Dynamic Characteristics Analysis and Testing of Polymer Granite Structures 蔡連錦、羅正忠
E-mail: [email protected]
ABSTRACT
This paper explores polymer granite application on the structures manufacturing of machine tools. This kind of material has very good damping characteristics, which may effectively improve machine’s performances such as low vibration, high machining accuracy and efficiency. In this research paper, we have three different testing workpieces of rectangular-bars, square-tables, and horizontal welding structures. At first, rectangular-bars of steel and polymer granite material, which are not only analyzed by finite element COSMOS software but also tested by a equipment that contains a frequency analyzer, accelerators, and a hammer.
Secondly, analysis and testing are executed on three square-tables, which are made from different material of cast iron, polymer granite, and quartz. The analysis software and testing equipments are the same as rectangular-bars. For horizontal welding
structures of carbon steel, dynamic characteristics of polymer granites filled and unfilled welding structures are tested and compared.
ANSYS finite element analysis is also used to compare with modal testing results of the above equipment. Polymer granites filled welding structure has higher resonance frequency and much lower resonance amplitude than polymer granites unfilled welding structure. It shows that polymer granite greatly improves dynamic characteristics of the structure. From the software analysis and testing results of three different testing workpiece, we can get a conclusion: The damping ratio of polymer granite is much higher than that of the other three different material (steel, cast iron and quartz). Therefore, we can say that polymer granite is a kind of good material, which can greatly reduce the vibration of machine tools.
Keywords : polymer granite ; dynamic characteristics ; finite element analysis ; modal testing ; damping ratio Table of Contents
第一章 緒論 1.1 研究動機...1 1.2 研究目標...2 1.3 研究內容...4 1.4 研究步 驟...5 第二章 國內外之研究情況 2.1 國內目前研究發展情況...11 2.2 國外研究及市場運用情 況...14 第三章 分析與測試之研究方法 3.1 研究方法...19 3.1.1 分析過程...19 3.1.2 模態 分析的參數...22 3.1.3 模態分析的目的...22 3.2 使用有限元素法作結構分析...23 3.3 模態測
試...24 3.3.1測試設備...24 3.3.2測試步驟...27 3.3.3分析方法...28 第四 章 分析與測試 4.1 有限元素分析...29 4.1.1 試棒分析...29 4.1.2 工作台分析...32 4.1.3 橫 樑分析...35 4.2 量測分析...42 4.2.1 測試棒量測...42 4.2.2 工作台量測...45 4.2.3 橫樑量測...49 第五章 結論...58 參考文獻...59
