Case report

Oral teratoma (epignathus) in a newborn: A case report

Mohammad Saeed Ahmadi

, Mohsen Dalband

, Elnaz Shariatpanahi

aScientific Emmision (Otolaryngologist & HNS), Hamadan Medical Science University of Iran, Iran

bScientific Emmision (Oral & Maxillofasial Surgen), Hamadan Medical Science University of Iran, Iran

cOtolaryngology Assistance, Hamadan Medical Science University of Iran, Iran

a r t i c l e i n f o

Article history:

Received 30 January 2011

Received in revised form 22 May 2011 Accepted 22 June 2011

Available online 7 September 2011

Keywords:

Oropharyngeal Teratoma Epignathus

a b s t r a c t

An oropharyngeal teratoma (epignathus) is a rare malformation composed of cells from all three germinal layers and few papers have been published about it. Epignathus arises from the palate or pharynx and protrudes from the mouth. We present a large skin-covered teratoma that arose from the hard palate in a neonate. A total surgical excision was performed and histology examination showed mature teratoma with no malignant features.

© 2011 Asian Association of Oral and Maxillofacial Surgeons. Published by Elsevier Ltd. All rights reserved.

1. Introduction

Teratoma was defined by Weaver et al. as a tumour consisting of multiple tissues that are not indigenous to their site of origin[1].

In Greek teratoma means; monsterous tumour. It is a tumour com- posed of multiple tissues foreign to the normal organ from which it arises. Teratomas are true neoplasms originating from pluripotent cells and are composed of tissues from all three germinal layers, usually benign in nature. The most common sites are the sacro- coccyx, anterior mediastinum, testicle, ovary, or retroperitoneum [1,2]. Teratomas of head and neck are exceedingly rare and only about 10% of teratomas are found in this area. Nasopharynx and cervical region are the most common sites[3–8,23]. Epignathus; is commonly used to describe a congenital teratoma in the oropha- ryngeal region, with an estimated incidence of one in 35,000 to one in 200,000 live births[5,25,29]. We describe a female neonate with a large oral teratoma originating from the anterior hard palate that was successfully treated with surge.

2. Case report

A 2.6 kg female neonate born at 38 weeks gestation in August 2010 by vaginal delivery to a 22-year-old mother (G2 P1) who had irregular antenatal examinations during pregnancy and obstetric history was unremarkable. Apgar score of the newborn was nor- mal. Examination showed a large, bony, fleshy, trapeziform mass

∗ Corresponding author.

E-mail addresses:dmsamd@yahoo.com(M.S. Ahmadi),moh110d@yahoo.com (M. Dalband),shariatpanahi@yahoo.com(E. Shariatpanahi).

Fig. 1. A large, bony, fleshy, trapeziform mass protruding from her oral cavity.

6 cm× 5 × 3 cm in diameter with smooth surface covered on one side with numerous fine and coarse hair and protruding from her oral cavity (Fig. 1).

Due to the oral mass, feeding was not possible and there was mild respiratory distress. She was referred from her hospital of birth to our hospital, At the initial examination the mass was mobile and attached to a stalk that originated from the hard palate (Fig. 2).

Computed tomography showed a complex mass protruding from the oral cavity. It was viewed three-dimensionally and seen to arise from the palate. It consisted of cystic, fat, bony, and neural elements, with defined teeth within the bone (Fig. 3).

0915-6992/$ – see front matter © 2011 Asian Association of Oral and Maxillofacial Surgeons. Published by Elsevier Ltd. All rights reserved.

doi:10.1016/j.ajoms.2011.06.006

60 M.S. Ahmadi et al. / Journal of Oral and Maxillofacial Surgery, Medicine, and Pathology 24 (2012) 59–62

Fig. 2. The mass was mobile and attached to a stalk that originated from the hard palate.

As there was no associated anomaly and the mass was localized, an excisional biopsy was planned. Under general anesthesia, the mass was ligated and totally excised at 10th day (Fig. 4).

After excision of the mass, hemostasis achieved (Fig. 5).

Histopathological examination of the mass revealed mature teratoma with mature keratinising squamous epithelium, skin adnexa, adipose tissue, teeth, neurological tissue and bone forma- tion. Smooth muscle fibers were scattered throughout of specimen (Fig. 6).

Postoperatively the palatal wound epithelialised well. She had a nasogasteric tube at the age of 2 weeks. Masseteric function

Fig. 5. Oral cavity after excision of the mass.

and swallowing slowly improved over several weeks. The infant remained asymptomatic and was discharged home on day 28 of life. At present, she is well and symptom-free at 2 month follow-up.

3. Discussion

Teratomas contain all three primordial germ cell layers (ecto- derm, mesoderm and endoderm)[5–8,28]and histologically they may be mature, immature or malignant[6]. They may arise from different sites of the body, the most common site in the newborn is the sacrococcygeal region, (accounting for nearly 40% of the total cases)[9]. Less than 5% occur in the head and neck[9,26]. Epig- nathus is a teratoma arising from the oropharynx[6,29,30]. When

Fig. 3. CT showed a complex mass protruding from the oral cavity. (A) Sagital and (B), coronal and (C) axial views.

Fig. 4. (A) Dorsal view of mass with fine and coarse hair, (B) ventral view and teeth.

M.S. Ahmadi et al. / Journal of Oral and Maxillofacial Surgery, Medicine, and Pathology 24 (2012) 59–62 61

Fig. 6. Histopathology of the mass (mature teratoma): (A) skin and related appendages (ectodermal derivatives). (B) Trabecular bone and bone marrow components (mesodermal derivatives). (C) Neural tissue (endodermal derivative).

large, they fill the oral cavity and can protrude externally, dis- tort facial anatomy and often cause respiratory embarrassment at birth. Our case was noted to have an oral mass causing respira- tory and feeding problems. Teratomas are more common in female [3,10,11,13]. Carney et al. found malignant teratoma to be more common in men in a ratio of 5:4[14].

When present during early childhood, they are usually benign [3,12,23]. As most reported cases, our patient is female and the tumour is benign. There are at least three hypotheses about the aeti- ology of these lesions[15]. It has been suggested that the tissues of a teratoma derive from totipotential cells sequestered during embryogenesis. Another theory is that germ cells may give rise to teratomas by parthenogenetic development. Finally, a teratoma may originate from incomplete formation of Siamese twins[16].

In our case, incomplete division of blastula may provide enough cells for the production of a teratoma. Tharrington et al. presenting a case of nasopharyngeal teratoma in his review of 850 patients with teratoms[4,10]. It is described in nasopharynx and orophar- ynx as a solid polyp lesion covered by skin with hair and sebaceous glands and consists mainly of fibro adipose tissue, vascular tissue, foci of smooth and striated muscle, bone or cartilage and glandu- lar tissue[17,27]. In our case the tumour was composed of a fully developed single-root tooth and disorganized mixture of mature mucin secreting glands, adipose tissue, skeletal muscle, and bone covered with skin.

The teratoma may be diagnosed antenatally on ultrasound or magnetic resonance, which permits early multidisciplinary management. The tumour presents as a cystic, and solid lesion that originates from the palate. This diagnosis is confirmed by polyhydramnios[18,22,24]. Some authors, including Andze et al.

have reported increased in fetoprotein concentrations prenatally, which are suspicious of a teratoma[19]. The differential diagnosis is limited, but includes hamartoma, dermoid cyst, and hetero- topic gastrointestinal cyst [18]. Teeth within the mass confirm teratoma.

Resection is the treatment of choice, as there may be a small chance of malignant transformation the longer they are left [20]. The neonate’s prognosis worsens as the size of the tumour increases. The ultimate prognosis of lesions with intracranial involvement is poor and operation is inappropriate[21]. Exclusion of intracranial extension is an important part of preoperative man- agement[5]. Mortality rate associated with large teratomas in the head and neck are generally high in the absence of a well-prepared resuscitation team or meticulous delivery planning to secure the airway, as the majority of these teratomas are associated with obstruction of airway and difficulty in intubation. In the patient described here, it hampered feeding and mild respiratory distress without need to emergency airway management. In our case, the tumour was easily removed. Benign teratomas may recur after exci- sion. Carney et al. discussed three cases of mature sacrococcygeal

teratomas that recurred in children [14]. This does not neces- sarily imply malignancy, although the clinician should maintain follow-up. This report describes serial imaging studies during the pregnancy including sonography, MRI, and CT with delivery by the ex utero intrapartum treatment (EXIT) procedure. Teratomas aris- ing from the oral cavity are rare in the newborn; only 13 cases have been reported in the literature. In conclusion, we described a rare case of epignathus teratoma.

References

[1] Weaver RG, Meyerhoff WL, Gates GA. Teratomas of the head and neck. Surg Forum 1976;27:539–44.

[2] Shafer WG, Hine MK, Levy BM, Tomich CE, editors. Textbook of oral pathology, 78–79. 4th ed. London: W B Saunders; 1983. p. 312–3.

[3] Kountakis SE, Minotti AM, Maillard A. Teratomas of the head and neck. Am J Otolaryngol 1994;15:292–6.

[4] Tharrington CL, Bossen EH. Nasopharyngeal teratomas. Arch Pathol Lab Med 1992;116:165–7.

[5] Vandenhaute B, Leteurtre E, Lecomte-Houcke M, Pellerin P, Nuyts JP, Cuisset JM, et al. Epignathus teratoma: report of three cases with a review of the literature.

Cleft Palate Craniofac J 2000;37(1):83–91.

[6] Lionel J, Valvoda M, Al-Abdul Hadi KA. Giant epignathus: a case report. Kuwait Med J 2004;36(3):217–20.

[7] Wiatrak BJ, Myer III CM, Bratcher GO. Report of a nasopharyngeal teratoma evaluated with magnetic resonance imaging. Arch Otolaryngol Head Neck Surg 1990;102(2):306–9.

[8] Rothschild MA, Catalano P, Urken M, Brandwein M, Som P, Norton K, et al.

Evaluation and management of congenital cervical teratoma. Case report and review. Arch Otolaryngol Head Neck Surg 1994;120(4):444–8.

[9] Okafor CI, Okafor CO, Odike MA. Congenital teratoma of the face. J Obstet Gynaecol 2004;24(7):828–9.

[10] Ferlito A, Rinaldo A. Developmental lesions of the head and neck. In: Barnes L, editor. Surgical pathology of the head and neck. 2nd ed. New York: Marcel Dekker; 2001. p. 1649–71.

[11] Cay A, Bektas D, Imamoglu M, Bahadir O, Cobanoglu Y, Sarihan H. Oral teratoma:

a case report and literature review. Pediatr Surg Int 2004;20:304–8.

[12] Anderson PJ, David DJ. Teratomas of the head and neck region. J Craniomaxillo- fac Surg 2003;31:369–77.

[13] Ulger Z, Egemen A, Karapinar B, Veral A, Apaydin F. A very rare cause of recurrent apnea: congenital nasopharygeal teratoma. Turk J Pediatr 2005;47:

266–9.

[14] Carney JA, Thompson DP, Johnson CL, Lynn HB. Teratomas in children: clinical and pathological aspects. J Pediatr Surg 1972;7:271–82.

[15] Beutel K, Partsch CJ, Janig U, Nikischin W, Suttorp M. Oral mature teratoma containing epididymal tissue in female neonate. Lancet 2001;357:283–4.

[16] Hoeffel CC, Nguyen KQ, Phan HT, Truong NH, Nguyen TS, Tran TT, et al. Fetus in fetu: a case report and literature review. Pediatrics 2000;105:1335–44.

[17] Franco V, Florena AM, Lombardo F, Restivo S. Bilateral hairy polyp of the oropharynx. J Laryngol Otol 1996;110:288–90.

[18] Takeuchi K, Masuda Y, Narita F, Kiyoshi K, Mizutori M, Maruo T. Prenatal eval- uation of bidirectional epignathus: comparison of ultrasonography and MRI.

Fetal Diagn Ther 2003;18:26–8.

[19] Andze G, Pagbe JJ, Yomi J, Mbakop A, Juimo, Edzoa T. Teratome epignathe genat benin chez le nouveau-ne: a propos d’une observation clinique exceptionelle.

J Chir 1991;131:316–21 [English].

[20] Keswani RK, Chugh TD, Dhall JC, Mehrotra GC. Epignathus: a case report. Br J Plastic Surg 1968;21:355–9.

[21] Gull I, Wolman I, Har-Toov J, Amster R, Schreiber L, Lessing JB, et al. Antenatal sonographic diagnosis of epignathus at 15 weeks of pregnancy. Ultrasound Obstet Gynecol 1990;13:271–3.

62 M.S. Ahmadi et al. / Journal of Oral and Maxillofacial Surgery, Medicine, and Pathology 24 (2012) 59–62

[22] LiechtyF K.W., Crombleholme TM. Management of fetal airway obstruction.

Semin Perinatol 1999;23(6):496–506.

[23] Sreetharan SS, Prepageran N. Benign teratoma of the nasal cavity. Med J Malaysia 2004;59:678–9.

[24] Coppit 3rd GL, Perkins JA, Manning SC. Nasopharyngeal teratomas and der- moids: a review of the literature and case series. Int J Pediatr Otorhinolaryngol 2000;52:219–27.

[25] Parvathidevi GK, Belagavi CS, Shibaprakash V, Jyothi Swaroop R. Teratoma of palatine tonsil in a neonate. Indian J Pediatr 2005;72:367.

[26] Nasir S, Aydin A, Karahan N. Auricular teratoma: report of a case and review of rare sites. Scand J Plast Reconstr Surg Hand Surg 2006;40:57–9.

[27] Brown-Kelly A. Hairy or dermoid polyp of the pharynx and nasopharynx. J Laryngol Otol 1918;33:65–70.

[28] Lalwani AK, Engel TL. Teratoma of the tongue: a case report and review of the literature. Int J Ped Otolaryngol 1992;24:261–8.

[29] Noguchi T, Jinbu Y, Itoh H, Matsumoto K, Sakai O, Kusama M. Epignathus combined with cleft palate, lobulated tongue, and lingual hamartoma: report of a case. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 2006;101:

481–6.

[30] Vandenhaute B, Leteurtre E, Lecomte-Houcke M, Pellerin P, Nuyts JP, Cuisset JM, et al. Epignathus teratoma: report of three cases with a review of the literature.

Cleft Palate Craniofac J 2000;37:83–91.
