A LOW-COST PASSIVE OPTICAL NETWORK FOR TELEVISION

BROADCASTING AND HIGH-SPEED BIDIRECTIONAL

COMMUNICATIONS IN INTELLIGENT BUILDINGS

Zih-Rong Lin, Cheng-Kuang Liu*, Gerd Keiser, San-Liang Lee, Kuo-Chieh Lai, Huan-Chia Chang, Chih-Lung Tseng, and Jau-Ji Jou

ABSTRACT

In this paper, a low-cost passive optical network scheme is presented for intel-ligent buildings located in areas having difficulty with wireless signal reception. The network can simultaneously broadcast digital-video-broadcasting-terrestrial (DVB-T) signals and can transmit high-speed data bidirectionally using a Fabry-Pérot laser diode (FP-LD) injection-locked by a vertical cavity surface-emitting laser (VCSEL). Results are shown for the broadcast of DVB-T signals over an 1-km multimode fiber (MMF) and for non-return-to-zero (NRZ) data over a 25-km single mode fiber (SMF). Downstream and upstream transmission bit rates are 10 Gbps and 1.25 Gbps, respectively. Maintaining TV signal quality at 40%, receiver sensitivities are -20.2 dBm and -22.58 dBm for downstream and upstream transmissions, respectively. In addition, the constraint of injection-locking and the limitation of optical power are also analyzed.

Key Words: fiber optics communication, digital video broadcasting (DVB), optical

injection-locking, fixed-mobile convergence.

*Corresponding author. (Tel: 886-2-27336382; 886-953-021648; Email: ckliu@mail.ntust.edu.tw)

The authors are with the Department of Electronic Engineering, National Taiwan University of Science and Technology, Taipei 106, Taiwan, R.O.C.

I. INTRODUCTION

Modern intelligent buildings (including enter-prise facilities and smart homes) have premises distribution systems that allow occupants to take ad-vantage of new technology as it becomes available at a minimum cost (Flax, 1991). In addition to having modular and flexible internal communication networks, intelligent buildings also depend on high-quality ex-ternal landline and radio communication links. Al-ways available and accountable standard-definition and high-definition TV, data communication, and multimedia services are essential in an intelligent building. Recently, the demands for digital conver-gence such as multimedia service, cloud technology, cloud service, video on demand, and interactive TV

have increased demand for radio-over-fiber (ROF) techniques. Since all digital bits are alike, multime-dia services can be multiplexed seamlessly and de-livered in a digital format. With digital TV, the convergence of TV and optical access network tech-nologies is relatively inexpensive (Chand, 1999). Although, there has been much progress in digital TV broadcast and fixed mobile convergence, the cover-age area is still limited. For instance, difficulties in wireless signal reception exist in some regions such as some valleys and in corner areas between high and large buildings, as shown in Fig. 1. These situations can result in dead zones where no or only very weak signals are received. A building with limited exter-nal communication interfaces can hardly be called intelligent. Fortunately, one may find an alternative: building a base station with an optical fiber solution. A wavelength-division-multiplexing passive optical network (WDM-PON) is a good candidate for the bi-directional simultaneous transmission of data and digital broadcast video signals (Jung, 2001; Son, 2003), al-though its cost is generally high. Cost-reduction

708 Journal of the Chinese Institute of Engineers, Vol. 33, No. 5 (2010)

designs are essential in optical communications, es-pecially in high-speed and broadband communica-tions (Lin, 2009).

Radio over WDM-PON (Lu, 2005; Tzeng, 2009) has many advantages. ROF transport systems are used to enhance the radio coverage of wireless applications and to provide broadband services, such as intelli-gent transport systems (ITS) and local area networks (LAN). Previous ROF transport systems focused on using a distributed feedback (DFB) laser diode. However, using expensive DFB lasers may not be a good solution for optical network units/users (ONUs), since system cost reduction is one of the key issues in access networks. The less expensive VCSEL and FP-LD are two attractive candidates for use in fiber access networks, as far as the network cost is con-cerned. Although the operating characteristics of DBF lasers are superior to these two devices, an op-tical injection-locking technique (Tseng, 2008; Hung, 2003) can be adopted to improve their performance. In addition, the application of a VCSEL to radio-over-fiber has been reported to achieve some system cost reduction (Yee, 2006; Constant, 2008). Furthermore, we can make use of PON methodologies, which were developed to deliver bandwidth intensive applications to end users in a cost-effective and future-proof manner. As a low-cost alternative to wavelength-spe-cific upstream transmitters, we have proposed a scheme to use optical injection-locked FP-LDs as di-rectly modulated upstream transmitters, whereby the external injection-locking light is furnished by a VCSEL. The VCSEL not only carries downstream DVB-T signals to users from a receiving base station on the top of a building, but also serves as a master laser to optically injection-lock an upstream slave FP-LD in each ONU. Aiming at the solution to dead-zone situations in corner areas between high and large buildings or in some valleys, as shown in Fig. 1, we present in this article a combined study of the above

mentioned technologies.

This paper is organized as follows. In Section II, we describe the basic configuration of the system and give a brief discussion of the proposed scheme setup. Section III is devoted to experimental results and discussion. First, the DVB-T signal broadcast experiments are reported and discussed. We show that by using a VCSEL the DVB-T signal can be suc-cessfully modulated and transmitted over a 1-km MMF. Secondly, for the simultaneously transmitted high-speed bidirectional data experiments, we discuss methods to adjust the bistable region of the DVB-T signals and present bidirectional performance data. Injection technology based on conditions and roles of VCSEL and FP-LD are also demonstrated in this section. Finally, the main results are summarized in Section IV.

II. PROPOSED SCHEME

One solution to receiving DVB-T signals in a shadowed area or a dead zone for ubiquitous multi-media communication developments is shown in Fig. 1. Here ROF techniques are used to improve the per-formance of high-speed communication by adopting a VCSEL and an FP-LD combination, together with an injection-locking technique. Using this technique, we proposed a novel scheme as shown in Fig. 2. There are three transmission paths in our proposed scheme for television broadcasting and high-speed com-munications.

Path 1. In the base station, a TV broadcasting signal

is transmitted optically to the ONUs, as shown in Fig. 2. The DVB-T signal received by an antenna is applied through the Bias-T to modulate the C-band VCSELs and is then transmitted via a 1-km MMF to the ONUs to achieve a stable and high-quality ROF en-vironment.

Path 2. At the ONU, a 50/50 coupler is used to split

the power coming from the C-band VCSEL into two ports. One port leads the DVB-T signal to a receiver (Rx), a set top box (STB), and a monitor; the other port goes to a FP-LD. The FP-LD is injection-locked by the laser light from the C-band VCSEL and is directly modulated by the upstream 1.25 Gbps NRZ (27_{-1) pseudorandom sequence (PRBS)}

data provided by a pulse pattern generator (PPG). Data is then transmitted to the cen-tral office (CO) via a 25-km SMF. The DVB-T downstream data and the digital upstream data are carried by the same wavelength of 1550 nm (λC).

Path 3. At the CO, downstream 10 Gbps NRZ (231_-1) Radio Signal

VCSEL

FP-LD ONU

CO

Fig. 1 A low-cost PON for television broadcasting and high-speed bidirectional communications in a valley

ACKNOWLEDGMENTS

This work was supported in part by the National Science Council of the R.O.C. through 2219-E-011-003, NSC-98-3114-P-011-001-Y and NSC-97-2218-E011-007-MY3 projects.

NOMENCLATURE

λC optical communications wavelength

range 1530 nm to 1565 nm

λC1 ... λCn upstream lightwaves λL1 ... λLn downstream lightwaves

λL optical communications wavelength

range 1565 nm to 1625 nm

REFERENCES

Chand, N., Magill, P. D., Swaminathan, S. V., and

Daugherty, T. H., 1999, “Delivery of Digital Video and Other Multimedia Services (> 1 Gb/s Bandwidth) in Passband above the 155 Mb/s Baseband Services on a FTTX Full Service Ac-cess Network,” Journal of Lightwave Technology, Vol. 17, No. 12, pp. 2449-2460.

Constant, S. B., Guennec, Y. Le, Maury, G., Corrao, N., and Cabon, B., 2008, “Low-Cost All-Optical Up-Conversion of Digital Radio Signals Using a Directly Modulated 1550-nm Emitting VCSEL,”

IEEE Photonics Technology Letters, Vol. 20, No.

2, pp. 120-122.

ETSI EN 300 744 V1.6.1, 2009, “Digital Video Broadcasting (DVB); Framing Structure, Chan-nel Coding and Modulation for Digital Terrestrial Television,” European Telecommunications

Stan-dards Institute, European Standard (Telecom-munications series).

ETSI ETR 290 ed.1, 1997, “Digital Video Broadcast-ing (DVB); Measurement Guidelines for DVB Systems,” European Telecommunications

Stan-dards Institute, Technical Report.

Flax, B. M., 1991, “Intelligent Buildings,” IEEE

Com-munications Magazine, Vol. 29, No. 4, pp.

24-27.

Genay, N., Chanclou, P., Duong, T., Brochier, N., and Pincemin, E., 2006, “Bidirectional WDM/TDM-PON Access Networks Integrating Downstream 10 Gbit/s DPSK and Upstream 2.5 Gbit/s OOK on the Same Wavelength,” Optical

Communica-tions, ECOC 2006. European Conference, Cannes,

France, pp. 1-2.

Hung, W., Chan, C. K., Chen, L. K., and Tong, F., 2003, “An Optical Network Unit for WDM Ac-cess Networks with Downstream DPSK and Upstream Remodulated OOK Data Using Injec-tion-Locked FP Laser,” IEEE Photonics

Technol-ogy Letters, Vol. 15, No. 10, pp. 1476-1478. ONU 1.25 Gbps NRZ PRBS FP-LD VCSEL Bias-T DC Bias Set top box Monitor RF Singal Rx 50/50 Coupler 1-km MMF OC 1.25 Gbps Rx/BERT VCSEL FP-LD Bias-T DVB-T signal Antenna Base station DC Bias

Fig. 10 Measurement setup of simultaneous transmissions of DVB-T signals and bidirectional high-speed data

10–2 10–3 10–4 10–5 10–6 10–7 10–8 10–9 10–10 10–11 10–12 BER -26 -24 -22 -20 Received power (dBm) Injection-locked FP-LD by VCSEL Upstream 1.25 Gbps BTB Injection-locked FP-LD by VCSEL Upstream 1.25 Gbps 1-km MMF Injection-locked VCSEL by FP-LD Upstream 1.25 Gbps BTB Injection-locked VCSEL by FP-LD Upstream 1.25 Gbps 1-km MMF

Fig. 11 Measured BERs of BTB and 1-km MMF bidirectional transmissions, by interchanging the master laser and slave laser in injection-locking technique

716 Journal of the Chinese Institute of Engineers, Vol. 33, No. 5 (2010)

Jung, D. K., Kim, H., Han, K. H., and Chung, Y. C., 2001, “Spectrum-Sliced Bidirectional Passive Optical Network for Simultaneous Transmission of WDM and Digital Broadcast Video Signals,”

Electronics Letters, Vol. 37, No. 5, pp. 308-309.

Lee, J. H., Lee, K., Han, Y. G., Lee, S. B., and Kim, C. H., 2007, “Single Depolarized CW Upper Con-tinuum-Based Wavelength Division Multiplexed Passive Optical Network Architecture with C-Band OLT, L-C-Band ONU, and U-C-Band Monitor-ing,” Journal of Lightwave Technology, Vol. 25, No. 10, pp. 2891-2897.

Lin, C., and Mengel, F., 1984, “Reduction of Fre-quency Chirping and Dynamic Linewidth in High-Speed Directly Modulated Semiconductor Lasers by Injection Locking,” Electronics Letters, Vol. 20, No. 25/26, pp. 1073-1075.

Lin, C. H., Lin, M. C., Ting, P. A., 2008, “DVB-T Baseband Signal Processing Techniques,” SoC

Technical Journal, Vol. 9, No. 9, pp. 41-53.

Lin, H. H., Lee, C. Y., Lin, S. C., Lee, S. L., and Keiser, G., Feb. 2008, “WDM-PON Systems Using Cross-Remodulation to Double Network Capacity with Reduced Rayleigh Scattering Effects,” Optical

Fiber communication/National Fiber Optic En-gineers Conference, San Diego, CA., pp. 1-3.

Lin, Z. R., Lai, K. C., Liu, C. K., Lee, S. L., Keiser, G., Chang, H. C., Tseng, C. L., and Jou, J. J., 2009, “A Low-Cost Passive Optical Network for Television Broadcasting and High-Speed Bidirec-tion CommunicaBidirec-tion in Intelligent Buildings,”

Proceedings of Intelligent Buildings and Smart Homes Conference, Taipei, Taiwan, pp. 217-220.

Lu, H. H., Tsai, W. S., Liu, Y. L., and Chen, Y. L.,

2005, “A Radio-on-Hybrid WDM Transport System,” IEEE Photonics Technology Letters, Vol. 17, No. 7, pp. 1576-1578.

Son, E. S., Han, K. H., Kim, J. K., and Chung, Y. C., 2003 “Bidirectional WDM Passive Optical Net-work for Simultaneous Transmission of Data and Digital Broadcast Video Service,” Journal of

Lightwave Technology, Journal of Vol. 21, No.

8, pp. 1723-1727.

Tseng, C. L., Liu, C. K., Jou, J. J., Lin, W. Y., Shih, C. W., Lin, S. C., Lee, S. L., and Keiser, G., 2008, “Bidirectional Transmission Using Tunable Fiber Lasers and Injection-Locked Fabry-Pérot Laser Diodes for WDM Access Networks,” IEEE

Pho-tonics Technology Letters, Vol. 20, No. 10, pp.

794-796.

Tzeng, S. J., Lu, H. H., Lin, W. I., Peng, H. C., Hsu, S. S., and Wang, H. W., 2009, “A Hybrid Radio-on-DWDM Transport System for PHS/LAN/ITS/ WiMAX Applications,” Optical Fiber Technology, Vol. 15, No. 2, pp. 119-124.

Wang, J., Haldar, M. K., Li, L., and Mendis, F. V. C., 1996, “Enhancement of Modulation Bandwidth of Laser Diodes by Injection Locking,” IEEE Photonics

Technology Letters, Vol. 8, No. 1, pp. 34-36.

Yee, M. L., Ong, L. C., and Sim, C. K., 2006, “Low-Cost Radio-Over-Fiber In-Building Distribution N e t w o r k f o r W L A N , U W B a n d D i g i t a l T V Broadcasting,” Asia-Pacific Microwave

Con-ference, Yokahama, Japan, pp. 95-98.

Manuscript Received: Dec. 11, 2009 Revision Received: Mar. 10, 2010 and Accepted: Apr. 10, 2010
