Effects of fabrication processes and material parameters of GDL

on cell performance of PEM fuel cell

Wei-Mon Yan

a,∗

, Ching-Yi Hsueh

a

, Chyi-Yeou Soong

b

, Falin Chen

c

,

Chin-Hsiang Cheng

d

, Sheng-Chin Mei

a

a_{Department of Mechatronic Engineering, Huafan University, Shih-Ting, Taipei 223, Taiwan, ROC} b_{Department of Aerospace and Systems Engineering, Feng Chia University Seatwen, Taichung 407, Taiwan, ROC}

c_{Institute of Applied Mechanics, National Taiwan University, Taipei 106, Taiwan, ROC} d_{Department of Aeronautics and Astronautics, National Cheng Kung University, Tainan 701, Taiwan, ROC}

Received 17 September 2006; received in revised form 4 January 2007; accepted 8 February 2007 Available online 23 March 2007

Abstract

In this work, the main theme is to study the effects of electrode fabrication processes and material parameters on cell performance of PEM fuel cell. Adding a micro porous layer to traditional gas diffusion layer (GDL) can enhance the ability of water management, and therefore achieve better cell performance and higher limiting current density. For the effects of fluorinated ethylene propylene (FEP), either too high or too low content will deteriorate the performance of fuel cells. If the FEP content in the GDL is too high, indicating the GDL with a quite small pore size, the fuel gas will be difficult to diffuse in the GDL. If the content is too low, the water generated in the cell cannot be effectively removed. It is disclosed by the present experiments that when using air as cathode oxidant at an operating voltage above 0.6 V, the best performance can be achieved by using a GDL with 10% FEP content in the carbon paper and 20% content in the micro porous layer. The Vulcan XC-72R carbon loading of 1 mg/cm2in the micro porous layer is sufficiently high to obtain the maximum performance.

1. Introduction

Proton exchange membrane fuel cell (PEMFC) consists of seven layers, namely, anode flow field, anode gas diffusion layer, anode catalyst layer, proton exchange membrane, ode catalyst layer, cathode gas diffusion layer (GDL) and cath-ode flow field. The GDL is an important part of membrane electrode. It should be hydrophobic and provide passages for gas transport from flow fields to catalyst layers and water re-moval from the catalyst layers to the flow fields. It is found that improvement of the gas distribution and water management in PEMFC can avoid water flooding. Conventional GDL usually used carbon substrates as diffusion media such as carbon pa-per or carbon cloth. Prasanna et al.[1] used carbon paper as GDL. They found that cells with different thicknesses of GDL

∗_{Corresponding author.}

E-mail address:wmyan@huafan.hfu.edu.tw(W.M. Yan).

have almost the same performance at low current density. But at high current density, too thin GDL would perform poorly, as it causes high mass transfer loss, high contact resistance and water ﬂooding. Too thick GDL would lead to high activation potential, high ohmic resistance and high mass transfer resis-tance. Therefore, there should be an optimal GDL thickness. Their experiments also found that the cells with 20% PTFE content have the best performance.

Novel GDL is composed by carbon substrates and micro porous layer. Passalacqua et al.[2], in their experimental mea-surement, found that cells perform better with a gas diffusion electrode made of mixture of carbon black with PTFE in carbon paper, especially at high current density. When no mixture of carbon black with PTFE is contained in gas diffusion electrode and oxygen was used as cathode fuel gas, liquid water would block the pore, resulting in serious water ﬂooding, and catalyst layer would enter carbon paper easily, deteriorating cell per-formance. If a carbon micro porous layer is added, the catalyst

(2)

layer would not contact the carbon paper directly. Giorgi et al.

[3]reported that cell performance decreases with PTFE content in GDL. When PTFE content increases, the porosity decreased. At high current density, the diffusion layer controlled electrode characteristics. Jordan et al.[4]found experimentally that cells with thinner carbon paper in GDL perform better, because the thinner GDL has shorter gas diffusion path. But the thinner GDL also has a larger electric resistance. Thicker GDL made cell performance worse due to its longer gas diffusion path. So, there should be an optimal thickness of GDL. They also found that the cell using Acetylene Black (AB) carbon powder per-forms better than that using Vulcan carbon powder. They found that the AB carbon is denser and has less micro pores than XC-72R carbon[5]. In their experiments, cells can achieve the best performance with the AB carbon loading of 1.9 mg/cm2 when oxygen is used as the cathode fuel gas. As air is used, the optimal AB carbon loading is 1.25 mg/cm2. Their results also demonstrated that the cell performance increases by 15% when using AB carbon instead of XC-72R carbon. Song et al. [6]

employed AC impedance method to study the effects of carbon loading in catalyst-supporting layer on cell performance. Their results revealed that the catalyst active area decreases with a decrease in carbon loading. The catalyst active area reached the maximum value with the carbon loading of 3.5 mg/cm2_{. Also,}

the thickness of catalyst-supporting layer is related to the max-imum active area of Pt in catalyst layer. They also obtained the optimal cell performance with 30% PTFE content. Qi and Kaufman[7]added a sublayer onto GDL to improve mechan-ical stability and cell performance. Their experimental results proved that the performance of a cell with 24% PTEE contents in GDL slightly increases with increased carbon loading. With the GDL of 35% PTEE content, the cell performs better. As the GDL contains 45% PTEE, the cell performance becomes worse. Antolini et al.[8] coated two types of carbon, Vulcan XC-72R and Shawinigan AB, onto carbon cloth or carbon pa-per to manufacture GDL. They found that coating Shawinigan AB onto the both sides of carbon paper/cloth results in a bet-ter performancewhen oxygen partial pressure was 1 atm; while coating Vulcan XC-72R onto catalyst side is better when oxy-gen partial pressure was 3 atm. Thus, they suggested that it is better to coat Shawinigan AB onto channel side and Vulcan XC-72R onto catalyst side at high pressures. Park et al.[9] investi-gated the effect of hydrophobic treatment on GDL. They found that the porosity and pore radius of GDL material is related to PTEE content. The porosity decreases with PTEE content. But PTEE content has no inﬂuence on the thickness of GDL. They had used micro porous layer in their investigation to improve cell performance. The micro porous layer plays an important role on water management and electrical conductivity. Also, the micro porous layer is able to improve cell performance effec-tively. Lim and Wang’s[10]investigation indicated that the cell with 10 wt% FEP performs better than that with 30 wt% FEP. Since the cell with 30 wt% FEP has smaller pores and may lead to much more saturation water on the surfaces of ﬂow passages and GDL, and too much FEP would hamper mass transfer and water removal. Chen et al.[11]reported that, at high current density, cell performance can be improved by adding a water

management layer between traditional GDL and catalyst layer. The water management layer is able to avoid PEM drying out and cathode water ﬂooding, especially at low temperature hu-midiﬁed gas. Wang et al. [12] had investigated the effects of carbon black in the PEMFC on the cell performance. A GDL with AB carbon is found to have a high permeability. But, the water management is not good. Aa GDL with Black Pearls 2000 carbon exhibited less permeable to cause mass transport limitations. The results indicated that an optimal cell perfor-mance can be obtained by 10 wt% Black Pearls 2000 carbon and 90 wt% AB carbon in composite carbon black.

Lee et al. [13]found that the best cell performance can be achieved with the torque of 125 in-lb/bolt using ELAT carbon cloth or 100 in-lb/bolt using TORAY carbon paper. Because the TORAY carbon paper is brittle, high torque could crush carbon paper, making electric conductivity decrease. As the CARBEL is used as the GDL material, the optimal torque is 125 in-lb/bolt. Kong et al. [14] explored the effects of pore distribution in GDL on cell performance of PEM fuel cell. They found experimentally that the summation of pore number has an optimal value. At high current density, mass transfer loss would restrict cell performance, resulting in large excessive potential loss due to water flooding. When water flooding occurs, large pore would still provide a gas transport path, improve water management effectively and decrease mass transfer limit. As a result, large pore could drain water at high current density. But too large pore would decrease electric conductivity. Therefore, there must be an appropriate ratio of the large pore to the small pore and the pore distribution is important rather than the number of pores. Lee et al. [15]dealt with the influences of GDL fabrication processes on GDL characteristics. They found that the GDL coated by spraying or printing method is suitable for reaction because pores in carbon powder are large enough to separate water vapor and liquid water. Also, the GDL prepared in this way has rough surface, which is suitable for coating catalyst layer. The critical properties of five commercial and one in-house GDLs for PEMFC was characterized and compared by Williams et al.[16]. Recently, a hybrid technique for fabricating PEMFCs low platinum loading electrodes was proposed by Abaoud et al.[17]. It is concluded that the results of electrodes by hybrid method are superior to those with spraying and screen-printing techniques.

Recently, a fundamental understanding of liquid water trans-port in hydrophobic GDL and the effect of ﬂooding on the PFMFC performance was examined by Pasaogullari and Wang

[18]. It is found that flooding diminishes the cell performance as a result of decreased oxygen transport and surface coverage of active catalyst by liquid water. Yan et al.[19] numerically studied the effects of flow passage distribution and excessive electric potential on the local characteristics in the cell. The simulation results indicated that the local current distribution inside cells becomes homogeneous and leads to a better cell performance as the number of the flow passages increases. They also found that the cells achieve got better performance when the porosity increases from 0.3 to 0.6. Both the pressing pressure during electrode assembly and the water generated in cathode GDL could change pore distribution and influence

(3)

diffusion coefficient. Roshandel et al.[20]employed a numeri-cal model to explore the influences of pore distribution in GDL on the cell performance. At low current density, the pore distri-bution in GDL has no influence on the cell performance; while at a high current density, the influence becomes noticeable. More recently, Zhan et al.[21]numerically studied the liquid water flux distributions with different GDL designs. When a micro porous layer is added between catalyst and GDL, the liquid saturation is redistribution across MPL and GDL to improve the water management within the PEM fuel cell. The liquid water flux is increased in the GDL with those caused by increasing MPL porosity and decreasing MPL thickness.

In the above literature survey, some literature is available on the effects of GDL fabrication processes and material parame-ters on cell performance, little is known about the effect of FEP content in the GDL and micro porous layer on the performance of PEMFC. This motivates the present study.

2. Experimental methods

2.1. Fabrication principle and steps of GDL

The fabrication process of GDL has been presented by Mathias et al.[22]. In[22], they presented the carbon substrates as diffusion media, and coated with PTFE. Carbon substrates, especially carbon paper or carbon cloth, are the most prevalent gas diffusion medium used in PEMFC for its high electrical conductivity and suitable porosity. The GDL fabrication pro-cesses involved in literature can be classiﬁed into two different types, one-stage and two-stage. Conventional GDL is usually produced with a one-stage fabrication process. The procedure for coating the hydrophobic material onto carbon paper or carbon cloth is shown in Fig. 1(a). Since carbon paper has

Gas Diffusion Medium

Coating Coating Coating Carbon Powder Kind Scraping Spraying Screen Printing Carbon Paper Carbon Paper Brushing Brushing Carbon Cloth Carbon Cloth Content Content Content Content Time Time Time FEP FEP FEP Sinter Loading Sinter Sinter Temperature Temperature Temperature Performance Performance Spraying Spraying Dipping Dipping

Fig. 1. Flow charts of the fabrication processes of gas diffusion layer (GDL): (a) one-stage process; (b) two-stage process.

low electric resistance and is hydrophobic in nature, it is cho-sen as the basic gas diffusion medium in this work. To further enhance the hydrophobicity of carbon paper, fluorinated ethy-lene propyethy-lene (FEP) solution is used for carbon paper coat-ing. Novel GDL consists of two components: carbon paper and micro porous layer through a two-stage fabrication process is shown in Fig. 1(b). At stage one, the hydrophobic material is coated onto a carbon paper or carbon cloth. While at stage two, blending with hydrophobic material and carbon powder to form a micro porous layer is coated onto the treated carbon paper or carbon cloth. Because the micro porous layer is formed by carbon powder aggregation, it has much smaller pores than that using carbon paper as the backing material, the main purpose of which is to improve water management capability, provide effective mass transfer of liquid water, and carry liquid water in catalyst layer to GDL. According to the above introduction, the GDL produced by the two-stage fabrication process con-sists of two parts. One is called gas diffusion medium, that is, carbon paper; the other part is a micro porous layer between the carbon paper and the catalyst layer. Adding a micro porous layer onto catalyst layer can hinder saturation water from en-tering catalyst layer immediately to decrease the concentration of saturation water in the catalyst layer. Besides, coating car-bon slurry onto the carcar-bon paper can make its surface smooth to decrease electric resistance effectively since the roughness of the carbon paper surface has influences on the catalyst layer. 2.2. PEMFC materials and specifications

The membrane electrode assembly (MEA) used in the present experiments consists of three layers, i.e., the anode catalyst layer, the cathode catalyst layer and the PEM. It is manufactured by GORE䉸, named PRIMEA 5621, with the

(4)

reactive area of 5× 5 cm2, the Pt loading of 0.45 mg/cm2 at anode and 0.6 mg/cm2 at cathode and the PEM thickness of 35m. The test GDL is made by us. The backing material is TGP-H-090 carbon paper produced by Toray Corp., with a thickness of 270m and size of 5 × 5 cm2. The hydrophobic material and carbon powder used in GDL are FEP solution pro-duced by Dupont and Vulcan XC-72R, respectively. The bipo-lar plates used in the experiments are AXF-5QCF high density carbon plate produced by POCO, which has the material of pure graphite plate, the size of 10× 10 cm2, the thickness of 10 mm. In the central section, with the size of 5× 5 cm2, the serpentine ﬂow passages are machined with the cross section of 1×1 mm2_{. The collector plates with the size of 10}_{×10 cm}2

and a thickness of 2 mm are made of copper and gold-plated surface to increase its surface conductivity and reduce con-tact resistance in connection of the collector plate with bipolar plates. The end plate surfaces are made of stainless steel with the size of 10× 10 cm2and the thickness of 10 mm.

2.3. Test conditions

In this paper, ﬂow is controlled with stoichiometric mode with values of 1.5 at anode and 2.0 at cathode. In the exper-iments, the cell temperature is set as 65◦C, and the inlet hu-midifying temperatures at cathode and anode are 70 and 80◦C, respectively. The cell pressure is the same as the normal atmo-sphere.

3. Results and discussion

Adding micro porous layer on GDL of PEMFC has influ-ences on water management, limiting current density and cell overall performance. In this paper, the influences of one-stage and two-stage fabrication processes on cell performance will be discussed as follows. To study the micro porous layer ef-fects, three types of carbon paper with 10%, 20%, 30% FEP contents are used in GDL, and both the conditions with and without micro porous layer (30% FEP+ 70% XC-72R, carbon loading 2 mg/cm2) are considered. The unit fuel cell test re-sults are shown inFig. 2. When the inlet fuel gas at the cathode is air, which comprises 1₅ oxygen and 4₅ nitrogen, the limiting current density phenomenon occurs at a high current density. So, it is more important to improve the diffusion of air. When adding micro porous layers into the carbon paper, not only the cell performance improves significantly but also the limiting current density is delayed. It is because the micro porous layer is beneficial to the mechanical support, water management, and gas diffusion.

In order to investigate the inﬂuences of FEP content in the ﬁrst stage of the two-stage fabrication process on cell per-formance, the GDLs made with carbon papers of 10%, 20%, 30% FEP contents and coated by micro porous layers (30% FEP+ 70% XC-72R, carbon loading 2 mg/cm2_{) are used. The}

test results of the unit cells using above GDLs are shown in

Fig. 3, in which it is found that cell performance and limiting current density increase with decreasing FEP content in car-bon paper for the cases with air as the fuel gas. This indicates

1 0 1 10wt% FEP GDM 20wt% FEP GDM 30wt% FEP GDM ML-coated 10wt% FEP GDM ML-coated 20wt% FEP GDM ML-coated 30wt% FEP GDM Voltage (V) 0.9 0.8 0.7 0.6 0.5 0.4 0.3 0.2

Current density (A/cm2₎ 0.8 0.6

0.4 1.2

Fig. 2. Effects of FEP contents in GDLs with and without coating micro porous layer.

0 1

10wt% FEP GDM coated by 30wt% FEP ML 20wt% FEP GDM coated by 30wt% FEP ML 30wt% FEP GDM coated by 30wt% FEP ML

Voltage (V) 0.9 0.8 0.7 0.6 0.5 0.4 0.3 0.2

Current density (A/cm2)

0.4 0.6 0.8 1.2

Fig. 3. Effects of FEP content in GDL for the ﬁrst stage of two-stage fabrication process on cell performance.

that low hydrophobicity is good for air transport. Moreover, the limiting current density reduces with a decrease in the FEP content, because oxygen content in air is only 1₅, and the rest are nitrogen and other gas components, and therefore nitrogen can accumulate on catalyst layer surfaces and hinder air trans-port. Hence, less hydrophobic material is needed for air to avoid pore decreasing. As known from the above discussion, in the ﬁrst stage of two-stage fabrication processes, the cell performs better with 10% FEP in carbon paper.

Fig. 4 illustrates the inﬂuences of FEP content in micro porous layer on cell performance to understand the effects of FEP content in the second stage of the two-stage fabrication process. In the experiments, GDLs are prepared with 10% FEP in carbon paper, and micro porous layer coating with three different FEP contents, namely, 10%, 20%, 30%, and the car-bon loading of 2 mg/cm2_{. With these GDLs unit cell tests are}

performed. The results showed that when air is the oxidant, the operation voltage is above 0.45 V and the micro porous layer contains 20% FEP, the cells perform the best because of the optimal usage of catalyst. It is also found that less FEP

(5)

0 1

10wt% FEP GDM coated by 10wt% FEP ML 10wt% FEP GDM coated by 20wt% FEP ML 10wt% FEP GDM coated by 30wt% FEP ML

Voltage (V) 0.9 0.8 0.7 0.6 0.5 0.4 0.3

Current density (A/cm2₎ 0.8 0.6 0.4

0.2 1.2 1.4

Fig. 4. Effects of FEP content in micro porous layer for the second stage of two-stage fabrication process on cell performance.

content leads to more delay of limiting current density. In the past literature, too large or too small pores in micro porous layer could affect the distribution of liquid water content and then the cell performance. Discovered in our measurement, the optimal FEP content in micro porous layer is 20% when the operating voltage is above 0.45 V.

The comparison of performance curves is shown in Fig. 5

to understand the influences of FEP content on GDL. In this figure, all GDLs with different FEP contents and different fab-rication processes of carbon paper, including untreated, one-stage, and two-stage processes are compared. For the cases of oxygen as the oxidant and without coating micro porous layer, a higher FEP content such as 20% or 30% at low voltage re-gion(V < 0.6 V) may lead to liquid water blocking pores and hindering oxygen transfer in GDL, see Fig. 5(a). But if the FEP content is too low, such as 0% or 5%, the cell perfor-mance decreases. While with a micro porous layer coating on the GDL, the cell performance is obviously better than that without coating micro porous layer. InFig. 5(a), it is found that the cells with a micro porous layer on GDL perform even better than that with commercial carbon cloth. Furthermore, it is also found that the cells achieve the best performance with 10% hy-drophobic material in carbon paper and 20% in micro porous layer. When air is used as oxidant and no micro porous layer is coated on carbon paper, cell performance at low voltage region (V < 0.6 V) is quite poor obviously. This is because of serious water flooding appearing in GDL. For GDL with coating micro porous layer, cell performance is improved significantly due to proper water management. When the operating voltage is above 0.6 V, the cell with GDL of 20% FEP in micro porous layer performs best. For limiting operation condition, the cells with two-stage fabrication process perform better in extending limit-ing current density than that with one-stage fabrication process. But carbon paper of 30% FEP with micro porous layer of 30% FEP and carbon paper of 10% FEP without micro porous layer have the same limiting current density, because too much FEP content in carbon paper and micro porous layer lead to small pores and then large mass transfer loss. However, in two-stage

1 0 2 3 0wt% FEP GDM 5wt% FEP GDM 10wt% FEP GDM 20wt% FEP GDM 30wt% FEP GDM

10wt% FEP GDM coated by 10wt% FEP ML 10wt% FEP GDM coated by 20wt% FEP ML 10wt% FEP GDM coated by 30wt% FEP ML 20wt% FEP GDM coated by 20wt% FEP ML 20wt% FEP GDM coated by 30wt% FEP ML 30wt% FEP GDM coated by 30wt% FEP ML commercial cloth Voltage (V) 1 0 1 2 0wt% FEP GDM 5wt% FEP GDM 10wt% FEP GDM 20wt% FEP GDM 30wt% FEP GDM

10wt% FEP GDM coated by 10wt% FEP ML 10wt% FEP GDM coated by 20wt% FEP ML 10wt% FEP GDM coated by 30wt% FEP ML 20wt% FEP GDM coated by 20wt% FEP ML 20wt% FEP GDM coated by 30wt% FEP ML 30wt% FEP GDM coated by 30wt% FEP ML commercial cloth Voltage (V) 0.9 0.8 0.7 0.6 0.5 0.5 1 1.5

Current density (A/cm2₎

2.5

Current density (A/cm2₎ 1.5 0.5 0.3 0.4 0.5 0.6 0.7 0.8 0.9

Fig. 5. Effects of FEP content in GDL with one stage or two-stage fabrication process on cell performance: (a) oxygen; (b) air.

fabrication processes, the GDL with low FEP content can delay the occurrence of limiting current density. Thus, GDL with 10% FEP in both carbon paper and micro porous layer delays the occurrence of limiting current density most effectively; GDL with 10% FEP in carbon paper and 20% FEP in micro porous layer will cause the optimal power curve of fuel cell.

Carbon loading also has inﬂuences on GDL performance. To investigate the inﬂuences, carbon paper of 10% FEP is used in the GDL fabrication processes and then micro porous layer of 10% FEP and 90% XC-72R is coated, therein carbon load-ings of 1, 2, 3 mg/cm2 are, respectively, used. Unit cell tests on those micro porous layers with different carbon loading are performed and the results are shown inFig. 6. For the cases of air as the cathode fuel gas and the carbon loading of 3 mg/cm2, the data implies that the micro porous layer with the carbon loading of 3 mg/cm2is confronted with gas diffusion and water management problems. Because the gas diffusion in too thick micro porous layer needs to undergo long distance and small pores in the mass transport, which leads to the early occur-rence of limiting current density. When micro porous layer has the carbon loading of 1 mg/cm2, the cell performs better and

(6)

0 C loading 1 mg/cm2 C loading 2 mg/cm2 C loading 3 mg/cm2 0.9 Voltage (V) 0.7 0.8 0.6 0.5 0.4 0.3

Current density (A/cm2₎

0.5 1 1.5

Fig. 6. Effects of carbon loading in micro porous layer on the cell performance.

1

0 1 1.5 2 3

carbon paper improved carbon paper commercial carbon coth lcommercial carbon paper

0.6 1

0 1 2

carbon paper improved carbon paper commercial carbon cloth commercial carbon paper

Voltage (V) Voltage (V) 0.9 0.8 0.7 0.6 0.5 0.5

Current density (A/cm2)

2.5 0.9 0.8 0.7 0.5 0.4 0.3 0.5

Current density (A/cm2₎ 1.5

Fig. 7. Comparison of cell performance with different GDLs (untreated carbon paper, improved carbon paper, commercial carbon paper and commercial carbon cloth): (a) oxygen; (b) air.

the occurrence of the mass transport loss can be delayed. Because the thin micro porous layer and thus large pores pro-vide short gas diffusion distance and can improve gas diffusion

performance effectively. However, a thin micro porous layer has large electric resistance. Therefore, a too thin micro porous layer will decrease electrical and ion conductivity.

To ﬁnd out the inﬂuences of various carbon papers on cell performance, untreated carbon paper, improved carbon paper, commercial carbon paper and commercial carbon cloth are used as GDL for test cells in this study. Unit cell tests with these GDLs under the same experimental conditions are performed and the results are compared inFig. 7. For oxygen as the oxi-dant, as shown inFig. 7(a), improved carbon paper has much better performance than untreated carbon paper and even better than commercial carbon paper and commercial carbon cloth. For the cases of air as the oxidant, as shown inFig. 7(b), com-parison between improved carbon paper and untreated carbon paper reveals that the current density increases from 0.3 to 1.15 mA and cell performance curve increases by about 70% under the operating voltage of 0.6 V. Besides, improved carbon paper recommended in this paper also has better performance than commercial carbon paper or commercial carbon cloth. In general, improved carbon paper proposed and manufactured in the present study can effectively improve gas transfer, ohmic resistance and water management in fuel cells.

4. Conclusion

In this paper, the effects of GDL fabrication process, FEP content, and carbon loading on cell performance of PEM fuel cells have been investigated experimentally. According to the present measurements, the following conclusions can be drawn.

1. The GDL fabrication process employing two-stage method, I i.e., coating GDL with a micro porous layer, can improve cell performance effectively and delay the occurrence of limiting current density, because adding micro porous layer onto GDL improves gas transport and reduces ohmic resis-tance inside GDL effectively, and also provides proper water management capability.

2. In the two-stage fabrication process of GDL, FEP contents in carbon paper and micro porous layer have obvious effects on cell performance. The GDL with the carbon paper of 10% FEP and micro porous layer of 20% FEP results in the best cell performance.

3. With air, the fuel cell achieves much better cell performance with the carbon loading of 1 mg/cm2 in the micro porous layer due to the presence of the thin micro porous layer and large pores in GDL.

Acknowledgement

The study was supported by the National Science Council, the Republic of China, through the Grants NSC 94-2212-E-211-004, NSC 94-2622-E-002-94-2212-E-211-004, and NSC 92-2212-E-002-096.

References

[1]Prasanna M, Ha HY, Cho EA, Hong SA, Oh IH. Inﬂuence of cathode gas

diffusion media on the performance of the PEMFCs. J Power Sources 2004;131:147–54.

(7)

[2]Passalacqua E, Lufrano F, Squadrito G, Patti A, Giorgi L. Inﬂuence of structure in low-Pt loading electrodes for polymer electrolyte fuel cells. Electrochim Acta 1998;43:3665–73.

[3]Giorgi L, Antolini E, Pozio A, Passalacqua E. Inﬂuence of the PTFE

content in the diffusion layer of low-Pt loading electrodes for polymer electrolyte fuel cells. Electrochim Acta 1998;43:3675–80.

[4]Jordan LR, Shukla AK, Behrsing T, Avery NR, Muddle BC, Forsyth

M. Effect of diffusion-layer morphology on the performance of polymer electrolyte fuel cells operating at atmospheric pressure. J Appl Electrochem 2000;30:641–6.

[5]Jordan LR, Shukla AK, Behrsing T, Avery NR, Muddle BC, Forsyth M.

Diffusion layer parameters inﬂuencing optimal fuel cell performance. J Power Sources 2000;86:250–4.

[6]Song JM, Cha SY, Lee WM. Optimal composition of polymer electrolyte

fuel cell electrodes determined by the AC impedance method. J Power Sources 2001;94:78–84.

[7]Qi Z, Kaufman A. Improvement of water management by a microporous

sublayer for PEM fuel cells. J Power Sources 2002;109:38–46.

[8]Antolini E, Passos RR, Ticianelli EA. Effects of the carbon powder

characteristics in the cathode gas diffusion layer on the performance of polymer electrolyte fuel cells. J Power Sources 2002;109:477–82.

[9]Park GG, Sohn YJ, Yang TH, Yoon YG, Lee WY, Kim CS. Effect of

PTFE contents in the gas diffusion media on the performance of PEMFC. J Power Sources 2004;131:182–7.

[10]Lim C, Wang CY. Effects of hydrophobic polymer content in GDL

on power performance of a PEM fuel cell. Electrochim Acta 2004;49: 4149–56.

[11]Chen J, Matsuura T, Hori M. Novel gas diffusion layer with water

management function for PEMFC. J Power Sources 2004;131:155–61.

[12]Wang XL, Zhang HM, Zhang JL, Xu HF, Tian ZQ, Chen J. et al.

Micro-porous layer with composite carbon black for PEM fuel cells. Electrochim Acta 2006;51:4909–44915.

[13]Lee WK, Ho CH, Van Zee JW, Murthy M. The effects of compression

and gas diffusion layers on the performance of a PEM fuel cell. J Power Sources 1999;84:45–51.

[14]Kong CS, Kim DY, Lee HK, Shul YG, Lee TH. Inﬂuence of

pore-size distribution of diffusion layer on mass-transport problems of proton exchange membrane fuel cells. J Power Sources 2002;108: 185–91.

[15]Lee HK, Park JH, Kim DY, Lee TH. A study on the characteristics

of the diffusion layer thickness and porosity of the PEMFC. J Power Sources 2004;131:200–6.

[16]Williams MV, Begg E, Bonville L, Kunz HR, Fenton JM.

Characterization of gas diffusion layers for PEMFC. J Electrochem Soc 2004;151:A1173–80.

[17]Abaoud HA, Ghouse M, Lovell KV, Al-Montairy GN. A hybrid technique

for fabricating PEMFC’s low platinum loading electrodes. Int J Hydrogen Energy 2005;30:385–91.

[18]Pasaogullari U, Wang CY. Liquid water transport in gas diffusion

layer of polymer electrolyte fuel cells. J Electrochem Soc 2004;151: A399–406.

[19]Yan WM, Soong CY, Chen F, Chu HS. Effects of ﬂow distributor

geometry and diffusion layer porosity on reactant gas transport and performance of proton exchange membrane fuel cells. J Power Sources 2004;125:27–39.

[20]Roshandel R, Farhanieh B, Saievar-Iranizad E. The effects of porosity

distribution variation on PEM fuel cell performance. Renew Energy 2005;30:1557–72.

[21]Zhan Z, Xiao J, Li D, Pan M, Yuan R. Effects of porosity distribution

variation on the liquid water ﬂux through gas diffusion layers of PEM fuel cells. J Power Sources 2006;160:1041–8.

[22]Mathias M, Roth J, Fleming J, Lehnert W. Diffusion media materials

and characterisation. Handbook of fuel cells. New York: Wiley; 2003 [Chapter 46].
