Cite this: Nanoscale Horiz., 2020, 5, 1058

Spontaneously induced magnetic anisotropy in an ultrathin Co/MoS

₂

heterojunction†

Chun-I Lu, ^abChih-Heng Huang,^acKui-Hon Ou Yang,^d

Kristan Bryan Simbulan, ^bKai-Shin Li,^eFeng Li,^fJunjie Qi, ^f Matteo Jugovac, ^g Iulia Cojocariu,^gVitaliy Feyer, ^gChristian Tusche,^gMinn-Tsong Lin,^hi

Tzu-Hung Chuang,^aYann-Wen Lan *^band Der-Hsin Wei *^a

Magnetic anisotropy (MA) is a material preference that involves magnetization aligned along a specific direction and provides a basis for spintronic devices. Here we report the first observation of strong MA in a cobalt–molybdenum disulfide (Co/MoS2) heterojunction. Element-specific magnetic images recorded with an X-ray photoemission electron microscope (PEEM) reveal that ultrathin Co films, of thickness 5 monolayers (ML) and above, form micrometer (lm)-sized domains on monolayer MoS2flakes of size tens of lm. Image analysis shows that the magnetization of these Co domains is oriented not randomly but in directions apparently correlated with the crystal structure of the underlying MoS2. Evidence from micro-area X-ray photoelectron spectra (l-XPS) further indicates that a small amount of charge is donated from cobalt to sulfur upon direct contact between Co and MoS2. As the ferromagnetic behavior found for Co/MoS2is in sharp contrast with that reported earlier for non-reactive Fe/MoS2, we suggest that orbital hybridization at the interface is what makes Co/MoS2 different. Our report provides micro- magnetic and micro-spectral evidence that consolidates the knowledge required to build functional heterojunctions based on two-dimensional (2D) materials.

Introduction

After the discovery of graphene, monolayer MoS₂ – a layered van der Waals (vdW) semiconducting transition-metal dichalcogenide (TMD)^1–4– has emerged as another 2D material proto- type, which can be obtained by exfoliation ex situ or chemical vapor deposition (CVD)^5,6 in situ. Bulk MoS2 has an indirect bandgap, which would become a direct bandgap when its thickness decreases to a monolayer.^5,7,8 This exotic property has enabled few-layer MoS2 to have applications of various types, such as field-effect transistors, light-emitting diodes, and solar cells.^9–12Moreover, because of the strong spin–orbit coupling and the absence of inversion symmetry in the monolayer regime, spin splitting arises at the boundaries of the surface Brillouin zone, specifically, at points K and K, to conserve the time-reversal symmetry.^13–15Such a unique band structure provides a possibility to encode information through the material valley pseudospin. Valley-based electronics is described as valleytronics, a name inspired after another famous field, spintronics.^16–19

MoS2 can also serve as a spacer in a spin-valve device to exploit its semiconducting nature and its stable spin polarization in the out-of-plane direction.^20,21Magnetoresistance (MR) of 0.73% at 20 K and 0.23% at 240 K has been demonstrated in a NiFe/MoS2/NiFe structure.²²MR denotes the change of electrical resistance when two ferromagnetic (FM) electrodes sandwiching a MoS2layer switch their magnetization alignment from parallel

aScientific Research Division, National Synchrotron Radiation Research Center, Hsinchu, Taiwan. E-mail: [email protected]

bDepartment of Physics, National Taiwan Normal University, Taipei, Taiwan.

E-mail: [email protected]

cInternational PhD Program for Science, National Sun Yat-Sen University, Kaohsiung, Taiwan

dGraduate Institute of Applied Physics, National Taiwan University, Taipei, Taiwan

eNational Nano Device Laboratories, National Applied Research Laboratories, Hsinchu, Taiwan

fState Key Laboratory for Advanced Metals and Materials, School of Materials Science and Engineering, University of Science and Technology Beijing, Beijing, People’s Republic of China

gForschungszentrum Ju¨lich, Peter Gru¨nberg Institut (PGI-6), 52425, Ju¨lich, Germany

hDepartment of Physics, National Taiwan University, Taipei, Taiwan

iInstitute of Atomic and Molecular Sciences, Academia Sinica, Taipei, Taiwan

†Electronic supplementary information (ESI) available. See DOI: 10.1039/

d0nh00108b

Received 17th February 2020, Accepted 29th April 2020 DOI: 10.1039/d0nh00108b rsc.li/nanoscale-horizons

New concepts

The new concept in this work is the observation of spontaneously induced magnetic anisotropy in monolayer MoS2due to charge donation at the interface of the Co/MoS2heterojunction. In this way, monolayer transition metal dichalcogenide (TMD) materials can be magnetized by simply attaching a suitable material, instead of doping them, to avoid damaging the atomic structure. Furthermore, the magnetic properties of TMDs could be fine-tuned by choosing diﬀerent materials, which involves diﬀerent orbital hybridization at the interface.

Nanoscale Horizons

COMMUNICATION

(3)

to anti-parallel. The confirmation of a spin-valve eﬀect in a MoS2- based heterostructure is encouraging, but the large discrepancy between measurement (MR less than 1%)²²and prediction (MR as large as 300%)²³indicates that we have yet to identify all players relevant to the spin-dependent transport in TMD-based spin valves.

Direct investigation of the fundamental magnetic properties of FM–TMD heterojunctions is believed to be informative but remains scattered. A recent experimental study of a Fe/MoS₂ heterojunction found that deposited Fe aggregates into nano- particles with no sign of magnetic coupling to MoS2. Neither is there charge transfer between Fe and MoS2, according to measurements of their X-ray photoemission spectra (XPS).^24,25 In contrast, Co/MoS2was suggested to be different. According to a first-principles calculation reported by Garandel et al., the energetically favored Co–S bonding at the Co/MoS2 interface would lead to a spin imbalance on the MoS2 side.²⁶We thus expect Co/MoS2to exhibit magnetic properties different from those of Fe/MoS₂.

This work began with the deposition of ultrathin films of Co onto flakes of SiO₂-supported monolayer MoS₂,⁶followed by an examination of the magnetic domain configuration with a photoemission electron microscope (PEEM)²⁷and chemical states with m-XPS.²⁸Element-specific images revealed that, with Co covering both MoS2 and SiO2, the magnetic domains appeared only at the area of Co/MoS2. Furthermore, the direction of magnetization of Co domains seems to correlate with the underlying MoS2 lattice structure. m-XPS measurements²⁸ on Co/MoS2 disclose further that a small charge transfer, induced by the formation of a covalent bond between S and Co atoms, occurs after the deposition of Co. Our observation of magnetic domains with preferred directions of magnetization is solid proof of magnetic anisotropy at a Co/MoS2(monolayer) heterojunction. The charge transfer identified with m-XPS indicates that a high spin-injection eﬃciency at this particular interface might be possible.

Results and discussion

Fig. 1 shows optical images of MoS2islands on a SiO2substrate after CVD growth. The surface is composed of flakes of various shapes, for example, star-like or triangular. The consistent transparency among MoS2flakes indicates their high thickness uniformity. The collective photoluminescence (PL) and Raman spectra, shown in Fig. 1(b) and (c), respectively, indicate that most MoS2flakes are monolayers. This condition is revealed by a separation of 21 cm ¹between the two dominant peaks, E¹2gat 383.8 cm ¹and A1gat 404.1 cm ¹, in the Raman spectra, as well as by an intense and sharp peak located at 1.8 eV in the PL spectra.^5,29

A schematic band structure of a typical FM 3d-transition metal is drawn in Fig. 2(a), in which a net magnetic moment originates from the asymmetric nature of the 3d band. According to the selection rules, an incident energetic photon beam with either right or left circular polarization (RCP or LCP) can excite electrons that fulfill the transition conditions: Ds = 0 and Dm =1.

The probabilities of each pair of corresponding transitions from

the occupied 2p core-level up to the empty 3d band are, however, unequal for the majority and minority spin channels because each channel has a diﬀerent number of empty states available for a transition. A schematic diagram of the experimental setup appears in Fig. 2(b), which shows an incident circularly polarized beam illuminating the sample – a Co ultrathin film on MoS2– at an angle of 251 of grazing incidence. The spatial distribution of the photo-emitted electrons under the X-ray magnetic-circular- dichroism (XMCD) effect^30,31is resolved with the PEEM, allowing the observation of magnetic domains in the Co layer. Fig. 2(c) shows an XMCD image recorded from a Co film (9 ML) deposited on monolayer MoS2. In that image, two regions of distinct contrast are labeled as regions A and B. From there, we extracted two micro-area spectra according to their intensity variation as a function of photon energy. As the difference of these two spectra in Fig. 2(d) shows a typical XMCD signature – opposite enhance- ment at Co L₃and L₂resonances – the contrast seen in Fig. 2(c) has indeed a magnetic origin.

Fig. 3(a)–(c) show XMCD images of Co films at thicknesses 5, 7, and 9 ML. After recording the first XMCD image from a Co film at thickness 5 ML, the images in succeeding sets were acquired after each subsequent deposition. After comparing the series of images, we concluded that the additional Co deposition would only enhance the magnetic contrast of the existing domains. The XMCD image can be conceived as an inner product of the sample magnetization (M) and the beam^- polarization (~s), i.e. I pM~^-s.³³ Under the conditions of fixed incident angle and beam polarization, the XMCD image is effectively a measure of the spatial distribution of magnetization directions with respect to the polarization of the photon beam. In our study, the thickness of Co was assumed to be uniform on MoS₂,^34,35 and likewise the magnitude of its magnetization. The fact that we observed only several distinct contrasts in Fig. 3 indicates that the localized magnetizations are somehow oriented into selected directions. To explain the directions of magnetization clearly, we plotted the contrast levels of domain images into histograms. The greyscale shown Fig. 1 Monolayer of MoS2. (a) OM image of CVD-grown MoS2islands on SiO2. The dashed square indicates a triangular MoS2sample, which is also featured in Fig. 3. (b) The Raman spectrum of the sample shows two dominant Raman modes at 383 and 404 cm ¹ of separation 21 cm ¹. (c) The PL spectrum of the sample indicates that the photoluminescence peak energy is equal to 1.83 eV. These two spectra indicate that the MoS₂ islands are monolayers.

Communication Nanoscale Horizons

(4)

at the bottom of the histogram indicates the range of contrast levels taken from images, whereas the intensity of the histogram

represents the frequency of finding a specific contrast level from the image pixels. In the hypothetical case of out-of-plane Fig. 2 XMCD. (a) Schematic diagram describing the principle of XMCD. The excitations of spin-up and spin-down electrons from the 2p band are distinct when a circularly polarized beam is applied along with a particular magnetic domain. This absorption, and the resulting photoelectron emission, asymmetry is reversed with the beam focused on the domain in the opposite magnetization. (b) Schematic diagram illustrating the experimental setup.

The incident circularly polarized soft X-ray beam has an angle of 251 with respect to the sample surface. Due to the effect of XMCD, opposite magnetic domains respond differently when the photon energy of the incident beam is resonant with the Co L₃and L₂edges. The emitted photoelectrons are collected with the PEEM to map spatially the domains in varied directions of magnetization. (c) XMCD image of cobalt (9 ML) on monolayer MoS2. The inset shows the direction of incident light. (d) The corresponding m-XAS of regions A and B, the positions of which are marked in (c), are shown. The bottom spectrum represents the asymmetric nature of spectra A and B, which proves that the grey-scale contrast in (c) is a consequence of the XMCD effect.

Fig. 3 Dependence on the thickness of Co. XMCD images of Co of thicknesses (a) 5, (b) 7 and (c) 9 ML. The histograms below each image measure the grey-scale distribution in the region enclosed with the dashed squares in each histogram corresponding to the XMCD images. The domains in (a), (b) and (c) tend to be identical but the color contrast increases. The greyscale is limited to the range 0 to 255; the three chosen squares have the same area.

The presence of several peaks in the histogram implies the magnetization to be in-plane.

(5)

magnetization, only two contrast levels would be possible, inward-pointing normal and outward-pointing normal. As all histograms in Fig. 3 display more than two contrast levels within a finite greyscale, we conclude that the magnetizations of Co domains not only lie either in-plane or canted but also have preferred orientations.

Our next task was to examine the relevance of the MoS₂ crystalline structure for the domain formation. Fig. 4(a) and (b) display the domain images of a Co film (9 ML) grown on a single crystalline monolayer MoS2 flake and a polycrystalline monolayer MoS2film, respectively.³⁴By controlling the degree of crystallinity in monolayer MoS2, we were able to adjust the lateral dimensions of the magnetic domains from tens of micrometers to sub-micrometers. In addition, as Fig. 4(b) shows a broader spread of greyscale, the Co domains on a polycrystalline surface are believed to be less aligned. Another observation worthy of mention concerns the domain boundaries on triangular MoS2flakes. As displayed in Fig. 4(c), the paths of the domain boundary are not arbitrary but follow a particular crystalline axis of MoS₂. Considering that CVD-grown triangular MoS₂flakes are typically treated as a single crystalline grain, and that the edge of the grain is in either an armchair or zig-zag configuration as illustrated in Fig. 4(d),³⁶ it seems that well-defined crystallinity in the MoS₂layer would not only promote the magnetization alignment in a Co layer but also aﬀect how the domains are divided. We emphasize here

that the same behavior was found repeatedly on other flakes of MoS2covered with Co.

Finally, we examined the electronic structure of Co/MoS₂ (flake) with m-XPS. Fig. 5 shows the m-XPS recorded from the Co(4 ML)/SiO₂ and the Co(4 ML)/MoS₂ regions, respectively.

As the Co layer was prepared in situ, under UHV conditions, the Co 2p core levels acquired in the two separate areas contain contributions mainly from Co(0) (2p_3/2 = 778.3 eV),³⁷ which corresponds to the metallic state of Co. Moreover, apart from a broad spectral feature corresponding to the Auger emission of S atoms in MoS2, there are noticeable diﬀerences between the two spectra displayed in Fig. 5. A fit of the Co 2p spectrum of Co/MoS2 (flake) produces two additional spectral features, namely Co(II) (2p3/2= 781.5 eV) and Co(III) (2p3/2= 779.7 eV).^37,38 As Co(III) has an emission energy similar to that of Co oxidization found in Co/SiO2,³⁹we suggest that both Co(II) and Co(III) found on Co/MoS2(flake) are the result of charge transfer from Co to MoS2. The spectra shown in Fig. 5 are inconsistent with the concept of chemical doping, which is generally accompanied by chemical shifts in XPS.⁴⁰Instead, the absence of an energy shift of all major emission peaks – Co(0), Mo 3d, and S 2p (Fig. S6, ESI†) – implies a small net extent of charge transfer.

Based on our experimental observations, we confirm that an ultrathin Co film deposited on monolayer MoS₂is able to form micrometer-sized ferromagnetic domains. Furthermore, the magnetization and the boundaries of domains have preferred directions or paths that are parallel to either the zig-zag or armchair directions of the MoS2crystal structure. The presence of magnetic order and magnetic anisotropy in Co/MoS2(flake) proves the possibility of using two-dimensional materials of monolayer thickness to evoke the anisotropy of a magnetic layer deposited thereon.

Fig. 4 Magnetic anisotropy. XMCD images of (a) a Co film (9 ML) on a single grain monolayer MoS2flake and (b) a Co film (9 ML) on polycrystalline monolayer MoS2. The inset in (a) shows a de-magnified image with a scale bar set at 30 mm. The domains are larger on single grain MoS₂than on polycrystalline MoS₂(c). The domain boundaries present preferential directions, parallel to either the zig-zag (red) or armchair (blue) direction as clearly seen in the corresponding MoS₂ball models, A and B, drawn in (d).

Fig. 5 m-XPS evidence of charge transfer in Co. Co 2p m-XPS recorded for Co/SiO₂(upper) and Co/MoS₂(lower).

(6)

The crystal structure of Co offers the most straightforward explanation of the observed MA, because an ultrathin metallic film under a lattice strain can display properties different from those found in its pristine structure. An effective example to show what a lattice strain can do to the magnetic properties of a material is Co/GaAs(110); the Co layer stabilized on the body- center-cubic (BCC) structure displays an a-Fe-like behavior.⁴¹ However, as the low energy electron diffraction (LEED) results on Co/MoS₂ (bulk crystal) failed to produce a sharp pattern, we suspect that Co/MoS2 (flake) might not be epitaxial in nature; in fact, the Co layer grown on the MoS2surface seems amorphous (Fig. S7, ESI†). Although we lack the appropriate tool to determine the crystal structure of Co/MoS2 (flake), we know that the shape anisotropy can play no major role because of the non-comparable thickness between the Co layer and the area of the MoS2flake (several nm vs. tens of mm²).

Readers might curious about the absence of magnetic domains in the part Co/SiO2. The uniformity of the Co layer could cause such a diﬀerence. However, with our Co deposition known to vary by at most a few percent within a diameter of 6 mm on the specimen and the confirmation of having the same Co L-edge intensity measured from Co/MoS₂and Co/SiO₂ (Fig. S11, ESI†), we believe that the thickness of the Co layer is not responsible for the observed diﬀerence in domain con- figurations. Also, the AFM image (Fig. S12, ESI†) of a Pd protected Co film on the substrate shows that nanoclusters form on both MoS2and SiO2. The absence of magnetic domains of Co/SiO2means that the orientations of spin are in a high symmetry phase whose orientations have equal probabilities of pointing in every direction. This could be the reason why XMCD-PEEM cannot observe the magnetic domain, although Co is a ferromagnetic material. In contrast, the presence of magnetic domains is a signature of symmetry lowering in which spins are grouped and oriented into selected directions.

Regarding the XPS evidence of charge transfer from Co to MoS₂, we find it consistent with the theoretical work of Garandel et al. that indicates that Co atoms at the interface bond covalently with the topmost S atoms of MoS₂.²⁶According to that reported work,²⁶the charge transfer at Co/MoS2would result in a spin-polarized metallic interface and facilitate eﬃ- cient spin injection. Another reason motivating us to look into the electronic structures of Co/MoS2and Co/SiO2is the distinct behavior recently reported in Fe/MoS2 (Fig. S8 (ESI†), and ref. 24); neither magnetic domains nor charge transfer between Fe and MoS2was found.

Conclusion

In conclusion, we have proved that a CVD-grown monolayer MoS₂flake can promote domain formation in a subsequently deposited Co layer. Furthermore, it is possible to fine-tune the magnetic behavior of Co/MoS₂ through the crystallinity of MoS2. Finally, according to the XPS evidence of charge donation at Co/MoS2, we suggest that the orbital hybridization at the interface is what distinguishes the magnetic properties of

Co/MoS2here and Fe/MoS2reported earlier.^24,25The interplay between Co and MoS2is electronically originated, and such an interplay has resulted in a spontaneously induced magnetic anisotropy in an ultrathin Co/MoS₂heterojunction.

Methods

High-quality single-crystal monolayer MoS₂flakes were grown inside a tubular furnace equipped with a silica tube (diameter 30 mm). SiO2(90 nm)/Si(001) substrates were cleaned according to a standard procedure and then soaked in a H2SO4/H2O2 (3 : 1) solution for 2 h. MoO3powder (0.01 g) was then positioned on a silver silica boat located at the heating zone of the furnace. The SiO2/Si substrate (size 2 cm 2 cm) was placed face down above the MoO3powder. Sulfur powder was placed in a separate ceramic boat located at the upper stream of the furnace at a temperature of about 170 1C. A flow of ultrahigh-purity Ar gas carried both S and MoO_{3 x}vapors onto the target substrate. The temperature of the furnace was initially raised to 120 1C (500 sccm) for 30 min, and then ramped up to 850 1C at a rate of 20 1C min ¹(200 sccm), allowing the CVD growth of MoS₂. The sample was kept in the environment described above for a further 30 min before passive cooling toB25 1C.

The MoS2 samples grown on the SiO2(90 nm)/Si(001) substrates were loaded into TLS endstation 05B2 and heated at 150 1C for 6 h under ultra-high vacuum (UHV) conditions for outgassing. The Co layers were grown with a commercial EFM3;

their thickness was defined in units of monolayer (ML). The rate of Co deposition was calibrated with the medium-energy electron-diﬀraction (MEED) oscillation recorded during the deposition of Co onto a Cu(001) single crystal. Note that it is necessary to check the structural stability of a 2D layer in a heterojunction. For that, we examine the micro-area XPS spectra taken from Co/MoS₂/SiO₂(Fig. S6, ESI†). Compared to previous publications with ones acquired from CVD growth of MoS₂, ref. 29, and Co-doped MoS₂, ref. 40, the molybdenum Mo 3d and sulfur S 2p spectra reported in this work are in great resemblance to the ones acquired from a single layer of MoS2. We conclude that the chemical bond of monolayer MoS2 is preserved after Co deposition. Our argument above can be strengthened further by the nature of the strong covalent bonds within MoS2, whose melting point is 2375 1C. As the Co deposition (whose melting point is 1495 1C) is accomplished via an EFM3 evaporator at a slow deposition rate (## ML per minute), we believe the way we deposited Co is not likely to damage the atomic structure of MoS2.

After the Co deposition, the sample was transferred into the PEEM chamber²⁷ under UHV conditions for XMCD imaging.

We enhanced the domain images (or XMCD images) by the absorption asymmetry, I_A= (I_L3 I_L2)/(I_L3+ I_L2); that is, each XMCD image (I_A) was actually an asymmetric superposition of two images, I_L2 and I_L3, recorded at L₂ and L₃, respectively.

As this image processing can eliminate geometric inhomogeneity, the contrast in the IA image served to recognize the magnetic domains of varied magnetization directions.^32,33 The exact

(7)

magnetization direction of the domains could not be determined as it was not possible to rotate the sample in situ or to apply an external magnetic field in the PEEM experimental chamber. The system is hence sensitive only to whether the magnetic domains are parallel (brighter) or antiparallel (darker) with respect to the incident light. The XMCD images were leveled by subtracting the polynomial background, which is supposedly a consequence of a shift of the beam spot caused by a change in the photon energy.

The micro-area X-ray absorption spectra (m-XAS) recorded on A and B domains (displayed in Fig. 2(d)) were extracted from a stack of images recorded at a step of 0.2 eV from hn = 750 eV to 810 eV, across the Co L2,3edges.

The m-XPS measurements were performed at beamline 1.2L NanoESCA at the Elettra Synchrotron (Trieste, Italy).²⁸ Before the deposition of cobalt, the MoS2/SiO2samples were outgassed at 250 1C in a UHV preparation chamber for 2 h. Co 2p spectra were recorded using an s-polarized photon energy of 950 eV.

Because of the decreased beam spot size on the sample (o20 mm) it was possible to record m-XPS selectively from the Co/MoS₂flakes and Co/SiO₂regions.

Data availability

All relevant data are available from the authors. Requests for data and materials should be addressed to D.-H. Wei.
