Robust Nonlinear Observer for Lipschitz Nonlinear Systems Subject to Disturbances
Min-Shin Chen and Chi-Che Chen
Abstract—This note proposes a robust nonlinear observer for systems
with Lipschitz nonlinearity. The proposed nonlinear observer, whose linear part adopts the linear LTR observer design technique, has two im-portant advantages over previous designs. First, the new observer does not impose the small-Lipschitz-constant condition on the system nonlinearity, nor other structural conditions on the system dynamics as in the existing observer designs. Second, it is robust in the sense that its state estimation error decays to almost zero even in the face of large external disturbances.
Index Terms—Disturbance, Lipschitz condition, nonlinear observer,
non-linear system, robust observer.
I. INTRODUCTION
State estimation of nonlinear systems has been a research topic for decades. A survey paper on this topic can be found in [1]. In recent literature, there are mainly four different approaches to the nonlinear observer design. In the first approach [2]–[4], the nonlinear system is transformed, via a nonlinear state transformation, into a so-called ob-server normal form. This special normal form admits the design of a nonlinear observer that yields a completely linear error dynamics. Linear observer theory can then be applied to guarantee stability. How-ever, the conditions to obtain completely linearizable error dynamics are strict, and finding the required nonlinear state transformation is nontrivial.
In the second approach, the system dynamics is split into a linear part and a nonlinear part. The linear part is assumed to be observable from the system output, and the nonlinear part is locally or globally Lipschitz. The idea is first suggested in [5], and then further pursued in [6]–[8]. The design can be easily carried out by solving a Lyapunov equation [5] or a Riccati equation [7]. Reduce-order nonlinear ob-servers of this type are introduced in [9] and [10]. Unfortunately, this approach suffers from a severe limitation that the Lipschitz constant of the nonlinearity has to be small.
There are some other approaches to the nonlinear observer design that do not impose the small-Lipschitz-constant condition. These ap-proaches include the variable structure observer design [11]–[13] and the high-gain observer design [14], [15]. However, their application is limited due to strict conditions on the system dynamics. For example, in the variable structure observer design [11]–[13], the transfer function from the nonlinearity to the system output is limited to be strictly pos-itive real (SPR). In the high-gain observer design [14], the system dy-namics must be in a semitriangular form. In [15], one must assume non-singularity of a nonlinear transformation matrix, and the transformed system must have an input matrix that is also in a triangular form.
To overcome the limitations of existing observer designs, this note proposes a new nonlinear observer that imposes less restrictions, and hence has a larger application domain. The new observer design uti-lizes the linear LRT observer design technique [16], [17] to enhance the
Manuscript received January 9, 2006; revised June 7, 2006; February 12, 2007; August 27, 2007. Recommended by Associate Editor M.-Q. Xiao. This work was supported by the National Science Council of the Republic of China, Taiwan, under Grant NSC-95-2221-E-002-133.
The authors are with the Department of Mechanical Engineering, Na-tional Taiwan University, Taipei 106, Taiwan, Republic of China (e-mail: mschen@ntu.edu.tw).
Digital Object Identifier 10.1109/TAC.2007.910724 0018-9286/$25.00 © 2007 IEEE
robustness of nonlinear observer. The resultant nonlinear observer has two important advantages over conventional observers. The first advan-tage is that the new observer does not impose the small-Lipschitz-con-stant condition as in [5]–[10], nor the SPR condition as in [11]–[13], nor the structural conditions as in [14] and [15]. The only assumption re-quired by the new observer is that the transfer function from the nonlin-earity to the system output be minimum-phase [meaning that the triple (A; G1; C) in (1) has only stable zeros]. The second advantage of the proposed observer is that its performance is robust with respect to ex-ternal disturbances. The robustness issue of nonlinear observer against disturbance is rarely studied in the literature. Previous nonlinear ob-server designs [18]–[20] ensure only bounded-input bounded-state sta-bility, while the new observer in this note ensures practical stasta-bility, meaning that the new observer in this note can achieve almost zero es-timation error in the face of large disturbances.
The remainder of this note is arranged as follows. Section II presents the new nonlinear observer design for nonlinear systems that have an arbitrarily large Lipschitz constant. Section III further modifies the nonlinear observer so that its performance is robust with respect to ex-ternal disturbances. Finally, Section IV gives the conclusions.
II. NONLINEAROBSERVER
Consider the state estimation problem for a nonlinear system _x = Ax + Bu + G1f(x)
y = Cx (1)
wherex 2 Rnis the unknown system state,u 2 Rmis the control input,y 2 Rp is the measured system output, andf(x) 2 Rqis a nonlinearity satisfying the Lipschitz condition
kf(x) 0 f(^x)k kx 0 ^xk (2)
for some Lipschitz constant > 0. It is assumed that
dim(y) dim (f(x)) : (3)
Without loss of generality it is assumed in the sequel thatdim(y) = dim(f(x)); the case dim(y) > dim(f(x)) can be treated similarly by artificially expanding the dimension off(x). Further, it is assumed that(A; C) is observable, (A; G1) controllable, and the square system (A+ I; G1; C) has only stable zeros (minimum-phase), where > 0 is a design parameter to be specified later. Notice that one does not require the boundedness assumption of the control inputu.
The proposed nonlinear observer for (1) is as follows:
_^x = A^x + Bu + L(y 0 C^x) + G1f(^x); L = QCT (4) where the output injection gainL 2 Rn2pis designed as in the linear LTR observer [16], [17], withQ a positive definite matrix solved from the LQ Riccati equation
Q(A + I)T + (A + I)Q 0 QCTCQ + G1GT 1 = 0;
> 0; > 0: (5) The existence and positive definiteness of the solutionQ of the LQ Riccati equation (5) is always guaranteed [21], [22] for all design pa-rameters > 0 and > 0 if (A; C) is observable and (A; G1) con-trollable. Note that in [7], [8], and [10], their nonlinear observers use anH1Riccati equation [21] in the following form:
QAT + AQ 0 Q(CTC 0 2)Q + I = 0
which contains the Lipschitz constant . In order for this H1Riccati equation to have a positive definite solution matrix, the Lipschitz con-stant is constrained to be small. In contrast, this note uses the LQ Riccati equation (5), which is independent.
Note that the solution matrixQ 2 Rn2ndepends on the design parameter in (5). The relationship between Q() and satisfies the following theorem.
Theorem 1 [16], [23]: If the system(A + I; G1; C) is
minimum-phase,C and G1are full rank, andrank(CT) = rank(G1), the solu-tionQ() of the observer Riccati equation (5) satisfies
lim !1
Q() = 0:
The state estimation error~x = x 0 ^x resulting from the above non-linear observer satisfies
_~x = (A 0 LC)~x + G1(f(x) 0 f(^x)) : (6) The goal of this section is to prove that even for large Lipschitz constant in (2), the error dynamics (6) is globally exponentially stable if in (5) is sufficiently large. This is the purpose of the theorem shown here.
Theorem 2: Consider the nonlinear system (1) withC and G1both full rank,rank(CT) = rank(G1), and (A + I; G1; C) minimum-phase. For whatever large Lipschitz constant in (2), if the design parameter > 0 in the Riccati equation (5) is sufficiently large, the state estimate^x of the nonlinear observer (4) approaches the true state x exponentially fast.
Proof: Define a Lyapunov functionV = ~xTQ01~x, where Q > 0
is from the observer Riccati equation (5), and~x as in (6). The change rate ofV along the trajectory (6) satisfies
_V 0 2 V 0 k~yk20 GT 1Q01~x 2 + 2 kf(x) 0 f(^x)k 1 GT 1Q01~x 0 2 V 0 k~yk20 GT1Q01~x 2 + 2 k~xk 1 GT 1Q01~x
where~y = C~x and the Lipschitz condition (2) was used to obtain the second inequality. Note that the maximum of the last two terms in the last equation occurs whenkGT1Q01~xk = k~xk=, with the maximum value being 2k~xk2=. Hence
_V 02 V 0 k~yk2+ 2k~xk2 02 V + 2k~xk2 : Using V (Q01)k~xk2= k~xk2=(Q) (7) one obtains _V 0 2 0 2(Q) V: (8)
According to Theorem 1,(Q)= approaches zero as the observer de-sign parameter approaches infinity. Hence, given any Lipschitz con-stant , there always exists a sufficiently large design parameter such that the number in the square bracket in (8) is positive. This implies that V (t) and, hence, ~x(t) decay to zero exponentially. One thus proves that the error dynamics (6) is globally exponentially stable. End of proof.
Remark 1: The proposed nonlinear observer (4) has two design
pa-rameters: and in (5). As explained in the proof of Theorem 2, > 0 must be sufficiently large to ensure the observer stability, and > 0 is to specify the estimation error convergence rate.
Fig. 1. (Q)= versus .
Remark 2: Equation (8) mandates that the observer design
param-eter must satisfy
(Q())
< 2 2 (9)
to ensure the observer stability. If the Lipschitz constant is known, and has been chosen, one can determine a stabilizing by referring to a figure that depicts the value of(Q)= versus . Fig. 1 shows such a figure for the system(A; [G1; G2]; C) in the simulation example in the next section.
Remark 3: Note that if the observer design parameter is chosen
too large, the proposed observer becomes high-gain. A disadvantage of high-gain observers is the peaking phenomenon [24], in which the estimated state^x(t) peaks to extremely large values during the very initial period of the observation process. One way to relieve the peaking phenomenon is to stepwisely schedule the design parameter(t) = i,t 2 [tk; tk+1], where ijumps within a finite time from 1 to the designed value requested by (9). See the simulation example in the next section.
III. ROBUSTNONLINEAROBSERVER
In practical applications, it may frequently happen that the nonlinear system (1) is subject to unknown external disturbances. It is therefore important to construct the nonlinear observer such that its performance is robust against external disturbances, and this will be the subject of this section.
Consider a nonlinear system subject to bounded disturbances _x = Ax + Bu + G1f(x) + G2d
y = Cx (10)
where all symbols are as defined in (1), the nonlinearityf(x) satisfies the Lipschitz condition (2), andd 2 Rrrepresents a bounded external disturbance
kd(t)k D: (11)
Note thatG1 6= G2; that is, the disturbanced enters the system equa-tion in a direcequa-tion different from that of the nonlinearityf(x). Further, it is assumed that(A; C) is observable, and (A; [G1; G2]) controllable. The “robust” nonlinear observer design is more difficult than the nonlinear observer design treated in the previous section. However, it
will be shown that if the number of output sensors is sufficient in the sense that
dim(y) dim (f(x)) + dim(d) (12)
then the design of a robust nonlinear observer is achievable. For sim-plicity, it will be assumed in the sequel thatdim(y) = dim(f(x)) + dim(d). The case dim(y) > dim(f(x))+ dim(d) can be treated sim-ilarly by artificially expanding the dimension ofd or f(x).
A robust nonlinear observer for the system (10) that can cope with both the nonlinearity and the disturbance is proposed as follows:
_^x = A^x + Bu + L(y 0 C^x) + G1f(^x) (13) where the output injection gainL = QCT 2 Rn2p, but the positive definite matrixQ 2 Rn2nis now obtained from a modified Riccati equation
Q(A + I)T+ (A + I)Q 0 QCTCQ + [G1; G2][G1; G2]T = 0; > 0; > 0: (14) Note that the existence of a positive definite solution matrixQ > 0 is guaranteed [21], [22] when(A; C)is observable, and (A; [G1; G2]) controllable.
The following theorem shows that the above robust nonlinear ob-server (13) guarantees that the estimation errorx 0 ^x decays to almost zero even in the face of large disturbanced.
Theorem 3: Consider the nonlinear system (10) subject to a bounded
disturbanced, and the assumptions that C and [G1; G2] both full rank, rank(CT) = rank([G1; G2]), and (A + I; [G1; G2]; C) minimum-phase. For whatever large Lipschitz constant , and whatever large dis-turbanced, the robust nonlinear observer (13) guarantees that the state estimation error~x = x 0 ^x will eventually approach a small residual set containing the origin, with the size of the residual set approaching zero as the design parameter in (14) approaches infinity.
Proof: From the assumptionsrank(CT) = rank([G1; G2]) and
(A + I; [G1; G2]; C) minimum-phase, one can quote Theorem 1 to conclude that the solutionQ() of the modified Riccati equation (14) still satisfies
lim !1
Q()
= 0: (15)
With the unknown disturbanced, the state estimation error ~x = x0^x resulting from the proposed robust nonlinear observer (13) obeys the dynamics
_~x = (A 0 LC)~x + [G1; G2] f(x) 0 f(^x)d (16) where the last term satisfies the bound
f(x) 0 f(^x)
d kf(x) 0 f(^x)k + kdk
k~xk + D (17)
in which one has used (2) and (11) to obtain the second inequality. Choose a Lyapunov functionV = ~xTQ01~x, where Q is from (14). Checking the change rate ofV along the error dynamics (16) gives
_V 02 V 0 k~yk20 kGTQ01~xk2+ 2( k~xk+D)kGTQ01~xk whereG = [G1; G2] and (17) is used to derive the inequality. Note that the maximum of the last two terms in the above equation occurs
whenkGTQ01~xk = ( k~xk + D)=, with the maximum value being ( k~xk + D)2=. Hence
_V 0 2 V 0 k~yk2+ ( k~xk + D)2 0 V 0 V 0 ( k~xk + D) 2 :
From the last inequality, one can say that _V < 0 as long as V > ( k~xk + D)2=( ). Therefore, asymptotically one has
lim
t!1V (t) ( k~xk + D) 2=( ) which implies, using (7),
lim
t!1k~x(t)k (Q)
( k~xk + D) : Rearranging the equation gives
lim
t!1 1 0 (Q) k~x(t)k D (Q) :
The property (15) ensures that given any Lipschitz constant , there always exists a sufficiently large observer design parameter such that the number in the parenthesis in the above equation is positive. Hence, one can write
lim
t!1k~x(t)k
D (Q) 1 0 (Q)
: (18)
The above inequality together with the property (15) imply that given any bounded Lipschitz constant and disturbance upper bound D, k~xk will eventually become arbitrarily small as long as is sufficiently large. End of proof.
The last theorem in this note given below will discuss the special case when the disturbanced enters the state equation (10) in the same direction as the nonlinearityf(x); that is, the case G1 = G2. For this special case, the requirement on the sensor number can be relaxed from (12) to (3); hence, one needs onlydim(y) dim(f(x)). The following theorem shows that whenG1= G2in the nonlinear system (10), the nonlinear observer (4) in the previous section, which uses the observer Riccati equation (5), can effectively cope with the disturbance.
Theorem 4: Consider the nonlinear system (10) subject to a bounded
disturbanced, and the assumptions that G1= G2,C and G1both full rank,rank(CT) = rank(G1), and (A + I; G1; C) minimum-phase. For whatever large Lipschitz constant , and whatever large distur-bance d, the nonlinear observer (4) in the previous section guaran-tees that the state estimation error~x will eventually approach a small residual set containing the origin, with the size of the residual set ap-proaching zero as the design parameter in (5) approaches infinity.
Proof: The proof is similar to that of Theorem 3, and is omitted. Remark 4: Theorem 4 shows that the nonlinear observer (4) and (5)
in the previous section is robust against disturbance that comes into the system equation in the same direction as the nonlinearity. How-ever, Theorem 3 shows that when the disturbance comes into the system equation in a direction different from that of the nonlinearity, the Ric-cati equation in the nonlinear observer must be modified according to (14) so that the disturbance’s effect on the observer can be reduced.
Remark 5: One should be aware that high gain design (using large
design parameter in the observer Riccati equation and hence large server feedback gain) does not always guarantee robustness of the ob-server if the linear part of the nonlinear system is not minimum-phase. Hence, both Theorems 3 and 4 request the minimum-phase condition.
Fig. 2. State estimation errorkxk versus time.
Example: Consider a flexible joint robot [25], whose governing
equation is as in (10) with A = 0 1 0 0 01 0 1 0 0 0 0 1 1 0 1 01 ; B = G2 = 0 0 0 1 G1= 0 1 0 0 ; CT = 0 1 0 0 1 0 0 0
the controlu(t) = 0, the disturbance d(t) = 2, and nonlinearity f(x) = 010sin(x1). Note that the nonlinearity f(x) is globally Lips-chitz, and the large Lipschitz constant = 10 implies a long or heavy robot arm. The initial conditions arexT(0) = [1; 1; 1; 1] for the robot, and ^xT(0) = [01; 01; 01; 01] for the observer (13). The modified Riccati (14) has design parameters = 1, and (t) scheduled step-wisely from 1 to1012within 8 s according to the formula(t) = 103k, t 2 [2k; 2k + 2), k = 0; 1; 2; 3; 4.
Fig. 2 shows the state estimation errork~x(t)k versus time. The esti-mation error decays to almost zero(k~x(t)k 1003), confirming that the proposed robust nonlinear observer design is successful in the face of disturbances and large-Lipschitz-constant nonlinearity. Note that if one uses = 1012right from the beginning of observation, there will be a substantial peaking phenomenon. The proposed stepwise sched-uling of(t) has successfully avoided the peaking phenomenon.
IV. CONCLUSION
This note proposes a new robust nonlinear observer for systems sub-ject to Lipschitz nonlinearity and bounded external disturbances. The linear part of the proposed observer, like the linear LTR observer, is based on an LQ Riccati equation design. Robustness of the proposed observer is achieved by asymptotic tuning of the design parameter in the Riccati equation. It is proved that the proposed nonlinear observer ensures asymptotically an almost zero estimation error in the face of large Lipschitz nonlinearity and large external disturbances.
REFERENCES
[1] E. A. Misawa and J. K. Hedrick, “Nonlinear observers—A state-of-the-art survey,” J. Dyn. Syst., Meaure., Control, vol. 111, pp. 344–352, 1989.
[2] A. J. Krener and A. Isidori, “Linearization by output injection and non-linear observers,” Syst. Control Lett., vol. 3, pp. 47–52, 1983. [3] D. Bestle and M. Zeitz, “Canonical form observer design for nonlinear
[4] A. J. Krener and W. Respondek, “Nonlinear observer with linearizable error dynamics,” SIAM J. Control Optim., vol. 23, pp. 197–216, 1985. [5] F. E. Thau, “Observing the state of nonlinear dynamic systems,” Int. J.
Control, vol. 17, pp. 471–479, 1973.
[6] S. R. Kou, D. L. Elliott, and T. J. Tarn, “Exponential observers for nonlinear dynamic systems,” Inf. Control, vol. 29, pp. 204–216, 1975. [7] S. Raghavan, “Observers and compensators for nonlinear systems, with application to flexible joint orbots,” Ph.D. dissertation, Univ. of Calif., Berkeley, 1992.
[8] R. Rajamani, “Observers for Lipschitz nonlinear systems,” IEEE Trans. Autom. Control, vol. 43, pp. 397–401, 1998.
[9] G. Besancon and H. Hammouri, “On uniform observation of nonuni-formly observable systems,” Syst. Control Lett., vol. 29, pp. 9–19, 1996. [10] F. Zhu and Z. Han, “A note on observers for Lipschitz nonlinear
sys-tems,” IEEE Trans. Autom. Control, vol. 47, pp. 1751–1754, 2002. [11] B. L. Walcott and S. H. Zak, “State observation of nonlinear
uncer-tain dynamical systems,” IEEE Trans. Autom. Control, vol. 32, pp. 166–170, 1987.
[12] S. H. Zak, “On the stabilization and observation of nonlinear/uncer-tain dynamical systems,” IEEE Trans. Autom. Control, vol. 35, pp. 604–607, 1990.
[13] D. M. Dawson, Z. Qu, and J. C. Carroll, “On state observation and output feedback problems for nonlinear uncertain dynamic sytems,” Syst. Control Lett., vol. 18, pp. 217–222, 1992.
[14] K. K. Busawon and M. Saif, “A state observer for nonlinear systems,” IEEE Trans. Autom. Control, vol. 44, pp. 2098–2103, 1999. [15] J. P. Gauthier, H. Hammouri, and S. Othman, “A simple observer for
nonlinear systems, applications to bioreactors,” IEEE Trans. Automat. Control, vol. 37, pp. 875–880, 1992.
[16] J. C. Doyle and G. Stein, “Robustness with observers,” IEEE Trans. Autom. Control, vol. AC-24, pp. 607–611, 1979.
[17] G. Stein and M. Athans, “The LQG/LTR procedure for multivariable feedback control design,” IEEE Trans. Autom. Control, vol. 32, pp. 105–113, 1987.
[18] M. Arcak and P. Kokotovic, “Nonlinear observers: A circle criterion design and robustness analysis,” Automatica, vol. 37, pp. 885–892, 2003.
[19] H. Shim, J. H. Seo, and A. R. Teel, “Nonlinear observer design via passivation of error dynamics,” Automatica, vol. 39, pp. 1923–1930, 2001.
[20] A. Alessandri, “Observer design for nonlinear systems by using input-to-state stability,” in Proc. IEEE Conf. Decision Control, 2004, pp. 3892–3897.
[21] A. Saberi, P. Sannuti, and B. M. Chen,H Optimal Control. Engle-wood Cliffs, NJ: Prentice-Hall, 1995, ch. 4, Theorem 4.1.2. [22] F. L. Lewis, Applied Optimal Control and Estimation. Englewood
Cliffs, NJ: Prentice-Hall, 1992, ch. 3, Theorem 2.
[23] H. Kwakernaak and R. Sivan, Linear Optimal Control Systems. New York: Wiley, 1972, ch. 3, Theorem 3.14.
[24] H. K. Khalil, Nonlinear Systems. Upper Saddle River, NJ: Prentice-Hall, 2000, ch. 14.5.
[25] R. Marino and P. Tomei, Nonlinear Control Design. Upper Saddle River, NJ: Prentice-Hall, 1995, p. 27.
