Effect of Hydrogen Dilution on the Intrinsic a-Si:H Film of the
Heterojunction Silicon-Based Solar Cell
Jui-Chung Hsiao,
a,bChien-Hsun Chen,
b,zChao-Cheng Lin,
bDer-Ching Wu,
band
Peichen Yu
a,zaDepartment of Photonics and Institute of Electro-Optical Engineering, National Chiao Tung University, HsinChu 30010, Taiwan
bGreen Energy and Environment Research Laboratories, Industrial Technology Research Institute, HsinChu, Taiwan
In this work, effects of a hydrogen dilution ratio on the intrinsic amorphous hydrogenated silicon (i-a-Si:H) film of heterojunction silicon-based (HJS) solar cells were systematically studied. Long lifetime samples were obtained for R 5 5, indicating a good a-Si:H/c-Si interface. The dark conductivity was drastically decreased for R = 2, indicating a good film quality. Consequently, an optimized power conversion efficiency of the HJS solar cells was obtained at a moderate R between 2 and 5. In contrast to the pre-vious emphasis on long lifetime, the results indicate that both the interface and film qualities are correlated to the hydrogen dilu-tion, which are important to achieve high-efficiency HJS solar cells. We show that the most optimized HJS solar cell exhibits a marked efficiency of 17.27%.
VC2011 The Electrochemical Society. [DOI: 10.1149/1.3607981] All rights reserved.
Manuscript submitted December 16, 2010; revised manuscript received April 26, 2011. Published July 13, 2011.
The heterojunction silicon-based (HJS) solar cell has recently attracted more attention because of its very high efficiency and sim-ple structure which is composed of hydrogenated amorphous silicon (a-Si:H) layers and a crystalline silicon (c-Si) substrate.1–3All of the processes required to produce of the heterojunction solar cells can be implemented below 250C using plasma enhanced chemical
vapor deposition (PECVD) system and HJS solar cells with a high energy conversion efficiency (>23%) and record high open circuit voltage (Voc) of >740 mV can thus be obtained.
2
The success of heterojunction solar cells is due to the insertion of an intrinsic a-Si:H (i-a-a-Si:H) layer between an emitter layer and a c-Si substrate. This i-a-Si:H layer effectively passivates the silicon surface, reduc-ing the surface recombination velocity.
Numerous deposition parameters control the quality of an i-a-Si:H layer.4–8The key considerations in setting the deposition parameters are the need to passivate the surface of a c-Si substrate; to prevent the initiation of the localized epitaxial growth at the a-Si:H/c-Si interface and to reduce the defects in a-Si:H films.4,9,10 Hydrogen dilution of the silane gas mixture is extensively used in the deposition of a-Si:H films in thin film solar cells to improve performance and sta-bility.11–14Furthermore, some studies have discussed the effects of the H2 dilution ratio (R¼ SiH4/H2) in HJS solar cells. Kim et al.
pointed out that an R of 2–4 can effectively improve the efficiencies of p-type HJS solar cells compared to those without H2 dilution.
6
More recently, Jeon et al. and Dao et al. used radio frequency PECVD and inductive coupled plasma CVD, respectively, to deposit a-Si:H films on c-Si substrates with various R.7,8The optimum R values to obtain the highest effective lifetime were very different (R¼ 15 for Jeon et al. and R¼ 1 for Dao et al.), perhaps because different deposi-tion systems were used. Note that both groups studied the quality of the a-Si:H layer without the fabrication of HJS solar cells. Das et al. fully produced HJS solar cells with R values from 0 to 10.5 They found a high effective lifetime does not ensure a high HJS solar cell efficiency because of the low fill factor (FF).
In this work, the a-Si:H films were deposited using very high fre-quency (80 MHz) PECVD system at a low temperature of200C
with R values from 0 to 8. Surface passivation quality of i-a-Si:H films on c-Si substrates, microstructure at the a-Si:H/c-Si interface and the dark conductivity of i-a-Si:H films were investigated. We found that the quality at the a-Si:H/c-Si interface and the quality inside the a-Si:H film are both important to obtain high efficiency HJS solar cells.
The n-type CZ Si(100) substrates were cut into 2 2 cm. The re-sistivity and thickness were 1–5 X cm and 170 m, respectively. Samples were dipped in 5% HF to remove the native oxide layer
and were rinsed in ionized water. The a-Si:H thin films were de-posited using a 80 MHz PECVD system. An i-a-Si:H layer with the a thickness of5 nm was deposited on a c-Si substrate, and then a B-doped a-Si:H film was deposited as a p-type emitter layer with a thickness of20 nm using B2H6as the precursor. A Ga-doped ZnO
(GZO) film with a thickness of 80 nm was sputtered on a p-type a-Si:H layer as an anti-reflection coating and conductive layer, and then an Ag grid layer using a shadow metal mask to define the grid pattern with a thickness of200 nm. To simplify and elucidate the effect of the H2dilution ratio (R¼ H2/SiH4), Ag/GZO layers were
directly sputtered on the back of a c-Si substrate as metal contact layers without a back surface field (BSF) layer. The performance of each HJS solar cell was characterized under standard test conditions (25C, 1000 W/m2
, AM 1.5 G). The dark current-voltage (I-V) measurements were done to extract the conductivities of the i-a-Si:H films. The i-a-i-a-Si:H films were symmetrically deposited on the c-Si substrate to evaluate the quality of surface passivation, which was determined by the micro photo conductance decay (u-PCD, SemiLab WT-2000) to extract the effective lifetime. The micro-structure at the a-Si:H/c-Si interface was investigated by high-reso-lution transmission electron microscopy (HR-TEM, JEOL- 2100F).
Figure1shows the PV characteristic parameters, including open circuit voltage (Voc), short current density (Jsc), fill factor (FF),
se-ries resistance (Rs), and solar cell efficiency of HJS solar cells as
functions of R in the intrinsic a-Si:H layers. There are some interest-ing findinterest-ings can be extracted from Fig.1. First, both Vocand Jscare
almost unchanged when R is smaller than 5. They decrease drasti-cally to 0.55 V and 22 mA/cm2, respectively, when R is larger than 5. Second, the series resistance decreases rapidly from 5 to 2 X as R is 2 and further decreases to 1 as R rises to 8. Third, the FFs increase with R. Fourth, the efficiencies of the HJS solar cells increase to 8.4% at R¼ 2, and remain almost the same as R increases from 2 to 8. Notably, the typical “S” curves are observed in the I-V measure-ment at R < 2.
The relationship between lifetime and Vocis given by the
follow-ing equation: Voc¼ kT q ln Jsc J0 þ 1 [1] and J0¼ qn2 iW NDs [2]
Here, K is Boltzmann’s constant, T is the absolute temperature, q is the electric charge, W is the thickness of the silicon substrate and s is the effective lifetime. NDand nidenote the donor concentration
z
E-mail: [email protected]; [email protected]
Journal of The Electrochemical Society, 158 (9) H876-H878 (2011)
0013-4651/2011/158(9)/H876/3/$28.00VCThe Electrochemical Society
H876
) unless CC License in place (see abstract). ecsdl.org/site/terms_use
address. Redistribution subject to ECS terms of use (see 140.113.38.11
and intrinsic concentration of the silicon substrate, respectively. Figure2shows the effective lifetimes of i-a-Si:H films symmetri-cally deposited on n-Si substrates as a function of R. Two regions are clearly distinguished. All of the lifetimes are almost the same (100 s) when R is smaller than 5, whereas decreases rapidly to 70 s as R rises to 8. These results suggest that H2dilution in the
a-Si:H films plays a critical role in the passivation of the c-Si sub-strates. This tendency is wholly consistent with the relation between Vocand R in Fig.1, which is consistent with Eq.1. As mentioned
earlier, localized epitaxy on a c-Si substrate seriously affects the passivation effect of a-Si:H films on a c-Si substrate. HRTEM was
utilized to investigate the micro-structure of an interface of an a-Si:H/c-Si, as shown in Fig.3. The a-SI:H/c-Si interface with R¼ 0 is abrupt while that R¼ 8 exhibits localized partial epitaxial growth and is rough . In this study, the lifetime is reduced if the a-Si:H/c-Si interface is roughened. The localized epitaxial growth with an aver-aged size of2.5 nm scattered on the c-Si substrate suggests more dangling bonds which act as recombination centers in the midgap states at an interface of an a-Si:H/c-Si, leading to a poorer passivation.4,15
Reducing the defect density of an intrinsic a-Si:H film is very important if the film is to be applied in an HJS solar cell. The dark conductivity of an a-Si:H film, which implies the quantities of defects, is widely used to evaluate the quality of an a-Si:H film.16–19 Carriers can transport in an a–Si film through the localized defect states by a defect-assisted hopping mechanism.20 Figure 4 shows the dark conductivity of intrinsic a-Si:H thin films as a function of R. For 8 R 2, the dark conductivity remains constant at about 1.6 1011S/cm. However, the dark conductivity increases rapidly to about 6 1010S/cm at R¼ 0, suggesting that hydrogen is criti-cal to the conductivity of i-a-Si:H films. Very probably, these defects are passivated by hydrogen, which further hamper the trans-portation of carriers, reducing the dark conductivity. Notably, these defects act as recombination centers when the HJS cell is under illu-mination. Very recently, Rahmouni et al.10 showed by simulation that FFs decreased from 0.769 to 0.721 as the defect density in the i-a-Si:H film increased from 9 1014
to 9 1017
cm3, indicating how defects inside the i-a-Si:H film affect the HJS cell performance. This can explain the low FF at R¼ 0 in our study.
As mentioned earlier, the typical “S” curves are observed in the I-V measurement at R < 2. In an HJS cell, an i-a-Si:H film is sand-wiched between an emitter layer and a base substrate. An i-a-Si:H
Figure 1. Photovoltaic characteristics of (a) series resistance, Rs(b) conver-sion efficiency, Eff. (c) fill factor, FF (d) short circuit current density, Jscand (e) open circuit voltage, Vocfor HJS solar cells as a function of the hydrogen dilution ratio, R.
Figure 2. Effective lifetimes of i-a-Si:H films symmetrically deposited on n-Si substrates as a function of the hydrogen dilution ratio, R.
Figure 3. HRTEM images of the a-Si:H/c-Si interface at (a) R¼ 0, (b) R¼ 8.
Figure 4. The measured dark conductivity values as a function of the hydro-gen dilution ratio, R for the i-a-Si:H thin films.
Journal of The Electrochemical Society, 158 (9) H876-H878 (2011) H877
) unless CC License in place (see abstract). ecsdl.org/site/terms_use
address. Redistribution subject to ECS terms of use (see 140.113.38.11
film in an HJS cell must be a good passivation layer to reduce the density of states on the surface of the silicon substrate. It also acts as a conducting layer through which minority carriers can pass under illumination. For example, an i-a-Si:H film with a high lifetime can be obtained at R¼ 0, suggesting a good surface passivation. How-ever, the dark conductivity results in Fig.4reveal too many defects inside an i-a-Si:H film, which make it too resistive to conduct mi-nority carriers and further are responsible for a high series resist-ance, as shown in Fig.1. Meanwhile, an i-a-Si film with a low dark conductivity can be obtained at R¼ 8, suggesting high film quality. It had a low lifetime, indicating a worse interface property between the a-Si:H and the c-Si substrate, as supported by the microstructural observation in Fig.3. The optimization of the i-a-Si:H films for the HJS solar cells is the trade-off between the series resistance and life-time. Consequently, optimal i-a-Si:H films will be obtained at an R of 2–5. They have both a favorable film quality and a favorable interface property, which explain the HJS solar cell efficiencies at R¼ 2–5.
An abrupt a-Si:H/c-Si interface(or a high effective lifetime) does not guarantee a high HJS cell efficiency, because the defects inside the i-a-Si:H film can seriously affect the HJS solar cell performance. Only when the defects inside an a-Si:H film are passivated (or reduced) and the a-Si:H/c-Si interface is abrupt, can a high HJS cell efficiency be excepted. In this work, the spatial distribution of the defects of the a-Si:H film from the surface to the bulk is controlled by introducing the hydrogen during deposition. At R¼ 0, a well-passivated surface with an abrupt a-Si:H/c-Si interface is obtained, but because of the insufficiency of the hydrogen, the defects in the i-a-Si:H film cannot be effectively passivated. As the amount of the
hydrogen is increased, the defects inside an a-Si:H film are passi-vated at R¼ 2–5. As the amount of the hydrogen is increased further to R¼ 8, localized epitaxy occurs at the a-Si:H/c-Si interface, detri-mentally affecting the transportation of the minority carriers. The HJS solar cell with an optimized i-a-Si:H film and a back surface field layer showed an efficiency of 17.27% (aperture area) in Fig.5.
Heterojunction silicon-based solar cells were fabricated by vary-ing R from 0 to 8. The i-a-Si:H films with excellent passivation were obtained at R 5 5. The i-a-Si:H films that were deposited at R=2 contained fewer defects. Optimum HJS cell efficiencies were achieved at 2 5 R 5 5. This result indicates not only an abrupt a-Si:H/c-Si interface but also a high a-Si:H film quality are required to optimize HJS cell efficiency.
