DOI 10.1007/s00170-003-1902-9 O R I G I N A L A R T I C L E
Jin-Shyan Lee · Pau-Lo Hsu
A systematic approach for the sequence controller design
in manufacturing systems
Received: 15 March 2003 / Accepted: 27 May 2003 / Published online: 24 November 2004 Springer-Verlag London Limited 2004
Abstract This paper presents a systematic approach for the
design and implementation of the sequence controller in manu-facturing systems. By employing the IDEF0, we construct the simplified Petri net controller (SPNC) through the mate-rial flow diagram and the information flow diagram. Then, the ladder logic diagram (LLD) can be transformed from the SPNC through the token passing logic (TPL). The pro-posed approach, including the IDEF0, SPNC, and TPL tools, leads to the standard IEC1131-3 LLD for PLC implemen-tation. Finally, an application of a stamping process is pro-vided to illustrate the design procedure of the developed approach.
Keywords IDEF0· Ladder logic diagrams · Manufacturing
systems· Petri nets · Programmable logic controllers · Sequence controllers
1 Introduction
Recently, automated manufacturing systems have become more complex. In the control of manufacturing systems, the sequence control for the discrete events plays an important role [1]. Basi-cally, the ladder logic diagram (LLD) has been used to conduct the control software’s sequence of operations and it is usually implemented with a programmable logic controller (PLC). The PLC has the advantages of reliability, robustness, and direct pro-grammability. The I/O procedures of the PLC are specified by the LLD and industrial machines, and thus perform repetitive opera-tions in sequence.
For simple systems, it is easy to program the LLD by heuris-tic methods. However, as systems become more complex, the controller design becomes more difficult and the LLD implemen-J.-S. Lee · P.-L. Hsu (u)
Department of Electrical and Control Engineering, National Chiao-Tung University,
1001 Ta-Hsueh Road, Hsinchu, Taiwan E-mail: plhsu@cc.nctu.edu.tw
tation becomes more complicated. Moreover, because the PLC is usually programmed only to control the process, qualitative analysis and the performance characteristics of the implemented PLC controllers are seldom discussed in practice. In addition, as design specifications change, the LLD program usually needs to be modified significantly [2–4]. Hence, researchers are pursuing a systematic and efficient approach to the design and implemen-tation of the sequence controller.
In the past years, Petri nets (PN) became popular tools for designing sequence controllers in manufacturing systems [5– 10]. Uzam and Jones [11] proposed an extended PN method to analyze a target system and then implemented it via the LLD. Feldmann, et al. [12, 13] used colored PN to form the structured text (ST) for PLC implementation. In fact, most industrial PLC users still prefer to program in LLDs. Although some researchers have attempted to convert Petri nets into LLDs [11, 14–17], the resulting LLDs are usually more complex compared to those programmed directly by engineers. Moreover, it is not straight-forward or easy for manufacturing engineers to construct the PN models.
In this paper, a systematic approach is proposed for the design and implementation of the sequence controller in manu-facturing systems. By introducing the sensor state into the PN to form a simplified Petri net controller (SPNC), we obtain a more compact LLD structure through the token passing logic (TPL). Typically, the sensor state is used to trigger sequences in manufacturing. We show that the integration definition lan-guage 0 (IDEF0) [18] can be used to obtain the SPNC model through the material flow diagrams and information flow di-agrams in sequence. The proposed IDEF0/SPNC/TPL/LLD approach, including the IDEF0, SPNC, and TPL tools, then leads to the industrial standard IEC1131-3 [19] LLD for PLC implementation.
The remainder of this paper is organized as follows. First, the SPNC is defined in Sect. 2. Then, Sect. 3 introduces the proposed IDEF0/SPNC/TPL/LLD approach. In Sect. 4, an application ex-ample of a stamping process is provided to illustrate the pro-posed approach. Conclusions and recommendations for further research are provided in Sect. 5.
2 Simplified Petri net controller
In this section, we propose a simplified Petri net controller (SPNC) by introducing sensor states into the ordinary PN. The SPNC is applied to simulate the manufacturing system and to lead the IDEF0 to LLD in the proposed IDEF0/SPNC/TPL/LLD approach.
2.1 Formal definition
Fig. 1a shows an ordinary PN model for pushing a button to trigger a process. When using the ordinary PN approach in con-trolling manufacturing processes, dealing with multiple sensor readings makes the net structure more complicated and difficult to analyze. Therefore, by introducing the sensor state into the PN to form an SPNC, implementation of the net structure is sim-plified. From the control point of view, as shown in Fig. 1b, the sensor state in the SPNC replaces the reading sensor model such as push buttons or limit switches within the ordinary PN. Note that the condition of sensor states may change depending on the practical situation. Thus, as sensors increase in processes, the net structure of the SPNC is greatly simplified, as shown in Fig. 1c. Then, it becomes easy to model and implement the sequence controller through the SPNC defined as:
SPNC= (P, T, A, S, M0)
where,
P= {P1, P2, . . ., Pm} is a finite set of places,
T= {T1, T2, . . ., Tn} is a finite set of transitions with P∪ T =
∅ and P ∩ T = ∅,
A⊆ {P × T}∪ {T × P} is the set of arcs between the places and transitions,
S= {S0, S1, . . ., Sn} is the set of sensor states, and
M0: P → 1 is the initial marking.
Fig. 1a–c. The comparison between the PN and the SPNC via a simple process. a Ordinary PN. b SPNC. c Comparison results
2.2 Graphical representation
As shown in Fig. 2, the SPNC consists of three kinds of nodes: (1) the place, drawn as a circle, (2) the transition, drawn as a bar, and (3) the sensor state, drawn as a smaller circle with a hidden arrow. The arcs, represented by directed arrows, are either from a place to a transition or from a transition to a place. In modeling, the marking conditions of places represent the status of the sys-tem and the transitions represent events. A transition has a set of input and output places, which represent the pre-conditions and post-conditions of the event, respectively. A sensor state, associ-ated with its transitions, represents the sensor readings as a firing condition, which triggers a manufacturing sequence. The sensor state is a Boolean variable that can be 0, in which case the related transition is not fired, or 1, in which case the related transition is fired if it is enabled. The marking of the SPNC is represented by the number of tokens in each place, drawn as black dots. The presence of a token in a given place means that the associated condition is true or that the actions associated with this place are taken.
2.3 Dynamic behavior
The dynamic behavior of a system is simulated by the distribu-tion of tokens in places as the enable transidistribu-tions fire. The flow of tokens in the SPNC is governed according to the following rules: 1) Enabling rule:
A transition is said to be enabled if all its input places are marked.
2) Firing rule:
Furthermore, the enabled transition is fired if all its sensor states are true. When an enabled transition fires, it removes one token from all its input places and deposits one token into all its output places at the same time.
2.4 Comparison with other models
The behavior of the proposed SPNC is similar to the sequen-tial function chart (SFC). However, since SFC is derived from PN with some modifications and simplifications, theoretical re-sults of PN cannot be directly applied to SFC [20]. Since the present SPNC is an extension of the PN by introducing sen-sor states, SPNC allows formal analysis of various properties, such as the safety, liveness, and reversibility for the process [9, 10]. Moreover, SFC only offers the method for depicting se-quences of control system without providing any mechanisms to perform the functional analysis. Note that in the present
IDEF0/SPNC/TPL/LLD approach, by applying the IDEF0 for functional analysis and information flow design, the SPNC model can be transformed from the information flow diagram.
Furthermore, in contrast to other extended PN applications such as Interpreted PN [21], Automation PN [11], or Sig-nal Interpreted PN [16], which use exterSig-nal events to model sensor readings, the present SPNC simply applies the sen-sor states to model the firing conditions. Also, the present IDEF0/SPNC/TPL/LLD approach obtains the PLC programs systematically, from the design specifications through the SPNC, and to the final LLD. Since the PN model is inherently concur-rent, whereas the LLD is typically scan-based, the sequential specification must be determinate and deterministic [5] in the present approach. Also, the mono marked restrictions design is required in the proposed SPNC to guarantee the safety of the sequence in practice.
3 The IDEF0/SPNC/TPL/LLD approach
In this section, the integrated IDEF0/SPNC/TPL/LLD approach, including the IDEF0, SPNC, and TPL tools, is proposed to sys-tematically obtain the LLD for PLC implementation. The design procedure of the IDEF0/SPNC/TPL/LLD approach, depicted in Fig. 3, consist of five stages and each stage is described as follows.
3.1 Functional analysis stage: IDEF0
With the given specifications, the purpose of functional analysis is to realize the functions and operations of the system and then generate the control signals for the next stage. At this stage, each function of the manufacturing system has to be specified with a top-down hierarchically decomposing process by using the IDEF0 [18]. IDEF0 is an activity-oriented modeling approach and its representation of a manufacturing process consists of an ordered set of boxes representing activities performed by the sys-tem. The inputs are those items transformed by the activity and the outputs are the results of the activity, as shown in Fig. 4. The mechanisms, drawn as supporting arrows, represent resources such us machines, computers, and operators, etc. The decompos-ition process continues until there is sufficient detail on the basic activities to serve the purpose of sequence control. A functional model of the material flow diagram is obtained at this stage.
3.2 Information flow design stage: IDEF0
At this second stage, the information flow is used to control the material flow in a manufacturing system. The information flow diagram is constructed from the material flow diagram with static analysis, again using the IDEF0. In the information flow dia-gram, the input and output commands are designed to enable the activity and to change the machine status after firing, respec-tively. Because the mechanisms will be assigned within the I/O ports at the layout stage later, the supporting arrows for
mech-Fig. 3. Design procedure of the IDEF0/SPNC/TPL/LLD approach
Fig. 4. The IDEF0 scheme
anisms are omitted here to simplify the information flow design. The sensor readings representing the conditions to fire the activ-ity are drawn as control signal arrows. A controllable model of the information flow diagram is obtained at this stage.
3.3 Dynamic verification stage: SPNC
The information flow diagram only represents system activities and their interrelationships. Since it does not show direct logical and dynamic dependencies between activities, it is transformed into a dynamic SPNC model, which is applied to verify the dy-namic behavior of the system. The transformation of information flow diagram into SPNC model is based on the following steps: 1. An activity box in the information flow diagram is
trans-formed into a transition of the SPNC.
2. The input and output commands are transformed into input and output places, respectively.
3. The control signals of the sensor readings are transformed into sensor states.
4. The initial marking of the SPNC is set according to the initial condition of the system.
An example is shown in Fig. 5. The activity of the informa-tion flow diagram is transformed into the transiinforma-tion T1. The input
command I1 and output command I2 are transformed into the
input place P1 and output place P2, respectively, and the
con-trol signal ‘concon-trol’ is transformed into the sensor state S1. When
the SPNC model is obtained, the correctness of the sequence order can be verified by studying the behaviors via computer simulations. Also, the properties of the PN such as the safety, liveness, and reversibility can be analyzed to identify the dy-namic behavior [9].
3.4 Layout stage: TPL
To simplify the conversion of the SPNC into the LLD, the token passing logic (TPL) is employed in this stage [11]. The attrac-tive feature of the TPL is that it facilitates the direct conversion of a SPNC into a generic form of control logic, which may be implemented with low-level languages such as LLD, or with high-level languages such as C. This is achieved by adopting the SPNC concept of using tokens as the main mechanism for con-trolling the flow of the control logic. At this stage, the SPNC model is transformed into the TPL model to assign the I/O ports
Fig. 5. The transformation from the IDEF0 to the SPNC
for actions and sensor readings. For applications in a variety of industrial PLC hardware, the TPL is modified as follows: The Modified TPL= (M, T, A, in, out, time),
where,
M= {M1, M2, . . ., Mm} is a finite set of memory bits,
T= {T1, T2, . . ., Tn} is a finite set of transitions,
A⊆ {M × T} ∪ {T × M} is the set of arcs between the memories and transitions, in= {in0, in1, . . ., inn} is the set of sensor inputs,
out= {out1, out2, . . ., outm} is the set of actuator outputs,
and
time= {time1, time2, . . ., timem} is the set of delay timers.
The transformation from the SPNC model into the TPL form is based on the following steps:
1. The transition of the SPNC is transformed into a transition of the TPL.
2. The place is transformed into a memory bit. 3. The sensor state is transformed into a sensor input.
4. For the action with a place, besides the memory bit, an actu-ator output is assigned.
5. For the delay time with a place, besides the memory bit, a de-lay timer is assigned.
An example is shown in Fig. 6. The places P1 and P2 are
transformed into the memory bits M1and M2, respectively, and
the sensor state S1 is transformed into the sensor input in1.
As-sume there is an action with P2, the actuator output out1 is
assigned. Hence, each place whose capacity is limited to one within the SPNC corresponds to a memory bit in the TPL. The token flow is then simulated by setting and resetting these mem-ory bits. Thus, each place within the SPNC has at least one associated memory bit in the TPL. The sensor state within the SPNC corresponds to a sensor input contact in the TPL. To sim-ulate the firing of a transition, if the memory bits associated with input places are set and the sensor inputs of the transition yield “true”, the memory bits at the input places are reset and the
memory bits at the output places are set simultaneously. More-over, the actions and delays within the SPNC are assigned to appropriate memory bits within the TPL by using the actuator outputs and delay timers, respectively. By using the Modified TPL, the I/O ports for the sensor readings and actuator out-puts are assigned and the layout for implementation in LLD can be completed. The Modified TPL bridges the gap between SPNC and LLD and provides a simple way of developing PLC controllers.
3.5 Implementation stage: LLD
In order to convert the TPL model into LLD code for real-time implementation, a direct mapping is used from the TPL to the LLD by maintaining the enabling and firing rules at this stage. The transformation from TPL model into LLD format is based on the following steps:
1. Initial condition setting: the token in the SPNC is mapped to the corresponding internal relay with the SET command. 2. For each transition, the input memory is mapped to a
condi-tional contact and an internal relay with the RST command, and the output memory is mapped to an internal relay with the SET command.
3. The sensor input is mapped to a conditional contact for the associated transition.
4. The output relay is assigned to send the command to perform the operation.
5. The delay timer is assigned to perform the delay.
An example is shown in Fig. 7. For transition T1, the input
memory M1 is mapped to a conditional contact and an internal
relay M1 with the RST command, and the output memory M2
is mapped to a internal relay M2 with the SET command. The
sensor input in1is mapped to a conditional contact X1 and the
actuator output out1 is mapped to the output relay Y1. By
inte-grating the initial condition and setting all transitions, the LLD for sequence control is thus completed.
In the proposed IDEF0/SPNC/TPL/LLD approach, the mate-rial flow diagram and the information flow diagram are obtained by using the IDEF0 technique for functional analysis and in-formation flow design. Then, the inin-formation flow diagram is transformed into the SPNC model to verify its dynamic behav-ior. Subsequently, the SPNC model is converted into a modified
Fig. 8. The transformations of the IDEF0/SPNC/TPL/LLD approach
Fig. 7. The transformation from the TPL to the LLD
TPL model for implementation layout. Finally, the IEC1131-3 LLD for implementation on the PLC controller is obtained using a direct mapping from the TPL to the LLD. Figure 8 summarizes the transformations in the proposed IDEF0/SPNC/TPL/LLD approach.
4 An application example
To demonstrate the viability of the developed approach, an appli-cation to a stamping process is provided.
4.1 System description
As shown in Fig. 9, a stamping system consists of three cylin-ders that are operated by four-port and two-way solenoid valves. Each cylinder has two normally open limit switches. For ex-ample, when the end of pusher_A contacts limit switch a0, a0 is then closed. This indicates that pusher_A is at the end of its return stoke. The whole system has 7 input sensors correspond-ing to six limit switches, one push button for startcorrespond-ing the system and six output actuators corresponding to six solenoid valves. In the stamping process, pusher_A moves the workpiece from a store onto the worktable. Then the workpiece is stamped by stamper_B and afterwards is ejected by thrower_C. Thus, the se-quence of the stamping system is A+, B+, {A−, B−}, C+, C−,
Fig. 9. The stamping system
where the plus and the minus signs mean a piston performing forward strokes and return strokes, respectively.{A−, B − } rep-resents two concurrent actions as the pistons of both pusher_A and stamper_B perform return stokes simultaneously.
4.2 Sequence controller design
Through the use of the proposed IDEF0/SPNC/TPL/LLD ap-proach, as shown in Fig. 10, the LLD code for real-time
im-Fig. 10. Design of the sequence controller using IDEF0/SPNC/TPL/LLD approach
Table 1. Notations for the stamping process
SPNC TPL LLD Description
element element element
P1 M1 M1 Ready
P2 M2, out1 M2, Y1 Holding{A}
P3 M3, out2 M3, Y2 Stamping{B}
P4 M4, out3 M4, Y3 Releasing{A}
P5 M5, out4 M5, Y4 Releasing{B}
P6 M6 M6 –
P7 M7 M7 –
P8 M8, out5 M8, Y5 Throwing{C}
P9 M9, out6 M9, Y6 Resetting{C}
T1 T1 – Push in and Hold on{A + }
T2 T2 – Stamp down{B+ }
T3 T3 – Release workpiece{A−, B− }
T4 T4 – –
T5 T5 – –
T6 T6 – Throw out{C+ }
T7 T7 – Reset{C− }
T8 T8 – Repeat{A + }
S0 in0 X0 Push button {ON}
S1 in1 X1 Sensor a1 {ON} S2 in2 X2 Sensor b1 {ON} S3 in3 X3 Sensor a0 {ON} S4 in4 X4 Sensor b0 {ON} S5 in5 X5 Sensor c1 {ON} S6 in6 X6 Sensor c0 {ON}
plementation on PLC controllers was systematically generated. First, the material flow diagram and the information flow di-agram were obtained by using the IDEF0 technique. Then, to
verify its dynamic behavior, the information flow diagram was transformed into the SPNC model. Subsequently, the SPNC model was converted into a modified TPL model for layout. Fi-nally, the LLD for implementation with PLC controllers was obtained by a direct mapping from the TPL. This LLD code is written for Mitsubishi FX2 PLCs, which meet IEC1131-3. Table 1 gives the notations used in the IDEF0/SPNC/TPL/LLD together with their descriptions.
5 Conclusions
In this paper, we have proposed a systematic IDEF0/SPNC/ TPL/LLD approach for the PLC-based sequence controller de-sign in manufacturing systems. To obtain the LLD for PLC implementation, the SPNC is defined by introducing the sen-sor states into the ordinary Petri net. This leads to meaningfully simplified process modeling. Moreover, the IDEF0 technique is employed to construct the SPNC model through the material flow diagram and information flow diagram. Starting from the basic sequential specification, the proposed approach includes IDEF0, SPNC, and TPL, and systematically leads to the stan-dard IEC1131-3 LLD for PLC implementation. An application of a stamping process is provided to demonstrate the viability of the developed approach. In the future, we plan to enrich the sequence controller with the capability of fault diagnosis, and to apply the IDEF0/SPNC/TPL/LLD approach to more compli-cated systems.
Acknowledgement This work was supported by the National Science Council, R.O.C., under Grant NSC 89-2218-E-009-034.
