Glandular odontogenic cyst: a case report

J.F.L. de Castro1, Á.C.G. Henriques2, M.D. Medeiros,3L.T. Montenegro4& C. Cazal5

1Oral Pathology Department, School of Dentistry, Federal University of Pernambuco, Pernambuco, Brazil

2Oral Pathology Department, School of Dentistry, Federal University of Pernambuco, Pernambuco, Brazil

3Maxillofacial Surgery Department, School of Dentistry, Federal University of Pernambuco, Pernambuco, Brazil

4Pathology Department, School of Medicine, Federal University of Pernambuco, Pernambuco, Brazil

5Oral Pathology Department, School of Dentistry, Federal University of Pernambuco, Pernambuco, Brazil


The glandular odontogenic cyst (GOC) is a rare developmental lesion con- sidered a distinct entity because of its uncommon histopathological charac- teristics. It has morphological similarities to other lesions, which makes its histopathological diagnosis challenging for some pathologists. This lesion can involve either jaws, but the anterior region of the mandible is the most affected area. It strikes distinct age groups, with an average patient age of 50 years. It can exhibit a tendency towards recurrence when conservative treatment is administered. It is believed that the low prevalence of GOC in the literature is because of not only its rarity, but principally to the fact that its main characteristics are also found in other pathological entities, thereby generating controversial diagnoses. The aim of the present article is to report a case of GOC in a 40-year-old female patient exhibiting an intrabone cyst in the anterior mandibular region. The initial diagnostic hypothesis by means of radiographic imaging was of a traumatic bone cyst. After histological analysis, the lesion was diagnosed as GOC. The specimen was stained with haematoxylin and eosin, and then with the Periodic Acid Schiff (PAS) method. Through immunohistochemical analysis, the cyst tested positively for the Ki-67 and p53 antibodies as well as high molecular pan-cytokeratin.

Key words:

glandular odontogenic cyst, odontogenic cyst, odontogenic neoplasm

Correspondence to:

Dr. C Cazal Alcides Maia, 701, 04 Camaragibe

Pernambuco 54792-560 Brazil

Tel.:+55(083)3216-7252 Fax:+55(083)3216-7252 email: claudiacazal@yahoo.com.br Accepted: 16 October 2008



The term glandular odontogenic cyst (GOC) has been proposed as the most appropriate designation for this rare pathological lesion1. It was formerly denomi- nated mucous-producing odontogenic cyst and sialo- odontogenic cyst because of a probable origin from the tissue which forms the salivary glands1,2. Binda et al.3 stated that a large number of controversies exist regarding the terminology and origin of the GOC. The authors stressed the rarity of the lesion collecting rea- sonable information from 23 cases of GOC reported in the literature. In 1997, Ramer et al.4published a new case of GOC, and reviewed 39 reported cases (35 from the English literature and four cases from the German literature). In 2002, Noffke and Raubenheimer5 reported seven new cases of GOC diagnosed over a

10-year period, and finally, in 2006, Shen et al.6analy- sed and published more 12 new cases of GOC including immunohistochemical analysis of them.

Clinically, GOC can involve either jaw, but the ante- rior region of the mandible is pointed as the most affected area. When in the maxilla, the lesion seems to affect mainly the tuberosity region5,6. The limited numbers of reported cases of GOC do not allow the elaboration of trustworthy epidemiological infor- mation regarding gender predilection, age or most common location. The main published features include the presence of a radiolucent swelling in the jaws, a tendency towards local recurrence after conservative surgical treatment. Some lesions can grow slowly and remain small, others may reach larger dimension, infiltrate and destroy the bone2,3,5,7. Radiography reveals a unilocular or multilocular radiolucent image


with well-defined margins. Other radiographic char- acteristics which can be presented in GOC include: root displacement and resorption of the teeth involved as well as tapering, erosion and perforation of the cortical bone8,9.

According to the literature2,3, GOC’s histopatho- logical characteristics comprise: cystic cavity lined with stratified squamous epithelium of variable thickness; the absence of inflammatory infiltrate in the capsular conjunctive tissue; and surface layer of the epithelium may present areas of cuboidal eosino- philic cells, or ciliated cells. Sometimes an irregular papillary surface can be identified. The epithelial cells may form circular proliferations resembling spheres, or spherical nodules, which are a significant charac- teristic, although not always present. Other charac- teristics include microcysts or intraepithelial crypts containing mucin, mucous cells and hyaline bodies, within the thickest section of the epithelium and in the lumen of the cyst. An uncommon presence of calcifications, phantom cells, foreign multinuclear giant cells and a chronic inflammatory infiltrate in the wall of the cyst might be also observed. Binda et al.3 and Ferreira Jr et al.10 observed an interesting histo- logical characteristic: epithelial proliferation within the cyst wall, which may suggest a neoplasic potential and a possible association with central mucoepider- moid carcinoma (MEPCa).

A case of GOC is described. The GOC was located in the anterior region of the mandible, mimicking a lesion of an endodontic origin or a pseudocyst. The diagnosis of GOC was confirmed through histopathological examination.

Case report

During a routine radiographic exam, a 40-year-old female patient presented an asymptomatic intrabone lesion. It was located in the anterior area of the man- dible near the periapical region of the 41, 31 and 32 tooth. The radiography revealed a unilocular radiolu- cent image with well-defined margins and radiopaque sclerotic edges (Fig. 1). The initial diagnostic hypoth- esis was of traumatic bone cyst. Involved tooth responded positively to pulp vitality tests. Because it was not a periapical inflammatory lesion of endon- dontic origin, patient was informed to proceed with surgical removal of the cyst. However, the patient did not return to give continuity to the suggested treat- ment. Upon returning 4 months after the initial diagnosis, the patient returned with the 41 teeth endodontically treated. The oral surgeon was able to give continuity to the treatment and to perform the

complete surgical removal of the lesion with ample curettage (Fig. 2).

The specimen was formalin fixed and sent to the oral pathology laboratory where the histopathological analysis was performed. The anatomopathological examination revealed fragments of a cystic lesion of odontogenic nature compatible with GOC. The epithe- lial lining exhibited cuboidal or columnar cells with a stratified aspect in which areas of papillary irregularity could be observed (Fig. 3). Duct-like microcystic spaces were observed bordered by cuboidal cells (Fig. 4). Mucous cells were also seen, as well as

Figure 1 Initial radiographic appearance of the lesion exhibiting a well- defined circumscribed radiolucent image, resulting in root displacement of the 41, 31 and 32 dental elements.

Figure 2 Transurgical findings after specimen removal. Surgeon is replacing a lyophilised bone membrane over the bone defect.


occasional eosinophilic material in the interior of the microcystic structures. The cyst sac was composed of richly cellularised and vascularised fibrous conjunctive tissue containing occasional islands of inactive odon- togenic epithelia. Special methods using PAS and immunohistochemistry were performed for the pro- teins p53, Ki-67 and pan-cytokeratin. The PAS staining revealed positive mucous cells and occasional cystic spaces containing positive PAS material (Fig. 5).

The immunohistochemistry study was performed using the avidinbiotin complex method (ABComplex/

HRP Duet, Mouse/Rabbit Dako A/S, Glostrup Denmark). The following primary antibodies at various

working dilutions were Ki-67 1:100 (Mib-1, Dako), p53 1:100 (DO7, Dako) and pan-cytokeratin 1:500 (AE1/AE3, Dako). Microwave antigen retrieval and overnight incubation were performed for primary antibodies. Diaminobenzidine tetrahydrochloride was used as a chromogen.

The AE1/AE3 antibody was positive (Fig. 6), and the proteins p53 and Ki-67 were strongly expressed throughout the length of the epithelia, respectively confirming the deregulation of the tumour suppression mechanism (Fig. 7) and the presence of mitotic activity (Fig. 8). The patient’s follow up has been carried out for 18 months and she has not presented any recurrences

Figure 3 Photomicrography exhibiting a thin epithelial lining with areas of proliferate papillary irregularity. Epithelial cells are predominantly cuboidal shaped (HE–40¥).

Figure 4 Duct-like microcystic spaces are observed bordered by cuboidal cells (arrow). Some mucous cells are also present, as well as occasional columnar shaped cells (asterisk) (HE–100¥).

Figure 5 Photomicrography exhibiting PAS-positive eosinophilic material in the interior of the microcystic structures (arrow). Some PAS-positive mucous cells are also present (asterisk) (HE–100¥).

Figure 6 Photomicrography exhibiting the strong positive immunoreac- tion to the AE1/AE3 (SBP–200¥).


thus far. Figure 9 shows the initial bone regeneration after 1 year from the surgical treatment.


The few cases of GOC reported in the literature impede any reliable information regarding predilection for gender, age or most common localisation. Moreover, there remains a lack of clarification on some issues, such as histogenesis, biological behaviour and the appropriate treatment of these lesions. The present case report is in agreement with most cases cited in the lit- erature2,5,8, which consider the anterior region of the mandible the most affected area. Contrarily, Qin et al.9

reported a series of cases with a greater prevalence of lesions in the anterior region of the maxillary.

The high degree of multilocularity in GOC in com- parison to other odontogenic cysts and its tendency towards the expansion of the cortical bone underline the local aggressive potential. Data collected in a study by Manor et al.8indicated that GOC exhibited aggres- sive behaviour, with expansion and perforation in a significant number of cases. Such aspects were not observed in the case reported herein.

Because of the location of the cyst near the apices of elements 41, 31 and 32, it mimicked an inflammatory endodontic lesion. Therefore, pulp vitality testing was essential in order to exclude the possibility of a peri- apical lesion of an endodontic origin. Consequently, the most adequate clinical diagnostic hypothesis was that of a traumatic bone cyst. The unnecessary endo- dontic treatment carried out on the teeth directly related to the cyst was because of the patient’s seeking another dental health-care professional after the initial diagnosis of traumatic bone cyst. This fact reveals the importance of knowledge regarding the intrabone lesions that share the differential diagnosis with GOC.

According to Tran et al.11, the radiographic characteris- tics observed in GOC can lead to a diagnosis of kerato- cystic odontogenic tumour, ameloblastoma, central lesion of giant cells, lateral periodontal cyst, root cyst, simple bone cyst, aneurysmatic bone cyst, periapical cementum dysplasia, ossifying fibroma, odontogenic myxoma and central low-grade MEPCa.

The patient ultimately sought the assistance of the oral surgeon once again and the correct treatment was performed, namely, the complete excision of the cyst with ample curettage. The recurrence mechanism may be partially related to the thinness of the cyst wall and the presence of microcysts that hamper the complete

Figure 7 Photomicrography exhibiting the strong positive immunoreac- tion to the p53 protein (SBP–200¥).

Figure 8 Photomicrography exhibiting the strong positive immunoreac- tion to the Ki-67 protein (SBP–200¥).

Figure 9 Final radiographic appearance of the lesion 9 months after total excision. It can be observed as initial bone regeneration. Note the endo- dontic treatment performed on the right lower incisor before the surgical treatment.


removal of the lesion, as well as the surgical technique employed for treatment9,12. The aggressive nature of GOC is also cited as a possible cause of recurrence10. As a result, a local block excision is suggested as the best treatment option9. In our case, based on the patient’s decision, the surgeon opted for conservative surgery with curettage, follow up and a commitment to rigor- ous radiographic control.

The definitive diagnosis of GOC cannot be performed by radiographic exams because of the similarities with the various intrabone pathologies mentioned above8. Thus, the majority of the authors1,2,6,8,9 stress the importance of a histological evaluation of all cases. In fact, lateral periodontal cysts may also present histo- logical findings described as ‘circular nodules’ on epi- thelial layer surface11, but the later should not reach bigger dimensions or provoke clinical swellings. Thus, ultimate diagnosis should be achieved by a complete observation of all possible characteristics: clinical, radiographic and histopathological.

Attention to some microscopic details should help in separating low-grade MEPCa from GOC. To help in the differentiation from MEPCa, the lesion should be screened for presence of hobnail or cuboidal eosino- philic cells in the superficial layer of the lining epithe- lium, and for small intraepithelial glandular microcysts or duct-like structures which are not typical for MEPCa. The epidermoid component in MEPCa is usually seen at the periphery of the cystic spaces, and not as epithelial spherules or whorls protruding into the lumen which is characteristic of GOC13.

In a study by Kaplan et al.12, immunohistochemical findings revealed that GOC positively marks the pro- teins p53 and Ki-67, which was corroborated by our findings. The authors also affirm that the immunore- action for these antibodies in GOC is stronger when compared with that of MEPCa, and these markers may be considered an auxiliary aide in the differential his- topathological diagnosis between these lesions.

The presence of p53-positive and Ki-67-positive cells in GOC should not be taken as an indication of malig- nancy or malignant potential. In fact, it requires further investigation because it may reflect a disrupted cell proliferation and thereby the aggressive behaviour of the lesion12,13.

We stress the importance of a prolonged post-surgery follow-up period for approximately 3–5 years. As Ferreira Jr et al.10state, GOC has an aggressive nature, with a considerable chance of recurrence. The authors report a case of GOC that recurred four times following unsuccessful surgical treatment. The present case has

been followed up for 18 months and there have been no signs of recurrence thus far. The presentation of this case can contribute to the previously presented data in the world literature and add further information so that this thus far little understood entity can be better clarified statistically.


1. McClatchey KD, Zarbo RJ. Sternberg’s Diagnostic Surgical Pathology, 4th edn. Philadelphia, PA:

Lippincott Willams & Wilkins, 2004:879–932.

2. Abu-Id MH, Kreusch T, Brüschke C. Glanduläre odontogene zyste dës unterkiefers. Ein Fallbericht.

Mund Kiefer Gesichtschir 2005;9:188–92.

3. Binda JE, Kuepper R, Pulse C. Glandular odontogenic cyst: a case report and review of the literature. Col Dent Rev 1997;2:1.

4. Ramer M, Montazem A, Lane SL, Lumerman H.

Glandular odontogenic cyst: report of a case and review of the literature. Oral Maxillofac Path 1997;84:54–7.

5. Noffke C, Raubenheimer EJ. The glandular odontogenic cyst: clinical and radiological features; review of the literature and report of nine cases. Dentomaxillofac Radiol 2002;31:333–8.

6. Shen J, Fan M, Chen X, Wang S, Wang L, Li Y.

Glandular odontogenic cyst in China: report of 12 cases and immunohistochemical study. J Oral Pathol Med 2006;35:175–82.

7. Economopoulou P, Patrikiou A. Glandular odontogenic cyst of the maxilla: report of case. J Oral Maxillofac Surg 1995;53:834–7.

8. Manor R, Anavi Y, Kaplan I, Calderon S. Radiological features of glandular odontogenic cyst.

Dentomaxillofac Radiol 2003;32:73–9.

9. Qin XN, Li JR, Chen XM, Long X. The glandular odontogenic cyst: clinicopathologic features and treatment of 14 cases. J Oral Maxillofac Surg 2005;63:694–9.

10. Ferreira Jr O, Azevedo LR, Sant’Ana E, Lara VS.

Glandular odontogenic cyst: case report and review of the literature. Quintessence Int 2004;35:385–9.

11. Tran PT, Cunnighan CJ, Baughman RA. Glandular odontogenic cyst. J Endodont 2004;30:182–4.

12. Kaplan I, Anavi Y, Manor R, Sulkes J, Calderon S. The use of molecular markers as an aid in the diagnosis of glandular odontogenic cyst. Oral Oncol


13. Kaplan I, Anavi Y, Hirshberg A. Glandular odontogenic cyst: a challenge in diagnosis and treatment. Oral Dis 2008;14(7):575–81.
