Chien-Kuo Wang, MD
Chun-Wei Li, PhD
Tsyh-Jyi Hsieh, MD
Sang-Hsiung Chien, MD
Gin-Chung Liu, MD
Kun-Bow Tsai, MD
Index terms: Bone neoplasms, 40.31, 40.32, 40.33, 40.35, 40.37 Bone neoplasms, MR, 40.121411, 40.121413, 40.121415, 40.12143, 40.12145 Magnetic resonance (MR), spectroscopy, 40.121415, 40.12145 Soft tissues, MR, 40.121411, 40.121413, 40.121415, 40.12143, 40.12145Soft tissues, neoplasms, 40.36, 40.37, 40.39
Published online
10.1148/radiol.2322031441 Radiology 2004; 232:599 – 605
1From the Departments of Medical Imaging (C.K.W., T.J.H., G.C.L.), Or-thopedics (S.H.C.), and Pathology (K.B.T.), Chung-Ho Memorial Hospital and Faculty of Medical Radiation Technology (C.W.L.), Kaohsiung Med-ical University, 100 Tzyou 1st Rd, Kaohsiung 807, Taiwan. From the 2003 RSNA scientific assembly. Re-ceived September 9, 2003; revision quested November 20; revision re-ceived November 27; accepted January 19, 2004. Address correspondence to C.K.W. (e-mail: [email protected]).
Author contributions:
Guarantors of integrity of entire study, C.K.W., C.W.L., G.C.L.; study con-cepts, C.K.W., C.W.L.; study design, C.K.W.; literature research, C.K.W., T.J.H.; clinical studies, C.K.W., T.J.H., S.H.C.; data acquisition, C.K.W., C.W.L., K.B.T.; data analysis/interpre-tation, C.K.W., C.W.L.; statistical anal-ysis, C.K.W.; manuscript preparation, C.K.W.; manuscript definition of intel-lectual content, C.K.W., C.W.L.; manuscript editing, C.W.L., G.C.L.; manuscript revision/review, C.K.W., G.C.L.; manuscript final version ap-proval, C.K.W., C.W.L., G.C.L. ©RSNA, 2004
Characterization of Bone and
Soft-Tissue Tumors with in
Vivo
1
H MR Spectroscopy:
Initial Results
1
PURPOSE: To determine if in vivo detection of choline by using hydrogen 1 (1H) magnetic resonance (MR) spectroscopy with dynamic contrast material– enhanced MR imaging can help differentiate between benign and malignant musculoskeletal tumors.
MATERIALS AND METHODS: MR imaging was performed in 36 consecutive
patients with bone and soft-tissue tumors larger than 1.5 cm in diameter. Exami-nations were performed at 1.5 T with a surface coil appropriate for the location of the lesions. Single-voxel 1H MR spectroscopy was performed by using a point-resolved spectroscopic sequence with echo times of 40, 135, and 270 msec. The volume of interest within lesions was positioned on the areas of early enhancement (⬍8 seconds after arterial enhancement) according to the findings of dynamic contrast-enhanced MR imaging with subtraction. The criterion for determining whether choline was present in a lesion was a clearly identifiable peak at 3.2 ppm in at least two of the three spectra acquired at echo times. MR spectroscopic results and histopathologic findings were determined in blinded fashion and compared with statistics. P ⬍ .001 was considered to indicate a significant difference.
RESULTS: Choline was detected in 18 of 19 patients with malignant tumors and in
three of 17 patients with benign lesions. The three benign lesions included one perineurioma, one giant cell tumor, and one abscess. Choline was not detected in 14 patients with benign lesions nor in one patient with a densely ossifying low-grade parosteal osteosarcoma. In vivo1H MR spectroscopy characterized bone and soft-tissue tumors, resulting in a sensitivity of 95%, specificity of 82%, and accuracy of 89% (P⬍ .001).
CONCLUSION: Choline can be reliably detected in large malignant bone and
soft-tissue tumors by using a multiecho point-resolved spectroscopic protocol.1H MR spectroscopy can help differentiate malignant from benign musculoskeletal tumors by revealing the presence or absence of water-soluble choline metabolites.
©RSNA, 2004
The effectiveness of magnetic resonance (MR) imaging in accurate characterization of musculoskeletal tumors has not gone unquestioned (1–9). Improvement in the treatment and outcome of patients with bone and soft-tissue tumors requires the development of diagnostic tools that can help differentiate between benign and malignant lesions in a noninvasive and reliable manner. During the past few years, differentiation between benign and malignant masses on unenhanced MR images has been based mainly on the evaluation of morphologic parameters such as size, demarcation of margins, involvement of adjacent vital structures, signal homogeneity, and measurements of relaxation times (2,6,7,10,11). In dynamic gradient-echo MR studies, this technique provides clinically useful information by depicting tissue vascularization and perfusion, capillary permeabil-ity, and composition of interstitial space (5,12). Attempts have been made to use the slope of a time-intensity curve, which reflects the increased signal intensity after the
adminis-R
tration of a contrast agent, as a criterion for differentiation between benign (low-slope) and malignant (high-(low-slope) lesions (1,4,5,9,13,14).
Despite the highly statistically signifi-cant differences in slope values between benign and malignant lesions, sensitivity and specificity are adversely affected by slope values of poorly vascularized malig-nant tumors and highly vascularized be-nign tumors, such as giant cell tumor, granulation tissue, capillary or arterio-venous hemangioma, and abscess (4,5). Authors of a study have suggested that the enhancement parameters used for dynamic contrast material– enhanced MR imaging, such as start of enhance-ment, enhancement patterns, and pro-gression of enhancement, could be used to improve the sensitivity in differential diagnosis of soft-tissue masses (9). How-ever, because of the overlap between be-nign and malignant lesions, time-inten-sity curves and slope values should be used only in combination with conven-tional spin-echo images and other radio-logic, anatomic, and clinical data to nar-row down the differential diagnostic possibilities (12).
In addition to imaging features, infor-mation regarding the cellular chemistry obtainable from ex vivo or in vitro hy-drogen 1 (1H) nuclear MR spectroscopy
(15–19) may help characterize suspicious lesions. Reports have demonstrated that the composition of membrane phospho-lipid in tumor tissue is an important in-dicator of a tumor’s cellularity, prolifera-tive capacity, and differentiation state. Millis et al (16) have reported that the phosphatidylcholine level on ex vivo nu-clear MR spectra as an estimate of the total tissue cell membrane phospholipid mass in pleomorphic liposarcoma was three times higher than that in dediffer-entiated liposarcoma. The pleomorphic liposarcoma is the most aggressive and metastatic subtype of liposarcoma. Mukherji et al (18) also reported that the choline-creatine ratio obtained by in vitro1H MR spectroscopy was capable of
helping to distinguish malignant tumors of the extracranial head and neck from the uninvolved muscle. The choline-cre-atine ratio is markedly higher in squa-mous cell carcinoma than in muscle. In vivo1H MR spectroscopy has been
uti-lized for analysis of bone and soft-tissue tumors (20), as well as other malignant lesions (21), such as breast carcinoma (22–24), prostate cancer (25), and cervi-cal carcinoma (26). The preliminary study of in vivo1H MR spectroscopy in
bone and soft-tissue tumors by Oya et al
(20) did not focus on the level of choline-containing compounds at 3.2 ppm. How-ever, the malignancies in breast, prostate, and cervix peaked at a chemical shift of 3.2 ppm, which corresponded to that of choline at1H MR spectroscopy (22–26).
Detection of choline with absolute measurement methods (27) requires an external standard because neither fat nor water can serve as an internal reference. If an external standard is placed near the lesions, variations in signal amplitude measurements and the reference due to magnetic field inhomogeneities may lead to ambiguous concentration estimates (28). Yeung et al (23) reported that a mul-tiecho acquisition approach for deter-mining the presence or absence of cho-line at in vivo1H MR spectroscopy is a
useful tool in the characterization of breast lesions. Because well-vascularized viable areas of a tumor can be identified with dynamic contrast-enhanced MR im-aging, which provides physiologic infor-mation about the vascularization and perfusion of the lesion, the correct posi-tioning of the volume of interest for sus-picious lesions during 1H MR
spectros-copy can be guided by the use of dynamic contrast-enhanced MR images.
The aim of the present study was to determine if in vivo detection of choline by using1H MR spectroscopy performed
with dynamic contrast-enhanced MR im-aging can help differentiate between be-nign and malignant musculoskeletal tu-mors.
MATERIALS AND METHODS Patients
Thirty-six patients (mean age, 47.8 years; age range, 13– 87 years) with bone and soft-tissue tumors larger than 1.5 cm in diameter were included in the study. There were 16 male (mean age, 49.9 years⫾ 18.5; range, 18–87 years) and 20 female (mean age, 46.1 years ⫾ 18.7; range, 13–70) patients. The patients were enrolled consecutively between Novem-ber 2002 and May 2003. The study was approved by our institutional medical ethical review board. Informed consent was obtained from all patients prior to examination. MR examinations were in-cluded in our routine protocol for the evaluation of the tumor extent and to obtain baseline information for possible neoadjuvant chemotherapy. No inter-ventional procedures such as biopsy or aspiration were performed on the tumors prior to MR studies.
MR Imaging and MR Spectroscopy
The examinations were performed with a 1.5-T whole-body MR imaging sys-tem (Gyroscan ACS-NT; Philips, Best, the Netherlands). A body coil was used for identification of tumors. An appropriate surface coil was selected for MR spectros-copy. Transverse and sagittal or coronal images were obtained by using a T1-weighted spin-echo sequence (500/14 [repetition time msec/echo time msec], two signals acquired, 512⫻ 512 matrix size, section thickness and intersection gap depending on tumor size) and a T2-weighted turbo spin-echo sequence with fat suppression (1,800/160/100 [repeti-tion time msec/echo time msec/inver-sion time msec], three signals acquired, 512⫻ 512 matrix size, section thickness and intersection gap depending on tu-mor size). After a bolus of 0.1 mmol per kilogram of body weight gadopentetate dimeglumine (Magnevist; Schering, Ber-lin, Germany) was intravenously injected with an MR-compatible power injector (Spectris; Medrad, Pittsburgh, Pa) at 2 mL/sec, dynamic contrast-enhanced MR images covering the entire lesions were acquired by using a T1-weighted turbo-field-echo sequence (15/4.1, 25° flip angle, one signal acquired, 256 ⫻ 256 matrix size, section thickness and inter-section gap variable). Each phase was no longer than 8 seconds. The dynamic imaging time lasted 3 minutes after intra-venous administration of contrast mate-rial. Image subtraction was then performed to show areas of early enhancement on the subtracted images. The delayed contrast-enhanced transverse and sagittal or coro-nal images were obtained by using T1-weighted spin-echo spectral presaturation with inversion recovery sequence (500/14, two signals acquired, 512 ⫻ 512 matrix size, section thickness and intersection gap variable).
Spectra for each volume of interest were acquired 10 –15 minutes after the administration of contrast material by using the point-resolved spectroscopic sequence (2,000/40, 2,000/135, and 2,000/270). A staff musculoskeletal radi-ologist (H.T.J.) with 4 years of experience carefully positioned one volume of inter-est (mean volume, 6.2 cm3; range, 3.4 –21
cm3) to include the early enhancing areas
of the tumors, as demonstrated on the subtracted images. Inclusion of the adja-cent bone cortex and muscle was avoided. If a slowly enhancing tumor or absence of enhancement during the 3-minute acquisition was depicted, the volume of interest fitted the size of
tu-R
mors according to the delayed contrast-enhanced MR images. Automated opti-mization of transmitter pulse power, localized shimming, gradient tuning, and water suppression were used. The pa-rameters used to perform MR spectros-copy were a spectral width of 1,000 Hz and 128 signals acquired, and the time required to complete the examination was approximately 20 minutes.
After acquisition, MR spectroscopic data were processed by a physicist (L.C.W.) with 15 years of experience with MR spectros-copy. The commercial MR software pack-age provided by the manufacture was used. In the time domain, spectrum processing parameters are zero filled to 2,048 data points, 3-Hz Gaussian line-broadening fil-ter, phase correction, and baseline cor-rection. The criterion for determining whether choline was present in a lesion was the presence of a clearly identifiable peak at 3.2 ppm in at least two of the three spectra acquired at different echo times.
Histopathologic diagnoses of bone and soft-tissue tumors were established with resected specimens in 24 patients, speci-mens from core biopsy with a 16-gauge needle (Temno Biopsy System; Alle-giance, Tokyo, Japan) in nine patients, and specimens from core biopsy with a bone marrow biopsy needle (Trap Sys-tem; MD Tech, Gainesville, Fla) in three patients. Histopathologic examinations of the samples were performed by one pathologist (T.K.P.) with 7 years of expe-rience with musculoskeletal tumors. The tumor cell differentiation, necrosis, and mitosis were evaluated. Both the radiolo-gist and the patholoradiolo-gist were blinded to the MR spectroscopic measurements per-formed by the physicist.
Statistical Analysis
The age between the male and female groups was evaluated by using a two-sample t test. P⬍ .05 was considered to
indicate a statistically significant differ-ence.
The statistic was used to compare MR spectroscopic results with histopatho-logic and surgical information. The re-sultant data were analyzed with software (SPSS, version 10.0; SPSS, Chicago, Ill). A value of 0.40 or less was considered to indicate marginal reproducibility; 0.40 – 0.75, good reproducibility; and 0.75–1.00, excellent reproducibility. P ⬍ .001 was considered to indicate a statistically signif-icant difference. True-positive, true-nega-tive, false-positrue-nega-tive, and false-negative de-tection rates, as well as sensitivity and specificity, were determined.
RESULTS Tumor Types
There was no significant difference be-tween the mean age of the male and fe-male groups (P⬎ .05). Nineteen patients
Summary of MR Spectroscopic and Pathologic Findings Patient No./
Age(y)/Sex Tumor Location
Tumor Size in
Long Axis (cm) Pathologic Finding
Voxel Size (cm3)
Choline Signal
40-msec TE 135-msec TE 270-msec TE
1/17/F Vastus medialis 4.43 Hemangioma 8.0 No No No
2/65/F Thigh 3.18 Nodular fasciitis 5.6 Yes No No
3/65/F Gluteus maximus 11.8 Lymphoma 21.0 Yes Yes Yes
4/50/M Hand 2.75 Trichilemmal cyst 3.4 No No No
5/68/F Femur 2.43 Metastasis 3.4 Yes Yes Yes
6/25/M Fibula 12.87 Osteosarcoma 6.6 Yes Yes Yes
7/55/M Elbow 5.55 Hematoma 8.6 Yes No No
8/56/M Leg 2.95 Ganglion 3.4 No No No
9/70/M Inguinal area 5.15 Metastasis 6.8 No* Yes Yes
10/32/M Femur 10.39 Fibrous dysplasia 5.2 No No No
11/58/F Gluteal region 4.18 Bursitis 4.2 No No No
12/45/F Inguinal area 3.30 Lymphoma 4.6 Yes Yes Yes
13/13/F Arm 3.37 Pilomatricoma 4.9 No No No
14/66/F Arm 4.50 Lipoma 6.8 No No No
15/54/M Knee 7.62 Tuberculous arthritis 3.4 No No No
16/25/F Femur 11.05 Parosteal osteosarcoma 4.1 No No No
17/54/F Sacrum 5.87 Metastasis 8.0 Yes Yes Yes
18/44/F Foot 3.94 Perineurioma 4.0 Yes Yes Yes
19/46/M Vastus lateralis 3.20 Foreign body granuloma 3.4 No No No
20/29/F Wrist 3.64 GCT of tendon sheath 3.4 No No No
21/32/M Thigh 3.98 Metastasis 4.5 Yes Yes No
22/47/M Femur 5.91 GCT 4.2 No No No
23/39/M Tibia 6.16 Metastasis 4.1 Yes Yes Yes
24/56/F Pelvis 7.09 Metastasis 9.3 Yes Yes Yes
25/56/F Ilium 6.87 Metastasis 5.2 Yes Yes Yes
26/64/F Fibula 10.74 Osteosarcoma 5.8 Yes Yes Yes
27/37/F Thigh 4.02 Hemangioma 6.9 No No No
28/48/M Femur 7.75 Metastasis 6.3 Yes Yes Yes
29/22/F Femur 5.19 GCT 7.5 Yes Yes No
30/66/M Pelvic sidewall 6.84 Leiomyosarcoma 9.6 Yes Yes Yes
31/27/F Thigh 14.26 Abscess 8.4 Yes Yes Yes
32/87/M Sacrum 2.80 Metastasis 3.6 Yes Yes Yes
33/70/F Pelvis 6.26 Metastasis 4.5 Yes Yes No
34/41/F Thigh 3.54 Liposarcoma 4.1 Yes Yes Yes
35/18/M Arm 11.41 Epitheloid sarcoma 9.5 Yes Yes Yes
36/74/M Sacrum 8.19 Metastasis 12.3 Yes Yes No
Note.—GCT⫽ giant cell tumor, TE ⫽ echo time.
* Prominent resonances derived from fatty acids masked the choline peak at 3.2 ppm.
R
had malignant bone and soft-tissue tu-mors, including 11 metastatic tutu-mors, three osteosarcomas, two lymphomas, one leiomyosarcoma, one liposarcoma, and one epitheloid sarcoma. The mean size of these tumors was 7.06 cm (range, 2.43–12.87 cm). Seventeen patients had benign lesions, including two soft-tissue hemangiomas, two giant cell tumors, one nodular fasciitis, one trichilemmal cyst, one hematoma, one ganglion, one fi-brous dysplasia, one case of bursitis, one pilomatricoma, one lipoma, one case of tuberculous arthritis, one perineurioma, one foreign body granuloma, one giant cell tumor of tendon sheath, and one abscess. The mean size of these lesions was 5.24 cm (range, 2.75–14.26 cm).
MR Spectroscopy
The Table summarizes the MR spectro-scopic and histopathologic findings of the musculoskeletal lesions in all 36 pa-tients. In 18 patients with malignant tu-mors, a resonance at 3.2 ppm attributed to a choline-containing compound was detected (Fig 1). In 14 of the 17 patients with benign lesions, no choline signal
was detected. Choline was found in three benign lesions, including one perineu-rioma (patient 18), one giant cell tumor (patient 29), and one abscess (patient 31). The peaks in 3.2-ppm regions were de-tected on the spectra, with all three echo times in the perineurioma (Fig 2) and abscess. The spectra of the patient with giant cell tumor were positive, with echo times of 40 and 135 msec. Choline was not detected in one malignant parosteal osteosarcoma (patient 16) (Fig 3). Seven-teen of 21 positive choline findings were based on spectra with all three echo times; the remaining four positive find-ings, on spectra with two echo times. Thirteen of the 15 negative choline find-ings were determined on the basis of the absence of any identifiable signal in the 3.2-ppm region above the baseline noise on spectra obtained with all three echo times, and only peaks at 3.2 ppm with an echo time of 40 msec were found in the remaining two negative cases (patients 2 and 7). Signal contribution arising from fat in the 0.9 –2.1 and 5.3-ppm regions decreased with increasing echo time, which resulted in an improved spectral
resolution. However, with an increasing echo time, a decreasing spectral signal-to-noise ratio was observed due to relax-ation losses.
Overall, the true-positive detection rate of malignant bone and soft-tissue lesions was 18 of 19; the true-negative rate, 14 of 17; the false-positive rate, three of 17; and the false-negative rate, one of 19. Therefore, in vivo1H MR
spec-troscopy had a sensitivity of 95% (18 of 19), specificity of 82% (14 of 17), positive predictive value of 86% (18 of 21), nega-tive predicnega-tive value of 93% (14 of 15), and accuracy of 89% (32 of 36). Excellent agreement between MR spectroscopic and histopathologic findings was present, as indicated by the value of 0.776 ⫾ 0.105 (P⬍ .001).
DISCUSSION
Using a multiecho acquisition approach to determine the presence or absence of choline in bone and soft-tissue tumors in vivo, we found a strong relationship be-tween 1H MR spectroscopic and
his-topathologic findings. The position of
Figure 1. Patient 17. (a) Spectra acquired at different echo times in patient with metastatic carcinoma. Choline (Cho) (3.2 ppm) was found on all three spectra and was a true-positive MR spectroscopic finding for malignancy. Resonances derived from fat and water were present. Wa-ter peaks were the result of waWa-ter suppression. (b) Trans-verse arterial phase dynamic contrast-enhanced subtrac-tion MR image (15/4.1) demonstrates a peripherally enhancing tumor (large arrows) at left ilium. External iliac arteries (small arrows) are also evident. (c) This tumor (arrows) became homogeneously enhanced on the corre-sponding delayed contrast-enhanced MR image with fat suppression (500/14).
R
the volume of interest, including the early enhanced regions inside the le-sions, is determined with dynamic con-trast-enhanced images. According to van der Woude et al (9), the early enhanced regions represent areas of high biologic activities, such as cellularity, cell turn-over time, and neovascularity. In malig-nant tumors, these areas may contain more choline-containing compounds. A 15% decrease in the choline signal was noted after injection of contrast material during chemical shift imaging with a long echo time (29). However, authors of single-voxel1H MR spectroscopic studies
(30,31) have found no statistically signif-icant differences in long- or short-echo-time acquisitions following the adminis-tration of contrast material.
Three of the 17 benign lesions found in our patients were false-positive. These le-sions included one perineurioma, one gi-ant cell tumor, and one abscess. The his-tologic findings of perineurioma, as well as of giant cell tumor, showed
hypercel-lularity and hypervascularity. The patho-logic examination of the patient with ab-scess demonstrated an abundance of inflammatory cells in the wall of abscess. Choline and its derivatives are thought to represent important constituents in the phospholipid metabolism of cell membranes (32). In vivo, the choline peak (resonance at 3.2 ppm) is composed of choline, phosphocholine, phosphati-dylcholine, and glycerophosphocholine. Elevation of this peak is thought to rep-resent increased membrane phospho-lipid biosynthesis and also to be an active marker for cellular proliferation (21,33). Previous reports have demonstrated that benign tumors that are hypercellular may show an elevated choline level in brain lesions, as well as in head and neck tumors (34 –36). In addition, a large number of inflammation-related cells produced by inflammatory processes may also result in a high choline peak (37). The cellular proliferation and/or cell density of these lesions may explain the
presence of choline peaks at 3.2 ppm in
1H MR spectroscopy.
There was only one false-negative re-sult in our study. The malignant tumor with no detectable choline was a paros-teal osteosarcoma arising from distal fe-mur. Most of the tumor was densely os-sified. Prevention of ossification in the volume of interest was impossible. The lower proton amounts and susceptibility effects due to mineralization may ac-count for the false-negative choline up-take in this case. Another possible expla-nation is the low-grade malignancy of this kind of tumor. The parosteal osteo-sarcoma has a better prognosis than do other subtypes of osteosarcoma.
In vitro 1H MR spectroscopy of the
normal muscle can show two peaks with almost the same height at 3.0 and 3.2 ppm (38). The volume of interest should be positioned carefully inside the tumor. In our study, most cases had no identifi-able signal at 3.0 ppm that was attributed to a creatine-containing compound. Therefore, the contamination from the adjacent muscle that causes the choline signal at 3.2 ppm can be eliminated.
A limitation of this study was the ex-clusion of smaller lesions (⬍1.5 cm in diameter). In vivo 1H MR spectroscopy
with a 1.5-T MR imager is not possible with a voxel size of less than 1 cm3. The
decreased signal-to-noise ratio in the
Figure 2. Patient 18. (a) Spectra acquired at different echo times in patient with perineurioma showed positive choline (Cho) findings. This was a case of a false-positive MR spec-troscopic study. (b) Sagittal arterial phase dynamic contrast-enhanced subtraction MR image (15/4.1) of the foot shows an early enhancing tumor (straight arrow). The dorsalis pedis artery (curved arrow) is well identified. (c) Sagittal delayed contrast-enhanced MR image with fat suppression reveals a diffusely enhancing tumor (arrow) between the metatarsals. Photomicrograph of the pathologic specimen (not shown) from the tumor demonstrated that this benign tumor had increased cellular proliferation.
R
smaller voxel also makes interpretation of spectra difficult. The 3.0-T MR imager may increase signal-to-noise ratio and can acquire reliable spectra from smaller lesions.
There were very diverse pathologic conditions in this study, which included a variety of metastases, primary malig-nant and benign bone tumors, and a number of nonneoplastic lesions. With these limited numbers, it is difficult to draw meaningful conclusions regarding a specific disease. Another limitation of the study was the total, relatively small, number of tumors imaged. Further stud-ies focusing on a specific disease should be performed in a larger group of pa-tients.
In conclusion, our results demonstrate that choline can be detected in contrast-enhanced bone and soft-tissue tumors or tumorlike lesions in vivo by using a mul-tiecho point-resolved spectroscopic se-quence. In the evaluation of 36 patients for bone and soft-tissue tumors based on the presence of choline, the sensitivity, specificity, and accuracy of1H MR
spec-troscopy were 95%, 82%, and 89%, re-spectively. The information provided with 1H MR spectroscopy and dynamic
contrast-enhanced MR imaging may complement other findings, such as ad-jacent bone invasion and tissue plane de-struction, and may improve the diagnos-tic specificity of MR examination in the identification of malignancy.
Acknowledgments: Special thanks to Yuan-Yu Chiau, RT, and Feng-O Shu, RT, for MR technical assistance and Faline Lin and Chu-Hui Min for preparation of this manu-script.
