Reduction of motion artifacts for PET imaging by respiratory correlated dynamic scanning

Keh-Shih Chuang

^a,

, Tzong-Jer Chen

^b

, Chia-Chi Chang

^a

, Jay Wu

^c

, Sharon Chen

^a

, Liang-Chih Wu

^d

, Ren-Shyan Liu

^d

aDepartment of Nuclear Science, National Tsing-Hua University, Taiwan

bDepartment of Medical Imaging Technology, Shu-Zen College of Medicine and Management, Taiwan

cDepartment of Radiological Technology, Central Taiwan University of Science and Technology, Taiwan

dDepartment of Nuclear Medicine, National PET/Cyclotron Center, Taipei Veterans General Hospital, Taiwan Available online 18 September 2006

Abstract

Organ motion caused by respiration is a major challenge in positron emission tomography (PET) imaging. This work proposes a technique to reduce smearing in PET imaging caused by respiratory motion. Dynamic scanning at 1 frame/s is used. A point source, used as a marker, is attached to the object’s abdomen during the scan. The source position in the projection view moves with respiratory motion and can be used to represent the respiratory phase within the time interval in which each frame data are acquired. One hundred and twenty frames are obtained for each study. The range of the positions of the marker is divided into four groups, representing different respiratory phases. The frames in which the organ positions (phases) are the same summed to produce a static sub-sinogram.

Each sub-sinogram then undergoes regular image reconstruction to yield a motion-free image. The technique is applied to one volunteer under both free and coached breathing conditions. A parameter called the volume reduction factor is adopted to evaluate the effectiveness of this motion-reduction technique. The preliminary results indicate that the proposed technique effectively reduces motion artifacts in the image. Coached breathing yields better results than free breathing condition. The advantages of this method are that (1) the scanning time remains the same; (2) free breathing is allowed during the acquisition of the image; and (3) no user intervention is required.

PACS: 87.58.Fg

Keywords: Respiration; PET; Motion artifact; Motion correction; Dynamic scan

1. Introduction

Patient movement due to respiration is known to inﬂuence lung, breast and abdomen treatments in radiation oncology. Respiration requires that the treatment volume is increased, such that a larger normal tissue volume is irradiated to higher doses. Osman et al.

[1]

reported that patient motion causes the fusion of the image sets to be imperfect. Osman et al.

[2]

investigated the respiratory motion artifacts in PET emission images obtained follow- ing CT attenuation correction, and concluded that

respiratory motion artifacts were noted in images of most patients as a curvilinear cold area at the lung/diaphragm interface.

The time taken to perform a PET scanning signiﬁcantly exceeds the time for which a patient can hold his or her breath, and respiratory motion artifacts importantly degrade image quality. Motion artifacts have two main effects

[3–5]. First, it affects the accuracy of

quantitation and reduces the measured standard uptake value (SUV). Second, it causes the lesion volume to be overestimated and increases the planned target volume and, therefore, the radiation dose delivered to the normal tissues. Eliminating the artifacts of respiration motion improve patient care.
