Lymphadenoma of parotid gland: Two additional cases and a literature review
Irving Dardick, MD, MSc, FRCPCa, and M. Jane Thomas, MD, FRCPCb, Toronto, Ontario and Ottawa, Ontario
UNIVERSITY OF TORONTO AND UNIVERSITY OF OTTAWA
For classification purposes, proper identification of infrequent and unique salivary gland tumors requires the gradual accumulation of a sufficient number of cases. Lymphadenoma (i.e., an adenomatous, generally parotid-based lesion with an exaggerated lymphocytic infiltrate, but a lack of sebaceous differentiation) has approximately 9 reported cases. This report adds 2 additional cases occurring as a discrete, at least partially encapsulated nodule in the parotid gland. Embedded within the extensive lymphocytic component were isolated nests of solid or glandular epithelium, with 1 case displaying a few foci of chondrocytic differentiation. Immunohistochemical investigation of the latter case revealed the presence of both luminal and myoepithelial cells. (Oral Surg Oral Med Oral Pathol Oral Radiol Endod 2008;105:491-4)
A lymphoid component is the norm for salivary gland lesions such as Warthin’s tumor, sebaceous lymphade- noma and carcinoma, lymphoepithelial cyst, and lym- phoepithelial carcinoma. With varying but considerably less frequency, tumor-associated lymphoid stroma also occurs in acinic cell carcinoma, mucoepidermoid car- cinoma, oncocytoma, oncocytic carcinoma, primary squamous cell carcinoma, and cystadenocarcinoma.1,2
Lymphadenoma represents a relatively recent addi- tion to the group of salivary gland lesions with a prominent tumor-associated lymphoid stroma, with perhaps 9 cases reported or illustrated in journals and texts—in a few instances, it is not possible to tell if the same cases are being illustrated.1,3-8 Histologically, lymphadenomas are well-defined, generally encapsu- lated lesions with a predominant lymphoid background within which most often are embedded solid nonde- script or squamous epithelial nests.4,6-8 But occasion- ally, the epithelium is glandular,5mixed solid/glandu- lar,3 or cystic.3-5 In all of these cases, what distinguishes these lesions from sebaceous lymphade- noma has been the absence of sebaceous differentia- tion. In addition, the arrangement and cellular makeup of the epithelium does not resemble any of the usual benign or malignant salivary gland tumors. This report
describes 2 additional cases of lymphadenoma occur- ring in the parotid gland, 1 of which has some unique histological aspects.
MATERIAL AND METHODS
Case 1 had been recently accessioned as a surgical pathology specimen in the Department of Laboratory Medicine at the Ottawa Hospital, Ottawa, Ontario, whereas Case 2, which in 1981 had originally been thought to represent a basal cell adenoma with exten- sive lymphocytic infiltrate, was retrieved from the files of the Canadian Reference Centre for Cancer Pathol- ogy, University of Ottawa, Ottawa, Ontario.
Following review of the hematoxylin-eosin sections, additional sections were cut and immunostained using routine immunoperoxidase techniques and antigen re- trieval (except for S-100 protein) with the following antibodies: AE1/AE3 (Chemicon, Temecula, CA;
1:400 dilution), smooth muscle actin (Dako Canada, Mississauga, Ontario, Canada; 1:50 dilution), p63 (Dako Canada; 1:100 dilution), and S-100 protein (Bio- genex Inc., San Ramon, CA; 1:200 dilution). Unfortu- nately, due to poor fixation of the material archived from Case 2 in 1981, meaningful immunostaining could not be obtained.
CASE REPORTS Case 1
A 45-year-old man appeared with a right parotid mass approximately 2 cm in diameter. There was no cervical lymphadenopathy. The excised tumor was well defined and separated from the parotid gland by a capsule of variable thickness, below which there was no evidence of lymphatic sinusoids (Fig. 1, A, B).
Histologically, the main feature was a dense lymphatic
aProfessor Emeritus, Department of Laboratory Medicine and Patho- biology, Faculty of Medicine, University of Toronto, Toronto, On- tario.
bAssociate Professor, Department of Pathology and Laboratory Med- icine, Faculty of Medicine, University of Ottawa, Ottawa, Ontario.
Received for publication Jul 1, 2007; returned for revision Aug 26, 2007; accepted for publication Aug 27, 2007.
1079-2104/$ - see front matter
© 2008 Mosby, Inc. All rights reserved.
doi:10.1016/j.tripleo.2007.08.035
491
infiltrate that tended to obscure an isolated epithelial component (Fig. 1,A, B). The latter consisted of irreg- ularly sized and shaped sheets of tumor cells and col- lections of ductlike glandular structures (Fig. 1, C, D), both of which became more obvious in immunohisto- chemical preparations (Fig. 2, A, B). A few foci of collagenous and chondroid matrix, as well as epithelial nests with prominent basement membranes, were evi- dent (Fig. 3, A, B). The numerous lymphocytes were small and uniform in appearance (Fig. 1, B, C;Fig. 2, A, B) and the epithelial component showed no evidence of cytological or nuclear abnormalities and a lack of mitotic activity (Fig. 1,C, D).
Immunohistochemistry for cytokeratins (AE1/AE3) confirmed the glandular differentiation of the epithelial portion of this tumor (Fig. 2, A, B), whereas antibodies to smooth muscle actin (Fig. 2, C), p63 (Fig. 2, D), and S-100 protein highlighted the neoplastic myoepithelial cell differentiation on the outer aspect of unstained luminal cells. There was no evidence of recurrence at 6-months follow-up.
Case 2
The patient was a 52-year-old male with a 6-month history of a painless mass in the right parotid gland. A discrete, fleshy mass 20 mm in diameter was subse-
quently resected, together with a portion of a normal parotid gland. Histologically, the lymphocytic compo- nent of this well-defined tumor nodule tended to ob- scure the epithelial component (Fig. 4, A). A fibrotic capsule, lacking evidence for a subcapsular sinus, en- Fig. 1. Case 1. A, Intraparotid, discrete, thinly encapsulated
tumor nodule. Note the extensive lymphocytic infiltrate (he- matoxylin-eosin). B, A relatively thin capsule separates the tumor nodule from normal parotid gland (right; (hematoxylin- eosin, original magnification⫻50). C, At this magnification, the ill-defined epithelium is distinguishable from the more numerous lymphocytes (hematoxylin-eosin, original magni- fication⫻130). D, In this region, the epithelium consists of nests of regular epithelial cells forming variably sized, glan- dular, or ductlike lumens (arrows; (hematoxylin-eosin, orig- inal magnification⫻325).
Fig. 2. Case 1. Immunohistochemical preparations. A, Low- power micrograph (⫻50) immunostained with anticytokeratin antibody AE1/AE3, showing the irregular clusters of epithe- lial cells within the predominant and unstained lymphocytic population. Note the preferential staining of ductal structures in the adjacent, normal parotid gland (top). B, Higher mag- nification of AE1/AE3 immunostained tumor (⫻130) show- ing the irregularly shaped and sized ductlike structures en- closed by lymphocytes. C, Immunostaining with anti–
smooth-muscle actin antibody revealing polygonal to spindle- shaped abluminal tumor cells, some of which surround nonstaining luminal cells (arrows;⫻325). D, In this region, antibody to p63 clearly defines the polygonal to slightly flattened abluminal cells surrounding unstained luminal cells (arrows;⫻325).
Fig. 3. Case1. A, Note the focus of chondrocytic differenti- ation among the epithelial cells, which in this region have a sheetlike distribution with an occasional ductlike lumen (ar- rows; hematoxylin-eosin, original magnification⫻130). B, In another region of this lymphadenoma, tumor cell nests are partially to completely enclosed by relatively thick bands of hyaline material, some of which is also present within the cell groups (arrows; hematoxylin-eosin, original magnification
⫻130).
OOOOE
492 Dardick and Thomas April 2008
closed the tumor (Fig. 4, B). Scattered among the lymphocytes were numerous, discrete, relatively small round to irregularly shaped nests of epithelial cells (Fig.
4, B, C). Tumor cells were polygonal to irregular in shape, with round-to-oval shaped nuclei and small-to- moderately sized nucleoli; mitotic figures were absent (Fig. 4, D). Glandular differentiation was absent (Fig.
4, B-D). Primarily small mature lymphocytes, with occasional plasma cells and germinal centers, separated the epithelial tumor cells (Fig. 4,B-D). The patient was well 3 years after surgical removal, with no evidence of local recurrence or metastases.
DISCUSSION
In this class of adenoma with tumor-associated lym- phoid proliferation (i.e., lymphadenoma), the growth pattern of the epithelial component generally lacks re- semblance to other benign salivary gland tumors such as pleomorphic adenoma, basal cell adenoma, canalic- ular adenoma, or myoepithelioma. Basic criteria for this entity are outlined in Table I. For practical purposes, lymphadenoma is thus a form of adenoma, not other- wise specified, with an absence of sebaceous differen- tiation but an obvious lymphocytic infiltrate.1 This is especially evident in routinely stained histological preparations where the intensity of the lymphocytic cell population tends to obscure the epithelial portion. As noted by Ma and associates,4 however, the growth
pattern within some lymphadenomas resembles basal cell adenoma or cystadenoma. Epithelial growth pat- terns become more apparent with immunohistochemi- cal techniques.4,7These features are apparent for the 2 cases included in this report.
As was indicated in the case reports, no histological features suggested either case arose from salivary gland rests within an intraparotid lymph node. No character- istic histology was initially noted in case 1 and the diagnosis was unclear, especially with the overriding lymphocytic component. A few foci of chondroid dif- ferentiation, however, together with the ductal elements and associated neoplastic myoepithelial cells (particu- larly evident with immunohistochemistry), made cellu- lar pleomorphic adenoma a consideration. Pleomorphic adenoma with lymphocytic stroma is said to be ex- tremely rare,1but we are not aware of a reported case.
So, although this case might qualify as a pleomorphic adenoma with tumor-associated lymphocytic stroma, it is more practical to include such a case within the lymphadenoma category. A similar argument applies to case 2. This example and a number of the lymphade- noma cases reported in the literature have histological features of basal cell adenoma4,7 but continue to be classified as lymphadenomas. Other lymphadenomas have the basic architecture of a cystadenoma.4,5 At low-to-medium magnifications, however, the histology of both lesions in this report was comparable to that evident in other examples of lymphadenoma in the literature. Since all such lesions raise comparable dif- ferential diagnostic problems, grouping these serves a practical approach, particularly with the already diverse histopathology of lymphadenomas. One example of a lymphadenocarcinoma has been reported.9
The potential differential diagnoses for lymphade- noma are considerable (summarized in Table II) and have been previously well discussed.1,4Given the gen- eral histological features of lymphadenoma, metastatic carcinoma, mucoepidermoid, and acinic cell carcino- mas with tumor-associated lymphocytic proliferation and sebaceous lymphadenoma or lymphadenocarci- noma are the main considerations. Warthin’s tumor is ruled out by the absence of both a bilayered oncocytic epithelium and a papillary growth pattern.
Fig. 4. Case 2. A, Circumscribed tumor nodule, part of which has a thin capsule, with an extensive lymphocytic infiltrate. B and C, At progressively higher magnification (B,⫻50; C,
⫻130), the degree of separation of the discrete epithelial tumor cell nests by the germinal center-forming lymphocytes (arrows) becomes evident. Note the tumor-associated capsule (lower left in B; hematoxylin-eosin). D, The discrete nests of polygonal to irregularly shaped tumor cells, surrounded by normal lymphocytes, have regular nuclear features (hematox- ylin-eosin, original magnification⫻325).
Table I. Diagnostic criteria for lymphadenoma
No sebaceous differentiation Nononcocytic epithelium
Predominant lymphocytic component with or without germinal centers (may be plasma cells)
Solid, glandular, or cystic epithelial nests
Well-defined tumor mass with a lack of nodal capsule or subcapsular sinusoids
OOOOE
Volume 105, Number 4 Dardick and Thomas 493
Parotid gland involvement by metastatic carcinoma is likely to involve an intraglandular lymph node. Thus, the absence of subcapsular sinusoids and nuclear and cellular atypia, no increased mitotic activity, and lack of invasive tumor features all support a diagnosis of lymphadenoma. It should be noted, however, that one lymphadenoma had evidence of a subcapsular sinus but an absence of histological features of malignancy.5 Although some lymphadenomas will be cystic,3,4such lesions lack the goblet and intermediate cell lining epithelium characteristic of mucoepidermoid carci- noma with tumor-associated lymphoid proliferation.1 In addition, lymphadenomas lack the extravasation of mucus and invasive tendencies of mucoepidermoid car- cinoma. The epithelial component of lymphadenoma does not demonstrate the microcystic and follicular growth patterns and acinar cell differentiation with its characteristic granular cytoplasm of acinic cell carci- noma with prominent lymphoid stroma.2 Such histo- logical features would also apply to primary muco-
epidermoid and acinic cell carcinomas arising in intraparotid lymph nodes.10The absence of sebaceous differentiation is the key differential criteria eliminating sebaceous lymphadenoma and lymphadenocarcinoma.
Thus, there would be good reason for referring to the current entity as nonsebaceous lymphadenoma.
REFERENCES
1. Auclair PL. Tumor-associated lymphoid proliferation in the pa- rotid gland. A potential diagnostic pitfall. Oral Surg Oral Med Oral Pathol 1994;77:19-26.
2. Michal M, Skalova A, Simpson RHW, Leivo I, Ryska A, Starek I. Well-differentiated acinic cell carcinoma of salivary glands associated with lymphoid stroma. Hum Pathol 1997;28:595-600.
3. Ellis GL, Auclair PL. Tumors of the salivary glands, atlas of tumor pathology. 3rd series, Fascicle 17. Washington, DC:
Armed Forces Institute of Pathology; 1996. p. 135-6.
4. Ma J, Chan JKC, Chow CW, Orell SR. Lymphadenoma. A report of three cases of an uncommon salivary gland neoplasm. Histo- pathology 2002;41:342-50.
5. Kwon GY, Kim EJ, Go JH. Lymphadenoma arising in the parotid gland. A case report. Yonsei Med J 2002;43:536-8.
6. Chang JY, Hsiao CH. Lymphadenoma lacking sebaceous differ- entiation in the parotid gland. J Formosa Med Assoc 2004;103:459-62.
7. Bos I, Meyer S, Merz H. Lymphadenoma of the parotid gland without sebaceous differentiation. Immunohistochemical inves- tigations. Pathologe 2004;25:73-8.
8. Musthyala NB, Low SE, Seneviratne RH. Lymphadenoma of the salivary gland. A rare tumor. J Clin Pathol 2004;57:1007.
9. Hill DS, Ellis GL, Gatland DJ. A unique parotid adenocarci- noma. J Laryngol Otol 2000;114:402-4.
10. Seifert G. Primary salivary gland tumors in the lymph nodes of the parotid gland. Report of 3 cases and review of the literature.
Pathologe 1997;18:141-6.
Reprint requests:
Irving Dardick, MD, MSc, FRCPC 2428 Rosewood Avenue
Ottawa, Ontario K2B 7L4, Canada
Table II. Differential diagnoses for lymphadenoma
Metastatic carcinoma
Mucoepidermoid carcinoma with lymphoid stroma Acinic cell carcinoma with lymphoid stroma Sebaceous lymphadenoma and lymphadenocarcinoma Warthin’s tumor
Myoepithelial sialadenitis
Benign lymphoepithelial cyst and AIDS-related lymphoepithelial cyst
Lymphoepithelial carcinoma Malignant lymphoma
Papillary cystadenocarcinoma with lymphoid stroma Primary squamous cell carcinoma with lymphoid stroma Primary salivary gland tumors arising within a lymph node AIDS, acquired immunodeficiency syndrome.
