Molecular mechanism of the inhibitory eﬀect of KS-5

on bFGF-induced angiogenesis in vitro and in vivo

Chieh-Yu Peng

a

, Shiow-Lin Pan

a

, Kuo-Hsiung Lee

b

, Kenneth F. Bastow

c,*,1

,

Che-Ming Teng

a,*,1

a_{Pharmacological Institute, College of Medicine, National Taiwan University, No. 1, Jen-Ai Road, Section 1, Taipei, Taiwan} b_{Natural Products Research Laboratories, School of Pharmacy, University of North Carolina, Chapel Hill, NC 27599, USA} c_{Division of Medicinal Chemistry and Natural Products, School of Pharmacy, University of North Carolina, Chapel Hill, NC 27599, USA}

Received 31 October 2007; received in revised form 14 December 2007; accepted 14 December 2007

Abstract

Inhibition of angiogenesis controls the expansion and metastasis of many solid tumors and other related-diseases. KS-5 (1,7-dihydroxy-3-methoxyacridone), is an inactive analogue of the substituted 1-hydroxy acridone antiviral class. This study aimed at studying the effects of KS-5 on bFGF-induced angiogenesis in cultured human umbilical vein endothelial cells (HUVECs) in vitro and in vivo. KS-5 inhibited bFGF (10 ng/ml)-induced cell proliferation in a concentration-dependent manner, but did not exhibit significant cytotoxic effect examined by LDH release assay. KS-5 inhibited bFGF-induced angi-ogenesis was associated with decreasing DNA synthesis as evaluated by BrdU incorporation assay, and abrogating endo-thelial cell ERK1/2 and Akt protein phosphorylation, the major signaling pathways involved in cellular processes of angiogenesis. In addition, KS-5 also inhibited bFGF-induced phosphorylation of mTOR and the major downstream effec-tors, eIF4E and p70S6K_{. Moreover, bFGF-induced protein synthesis was also inhibited by KS-5. Most importantly, KS-5}

treatment in nude mice inhibited in vivo angiogenesis as revealed by Matrigel implant assay. In conclusion, the present study suggests that KS-5 has potential anti-angiogenetic eﬀect for cancer therapy and other angiogenesis-dependent diseases. Ó 2007 Elsevier Ireland Ltd. All rights reserved.

Keywords: Angiogenesis; Acridone derivatives; Endothelial cells

1. Introduction

Angiogenesis, the growth of microvessel sprout-ing the size of capillary blood vessels, is a tightly

regulated process and restricted to a few physio-logical conditions including reproduction, embry-onic development, and wound healing [1]. In contrast, uncontrolled angiogenesis is a driving force for a number of pathologies, such as cancer, ocular neovascular disease and chronic inﬂamma-tory diseases [2]. Angiogenesis is a multiple-step process involving matrix degradation, endothelial cell proliferation, migration and diﬀerentiation. To complete the process, all of the steps must

* _{Corresponding authors. Tel.: +1 919 966 7633; fax: +1 919}

966 0204 (K.F. Bastow); tel./fax: +886 2 2322 1742 (C.-M. Teng). E-mail addresses: Ken_Bastow@unc.edu (K.F. Bastow),

cmteng@ntumc.org(C.-M. Teng).

1

These authors contributed equally to this work.

Cancer Letters 263 (2008) 114–121

(2)

occur [3]. One of the most potent stimulators of angiogenesis is basic ﬁbroblast growth factor (bFGF), which regulates endothelial cell prolifera-tion, migraprolifera-tion, protease producprolifera-tion, integrin and cadherin receptor expression [4]. Inhibition of angiogenesis is becoming one promising, alterna-tive approach to treat cancer and other related-diseases.

The mammalian target of rapamycin (mTOR) is an evolutionarily conserved serine/threonine kinase. This kinase is centrally involved in protein translation, cell cycle progression and cellular pro-liferation [5,6]. The best-understood roles of mTOR in mammalian cells are related to control of cap-dependent mRNA translation. The eIF4E and p70S6Kpathways are the major mTOR-depen-dent downstream signaling pathways that mediate mTOR-dependent control of cell size and cell growth [6,7]. A key regulatory step in translation is initiation, eIF4E is the limiting initiation factor in most cells. Thus, eIF4E activity plays a princi-ple role in determining global translation rates [8]. The function of eIF4E is inhibited by the eIF4E-binding proteins (4E-BP1, 4E-BP2, 4E-BP3), that bind eIF4E and block its function [9]. The regula-tion of the 4E-BP1 is much better understood than that of 4E-BP2/3. 4E-BP1 undergoes phos-phorylation at seven sites, at least four of which are linked to mTOR signaling [10,11]. Phosphory-lation of these sites is required for release of eIF4E from 4E-BP1.

Acridine derivatives are interesting chemothera-peutic agents that were ﬁrst used as antibacterial and antiparasite agents. The biological activity of acridines is mainly attributed to the planarity of these aromatic structures, which can intercalate within the double-stranded DNA structure, thus interfering with the cellular machinery. More recent understanding reveal that many acridine derivates have biological targets such as topoi-somerases I and II, telomerase/telomere and pro-tein kinases and leading to anti-tumor property

[12]. KS-5 (1,7-dihydroxy-3-methoxyacridone) was originally synthesized as an analogue of substituted 1-hydroxyacridone antivirals active against HSV-1, HSV-2 and or HCMV replication

[13,14]. However, preliminary screening work identiﬁed KS-5 as a potential anti-angiogenesis compound and this study reports a detailed study of KS-5 eﬀects on bFGF-induced angiogenesis in vitro and in vivo.

2. Materials and methods

2.1. Cell culture

Human umbilical vein endothelial cells (HUVECs) were obtained from human umbilical cord veins with col-lagenase, isolated according to protocols from Jaﬀe et al.

[15], and cultured in 75-cm2plastic flasks in M199 med-ium containing 20% inactivated fetal bovine serum (FBS) and 15 lg/ml endothelial cell growth supplements. Confirmation of cell identity as endothelial cells was pro-vided by detection of CD31 (PECAM-1) by immunostain-ing. The human nasopharyngeal cancer cell line, KB cell, was cultured in RPMI1640 medium containing 10% FBS. Cells were incubated at 37°C in a humidified atmosphere of 5% CO2in air. Medium was changed every 2 days, and

cells were passaged after treatment with a solution of 0.05% trypsin/0.02% EDTA. Experiments were conducted on HUVECs that had gone through two to ﬁve passages.

2.2. Growth inhibition assay

Method is according to the recommendation of the NCI DTP Angiogenesis Resource Center used. HUVECs (5 103

cells/well) are plated in a 96-well plate in 100 ll of EGM-2 (Clonetic #CC3162). After 24 h (day 0), the test compound (100 ll) is added to each well at 2 the desired concentration in EGM-2 medium. On day 0, one plate is stained with 0.5% crystal violet in 20% methanol for 10 min, rinsed with water, and air-dried. The remaining plates are incubated for 72 h at 37°C. After 72 h, plates are stained with 0.5% crystal violet in 20% methanol, rinsed with water and air-dried. The stain is eluted with 1:1 solu-tion of ethanol: 0.1 M sodium citrate (including day 0 plate), and absorbance is measured at 540 nm with an ELISA reader. Day 0 absorbance is plotted as basal.

2.3. Cytotoxicity assay

The lactate dehydrogenase (LDH) released into cell cultures is an index of cytotoxicity and evaluates the per-meability of the cell membrane. After an incubation of 24 h with various drug concentration in EBM2, the cul-ture supernatants were collected. The LDH assay was per-formed using the CytoTox96 Nonradioactive Cytotoxicity Assay kit (Promega, Madison, WI) according to the man-ufacturer’s instructions. The percentage of LDH released was expressed as a proportion of the LDH released into the medium compared to the total amount of LDH pres-ent in cells treated with 2% Triton X-100.

2.4. DNA synthesis assay

Based on the measurement of 5-bromo-2-deoxyuri-dine (BrdU) incorporation during DNA synthesis, the

(3)

colorimetric ELISA kit (Amersham Biosciences, Piscat-away, NJ) was used for the quantiﬁcation of DNA synthesis. HUVECs were seeded at 5.0 103 _{cells per}

well into 96-well plates in M199 medium supplemented with 20% FBS, and starved with 1% FBS-M199 med-ium for 24 h. The cells were then incubated with or without indicated reagents and bFGF (10 ng/ml) (Bio-vision, Palo Alto, CA) for 48 h. BrdU (10 lM) was added during last 16 h of incubation period. The assay was performed according to the manufacturer’s instructions.

2.5. Western blot analysis

After exposure of cells to indicated agents over spec-ified time courses, cells were washed twice with ice-cold PBS, and reaction was terminated by addition of 100 ll of ice-cold lysis buffer (10 mM Tris–HCl, pH 7.4, 150 mM NaCl, 1 mM EGTA, 0.5 mM phenylmethyl sul-fonyl fluoride, 10 lg/ml aprotinin, 10 lg/ml leupeptin, and 1% Triton X-100). Protein (30 lg/lane) was sepa-rated by electrophoresis on 7.5–12% SDS–polyacryl-amide gels. Proteins were electrophoretically transferred to polyvinylidene difluoride membranes and blots were blocked with 5% nonfat milk for 1 h. The membrane was immunoreacted with the primary anti-body to ERK1/2 (Thr202/Tyr204), Akt (Ser473), 4E-BP (Thr37/46), phospho-eIF4E (Ser209), phospho-p70S6K _{(Thr389) (Cell}

Signal-ing Technologies, Boston, MA), phospho-mTOR (Ser2448) (Novus Biologicals, Littleton, CO) and GAP-DH (Santa Cruz Biotechnology, Inc., Santa Cruz, CA) for overnight incubation at 4°C. After four washings with PBS/0.1% Tween 20, the secondary antibody (diluted 1:1000) was applied to the membranes for 1 h at room temperature. Antibody-reactive bands were detected with an enhanced chemiluminescence kit (Amersham, Buckinghamshire, UK).

2.6. Protein synthesis measurements

Incorporation of [3_{H]leucine was used as a sensitive}

parameter to measure de novo protein synthesis. HUVECs were seeded at a density 5.0 103 _cells/well

on 24-well plates. Cells were starved with DME/F12 medium containing 1% FBS for 24 h. Cells incubated with leucine-free DME/F12 medium for 1 h and pre-treat drug for 30 min, and then pre-treated with or with-out growth factor followed by incubation with 2.5 lCi/ml [3H]leucine for 6 h. Plates were washed twice with cold phosphate-buﬀered saline, and 10% tri-chloroacetic acid was added at 4°C and incubated for 60 min. The precipitates were washed twice and dis-solved in 1 N NaOH. The radioactivity of the incorpo-rated [3H]leucine was measured using liquid scintillation counting.

2.7. In vivo Matrigel plug assay

Nude mice (6 weeks of age) were given subcutaneous injections of 500 ll of Matrigel (BD Biosciences) at 4°C containing growth factor (150 ng/ml bFGF) and drug. After injection, the Matrigel rapidly formed a plug. After 7 days, the skin of the mouse was easily pulled back to expose the Matrigel plug, which remained intact. For his-tological examination, the plug were ﬁxed, embedded, and stained with Hematoxylin & Eosin.

2.8. Data analysis and statistics

Data are presented as mean ± SEM or as percentage of control. Statistical comparisons between groups were performed using the Student’s t test. P < 0.05 was consid-ered statistically signiﬁcant.

3. Results

3.1. Anti-proliferative eﬀect of KS-5 on endothelial and tumor cells

The anti-proliferative activity of KS-5 was determined on HUVECs and the human nasopharyngeal cancer cell line, KB cells. KS-5 inhibited cellular proliferation in a con-centration-dependent manner with IC50of 0.6 lM (Fig. 1A)

and 8.23 lM (Fig. 1B), against HUVECs and KB cells, respectively. Therefore, the results shown that KS-5 is about 10 times more selective against endothelial cells as opposed to cancer cells. Subsequently, we used LDH assay to test whether the inhibition of cell proliferation was the consequence of KS-5-mediated cellular toxicity. For cells treated with KS-5 in EBM-2 medium for 24 h, there was no signiﬁcant diﬀerence in LDH release between basal and treated cells even with a KS-5 concentration as high as 40 lM (about 70-fold higher than IC50,Fig. 1C).

3.2. Eﬀect of KS-5 on bFGF-induced DNA synthesis of HUVECs

Cell proliferation involves both cell growth and cell divi-sion[6]. Cell growth (increase cell mass) needs protein syn-thesis, and cell division (increase cell number) needs DNA synthesis. To determine that the eﬀect of KS-5 on bFGF-induced DNA synthesis the BrdU incorporation assay was used. As shown inFig. 2, KS-5 (0.1–20 lM) reduced bFGF-stimulated DNA synthesis in a concentration-dependent manner with IC50value of 0.98 lM and

signiﬁ-cant inhibition was observed from 1 lM upwards (P < 0.05).

3.3. KS-5 inhibits MAPK and Akt protein phosphorylation

The mitogenic signaling pathways are activated in response to a variety of extracellular stimuli such as growth factors, cytokines and cell stress [16]. We

(4)

exam-ined whether KS-5 caused alteration of mitogenic signal-ing pathways activated by bFGF. First, we examined its eﬀect on the MAP kinase pathway under bFGF-induction conditions. We utilized an antibody to detect phospho-ERK1/2, commonly used indirect assay to assess MAP kinase activation. As shown in Fig. 3A, treatment with KS-5 signiﬁcantly decreased phospho-ERK1/2 levels after bFGF-stimulated for the indicated times. However, the PI3 kinase/Akt signalling pathway is now recognized as being at least an important as the ras-MAP kinase path-way in cell survival and proliferation [17]. As shown in

Fig. 3B, treatment with KS-5 also inhibited bFGF-induced Akt phosphorylation. These data suggest that KS-5 is able to block bFGF-induced ERK1/2 and Akt signaling pathways in endothelial cells.

3.4. Eﬀect of KS-5 on bFGF-induced mTOR pathway activation in HUVECs

Cell proliferation requires enhanced rates of protein synthesis. The mTOR signaling pathway is important for protein synthesis. To determine whether the anti-pro-liferative eﬀects of KS-5 result from inhibition of mTOR signaling, we ﬁrst examined the phosphorylation status of mTOR, p70S6K, 4E-BP1, and eIF-4E on endothelial cells. As shown inFig. 4A and B, elevated phosphoryla-tion of mTOR, p70S6K, 4E-BP1, and eIF-4E were detected following bFGF treatment in a time-dependent fashion. As expected, basal levels of phosphorylated mTOR, p70S6K_{, 4E-BP1, and eIF-4E were much lower in}

untreated endothelial cells. However, when we examined the eﬀect of KS-5 on phosphorylation of mTOR, and phosphorylation of p70S6K, 4E-BP1 and eIF-4E, these downstream targets of mTOR, were signiﬁcantly decreased in endothelial cells by KS-5 treatment.

Fig. 1. Eﬀects of KS-5 on the proliferation of HUVECs and KB cells. HUVEC(A) and KB (B) cells were seeded in a 96-well plate at 5000 cells per well, after 72 h (A) or 48 h (B) incubation with varying concentrations of KS-5 (0.1–20 lM), crystal violet 50 ll were added to stain the cells, then wash twice and air dry. Bound dye was subsequently solubilized with enthanol: 0.1 M sodium citrate, and absorbance of the solution at 540 nm was determined. The IC50value of KS-5 is 0.61 (A) and 8.23 (B) lM, respectively.

Data represent the mean ± SEM of three independent experi-ments (each performed in triplicate). #P < 0.001 versus basal group;*_{P < 0.05;}**_{P < 0.01 versus control group. (C) Eﬀect of}

KS-5 on the LDH release in HUVECs. HUVECs were exposed to 0.1, 1, 10, 20 and 40 lM of KS-5. At 24 h of incubation after exposure, 0.05 ml of culture medium were collected for determi-nation of LDH activity according to the manufacturer’s instructions.

Fig. 2. Eﬀects of KS-5 on bFGF-induced HUVEC DNA synthesis. HUVECs were stimulated with bFGF 10 ng/ml con-taining varying concentrations of KS-5 for 48 h, and labeled with BrdU 10 lM during the last 16 h of stimulation. Data represent the mean ± SEM of three independent experiments (each per-formed in triplicate).#_{P < 0.001 versus basal group;}*_{P < 0.05;} **_{P < 0.01 versus control group.}

(5)

3.5. Eﬀect of KS-5 on bFGF-induced protein synthesis in HUVECs

The present data suggested that KS-5 inhibited bFGF-induced mTOR signaling pathway to modulate endothe-lial cells growth. Signaling by mTOR regulates protein synthesis by modulating the rate of translation of mRNAs. Therefore, we investigated the eﬀect of KS-5 on bFGF-induced [3H]leucine incorporation into the cells.

As shown inFig. 5, bFGF treatment for 6 h caused a sig-niﬁcant increase in [3H]leucine incorporation almost 2-fold. KS-5 signiﬁcantly abolished, in a concentration-dependent manner, the bFGF-induced increase in [3 H]leu-cine incorporation into HUVECs. These results suggest that KS-5 may inhibit angiogenesis probably through the inhibition of mTOR-dependent pathway by bFGF.

Fig. 4. Eﬀects of KS-5 on bFGF-induced translational regula-tory proteins. (A) Quiescent HUVECs were untreated (0) or treated for 10–60 min with bFGF (10 ng/ml) following a 30 min pretreatment with DMSO or KS-5 (10 lM). (B) Quiescent HUVECs were untreated (Basal) or treated with bFGF (10 ng/ ml) for 30 min following a 30 min pretreatment with DMSO (CTL) or KS-5 (0.1, 1, 10 lM). Cell extracts were prepared and equal amounts of protein were analysed by SDS–PAGE and immunoblotting with antibodies speciﬁc for phospho-mTOR, phospho-p70S6K_{, phospho-eIF4E, and phospho-4EBP. Similar}

results were obtained in three independent experiments.

Fig. 3. Eﬀects of KS-5 on bFGF-induced ERK1/2 and Akt protein phosphorylation. Top, Quiescent HUVECs were untreated (0) or treated for 10–60 min with bFGF (10 ng/ml) following a 30 min pretreatment with DMSO or KS-5 (10 lM). Bottom, Quiescent HUVECs were untreated (Basal) or treated with bFGF (10 ng/ml) for 30 min following a 30 min pretreat-ment with DMSO (CTL) or KS-5 (0.1, 1, 10 lM). Cell extracts were prepared and equal amounts of protein were analysed by SDS–PAGE and immunoblotting with antibodies speciﬁc for phosphorylated-ERK 1/2 (A) or phosphorylated-Akt, (B) The quantitative data is shown under each protein, respectively.

#_{P < 0.001 versus basal group;}*_{P < 0.05 versus control group.}

(6)

3.6. Eﬀect of KS-5 on neovascular formation in vivo

To determine whether KS-5 is capable of blocking bFGF-induced angiogenesis in vivo, we used an experi-mental model in which angiogenesis is induced by bFGF embedded in a pellet of Matrigel, which was injected

sub-cutaneously in mice; the degree of vascularization was evaluated after 7 days. bFGF (150 ng/ml) significantly induced angiogenic responses compared with Matrigel alone (Fig. 6), and KS-5 significantly inhibited the angio-genic response in a dose-dependent manner. Microscopic examination showed that the addition of bFGF to the Matrigel induced cellularity and the formation of cords, tubules, and several blood-filled channels containing red blood cells. In contrast, Matrigel pellets without angio-genic stimuli had only a few infiltrating, single, elongated cells. bFGF-induced angiogenesis was significantly reduced in mice treated with bFGF plus KS-5. These results clearly indicate that KS-5 is a potent anti-angio-genic molecule in vivo.

4. Discussion

Angiogenesis, the process of blood-vessel growth, is important during both normal development and tumor growth and metastasis. The inhibition of angiogenesis controls the expansion and metastasis of solid tumors and other related-diseases [18]. In the present study, we demonstrated that KS-5, a 1-hydroxy acridone derivative, has anti-angiogenic properties in vitro and in vivo. Using an in vitro model system, we demonstrated that KS-5 markedly and concentration dependently inhibited bFGF-induced endothelial cell proliferation. As noted above, the activation of ERK1/2, PI3-K and mTOR

Fig. 5. Eﬀects of KS-5 on bFGF-induced HUVEC protein synthesis. HUVECs were pre-treated with diﬀerent concentra-tions of KS-5 for 30 min and added [3_{H]leucine (2.5 lCi/ml) then}

stimulated with bFGF (10 ng/ml) for 6 h. After treatment, the cells were washed, and the cellular proteins were precipitated with 10% TCA for 1 h at 4°C. The precipitates were washed twice, dissolved in 1 M NaOH. The radioactivity of incorporated [3H]leucine was measured and expressed as counts/min. Data represent the mean ± SEM of three independent experiments.

#

P < 0.001 versus basal group; *_{P < 0.05;} **_{P < 0.01 versus}

control group.

Fig. 6. Effects of KS-5 on bFGF-induced angiogenesis in vivo. Top: anti-angiogenesis effect of KS-5 in in vivo mouse Matrigel-plug assay. The experimental procedures are described in Materials and methods. Matrigel without growth factor did not show any migration or invasion of endothelial cells. However, Matrigel containing growth factor (bFGF 150 ng/ml), many blood vessels appeared in the gel on mice subcutaneous. Treatment of KS-5 simultaneously significant dose-dependent inhibition of the formation of blood vessels in the gel after 7 days. Bottom: histological analysis (hematoxylin and eosin staining) of the effect of KS-5 in in vivo angiogenesis. Matrigel containing bFGF in vehicle-treated mice demonstrated a high degree of cellularity and the presence of blood-containing vessels (magnification 100).

(7)

signaling pathways are required for the growth and proliferation eﬀects of bFGF on endothelial cells

[17,19,20]. However, KS-5 signiﬁcantly inhibits bFGF-induced ERK1/2 and Akt protein phosphor-ylation in a concentration-dependent manner.

Abnormal activation of Raf/MEK/ERK and PI3K/Akt pathways often occurs in human cancer due to mutation or aberrant expression[21]. In cer-tain cancer types, the Raf/MEK/ERK pathway may induce the phosphorylation of Bcl-2 and other key molecules involved in the regulation of apopto-sis [22]. Certain phosphorylation events on Bcl-2 have been associated with prolonged activation

[23] and enhanced anti-apoptotic activity [24]. The abnormal activation or mutation of these pathways may result in the selectivity of KS-5 between HUVECs and KB cells.

In eukaryotes, 95–97% of total cellular mRNA translation is via cap-dependent pathway, the others are through cap-independent pathway[25]. mTOR is located at the intersection of several major signal-ing pathways (includsignal-ing PI3-kinase, ERK and AMPK) and is able to integrate a large and diverse panel of cell signals. mTOR can thereby modulate numerous cellular functions[26]. In this study, we show for the first time that KS-5 can inhibit protein synthesis and pathways involved in mTOR-depen-dency, revealing a possible new mechanism of endo-thelial cell growth regulation by KS-5. Overexpression of eIF4E leads to cell transforma-tion and/or enhanced cell growth [27]. It also enhances the translation of certain transcripts by recruiting other translation factors to the mRNA 50 _{cap. KS-5 inhibited bFGF-induced eIF4E} phos-phorylation on Ser209. The effects of phosphoryla-tion on eIF4E activity are not completely understood, but eIF4E phosphorylation has been reported to increase its affinity for mRNA caps

[28]. Although phosphorylation of Thr37/Thr46does not regulate the binding of 4E-BP1 to eIF4E directly, phosphorylation at the Ser65 and Thr70 sites do [11,29]. Phosphoryation of Thr37/Thr46 is required for modiﬁcation of Thr70, following which Ser65 undergoes phosphorylation [30]. KS-5 decreased 4E-BP phosphorylation at Thr37/Thr46 could be stand for decreasing eIF4E activity indi-rectly. Treatment of KS-5 also inhibited the phos-phorylation of p70S6K, which modulates translation of 50_{TOP-containing mRNAs,} suggest-ing that a potentially large number of endothelial cell proteins may have their synthesis regulated by KS-5 at the translational level.

Several types of experimental evidence suggest that bFGF induces angiogenesis indirectly by acti-vation of the VEGF/VEGFR system, e.g. (i) both endogenous and exogenous bFGF induces VEGF expression in endothelial cells [31]; (ii) systemic administration of VEGF-A neutralizing antibodies dramatically reduces bFGF-induced angiogenesis

[31]; (iii) bFGF induces VEGF receptor expression in endothelial cells [32]. However, in this study, we determinated that KS-5 did not aﬀect bFGF-induced VEGF expression at the mRNA level (data not shown). These data shown that KS-5 directly suppressed bFGF-induced cell proliferation signal-ing pathway to abolish the angiogenic function.

In conclusion, we evaluated the anti-proliferation activity of a series of acridone-derivatives on HUVECs induced by bFGF and KS-5 was identi-fied as the most effective one; structure-activity rela-tionships are interesting and will be reported elsewhere (Peng, Teng and Bastow, unpublished results). KS-5 inhibited bFGF (10 ng/ml)-induced cell proliferation in a concentration-dependent man-ner. It is very significant that KS-5 did not cause HUVEC cytotoxicity as revealed by LDH release assay results. The anti-proliferative mechanism involved decreasing phosphorylation of ERK1/2 and Akt proteins using Western blotting analysis. In addition, we have also identified that KS-5 inhib-ited bFGF-induced protein synthesis. This effect correlated with the phosphorylation state of mTOR and downstream factors, p70S6K and eIF4E, both being decreased when cells were pretreated with KS-5. Finally, in nude mice Matrigel implant model, KS-5 significantly inhibited in vivo angiogen-esis induced by bFGF. Taken together, our results suggest that KS-5 is a potent angiogenesis inhibitor with the potential to become a useful agent in the treatment of human cancer and other angiogene-sis-dependent diseases.

Acknowledgements

This study was supported by Grants from the National Science Council of Taiwan (NSC 96-2628-B002-108-MY2) and NIH-NCI CA17625. References

[1] J. Folkman, Angiogenesis: an organizing principle for drug discovery?, Nat Rev. Drug Discov. 6 (2007) 273–286. [2] A. Bikfalvi, Angiogenesis: health and disease, Ann. Oncol.

(8)

[3] C. Ruhrberg, Endogenous inhibitors of angiogenesis, J. Cell Sci. 114 (2001) 3215–3216.

[4] M. Presta, P. Dell’Era, S. Mitola, E. Moroni, R. Ronca, M. Rusnati, Fibroblast growth factor/ﬁbroblast growth factor receptor system in angiogenesis, Cytokine Growth Factor Rev. 16 (2005) 159–178.

[5] T. Schmelzle, M.N. Hall, TOR, a central controller of cell growth, Cell 103 (2000) 253–262.

[6] D.C. Fingar, S. Salama, C. Tsou, E. Harlow, J. Blenis, Mammalian cell size is controlled by mTOR and its downstream targets S6K1 and 4EBP1/eIF4E, Genes Dev. 16 (2002) 1472–1487.

[7] D.C. Fingar, C.J. Richardson, A.R. Tee, L. Cheatham, C. Tsou, J. Blenis, mTOR controls cell cycle progression through its cell growth eﬀectors S6K1 and 4E-BP1/eukaryotic trans-lation initiation factor 4E, Mol. Cell. Biol. 24 (2004) 200–216. [8] B. Raught, A.-C. Gingras, eIF4E activity is regulated at multiple levels, Int. J. Biochem. Cell Biol. 31 (1999) 43–57. [9] J. Marcotrigiano, A.-C. Gingras, N. Sonenberg, S.K. Burley,

Cap-dependent translation initiation in eukaryotes is regu-lated by a molecular mimic of eIF4G, Mol. Cell 3 (1999) 707–716.

[10] A.-C. Gingras, B. Raught, S.P. Gygi, A. Niedzwiecka, M. Miron, S.K. Burley, R.D. Polakiewicz, A. Wyslouch-Cies-zynska, R. Aebersold, N. Sonenberg, Hierarchical phos-phorylation of the translation inhibitor 4E-BP1, Genes Dev. 15 (2001) 2852–2864.

[11] X. Wang, A. Beugnet, M. Murakami, S. Yamanaka, C.G. Proud, Distinct signaling events downstream of mTOR cooperate to mediate the eﬀects of amino acids and insulin on initiation factor 4E-binding proteins, Mol. Cell. Biol. 25 (2005) 2558–2572.

[12] P. Belmont, J. Bosson, T. Godet, M. Tiano, Acridine and acridone derivatives, anticancer properties and synthetic methods: Where are we now?, Anti-Cancer Agents Med Chem. 7 (2007) 139–169.

[13] C.T. Lowden, K.F. Bastow, Cell culture replication of herpes simplex virus and or human cytomegalovirus is inhibited by 3,7-dialkoxylated, 1-hydroxyacridone derivatives, Antiviral Res. 59 (2003) 143–154.

[14] K.F. Bastow, New acridone inhibitors of human herpes virus replication, Curr. Drug Targets Infect. Disord. 4 (2004) 323– 330.

[15] E.A. Jaﬀe, R.L. Nachman, C.G. Becker, C.R. Minick, Culture of human endothelial cells derived from umbilical veins. Identiﬁcation by morphologic and immunologic crite-ria, J. Clin. Invest. 52 (1973) 2745–2756.

[16] J.D. Graves, J.S. Campbell, E.G. Krebs, Protein serine/ threonine kinases of the MAPK cascade, Ann. NY Acad. Sci. 766 (1995) 320–343.

[17] S. Brader, S.A. Eccles, Phosphoinositide 3-kinase signalling pathways in tumor progression, invasion and angiogenesis, Tumori. 90 (2004) 2–8.

[18] D. Hanahan, J. Folkman, Patterns and emerging mecha-nisms of the angiogenic switch during tumorigenesis, Cell 86 (1996) 353–364.

[19] K. Tanaka, M. Abe, Y. Sato, Roles of extracellular signal-regulated kinase 1/2 and p38 mitogen-activated protein

kinase in the signal transduction of basic ﬁbroblast growth factor in endothelial cells during angiogenesis, Jpn. J. Cancer Res. 90 (1999) 647–654.

[20] M.J. Cross, L. Claesson-Welsh, FGF and VEGF function in angiogenesis: signalling pathways, biological responses and therapeutic inhibition, Trends Pharmacol. Sci. 22 (2001) 201–207.

[21] J.A. McCubrey, L.S. Steelman, W.H. Chappell, S.L. Abrams, E.W.T. Wong, F. Chang, B. Lehmann, D.M. Terrian, M. Milella, A. Tafuri, F. Stivala, M. Libra, J. Basecke, C. Evangelisti, A.M. Martelli, R.A. Franklin, Roles of the Raf/MEK/ERK pathway in cell growth, malignant transformation and drug resistance, Biochim. Biophys. Acta. 1773 (2007) 1263–1284.

[22] J.M. Davis, C.R. Weinstein-Oppenheimer, L.S. Steelman, P.M. Navolanic, W. Hu, M. Konopleva, M.V. Blag-osklonny, J.A. McCubrey, Raf-1 and Bcl-2 induce distinct and common pathways which contribute to breast cancer drug resistance, Clin. Cancer Res. 9 (2003) 1161–1170. [23] X. Deng, P. Ruvolo, B. Carr, W.S. May Jr., Survival

function of ERK1/2 as an IL-3 activated, staurosporine-resistant Bcl2 kinases, Proc. Natl. Acad. USA 97 (2000) 1578–1583.

[24] X. Deng, S.M. Kornblau, P.P. Ruvulo, W.S. May Jr., Regulation of Bcl2 phosphorylation and potential signiﬁ-cance for leukemic cell chemoresistance, J. Natl. Cancer Inst. Monogr. 28 (2001) 30–37.

[25] W.C. Merrick, Cap-dependent and cap-independent trans-lation in eukaryotic systems, Gene 332 (2004) 1–11. [26] J. Averous, C.G. Proud, When translation meets

transfor-mation: the mTOR story, Oncogene 25 (2006) 6423–6435. [27] A. De Benedetti, J.R. Graﬀ, eIF-4E expression and its role in

malignancies and metastases, Oncogene 23 (2004) 3189– 3199.

[28] W.B. Minich, M.L. Balasta, D.J. Goss, R.E. Rhoads, Chromatographic resolution of in vivo phosphorylated and nonphosphorylated eukaryotic translation initiation factor eIF-4E: increased cap aﬃnity of the phosphorylated form, Proc. Natl. Acad. USA 91 (1994) 7668–7672.

[29] X. Wang, W. Li, J.L. Parra, A. Beugnet, C.G. Proud, The C terminus of initiation factor 4E-binding protein 1 contains multiple regulatory features that inﬂuence its function and phosphorylation, Mol. Cell. Biol. 23 (2003) 1546–1557. [30] A.-C. Gingras, S.P. Gygi, B. Raught, R.D. Polakiewicz, R.T.

Abraham, M.F. Hoekstra, R. Aebersold, N. Sonenberg, Regulation of 4E-BP1 phosphorylation: a novel two-step mechanism, Genes Dev. 13 (1999) 1422–1437.

[31] G. Seghezzi, S. Patel, C.J. Ren, A. Gualandris, G. Pintucci, E.S. Robbins, R.L. Shapiro, A.C. Galloway, D.B. Rifkin, P. Mignatti, Fibroblast growth factor-2 (FGF-2) induces vas-cular endothelial growth factor (VEGF) expression in the endothelial cells of forming capillaries: An autocrine mech-anism contributing to angiogenesis, J. Cell Biol. 141 (1998) 1659–1673.

[32] Y. Hata, S.L. Rook, L.P. Aiello, Basic ﬁbroblast growth factor induces expression of VEGF receptor KDR through a protein kinase C and p44/p42 mitogen-activated protein kinase-dependent pathway, Diabetes 48 (1999) 1145–1155.
