High-power diode-pumped actively Q-switched Nd : YAG laser at 1123 nm

(1)

High-power diode-pumped actively Q-switched

Nd:YAG laser at 1123 nm

Y.F. Chen

a,*

, Y.P. Lan

a

, S.W. Tsai

b

a_{Department of Electrophysics, National Chiao Tung University, 1001 Ta-Hsueh Road, Hsinchu 30050, Taiwan}

b_{Institute of Electro-Optical Engineering, National Chiao Tung University, Hsinchu, Taiwan}

Received 23 October 2003; received in revised form 26 January 2004; accepted 4 February 2004

Abstract

A high-power diode-pumped Nd:YAG laser at 1123 nm is acousto-optically Q-switched at a pulse repetition rate range of 5–20 kHz. Experimental results reveal that the resonator mirrors need to suppress parasitic oscillations on lines in the 1064 nm as well as 1319 nm regions for actively Q-switching operation. With an incident pump power of 19.2 W, the pulse energy increases from 0.15 mJ at 20 kHz to 0.4 mJ at 5 kHz. The highest peak power is up to 8.0 kW at 5 kHz. Furthermore, a conventional model of coupled rate equations is used to analyze the experimental data. The general agreement indicates that the simple model is adequate for a ﬁrst order prediction of the low-gain laser characteristics. Ó 2004 Elsevier B.V. All rights reserved.

PACS: 42.60.Gd; 42.55.Rz; 42.55.Xi

Keywords: Nd:YAG; Diode-pumped; Acousto-optic Q-switching

1. Introduction

The progress in diode-pumped solid-state lasers makes considerable advances in various ﬁelds of science and technology. Nd:YAG crystal is one of the prevalent active media among the diode-pumped Nd-doped lasers because of its excellent optical and mechanical properties. It is well-known that the emission at 1064 nm is the most commonly used wavelength in Nd:YAG lasers

because of the highest gain [1–4]. However, Nd:YAG lasers can also operate in various Stark components of the4_F

3=2!4I11=2transition [3,5,6],

such as 1112 and 1123 nm. In spite of low gain, the operation of a highly eﬃcient Nd:YAG laser with wavelengths of 1.11–1.12 lm is particularly desir-able for a few practical applications. For example, the 1112 nm line that is close to the second over-tone of the unsaturated hydrogen carbonates can be applied to the selective photo-ionization in laser chemistry [6]. Furthermore, the 1123 nm line can be used as a pump source for Thulium upconver-sion ﬁber lasers to generate blue light emisupconver-sion [7,8].

*

Corresponding author. Tel.: 712121; fax: +886-35-729134.

E-mail address:[email protected](Y.F. Chen).

doi:10.1016/j.optcom.2004.02.009

(2)

Previously, Moore et al. [5] has demonstrated a cw output of 1.7 W at 1123 nm with an incident pump power of 5.6 W in a diode-pumped Nd:YAG laser. An uphill struggle for operation of Nd:YAG laser at 1123 nm is to utterly suppress the competing transition at 1064 nm because the stimulated emission cross section for the 1123 nm transition approximately 15 times smaller than that for the 1064 nm line [2]. In this work, we re-port present a high-power actively Q-switched di-ode-pumped 1123 nm Nd:YAG. With 19.2 W of incident pump power, the compact cavity produces the average power of 3 W and the peak power higher than 1 kW at 20 kHz repetition rate.

2. Experimental setup

Fig. 1 is a schematic of the actively Q-switched Nd:YAG laser on the low-gain 1123 nm line. The active medium was a 1.0 at.% Nd3þ_{, 5-mm-long}

Nd:YAG crystal. The laser crystal was wrapped with indium foil and mounted in a water-cooled copper block. The water temperature was main-tained at 25°C. Both sides of the laser crystal were coated for antireflection at 1123 nm (R < 0:2%). The AO Q-switch (NEOS) was made by a 10-mm-long SF10 glass with antireflection coating at 1123 nm on both sides and was driven at an 80 MHz center frequency with 3.0-W of rf power. The pump source was a 20-W 808-nm fiber-coupled laser diode with a core diameter of 800 lm and a numerical aperture of 0.16. Focusing lens with 12.5 mm focal length and 96% coupling efficiency was used to re-image the pump beam into the laser

crystal. The pump spot radius was around 310 lm. The input mirror, M1, was a 200 mm radius-of-curvature concave mirror with antireflection coating at the pump wavelength (808 nm) on the entrance face (R < 0:2%), high-reflection coating at 1123 nm (R > 99:8%) and high-transmission coating at the pump wavelength on the other surface (T > 95%). The output coupler is a flat mirror with a 6% transmission at 1123 nm. Note that all the coatings of the cavity mirrors were characterized by high losses at wavelengths cor-responding to the stronger Nd3þ _transitions

(transmission >90% at 1064 nm, >60% at 1319 nm). Our experimental results reveal that the res-onator mirrors only need to suppress parasitic oscillations on lines in the 1064 nm region for cw operation, as indicated in [5]. For Q-switching operation, however, another requirement on the mirror coatings is to suppress the lasing channel at 1319 nm. The eﬀective cavity length was approxi-mately 90 mm. The pulse temporal behavior at 1123 nm was recorded by a LeCroy 9362 digital oscilloscope (500 MHz bandwidth) with a fast InGaAs photodiode.

3. Experimental results and theoretical analysis Fig. 2 shows the average output power at 1123 nm in cw mode and Q-switched mode as a function of the incident pump power. The maximum cw output power of 3.8 W was obtained at an incident pump power of 19.2 W, corresponding to a slope eﬃciency of 25.0% and a threshold power of 4.4 W. The beam quality M2 _{factor was found to be}

less than 1.6 for all pump powers. As seen in Fig. 2, the highest average output power of 3.0 W was measured at 19.2 W of incident pump power in a Q-switch regime at a repetition rate of 20 kHz, corresponding to a slope eﬃciency of 22.8% and a threshold power of 6.1 W. The spectral informa-tion of the laser was monitored by an optical spectrum analyzer (Advantest Q8381A). The present spectrum analyzer employing diﬀraction lattice monochrometor can be used for high-speed measurement of pulse light with the resolution of 0.1 nm. The measurement of the optical spectrum for the laser beam is depicted in Fig. 3.

Fig. 1. Schematic of a diode-pumped actively Q-switched Nd:YAG laser at 1123 nm.

(3)

With the conventional model of coupled rate equations [9,10], the pulse energy Ep, peak power

Ppeak, and pulse width sp, are given by:

Ep¼ hm pw2ol ln 1=Rð Þ ln 1=Rð Þ þ Lð nni fÞ; ð1Þ Ppeak¼ hm pw2 ol tr ln 1=Rð Þ nf ni t½ þ ln n1 ð i=ntÞg; ð2Þ sp¼ tr ln 1=Rð Þ þ L ni nf ni nt½1þ ln nð i=ntÞ ; ð3Þ

where hm is the photon energy, ni is the initial

in-version density, nf is the ﬁnal inversion density,

nt¼ ln 1=R½ ð Þ þ L=ð2rlÞ is the population

inver-sion density at threshold, r is the emisinver-sion cross section, pw2

ois the cavity mode area, l is the crystal

length, tris the roundtrip transit time in the laser

resonator, R is the output mirror reﬂectivity, and L is the roundtrip dissipated optical loss. For Q-switching at a repetition rate f , the values of niand

nf are determined from solving the following

sys-tem of equations [11]: ni nf ¼ ntln nð i=nfÞ; ð4Þ ni¼ Rps 1 exp 1 sf þ nfexp 1 sf ; ð5Þ where Rpis the pump rate and s is the ﬂuorescence

lifetime of the upper laser level. In terms of the

Pulse repetition rate (kHz)

0 5 10 15 20 25 Pulse energy at 1123 nm (mJ) 0.0 0.1 0.2 0.3 0.4 0.5 0.6 Experimental result Theoretical calculation

Fig. 4. Pulse energy versus pulse repetition rate in Q-switching regime at an incident pump power of 19.2 W.

Incident pump power (W)

0 5 10 15 20

Average output power at 1123 nm (W)

0 1 2 3 4 cw mode Q-switched mode (20 kHz) Q-switched mode (10 kHz) Q-switched mode (5 kHz)

Fig. 2. Average output power versus incident pump power in actively Q-switching and cw operations at 1123 nm.

Wavelength (nm)

1114 1117 1120 1123 1126 1129 1132

Intensity (arb. units)

0 5 10 15 20

Fig. 3. Measured spectral output of the diode-pumped actively Q-switched Nd:YAG laser at 1123 nm.

(4)

absorbed pump power Pabs, the pump rate is given by Rp ¼ Pabs hmp 1 pw2 pl ; ð6Þ

where hmp is the pump photon energy and pw2p is

the pump beam area.

The results of the numerical analysis of the Q-switch operation are shown in Figs. 4–6. The pa-rameters used in the calculation are as follows: s¼ 230 ls, l ¼ 5 mm, wp ¼ 310 lm, wo¼ 200 lm,

L¼ 0:006, R ¼ 0:94, tr¼ 0:6 ns, Pabs¼ 19:2 W,

and r¼ 3 1020 _cm2 _{[2]. For comparison, the}

experimental data was also plotted in the same ﬁgure. It is seen that the theoretical analysis can reasonably describe the experimental data. The main discrepancy in the low frequency range (5–10 kHz) may arise from other mechanics such as en-ergy transfer up-conversion (ETU). It has been demonstrated that the ETU eﬀect leads to a lengthening of the pulse duration and a reduction of the pulse energy [12]. Despite the discrepancies,

0 5 10 15 20 25 Pulse width at 1123 nm (ns) 0 50 100 150 200 Experimental result Theoretical calculation

Fig. 5. Pulse width versus pulse repetition rate in Q-switching regime at an incident pump power of 19.2 W.

0 5 10 15 20 25 Peak power at 1123 nm (kW) 0 3 6 9 12 15 Experimental result Theoretical calculation

Fig. 6. Pulse peak power versus pulse repetition rate in Q-switching regime at an incident pump power of 19.2 W.

Fig. 7. A typical oscilloscope trace of a train of pulses; lower trace is an expanded shape of a single pulse.

(5)

the general agreement indicates that the simple model of the laser is adequate for a ﬁrst order prediction of the low-gain laser characteristics. As shown in Fig. 4, the pulse energy at an incident pump power of 19.2 W increases from 0.15 mJ at 20 kHz to 0.4 mJ at 5 kHz. With an incident pump power of 19.2 W, the overall peak power is higher than 1.0 kW at a pulse repetition rate range of 5– 20 kHz. A typical oscilloscopic trace of a train of output pulses is also presented in Fig. 7. The pulse-to-pulse amplitude ﬂuctuation of Q-switched pulse train was measured to be less than10%.

4. Conclusions

In summary, a diode-pumped actively Q-swit-ched Nd:YAG laser at 1123 nm has been demon-strated. It is found that 0.4 mJ pulses of 50 ns duration at a pulserepetition rate of 5 kHz can be obtained at an incident pump power of 19.2 W. The numerical analysis was found to be in general good agreement with the experimental results. The signiﬁcant peak power achievable with the present

laser might allow for interesting applications in other ﬁelds, such as second harmonic generation into the yellow light at 561 nm.

References

[1] R.G. Smith, IEEE J. Quantum Electron. 4 (1968) 505. [2] S. Singh, R.G. Smith, L.G. Van Uitert, Phys. Rev. B 10

(1974) 2566.

[3] J. Marling, IEEE J. Quantum Electron. 14 (1978) 56. [4] W. Koechner, Solid-State Laser Engineering, Optical

Sciences, vol. 1, fourth ed., Springer, Berlin, 1996. [5] N. Moore, W.A. Clarkson, D.C. Hanna, S. Lehmann, J.

B€osenberg, Appl. Opt. 38 (1999) 5761.

[6] N.V. Kravtsov, V.V. Firsov, P.P. Pashinin, Quantum Electron. 29 (1999) 778.

[7] S.G. Grubb, K.W. Benett, R.S. Cannon, W.F. Humer, Electron. Lett. 28 (1992) 1243.

[8] I.J. Booth, J.L. Archambault, B.F. Ventrudo, Opt. Lett. 21 (1996) 348.

[9] J.J. Degnan, IEEE J. Quantum Electron. 25 (1989) 214. [10] W.G. Wagner, B.A. Lengyel, J. Appl. Phys. 34 (1963) 2040. [11] R.B. Chesler, M.A. Karr, J.E. Geusic, Proc. IEEE 58

(1970) 1899.

[12] Y.F. Chen, Y.P. Lan, S.C. Wang, J. Opt. Soc. Am. B 19 (2002) 1558.
