doi: 10.1111/j.1834-7819.2008.01080.x
Abfraction: separating fact from fiction
JA Michael,* GC Townsend,* LF Greenwood,* JA Kaidonis*
*School of Dentistry, The University of Adelaide, South Australia.
ABSTRACT
Non-carious cervical lesions involve loss of hard tissue and, in some instances, restorative material at the cervical third of the crown and subjacent root surface, through processes unrelated to caries. These non-carious processes may include abrasion, corrosion and possibly abfraction, acting alone or in combination. Abfraction is thought to take place when excessive cyclic, non-axial tooth loading leads to cusp flexure and stress concentration in the vulnerable cervical region of teeth. Such stress is then believed to directly or indirectly contribute to the loss of cervical tooth substance. This article critically reviews the literature for and against the concept of abfraction.
Although there is theoretical evidence in support of abfraction, predominantly from finite element analysis studies, caution is advised when interpreting results of these studies because of their limitations. In fact, there is only a small amount of experimental evidence for abfraction. Clinical studies have shown associations between abfraction lesions, bruxism and occlusal factors, such as premature contacts and wear facets, but these investigations do not confirm causal relationships.
Importantly, abfraction lesions have not been reported in pre-contemporary populations.
It is important that oral health professionals understand that abfraction is still a theoretical concept, as it is not backed up by appropriate clinical evidence. It is recommended that destructive, irreversible treatments aimed at treating so-called abfraction lesions, such as occlusal adjustment, be avoided.
Key words: Abfraction, non-carious cervical lesions, stress, tooth wear.
Abbreviations and acronyms: FEA = finite element analysis; GICs = glass ionomer cements; NCCLs = non-carious cervical lesions;
RMGICs = resin-modified GICs.
(Accepted for publication 24 July 2008.)
INTRODUCTION
Non-carious cervical lesions (NCCLs) involve loss of hard tissue, and in some instances, restorative material at the cervical third of the crown and subjacent root surface, through processes unrelated to caries.1 Although it is accepted that NCCLs have a multifac- torial aetiology, the relative contributions of the various processes remain unclear. Currently, the most widely accepted causes of NCCLs are abrasion and corro- sion, although several alternative theories have been proposed.
Abfraction, a biomechanically-based theory, is one of the most discussed and controversial of these alterna- tive theories. Grippo2first used the term abfraction to refer to a process of cervical tooth structure loss, based on work completed by McCoy3and Lee and Eakle.4
Recent reviews of this field lack detail in particular areas and have not focused on the current clinical implications of abfraction. As an increasing number of articles exploring the validity of abfraction are pub- lished, it is essential that clinicians understand where
abfraction stands in current clinical practice. The aim of this article was to critically review the literature for and against abfraction.
The development of the concept of abfraction
Abfraction is said to take place when excessive cyclic, non-axial tooth loading leads to cusp flexure and concentration of stresses in the vulnerable cervical region of teeth. Such stresses are then believed to directly contribute to tooth structure loss, by overcom- ing bonds between hydroxyapatite crystals, or indi- rectly lead to tooth structure loss by making the tooth more susceptible to future breakdown via further abfraction and other processes (e.g., abrasion and corrosion).4–6
The concept that occlusal loading could cause cervical stress, with resultant loss of cervical tooth structure, began evolving in the late 1970s.3,4,7 The process was eventually termed abfraction by Grippo2in 1991.
Common to all accounts of this hypothesis was a lack of sound evidence and a number of errors in logic.
ª 2009 Australian Dental Association
Although the loss of enamel was addressed, no explanation was given about how dentine could be lost during this process.3,4,7 As dentine has a different structure from enamel and can withstand tensile stress better than enamel, this omission represents a major flaw in the concept of abfraction.8
Typically, abfraction is said to result from forces associated with mastication, swallowing and malocclu- sion. However, Gibbs et al.9found that occlusal forces during swallowing and mastication are only approxi- mately 40 per cent of maximal bite force. Suit et al.10 reported that tooth contact occurs on average for only 194 milliseconds during mastication and for 683 milli- seconds during swallowing. Considering that the dura- tion and magnitude of forces during bruxism are much greater than those during functional activity, it is more likely that parafunction would result in such a process rather than function.11 Interestingly, logic suggests the non-axial forces that result from tooth grinding (Fig 1), would actually cause compression on the buccal cervical surfaces of the teeth involved. How would compression produce a breakdown in this tooth structure?
Terminology
Throughout the literature there is misunderstanding about the most appropriate terminology to use when discussing abfraction. For example, Miller et al.12state that NCCLs are also called abfractions. This statement is misleading because NCCLs have a variety of possible causes, of which abfraction is only one. In addition, the aetiology of NCCLs is multifactorial, so while abfrac-
tion may be the primary aetiological agent, it must be understood that other factors may also play a part. This statement applies to all the following aetiological classifications of NCCLs described in this article. The correct use of terminology is essential in this confusing area of dentistry.
While on the topic of confused terminology, it is important to address two other misconceptions. Tradi- tionally, the dental profession has defined erosion as tooth wear resulting from prolonged exposure to low pH substances of non-bacterial origin. However, this process should be termed ‘‘corrosion’’ as it results from the action of a chemical (i.e., acid). In contrast, the term
‘‘erosion’’ refers to an abrasive process resulting from the dynamic contact of a solid, liquid or gas with a surface (e.g., water waves degrading a limestone coastline).13 Erosion is a physical process, whereas corrosion is a chemical process.
It is also important to differentiate the term ‘‘stress- corrosion’’ from ‘‘abfraction’’. Stress-corrosion refers to the synergistic effects of stress and corrosion acting simultaneously.13For example, this may occur when a tooth is heavily loaded in an acidic environment.
Currently, there is only limited research exploring the role of stress-corrosion in NCCL development.
Characteristics of abfraction lesions
Lee and Eakle4 first described the characteristics of lesions that may result from tensile stresses. They concluded that an abfraction lesion should be located at or near the fulcrum in the region of greatest tensile stress concentration, be typically wedge-shaped, and display a size proportional to the magnitude and frequency of tensile force application (Fig 2). Interest- ingly, Lee and Eakle4proposed that the direction of the lateral force(s) acting on a tooth would determine the location of the lesion. For example, if there were two or more lateral forces the result would be an NCCL composed of two or more overlapping wedge-shaped NCCLs. They acknowledged that local factors, such as abrasion and corrosion, might modify the appearance of NCCLs related to tensile stresses but did not expand on this speculation. The descriptions of Lee and Eakle4 have inherent limitations, as they were not based on
Fig 1. Diagrammatic representation of second premolars and their supporting structures engaged in tooth grinding. The non-axial forces
produced as a result of tooth grinding may produce unfavourable stresses in the cervical region of the teeth, potentially leading to the development of NCCLs. Interestingly, logic suggests that with tooth grinding in a buccal direction, the buccal cervical regions would be in
compression, while the lingual cervical regions would be in tension.
Fig 2. Proximal view of a mandibular central incisor demonstrating a wedge-shaped NCCL (located within the white box).
ª 2009 Australian Dental Association
direct experimental or clinical evidence. Laboratory studies are needed to attempt to produce NCCLs through abfraction to validate such descriptions.
It should be reiterated that not all wedge-shaped NCCLs necessarily result from abfraction. Abrasion, which results from prolonged dynamic contact of a tooth with an exogenous substance, such as a tooth- brush with dentifrice, is also a widely accepted cause of wedge-shaped NCCLs.14 There is also the possibility that other, yet to be discovered, processes contribute to the formation of wedge-shaped NCCLs. Sognnaes et al.15 observed extracted teeth that exhibited wedge- shaped NCCLs within silicate and amalgam restora- tions. This phenomenon could result from abrasion, but is unlikely to be explained by abfraction because the properties of amalgam and silicate restorations are notably different to those of dental hard tissues.
NCCLs in pre-contemporary populations
An important epidemiological finding relating to abfraction is the lack of NCCLs observed in pre- contemporary populations. NCCLs have not been observed in studies investigating their prevalence in ancient American skulls or prehistoric and historic skeletal remains from the south of France.16,17 Inter- proximal grooving has been observed in the cervical regions of teeth in pre-contemporary Australian Aboriginals but the lesions result from task activity (passing animal tendon interproximally between teeth) and are not observed in contemporary populations.18 NCCLs unrelated to task activity have not been observed in pre-contemporary Australian Aboriginals.19 There is a high prevalence of occlusal wear faceting observed in pre-contemporary Australian Aborigi- nals.20Many of these wear facets can only be matched between opposing teeth in extreme mandibular posi- tions, supporting a parafunctional aetiology.20 Heavy occlusal loading of teeth in Australian Aboriginals resulted in non-axial forces large enough to cause the movement of adjacent teeth against one another, leading to interproximal tooth wear.21 However, despite the presence of occlusal forces that one would expect might lead to abfraction, no lesions have been found. Absence of abfraction lesions in these circum- stances, particularly in an environment where there was also no toothbrush abrasion and little corrosion, provides strong evidence against the concept that abfraction can be caused by occlusal loading alone.
Theoretical evidence of abfraction
Finite element analysis (FEA) is a numerically-based computer modelling method that can be used to improve understanding of complicated mechanical problems, such as the stresses involved with tooth
loading. FEA involves breaking down a complex problem into numerous simple elements which, using appropriate formulae and data, are solved individually.
Individual solutions of each element are combined to enable an overall model to be developed. FEAs can be either two- or three-dimensional.18 A number of authors have used FEAs to investigate the validity of abfraction and Table 1 summarizes the outcomes of several of these studies. When considering the results of this research, the limitations of FEA as a means of investigating abfraction should be considered.
Rees23 correctly acknowledged the limitations of using two-dimensional FEA to investigate three-dimen- sional objects such as teeth. An important advantage of three-dimensional FEA, as pointed out by Rees,24 is that torsional stress can be measured. As such, three- dimensional FEAs allow more realistic simulations to be developed. However, many of the FEAs investi- gating abfraction have used two-dimensional models (Table 2).
Researchers have also used different force magni- tudes in their FEA models, ranging from 100 to 500 newtons, thereby making comparisons between FEA studies problematic (Table 2).
The properties allocated to the materials under investigation are critical to the validity of FEAs, since each element is assigned specific values that affect the results. Different researchers have assumed markedly different physical properties of dental tissues, such as enamel.22 Some have considered enamel to be an isotropic material in which properties are similar in all directions (Table 2).24,25 However, Spears26 pro- vided evidence that enamel should be considered to be anisotropic, rather than isotropic, as it is suspected of having different physical properties in different directions. This is an important issue because when Table 1. Summary of the outcomes of FEA studies related to abfraction
Reference(s) Conclusions
Rees23 Eccentrically loaded, restored premolars demonstrated higher stresses in the cervical region compared with similarly loaded unrestored premolars.
Palamara et al.30 Non-axial tooth loading resulted in potentially damaging cervical strains. The direction and magnitude of loading had a strong influence on the nature of cervical strains.
Rees et al.28 Peak cervical stresses upon tooth loading were highest for the maxillary incisor, intermediate for the maxillary premolar and lowest for the maxillary canine.
Rees24 Lee et al.25 Palamara et al.31
Non-axial tooth loading increases the magnitude of cervical stress values.
Borcic et al.32 Teeth in malocclusion generated larger tensile stresses in the cervical region compared to teeth in normal occlusion upon tooth loading.
ª 2009 Australian Dental Association
enamel is considered to be anisotropic, the tooth seems to be better able to cope with loading. Not only are the resultant stresses of lower magnitude, they are also preferably transferred into dentine which tolerates tensile stress better than enamel.27Therefore, the work of those authors who have considered enamel to be isotropic should be interpreted with caution (Table 2).
Another flaw of FEA is its inability to simulate accurately the biological dynamics of the tooth and its supporting structures. For example, with non-carious cervical tooth structure loss there are also changes in the structure of dentine as it becomes exposed to the oral environment. It is very difficult to develop a predictive model for the complex structure of tertiary dentine, which is formed in response to a stimulus such as tooth wear.
Perhaps the most important issue in using FEA to investigate abfraction is that this approach has high- lighted an anomaly. A common finding of FEAs has been that the magnitudes of facial and lingual stresses are similar in response to loading. However, this does not match the clinical picture of NCCLs that present much more commonly on the facial, rather than the palatal or lingual surfaces of teeth.14 Rees et al.28 propose that stress-corrosion may provide an explana- tion for this anomaly. They refer to the work of Lecomte and Dawes29 who found that erosive fluids, such as fruit juice, are cleared from palatal sites six times faster than from facial sites.
Experimental evidence of abfraction
There is only a small amount of experimental evidence supporting the concept of abfraction and, unfor-
tunately, there are many limitations to the studies reported so far. Palamara et al.34 found that teeth exposed to 500 newton loading over 200 000 to 500 000 cycles, while immersed in water, demonstrated microfractures and small areas of enamel loss when examined under scanning electron microscopy at 200·
to 1200· magnification. However, this research did not completely replicate a clinical situation. For example, although the teeth were subjected to cyclic, non-axial loading, a 20 newton pre-load was maintained. Main- taining a certain load, no matter the magnitude, limits the value of the results, as this is not what occurs clincally.
Litonjua et al.35 conducted an experiment to deter- mine the effect of axial and non-axial forces on the initiation and progression of NCCLs in teeth that were also subjected to toothbrush abrasion. They found that axially loaded teeth that were subjected to toothbrush abrasion exhibited significantly less cervical tooth substance loss than control teeth that were not loaded.
Non-axially loaded teeth that were simultaneously subjected to toothbrush abrasion showed similar amounts of cervical wear to control teeth that were not loaded. However, this experiment had several flaws. For example, teeth were loaded while being simultaneously subjected to toothbrush abrasion, a situation unlikely to occur clinically. In addition, the teeth were subjected to static loads. This does not represent the true clinical picture of tooth loading which is dynamic and variable in nature. The results of this study should therefore be interpreted with caution.
Staninec et al.36 investigated the magnitude and location of tooth structure loss using sectioned seg- ments of tooth structure that were subjected to cyclic mechanical loading. Despite the obvious limitation of using sectioned segments of tooth structure, they found that there was a greater loss of material in high-stress areas, supporting the possibility of abfraction.
A confounding factor to consider when examining the formation of abfraction lesions is the vulnerability of cervical tooth structure to breakdown.24 Cervical enamel has been shown to be more brittle compared with occlusal enamel.37The DEJ in the cervical region of teeth has poorly developed scalloping, which means the strength of this junction is compromised.38 The hardness modulus and elastic modulus of enamel also decrease as the DEJ is approached.39
In summary, the small amount of experimental evidence published for abfraction has limitations.
What has been shown experimentally is that cervical tooth structure may be more vulnerable to stress- induced breakdown. Future experimental studies that replicate the clinical situation as closely as possible are needed to provide further evidence for or against abfraction.
Table 2. Summary of the outcomes of FEA studies related to abfraction
Reference Force
(newtons)
Tooth class(es) investigated
Assumed behaviour of enamel
Rees23 100 Mandibular second
premolars
Anisotropic Palamara et al.30 100 Mandibular second
premolars
Not specified Lee et al.25 170 Maxillary second
premolars
Isotropic
Rees24 500 Mandibular second
premolars
Isotropic Rees et al.28 500 Maxillary central
incisors, canines and first premolars
Anisotropic
Rees and Hammadeh33
100 Maxillary central incisors, canines and first premolars
Anisotropic
Borcic et al.32 200 Maxillary first premolars
Isotropic Palamara et al.31 100 Mandibular second
premolars and lower central incisors
Isotropic
ª 2009 Australian Dental Association
Abfraction lesions and occlusal factors
There have been strong associations reported between occlusal wear facets and NCCLs. Since occlusal wear facets are indicative of past tooth grinding it has been proposed that this is evidence for abfraction.12,40–42 However, not all teeth with NCCLs exhibit wear facets and not all teeth with wear facets exhibit NCCLs.42As indicated previously, a cross-sectional study looking at facet frequencies caused by tooth grinding in an Australian Aboriginal population indicated a high prevalence of tooth grinding and no evidence of NCCLs.20
One must recognize that a limitation of using wear facets as indicators of bruxism is that not all wear results from bruxism-related attrition. It may also result from corrosion and abrasion (e.g., with mastication of coarse substances). Previous researchers have appar- ently ignored this fact and, therefore, their results should be interpreted with caution. Khan et al.43tried to overcome this issue by determining whether occlusal wear lesions had resulted from erosion or attrition.
They found a 96 per cent association between non- carious occlusal and cervical lesions but no statistically significant association was found between the number of wedge-shaped NCCLs associated with occlusal erosion or attrition lesions.43 Future studies must take into account the multifactorial aetiology of wear facets.
As malocclusion may predispose to non-axial forces, there has been research investigating the associations between malocclusion and NCCLs. Strong associations have been found between NCCLs and group func- tion.12,41Piotrowski et al.44found that all 10 teeth with premature contacts, which may have predisposed these teeth to excessive, non-axial loading, had wedge-shaped lesions.
Analysing the occlusion has its limitations because the occlusal relationships noted at the time of an examination may change as NCCLs progress. In addition, bruxism involves both clenching and grinding of teeth. Clenching does not result in the formation of wear facets, yet it can still lead to tooth flexure. There is no simple, accurate way of recording or reporting clenching. Bruxism is thus underestimated if wear facets are the only measures of its activity.
Management of abfraction lesions
As evident from the previous text, there is currently a lack of sound evidence to confirm whether abfraction is a real clinical phenomenon. However, a variety of management strategies for abfraction lesions have been proposed. Some strategies are tailored for abfrac- tion lesions and others are used for NCCLs of all aetiologies.
Monitoring abfraction lesions
As abfraction is still yet to be supported by appropriate evidence, it is advisable to monitor suspected abfraction lesions where appropriate. This avoids unnecessary treatment and, over time, a more obvious cause(s) (e.g., toothbrush abrasion or corrosion) may present itself. As with all forms of tooth wear, it is vital to take into consideration the age of the individual and the pre- dicted rate of tooth wear. Wear can be considered physiological in older individuals when the tooth in question is not causing clinical consequences and would be seen to last the patient’s lifetime without operative intervention. However, if the tooth wear is likely to compromise the long-term prognosis of the tooth then operative intervention may be required.19
When possible abfraction lesions are not causing clinical consequences and ⁄ or they are only shallow in depth (less than 1 mm), one may elect to simply monitor them at regular intervals (e.g., six-monthly).
Standardized intra-oral photographs, study models and measuring lesion dimensions are all potential approaches. However, these methods are generally only useful for long periods of time, such as months and years.
A novel method of determining the activity of abfraction lesions over time is to undertake a scratch test. A number 12 scalpel blade is used to superficially scratch the tooth surface. Visual observation of the scratch will give an indication of the rate of the tooth structure loss. Loss of scratch definititon or loss of the scratch altogether signifies active tooth structure loss.19
Restoration of abfraction lesions
It should be noted that when restoring abfraction lesions clinicians are not treating the aetiology but are merely replacing what has been lost. There are no generally accepted, specific guidelines in the literature stating when abfraction lesions should be restored.
Logic and good clinical judgement would suggest that they should be restored when clinical consequences (e.g., dentine hypersensivity) have developed or are likely to develop in the near future. Aesthetic demands of the patient may also influence the decision to restore these lesions. One must conduct a risk-benefit analysis when considering restoring these lesions. Cervical restorations may contribute to increased plaque accu- mulation potentially leading to caries and periodontal disease.
Problems with restoring NCCLs include difficulty in obtaining moisture control, gaining access to subgingi- val margins and high failure rates.45–47 Rubber dam clamps, gingival retraction cord and periodontal sur- gery are methods that can be used to retract and control the gingival tissues and thus facilitate access and control
ª 2009 Australian Dental Association
moisture. Reasons for restoration failure include loss of retention, secondary caries, marginal defects, discol- ouration and sensitivity.
It is evident from the recent literature that there is no place for metallic materials such as amalgam and gold in the modern day restoration of NCCLs.48,49Glass iono- mer cements (GICs), resin-modified GICs (RMGICs), a GIC ⁄ RMGIC liner ⁄ base laminated with a resin com- posite, and resin composite in combination with a dentine bonding agent are all restorative options.
Tyas48recommended that RMGIC should be the first preference for restoration of NCCLs or, in aesthetically demanding cases, a RMGIC ⁄ GIC liner ⁄ base be lami- nated with resin composite. Vandelwalle and Vigil49 recommend NCCLs suspected of being caused primar- ily by abfraction should be restored with a microfilled resin composite that has a low modulus of elasticity, as it will thus flex with the tooth and not compromise retention. However, a seven-year study found no statistically significant difference between failure rates of three resin composites of different stiffness used to restore NCCLs.50
Occlusal adjustment
As a result of the reported associations between occlusal interferences and abfraction lesions, and loading direction (influenced by cusp inclines) and unfavourable tensile stresses, occlusal adjustment has been advocated to prevent their initiation and progres- sion and to minimize failure of cervical restora- tions.44,51 Occlusal adjustments may involve altering cuspal inclines, reducing heavy contacts and removing premature contacts. Expensive devices claiming to assist the clinician in adjusting the occlusion and therefore managing abfraction should be considered with caution.
It is not recommended that occlusal adjustments be carried out at this time in an effort to manage abfraction because the effectiveness of such treatment is not supported by evidence. In fact, inappropriate occlusal adjustments may increase the risk of certain conditions such as caries, occlusal tooth wear and dentine hypersensitivity.
Occlusal splints
Occlusal splints, aimed at reducing the amount of nocturnal bruxism and non-axial tooth forces, have been recommended to prevent the initiation and progression of abfraction lesions.44However, it should be noted that the use of occlusal splints to reduce bruxism is still a controversial topic. Some studies support their efficacy, while others do not.52 Occlusal splints have the potential to reduce non-axial tooth loading when constructed appropriately. Although they
provide a conservative treatment option for managing suspected abfraction lesions, there is no evidence base to support their use.
CONCLUSIONS
There is still much to be discovered about NCCLs in general and the possible role of abfraction remains controversial and frequently misunderstood. The find- ings from anthropological, epidemiological, theoretical, experimental and clinical studies suggest that abfrac- tion should still be considered to be a theoretical concept rather than a genuine contributor to NCCL formation. If abfraction is suspected to be a dominant factor in the aetiology of NCCLs, then any decision to carry out destructive, irreversible treatment, such as occlusal adjustment, should be considered very carefully.
