R E V I E W Open Access

Epithelial-myoepithelial carcinoma of the tongue base: a case for the case-report and review of the literature

Peter Peters1,3*, Costa Repanos1, James Earnshaw1, Patrick Stark1, Bryan Burmeister2,3, Lloyd McGuire4,5, Susanne Jeavons6, William B Coman AM1,3


A 60 year old lady was referred to the Princess Alexandra Hospital (Brisbane, Queensland, Australia) tertiary Otolar- yngology, Head and Neck Unit from a peripheral hospital for investigation and management of a tumour at the base of the tongue. Biopsy of the tumour revealed it to be an epithelial-myoepithelial carcinoma of the base of the tongue. This is an extremely rare tumour in this location with only 2 other case reports in the world literature:

the patients were treated with chemo-radiotherapy and surgery respectively. Our patient was made aware of the world literature and was able to make a fully informed decision on her choice of treatment modality and was trea- ted with radiotherapy. Increasingly journals are limiting publication of case reports to“world firsts” only. We present a case where such a policy would have denied patient choice and possibly led to detrimental treatment.

We review the world literature of tongue base epithelial-myoepithelial carcinoma of the tongue.


Epithelial-myoepithelial carcinoma is an rare tumour occurring in the salivary glands, (most commonly in the parotid gland), with a reported incidence of between 0.2% [1] and 1% [2,3] of salivary duct tumours. It is a hybrid tumour, composed of two different tumour enti- ties, each of which conforms to a defined tumour cate- gory [4,5] and based upon the Salivary Gland Register at the University of Hamburg. Specimens collected between 1965 and 1994 showed that only 0.1% of sali- vary gland tumours were hybrid tumours [5]. Other examples of hybrid tumours include mucoepidermoid carcinoma, basaloid-squamous carcinoma, adeno-squa- mous carcinoma, sarcomatoid carcinoma and carcinoma in pleomorphic adenoma with differentiation as squa- mous cell carcinoma as well as adenocarcinoma [5].

Case Report

A 60 year old lady was referred to the Princess Alexan- dra Hospital Head and Neck Clinic in July 2009 follow- ing a biopsy taken from a suspected tumour at the base

of the tongue (BOT). The patient was referred to our unit for ongoing investigation and management. She had noted a one year history of dysphagia and difficulty in moving her tongue. Our patient also noted an unin- tended a 25 kg weight loss over the past year and had had a PEG feeding tube inserted in the interim before being referred to our department. The patient confirmed that she was an ex-smoker with a 30 pack year history but denied alcohol consumption.

On examination there was limited movement of her tongue with significant tethering (Figure 1 and 2). A large mass was palpable predominantly on the right side of the base of the tongue and there were no masses palpable in the neck.

An MRI taken shows an extensive BOT tumour across the midline which extends to involve the right faucial tonsil. The tumour has an intermediate T2 signal with foci of bright T2 fluid within (Figure 3). The intermedi- ate T1 signal tumour shows irregular enhancement fol- lowing Gadolinium (Figure 4, 5). The tumour appears exophytic. The tumour extended inferiorly to the level of the epiglottis which it displaced posteriorly. The ver- tical length of the tumour was 3.7 cm. Small (approx 1 cm) lymphadenopathy was noted bilaterally in level 2

* Correspondence: peter2734@gmail.com

1Department of Otolaryngology Head and Neck Surgery, Princess Alexandra Hospital, Ipswich Rd, Woolloongabba, Queensland, Australia

© 2010 Peters et al; licensee BioMed Central Ltd. This is an Open Access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/2.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.


but this was thought to be clinically unlikely to be involved with tumour in view of the size, morphological appearance and clinical nature of the disease. The appearances of the BOT tumour are not typical for the more common SCC in this location with the irregular bright T2 signal. However an unusual SCC appearance is still be more likely than a minor salivary gland rare tumour based a review of the literature.

A panendoscopy was performed which revealed a 4 cm submucosal lesion with a firm, posterior tongue (Figure 6). The mass extended over the midline, into the inferior half of the tonsil and into the vallecula but the glossal epiglottis was clear of tumour. The mass was not fixed to the mandible. Histological examination of the biopsy samples demonstrated epithelial-myoepithelial carcinoma of the tongue base. The morphology and the pattern of immunoreacitivity are typical for Epithelial- Myoepithelial carcinoma (Table 1 and Figures 7, 8, 9 and 10). The results of the panendoscopy and the biopsy were discussed with the patient and a thorough litera- ture review enabled the multidisciplinary Head and

Figure 1 Extent of limited tongue protrusion due to tumour invasion of tongue muscles.

Figure 2 Close up of the tongue, with the patient protruding tongue maximally.

Figure 3 Axial T2 Fat saturated MRI representing mass invading right base of tongue extending across the midline involving the right faucial tonsil. Mass shows immediate T2 signal enhancement with bright focus within.

Peters et al. Head & Neck Oncology 2010, 2:4 http://www.headandneckoncology.org/content/2/1/4

Page 2 of 7


Figure 4 Sagittal T1MRI, sagittal view, mass located at the base of the tongue.

Figure 5 Axial intermediate T1 Fat saturated MRI, post gadolinium on lesion on right base of tongue. Lesion has irregular enhancement following gadolinium


Neck team to realistically discuss potential treatment options.

Planning by the Radiation Oncology team was under- taken with a view to a 60 Gy treatment over 30 fractions with a 2 cm margin around the primary tumour. Her treatment was well tolerated although she did require daily hyoscine injections to dry up excessive secretions.

She has had a complete clinical response and will be fol- lowed with a new MRI in 6 months.

Literature Review

2 cases have been reported in the literature of epithelial- myoepithelial carcinoma in the base of the tongue [1,6]

with contrasting modes of treatment (Table 2).

These two cases were both published as“world firsts”

and whilst sharing a common histology of tumours in an identical location (base of tongue), were where mana- ged in different ways. This allowed our team to present the patient with options for management of her rare tumour.


There are three major salivary glands–parotid, subman- dibular, and sublingual–as well as innumerable minor salivary glands distributed throughout the mucosa of the oral cavity and nasopharynx. All these glands are subject to inflammation or to the development of neoplasms

[7]. These glands give rise of over 30 histologically dis- tinct tumours [7].

The tumours in Table 3 represent only around 2% of human neoplasms and occur predominantly in the paro- tid gland (60-80%), followed by the submandibular gland (10%) and then the minor salivary glands (including the sublingual gland) [7]. Interestingly, the parotids have the lowest level of malignancy (15-30%), with the subman- dibular gland (40%) and the minor salivary gland having a 50% malignancy rate, whilst the rate of malignancy in the sublingual gland is 70-90% [7].

Epithelial-myoepithelial carcinomas are defined, histo- logically, by tubular or ductal structures lined by both basal myoepithelial cells and luminal epithelial cells similar to normal intercalated salivary gland ducts.

Whilst neoplasms are monoclonal and, as such, com- prise one cell type, there are uncommon tumours at all sites which show divergent differentiation. In some case, as for this tumour, this can be explained by the com- mon precursor cells for both of the cell types repre- sented in tis particular tumour.

Immunohistochemistry for expression of different cell proteins is essential in identifying the two cell types demonstrated in this tumour. The outer basal or myoe- pithelial cell layer expresses p63 (figure 8), low molecular weight cytokeratins (CK5/6) and variably expresses other cytokeratin subclasses because these cells unique in expressing both epithelial and smooth muscle characteris- tics reflecting their normal function of lining ducts AND being capable of contraction to aid salivary fluid flow. The inner luminal layer is typical of all epithelial cells in expressing cytokeratin but not smooth muscle proteins.

This tumour displayed the typical and characteristic features of Epithelial-Myoepithelial Carcinoma with an inner luminal epithelial layer (cytokeratin positive only Figures 7 &9) and an outer myoepithelial cell layer (cytokeratin positive Figure 9) and co-expression of smooth muscle proteins (Figures 8 &10).

Table 1 Histology results for biopsy IMMUNOHISTOCHEMISTRY RESULT

p63 Positive in basal cells (nuclear)

CK5/6 Positive in luminal cell (cytoplasmic);

positive in basal cell (Golgi) HMWCK (CK34) Positive in luminal cell (cytoplasmic);

positive in basal cell (Golgi)

SMA Positive in basal cells

AE1/AE3 Positive in luminal cells

Figure 6 Intraoperative views of the mass at the base of the tongue.

Peters et al. Head & Neck Oncology 2010, 2:4 http://www.headandneckoncology.org/content/2/1/4

Page 4 of 7


Epithelial-myoepithelial carcinomas, whilst rare, most commonly occur in the parotid gland, but as with all salivary gland tumours, may arise anywhere in the naso- oro-pharynx in relation to minor salivary glands. By definition, an epithelial-myoepithelial carcinoma is a hybrid tumour, which is a tumour consisting of two dis- tinctly different entities, each of which conforms to an exactly defined tumour category [5].

Epithelial-myoepithelial are, low grade malignant tumours although some tumours do exhibit more rapid growth and high grade behaviour. Histologically the high grade tumours show evidence of dedifferentiation which is not seen otherwise. Tumour behaviour can, therefore to some extent, be predicted by histologic fea- tures. In this case, the prediction would low grade malignancy.

During a study of 954 consecutive salivary gland tumours, Fonseca et al [8] found 22 epithelial-myoe- pithelial carcinomas (2.3%). In all these cases, the

tumours were excised with the associated salivary gland.

Follow up of these patients indicated a recurrence rate of 41% with a 5 year survival rate of 87.5% and a 10 year survival rate of 67.5%. This rate of recurrence was similar to what was observed by Corio et al (39%) [9].

A review of the literature has revealed only two pre- vious instances at the base of tongue [6,10] which were treated with chemo-radiation and surgery respectively without recurrence over a year later. Surgery and chemo- radiation are the two treatment modalities reported in the literature to have been used in base of tongue tumours and it is extremely helpful in a tertiary referral centre to have instant access to the only published experience with this particular tumour in this location.

It is important for very rare cases such as this to be reported particularly in respect of behaviour and treat- ment so as to build a database for these tumours. The current trend in journals not to publish case reports not

Figure 7 AE1/AE3 Immunohistochemistry stain of epithelial- myoepithelial carcinoma.

Figure 8 p63 Immunohistochemistry stain of epithelial- myoepithelial carcinoma in the base of the tongue.

Figure 9 CK5/6 Immunohistochemistry stain of epithelial- myoepithelial carcinoma, biopsy taken from mass at base of tongue.

Figure 10 SMA stain, Immunohistochemistry stain from mass at the base of tongue in a 60 year old female patient.


only discourages junior researchers from getting on the publishing ladder but, as in our patient’s case, could have severely limits evidence based options. Journals not publishing case report include CA:A Cancer Journal for Clinicians (Impact factor 2007 69.26) and the Journal of the American Medical Association (JAMA - Impact fac- tor 2007 25.5), both highly respected journals with high ranking ISI impact factors.

Whilst the authors do not advocate that every journal should practice publishing case reports that have been published multiple times in the past, we would argue that limiting the world literature to“world firsts” will be to the detriment of our patients.


Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the Editor-in-Chief of this journal.


One of the authors (CR) received travel and fellowship funding from the HCA international foundation and would like to thank them for their generosity.

Author details

1Department of Otolaryngology Head and Neck Surgery, Princess Alexandra Hospital, Ipswich Rd, Woolloongabba, Queensland, Australia.2Department of Radiation Oncology, Princess Alexandra Hospital, Ipswich Rd,

Woolloongabba, Queensland, Australia.3School of Medicine, University of Queensland, St Lucia, Queensland, Australia.4Queensland Health Pathology Service, Gold Coast Hospital, Nerang St, Southport, Queensland, Australia.

5Faculty of Health Sciences and Medicine, Bond University, Robina, Queensland, Australia.6Radiology Department, Princess Alexandra Hospital, Ipswich Rd, Woolloongabba, Queensland, Australia.

Authors’ contributions

PP performed the literature review, participated in the clinical care of the patient and drafted the manuscript. CR drafted the“case for the case report”

component of the manuscript and assisted with the overall manuscript and participated in the clinical care of the patient. JE performed the

panendoscopy of the patient. PS assisted with the literature review and clinical care of the patient. LM reviewed the biopsy specimen histology and determined the diagnosis. BB directed the radiation therapy component of the treatment. SJ reviewed the MRI for technical radiology input. WC was the consultant surgeon in overall care of the patient. All authors read and approved the final manuscript.

Competing interests

The authors declare that they have no competing interests.

Received: 31 December 2009

Accepted: 2 February 2010 Published: 2 February 2010


1. Kumai Y, Ogata N, Yumoto E: Epithelial-myoepithelial carcinoma in the base of the tongue: a case report. American journal of otolaryngology 2006, 27:58-60.

2. Seifert G, Sobin LH: Histological typing of salivary gland tumours. World Health Organization International Histological Classification of Tumours Berlin:

Springer-Verlag, 2 1991.

3. Deere H, Hore I, McDermott N, Levine T: Epithelial-myoepithelial carcinoma of the parotid gland: a case report and review of the cytological and histological features. J Laryngol Otol 2001, 115:434-436.

4. Kainuma K, Oshima A, Suzuki H, Fukushima M, Shimojo H, Usami SI: Hybrid carcinoma of the parotid gland: report of a case (epithelial-myoepithelial carcinoma and salivary duct carcinoma) and review of the literature.

Acta Otolaryngol 2009, 1-5.

5. Seifert G, Donath K: Hybrid tumours of salivary glands. Definition and classification of five rare cases. Eur J Cancer B Oral Oncol 1996, 32B:251-259.

Table 2 Comparison of previous cases

Puri et al 2004 [6] Kumai et al 2006 [10] Peters et al

Patient Male 48 yo Male 76 yo Female 60 yo

Base of Tongue Location

Right Left Right

Tumour Size 50 mm × 30 mm 40 mm × 20 mm 37-15 mm

Treatment Modality

3 drug Chemotherapy (cisplatin, doxorubicin and 5- Fluorourcil) Radiotherapy (66 Gy) (Coblalt Teletherapy Unit)

Surgery (subtotal glossectomy, bilat neck dissection and rectus abdominis flap)

Radiotherapy, 60 Gy over 30 fractions, 2 cm margin

Follow up Nil Recurrence (14 months) Nil recurrence (19 months) Complete clinical


Table 3 Histologic Classification and Incidence of Benign and Malignant Tumours of the Salivary Glands [7]


Pleomorphic adenoma (50%) (mixed tumour) Mucoepidermoid carcinoma (15%)

Warthin tumour (5% to 10%) Adenocarcinoma (NOS) (10%)

Oncocytoma (1%) Acinic cell carcinoma (5%)

Other adenomas (5% to 10%) Adenoid cystic carcinoma (5%)

Basal cell adenoma Malignant mixed tumour (3% to 5%)

Canalicular adenoma Squamous cell carcinoma (1%)

Ductal papillomas Other carcinomas (2%)

Peters et al. Head & Neck Oncology 2010, 2:4 http://www.headandneckoncology.org/content/2/1/4

Page 6 of 7


6. Puri T, Singh K, Sharma DN, Khurana N: Epithelial-myoepithelial carcinoma of the base of tongue: pathology and management. Indian J Cancer 2004, 41:138-140.

7. Kumar V, Abbas AK, Fausto N: Robbins and Cotran pathologic basis of disease Philadelphia: Elsevier Saunders, 7 2005.

8. Fonseca I, Soares J: Epithelial-myoepithelial carcinoma of the salivary glands. A study of 22 cases. Virchows Arch A Pathol Anat Histopathol 1993, 422:389-396.

9. Corio RL, Sciubba JJ, Brannon RB, Batsakis JG: Epithelial-myoepithelial carcinoma of intercalated duct origin. A clinicopathologic and ultrastructural assessment of sixteen cases. Oral Surg Oral Med Oral Pathol 1982, 53:280-287.

10. Kumai Y, Ogata N, Yumoto E: Epithelial-myoepithelial carcinoma in the base of the tongue: a case report. Am J Otolaryngol 2006, 27:58-60.


Cite this article as: Peters et al.: Epithelial-myoepithelial carcinoma of the tongue base: a case for the case-report and review of the literature.

Head & Neck Oncology 2010 2:4.
