zirconia surfaces to give a highly dispersed and stable catalyst. This catalyst may be further exploited for the related bromide-assisted oxidation reactions with H2O2[28].

W/m-ZrO2catalyst has many promising features such as: (i) high catalytic activity, (ii) pore structure for shape selectivity, (iii) thermal stability (at least 630 8C) for catalyst regeneration, and (iv) stable to acid and base. One only has to improve the stability in activity. It will be investigated in great details in the future.
