Abstract—For remote control systems, certain human opera-tions may violate desired requirements and result in catastrophic failure. For such human-in-the-loop systems, this paper imple-ments a hierarchical supervision system to guarantee that remote human-issued commands meet required specifications. In the pre-sented scheme, Petri nets are applied to model, design, and verify both the local controller and the remote supervisor. Then, the agent technology is adopted to implement the supervisor as an intelligent agent for an online supervision of the remote control system. Hence, undesired resource conflicts and deadlock states can be avoided. An application to a flexible manufacturing system controlled over the Internet is provided to illustrate the developed approach. Imple-mentation results show that by applying the presented hierarchical scheme, the supervisor has a more compact model with fewer states. Moreover, fewer request/response transmissions are consumed so that the effects of time delays and packet losses across the Internet could be moderated.
Index Terms—Agent technology, discrete event systems, hierar-chical supervision, Java, Petri nets, remote monitoring and control.
I. INTRODUCTION
O
VER the last decade, due to the rapid development of Internet technology, several approaches have been pro-posed to develop Web-based systems for remote monitoring and control of distributed manufacturing systems [1]–[8]. As compared with the traditional control, remote control allows people to monitor the processes of manufacturing systems from great distances and to perform maintenance functions in haz-ardous environments without exposure to dangers. Typically, an Internet-based control system is a “human-in-the-loop” system since people use a general web browser or specific software to monitor and control remotely located systems. As shown in Fig. 1(a), the remote manager is involved in the loop and sends control commands according to the observed status displayed by the state and/or image feedback. Research results indicate that approximately 80% of industrial accidents are attributed to hu-man errors, such as omitting a step, falling asleep, and improperManuscript received December 4, 2004; revised July 18, 2005. This work was supported by the National Science Council, Taiwan, R.O.C., under Grant NSC 92-2917-I-009-005 and in part by the Ministry of Economic Affairs under the Embedded System Software Laboratory in Domestic Communication and Op-toelectronics Infrastructure Construction Project. This paper was recommended by Associate Editor M. Jeng.
J. S. Lee is with the Information and Communications Research Labora-tory, Industrial Technology Research Institute, Hsinchu 31040, Taiwan, R.O.C. (e-mail: jinshyan_lee@itri.org.tw).
P. L. Hsu is with the Department of Electrical and Control Engineering, National Chiao Tung University, Hsinchu 30010, Taiwan, R.O.C. (e-mail: plhsu@cc.nctu.edu.tw).
Digital Object Identifier 10.1109/TSMCC.2006.876056
control of the system [9]. However, the Internet-based control literature provides few solutions for reducing or eliminating the possibility of human errors. Basically, an Internet-based control system is a discrete-event system (DES), which is a dynamic system with state changes driven by occurrences of individual events. Moreover, supervisory control theory provides a suit-able framework for analyzing DES [10]–[12] and its hierarchi-cal scheme is a familiar approach to the design of large-shierarchi-cale DES to reduce design complexity [13]–[17].
This paper proposes a hierarchical scheme to design such systems for the supervision of remote-controlled processes. As shown in Fig. 1(b), we use a three-level architecture. In the com-mand level, the abstract model is a simplified representation of the controlled system and is employed by the remote manager to make decisions for task allocation. Here, a task is a group of certain steps and the manager can send task requests to control the remotely located processes according to the displayed sta-tus. In this way, the manager exercises “virtual” control over the behavior of the abstract model. Actually, the manager sends a request for a decided task to the local controller, which really regulates the detailed operations of the task with event feedback in the control level. State changes in the system will eventually be conveyed in a summary form to the abstract model via the response channel. To avoid resource conflicts and deadlock, an agent is designed to acquire the system status and then enable and disable associated tasks so as to advise and guide the man-ager in issuing commands at the supervisory level. Thus, the human manager is only allowed to issue the enabled tasks, and the hierarchical loop is closed in this way.
Most existing design methods for a hierarchical supervision are based on automata models, which often involve exhaustive searches of overall system behavior and result in state-space explosion problems. One way of dealing with these problems is to model the DES with Petri nets (PNs) [18], [19]. PN model-ing is normally more compact than the automata approach and is better suited for modeling concurrent systems. In addition, PNs have an appealing graphical representation with a powerful algebraic formulation, and have, therefore, generated intense interest among many researchers [20]–[24]. In this paper, PNs are used in designing both the remote supervisor and the lo-cal controller, yielding compact and graphilo-cal models for the hierarchical supervision.
We have found that the hierarchical supervision literature merely discusses how to implement various abstract supervisory models in real applications [13]–[15]. This paper demonstrates the feasibility and practicability of the proposed hierarchical
Fig. 1. (a) Basic remote control system over the Internet. (b) Proposed three-level architecture for hierarchical supervision.
supervision model by applying it to a flexible manufacturing system (FMS), where the local controller is implemented by lad-der logic diagrams (LLDs) and the supervisory agent is imple-mented using agent technology on an industrial programmable logic controller (PLC) [25], [26]. When executing a number of concurrent operations, our approach ensures that remote control tasks via the Internet meet the given resource constraints and deadlock-free requirements with fewer packet transmissions re-quired. Also, results show that the supervisor synthesis of the presented hierarchical scheme is less complex by far than a nonhierarchical one.
II. PN-BASEDDESIGNFORHIERARCHICALSUPERVISION
This section first introduces the PN concept in production pro-cesses, and then, shows the different specifications for the com-mand level and control level, separately, in remote supervisory control design. Finally, the PN-based design for the supervisor and the controller is introduced.
A. PN in Production Processes
A PN is identified as a particular kind of bipartite directed graph populated by three types of objects, which are places, transitions, and directed arcs connecting places and transitions. Formally, a PN can be defined as
PN = (P, T, I, O, M0)
where
P ={p1, p2, . . . , pm} is a finite set of places, where m >
0;
T ={t1, t2, . . . , tn} is a finite set of transitions with P∪
T = and P ∩ T = , where n > 0;
I : P× T → N is an input function that defines a set of directed arcs from P to T , where N ={0, 1, 2, . . .};
O : T × P → N is an output function that defines a set of directed arcs from T to P ; M0: P → N is the initial marking.
A transition t is enabled if each input place p of t contains at least the number of tokens equal to the weight of the directed arc connecting p to t. When an enabled transition fires, it removes the tokens from its input places and deposits them on its out-put places. PN models are suitable to represent the systems that exhibit concurrency, conflict, and synchronization. Some impor-tant PN properties in manufacturing systems include boundness (no capacity overflow), liveness (freedom from deadlock), con-servativeness (conservation of nonconsumable resources), and reversibility (cyclic behavior). The concept of liveness is closely related to the complete absence of deadlocks. A PN is said to be live if, no matter what marking has been reached from the initial marking, it is possible to ultimately fire any transition of the net by progressing through some further firing sequences. This means that a live PN guarantees deadlock-free operation, no matter what firing sequence is chosen [20]. Validation methods of these properties include reachability analysis, invariant anal-ysis, reduction method, siphons/traps-based approach, and sim-ulation [22]. Among them, simsim-ulation is often used in real-world cases due to its convenience and effectiveness for engineers to validate the desired properties of manufacturing systems.
At the modeling stage, one needs to focus on the major oper-ations and their sequential or precedent, concurrent, or conflict-ing relationships. The basic relations among these processes or operations can be classified as follows.
1) Sequential: As shown in Fig. 2(a), if one operation follows the other, then the places and transitions representing them should form a cascade or sequential relation in PNs. 2) Concurrent: If two or more operations are initiated by an
event, they form a parallel structure starting with a tran-sition, i.e., two or more places are the outputs of a same transition. An example is shown in Fig. 2(b). The pipeline concurrent operations can be represented with a sequen-tially connected series of places/transitions in which mul-tiple places can be marked simultaneously or mulmul-tiple transitions are enabled at certain markings.
3) Cyclic: As shown in Fig. 2(c), if a sequence of operations follow one after another and the completion of the last one initiates the first one, then a cyclic structure is formed among these operations.
Fig. 2. Basic PN models for (a) sequential, (b) concurrent, (c) cyclic, (d) conflicting, and (e) mutually exclusive relations.
4) Conflicting: As shown in Fig. 2(d), if either of two or more operations can follow an operation, then two or more transitions form the outputs from the same place. 5) Mutually exclusive: As shown in Fig. 2(e), two processes
are mutually exclusive if they cannot be performed at the same time due to constraints on the usage of shared resources. A structure to realize this is through a common place marked with one token plus multiple output and input arcs to activate these processes.
B. Specification Separation
The objective of the hierarchical supervision is to restrict the behavior of the system so that it is contained within the desired states, called the specifications. The specifications are separated into two levels as follows.
1) Command-level specifications for recipes, resources, and liveness: These specifications require that the logical order of each recipe, resource constraints, and liveness requirement are satisfied throughout all operations of the system. The recipe specification indicates the sequence of tasks to be executed, and it can be modeled as a sequential flow. The resource specification presents the physical constraints of the limited resources, and shared resources can be adequately expressed in terms of mutual exclusion conditions. The liveness specification ensures that a given behavior is deadlock-free and repeatable, and it can be preserved by deadlock analysis with avoidance policies [24]. In the proposed hierarchical architecture, the supervisory agent enforces these specifications by restricting the task commands available to the remote manager.
2) Control-level specifications for detailed operations: These specifications are the detailed logical operations of each task. In the proposed hierarchical architecture, the control-level specifications are enforced by a local controller, which accom-plishes certain operations of the requested task for the physical plant in a desired logical order.
To summarize, the system requirements are separated into the command-level specification, which results in nondeterministic sequences of tasks, and the control-level specification, which
PNs have been used to model, analyze, and synthesize control laws for DES. Zhou and DiCesare [27], moreover, addressing the shared resource problem, recognized that mutual exclusion theory plays a key role in synthesizing a live, bounded, and reversible PN. In mutual exclusion theory, parallel mutual ex-clusion consists of a place marked initially with one token to model a single shared resource, and a set of pairs of transitions. Each pair of transitions models a unique task that requires the use of the shared resource. In this paper, we adopt mutual exclu-sion theory to build the resource specification models and then compose them with the recipe models to design the supervisor. The supervisor design procedure consists of the following steps. Step 1: Construct the PN model of the recipe specifications in
the command level using the task-oriented approach. Step 2: Build the PN model of the resource specifications using
the mutual exclusion concept.
Step 3: Compose the recipe and resource models to yield the basic supervisor model.
Step 4: Analyze and refine the supervisor model to obtain a deadlock-free, bounded, and reversible model.
The PN recipe model is constructed using the task-oriented concept. Each task is modeled with a start transition, an end tran-sition, a progressive place, and a completed place. Note that the start transition, as the “command” input is a controllable event, while the end transition, as the “response” output is an uncon-trollable event. Obviously, the presented hierarchical scheme is endowed with task-based modularity in the command level. D. Design of Local Controller to Meet Control-Level Specifications
The logical behavior of each task in the control level is a de-terministic process. For the local controller design, the detailed PN models of each controllable task in the recipe are built to describe the detailed operations and follow the deterministic se-quences in this stage. Applying the PN to design the controller leads to a unified PN-based approach to develop the hierarchi-cal supervision, and thus facilitates the use of established PN analysis and implementation methods.
III. IMPLEMENTATION OFHIERARCHICALSUPERVISION
This section first describes the agent concept, and then shows the implementation architecture and interactive modeling of the hierarchical supervisory control system. Finally, the reasons of choosing implementation methods in Java technology are mentioned.
Fig. 3. Implementation architecture of the remote hierarchical supervision system.
A. Agent Technology
The agent technology is a new and important technique in re-cent novel researches of the artificial intelligence. Using agent technology leads to a number of advantages, such as scalability, event-driven actions, task-orientation, and adaptivity [28]. The concept of an agent as a computing entity is very dependent on the application domain in which it operates. As a result, there exists many definitions and theories on what actually constitutes an agent and the sufficient and necessary conditions for agency. Wooldridge and Jennings [29] depict an agent as a computer system that is situated in some environment and that is capable of autonomous actions in this environment to meet its design objectives. From a software technology point of view, agents are similar to software objects, which, however, run upon call by other higher-level objects in a hierarchical structure. On the contrary, in the narrow sense, agents must run continuously and autonomously. In addition, the distributed multiagent coordina-tion system is defined as the agents that share the desired tasks in a cooperative point of view, and they are autonomously exe-cuting at different sites. For our purposes, we have adopted the description of an agent as a software program associated with the specific function of remote supervision for the manufactur-ing system. A supervisory agent is implemented to acquire the system status and then enable and disable associated tasks so as to advise and guide the manager in issuing commands. B. Client/Server Architecture
Fig. 3 shows the client/server architecture for implementing the remote hierarchical supervision system. On the remote client side, the manager uses a Java-capable Web browser, such as Netscape Navigator or Microsoft Internet Explorer, to connect to the local controller through the Internet. On the server side, a Java servlet handles user authentication, while a Java applet pro-vides a graphical human/machine interface (HMI) and invokes the supervisory agent. In this paper, we use Java technology to implement the supervisory agent on an industrial PLC, with a built-in Java-capable Web server assigned to handle the client requests [25], [26]. In addition, the LLD is used to implement the local controller on the same PLC so as to perform the detailed operations of the requested tasks. Our choice of using LLD to implement the local controller is due to its wide use in indus-try, while using Java to implement the supervisory agent is due to its object-orientation, portability, safety, and built-in support for networking and concurrency [30], [31]. The object-oriented
programming is one where each small part of the program is considered as a separate object that can interact with other ob-jects. The advantage of object-oriented software is that blocks of code can easily be reused in different parts of the program, or even in different programs. This reduces development time, and therefore, costs [32].
C. Interactive Modeling
A sequence diagram of the unified modeling language (UML) [33] is applied to model client/server interaction in the proposed remote hierarchical supervision system. Within a sequence dia-gram, an object is shown as a box at the top of a vertical dashed line, called the object’s lifeline and representing the life of the object during the interaction. Messages are represented by hori-zontal arrows and are drawn chronologically from the top of the diagram to the bottom.
Fig. 4 shows the sequence diagram of the implemented remote hierarchical supervision system. At the first stage, the Remote Manager sends a hypertext transfer protocol (HTTP) request to the Local Controller. Next, the Local Controller sends an HTTP response with an authentication Web page, on which the Remote Manager can login to the system by sending a re-quest with user/password. The Local Controller then invokes a Java servlet to authenticate the user. If the authentication fails, the Java servlet will respond with the authentication Web page again. On the other hand, if the authentication succeeds, the Java servlet’s response will be a control Web page with a Java applet. The Java applet first builds a graphical HMI and constructs a socket on the specified port to maintain continuous communi-cation with the server. Then, the Java applet acquires the system status through the constructed socket and displays it on the con-trol Web page iteratively by invoking the Device Handler to fetch the sensor states of Device objects. Finally, the supervisory agent is called by the Java applet and run to enable/disable associated control buttons on the HMI according to the current system status so as to meet the required specifications. Thus, the Re-mote Manager can send a task command by pushing an enabled button to control the remote process through the constructed socket.
D. Java Implementation
In this paper, we have employed the Java servlet for authenti-cation and Java applet for graphical HMI. A Java servlet [34] is a compiled code, dynamically loaded to process requests from a
Fig. 4. Interactive modeling with sequence diagram for the implemented hierarchical supervision system.
Web server. It does not depend on browser compatibility due to running on the server side. Moreover, a Java server page (JSP) is a script and it is compiled into Java servlets during its first invocation and may call JavaBeans to perform processing on the server. A JavaBean is a portable, platform-independent compo-nent model, developed in collaboration with industry leaders. Since JSP with JavaBean requires the script translation, Java servlet has been selected for implementation due to its faster performance and easier debugging. On the other hand, a Java applet is a widely used program that can be embedded in a Web page. When you use a Java-enabled browser to view a page that contains an applet, the applet’s code is transferred to your sys-tem and executed by the browser’s Java virtual machine (JVM). This paper has adopted the Java applet for graphical HMI due to its plentiful availability of application programming interfaces (API) [35]. Also, most Web browsers (Navigator or Internet Ex-plorer) provide the JVM to support Java applets. Moreover, as shown in Fig. 4, the TCP socket communication is used for data transmission due to its easier implementation. For distributed application development, the Java remote method invocation (RMI) or interface definition language (IDL) can be further ap-plied [34].
IV. REMOTEHIERARCHICALSUPERVISION OF ANFMS A. Description of the Flexible Manufacturing System
Fig. 5 shows the remote-controlled FMS, which is composed of: 1) three processing machines; 2) three raw material sup-pliers; and 3) six automated conveyers. It is assumed that the raw materials are provided infinitely. The FMS corresponding to different products are specified in terms of recipes, i.e., the sequences of tasks to be carried out on discrete amounts of ma-terials by employing all or part of the machines. This particular
Fig. 5. Schematic diagram of the three-recipe FMS.
FMS has three recipes for three different products described as follows:
Recipe 1 (Product x-y): Load materials x and y to Machine 1 (M1) for processing. Then, convey x-y to Machine 3 (M3). After processing x-y in M3, unload the product.
Recipe 2 (Product x-z): Load materials x to M1 and z to Machine 2 (M2) for processing, and then convey x and z to M3. After processing x-z in M3, unload the product.
Recipe 3 (Product y-z): Load materials y to M1 and z to M2 for processing, and then convey y and z to M3. After processing y-z in M3, unload the product.
By applying the task-oriented concept, the PN model for the three recipes is constructed as shown in Fig. 6, which consists of 19 places and 22 transitions. Transitions drawn with dark symbols are events that are controllable by remote managers via the Internet. Corresponding notation is described in Table I. B. Design of Supervisor to Meet Command-Level Specifications
The three machines represent resources shared between the different recipes. Since more than one recipe may require access
Fig. 6. Preliminary PN model of the three-recipe FMS.
TABLE I
NOTATION FOR THEPNOF THEFMSINFIG. 6
to the same resource, but each resource can only serve one recipe at a time, deadlock between different recipes may, thus, occur. The required specifications are as follows.
Spec-1: Raw material loading of x and y is allowed only when M1 is available.
Spec-2: Raw material loading of z is allowed only when M2 is available.
Spec-3: Material conveying to M3 is allowed only when M3 is available.
Spec-4: Liveness, i.e., no deadlock states, must be enforced throughout system operation.
Fig. 7. Composed PN model of the three-recipe FMS. TABLE II
NOTATION FOR THESUERVISORYPLACES OF THEPNINFIG. 7
In the specification model, Spec-1 and Spec-3 are built by using the mutual exclusion concept, while Spec-2 is modeled as the precondition of the associated tasks. The composed PN model of both the recipe and specifications is shown in Fig. 7. The supervisory arcs are shown with dashed lines and the places showing the supervisory positions are drawn thicker than those showing the task positions. The supervisory places ps1-4 (ps1 for Spec-1, ps2 for Spec-2, ps3-4 for Spec-3) are used to prevent the remote manager from issuing undesired commands leading to resource conflicts on the part of the system. Corresponding notation for the supervisory places is described in Table II.
At this stage, due to its ease of manipulation, support for graphics import, and ability to perform structural and perfor-mance analyses, the software package ARP [36] is chosen to verify the behavioral properties of the composed PN model us-ing the reachability analysis. The validation result (without ps5) shows that one deadlock occurs with the places p2, p10, p12, and ps3 marked only. The physical meaning of the deadlock state is that if both M2 and M3 are occupied with z for the prod-uct x-z or y-z, while M1 is loaded for the prodprod-uct x-y, then no product can be completed and the system is deadlocked. Hence, for Spec-4, the ps5 is further designed and added to the PN model, as shown in Fig. 7. Validation results (with ps5) reveal that the present PN model is live, bounded, and reversible. The liveness property means that the system can be executed prop-erly without deadlocks, boundedness indicates that the system can be executed with limited resources, and reversibility implies
Fig. 8. PN models of (a) loading, (b) conveying, and (c) processing tasks for FMS.
Fig. 9. Hardware setup during prototype development.
that the initial system configuration is always reachable. In this approach, the supervisor consists only of places and arcs, and its size is proportional to the number of specifications that must be satisfied.
C. Design of Local Controller to Meet Control-Level Specifications
As mentioned in Section II-D, the detailed operations of each task can also be designed and constructed with PN models. Fig. 8(a)–(c) shows the PN model of the tasks loading (from raw material supplier to M1 or M2 with processing), conveying (from M1 or M2 to M3), and processing (processed by M3 and unloaded), respectively.
D. Implementation of Remote Hierarchical Supervision The system modeling and design developed in previous stages provide supervisory and control models for implementation of the present remote hierarchical supervision. The developed local controller and supervisory agent are implemented on the Mirle SoftPLC (80486-100 CPU), an advanced industrial PLC with built-in Web server and JVM so that it can interpret the LLD, HTTP requests, and Java programs [25], [26], as shown in Fig. 9.
The developed HMI, shown in Fig. 10, is carefully designed to make its Web pages more user friendly and also to increase download speed by avoiding unnecessary images. Since the client users will be mainly operators and engineers, they will want efficient information delivery instead of flashy graphics [37]. The current system status is placed on the left, the system message is in the center, and the button control area is on the right. By pushing the enabled buttons, the remote manager can issue commands to start tasks operated by the local controller.
Fig. 10 also shows that M1 is available, and both M2 and M3 are occupied with the material z (the prestate of the mentioned deadlock in Section IV-B). In this situation, the button Load X to M1 or Load Y to M1 is enabled to meet Spec-1, while the Load X-Y to M1 button is disabled by the supervisory agent to satisfy Spec-4, and the other buttons are disabled to meet Spec-2, Spec-3, and recipe specifications. The remote manager can only push the button Load X to M1 or Load Y to M1 to generate the product x-z or y-z, respectively. Thus, the desired requirements of the three-recipe FMS are guaranteed as the commands issued by the remote human manager are conducted.
E. Discussion
In the proposed hierarchical framework, the supervisor turns out to be more compact and simple, since it deals only with the command-level tasks, i.e., groups of operations. This greatly simplifies analysis and validation of the supervisor. The im-plementation of several elementary operations can be grouped into a single task performed by the local controllers. Separation of detailed control and supervision enables us to increase the conciseness of our design problem and makes the complexity manageable.
By comparison, as shown in Table III, using a conventional nonhierarchical approach [8] to the present three-recipe FMS, verification of the supervisor has to resolve all deadlock sit-uations by searching the whole reachability graph, with the detailed control-level operations in a 2228-state space. How-ever, by applying the proposed hierarchical framework, the
Fig. 10. Interactive Web page for remote supervision of the FMS by a Java applet (only three buttons are admissible).
TABLE III
COMPARISON BETWEEN THENONHIERARCHICAL ANDHIERARCHICALAPPROACHES
supervisor design has a more compact model with a 248-state space.
Moreover, to produce 30 products (ten x-y, x-z, y-z each), 560 request/response transmissions over the Internet are consumed in the nonhierarchical approach, while only 260 ones are re-quired using the proposed hierarchical scheme.
V. CONCLUSION
This paper has presented a unified PN framework to design and implement a hierarchical supervisory system for remote-controlled processes. The supervisor is systematically synthe-sized using PNs to enforce the command-level specifications of resource constraints and liveness for the processes, and then is implemented with agent technology. The local controller in the lower level is also designed with PNs to meet the control-level specifications and is implemented by the LLD. To illustrate the proposed approach, an application to a three-recipe FMS controlled over the Internet is provided. According to the feed-back status of the remotely located system, the designed Java-based supervisory agent guarantees that all requested commands
from the human manager satisfy the requirements for multiple recipes, resource sharing, and deadlock avoidance, while the de-veloped local controller performs the corresponding operations to meet the requested tasks. Moreover, results show that the su-pervisor synthesis of the presented hierarchical scheme is less complex than the conventional nonhierarchical one, and fewer packet transmissions are consumed so that the effects of time delays and packet losses across the Internet could be moderated. Since the original supervisory control framework [10]–[14] is restricted to purely logical system models, for applications with time-based requirements (e.g., transmission delays), it is necessary to extend the present models with time specifications. Moreover, novel specifications for the error recovery due to the packet losses should be investigated in the future.
