口腔病理科 On-Line KMU Student Bulletin

原文題目(出處): Osteochondroma of the Mandibular Condyle: Literature Review and Report of a Case, J Contemp Den Pract Volume 8, No. 4, May 1, 2007 原文作者姓名: Marina de Oliveira Ribas, Wilson Denis Martins, Maria Helena de

Sousa, Fernando Luis Zanferrari, Thais Lanzoni 通訊作者學校: Pontifical Catholic University of Curitiba, Brazil 報告者姓名(組別): 曾懷廷 (I組)

報告日期: 2007年6月4日



Aim: brief review of literature on osteochondroma and to present a case involving surgical removal and replacement of part of condyle and mandibular angle.

Background: osteochondroma is the most common tumor of bones, but relatively uncommon in the jaws. This benign cartilage-capped growth is usually discovered incidentally on radiographic examination or on palpation.

Report: 29-year-old woman with osteochondroma of the mandibular condyle. Surgical treatment was tumor resection, grafting & reshaping of the mandibular angle & ramus.

Summary: If the tumor involves only a limited area of the condylar surface, preservation of the condyle and reshaping should be done. Reasons for not taking a conservative approach are the possibilities of malignancy and the risk or recurrence.


1. Osteochondroma/solitary osteocartilaginous exostosis is a cartilage-capped osseous projection

2. Most common tumor of bone 3. Relatively uncommon in jaws Review of Literature

1. Vichow 1891: physeal cartilage becomes separated and grows transverse to the long axis of bone

2. Keith 1920: defect in the perichondral ring surrounding the physis is the cause 3. Muller: exostoses are produced by small nests of cartilage derived from the

cambium layer of periosteum

4. Lichtenstein: periosteum has potential to develop osteoblasts and chodroblasts 5. Osteochondroma of the mandible occurs at the condyle or tip of the coronoid


6. Accounts for 35.8% of benign bony tumors and for 8.5% of tumors overall

7. Malignant change is rare in solitary osteochondroma but does occur in 5% of multiple hereditary osteochondromatosis

8. It occurs in adolescents or young children, both sexes equally affected

9. Histological distinction between osteochondroma and chondrosarcoma can be difficult. High cellularity, pleomorphism and plump cells Æmalignant lesion

10. Lesion usually discovered incidentally

11. Lateral open bite on the contralateral side and progressive facial asymmetry in most cases

12. Pain may precede or accompany facial asymmetry

13. Radiographic image: globular radiolucent, lobulated mass which distorts normal morphology, can be differentiated from the elongated condylar process seen in hyperplasia

14. Lesion may have a pedunculated stalk or sessile base 15. CT可以幫助把lesion和周圍正常的組織做區分

16. Vezeau et al.: condylectomy is the surgical treatment of choice

17. Joint reconstruction: condylosplasty, discectomy, costchondral grafting

- 1 -


口腔病理科 On-Line KMU Student Bulletin

Case Report Diagnosis

1. 29-year-old woman

2. Complaint of increasing facial asymmetry over a period of four years 3. Normal mouth opening

4. Mandible deviated 8mm to the right side 5. No associated pain

6. Increased length of left ascending ramus

7. Pano: mandibular asymmetry, enlargement of the left mandibular condyle 8. CT: large globular, mixed radiopaque/radiolucent condylar mass of the left TMJ 9. Scintillography: increased captivation in left condyle, no evidence of multiple

osteochondromas Treatment

1. EKG, chest radiography, urine and blood values within normal range

2. Tumor resection, grafting and reshaping of the mandibular angle and ramus were planned

3. Risdon approach to access ramus and condylar neck 4. Osteotomy carried out

5. Graft was prepared and fixed with #2 wires 6. Intermaxillary fixation for 2 weeks

7. Microscopic: cancellous bone with trabeculae of variable size. Cartilaginous inclusions were visible

8. 3 year follow up: patient presented good facial symmetry and stable occlusal relationship


1. 42 cases affecting mandibular condyle reported in English language literature 2. Found in the fourth decade, mean age 38.5 years

3. Male: female 1.0:1.2

4. Symmetry(?) of face present in 83.3%, 52.3% pain was present, 30.9% mandibular hypomobility


1. If the tumor involves only a limited area, preservation &reshaping should be done 2. If possibility of malignancy or risk of occurrence, then carry out condylectomy

題號 題目

1 醫師懷疑病患有osteochondroma並作組織切片發現組織切片沒有軟骨組織, 請問較


(A) Osteoid osteoma (B) Osteoblastoma (C) Osteoma (D) Osteosarcoma

答案(C) 出處:A Textbook of Oral Pathology, Shafer, W.B. Saunders Second Edition, 1983, pg 163

題號 題目

2 如果一個osteochondroma的病患發現下顎往右側偏的時候, 請問病灶區在哪一邊?

(A) 前面 (B) 右側 (C) 後面 (D) 左側

答案(D) 出處:Oral & Maxillofacial Pathology, Saunders Second Edition, Neville Damm Allen Bouquot, pg 566
