Effects of pressure, temperature, and geometric structure of pillared graphene on hydrogen storage capacity

(1)

Effects of pressure, temperature, and geometric structure

of pillared graphene on hydrogen storage capacity

Cheng-Da Wu

1

, Te-Hua Fang

*

, Jian-Yuan Lo

1

Department of Mechanical Engineering, National Kaohsiung University of Applied Sciences, Kaohsiung 80807, Taiwan

a r t i c l e i n f o

Article history:

Received 22 May 2012 Received in revised form 9 July 2012

Accepted 10 July 2012 Available online 26 July 2012 Keywords: Pillared graphene Hydrogen Adsorption Pressure Molecular dynamics

a b s t r a c t

The adsorption of molecular hydrogen on a three-dimensional pillared graphene structure under various environments is studied using molecular dynamics simulations. The effects of pressure, temperature, and the geometric structure of pillared graphene are evaluated in terms of molecular trajectories, binding energy, binding force, and gravimetric hydrogen storage capacity (HSC). The simulation results show that in a pillared graphene structure, the HSC of the graphene sheets is better than that of the carbon nanotube (CNT) pillars. An insufficient gap between graphene sheets decreases the HSC because hydrogen adsorbed at the edges of a pillared graphene structure prevents hydrogen from entering the structure. A low temperature, a high pressure, and a large gap between graphene sheets maximize the HSC. The HSC is only slightly improved by increasing the CNT diameter.

1. Introduction

Carbon-based systems that comprise carbon atoms with sp2 hybridization (i.e., carbon nanotubes (CNTs) and fullerenes) have been widely studied and applied in micro/nano-systems due to their excellent mechanical, thermal, and electronic properties[1e4]. A single layer of graphene has been synthe-sized using the mechanical exfoliation of graphite[5]. Carbon-based systems are considered as potential candidates for energy storage[6]due to their high adsorption surface area.

Hydrogen is a potential successor to gasoline due to its many advantages, including clean combustion and the high-est energy content per weight unit of any known fuel. However, hydrogen is a gas with a very low density under ambient conditions. Understanding the mechanisms of hydrogen adsorption on graphene under various environ-ments would benefit various fields, including motor vehicles,

fusion reactor design, and hydrogen storage [7]. Molecular dynamics (MD) simulations of the grapheneehydrogen inter-face can be used to explore the nature of surinter-face adsorption. Atomistic simulation avoids experimental noise and turbu-lence problems. It can be used to analyze molecular trajecto-ries and thermodynamic properties. Many nanosystems have been analyzed using MD, such as studies on nanowetting properties[8], nanoimprinting[9], nanoforming[10], and dip-pen nanolithography [11,12]. Herrero and Ramirez [13]

studied the diffusion of hydrogen in graphite and found that hydrogen atoms jump from a C atom to a neighboring one with an activation energy of about 0.4 eV. Compared to atomic hydrogen, molecular hydrogen has a much smaller activation energy and faster diffusion speed. Lamari and Levesque[14]

studied hydrogen adsorption on graphene and found that at a temperature of 77 K and a pressure of 1 MPa, the excess hydrogen physisorption is estimated to be equal tow7 wt%,

* Corresponding author. Tel./fax:þ886 7 3814526 5336.

E-mail addresses:nano112002@gamil.com(C.-D. Wu),fang.tehua@msa.hinet.net(T.-H. Fang),1099303134@kuas.edu.tw(J.-Y. Lo). 1_Tel.:_{þ886 7 3814526 5336; fax: þ886 7 3831373.}

Available online at

www.sciencedirect.com

journal hom epa ge: www.elsev ier.com/locate/he

i n t e r n a t i o n a l j o u r n a l o f h y d r o g e n e n e r g y 3 7 ( 2 0 1 2 ) 1 4 2 1 1e1 4 2 1 6

(2)

and decreases with increasing temperature. Du et al. [15]

studied the separation of hydrogen and nitrogen gases by porous graphene membranes. They found that the separation mechanism is related to the van der Waals (VDW) interactions of the gases with the graphene membrane.

This work investigates the mechanism of molecular hydrogen adsorption on a pillared graphene structure using MD simulations. Pillared graphene is considered to be superior to CNTs as a hydrogen storage material due to its higher surface area and storage capacity. To optimize the operating parameters, the effects of pressure, temperature, and the geometric structure of pillared graphene are studied. The results are discussed in terms of molecular trajectories, binding energy, binding force, and gravimetric hydrogen storage capacity (HSC).

2. Methodology

Fig. 1(a) shows a schematic of three-dimensional pillared graphene array that combines two allotropes of carbon, namely CNTs and graphene sheets. In the nanostructure, CNT pillars occupy the empty space between two graphene sheets. The graphene sheets are perfectly arranged in hexagonal form.Fig. 1(b) shows the initial MD model of a hydrogen/pil-lared graphene interface. The pilhydrogen/pil-lared graphene structure is placed at the middle of the system, and hydrogen with a face-centered cubic (fcc) structure is placed above and below the pillared graphene. The hydrogen molecules are treated as single spherical molecules to simplify the model. The two

graphene sheets have dimensions of 7 nm (length) 7 nm (width). The length of a (10,10) CNT is 1.2 nm. There are 4000 hydrogen molecules in the simulated system, whose dimen-sions are 10 nm (length) 10 nm (width) 12 nm (height). Periodic boundary conditions are applied in all three dimen-sions. To focus on the hydrogen adsorption mechanism, the graphene is considered to be ideally rigid to increase compu-tational efficiency; this is reasonable due to graphene’s extremely strong bonding energy. Pressure, temperature, the separation distance (gap) between the graphene sheets, and the pore size of the CNT are varied in ranges of 4e15 MPa, 77e300 K, 0.6e1.5 nm, and 0.81e2.44 nm, respectively, to determine their effects on HSC. Before adsorption simula-tions, all hydrogen underwent an MD equilibrium run of 100 ps in order to achieve energy relaxation and uniform distribution in the system. The VDW interactions of C/H2and H2/H2are described by the Lennard-Jones potential[16]. A cut-off radius of 1.0 nm is used to evaluate the number of hydrogen molecules adsorbed on the graphene. The time step is fixed at 1 fs. The ensemble in the system is isothermal-isobaric (NPT).

3. Results and discussion

3.1. Effect of pressure

To focus on the effect of system pressure on hydrogen adsorp-tion, the system was maintained at an isothermal state at 77 K and the gap of the pillared graphene structure was set to 1.2 nm. Fig. 1e (a) Schematic of three-dimensional pillared graphene array. (b) Initial MD model of a hydrogen/pillared graphene interface.

Fig. 2e Snapshots of hydrogen adsorption on pillared graphene at a temperature of 77 K at a time of 1500 ps for pressures of (a) 4, (b) 6, (c) 8, and (d) 15 MPa.

(3)

[3] Vaccarini L, Goze C, Henrard L, Hernandez E, Bernier P, Rubio A. Mechanical and electronic properties of carbon and boron-nitride nanotubes. Carbon 2000;38:1681e90.

[4] Yu MF, Lourie O, Dyer MJ, Moloni K, Kelly TF, Ruoff RS. Strength and breaking mechanism of multiwalled carbon nanotubes under tensile load. Science 2000;287:637e40. [5] Novoselov KS, Geim AK, Morozov SV, Jiang D, Zhang Y, Dubonos SV, et al. Electric field effect in atomically thin carbon films. Science 2004;306:666e9.

[6] Wang L, Stuckert NR, Yang RT. Unique hydrogen adsorption properties of graphene. AIChE J 2011;57:2902e8.

[7] Schlapbach L, Zuttel A. Hydrogen-storage materials for mobile applications. Nature 2001;414:353e8.

[8] Wu CD, Kuo LM, Lin SJ, Fang TH, Hsieh SF. Effects of temperature, size of water droplets, and surface roughness on nanowetting properties investigated using molecular dynamics simulation. Comput Mater Sci 2012;53:25e30. [9] Wu CD, Fang TH, Lin JF. An investigation of the effects of

PMMA orientation and antistiction layer on the nanoimprint process using molecular dynamics. Adv Sci Lett 2011;4:36e43. [10] Lin SJ, Wu CD, Fang TH, Kuo LM. Effects of forging

temperature and velocity on nano-forming process using molecular dynamics simulation. Comput Mater Sci 2011;50: 2918e24.

[11] Wu CD, Fang TH, Lin JF. Formation mechanism and mechanics of dip-pen nanolithography using molecular dynamics. Langmuir 2010;26:3237e41.

[12] Wu CD, Fang TH, Lin JF. Effect of chain length of self-assembled monolayers in dip-pen nanolithography using molecular dynamics simulations. J Coll Interf Sci 2011;361: 316e20.

[13] Herrero CP, Ramirez R. Diffusion of hydrogen in graphite: a molecular dynamics simulation. J Phys D: Appl Phys 2010; 43:255402.

[14] Lamari FD, Levesque D. Hydrogen adsorption on functionalized graphene. Carbon 2011;49:5196e200. [15] Du H, Li J, Zhang J, Su G, Li X, Zhao Y. Separation of hydrogen

and nitrogen gases with porous graphene membrane. J Phys Chem C 2011;115:23261e6.

[16] Simon JM, Haas OE, Kjelstrup S. Adsorption and desorption of H2on graphite by molecular dynamics simulations. J Phys Chem C 2010;114:10212e20.

[17] Dimitrakakis GK, Tylianakis E, Froudakis GE. Pillared graphene: a new 3-D network nanostructure for enhanced hydrogen storage. Nano Lett 2008;8:3166e70.

[18] Poirier E, Chahine R, Benard P, Cossement D, Lafi L, Melancon E, et al. Storage of hydrogen on single-walled carbon nanotubes and other carbon structures. Appl Phys A 2004;78:961e7.

[19] Tibbetts GG, Meisner GP, Olk CH. Hydrogen storage capacity of carbon nanotubes, filaments, and vapor-grown fibers. Carbon 2001;39:2291e301.

[20] Darkrim F, Levesque D. High adsorptive property of opened carbon nanotubes at 77 K. J Phys Chem B 2000;104:6773e6. [21] Gordon PA, Saeger RB. Molecular modeling of adsorptive

energy storage: hydrogen storage in single-walled carbon nanotubes. Ind Eng Chem Res 1999;38:4647e55.

[22] Zhu HW, Ci LJ, Chen A, Mao ZQ, Xu CL, Xiao X, et al. Hydrogen uptake in multi-walled carbon nanotubes at room temperature. In: Mao ZQ, Veziroglu TN, editors. Hydrogen energy progress XIII: proceedings of the 13th world hydrogen energy conference. Beijing (China): International Association for Hydrogen Energy; 2000. p. 560e4.

[23] Wu HB, Chen P, Lin J, Tan KL. Hydrogen uptake by carbon nanotubes. Int J Hydrogen Energy 2000;25:261e5.

[24] Cheng J, Yuan X, Zhao L, Huang D, Zhao M, Dai L, et al. GCMC simulation of hydrogen physisorption on carbon nanotubes and nanotube arrays. Carbon 2004;42:2019e24.

[25] Browning DJ, Gerrard ML, Laakeman JB, Mellor IM, Mortimer RJ, Turpin MC. Investigation of the hydrogen storage capacities of carbon nanofibres prepared from an ethylene precursor. In: Mao ZQ, Veziroglu TN, editors. Hydrogen energy progress XIII: proceedings of the 13th world hydrogen energy conference. Beijing (China): International Association for Hydrogen Energy; 2000. p. 554e9.

[26] Gupta BK, Awasthi K, Srivastava ON. New carbon variants: graphitic nanofibres and nanotubules as hydrogen storage materials. In: Mao ZQ, Veziroglu TN, editors. Hydrogen energy progress XIII: proceedings of the 13th world hydrogen energy conference. Beijing (China): International Association For Hydrogen Energy; 2000. p. 487e92.

[27] Sun Q, Jena P, Wang Q, Marquez M. First-principles study of hydrogen storage on Li12C60. J Am Chem Soc 2006;128: 9741e5.
