Dilated Left Atrium and Pulmonary Veins in Patients with Calcified Coronary Artery: A Potential Contributor to the Genesis of Atrial Fibrillation

Dilated Left Atrium and Pulmonary Veins in Patients with Calcified Coronary Artery: A Potential Contributor to the Genesis

of Atrial Fibrillation

NAN-HUNG PAN, M.D.,

HSUAN-MING TSAO, M.D., † NEN-CHUNG CHANG, M.D., Ph.D.,

CHIH-MING LEE, M.D., ‡ YI-JEN CHEN, M.D., Ph.D.,§ and SHIH-ANN CHEN, M.D.¶

From the^∗Division of Cardiovascular Medicine, Taipei Medical University Hospital, Taipei, Taiwan;†I-Lan Hospital, Taiwan;

‡Department of Radiology, Taipei Medical University Hospital, Taipei, Taiwan; §Graduate Institute of Clinical Medicine, Taipei Medical University and Division of Cardiovascular Medicine, Taipei Medical University-Wan Fang Hospital, Taiwan; and¶National Yang-Ming

University, School of Medicine; Division of Cardiology and Cardiovascular Research Center, Veterans General Hospital-Taipei, Taipei, Taiwan

Ischemic Remodeling of Left Atrium and Pulmonary Vein.

Methods and Results: A total of 166 patients undergoing MDCT for general check-up (n= 128, 77%) or suspected CAD (n= 38, 23%) were enrolled and divided into a control (calcium score = 0, n = 60), medium calcium score (calcium score= 100∼400, n = 47), and high calcium score (calcium score >400, n = 59) groups. Diameters and areas of the LA, left atrial appendage (LAA), and PVs were measured by MDCT. The high calcium score group had significantly larger PVs diameters, LAA orifice area (1.9± 1.4 cm², 0.9± 0.5 cm², 0.8± 0.4 cm², P< 0.005), LA anterior-posterior distance (32.2 ± 6.8 mm, 30.4 ± 6.5 mm, 27.3± 6.0 mm, P < 0.05), and transverse distance (52.6 ± 7.3 mm, 50.2 ± 9 mm, 49.5 ± 4.6 mm, P< 0.05) than the medium calcium score and control groups. Six (3.6%) patients with paroxysmal AF had higher calcium scores and larger diameters of LA, LAA, and PVs than those (96.4%) without paroxysmal AF. Two patients in the high calcium score group had calcified PVs localized to the right upper and left upper PVs. The incidence of calcified PVs was 1.2% for the total patients and 3.3% for the high calcium score patients.

Conclusion: In the presence of high calcium scores in this patient population, the LA, LAA, and PVs were enlarged. (J Cardiovasc Electrophysiol, Vol. 20, pp. 153-158, February 2009)

coronary artery calcification, atrial fibrillation, pulmonary vein

Introduction

Atrial fibrillation (AF) is the most common cardiac ar- rhythmia observed in clinical practice and induces cardiac dysfunction and strokes.^1,2Myocardial ischemia is an impor- tant risk factor of AF.^3,4Coronary artery disease (CAD) can induce myocardial dysfunction with an increase of ventricu- lar filling pressure, which is closely reflected by enlarged left atrium (LA).^5,6 Atrial myocardial perfusion abnormalities may have a role in AF.⁷Moreover, the elevated ventricular filling pressure may increase atrial remodeling and stretch,

The present work was supported by the Center of Excellence for Clinical Trial and Research in Wan Fang Hospital (DOH-TD-B-111-002) and grants NSC 95-2314-B-016-015, NSC 95-2314-B-038-026, NSC 96-2628-B-038- 012-MY3, NSC 96-2314-B-010-006, and V95A-008.

Address for correspondence: Yi-Jen Chen, M.D., Ph.D., Division of Cardio- vascular Medicine, Taipei Medical University-Wan Fang Hospital 111, Hsin- Lung Road, Sec. 3, Taipei, Taiwan. Fax: 886-2-29339378, 886-2-28735656;

E-mail: a9900112@ms15.hinet.net

Manuscript received 10 March 2008; Revised manuscript received 10 July 2008; Accepted for publication 2 June 2008.

doi: 10.1111/j.1540-8167.2008.01290.x

which may further produce electrical changes with the en- hancement of the inhomogeneity of the atrial conduction and refractoriness.^8,9Those findings suggest that myocardial is- chemia can induce electrical and structural remodeling of AF substrate, which can facilitate AF maintenance. Pulmonary veins (PVs) are the main sources of ectopic beats with the initiation of paroxysmal AF or foci of ectopic atrial tachycar- dia and focal AF.¹⁰ However, limited information has been available on the effects of myocardial ischemia on the struc- tural changes in the PVs. Since stretched PV may enhance the arrhythmogenesis and induce more AF,^11,12it should be very important to study the relationship between CAD and PV structures. In addition, it is not clear whether the PVs could also become calcified as is found in coronary arteries.

Calcified coronary arteries are a marker of coronary atherosclerosis and are associated with a higher incidence of coronary events.^13,14 A previous study has shown that high coronary calcium score patients have an increased left ventricular (LV) wall thickness and LV diastolic dysfunc- tion in African-Americans.¹⁵ Because myocardial dysfunc- tion can alter the atrial structure, a highly calcified coro- nary artery may produce an abnormal atrial and PV structure that could facilitate AF genesis. Multidetector computed to- mography (MDCT) provides better and reliable imaging of smaller cardiac structures such as vascular structures and

that MDCT provided accurate and detailed imaging of the LA and PVs.²⁰ Therefore, the purpose of this study was to investigate whether larger left atrium (AF substrate) and PVs (AF initiators) were seen by MDCT scans in those patients with higher coronary calcium scores.

Methods Patient Selection

This study received IRB approval and enrolled 166 con- secutive individuals (110 men and 56 women with a mean age of 58± 17 years) for 64-row scan MDCT. The patients were evaluated because of suspected CAD in 38 (23%) pa- tients and for general checkup in 128 (77%) patients.^21,22Six patients (3.6%) had a history of paroxysmal AF (5 patients for general checkup and 1 patient for suspected CAD), while 160 patients (96.4%) did not have paroxysmal AF. The AF was documented by 12-lead ECG or ambulatory ECG. For the reliability and accuracy of the results of the MDCT, we did not include the patients with persistent or permanent AF.

All patients had sinus rhythm during the MDCT examina- tions. Each participant underwent a medical history, weight, height, blood pressure, and laboratory assessment. The sig- nificant coronary artery stenosis was defined as over 50%

luminal obstruction by MDCT calculation.²³ We grouped the patients according to the calcium score data.²² There were 40 patients with a zero calcium score (control group), 37 patients with a 100∼400 calcium score (medium calcium score group), and 49 patients with a>400 calcium score (high calcium score group). The patients with renal function impairment (Cr>2.0 mg/dL) were excluded.

Computed Tomography

The patients underwent a 64-row scan (LightSpeed VCT, GE Healthcare, USA) using an EKG synchronized tube modulation. The patients with a heart rate>70 bpm were given a single oral dose of propranolol (10∼40 mg) at least 40 minutes before the examination. Images were recon- structed retrospectively in the diastolic phase (at 60% of the start of the RR interval). Nonionic contrast medium was given in a test dose of 250 mL. The total calcium score was calculated as the sum of the individual lesion scores in all coronary arteries as the following formula: slice thickness

×  (area cofactor). To avoid any interobserver variability, all CT scans were scored by an experienced radiologist that measured the calcium score.

Measurement of the Left Atrium and PV

The left inferior, left superior, right inferior, right superior PV (LI, LS, RI, RSPV) diameters were measured by the max- imal transverse diameter of the four PV trunk orifices by a virtual endoscopic view. The left atrium (LA) diameters were measured by the maximal anterior-posterior distance (LA1) and maximal transverse distance (LA2). The LA1 was mea- sured in the oblique sagittal view and LA2 was measured in the oblique coronal view from the LSPV to the RSPV. The orifice of the LA appendage (LAA) was defined as the deflec- tion between the LAA and LA free wall. The largest diameter and area were measured in the oblique sagittal view where the LAA area was traced. The LV wall thickness was measured

muscle in the end-diastolic phase in the four-chamber axial view.

Statistical Analysis

Continuous variables are expressed as the mean±SD. The comparisons between the control, medium, and high calcium score groups were analyzed by a one-way ANOVA with a post hoc Tukey test. Nominal variables were compared by a Chi-square analysis with a Yates correction or Fisher’s exact test. A P value less than 0.05 was considered to be statistically significant.

Results Patient Characteristics

The age, gender distribution, incidence of hypertension, diabetes, dyslipidemia, smoking and CAD family history were similar among the three groups (Table 1). Otherwise, the CAD vessel numbers found by results of MDCT were significantly different among the three groups (Table 1).

Structural Differences among Different Calcium Score Patients

The LAA orifice was oval shaped in all subjects according to the MDCT oblique sagittal section and endoscopic view.

The largest area of the LAA orifice was significantly larger in the high calcium score group than in the other two groups (Table 1 and Fig. 1). Moreover, the high calcium score group had a larger LA1 and LA2 than the zero calcium score group (Table 1 and Fig. 2). The LV anterior and posterior walls were also significantly thicker in the high calcium score group than the other two groups (Table 1 and Fig. 2).

The high calcium score group had larger LSPV, RSPV, LIPV, and RIPV diameters than the other two groups (Table 1 and Fig. 1). Compared with the zero calcium score group, the high calcium score group had an increased PV diameter by 12% for LSPV, by 19% for RSPV, by 16% for LIPV, and by 17% for RIPV. In addition, two patients were found to have calcified PVs (Fig. 3). The incidence of calcified PVs was 1.2% for the total patients and 3.3% for the high calcium score patients. The two patients with calcified PVs were older (age, 76 and 73 years) and had very high calcium scores (2,684 and 2,420) with significant three-vessel CAD. Both the two patients had diabetes, history of smoking, hypertension, dys- lipidemia, and family history of CAD. In contrast, none of the patients in the control group or medium calcium score group had calcified PVs. The two patients with calcified PVs had significantly enlarged LAA (orifice area, 3.8 cm² and 4.6 cm²), LA (anterior-posterior distance, 39.4 mm and 38.7 mm; transverse distance, 58.3 mm and 61.5 mm), LSPV (12.6 mm and 12.4 mm), RSPV (11.2 mm and 12.4 mm), LIPV (11.7 mm and 12.7 mm), and RIPV (12.6 mm and 12.6 mm). The LAA orifice, LA diameter, and four PV di- ameters were beyond the average data from the high calcium score patients. The calcified PVs were located at the right up- per PV (11 mm from the orifice) and left upper PV orifices, respectively.

Moreover, as the results shown in Table 2, the patients with paroxysmal AF have higher calcium scores (3,064, 2,684,

TABLE 1 Baseline Characteristics

Calcium Score 0 (n= 60) 100∼400 (n = 47) >400 (n = 59) P Value

Calcium score average 0 261± 84^∗ 1254± 599^∗,† <0.001

Age 57± 8 59± 14 60± 13 NS

Male 38 (63.3%) 30 (63.8%) 42 (71.2%) NS

Hypertension 38 (63.3%) 36 (76.6%) 38 (64.4%) NS

Diabetes 8 (13.3%) 11 (23.4%) 14 (23.7%) NS

Dyslipidemia 6 (10%) 11 (23.4%) 10 (16.9%) NS

CAD family history 16 (26.7%) 20 (42.6%) 22 (37.3%) NS

Smoking 35 (58.3%) 36 (76.6%) 41 (69.5%) NS

CAD vessel number by MDCT results

One-vessel disease 13 (21.7%) 17 (36.2%) 7 (11.9%)^† <0.05

Two-vessel disease 1 (1.7%) 7 (14.9%)^∗ 16 (27.1%)^∗ <0.001

Three-vessel disease 0 7 (14.9%)^∗ 24 (40.7%)^∗,† <0.001

LA1 (mm) 27.3± 6 30.4± 6.5^∗ 32.2± 6.8^∗ <0.001

LA2 (mm) 49.5± 4.6 50.2± 9 52.6± 7.3^∗ <0.05

LAA orifice

Diameter (mm) 13.6± 0.4 13.8± 0.8 14± 1.2^∗ <0.05

Area (cm²) 0.8± 0.4 0.9± 0.5 1.9± 1.4^∗,† <0.001

LSPV (mm) 8.9± 1.1 9.2± 1.3 10± 1.8^∗,† <0.001

RSPV (mm) 9.0± 1.4 9.9± 1.5^∗ 10.7± 2.1^∗,† <0.001

LIPV (mm) 9.0± 1.3 10± 1.6^∗ 10.4± 2.1^∗,† <0.001

RIPV (mm) 9.6± 1.0 10.2± 2.2 11.2± 2.6^∗,† <0.001

LV wall thickness (mm) 8.3± 1.4 9± 1.5 13.8± 2.0^∗,† <0.001

CAD = coronary artery disease; LAA = left atrial appendage; LV = left ventricle; LA1 = anterior-posterior distance; LA2 = transverse distance;

LI/LS/RI/RSPV= left inferior/left superior/right inferior/right superior pulmonary vein; NS = not significant. P value = comparisons among the three groups.^∗P< 0.05 versus calcium score 0, †P < 0.05 versus calcium score 100∼400.

1,176, 1,104, 1,021, and 680) and larger diameters of LA, LAA, and PVs than those without paroxysmal AF.

Discussion

The genesis of AF arises from the changes in the AF sub- strate (atrium) and initiators (PVs). This study found that highly calcified coronary arteries were seen on MDCT scans with larger PVs and larger LA. This finding suggests a re- lationship of CAD with dilated LA and PVs. The increase of atrium and PV size would facilitate the genesis of atrial reentrant circuits.²⁴Moreover, as compared with those with- out paroxysmal AF, our paroxysmal AF patients had sig-

Figure 1. Intraatrial oblique sagittal views during the multidetector computed tomography in the patients in the con- trol (panel A), medium calcium score (panel B), and high calcium score (panel C) groups. The largest diameter (LS) of the left superior pulmonary vein and the largest diameter (LI) of left inferior pul- monary vein (LI) were measured using the virtual intraatrial view. The left atrial ap- pendage (LAA) orifice area and diameter were measured using the oblique sagittal view. Panel A: LS= 8 mm, LI = 7.5 mm, LAA orifice diameter= 12.4 mm, and LAA orifice area= 0.83 cm². Panel B: LS= 9.5 mm, LI= 9.3 mm, LAA = 13.6 mm, and LAA area= 0.98 cm². Panel C: LS= 11 mm, LI= 11.6 mm, LAA = 15.5 mm, and LAA area= 1.9 cm².

nificantly higher calcium scores with larger LA, LAA, and four PVs. However, the majority of patients who had high calcium scores did not have paroxysmal AF. Because the pa- tients with paroxysmal AF had significantly enlarged PVs, LA, and LAA, it is possible that the PVs and LA were not dilated enough to induce AF in the high calcium score pa- tients without paroxysmal AF. These findings also suggest a potential relationship of AF and high calcium scores. Sim- ilarly, Schwartzman et al. also used MDCT to find that AF patients have a larger LA and PVs than non-AF patients.²⁰ Since dilated LA and PVs may facilitate the occurrence of AF, the patients with high calcium scores should cautiously prevent progressively structural changes of atrium and PVs.

Figure 2. Oblique sagittal view (upper panels) and oblique coronal (lower pan- els) view during the multidetector com- puted tomography in the patients in the control (panel A), medium calcium score (panel B), and high calcium score (panel C) groups. The LA1 was measured in the oblique sagittal view using the anterior- posterior largest distance; the LA2 was measured in the oblique coronal view from the left superior to right superior distance.

Panel A: LA1= 30 mm, LA2 = 47 mm.

Panel B: LA1= 33 mm, LA2 = 50 mm.

Panel C: LA1= 36 mm, LA2 = 59 mm.

In addition to the treatment of underlying CAD and con- trol of multiple atherosclerosis risk factors, the patients with high calcium scores may consider angiotensin-converting enzyme inhibitors or angiotensin receptor blockers for hyper- tension control. Besides, these patients should receive statins for treating hypercholesteremia.²⁵

Mechanoelectrical feedback has been found to play an important role in the pathophysiology of AF.^11,12 Previous studies have shown that enlarged PVs are associated with an enhanced PV arrhythmogenic activity. Through in vitro

Figure 3. Multidetector computed to- mography of a calcified left superior pul- monary vein (LSPV) in a patient with a high calcium score (2684). Panel A shows that calcified lesions (↑) were found in the coronal view. Panel B shows calcified lesions in the axial view. Panel C shows calcified lesion in the angiographic view of left atrium. Panel D shows the calcified coronary artery lesions in angiographic view.

experiments, stretch was also found to increase the PV elec- trical activity and to induce AF.^11,12The mechanisms may be caused by an increasing PV firing and generation of triggered activity or reentrant circuits. In this study, we have found that high calcium scores were associated with dilated PVs. Simi- larly, Herweg et al. found that hypertension and hypertensive heart disease are associated with PV dilation, which supports the role of stretch in the PV arrhythmogenesis.²⁶The PV di- lation could increase the PV arrhythmogenesis and provoke AF. Therefore, the association of high calcium score and

TABLE 2

Patients and Structural Characteristics between PAF and Non-PAF Groups

Non-PAF PAF

(n= 160) (n= 6) P Value

Calcium score 478± 614 1621± 992 <0.001

Age 59± 12 68± 4 NS

Male 105 (66%) 5 (83%) NS

Hypertension 106 6 NS

Diabetes 28 3 NS

Dyslipidemia 23 4 <0.005

CAD family history 54 4 NS

Smoking 107 5 NS

LA1 (mm) 30.7± 6.3 39.4± 4.4 <0.001

LA2 (mm) 50.8± 7.2 61.2± 3.7 <0.001

LAA orifice

Diameter (mm) 13.7± 1.0 15.6± 1.3 <0.001

Area (cm²) 1.2± 0.8 3.2± 1.0 <0.001

LSPV (mm) 9.4± 1.2 13.1± 2.6 <0.05

RSPV (mm) 9.3± 1.3 12.9± 2.7 <0.05

LIPV (mm) 9.6± 1.5 13.7± 2.6 <0.005

RIPV (mm) 9.7± 1.5 13.2± 2.9 <0.001

LV wall thickness (mm) 11.9± 1.5 14.2± 1.6 <0.05 CAD= coronary artery disease; LAA = left atrial appendage; LV = left ventricle; LA1= anterior-posterior distance; LA2 = transverse distance;

LI/LS/RI/RSPV = left inferior/left superior/right inferior/right superior pulmonary vein; NS= not significant; PAF = paroxysmal atrial fibrillation.

dilated PVs may account for the high incidence of AF in the CAD patients in part.

In this study, for the first time, we demonstrated the pres- ence of calcified PVs in the patients with high calcium scores.

Arterial calcification is a common picture in atherosclerosis found in patients with hypertension, aging, metabolic dis- eases, and chronic renal failure.^27,28 However, studies on venous calcification are limited. Only chronic renal failure patients have been reported in the literature to have calci- fied PVs, and the mechanism is not clear.²⁹In our study, we found that 3.3% of the high calcium score patients had cal- cified upper PVs with a normal renal function. The patients with calcified PVs were older and had very high calcium scores, dyslipidemia, diabetes, hypertension, and family his- tory of CAD. Therefore, multiple atherosclerosis risk factors seem to contribute to the occurrence of PV calcifications.

Vascular calcification could impair the endothelial function with an increased susceptibility to stretch and mechanoelec- trical feedback. Nevertheless, only two patients were found to have calcified PVs; thus, it is difficult to make any conclu- sions about why and where the calcified lesions were found by the current study. Moreover, it is not clear whether PV calcifications may have a role in the increased prevalence of AF in chronic renal failure patients.^30,31

The data in this study should be interpreted with caution due to the limitations of this study. First, this study did not include persistent/permanent AF patients. We did not know whether chronic AF patients had higher calcium scores. How- ever, our study has found that paroxysmal AF patients were associated with high calcium scores. Second, we did not know how many patients would develop AF and the electro- physiological correlations were not available. Thus, at best we can suggest that the presence of CAD and atherosclero- sis, exemplified by higher calcium scores, relates indirectly to the structural findings previously associated with the de- velopment of AF.

Conclusion

In the presence of high calcium scores in this patient pop- ulation, the LA, LAA, and PVs were significantly enlarged.

References

1. Fenberg WM, Blackshear JL, Laupacis A, Kronmal R, Hart RG: Preva- lence, age distribution, and gender of patients with atrial fibrillation.

Analysis and implications. Arch Intern Med 1995;155:469-473.

2. Kannel WB, Abbott RD, Savage DD, McNamara PM: Epidemiologic features of chronic atrial fibrillation: The Framingham study. N Engl J Med 1982;306:1018-1022.

3. Krahn AD, Manfreda J, Tate RB, Mathewson FA, Cuddy TE: The nat- ural history of atrial fibrillation: Incidence, risk factors, and prognosis in the Manitoba follow-up study. Am J Med 1995;98:476-484.

4. Psaty BM, Manolio TA, Kuller LH, Kronmal RA, Cushman M, Fried LP, White R, Furberg CD, Rautaharju PM: Incidence of and risk factors for atrial fibrillation in older adults. Circulation 1997;96:2455-2461.

5. Tsang TS, Barnes ME, Gersh BJ, Bailey KR, Seward JB: Left atrial volume as a morphophysiologic expression of left ventricular diastolic dysfunction and relation to cardiovascular risk burden. Am J Cardiol 2002;90:1284-1289.

6. Apstein CS, Grossman W: Opposite initial effects of supply and demand ischemia on left ventricular diastolic compliance the ischemia-diastolic paradox. J Mol Cell Cardiol 1987;19:119-128.

7. Skalidis EI, Hamilos MI, Karalis IK, Chlouverakis G, Kochiadakis GE, Vardas PE: Isolated atrial microvascular dysfunction in patients with lone recurrent atrial fibrillation. J Am Coll Cardiol 2008;51:2053-2057.

8. Douglas PS: The left atrium a biomarker of chronic diastolic dysfunc- tion and cardiovascular disease risk. J Am Coll Cardiol 2003;42:1206- 1207.

9. Li D, Fareh S, Leung TK, Nattel S: Promotion of atrial fibrillation by heart failure in dogs atrial remodeling of a different sort. Circulation 1999;100:87-95.

10. Chen SA, Hsieh MH, Tai CT, Tsai CF, Prakash VS, Yu WC, Hsu TL, Ding YA, Chang MS: Initiation of atrial fibrillation by ectopic beats originating from the pulmonary veins: Electrophysiological char- acteristics, pharmacological responses, and effects of radiofrequency ablation. Circulation 1999;100:1879-1886.

11. Kalifa J, Jalife J, Zaitsev AV, Bagwe S, Warren M, Moreno J, Beren- feld O, Nattel S: Intra-atrial pressure increases rate and organization of waves emanating from the superior pulmonary veins during atrial fibrillation. Circulation 2003;108:668-671.

12. Chang SL, Chen YC, Chen YJ, Wangcharoen W, Lee SH, Lin CI, Chen SA: Mechanoelectrical feedback regulates the arrhythmogenic activity of pulmonary veins. Heart 2007;93:82-88.

13. Mohlenkamp S, Lehmann N, Schmermund A, Pump H, Moebus S, Baumgart D, Seibel R, Gronemeyer DH, Jockel KH, Erbel R:

Prognostic value of extensive coronary calcium quantities in symp- tomatic males–a 5-year follow-up study. Eur Heart J 2003;24:845- 854.

14. Wayhs R, Zelinger A, Raggi P: High coronary artery calcium scores pose an extremely elevated risk for hard events. J Am Coll Cardiol 2002;39:225-230.

15. Tong W, Lima JA, Lai H, Celentano DD, Dai S, Lai S: Relation of coronary artery calcium to left ventricular mass in African-Americans.

Am J Cardiol 2004;93:490-492.

16. Nieman K, Cademartiri F, Lemos PA, Raaijmakers R, Pattynama PM, de Feyter PJ: Reliable noninvasive coronary angiography with fast submillimeter multislice spiral computed tomography. Circulation 2002;106:2051-2054.

17. Mollet NR, Cademartiri F, Nieman K, Saia F, Lemos PA, McFadden EP, Pattynama PM, Serruys PW, Krestin GP, de Feyter PJ: Multislice spiral computed tomography coronary angiography in patients with stable angina pectoris. J Am Coll Cardiol 2004;43:2265-2270.

18. Mollet NR, Cademartiri F, Nieman K, Saia F, Lemos PA, McFadden EP, Serruys PW, Krestin GP, de Feyter PJ: Noninvasive assessment of coronary plaque burden using multislice computed tomography. Am J Cardiol 2005;95:1165-1169.

19. Ropers D, Baum U, Pohle K, Anders K, Ulzheimer S, Ohnesorge B, Schlundt C, Bautz W, Daniel WG, Achenbach S: Detection of coro- nary artery stenoses with thin-slice multi-detector row spiral computed tomography and multiplanar reconstruction. Circulation 2003;107:664- 666.

left atrium and distal pulmonary vein morphology using multidi- mensional computed tomography. J Am Coll Cardiol 2003;41:1349–

1357.

21. Pan NH, Tsao HM, Chang NC, Chen YJ, Chen SA: Aging dilates atrium and pulmonary veins: Implications for the genesis of atrial fibrillation.

Chest 2008;133:190-196.

22. Pan NH, Yang HY, Hsieh MH, Chen YJ: Coronary calcium score from multislice computed tomography correlates with QT dispersion and left ventricular wall thickness. Heart Vessels 2008;23:155-160.

23. Hoffmann U, Moselewski F, Cury RC, Ferencik M, Jang IK, Diaz LJ, Abbara S, Brady TJ, Achenbach S: Predictive value of 16-slice multidetector spiral computed tomography to detect significant ob- structive coronary artery disease in patients at high risk for coro- nary artery disease: Patient-versus segment-based analysis. Circulation 2004;110:2638-2643.

24. Huang BH, Wu MH, Tsao HM, Tai CT, Lee KT, Lin YJ, Hsieh MH, Lee SH, Chen YJ, Kuo JY, Chen SA: Morphology of the thoracic veins and left atrium in paroxysmal atrial fibrillation initiated by su- perior caval vein ectopy. J Cardiovasc Electrophysiol 2005;16:411–

417.

atrial fibrillation. Curr Opin Cardiol 2007;22:450-457.

26. Herweg B, Sichrovsky T, Polosajian L, Rozenshtein A, Steinberg JS:

Hypertension and hypertensive heart disease are associated with in- creased ostial pulmonary vein diameter. J Cardiovasc Electrophysiol 2005;16:2-5.

27. Tohno S, Tohno Y: Age-related differences in calcium accumulation in human arteries. Cell Mol Biol (Noisy-le-grand) 1998;44:1253-1263.

28. El-Abbadi M, Giachelli CM: Mechanisms of vascular calcification.

Adv Chronic Kidney Dis 2007;14:54-66.

29. Koroglu M, Chen PS, Oto A, Koroglu BK: Left atrial, pulmonary vein and dural calcification in a patient with arrhythmia and chronic renal failure. JBR-BTR 2005;88:78-79.

30. Das M, Aronow WS, McClung JA, Belkin RN: Increased prevalence of coronary artery disease, silent myocardial ischemia, complex ventric- ular arrhythmia, atrial fibrillation, left ventricular hypertrophy, mitral annular calcium, and aortic valve calcium in patient with chronic renal insufficiency. Cardiol Rev 2006;14:14-17.

31. Korantzopouls P, Kokkoris S, Liu T, Protopsaltis I, Li G, Goudevenos JA: Atrial fibrillation in end-stage renal disease. PACE 2007;30:1391- 1397.
