Two-machine flow shop scheduling of polyurethane foam production

(1)

Two-machine ﬂow shop scheduling of polyurethane foam production

Bertrand M.T. Lin

n

, Y.-Y. Lin, K.-T. Fang

Institute of Information Management, Department of Information and Finance Management, National Chiao Tung University, Hsinchu 300, Taiwan

a r t i c l e

i n f o

Article history: Received 23 June 2011 Accepted 1 August 2012 Available online 16 August 2012 Keywords: Polyurethane foam Flow shop Precedence constraints Branch-and-bound algorithm Heuristic

Iterative local search

a b s t r a c t

This paper studies a two-machine flow shop scheduling problem with a supporting precedence relation. The model originates from a real production context of a chemical factory that produces foam-rubber products. We extend the traditional two-machine flow shop by dividing the operations into two categories: supporting tasks and regular jobs. In the model, several different compositions of foam rubber can be mixed at the foam blooming stage, and products are processed at the manufacturing stage. Each job (product) on the second machine cannot start until its supporting tasks (parts) on the first machine are all finished and the second machine is not occupied. The objective is to find a schedule that minimizes the total job completion time. The studied problem is strongly NP-hard. In this paper, we propose a branch-and-bound algorithm incorporating a lower bound and two dominance rules. We also design a simple heuristic and an iterated local search (ILS) algorithm to derive approximate solutions. The performances of the proposed algorithms are examined through computational experiments.

1. Introduction

This research investigates a flow shop scheduling model inspired by a real production line of polyurethane (PU) foam at a manufacturing site in central Taiwan. Due to different chemical compositions, various types of foams, including general-PU foam, inert foam, viscoelastic (VE) foam and bamboo charcoal foam, can be produced by mixing different materials on a foam blooming machine. While only one foam blooming machine is available, a certain amount of each composition type can be processed at a time. When a composition is finished, the foam can be segmented or sliced into specific sizes for different final products on another machine. To synthesize a final product (job), different types of compositions could be required. Consider the following example production scenario. There are four products to be produced— multi-layer mattress, single-layer mattress, memory pillow and seat pad. Materials required for producing the above products include general PU foam, inert foam and bamboo charcoal foam. The combination of materials for the four products is shown below:

Product 1 Multi-layer mattress requires general-PU foam and inert foam;

Product 2 Single-layer mattress requires general PU foam; Product 3 Memory pillow requires inert foam;

Product 4 (Seat pad) requires general PU foam and bamboo charcoal foam.

Fig. 1 depicts a production sequence (Product 2, Product 3, Product 1, Product 4). Note that Product 1 cannot be produced until the processing of general PU foam and inert foam is ﬁnished at the ﬁrst stage.

The above foam production environment can be modeled as a two-machine flow shop. Johnson’s seminal work (1954) has spurred extensive research works on flow shop scheduling with new manufacturing settings and different objective functions ( El-Bouri et al., 2008; Fondrevelle et al., 2009; Haouari and Hidri, 2008; Haq et al., 2010; Yang, 2010). A flow shop consists of several machines arranged in series, and each stage consists of a single machine such that all jobs or products must visit the machines along the specified route. To minimize the time required for finishing all jobs in a two-machine flow shop, Johnson (1954) proposed an elegant algorithm that can solve the problem in polynomial time. In a two-machine flow shop, each job (product) has two operations to process on the machines subject to the specified route, i.e. all jobs need to visit the first machine and then the second machine. Moreover, each operation on the second machine cannot start until the corresponding operation on the first machine is finished and the second machine is not occupied. The problem studied in this research is an extension of flow shop scheduling in the following aspects: For a specific product, it requires one or more types of foams. Preparation of the required foams is performed on the first machine, while production of the final products is carried out Contents lists available atSciVerse ScienceDirect

journal homepage:www.elsevier.com/locate/ijpe

Int. J. Production Economics

n

Corresponding author. Tel.: þ886 3 5729915; Fax: þ 886 3 5131472 E-mail address: [email protected] (B.M.T. Lin).

(2)

on the second machine. The production process of a product on the second machine cannot start until the second machine is available and all the required foams are prepared and ready for use. The production model in this research exhibits a clear difference from traditional two-machine flow shop scheduling. A multiple-to-multiple relation exists between machine-one operations and machine-two operations because a type of foam can support one or more products and vice versa. This feature exhibits a significant difference from the one-to-one relationship inherent in the traditional two-machine flow shop. In summary, in the studied model all operations are categorized into two types: supporting tasks and regular jobs. Machine one is dedicated to the supporting tasks and machine two to the regular jobs. A job can be processed only if the second machine is free and all of its supporting tasks have been done on the first machine. The model was also studied byChen and Lee (2009)in the context of cross-docking to minimize the makespan of the jobs on the second machine. This paper will investigate the scheduling problem of minimizing the sum of job completion times on the second machine, in short, the total job completion time. This objective function reflects not only the service quality, indicating the average customer waiting time, but also the work-in-process inventory cost.

The rest of this paper is organized as follows. Section 2 presents formal statements of the problem deﬁnition as well as reviews related previous works. InSection 3, we will propose an integer linear programming model and some preliminary proper-ties that will assist the development of solution algorithms. Section 4is dedicated to the development of a lower bound and two dominance rules that are to be included in a branch-and-bound algorithm for solving the problem optimally. To derive production schedules in an acceptable time, two approximation algorithms, including a greedy heuristic and an iterated local search (ILS) algorithm, are designed inSection 5. A computational study on the proposed algorithms is given inSection 6. We give conclusions and suggest potential research directions inSection 7.

2. Problem statements and literature review

This section ﬁrst gives formal statements of the studied problem. Notation and an example follow. Review on related works will also be presented.

The scheduling problem is formally deﬁned as follows: There are two disjoint sets of operations A ¼ fa1,a2, . . . ,amg and B ¼ fb1,b2, . . . ,bngto process on two machines MAand MB,

respec-tively. Processing times of aiAA and b_jAB are denoted by pa i and pb

j, respectively. The relation between the operations of sets A and B is speciﬁed by the supporting relation R DA B such that for aiAA and b_jAB, if ða_i,b_jÞ AR then operation b_jcannot start on machine MB unless operation ai is complete on machine MA.

Hereafter, we call the elements of set A (supporting) tasks and the elements of set B (regular) jobs. Let

a

i denote the subset of jobs supported by task i, and

b

jthe subset of tasks supporting job j. For example, if R ¼ fða1,b1Þ,ða1,b2Þ,ða2,b1Þ,ða3,b2Þg then

a

1¼ f1,2g,

a

2¼ f1g,

a

3¼ f2g, and

b

1¼ f1,2g,

b

2¼ f1,3g.

and 9

b

j9 ¼ 1 for all jobs bj. This is depicted inFig. 2. In the studied

problem, the supporting tasks of a job are not always processed consecutively on machine MA. Similarly, the jobs supported by a

task are not required to be executed consecutively on machine MB, either. Therefore, the structure of the problem setting is much

more complicated. This paper investigates the objective function of the total completion time.

Throughout the paper, a sequence of tasks on machine MAis

denoted by s ¼ ðs1, . . . ,smÞ, and a sequence of jobs on machine MB

by S ¼ ðS1, . . . ,SnÞ. In a particular schedule, CAi denotes the com-pletion time of task aion MA, and CBj the completion time of job bj

on MB. Function Zðs,SÞ gives the objective value under sequences s

and S. Later, we will show that parameter s can be omitted for it can be determined once a job S is given.

To illustrate the problem deﬁnition, we consider the following instance. There are ﬁve tasks A ¼ fa1,a2,a3,a4,a5g and four jobs B ¼ fb1,b2,b3,b4g. The processing times are shown below.

tasks a1 a2 a3 a4 a5

pA

i 6 3 2 5 9

jobs b1 b2 b3 b4

pjB 10 3 1 7

The supporting relation is R ¼ fða1,b1Þ,ða1,b3Þ,ða2,b1Þ,ða2,b4Þ, ða3,b2Þ,ða3,b3Þ,ða4,b3Þ,ða5,b4Þg, as depicted in Fig. 3(a). Given sequence s¼(3, 4, 1, 2, 5) on MAand sequence S ¼(2, 3, 1, 4) on

MB, we have the corresponding Gantt chart shown inFig. 3(b). The

completion times of the jobs on machine MBare 5, 14, 26 and 33.

Therefore, the total completion time is 78.

Since Johnson’s paper (1954), flow shop scheduling has been widely studied in the literature. While the minimization of makespan in a two-machine flow shop (F299Cmax) can be solved by Johnson’s Oðn log nÞ-time algorithm, the minimization of total completion time (F2JPCj) is nevertheless strongly NP-hard (Garey et al., 1976). With the strongly NP-hard F2JPCjproblem as a special case, the problem we are considering is also computationally intractable. To the best of our knowledge, there are two models related to the production setting of this paper. First,Chen and Lee (2009)studied a cross-docking problem where a warehouse receives goods from various vendors and then repackages the goods for distributions to various destinations. The operations can be regarded as the two-machine flow shop setting investigated in this paper. They proved the problem of makespan minimization to be strongly NP-hard, proposed a branch-and-bound algorithm, and designed a heuristic algorithm. It is shown that the ratio between the heuristic solution and optimal solution is not greater than 3/2. The second related model is due toLin et al. 2010where all of the supporting tasks and the regular jobs are processed on a single machine. The model stems from streaming and scheduling of multi-media objects. They discussed the complexity status of three objective functions, namely Lmax,PwjCj, andPwjUj, on the single-machine setting and extended the existing complexity results of single-machine scheduling with precedence constraints.

(3)

3. Mathematical model and preliminary properties

In this section, a mathematical programming model will be given to describe the problem. We will develop two properties that not only address complexity issues but also serve as the base of the development of exact and approximation algorithms.

Integer linear program. There are three approaches commonly adopted for formulating scheduling problems into integer (linear) programs; namely, positional, time-indexed, and sequencing (Ziaee and Sadjadi, 2007). In this paper, we adopt positional variables in the program. Let xikbe a binary variable that equals

1 if task aiis scheduled at position k on machine MAand equals

0 otherwise. Let yjlbe a binary variable that equals 1 if job bjis

scheduled at position l on machine MBand equals 0 otherwise.

ðILPÞ Minimize X 1r j r n CB½j ð1Þ subject to CA½1¼ Xm i ¼ 1 xi1pai; ð2Þ CA ½k¼C A ½k1þ Xm i ¼ 1 xikpai, 2rkrm; ð3Þ CB½lZC B ½l1þ Xn j ¼ 1 yjlpbj, 2rlrn; ð4Þ Xn l ¼ 1 yjlC B ½lZ Xm k ¼ 1 xikCA½kþpbj 8ði,jÞ A R; ð5Þ Xm i ¼ 1 xik¼1, 1rkrm; ð6Þ Xn j ¼ 1 yjl¼1, 1rlrn; ð7Þ Xm k ¼ 1 xik¼1, 1rirm; ð8Þ Xn l ¼ 1 yjl¼1, 1rjrn; ð9Þ xik,yjlAf0,1g, 1ri, krm, 1rj, lrn: ð10Þ

Eq.(1)gives the objective function of minimizing the sum of job completion times. Constraints (2)enforce the processing of any aion machine MAto start from time 0 onward. Constraints(3)

dictate that a supporting task cannot be processed before its immediate predecessor is completed on machine MA. Constraints

(4)give similar restrictions for jobs on machine MB. Constraints

(5)require that job bjcannot start on machine MBbefore all of its

supporting tasks are completed on machine MA. Constraints

(6) and (7)enforce that exactly one operation is allowed at any specific position on either machine. On the contrary, any task or any job can be allocated to exactly one position on their dedicated machines. This is reflected in constraints(8) and (9). Constraints (10)confine the decision variables to be either 0 or 1. The model uses m2_þn2_{decision variables and O(mn) constraints.}

Preliminary properties. In this section, we present the proper-ties that will be used in the development of exact and approx-imation algorithms. The ﬁrst result states that if a processing Fig. 3. Example for problem deﬁnition. (a) Example of supporting relation. (b) Gantt chart of the example schedule.

(4)

empty task sequence. For j ¼1 To n Begin

Set s ¼ s sðSjÞ, where sðSjÞis an arbitrary permutation of the tasks of

b

Sj, and is a sequence concatenation operator.

For j0 ¼j þ 1 To n Begin Set

b

Sj0¼

b

Sj0 \

_b

Sj. End End Return sequence s. End

In the algorithm, the loop on index j iteratively augments sequence s by appending a subsequence of tasks supporting job j, and the loop on index j0

removes the newly sequenced tasks from the supporting relation with the unscheduled jobs.

Theorem 1. Given a sequence S of jobs of set B, ALGORITHM S-to-s optimally produces a sequence of tasks of set A in Oð9R9Þ time. Proof. Let s0_{as be an optimal sequence of tasks on machine M}

A

subject to the given sequence S on machine MB. Assume i is the

smallest index such that sias0i. Then, in sequence s0, there must be some position l 4 i with si¼sl0. Move task asl0 backward to the

position immediately preceding task as0

i. It is clear that the

completion time of any job will not increase after the move. Repeating the move, if necessary, we can come up with sequence s without increasing the total completion time. &

Theorem 1states that when the sequence of jobs on machine MB is settled, the sequence of tasks on machine MA can be

subsequently determined in a greedy manner. It is interesting to consider the reverse of the scenario. Given a processing sequence of tasks on MA, it however remains hard to determine an optimal

sequence of jobs on machine MB.

Theorem 2. Given a sequence s of tasks of set A, to determine an optimal sequence of jobs of set B is strongly NP-hard.

Proof. We show the hardness of determining a optimal sequence of jobs of B via a reduction from the single-machine scheduling problem of minimizing total completion time subject to release dates, i.e. 19ri9 P Ci (Garey and Johnson, 1979). Consider an instance of t jobs with processing times piand release dates ri

of the 19ri9 P Ciproblem. Re-index the jobs in non-decreasing order of release dates, i.e. r1rr2r rrt. An instance of the

scheduling problem is constructed by letting

m ¼ n ¼ t; pa

1¼r1; pai ¼riri1 for 2rirn; pbj¼pjfor 1rjrn. Given the sequence s ¼ ð1,2, . . . ,tÞ of supporting tasks, we want to ﬁnd an optimal sequence of jobs. Since this is equivalent to solving an instance of the problem 19ri9 P Ci which is NP-hard, the problem considered is NP-hard as well. &

From the problem deﬁnition, to reach an optimal schedule the decision is to compose an optimal combination of machine-one sequence s and machine-two sequence S. The number of possible combinations is Oðm!n!Þ, which explodes exceedingly fast when m and n grow large. With the above two properties, it is evident that

4. Branch-and-bound algorithm

The strong NP-hardness indicates that it is very unlikely to design a polynomial time algorithm for producing optimal solu-tions. Branch-and-bound algorithm is one of the exact methods widely adopted for tackling hard optimization problems. Effective lower bounds and dominance rules, used to prune off non-promising solutions, are crucial to the efﬁciency of

branch-and-bound algorithms. Based upon the optimality properties

addressed in the previous section, we develop a lower bound and two dominance rules. To provide a better starting point for the branch-and-bound algorithm, a heuristic is proposed to provide the initial incumbent values. As for the branching rule, we adopt the depth-ﬁrst search strategy, which exhibits the advantages of low memory requirement and easy implementa-tions. The unscheduled jobs are examined for further recursion in the order speciﬁed by Johnson’s sequence.

Lower bound. By Theorem 1, the enumeration tree will be explored to enumerate all possible job sequences, i.e. each node corresponds to a subset of scheduled jobs. Given a partial job sequence, the algorithm in the search tree produces the corre-sponding partial sequence of supporting tasks using ALGORITHM S-to-s. Note that ALGORITHM S-to-s can be deployed to ﬁnd a task sequence minimizing the makespan (Cmax) as well because the proof ofTheorem 1still works. The task sequence for minimizing makespan subject to a given job sequence is crucial to further discussion because it provides the validity of the development of dominance rules and lower bounds.

To minimize the total job completion time, the studied problem is reshaped into a single-machine scheduling problem with different release times (i.e. 19rj9 P Cjproblem).Ahmadi and Bagchi (1990)tackled this problem by exploiting the SRPT (Short-est Remaining Processing Time) rule to solve the preemptive relaxation in Oðn log nÞ time. Adjustment is needed before deploy-ing the same technique. To create an instance of problem 19rj9 P Cj, let pjbbe the processing time of job Jj, and let the sum

P i Abjp

a

i be the release date rjof job Jj. It is worthy to emphasize

again that the supporting tasks are shared. As a consequence, given a partial sequence S in the enumeration tree, the release date rj of unscheduled job Jj is recalculated by excluding the

supporting tasks that are already ﬁnished on machine MA. Then,

the adjusted release dates are used to implement the SRPT rule. Herewith we use the same numerical example ofSection 2. Assume that the partial sequence S consists of only job b2. Then,

CA1¼2 and C B

1¼5. The sums of processing lengths of supporting tasks for the unscheduled jobs b1,b3,b4become 9, 11 and 9, respectively. The new release dates rj are now 11, 13 and 11,

respectively, by including CA1. Consequently, the values shown in Fig. 4follow. With CB 3ðSRPTÞ ¼ 14,C B 4ðSRPTÞ ¼ 21,C B 1ðSRPTÞ ¼ 31, the lower

bound on the total completion time is calculated as

5þ14þ 21þ31¼ 71.

Dominance rules. Making good use of dominance rules can curtail a great amount of unnecessary nodes of an enumeration tree. Dominance rules tell that if certain conditions are met, then some branches can be eliminated without sacriﬁcing the optimal solution.

(5)

D1: Consider a partial sequence

s

and two jobs bxand byto be

scheduled in the next two consecutive positions after

s

. If

b

xD

b

_yand pb

xrpby, then the node rooted at partial schedule

s

bybx can be eliminated.

Proof. Assume partial sequence

s

and jobs by,bx satisfy the conditions of D1. Let t be the starting time of job byon MBsubject

to

s

bybx. Because

b

xD

b

_y, job J_x is ready for processing on M_B when job byis ﬁnished. The sum of completion times of bxand by

in sequence

s

bybx is thus ðt þ pbyÞ þ ðt þpbyþpbxÞ. Consider the sequence

s

bxbyobtained from swapping the positions of jobs by

and bx. The starting time t0 of job bxis not later than t, i.e. t0rt.

The starting time of job byis not greater than maxft,t0þpbxg. The sum of completion times of bxand byin

s

bxbyis not greater than ðt0_þpb

xÞ þ ðmaxft,t0þpbxg þpbyÞ. The premises t0rt and pbxrpby boil

down to ðt0_þpb

xÞ þ ðmaxft,t0þpbxg þpbyÞrðt þpbyÞ þ ðt þ pbyþpbxÞ. Moreover, the completion time of

s

bxby is maxft,t0þpbxg þpby, which is not greater than the completion time t þ pb

yþpbxof partial schedule

s

bybx. In other words, partial schedule

s

bxby has a shorter completion time and a smaller total completion time than partial schedule

s

bybx. &

Note that the two jobs of concern in D1 must be adjacent, otherwise the rule may not work. The second dominance rule follows from the calculation of the cost already incurred by the scheduled jobs and an estimate of the cost of the remaining jobs. Della Croce et al. (1996)deployed the basic concept of dynamic programming approach to formulate a dominance rule, which states that for two different partial schedules S and S0_{of the same} subset B0

of jobs, if S has a smaller total completion time and a shorter makespan, then schedule S0

can be pruned. To realize this concept in the studied problem, we consider the following inequality: ZðSÞZðS0 Þ þ ðn9B0_9ÞðCS maxC S0 maxÞr0, ð11Þ

where CSmax (respectively, C S0

max) denotes the makespan of S

(respectively, S0

). If partial schedule S has a smaller objective value and completes the jobs earlier, then Eq.(11)is satisﬁed and the partial schedule S0

is fathomed. Note that in the case where partial schedule S completes the jobs later (i.e. makespan is larger), if the advantage in the total completion time (ZðSÞZðS0

Þ) overrides the inferior inﬂuence over the unscheduled jobs (ðn9B0_9ÞðCS

maxC S0

maxÞ), then we still can curtail the branching toward partial schedule S0

. The discussion leads to the second dominance rule.

D2: If inequality (11) is satisﬁed, then the subtree rooted at partial schedule S0

can be eliminated.

Branch-and-bound algorithm. With the lower bound and two dominance rules addressed above, we design a branch-and-bound algorithm for deriving optimal solutions to the studied problem. Depth-ﬁrst search is employed as the branching strategy for the branch-and-bound algorithm. Such a strategy merits simplicity in

implementation and avoids exceeding demand for computer memory. The branch-and-bound algorithm starts with an initial solution derived by a greedy heuristic algorithm designed in the next section to have a better starting point. During the course of exploration of the search tree, rule D1 is applied to determine if a branch can be dropped or not. When the answer is negative, the lower bound of the partial solution will be calculated. If the incumbent value is less than or equal to the lower bound, then we eliminate the node. If the node passes the two tests, rule D2 is examined. The exploration proceeds until all nodes are visited or pruned. If the algorithm can complete the exploration within a given limit on the execution time, the optimal solution will be found and reported. On the other hand, if the algorithm does not complete its execution when the speciﬁed time limit is elapsed, then it will abort with failure and report the best incumbent value found thus far.

5. Heuristic algorithms

Although the branch-and-bound approach is designed to produce optimal solutions, an exceedingly long running time can be demanded when the problem size grows large. For large-scale problems, optimal solutions cannot be obtained within reasonable time. Therefore, seeking effective approximate solu-tions is an alternative for decision makers in practical applica-tions. In this section, we will develop a heuristic as well as a meta-heuristic to produce quality schedules in an acceptable time. The heuristic method dispatches the jobs in a greedy manner. The algorithm is outlined as follows.

HEURISTICG Step 1 : Let A0

¼| be the set of scheduled supporting tasks. Calculate the total processing time pj¼pbjþ

P i Abjp

a i for each job bj, where

b

j¼

b

j\A0.

Step 2 : If there are jobs that will not induce idle times on machine MB, then select from these jobs the one that

attains the minimum makespan when dispatched; otherwise, select the job that has the minimum

make-span when dispatched. Call this job bjn. Set

A0 ¼A0

[

b

jn and

b

_k¼

b

_k\

b

jn for all unscheduled jobs b_k.

Repeat the process until all jobs are scheduled. Step 3 : Stop and report the solution.

Note that when selecting the next job to schedule, if there are more than one job inducing the smallest makespan, we select the one that has the largest number of supporting tasks. This can be easily justiﬁed. If all of the supporting tasks on machine MAare

ﬁnished, then the remaining jobs on machine MBcan be processed

by the SPT rule directly.

We next design an iterated local search (ILS) algorithm to improve the solution derived by the greedy Heuristic G. Iterated Fig. 4. Result of the SRPT rule.

(6)

tions of the acceptance of new solutions. With regard to the literature, the basic structure of ILS is given inStutzle (1998)and can be found also in Lourenco et al. (2001). Stutzle (1998)and Dong et al. (2009)applied ILS to solve the permutation ﬂow shop problem and compared it with other heuristics for performance assessment. ILS is also applied to resource-constrained project scheduling (Ballestin and Trautmann, 2008), vehicle routing (Prins et al., 2009), scheduling of machines and automated guided vehicles (Deroussi et al., 2007), just to name a few. Previous works showed that ILS runs fast and can convey impressive solution quality. The construct of ILS can be outlined as follows:

PROCEDUREITERATEDLOCALSEARCH Generate initial solution S0.

S ¼ LocalSearch(S0). repeat S0_{¼ PerturbationðSÞ.} S00 ¼ LocalSearchðS0 Þ: S ¼ AcceptanceCriterionðS,S00_Þ: until termination conditions are met.

Detail speciﬁcations for each stage of the iterated local search are elaborated in the following.

Initial solution: The initial solution is generated by HEURISTICG. Local search: One of the major ingredients of local search

algorithms is concerned about the neighborhood struc-tures. The approaches commonly adopted for deﬁning the neighborhood of a solution include, although not limited to, (1) swap-moves that swap two neighboring positions i and iþ1, (2) exchange-moves that swap two arbitrary positions i and j, and (3) insertion-moves that select two positions i and j and insert the job at the i-th position to the j-th position (Stutzle, 1998). This paper uses insertion-moves, which are realized by two for loops to ensure that every pair of positions is consid-ered. During the iterative process, if a better solution or sequence is encountered, the local search procedure will start the insertion-moves again from scratch.

Perturbation: Due to the fact that the solution yielded by a local search algorithm is not necessarily global optimal, the perturbation phase of solution modiﬁcations is a very important mechanism to allow for the possibility of exploring other regions of the solution space. It can

enable escape from local optimum. Ruiz and Stutzle

(2007)applies insertion neighborhood of perturbation, which is commonly regarded as being a very good

choice for the permutation ﬂow shop problem.

Tasgetiren et al. (2011)tested perturbation values ran-ging from 1 to 20, and their experiments showed that

swap-moves or insertion-moves generated better

results with perturbation values equal to 1 or 2. In the studied problem, the supporting relation in some sense is a kind of precedence constraint, from tasks to jobs. If we adopt a ‘‘macro’’ operation, say 2-opt moves, on S, then the structure of sequence s will be drastically changed. With such macro operations, diversity could be achieved, but in the meantime ﬂuctuation would also

Acceptance criterion: As for acceptance criterion, we consider the simple one that has been widely adopted by pre-vious ILS works: If the objective value of new schedule S00

is better than that of the original schedule S, then we accept sequence S00

and replace the current schedule S with it.

In the implementation of ILS for the studied problem, the termination condition is deﬁned by an upper limit on the number of iterations exercised. The limit is set to be 200 iterations.

6. Computational study

Previous sections presented a branch and bound algorithm for ﬁnding exact solutions, and a greedy heuristic and a meta-heuristic ILS algorithm for approximate solutions. This section is dedicated to computational experiments for comparison and analysis of the performances of the proposed algorithms. The programs were coded in Cþþ and executed on a personal com-puter with an Intel Pentium(R) 4 CPU (3.4 GHz) with 0.99G RAM running Microsoft Windows XP Professional. Function ‘‘srand((un-signed)time(NULL))’’ was used to generate random numbers. Processing times were randomly drawn from the uniform discrete interval [1, 100]. For each pair of task aiand job bj, if a random

number drawn from interval [0, 1] is smaller than parameter 0.5, then task aisupports job bj, i.e. ðai,bjÞ AR. The parameters m and n representing the numbers of operations on the two machines were taken into account simultaneously for determining problem sizes. For each combination of n and m, we generated and tested 10 independent instances. In the following, the numerical results from the experiments are analyzed in two parts. The ﬁrst part is for exact solutions and the second part is for approximate solutions.

In the ﬁrst part concerning optimal solutions, two branch-and-bound algorithms were examined. The ﬁrst one (B&B) is equipped with the lower bound derived from the SRPT solution of the 19rj9 P Cjproblem, and the second one (B&B_D) further incorpo-rates two dominance rules D1 and D2. Heuristic G was deployed to generate initial solutions for the branch-and-bound algorithms. A limit of 30 min was given to the execution of the branch-and-bound algorithms. If the algorithms could not completely exam-ine the enumeration tree, then they aborted with failures. As some of the instances were not successfully solved, we kept track the detail statistics of only those optimally solved. The perfor-mance indices investigated in the experiment include the number of instances optimally solved (#Opt), the average number of nodes explored (Nodes), and the average elapsed running time (Time). The problem size n ranges from 10 to 40 with an increment of 5.Table 1 summarizes the performance results of the two branch-and-bound algorithms with the sizes of m ¼ d0:25ne, m ¼ d0:5ne and n ¼m. The numerical values for each problem size n and m are averaged over the solved instances from each 10 problem instances.

We can readily see from the statistics that the execution time and the number of visited nodes are signiﬁcantly reduced if the two dominance rules are incorporated. For example, for solving the setting of n ¼25 and m ¼ d0:25ne, the average running time of algorithm B&B is 82.09 s, and that of algorithm B&B_D is only 3.57 s. The results also suggest that the values of m plays a crucial

(7)

role in determining the level of hardness of the problem. As the number of tasks m grows, more entries would emerge in the supporting relation and the problem thus becomes relatively hard to solve. While all instances of 25 jobs with m ¼ d0:25ne and m ¼ d0:5ne were solved by algorithm B&B_D, only 5 of the 10 instances with m¼n were solved. As shown in the literature, the best exact algorithms of the classical F2JPCjproblem can solve instances of around 40 jobs (Della Croce et al., 1996, 2002; Hoogeveen et al., 2006;Lin and Wu, 2005). The problem setting studied in this paper is much more complicated than F2JPCj. Therefore, the proposed properties are quite useful in curtailing unnecessary branching.

The second part of the experiment was conducted for the appraisal of two approximation algorithms. We used the same test instances and the solution values derived by the branch-and-bound as in Table 1 for m ¼ d0:25ne. The test instances of the settings m ¼ d0:5ne and m ¼ dne were not used because less exact solutions were successfully reported. The greedy method Heur-istic G was invoked ﬁrst and then the ILS algorithm was applied for further improvement. Solution values of the problems with n ranging from 10 to 40 are shown in Table 2. The underlined entries are the incumbent values reported when the branch-and-bound algorithm aborted upon the limit of 30 min. The rows entitled ‘‘avg’’ contain the average objective values over each 10 instances. The error ratios in percentages are calculated as Avg_devð%Þ ¼ðAppxB&B_DÞ 100%

Appx ,

where Appx and B&B_D respectively denote the solution values given by the approximation approaches and the branch-and-bound algorithms with two dominance rules. The error ratios of ILS are around 0.1%. Examining the numerical results, we can ﬁnd that ILS even provides better solutions than the branch-and-bound algorithms that failed to completely explore the enumera-tion tree. Consider the last instance of (n ¼40, m¼10) as an example, the best solution value ever found before the termina-tion of the two branch-and-bound algorithms is 37,191, while that given by ILS is 36,051. In other words, ILS is not only efﬁcient (using less execution time) but sometimes more effective (giving

better solutions) than exact methods within a time limit of 30 min. Another observation is about the execution of branch-and-bound algorithms. Consider the second instance of (n ¼40, m¼10). Although algorithm B&B_D encountered the optimal solution value 39,713, it did not possess any information to terminate the execution until the time limit was reached.

Next we examine all approaches, including CPLEX implemen-tation of the proposed integer linear programming model, with 10 test instances of (n ¼200, m¼50). The results are shown in Table 3. For each instance, we ﬁrst deployed the greedy heuristic G and then improve the solution by ILS. The solutions generated by heuristic G and ILS were used as the initial incumbent values for the branch-and-bound algorithm. The corresponding columns are B&BGand B&BI. A time limit of 30 min was also imposed on

the branch-and-bound algorithm and the CPLEX implementation. The column entitled ILS contains the solution reported by two execution runs of the ILS algorithm such that for a given instance, ILS was invoked to provide an initial solution for the branch-and-bound, and the incumbent solution kept at the termination of the branch-and-bound algorithm was used as the seed solution for further improvement by deploying ILS for another 200 iterations. Such a design is due to the fact that the running time of ILS is less than 1 min which is relatively negligible than the execution time (30 min) of CPLEX implementation and branch-and-bound algo-rithm. The results are shown in the column entitled B&BIþILS.

FromTable 3, it is evident that the branch-and-bound algorithms did not ﬁnd solutions better than the initial values given by the greedy heuristic or the ILS algorithm. Better solutions can be found when the execution of the ILS algorithm was further exercised. The CPLEX solutions are even more inferior. The average CPLEX solution value is 1,491,376, while the average B&BIþILS solution value is only 1,042,097.

From the above discussion, we may conclude that the pro-posed lower bound and dominance rules really help to reduce the efforts required for locating optimal solutions. For small-scale instances, ILS can produce optimal solutions or approximate solutions with negligible errors. When the instances contain more jobs, ILS still exhibits impressive performances in comparison with the exact approaches. The results suggest that if no stronger Table 1

Computational results of branch-and-bound algorithms.

n #Opt B&B #Opt B&B_D

Time Node Time Node

Min Avg Max Min Avg Max Min Avg Max Min Avg Max

m ¼0.25n 10 10 0.00 0.00 0.00 10 209 552 10 0.00 0.00 0.00 10 94 252 15 10 0.00 0.06 0.23 43 15,236 56,580 10 0.00 0.11 0.03 40 3023 11,454 20 10 0.02 0.58 3.34 1919 100,047 586,493 10 0.00 0.08 0.23 675 13,329 39,885 25 10 0.77 82.09 623.70 80,595 9,289,494 69,918,835 10 0.23 3.57 20.55 27,610 451,817 2,656,050 30 7 6.36 326.27 719.64 513,969 27,366,574 60,553,746 9 1.03 37.26 195.66 92,865 3,267,712 17,019,896 35 3 147.59 387.96 704.34 8,177,593 21,860,926 40,219,927 8 15.20 202.93 505.78 1,030,298 13,734,189 35,065,211 40 1 1327.81 1327.81 1327.81 57,060,164 57,060,164 57,060,164 4 102.56 501.39 876.92 5,226,700 27,285,385 49,296,815 m ¼0.5n 10 10 0.00 0.00 0.02 37 616 2190 10 0.00 0.00 0.00 37 289 947 15 10 0.06 0.63 3.52 14,567 161,138 920,569 10 0.03 0.12 0.31 9264 29,908 78,183 20 10 1.27 22.97 97.97 146,826 2,923,146 12,515,288 10 0.25 1.76 4.33 33,639 233,734 572,985 25 8 62.50 524.13 1246.00 5,109,862 4,594,456 112,392,401 10 9.74 48.19 151.77 828,691 4,394,067 13,999,552 30 4 244.91 977.89 1400.33 14,997,852 21,267,628 88,587,485 7 35.09 205.82 427.63 2,339,135 13,765,936 28,691,204 35 1 1355.69 1355.69 1355.69 58,578,183 58,578,183 58,578,183 1 223.13 223.13 223.13 11,152,226 11,152,226 11,152,226 m ¼n 10 10 0.00 0.01 0.03 357 3565 11,182 10 0.00 0.00 0.02 246 1339 2768 15 10 0.50 5.96 18.44 76,983 997,053 3,104,254 10 0.14 0.57 1.05 24,796 102,470 187,893 20 10 21.66 300.23 706.33 2,334,570 36,860,095 89,919,773 10 2.94 13.59 32.52 367,149 1,750,577 4,221,092 25 1 621.48 621.48 621.48 37,474,591 37,474,591 37,474,591 5 96.41 312.39 628.59 6,276,946 21,190,718 42,573,752

(8)

5 2088 2088 2495 2088 5790 5790 6411 5790 8303 8303 8779 8341 13,529 13,529 13,740 13,529 6 1945 1945 2196 1945 4251 4251 4877 4251 9482 9482 9497 9482 14,865 14,865 14,865 14,865 7 1565 1565 1565 1565 4510 4510 4514 4510 7029 7029 7600 7029 13,504 13,504 13,808 13,573 8 2228 2228 2505 2228 5532 5532 5772 5532 7591 7591 7627 7591 15,593 15,593 17,265 15,593 9 2458 2458 2458 2458 4253 4253 4296 4253 9649 9649 9649 9649 13,860 13,860 15,403 13,914 10 2136 2136 2220 2136 5936 5936 5936 5936 7503 7503 7866 7503 12,880 12,880 13,658 12,880 Avg_obj 2303.2 2303.2 2471.4 2303.2 4861.5 4861.5 5267.9 4861.5 8777.3 8777.3 9021.7 8781.1 14,360.3 14,360 15,206 14,373 Avg_dev (%) 6.8 0.0 7.7 0.0 2.7 0.0 5.6 0.1 Instance n ¼ 30,m ¼ 8 n ¼ 35,m ¼ 9 n ¼ 40,m ¼ 10

B&B B&B_D Greedy ILS B&B B&B_D Greedy ILS B&B B&B_D Greedy ILS 1 20,369 20,369 21,237 20,369 28,890 28,888 30,784 28,888 35,532 35,398 35,532 35,532 2 19,555 19,555 20,319 19,555 25,894 25,894 26,746 25,971 39,713 39,713 40,050 39,713 3 18,772 18,772 20,797 18,772 22,639 22,379 23,708 22,482 38,273 38,273 40,505 37,814 4 20,086 20,069 20,086 20,069 21,284 21,160 21,563 21,284 39,819 39,819 41,023 39,819 5 18,113 18,113 18,119 18,113 30,380 30,302 32,575 30,338 36,939 36,055 38,701 36,055 6 21,873 21,873 24,129 21,873 31,744 31,744 34,824 31,744 38,275 36,767 38,532 36,527 7 22,724 22,724 23,087 22,832 26,373 26,373 26,728 26,373 35,681 35,681 36,174 34,768 8 15,799 15,799 16,080 15,799 24,588 24,588 24,699 24,588 37,456 36,724 39,997 36,464 9 16,397 16,397 17,034 16,397 29,020 29,020 29,700 29,020 40,824 40,389 42,272 39,060 10 18,227 18,227 19,437 18,227 28,687 28,452 31,151 28,452 37,191 37,191 37,363 36,051 Avg 19,601 19,092 20,027 19,104 27,096 27,192 28,498 27,221 39,819 37,746 38,826.5 37,779.8 Avg_dev(%) 5 0 4.6 0.1 2.8 0.1 / Int. J. Production Economics 141 (2013) 286 –294 293

(9)

properties can be developed for the exact approaches, then the designed approximation approaches would be more appropriate for dealing with the studied problem.

7. Concluding remarks

From a real production context of foam-related products, we formulated a two-machine ﬂow shop scheduling problem with supporting precedences. The objective in this research is to minimize the total job completion time. The unique feature of the production model is the multiple-to-multiple relation between machine-one and machine-two operations. We devel-oped an integer linear programming model to interpret the studied problem in a mathematical way. Two preliminary proper-ties about sequencing of tasks and jobs on either machines were proposed. The properties simplify the solution structures and facilitate the development of solution algorithms. A lower bound and two dominance rules were presented to design branch-and-bound algorithms for producing optimal solutions. A greedy heuristic and an ILS algorithm were designed to produce approx-imate solutions. Through computational experiments, we studied the performance of the proposed properties and algorithms. The branch-and-bound algorithm incorporating the lower bound and two dominance rules can solve the test instances with up to 40 jobs and 10 supporting tasks. The numerical results also suggest that ILS is quite efﬁcient and effective when applied to the test instances with up to 200 jobs. The ILS algorithm resulted in average deviations less than 0.109% from the optimum of the small-scale problems.

For future research, design and analysis of approximation algorithms for the studied problem could be an interesting topic. Settling the complexity of some further restricted cases are also of research interest. For example, the three special cases (1) 8iA Aðpa i ¼1Þ; (2) 8j A Bðp b j¼1Þ and (3) 8i A Aðp a i ¼pÞ, 8j A Bðp b j¼qÞ may exhibit theoretical challenges. Moreover, we may include another type of precedence among the regular jobs to reﬂect more practical applications. For example, streaming and scheduling of multi-media presentations especially demands speciﬁc subse-quences of playbacks (jobs, in this paper).

Acknowledgements

The authors are grateful to the anonymous reviewers for their constructive comments which are very helpful in improving the paper. This research was partially supported by the National Science Council of Taiwan under Grant NSC-100-2410-H-009 -015 -MY2. References

Ahmadi, R.H., Bagchi, U., 1990. Improved lower bounds for minimizing the sum of completion times of n jobs over m machines in a ﬂow shop. European Journal of Operational Research 44, 331–336.

Ballesti’n, F., Trautmann, N., 2008. An iterated-local-search heuristic for the resource-constrained weighted earliness-tardiness project scheduling pro-blem. International Journal of Production Research 46 (22), 6231–6249. Chen, F., Lee, C.Y., 2009. Minimizing the makespan in a two-machine

cross-docking ﬂow shop problem. Discrete Optimization 193, 59–72.

Della Croce, F., Ghirardi, M., Tadei, R., 2002. An improved branch-and-bound algorithm for the two machine total completion time ﬂow shop problem. European Journal of Operational Research 139, 293–301.

Della Croce, F., Narayan, V., Tadei, R., 1996. The two-machine total completion time ﬂow shop problem. European Journal of Operational Research 90, 227–237.

Deroussi, L., Gourgand, M., Tchernev, N., 2007. A simple metaheuristic approach to the simultaneous scheduling of machines and automated guided vehicles. International Journal of Production Research 46 (8), 2143–2164.

Dong, X., Huang, H., Chen, P., 2009. An iterated local search algorithm for the permutation ﬂow shop problem with total ﬂowtime criterion. Computers and Operations Research 36 (5), 1664–1669.

El-Bouri, A., Balakrishnan, S., Popplewell, N., 2008. Cooperative dispatching for minimizing mean ﬂowtime in a dynamic ﬂowshop. International Journal of Production Economics 113 (2), 819–833.

Fondrevelle, J., Oulamara, A., Portmann, M.-C., Allahverdi, A., 2009. Permutation ﬂow shops with exact time lags to minimise maximum lateness. International Journal of Production Research 47 (23), 6759–6775.

Garey, M.R., Johnson, D.S., 1979. Computers and Intractability: A Guide to the Theory of NP-Completeness. Freedman, San Francisco, CA.

Garey, M.R., Johnson, D.S., Sethi, R., 1976. The complexity of ﬂow shop and jobshop scheduling. Mathematics of Operations Research 1 (2), 117–129.

Haq, A.N., Ramanan, T.R., Shashikant, K.S., Sridharan, R., 2010. A hybrid neural network-genetic algorithm approach for permutation ﬂow shop scheduling. International Journal of Production Research 48 (14), 4217–4231.

Haouari, M., Hidri, L., 2008. On the hybrid ﬂowshop scheduling problem. Interna-tional Journal of Production Economics 113 (1), 495–497.

Hoogeveen, H., van Norden, L., van de Velde, S., 2006. Lower bounds for minimizing total completion time in a two-machine ﬂow shop. Journal of Scheduling 9, 559–568.

Johnson, S.M., 1954. Optimal two- and three-stage production schedules with setup times included. Naval Research Logistics Quarterly 1, 61–68.

Lin, B.M.T., Kononov, A.V., Fang, K.T., Single-machine scheduling with supporting precedence constraints. Technical Report NSC 97-2923-H-009-001-MY3. National Chiao University, Taiwan, 2010.

Lin, B.M.T., Wu, J.M., 2005. A simple lower bound for total completion time minimization in a two-machine ﬂowshop. Asia-Paciﬁc Journal of Operational Research 22 (3), 1–17.

Lourenco, H., Martin, O., Stutzle, T., 2001. A gentle introduction to iterated local search. In: Proceedings of MIC2001, the 4th Metaheuristics International Conference, Porto, Portugal.

Prins, C., Labadi, N., Reghioui, M., 2009. Tour splitting algorithms for vehicle routing problems. International Journal of Production Research 47 (2), 507–535.

Ruiz, R., Stutzle, T., 2006. A simple and effective iterated greedy algorithm for the permutation ﬂowshop scheduling problem. European Journal of Operational Research 177 (3), 2033–2049.

Stutzle, T., 1998. Applying Iterated Local Search to the Permutation Flow Shop Problem. Technical Report, AIDA-98-04, FG Intellektik, TU Darmstadt. Tasgetiren, M.F., Pan, Q.K., Suganthan, P.N., Chen, A.H.L., 2011. A discrete artiﬁcial

bee colony algorithm for the total ﬂowtime minimization in permutation ﬂow shops. Information Sciences 181, 3459–3475.

Yang, J., 2010. A new complexity proof for the two-stage hybrid ﬂow shop scheduling problem with dedicated machines. International Journal of Produc-tion Research 48 (5), 1531–1538.

Ziaee, M., Sadjadi, S.J., 2007. Mixed binary integer programming formulations for the ﬂow shop scheduling problems. A case study: ISD projects scheduling. Applied Mathematics and Computation 185 (1), 218–228.

Table 3

Solution values of 10 large instances. Instance n ¼ 200, m ¼50

B&BG B&BI Greedy B&BIþILS CPLEX

1 1,064,893 1,063,035 1,064,893 1,060,902 1,475,739 2 995,598 994,345 995,598 990,737 1,422,659 3 1,020,419 1,008,944 1,020,419 1,008,944 1,457,987 4 1,043,034 1,039,199 1,043,034 1,039,199 1,483,254 5 1,194,550 1,179,502 1,194,550 1,179,502 1,649,472 6 1,113,713 1,105,535 1,113,713 1,103,055 1,576,792 7 1,009,519 1,008,472 1,009,519 1,007,271 1,437,228 8 974,819 959,338 974,819 959,338 1,393,268 9 1,020,943 1,012,749 1,020,943 994,125 1,470,480 10 1,087,319 1,077,901 1,087,319 1,077,901 1,546,883 Avg 1,052,481 1,044,902 1,052,481 1,042,097 1,491,376
