Inhibitory mechanisms of low concentrations of oxidized low-density

lipoprotein on platelet aggregation

Duen-Suey Chou

, Chih-Hsiang Chan

, George Hsiao

, Ming-Yi Shen

, Yan-Jyu Tsai

,

Tzeng-Fu Chen

& Joen-Rong Sheu

*

1

Graduate Institute of Medical Sciences, Taipei Medical University, Taipei, Taiwan, ROC; 2Graduate Institute of Pharmacology, Taipei Medical University, Taipei, Taiwan, ROC;3Division of Cardiology, Min-Sheng Hospital, Taoyuan, Taiwan, ROC

Received 12 April 2005; accepted 11 October 2005 Ó 2005 National Science Council, Taipei

Key words: cyclic AMP, Na+/H+ exchanger, oxLDL, protein kinase C, vasodilator-stimulated phos-phoprotein

Summary

The intracellular mechanisms underlying oxidized low-density lipoprotein (oxLDL)-signaling pathways in platelets are not yet completely understood. Therefore, the aim of this study was to further examine the effects of oxLDL in prevention of platelet aggregation. In this study, oxLDL concentration-dependently (40–120 lg/ml) inhibited platelet aggregation in human platelet-rich plasma stimulated by agonists. Moreover, oxLDL (40 and 80 lg/ml) markedly decreased the fluorescence intensity of platelet membranes tagged with diphenylhexatriene. Rapid phosphorylation of a protein of Mr 47,000 (P47), a marker of protein kinase C activation, was triggered by PDBu (150 nM). This phosphorylation was markedly inhibited by oxLDL (40 and 80 lg/ml) in phosphorus-32-labeled platelets. In addition, oxLDL (40 and 80 lg/ml) markedly increased levels of cyclic AMP and cyclic AMP-induced vasodilator-stimulated phosphoprotein (VASP) Ser157phosphorylation. The thrombin-evoked increase in pHi was inhibited in the presence of oxLDL (40 and 80 lg/ml). These results indicate that the antiplatelet activity of oxLDL may involve the following pathways. (1) oxLDL may initially induce conformational changes in platelet membranes, leading to inhibition of the activation of protein kinase C, followed by inhibition of P47 protein phosphorylation, and intracellular Ca2+mobilization. (2) oxLDL also activated formation of cyclic AMP and cyclic AMP-induced VASP Ser157 phosphorylation, resulting in inhibition of the Na+/H+ ex-changer; this leads to reduced intracellular Ca2+ mobilization, and ultimately to inhibition of platelet aggregation. This study further provides new insights concerning the effects of low concentrations of oxLDL on platelet aggregation.

Introduction

Plasma lipoproteins, particularly low-density lipo-protein (LDL), are the source of the lipid that accumulates in atherosclerotic lesions [1]. Oxida-tive modification dramatically changes the biological

properties of LDL, converting it into a form that is both atherogenic and prothrombotic [1]. The oxidation theory of atherosclerosis proposes that formation of oxidized low-density lipoprotein (oxLDL) in the subendothelial space of artery walls represents a causative event for atherogen-esis. Evidence of oxidized lipoproteins has been detected in atherosclerotic lesions [2], and oxLDL exhibits various proatherogenic activities [3].

*To whom correspondence should be addressed. Fax +886-2-27390450, E-mail: [email protected]

Journal of Biomedical Science (2006) 13:333–343 ₃₃₃

Platelets interact with plasma lipoprotein as well as with arterial wall macrophages that play an important role in atherogenesis [4]. Plasma lipo-proteins have been shown to affect platelet activity in vitroand in vivo. The susceptibility of platelets to aggregation in vitro upon stimulation by aggre-gating agents, such as ADP and collagen, has been shown to increase in most, but not all, studies of platelet-rich plasma (PRP) from hypercholesterol-emic individuals [5].

Oxidation of LDL may be one of the main factors involved in the initial development of atherosclerotic lesions [2]. LDL can be oxidized within the arterial wall by macrophages; this process, which favors accumulation of LDL in the intima of the arterial wall, is thought to be a possible explanation for the progression of arte-riosclerotic lesions. Endothelial cells also induce oxLDL formation, but in turn may be damaged by oxLDL [2]. LDL has been suggested to have platelet-activating properties such as decreasing the threshold for stimulation by aggregation agents and inducing platelet aggregation [6, 7]. However, evidence regarding the induction of platelet activation by LDL is controversial. Sev-eral studies have reported inhibition of agonist-induced platelet aggregation by native LDL (nLDL) [8, 9]. In others, platelet-activating effects of either lower nLDL (10–50 lg/ml) [10] or higher concentrations of LDL (more than 1–2 mg/ml) have been described [6]. Furthermore, platelet-activating activity was found to reside in oxLDL rather than in nLDL [11]. oxLDL plays an important role in the pathogenesis of atheroscle-rosis; it has also been reported to enhance platelet activation in some [7, 12], but not all studies [13, 14]. Vlasova et al. [14] found that highly oxidized LDL not only failed to activate platelet aggrega-tion, but also inhibited ADP-induced aggregation. However, they also found that mildly oxidized LDL diminished the time-dependent decrease in platelet aggregability in platelet-rich plasma [15]. Such discrepancies among reported oxLDL-plate-let interactions may depend on methodological variations in the isolation, oxidization, and dosage of lipoproteins employed, which might result in non-homogeneous oxidation [9].

In our previous studies, we found that oxLDL (LDL oxidized with copper), at lower concentra-tions (40–80 lg/ml), significantly inhibited ago-nist-induced platelet aggregation [16]. In that

study, we found that the 12 h- and 24 h-oxLDL, but not nLDL, concentration-dependently (20– 100 lg/ml) inhibited platelet aggregation stimu-lated by collagen (1 lg/ml) and AA (60 lM) in human platelet suspensions. The IC50values of the

12 h- and 24 h-oxLDL for platelet aggregation induced by collagen were estimated to be about 46.3±1.1 and 55.2±1.0 lg/ml, respectively [16]. We suggested that the inhibitory effect of oxLDL may induce radical–radical termination reactions by oxLDL-derived lipid radical interactions with free radicals (such as hydroxyl radicals) released from activated platelets, with a resultant lowering of intracellular Ca2+ mobilization, followed by inhibition of thromboxane A2formation, thereby

leading to increased cyclic AMP formation, and finally inhibited platelet aggregation [16]. In that study, we partially resolved the mechanisms of oxLDL on platelet aggregation, however detailed intracellular mechanisms underlying oxLDL-platelet interaction are still not yet completely understood. We therefore further examined the effect of oxLDL in human platelets, and utilized the findings to characterize the mechanisms in-volved in oxLDL-platelet interactions.

Materials and methods Materials

Collagen (type I, bovine Achilles tendon), arachi-donic acid, prostaglandin E1 (PGE1), nigericin,

sodium citrate, phorbol-12, 13-dibutyrate (PDBu), apyrase, diphenylhexatriene (DPH), and heparin were purchased from Sigma Chem. (St. Louis, MO). Fura 2-AM, BCECF-AM, and fluorescein isothiocyanate (FITC) were purchased from Molecular Probe (Eugene, OR). Trimeresurus flavoviridis venom was purchased from Latoxan (Rosans, France).

Preparation of human platelet suspensions

Human platelet suspensions were prepared as previously described [17]. In this study, human volunteers provided informed consent. In brief, blood was collected from healthy human volun-teers who had taken no medicine during the preceding 2 weeks, and was mixed with acid/ citrate/glucose. After centrifugation at 120
g 334

for 10 min, the supernatant (platelet-rich plasma; PRP) was supplemented with PGE1(0.5 lM) and

heparin (6.4 IU/ml), then incubated for 10 min at 30°C and centrifuged at 500
g for 10 min. The washed platelets were finally suspended in Ty-rode’s solution containing bovine serum albumin (BSA) (3.5 mg/ml) and adjusted to a concentration of 4.5
108

platelets/ml. The final concentration of Ca2+in Tyrode’s solution was 1 mM.

Isolation of human plasma LDL

Human LDL (at a density of 1.109–1.063) was isolated from fresh plasma of fasted normolipi-demic human volunteers and collected in EDTA (2 mM) by sequential density gradient ultracen-trifugation as described by Dousset et al. [18]. In brief, the plasma density was adjusted to 1.02 g/ml using a NaCl–KBr solution for immediate separa-tion of very low density lipoproteins (VLDLs) and intermediate-density lipoproteins (IDLs), and then adjusted to 1.063 g/ml for separation of LDL. The LDL was further purified by resuspension in the appropriate NaCl–KBr solution (1.063 g/ml) and ultracentrifuged. The LDL was then dialyzed for 24 h at 4°C against three changes of nitrogen gas with 0.02 M Tris buffer in order to remove the EDTA and KBr. After dialysis, LDL was stored for not more than 7 days under nitrogen at 4°C in the dark. Total protein concentration was mea-sured by the Lowry method using BSA as the standard [18].

Oxidation of LDL

After adjustment of the LDL concentration to 0.5 mg/ml (expressed as the total LDL concentra-tion), lipoprotein preparations were dialyzed against 100 volumes of 10 mM sodium phosphate buffer (containing 150 mM NaCl, pH 7.4) for 18 h at 4°C in the dark. Oxidation was initiated by addition of CuSO4(5 lM) for 24 h at 37°C, and

was stopped after the addition of EDTA (20 lM). Before the functional studies, oxLDL was filtered through a Sephadex PD-10 column (Pharmacia) in order to remove the EDTA and copper, and was reconcentrated at 4°C using Centricon 3000 filters (Amicon, Bedford, MA) according to the manu-facturer’s instructions. Oxidation was confirmed by the thiobarbituric acid-reactive substance (TBARS) assay [19]. Tetramethoxypropane was

used as a standard, and the results were expressed as nanomoles of malondialdehyde (MDA) equiv-alents per milligram protein of LDL. The extent of aldehyde-modified lysine in oxidized LDL (ad-justed to 0.1 mg LDL protein/ml) was monitored by determining the fluorescence intensity (excita-tion at 350 nm and emission at 420 nm) [20]. The oxLDL was used in all of the functional studies within 48 h of preparation.

Platelet aggregation

The turbidimetric method was applied to measure platelet aggregation [17], using a Lumi-Aggregometer (Payton, Canada). Platelet-rich plasma (PRP; 4.5
108 platelets/ml, 0.4 ml) was prewarmed to 37°C for 2 min in a silicone-treated glass cuvette. oxLDL (40–120 lg/ml) was added 3 min before the addition of agonists. The reaction was allowed to proceed for at least 6 min, and the extent of aggregation was expressed in light-transmission units.

Analysis of the platelet surface glycoprotein IIb/IIIa complex by flow cytometry

Triflavin, a specific fibrinogen receptor (glycopro-tein IIb/IIIa complex; aIIbb3 integrin) antagonist, was prepared as previously described [21]. Fluo-rescence-conjugated triflavin was also prepared as previously described [21]. The final concentration of FITC-conjugated triflavin was adjusted to 1 mg/ml. Aliquots of platelet suspensions (4.5
108

/ml) as described above were preincubat-ed with oxLDL (40 and 80 lg/ml) for 3 min, followed by the addition of 2 ll FITC-triflavin. The suspensions were then incubated for another 5 min, and the volume was adjusted to 1 ml/tube with Tyrode’s solution. The suspensions were then assayed for fluorescein-labeled platelets with a flow cytometer (Becton Dickinson, FACScan Syst., San Jose, CA). Data were collected from 50,000 platelets per experimental group. All exper-iments were repeated at least four times to ensure reproducibility.

Measurement of membrane fluidity by fluorescent probe

The intensity of fluorescence in human platelets was measured as described previously [22]. Briefly, 335

platelets (4.5
108/ml) were preincubated with oxLDL (40 and 80 lg/ml) for 3 min followed by the addition of 0.5 lM of a diphenylhexatriene (DPH) solution for another 6 min. The relative fluorescence intensity of platelets was measured in a fluorescence spectrophotometer (Hitachi F4500, Tokyo, Japan) at 37°C.

Determination of lactate dehydrogenase

Lactate dehydrogenase (LDH) was measured according to previously described methods [23]. Platelets (4.5
108/ml) were preincubated with oxLDL (40 and 80 lg/ml) for 30 min, followed by centrifugation at 15,000
g for 5 min. An aliquot of supernatant was incubated with phos-phate buffer containing 0.2 mgb-NADH for 20 min. Thereafter, 100 ll of pyruvate solution was added, and the absorbance wavelength was read at 334 nm using a UV-visible recording spectrophotometer (UV-160; Shimazu, Kyoto, Japan). A maximal value of LDH was constructed from sonicated platelets.

Measurement of Protein Kinase C (PKC) activation

Washed human platelets (2
109/ml) were incu-bated for 60 min at 37°C with phosphorus-32 (0.5 mCi/ml). Platelet suspensions were next washed twice with Tris–saline buffer. The [32 P]-labeled platelets were preincubated with oxLDL (40 and 80 lg/ml) in an aggregometer at 37°C for 3 min, then PDBu (150 nM) was added for 1 min to trigger PKC activation. Activation was termi-nated by the addition of Laemmli sample buffer, and analyzed by electrophoresis (12.5%; wt/vol) as described previously [24]. The gels were dried, and the relative intensities of the radioactive bands were analyzed using a Bio-imaging analyzer system (FAL2000, Fuji, Tokyo, Japan), and expressed as PSL/mm2(PSL, photostimulated luminescence).

Western blot analysis of vasodilator-stimulated phosphoprotein (VASP) phosphorylation

The method of Li et al. [25] was followed. In brief, platelet lysates were analyzed by SDS-PAGE gel (10%) and electrotransferred to PVDF mem-branes. Membranes were blocked with 5% nonfat dry milk in Tris

(tris(hydroxymethyl)-aminometh-ane)-buffered saline (TBS, pH7.5), incubated with the monoclonal antibody 5C6 (CALBIOCHEM), specific for the phosphorylated Ser157site of VASP (0.1 lg/ml). After three washes in TBS containing 0.05% Tween 20, the membrane was incubated with peroxidase-conjugated goat anti-mouse IgG (Amersham) for 2 h. The band with peroxidase activity was detected by enhanced chemilumines-cence detection reagents (ECL+ system; Amer-sham). Densitometric analysis of specific bands was performed with a Photo-Print Digital Imaging System (IP-008-SD) with analytical software (Bio-1Dlight, V 2000).

Platelet pHi measurement

Platelet pHi was measured with the fluorescent probe, BCECF-AM, according to a previously described method [26]. Washed platelets were incubated with 5 lM BCECF-AM at 37 °C for 30 min in a Hepes-buffered solution (HBS, pH 7.4) and then centrifuged at 450
g for 8 min. Washed pellets were finally suspended in buffer and adjusted to 4.5
108/ml. Leukocyte contamination was less than 0.01%. Aliquots of this platelet suspension (50 ll) were transferred to a cuvette containing 2 ml HBS in a dual-excitation wavelength spectrofluorometer (CAF 110, Jasco, Japan). Fluorescence signals for BCECF-AM were recorded at 430- and 490-nm excitation wave-lengths with an emission wavelength of 530 nm (5-nm slit). The background fluorescence of platelets was subtracted from each reading. Calibration was carried out after diluting the BCECF-loaded platelets in a high-K+ buffer (120 mM KCl, 30 mM NaCl, 1 mM MgSO4, and 5 mM glucose)

in the presence of nigericin (0.2 mg/ml), as described by Horne et al. [27]. In all experiments, platelets were stimulated by thrombin (1 U/ml) to trigger the Na+/H+exchanger.

Statistical analysis

Experimental results are expressed as the mean ± SEM and are accompanied by the num-ber of observations. Data were assessed using analysis of variance (ANOVA). If this analysis indicated significant differences among the group means, then each group was compared using the Newman-Keuls method. A P value of < 0.05 was considered statistically significant.

Results

Effect of OxLDL on platelet aggregation in platelet-rich plasma

The oxLDL preparation was oxidized and con-centrated to contain 51.4±1.8 nmol of MDA/mg protein. The extent of aldehyde-modified lysine in oxLDL was 13.1±1.4. In our previous study [16], we demonstrated that oxLDL, but not native LDL

(nLDL), concentration-dependently (20–100 lg/ ml) inhibited platelet aggregation stimulated by collagen (1 lg/ml) and arachidonic acid (60 lM) in washed human platelets [16]. The IC50value of

the oxLDL for platelet aggregation induced by collagen was estimated to be 55.2±1.0 lg/ml [16]. In this study, we further examined whether oxLDL also exhibits a similar inhibitory activity in PRP. As shown in Figure 1, oxLDL (40–120 lg/ml) concentration-dependently inhibited platelet

( l , r) p gg g p

Figure 1.Effect of oxLDL in agonists-induced platelet aggregation in human platelet-rich plasma. (a) Tracing curves of oxLDL on collagen (1 lg/ml)-induced aggregation and (b) concentration-inhibition curves of oxLDL on collagen (1 lg/ml,)-, and arachi-donic acid (60 lM,r)-induced platelet aggregation in human platelet-rich plasma (PRP). Platelets were preincubated with oxLDL (40–120 lg/ml) for 3 min, followed by the addition of collagen and arachidonic acid to trigger platelet aggregation. Data are pre-sented as a percentage of the control (means ± SEM, n=4).

aggregation stimulated by collagen (1 lg/ml) and arachidonic acid (60 lM) in human PRP. The IC50

value for platelet aggregation stimulated by colla-gen in PRP was about 83.2±9.5 lg/ml (Fig-ure 1b), a little higher than that of the IC50 value

obtained in washed platelets [16], indicating that oxLDL seems to be bound by plasma protein, thus lowers its antiplatelet activity. In addition, the solvent control (Tyrode’s solution) did not signif-icantly affect the platelet aggregation stimulated by collagen (1 lg/ml) in PRP (data not shown). In the following experiments, we used collagen as an agonist to further explore its inhibitory mecha-nisms on platelet aggregation.

Effect of OxLDL on collagen-induced

conformational change of the glycoprotein IIb/IIIa complex in human platelet

Triflavin is an Arg–Gly–Asp-containing antiplat-elet peptide purified from Trimeresurus flavoviridis snake venom [21]. Triflavin inhibits platelet aggre-gation through direct interference with fibrinogen binding to the glycoprotein IIb/IIIa complex (aIIbb3 integrin) [28]. There is now a multitude of evidence suggesting that the binding of fibrinogen to the glycoprotein IIb/IIIa complex is the final common pathway for agonist-induced platelet aggregation. Therefore, we decided to further evaluate whether or not oxLDL binds directly to the platelet glycoprotein IIb/IIIa complex, leading to inhibition of platelet aggregation induced by agonists.

In this study, the relative intensity of fluores-cence of FITC-triflavin (2 lg/ml) bound directly to collagen (1 lg/ml)-activated platelets was about 321.0±9.6 (Figure 2a), and it was markedly reduced in the presence of 5 mM EDTA (negative control; 77.6±2.6) (Figure 2b). oxLDL (40 and 80 lg/ml) did not significantly inhibit FITC-trifla-vin binding to the glycoprotein IIb/IIIa complex in platelet suspensions (Figure 2c, d), indicating that the mechanism of oxLDL’s inhibitory effect on platelet aggregation does not involve binding to the glycoprotein IIb/IIIa complex.

Effect of OxLDL on platelet membrane fluidity Platelet membrane fluidity was measured in DPH-labeled human platelets. Measurements using the fluorescent probe technique demonstrated that

oxLDL was capable of direct interaction with platelet membranes (Figure 3). Addition of ox-LDL (40 and 80 lg/ml) to the platelet prepara-tions resulted in a concentration-dependent decrease in the DPH-relative fluorescence inten-sity. However, native LDL (nLDL) (80 lg/ml) did not significantly affect the platelet membrane fluidity (data not shown). This result implies that the inhibitory effect of oxLDL on platelet aggre-gation may be due, at least partly, to the results of its effects on platelet membrane fluidity.

Effect of OxLDL on PDBu-stimulated phosphorylation of the 47-kDa protein

Stimulation of platelets with a number of different agonists, and PDBu in particular, induces activa-tion of PKC, which then phosphorylates proteins of Mr 40,000–47,000 in addition to other proteins [29]. In this study, phosphorylation experiments were performed to examine the role of oxLDL in the activation of PKC in human platelets. When PDBu (150 nM) was added to human platelets prelabeled with32PO4for 2 min, a protein with an

apparent Mr of 47,000 (P47) was predominately phosphorylated as compared with resting platelets

p

Figure 2. Flow cytometric analysis of FITC-triflavin binding to human platelets in the absence or presence of oxLDL. (a) The solid line represents the fluorescence profiles of FITC-tri-flavin (2 lg/ml) in the absence of oxLDL as a positive con-trol; (b) in the presence of EDTA (5 mM) as the negative control; or in the presence of oxLDL (c) (40 lg/ml) and (d) (80 lg/ml). Profiles are representative examples of four simi-lar experiments.

(Figure 4a, b). oxLDL (40 and 80 lg/ml) signifi-cantly inhibited the phosphorylation of P47 in this reaction. In this study, the extent of radioactivity in P47 was expressed as a relative detection density (PSL/mm2; PSL, photostimulated luminescence) of the radioactive bands (Figure 4b). Moreover, oxLDL (40 and 80 lg/ml) also significantly inhib-ited collagen (1 lg/ml)-induced phosphorylation of P47 in human platelets (data not shown). Effect of OxLDL on VASP phosphorylation In our previous study [16], oxLDL (40 and 80 lg/ ml) significantly increased the level of cyclic AMP but not cyclic GMP in human platelets. It is presumed that cyclic AMP can induce VASP Ser157 phosphorylation in human platelets [25]. In this study, PGE1 (10 lM) and oxLDL (40

and 80 lg/ml) markedly induced VASP Ser157 phosphorylation compared with resting platelets (Figure 5). This result further demonstrates that oxLDL-inhibited platelet aggregation may be mediated through an increase in cyclic AMP formation.

Effect of OxLDL on thrombin-evoked pHi changes in platelets

Thrombin can trigger more-pronounced pHi changes than collagen in human platelets. Thus,

we chose thrombin instead of collagen in this study. Figure 6 shows that the addition of thrombin (1 U/ ml) resulted in an increase in BCECF fluorescence equivalent to an increase in pHi values of about 0.302±0.058 (Figure 6). This thrombin-evoked increase in pHi values was markedly inhibited in the presence of oxLDL (40 and 80 lg/ml) (Figure 6). In addition, cariporide (0.5 lM), a Na+/H+ exchange inhibitor [30], significantly inhibited the thrombin-evoked pHi increase by about 90% in this study (data not shown).

Discussion

The principal objective of this study was to further describe the detailed inhibitory mechanisms in-volved in the inhibition of agonist-induced human platelet aggregation by oxLDL. This inhibitory effect of oxLDL was also demonstrable in the PRP. Although the action mechanisms of various platelet aggregation agonists, such as collagen and arachidonic acid, differ, oxLDL significantly inhibits platelet aggregation stimulated by all of them [16]. This implies that oxLDL may block a common step shared by these inducers. These results also indicate that the site of action of oxLDL is not at the receptor level of individ-ual agonists. Triflavin acts by binding to the glycoprotein IIb/IIIa complex on the platelet

Figure 3. Fluorescence emission spectra of platelet membranes in the (a) absence or (b) presence of DPH (1 lM). Curves C and D are the emission spectra of membranes labeled with DPH in the presence of oxLDL (c) (40 lg/ml) and (d) (80 lg/ml). Profiles are representative examples of four similar experiments.

surface membrane, resulting in interference with the interaction of fibrinogen with its specific receptor [21, 28]. In this study, we found that oxLDL did not significantly affect FITC-triflavin binding to the glycoprotein IIb/IIIa complex, indicating that the antiplatelet activity of oxLDL is possibly not directly due to interference with the binding of fibrinogen to its specific receptor on the platelet membrane. Furthermore, LOX-1 mono-clonal antibody (10 lg/ml) (Anti-human LOX-1/ SR-E1 antibody, R&D systems, Inc., Minneapolis, MN) did not significantly reverse the inhibitory effect of oxLDL (80 lg/ml) in collagen (1 lg/ml)-induced platelet aggregation (data not shown), indicating that the antiplatelet effect of oxLDL does not involve in LOX-1 receptor. Conforma-tional changes in the plasma membrane and/or changes in membrane fluidity represent a generally

Figure 4. (a) Effect of oxLDL on phosphorylation of a protein of Mr 47,000 (P47) in human platelets challenged with PDBu. Platelets were preincubated with oxLDL (40 and 80 lg/ml) or isovolumetric solvent control (Tyrode’s solution, ctl) followed by the addition of PDBu (150 nM) to trigger protein kinase C activation. (a) Profiles are representative examples of four similar experi-ments. The arrow indicates a protein of Mr 47,000 (P47). (b) The relative detection densities of the radioactive bands are expressed as PSL/mm2_{(PSL, photostimulated luminescence).}

Figure 5. Effect of oxLDL on phosphorylation of VASP at Ser157in human platelets. Platelets were incubated with pros-taglandin E1(PGE1) (10 lM) and oxLDL (40 and 80 lg/ml),

and solubilized directly in SDS-PAGE sample buffer. Phos-phorylation of VASP at Ser157_{was detected by}

immunoblot-ting with a monoclonal antibody specifically recognizing Ser157-phosphorylated VASP. Profiles are representative examples of four similar experiments.

accepted mechanism for the antiplatelet effect of numerous drugs, including local anesthetics, chlor-promazine, and beta-blockers [31]. Therefore, we wondered whether oxLDL might also inhibit platelet aggregation by influencing membrane fluidity. To test this hypothesis the fluorescent probe DPH was used to label biological mem-branes. In this study, oxLDL (40 and 80 lg/ml) concentration-dependently decreased the DPH relative fluorescence intensity of platelet mem-branes (Figure 3). Activation of platelets is accom-panied by a decrease in membrane fluidity as

reflected by an increase in fluorescence intensity of DPH-labeled platelets [32]. Reorganization of cytoplasmic contractile and structural proteins is essential for platelet functions [32]. Therefore, a decrease in membrane fluidity (relatively rigid membrane) in activated platelets may affect the cytoskeletal network [32]. This finding suggests that changes in platelet membrane fluidity may be the primary mechanism responsible for the anti-platelet effect of oxLDL.

On the other hand, oxLDL significantly inhibits PDBu-induced PKC activation. PDBu is known to

Figure 6.Effect of oxLDL on the thrombin-triggered intracellular pH increase in BCECF-AM-loaded platelets. Platelet suspen-sions (4.5
108_{/ml) were preincubated with BCECF-AM (5 lM), followed by the addition of thrombin (1 U/ml) to trigger}

intracel-lular alkalinization in the presence or absence of oxLDL (40 and 80 lg/ml). Profiles are representative examples of four similar experiments.

intercalate with membrane phospholipids and form a complex with PKC translocated to the membrane [33]. Moreover, increased cyclic AMP formation can negatively affect agonist-induced PKC activa-tion [34]. oxLDL increases the level of cyclic AMP [16] and cyclic AMP-induced VASP Ser157 phos-phorylation in human platelets (Figure 5); there-fore, the inhibitory effect of oxLDL in PDBu-induced PKC activation may be due, at least partly, to mediation of the increase in cyclic AMP forma-tion. On the other hand, we also measured [3H] inositol monophosphate (IP) formation as an index of total inositol phosphate formation. The addition of collagen (1 lg/ml) resulted in a rise in IP formation of about 1.6-fold compared to that in resting platelets [(1.6±0.3 vs. 2.5±0.2)
10)4cpm] (n=3, data not shown). In the pres-ence of oxLDL (40 and 80 lg/ml), the radioactivity of IP formation in collagen-stimulated human platelets markedly inhibited about 25% and 29%, respectively (n=3, data not shown).

Activation of platelets by a variety of agonists (i.e., thrombin and ADP) is associated with stimulation of the Na+/H+ exchanger [35]. This mode of activation of the Na+/H+ exchanger usually induces a rise in cytosolic Ca2+, granule secretion, stimulation of shape change, and aggre-gation [35]. Basal pHi is normally maintained within a narrow range, and even small changes in pHi may have significant effects on platelet activ-ity. In many cell types (i.e., smooth muscle cells), Na+/H+exchange activity is regulated by [Ca2+]i [36]. Furthermore, Kimura et al. [35] reported that cyclic nucleotides (i.e., cyclic AMP) modulate Na+/H+ exchange in human platelets. Inhibition of Na+/H+exchange by cyclic AMP has also been demonstrated in other cells, such as epithelia of the urinary system and in osteoblast-like cells [37]. Thus, an agent (i.e., parathyroid hormone or dopamine) known to stimulate adenylate cyclase in these cells can also inhibit the Na+/H+ exchanger [37, 38]. Therefore, relationships among PKC activation, [Ca2+]i, cyclic nucleotides (i.e., cyclic AMP), and the Na+/H+ exchanger may play an important role in mediating the antiplat-elet activity of oxLDL.

In conclusion, this study further suggests that the oxLDL may be due to induction of conforma-tional changes in the platelet membrane, with a resulting influence on membrane fluidity followed by inhibition of PKC activation and subsequent

inhibition of intracellular Ca2+ mobilization and phosphorylation of P47. In addition, oxLDL also triggers the formation of cyclic AMP and cyclic AMP-induced VASP Ser157 phosphorylation which subsequently inhibits the Na+/H+ exchan-ger. This leads to reduced intracellular alkaliniza-tion, intracellular Ca2+ mobilization, and ultimately inhibition of platelet aggregation. The most important finding in this study provides new insights concerning the effects of oxLDL on platelet aggregation.

Acknowledgements

This study was sponsored by the National Science Council of Taiwan (NSC 93-2321-B-038-001) and Min-Sheng Healthcare (93MSH-TMU-15).

References

1. Steinberg D., Metabolism of lipoproteins and their role in the pathogenesis of atherosclerosis. Atheroscler. Rev. 18: 1–23, 1988.

2. Leeuwenburgh C., Hardy M.M., Hazen S.L., Wagner P., Oh-ishi S., Steinbrecher U.P. and Heinecke J.W., Reactive nitrogen intermediates promote low density lipoprotein oxidation in human atherosclerotic intima. J. Biol. Chem. 272: 1433–1436, 1997.

3. Berliner J.A. and Heinecke J.W., The role of oxidized lipoproteins in atherogenesis. Free Radic. Biol. Med. 20: 707–727, 1996.

4. Weksler B.B. and Nachman R.L., Platelets and atheroscle-rosis. Am. J. Med. 71: 331–333, 1981.

5. Tremoli E., Colli S., Maderna P., Baldassarre D. and Di M.G., Hypercholesterolemia and platelets. Semin. Thromb. Hemost. 19: 115–121, 1993.

6. Andrews H.E., Aitken J.W., Hassall D.G., Skinner V.O. and Bruckdorfer K.R., Intracellular mechanisms in the activation of human platelets by low-density lipoproteins. Biochem. J. 242: 559–564, 1987.

7. Ardlie N.G., Selley M.L. and Simons L.A., Platelet activation by oxidatively modified low density lipoproteins. Atherosclerosis 76: 117–124, 1989.

8. Katzman P.L., Bose R., Walker S., Perry Y. and Bolli P., Temperature-dependence of LDL binding and activation of human platelets. Thromb. Res. 64: 503–508, 1991. 9. Takahashi Y., Chiba H., Matsuno K., Akita H., Hui S.P.,

Nagasaka H., Nakamura H., Kobayashi K., Tandon N.N. and Jamieson G.A., Native lipoproteins inhibit platelet activation induced by oxidized lipoproteins. Biochem. Biophys. Res. Commun. 222: 453–458, 1996.

10. Block L.H., Knorr M., Vogt E., Locher R., Vetter W., Groscurth P., Qiao B.Y., Pometta D., James R. and Regenass M., Low density lipoprotein causes general cellular activation with increased phosphatidy1 inositol

turnover and lipoprotein catabolism. Proc. Natl. Acad. Sci. USA 85: 885–889, 1998.

11. Weidtmann A., Scheithe R., Hrboticky N., Pietsch A., Lorenz R. and Siess W., Mildly oxidized LDL induces platelets aggregation through activation of phospholipase A2. Arterioscler. Thromb. Vasc. Biol. 15: 1131–1138, 1995.

12. Katzman P.L., Bose R., Henry S., McLean D.L., Walker S., Fyfe C., Perry Y., Mymin D. and Bolli P., Serum lipid profile determines platelet reactivity to native and modified LDL-cholesterol in humans. Thromb. Haemost. 71: 627– 632, 1994.

13. Pedreno J., de Castellarnau C., Cullare C., Ortin R., Sanchez J.L., Llopart R. and Gonzalez-Sastre F., Platelet receptor recognizes with same apparent affinity both oxidative and native LDL. Arterioscler. Thromb. Vasc. Biol. 14: 401–408, 1994.

14. Vlasova I.I., Azizova O.A. and Lopukhin Y.M., Inhibitor analysis of LDL induced platelet aggregation. Biochemistry (Moscow) 62: 307–311, 1997.

15. Vlasova I.I., The effect of oxidatively modified low-density lipoproteins on platelet aggregability and membrane fluid-ity. Platelets 11: 406–414, 2000.

16. Chou D.S., Hsiao G., Shen M.Y., Fong T.H., Lin C.H., Chen T.F. and Sheu J.R., Low concentration of oxidized low-density lipoprotein suppresses platelet reactivity in vitro: an intracellular study. Lipids 39: 433–440, 2004. 17. Sheu J.R., Lee C.R., Lin C.H., Hsiao G., Ko W.C., Chen

Y.C. and Yen M.H., Mechanisms involved in the antiplatelet activity of Staphylococcus aureus lipoteichoic acid in human platelets. Thromb. Haemost. 83: 777–784, 2000.

18. Dousset N., Ferretti G., Taus M., Valdiguie P. and Curatola G., Fluorescence analysis of lipoprotein peroxi-dation. Meth. Enzymol. 233: 459–469, 1994.

19. Sheu J.R., Lee C.R., Hsiao G., Hung W.C., Lee Y.M., Chen Y.C. and Yen M.H., Comparison of the relative activities ofa-tocopherol and PMC on platelet aggregation and antioxidative activity. Life Sci. 65: 197–206, 1999. 20. Steinbrecher U.P., Oxidation of human low-density

lipo-protein results in derivatization of lysine residues of apolipoprotein B by lipid peroxide decomposition prod-ucts. J. Biol. Chem. 262: 3603–3608, 1987.

21. Sheu J.R., Lin C.H., Peng C.H. and Huang T.F., Triflavin, an Arg–Gly–Asp-containing peptide, inhibits the adhesion of tumor cells to matrix protein via binding to multiple integrin receptors expressed on human hepatoma cells. Proc. Soc. Exp. Biol. Med. 213: 71–79, 1996.

22. Kitagawa S., Shinohara T. and Kametani F., Effects of alcohols on ADP-induced aggregation and membrane fluidity of gel-filtered bovine blood platelets. J. Membrane Biol. 79: 97–102, 1984.

23. Wroblewski F. and Ladue J.S., Lactic dehydrogenase activity in blood. Proc. Soc. Exp. Biol. Med. 90: 210–215, 1955.

24. Grabarek J., Raychowdhury M., Ravid K., Kent K.C., Newman P.J. and Ware J.A., Identification and func-tional characterization of protein kinase C isozymes in

platelets and HEL cells. J. Biol. Chem. 267: 10011–10017, 1992.

25. Li Z., Ajdic J., Eigenthaler M. and Du X., A predominant role for cAMP-dependent protein kinase in the cGMP-induced phosphorylation of vasodilator-stimulated phos-phoprotein and platelet inhibition in humans. Blood 101: 4423–4429, 2003.

26. Sweatt J.D., Johnson S.L., Cargoe E.J. and Limbird L.E., Inhibition of Na+/H+exchange block stimulus-provoked arachidonic acid release in human platelets. J. Biol. Chem. 260: 12910–12919, 1985.

27. Horne W.C., Norman N.E., Schwartz D.B. and Simons E.R., Changes in cytoplasmic pH and in membrane potential in thrombin-stimulated platelets. Eur. J. Biochem. 120: 295–302, 1981.

28. Sheu J.R., Teng C.M. and Huang T.F., Triflavin, an RGD-containing antiplatelet peptide, binds to GP IIIa of ADP-stimulated platelets. Biochem. Biophys. Res. Commun. 189: 1236–1242, 1992.

29. Siess W. and Lapetina E.G., Platelet aggregation induced by alpha 2-adrenoceptor and protein kinase C activation. A novel synergism. Biochem. J. 263: 377–385, 1989. 30. Baumgarth M., Beier N. and Gericke R., Bicyclic

acylgua-nidine Na+/H+antiporter inhibitors. J. Med. Chem. 41: 3736–3747, 1998.

31. Kobayashi T., Yamada J., Setaka M. and Kwan T., Effects of chlorpromazine and other calmodulin antago-nists on phosphatidylcholine-induced vesiculation of plate-let plasma membranes. Biochim. Biophys. Acta 855: 58– 62, 1986.

32. Pribluda V. and Rotman A., Dynamics of membrane-cytoskeleton interactions in activated blood platelets. Biochemistry 21: 2825–2832, 1982.

33. Kraft A.S. and Anderson W.B., Phorbol esters increase the amount of Ca2+, phospholipid-dependent protein kinase associated with plasma membrane. Nature 301: 621–623, 1983.

34. Walter U., Eigenthaler M., Geiger J. and Reinhard M., Role of cyclic nucleotide-dependent protein kinases and their common substrate VASP in the regulation of human platelets. Adv. Exp. Med. Biol. 344: 237–249, 1993. 35. Kimura M., Lasker N. and Avir A., Cyclic nucleotides

attenuate thrombin-evoked alterations in parameters of platelet Na/H antiport. The role of cytosolic Ca2+. J. Clin. Invest. 89: 1121–1127, 1992.

36. Nieuwland R., Van Willigen G. and Akkerman J.N., Different pathways for control of Na+_/H+_{exchange via}

activation of the thrombin receptor. Biochem. J. 297: 47– 52, 1994.

37. Felder C.C., Campbell T., Albrecht F. and Jose P.A., Dopamine inhibits Na+_-H+ _{exchanger activity in renal}

BBMW by stimulation of adenylate cyclase. Am. J. Physiol. 259: F297–F303, 1990.

38. Reid I.R., Civitelli R., Avioli L.V. and Hruska K.A., Parathyroid hormone depresses cytosolic pH and DNA synthesis in osteoblast-like cells. Am. J. Physiol. 255: E9– E15, 1988.
