An Image Annotation Approach Using Location References to Enhance Geographic Knowledge Discovery

(1)

An image annotation approach using location references to enhance

geographic knowledge discovery

Chung-Hong Lee

a,⇑

_{, Hsin-Chang Yang}

b

_{, Shih-Hao Wang}

a

Dept. of Electrical Engineering, National Kaohsiung University of Applied Sciences, Taiwan

b

Dept. of Information Management, National University of Kaohsiung, Taiwan

a r t i c l e

i n f o

Keywords: Image annotation Image classiﬁcation Image processing Text mining

a b s t r a c t

With the continuously increasing needs of location information for users around the world, applications of geospatial information have gained a lot of attention in both research and commercial organizations. Extraction of semantics from the image content for geospatial information seeking and knowledge dis-covery has been thus becoming a critical process. Unfortunately, the available geographic images may be blurred, either too light or too dark. It is therefore often hard to extract geographic features directly from images. In this paper, we describe our developed methods in applying local scale-invariant features and bag-of-keypoints techniques to annotating images, in order to carry out image categorization and geographic knowledge discovery tasks. First, local scale-invariant features are extracted from geographic images as representative geographic features. Subsequently, the bag-of-keypoints methods are used to construct a visual vocabulary and generate feature vectors to support image categorization and annota-tion. The annotated images are classiﬁed by using geographic nouns. The experimental results show that the proposed approach is sensible and can effectively enhance the tasks of geographic knowledge discovery.

1. Introduction

Location information provided on the web is a valuable contri-bution and useful resource for a multitude of applications and is becoming an important element of contents in web search. Recently several studies have reported that 5–20% of all user que-ries express a geographic information need, and an estimate of up to 20% of all web pages contain location references (Himmelstein, 2005; Kamvar & Baluja, 2006; McCurley, 2001; Sanderson & Kohler, 2004). In particular, a huge of geographic information are utilized and generated by various technologies, such as loca-tion-based services (LBS) and location-aware technologies (LAT), and are represented in the forms of images or texts on the inter-net. Under such a circumstance, geospatial search engines there-fore have to identify location-relevant content of web pages and analyze their semantics of location and related images. Going fur-ther, geoparsing approaches can be used to evaluate its location relevance.

Geographic knowledge discovery (GKD) is emerging as a novel and broad application research topic, covering ﬁelds of geospatial information science, environment management, national security,

and applications of location-based services, etc. Examples of geo-spatial data include data that describe the evolution of natural phe-nomena, earth science data that describe spatiotemporal phenomena in the atmosphere, or data that describe the location of individuals in the geographic space as a function of time. Geographic data represent an embedding to the Euclidean space, and therefore give distance information and topological informa-tion. In essence, the domain of the attributes is normally the real numbers. Also, geographic data sets can record additional informa-tion, such as environmental parameters and location-based tour-ism information, therefore defining high dimensional spaces of attributes that are highly correlated. As a result, geographic data mining methods offer solutions for finding and describing patterns in the geospatial data collections, which was previously unknown and is not explicitly stored in the database. In particular, it is worth mentioning that, the geographic knowledge discovery concerns not only the exploration and analysis of professional spatial data sets but also the methods in finding more general knowledge related to specific geographical locations.

The view is taken, therefore in this work the application sce-nario for the attempted solution is a location-based information system for mobile or pedestrian users. We aim to identify loca-tion references in the forms of texts and images at a ﬁne granu-larity level of individual buildings or tourist attraction that is directly applicable to a mobile user or retrieval and analysis tasks
