Ferromagnetic tendency at the surface of CE-type charge-ordered manganites

(1)

Ferromagnetic tendency at the surface of CE-type charge-ordered manganites

Shuai Dong,^1,2,3Rong Yu,^1,2Seiji Yunoki,^1,2J.-M. Liu,^3,4 and Elbio Dagotto^1,2

1Department of Physics and Astronomy, University of Tennessee, Knoxville, Tennessee 37996, USA

2Materials Science and Technology Division, Oak Ridge National Laboratory, Oak Ridge, Tennessee 32831, USA

3Nanjing National Laboratory of Microstructures, Nanjing University, Nanjing 210093, China

4International Center for Materials Physics, Chinese Academy of Sciences, Shenyang 110016, China 共Received 8 May 2008; revised manuscript received 8 July 2008; published 15 August 2008兲 Most previous investigations have shown that the surface of a ferromagnetic material may have antiferromagnetic tendencies. However, experimentally, the opposite effect has been recently observed—

ferromagnetism appears in some nanosized manganites with a composition such that the antiferromagnetic charge-ordered CE state is observed in the bulk. A possible origin is the development of ferromagnetic correlations at the surface of these small systems. To clarify these puzzling experimental observations, we have studied the two-orbital double-exchange model near half doping,n= 0.5, using open boundary conditions to simulate the surface of either bulk or nanosized manganites. Considering the enhancement of surface charge density due to a possible AO termination共A= trivalent/divalent ion composite, O = oxygen兲, an unexpected surface phase-separated state emerges when the model is studied using Monte Carlo techniques on small clusters. This tendency suppresses the CE charge ordering and produces a weak ferromagnetic signal that could explain the experimental observations.

DOI:10.1103/PhysRevB.78.064414 PACS number共s兲: 75.70.Rf, 75.47.Lx, 75.75.⫹a

I. INTRODUCTION

Perovskite manganites—with a general formula AMnO₃, whereAis the composite of trivalent rare-earth elements and divalent alkaline-earth elements—have attracted consider- able attention since the discovery of the colossal magnetore- sistance 共CMR兲 effect.¹ Both experimental and theoretical studies in the last decade have unveiled a plethora of phases in manganite compounds, with very different macroscopic properties but very similar energies.^2–5The CMR and colossal electroresistance⁶effects, which correspond to the obser- vation of drastic nonlinear responses of the manganites to external stimulations, can be understood as a result of the intense competition between the ferromagnetic共FM兲metal- lic phase and antiferromagnetic共AFM兲charge-ordered共CO兲 insulating phases.^7–10

This phase competition is not only sensitive to applied external fields but also to the geometric and chemical envi- ronments of the surface of the system under study. In nanosized materials there is a high surface-to-volume ratio and, as a consequence, the surface effects play a crucial role. This influence of the surface has been observed in a series of recent experiments. On one hand, in materials where a FM state is stabilized in the bulk, an AFM or spin-glass surface state is found.^11–15 On the other hand, FM tendencies at the surface of nanosized manganites presenting AFM/CO bulk order have also been observed.^16–27 The first tendency toward surface AFM ordering usually appears in nanosized FM or ferrimagnetics materials²⁸ and can be understood within the following naive picture. Generally, in strongly correlated electron materials, the charge conducting properties are de- termined by the ratioU/W, whereUis the Hubbard model’s Coulomb repulsion andWis the electron hopping bandwidth.

At the surface, the bandwidth W will be suppressed due to the reduction in dimensionality while the on-siteU will not change. Therefore, the enhancement of U/W at the surface

could prefer an insulating surface over a metallic one. The insulating phase in manganites is usually AFM. However, finding a model and rational for the other tendency found experimentally—namely, a FM tendency at the surfaces of CE manganites—is not straightforward. A theoretical model that can explain the FM tendency at the surface should be able to consider the following four experimental signatures.

First, the CO phase is significantly weakened. The CO transition peak in the magnetization 共M兲 vs temperature 共T兲 curve is suppressed until it completely disappears with decreasing the size of the manganite systems.^16–21Second,M is enhanced at low T and a FM-type hysteresis loop is observed.^18–24Third, the exchange bias effect emerges共indi- cating a coupling between phases with different spin orders兲.^18,23 Finally, the measurement of magnetocaloric properties and low-Tspecific heat also suggest the existence of a FM contribution.^25–27

Theoretically, previous investigations have mainly paid attention to the surface effects of FM manganites^29–31 whereas the study of the surface of AFM manganites has been rare. To understand these phenomena, it is reasonable to partition the nanosized 共with typical scales of 10– 10² nm兲 system into two regions: an inner core and a surface shell.

The physical properties of the inner core should be compa- rable to those of the bulk material. In contrast, the properties of the surface shell can be different from those of the bulk.

The lower coordination number at the surface, which effec- tively reduces the superexchange coupling, may give rise to a FM tendency at that surface. Following this idea, in previous investigations a core-shell model was proposed assuming an AFM core wrapped by a fully FM surface shell.³² This model fits some experimental results well, but in this sce- nario it is already established from the start共the nature of the phases at both the core and surface兲. As a consequence, it is too phenomenological to better understand the true physical origin of the AFM-FM transition at the surface. In particular, the assumption of a fully FM shell conflicts with some ex-

(2)

perimental results. Due to the weak value of the magnetiza- tionM, the calculated thickness of the FM shell can be even thinner than one “molecular” layer, which indicates that assuming a fully developed FM spin order at the surface is not correct. Thus, theoretical studies using realistic microscopic Hamiltonians and unbiased assumptions about the surface are necessary to clarify the experimental observations found at the surface of nanosized AFM/CO manganites.

In this paper, the core-shell model is incorporated into a two-orbital Hamiltonian for manganites. We show that the unscreened Coulomb interactions lead to an increase in electron density on the surface. Monte Carlo 共MC兲simulations reveal that this increase in the density drives the surface layer from an AFM/CO state to an unexpected phase-separated state, as opposed to a fully developed FM state. This surface phase-separated state exhibits clear FM signatures, but they are weak, compatible with the experimental observations.

II. MODEL

To better understand the physics at the surface, here we consider a two-orbital model Hamiltonian for manganites that includes both finite superexchange coupling and the effect of Jahn-Teller phonons. As a well-accepted approxima- tion for manganite models, we consider the limit of infinite Hund coupling. The Hamiltonian reads

H= −

兺

具ij典

␣␤

t_r^␣␤⍀ijc_i^†_␣c_j_␤+J_AF

兺

具ij典

S_i·S_j+

兺

_i ^共^⑀ⁱ⁻^␮^兲ⁿⁱ

+␭

兺

_i ^共^Q¹ⁱⁿⁱ⁺^Q²ⁱ^␶^xi⁺^Q³ⁱ^␶^zi^兲⁺¹₂

兺

_i ^共^2Q¹ⁱ² ⁺^Q²ⁱ² ⁺^Q³ⁱ²^兲^.

共1兲 Here, the first term is the two-orbital double-exchange interaction.␣and␤ denote the two Mnegorbitalsa共dx²−y²兲and b 共d_3z2−r²兲. c_ia 共c_ia^†兲 annihilates 共creates兲 an e_g electron in orbital a of site i with its spin parallel to the localized t_2g spin S_i. The hopping direction is denoted by r. As discussed in previous literature,^2,3 the hopping amplitudes are t_xâa=t_yâa= 3t_x^bb= 3t_y^bb= 3/4, t_yâb=t^ba_y = −t_xâb= −t_x^ba=

冑

3/4, t_zâa=t_zâb=t_z^ba= 0, and t_z^bb= 1 共energy unit兲. The infinite Hund coupling generates the factor ⍀ij= cos共␪i/2兲cos共␪j/2兲 + sin共␪i/2兲sin共␪j/2兲exp关−i共␾i−␾j兲兴, where ␪ ând ␾ ^{are the} angles of the t_2g spins in spherical coordinates. The second term is the superexchange interaction between nearest- neighbor共NN兲t_2gspins. In the third term,␮is the chemical potential.⑀icorresponds to a site-dependent Coulomb potential. The origin and relevance of this term will be discussed in detail later in this section.niis theegcharge density at site i. The fourth term stands for the electron-phonon coupling.

The Q’s are phonons corresponding to Jahn-Teller modes 共Q2 and Q₃兲 and the breathing mode 共Q1兲. ␶ is the orbital pseudospin operator giving ␶x=c_a^†cb+c_b^†ca and ␶z=c_a^†ca

−c_b^†cb. The last term is the elastic energy of the phonons. For simplicity, we have already assumed in this model that both the t_2g spins and the phononic degrees of freedom are clas- sical variables. The above-described Hamiltonian is solved via a combination of exact diagonalization and MC tech-

niques. Classicalt_2gspins and phonons evolve following the MC procedure and, at each MC step, the fermionic sector of the Hamiltonian is numerically exactly diagonalized. The first 10⁴MC steps are used for thermal equilibrium and another 6⫻10³MC steps are used for measurement. More details of the Hamiltonian and MC technique can be found in Refs. 2and3.

Since a FM tendency is often found in half-doped^16–18,24 or nearly half-doped^19,26 nanosized manganites, and since a CE-type AFM/CO phase usually appears in half-doped narrow-band manganites,³³ we solve the two-orbital model using densities corresponding to half-doped systems and for couplings where a bulk CE phase exists. This can be done by tuning the couplings 共JAF,␭兲to be within the CE regime of the phase diagram obtained in previous studies.^34,35Although only one set 共J_AF,␭兲 will be investigated in the studies described below, we believe that our qualitative conclusions remain valid for other choices of parameter sets, as long as they are within the CE region of the phase diagram.

Although there are several possible surface directions in real cases, here only the simplest case—i.e., the 共001兲 surface—will be considered similarly as in most former theoretical investigations in this context.^29–31,36 Strictly speak- ing, the surface problem should be considered on a three- dimensional 共3D兲 half-infinite cubic lattice, e.g., infinite in thexandydirections, but semi-infinite in thezdirection. In practice, to address this problem numerically the above two- orbital model Hamiltonian is studied using aL⫻L⫻Lcubic lattice as shown in Fig. 1. Periodic boundary conditions 共PBCs兲are applied in both thexandydirections. Following the core-shell-model idea discussed in Sec. I, in the zdirec- tion, the spins in the bottom layer共z=L兲arefixedhere so that they have the same CE-type AFM pattern as in the bulk. By this procedure, the properties of the half-infinite core are encoded in the bottom layer in our model. Hence, the rest of L− 1 layers are to be considered as the outer shell. To better justify the above assumption, L must be large enough such that surface effects are limited within the outer L− 1 shell layers. Our results below suggest that in practice L= 4 is enough for these purposes. This is fortunate since the numerical studies described here are rather CPU-time consum- ing.

For the surface layer共z= 1兲, we have to take into account the “termination” procedure. In this paper, a clean-limit AO FIG. 1. 共Color online兲Sketch of the model and geometry used in this investigation. Left: A cubic lattice with one open surface 共yellow layer兲. All spins in the bottom layer共orange兲are frozen to the CE-type AFM pattern. Right: The chemical unit taken from the surface layer of the cube at the left. TheAO sheet termination is considered here. Thus, the surface formula isA_1.5MnO_3.5.

(3)

sheet is considered as the termination, which makes the “molecular composition” of the surface layer to be A_1.5MnO_3.5. Therefore, the outmostAO sheet transfers an extra 0.25 electron per site to the nearby Mn cations and it is positively polarized. The polarizedAO sheet introduces an unscreened Coulomb attraction on the surface. As a result, those extra electrons must be localized near the surface. The effect of this surface Coulomb attraction has been taken into account here via an effective negative potential near the surface; ⑀i

=V⬍0 when i belongs to the surface layer and⑀i= 0 other- wise. This may be justified because of the typical short Thomas-Fermi-type screening length found in many of these materials. The boundary condition on the surface layer is then set to be open. The consideration of the AO sheet has another important effect—it keeps the oxygen octahedrons complete for the outmost Mn cations. Therefore, the phonon modes do not need to be changed even for the surface layer.

For the phonons, PBCs are used in all directions for simplicity. This will not affect much the central physics discussed in this paper since the oxygen displacements along the z axis are negligible in both the FM and CE-type AFM phases.³⁷In addition to theAO termination, the other possible choice for the surface is a clean-limit MnO₂ sheet as the termination, but this will not be considered in our current model. How- ever, the possible effects of this alternative termination will also be discussed in Sec. III.

To contrast results with those of the open-surface case, the model will also be studied following assumptions that address the bulk material. This corresponds to using PBCs in all directions, for both spins and phonons, and without freez- ing spins anywhere. Both simulations are performed at T

= 0.02 共experimentally, it corresponds to 50– 100 K兲. To simulate the bulk material, we set ⑀i= 0 for all sites. The parameters J_AF= 0.1 and␭= 1.2 are used to obtain a stable CE phase with an average density 具ni典= 0.5. Note that it is well known that the CE phase is stable over a broad range of couplings of the half-doped manganites; thus, this selection of parameters should not be considered arbitrary or fine tuned. The stability of the CE phase is also confirmed in the present simulations by analyzing the spin and charge structure factors, which will be discussed in detail in the Sec. III.

As observed in Fig. 2共a兲, this corresponds to choosing the chemical potential in the window −1.1⬍␮⬍−0.95. These parameters will also be adopted in our subsequent simulation of the open-surface model.

To obtain reasonable results from the simulation of the open-surface model, we have to set the Coulomb potential to an appropriate value. Actually, an optimal value of Vexists in order to fulfill the following three criteria: first, the average density per site of the entireL⫻L⫻Lsystem具n_i典should be equal to共0.5+ 0.25/L兲= 0.5625 to keep the charge neutral;

second, the chemical potential should remain within 共−1.1,

−0.95兲, which is required to have the CE phase stable far from the surface; and third, the charge density in the bottom layer should be very close to 0.50 to match the frozen CE type. In order to find the optimalV, we tested several values from 0 to −0.6 stepped by −0.1. In this range, V= −0.4 was found to be a proper parameter at␮= −1. Thus,V= −0.4 was the value adopted in the following simulations.

III. RESULTS AND DISCUSSION

Using共as initial configuration兲a perfect CE spin pattern³⁸ and random phonons, the MC simulation was carried out under the assumption V= −0.4 for the open-surface model.

The averaged egcharge density as a function of␮ ^{is shown} in Fig. 2共b兲, allowing us to compare the results for the bulk material model with those of the open surface. An interesting result is that the n= 0.5 plateau in the bulk model, which corresponds to the stable CE phase, disappears in the open- surface model. The charge density increases with increasing chemical potential but it has large fluctuations 共see error bars兲, suggesting that the system presents a strong competition between phases with different densities. In the following, we will focus on the properties at␮= −1 with the average total charge density close to 0.5625.³⁹

To understand the origin of the different average charge density between bulk and open-surface models shown in Fig.

2共b兲, it is important to analyze theeg charge density at each layer. The results are shown in Fig.3共a兲. The charge density is almost exactly 0.50 at the bottom layer and fluctuates around 0.50 in the two middle layers. The most prominent change occurs at the surface layer, where the charge density increases to 0.75, due to the presence of the Coulombic term.

As expected, the extra 0.25 electron from the outmost AO sheet is mainly located in the first Mn sheet, which offsets the Coulomb interaction arising from the outmost AO sheet for the Mn cations of the second layer. This is consistent with FIG. 2. 共Color online兲The totale_gcharge density as a function of the chemical potential usingL= 4.共a兲is for the case of the bulk material model. The corresponding NN spin correlation is also shown. There is a具n_i典= 0.50 plateau with the NN spin correlation of

⬃−0.3 in the range −1.1⬍␮⬍−0.95, indicating a stable CE phase.

共b兲contrasts the results for the open-surface and the bulk material models near half doping.

(4)

ab initio calculations showing that, for the AO termination, the uncompensated electrons are accumulated mainly at the surface.³⁶ This result is also consistent with the assumption that ⑀iis nonzero only for the first layer.

It should be noted that the density of 0.75 usually corresponds to a FM phase in bulk manganites as indicated in Fig.

2共a兲. If the bulk phase diagram remains valid at the surface, we would expect a FM state there. Then, the FM tendency could be naturally explained as a result of a density-driven transition. To verify this possible FM tendency, the average NN spin correlation as a function of layer index is shown in Fig.3共b兲. Starting from the bottom layer共L= 4兲, we find that the in-plane NN spin correlations are almost zero for layers L= 4 and L= 3, implying that the FM and AFM links have almost the same population. The interlayer correlation between these two layers is close to −1, indicating a fully AFM connection between the two layers. These are consistent with the picture that a CE AFM state is stabilized in these two layers given that the charge density is about 0.50. Interest- ingly, we see an increase in both the in-plane and interlayer NN spin correlations as we approach the surface. Both the correlations in the first layer and between the first and second layers take positive values and they display a clear FM tendency at the surface layer. But the positive value for the in-plane correlation is rather small 共⬃0.15兲 at the surface layer, which suggests that the state is only partially FM.

Therefore, the idea of a density-driven transition is too sim- plistic and not quite correct. This already shows an interesting conclusion of our research—the phase diagram at the

surface cannot be obtained by merely analyzing the bulk phase diagram at the appropriate charge density, but a special investigation is needed to clarify the surface’s properties.

To visualize the nature of the surface state more explicitly, we study the distribution of local charge density on the surface layer. In a FM phase, the distribution of local charge densityniis approximately uniform, in contrast to the charge disproportion typical of an AFM/CO phase.⁴⁰ The distribution of local charge density on the surface layer of the model studied here is presented in Fig. 4共a兲 and the result at the bottom layer is also shown in the same figure for contrast.

From the regular charge pattern, it is clear that the CE charge ordering in the bottom layer is very stable. Since the CE spin pattern is fixed at the bottom layer, the charge disproportion between large-density sites共bridge sites of the zigzag chains兲 and small-density sites 共corner sites of the zigzag chains兲 will not be smeared by MC average. However, for the surface layer, the charge distribution is not uniform and it is not regularly distributed. In some sites, the densities are large and close to 1, but in other sites the densities can be as low as approximately 0.5. This inhomogeneous distribution per- sists prominently even in the MC-averaged result, which rules out the possibility of observing a nonuniform charge state due to thermal fluctuations. This inhomogeneity can also be confirmed from the orbital occupation as shown in Fig.4共b兲. In contrast to the distinct CE-type orbital ordering in the bottom layer, the orbital distribution in the surface layer shows two regions corresponding to charge inhomogeneity. The high-density region shows an orbital ordering similar to the case in undoped manganites, in contrast to the low-density region which shows the orbital disorder similar to the case in FM manganites. In addition, the MC-time evolution of the e_g charge density is presented in Fig. 4共c兲, showing that the tunneling events are prominent among several possible densities. These tunneling events are characteristic of a first-order phase transition varying ␮ rather than standard thermal fluctuations.⁴¹ Therefore, the inhomogeneous charge distribution at the surface should be attributed to tendencies in the model toward nanoscale electronic phase separation,^2,3similarly as those observed in bulk simulations in other regions of parameter space.

To quantitatively reveal the competing phases that appear at the surface, the spin structure factorS共q兲for each layer is calculated via a Fourier transformation of the spin- correlation function⁴²

S共q兲= 1

L⁴

兺

_ij ^Sⁱ^·^S^j^e^iq·共^rⁱ^−r^j^兲^. ^共²^兲

By monitoring theq-dependent spin structure factor, we may detect possible weak spin-order signals in the complicated real-space-spin pattern^35,43 because each spin order corresponds to a unique set of characteristicqvectors.^44–47In Fig.

5共a兲, theS共q兲’s for some possible components共summed over all characteristic q vectors for each spin order兲 are shown layer by layer. For the bottom layer, which is frozen into a CE spin pattern, both the C and E components contribute 50%, respectively, as expected. The CE-phase tendencies FIG. 3. 共a兲Thee_gcharge density for each layer共counted from

the surface兲. 共b兲 The corresponding averaged NN spin correlation within共integer index兲and between共half-integer index兲layers.

(5)

become gradually weaker with decreasing layer index indicated by the decreasing values and large fluctuations of the correspondingS共q兲. At the surface, the C component is very weak共⬃10%兲and the dominating components here are FM 共⬃40%兲 and E 共⬃30%兲. In this case, the E value does not match the C value anymore because the site regions where n_i⬇1 can also contribute to the E-type order.⁴⁸

In addition to the S共q兲 spin structure factor, the charge structure factorC共q兲in each layer is also calculated to char- acterize the charge ordering

C共q兲= 4

L⁴

兺

_ij ^共nⁱ⁻ⁿ^l^兲共n^j⁻ⁿ^l^兲e^iq·共^rⁱ^−r^j^兲^, ^共3兲

where nl is the average density of each layer. Here, only C共␲^,␲兲is shown in Fig.5共b兲since all other components are very close to zero. For the CE phase at the bottom layer, C共␲^,␲兲 is about 18%, a result consistent with the expected charge ordering with charge disproportion of ⬃0.4 共the charge difference between high- and low-density sites兲. De- creasing the layer index,C共␲^,␲兲decreases monotonically as we move toward the surface until it completely disappears at the surface. This is also straightforward to understand since charge ordering usually accompanies the AFM phases in- stead of the FM ones, even in bulk manganites.

In the above simulation, the ground state is a robust CO CE phase by fixing the proper J_AF and ␭. Therefore, it is worth to address the other possible cases in real half-doped manganites. Here we will give a brief analysis based on the half-doped phase diagram obtained in previous works.^34,35 On one hand, by decreasing J_AFonly, the ground phase can change from the CE to A-type AFM then finally to FM FIG. 4.共Color online兲共a兲Thee_gcharge distribution correspond-

ing to the surface layer 共left兲 and bottom layer 共right兲. Here are shown both a typical MC “snapshot” 共upper panels兲 and MC- averaged results共lower panel, averaged over 6000 MC steps兲. The size of the circles is in proportion to the local charge densityn_i. For the surface layer, the dotted lines separate the high-density 共n_i

⬎0.75兲 and low-density 共n_i⬍0.75兲 regions.共b兲Sketch of the orbital occupation共based on the MC-averaged␶xiand␶zi兲correspond- ing to the above-described MC-averaged charge distribution. 共c兲 MC-time evolution after thermal equilibrium of thee_gcharge den- sity共average value for all the sites兲. The frequent tunneling events are prominent among the possible densities—indicating tendencies toward electronic phase separation, which is a first-order transition when␮is varied.

FIG. 5. 共Color online兲共a兲 The spin structure factor values for several spin orders, showing the reduction in the tendency toward a CE state as the surface is reached. At this surface, the FM and E phase tendencies are dominant. 共b兲 The charge structure factor at 共␲,␲兲as a function of the layer index, showing the reduction in the CE-phase staggered charge-order tendencies as the surface is reached.

(6)

phase. This process corresponds to the experimental observed transition from the narrow-band manganites to middle-band one, then finally to wide-band manganties.⁴⁹On the other hand, by decreasing␭only, the charge ordering共or the degree of charge disproportionation兲will become weaker and weaker until completely turn to the FM phase when 共J_AF,␭兲 crosses the phase boundary between CE and FM phases. In both cases, FM tendency will be enhanced. In short, our above simulation mainly aims at the family of narrow-band manganites whose CO CE phase is stable, e.g., Nd_0.5Ca_0.5MnO₃and Pr_0.5Ca_0.5MnO₃.

In the simulations described above, only the AO sheet termination was considered. But it is necessary to discuss the other choice already mentioned, namely, a MnO₂-sheet termination. In the case of this MnO₂ termination, the cubic symmetry is lost at the surface due to the breakdown of the oxygen octahedrons. Therefore, the 3d energy levels of the Mn cations at the surface are different from those with full oxygen octahedrons. In particular, the energy of the d_3z²_−r² orbital will be lowered substantially. An early model study by Calderón et al.²⁹ showed that the MnO₂ termination would generate an AFM surface for FM manganites because the eg density at the surface was enhanced from⬃0.7 to 1.

However, anab initiocalculation by Fanget al.³⁶showed the reverse result—decreasedegdensity at the surface by MnO₂ termination. Therefore, whether the MnO₂ termination can generate the FM tendency, e.g., by enhancing the surface charge density from 0.5 to 0.75 as it occurs in the case of the AO termination, remains unclear and is an interesting subject of investigations. However, this MnO₂ termination is far more complex than the case studied here and beyond the scope of the present work.

It is important to remark that some other extrinsic factors, such as defects of cations/oxygen and recomposition of surface structures, may also affect the physical properties of real manganites. Even qualitatively considering these effects, our model still gives reasonable results. For a crude comparison with experiments, the FM component fraction can be esti- mated as 40% of the surface layer关Fig.5共a兲兴. Therefore, to compare with experiments the FM fraction predicted by our study, we should use the number 40%⫻surface/volume 共at zero magnetic field and lowT兲, where surface/volume should be calculated based on the actual shape and size of the nanosized clusters used experimentally. By this procedure, our theory agrees with the weak magnetization found in Nd_0.5Ca_0.5MnO₃nanoparticles共diameter of⬃20 nm and experimental magnetization M⬃3 emu/g⬃3% of the satura- tion magnetization Ms while, in our model, our estimation gives⬃5%Ms兲¹⁸and Pr_0.5Ca_0.5MnO₃nanowires共diameter of

⬃50 nm and experimental magnetization M⬃1 emu/g

⬃1%Mswhile our model estimation is⬃1%Ms兲.¹⁷It should be noted that the phenomenological core-shell model cannot explain these very weak magnetizations.³² The agreement between our estimates and experimental data suggests that our model at least grasps the main physics of the surface effects in the nanosized CE-phase manganites.

IV. CONCLUSION

In conclusion, we have performed a Monte Carlo study of the CE-type AFM/CO phase in a 3D lattice with an open surface. TheAO sheet termination leads to the generation of an extra 0.25 electron per site at the surface here simulated by the introduction of an unscreened Coulomb attraction at that surface. As a result, the charge density on the surface Mn layer was enhanced from 0.50 to ⬃0.75. The charge density of⬃0.75 usually corresponds to a fully FM phase in bulk manganites. However, within the Monte Carlo simulations for small clusters discussed in this paper, the surface was found to have a nontrivial nanoscale electronic phase- separated state. At the surface, the charge distribution was found to be inhomogeneous and coexisting with a weak FM spin correlation. The studies of both the charge structure factor and spin structure factor confirmed the suppression of AFM/CO order and the enhancement of FM order near the surface. Our result is helpful to understand the weak FM tendencies observed in nanosized AFM/CO manganites.

However, clearly these results have to be considered as just a first step toward the understanding of the phase diagram at the surfaces of manganites. Larger clusters and other numerical/analytical techniques should be used to confirm our results and further explore the physics unveiled here.

Also, a systematic study varying parameters of the many tendencies expected in the anticipated rich phase diagram of these compounds at the surface should be carried out in fu- ture investigations.

ACKNOWLEDGMENTS

We thank W. Plummer, M. J. Calderón, S. V. Bhat, and A.

Biswas for useful comments. This work was supported by the NSF under Grant No. DMR-0706020 and by the Division of Materials Science and Engineering, U.S. DOE under con- tract with UT-Battelle, LLC. S.D. and J.M.L were supported by the National Key Projects for Basic Research of China 共Grant No. 2006CB921802兲and Natural Science Foundation of China共Grant No. 50601013兲. S.D. was also supported by the China Scholarship Council and the Scientific Research Foundation of the Graduate School of Nanjing University.
