Femtosecond Laser-Induced Formation of Wurtzite Phase ZnSe Nanoparticles in Air

(1)

Volume 2012, Article ID 278364,6pages doi:10.1155/2012/278364

Research Article

Femtosecond Laser-Induced Formation of Wurtzite Phase

ZnSe Nanoparticles in Air

Hsuan I Wang,

1

_{Wei Tsung Tang,}

1

_{Li Wei Liao,}

1

_{Pei Shan Tseng,}

1

_{Chih Wei Luo,}

1

Chu Shou Yang,

2

_{and Takayoshi Kobayashi}

1, 3

1_{Department of Electrophysics, National Chiao Tung University, Hsinchu 30010, Taiwan} 2_{Graduate Institute of Electro-optical Engineering, Tatung University, Taipei 104, Taiwan}

3_{Advanced Ultrafast Laser Research Center and Department of Engineering Science, Faculty of Informatics and Engineering,}

The University of Electro-Communications, 1-5-1 Chofugaoka, Chofu, Tokyo 182-8585, Japan Correspondence should be addressed to Chih Wei Luo,[email protected]

Received 27 March 2012; Revised 21 June 2012; Accepted 9 July 2012 Academic Editor: Marinella Striccoli

Copyright © 2012 Hsuan I Wang et al. This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. We demonstrate an eﬀective method to prepare wurtzite phase ZnSe nanoparticles from zincblende ZnSe single crystal using femtosecond pulse laser ablation. The fabricated ZnSe nanoparticles are in spherical shape and uncontaminated while synthesized under ambient environment. By controlling the laser fluences, the average size of ZnSe nanoparticles can be varied from∼16 nm to∼22 nm in diameter. In Raman spectra, the surface phonon mode becomes dominant in the smaller average particle size with uniform size distribution. The interesting phase transition from the zinc blende structure of ZnSe single crystal to wurtzite struc-ture of ZnSe nanoparticles may have been induced by the ultrahigh ablation pressure at the local area due to the sudden injection of high energy leading to solid-solid transition.

The nanometer sized materials have provided an opportu-nity to study the relation between material properties and size. Due to the uniquely dimension-dependent properties, the nanosized material has the potential for various applica-tions such as nanoelectronics, nanosensors, nanooptronics, and chemical catalyst [1–3]. The nanostructures of zinc selenide (ZnSe), in particular, have attracted considerable attention. ZnSe is an important II–VI semiconductor due to its promising optoelectrical and electrical properties of direct wide band gap 2.68 eV at 300 K. The ZnSe nanoparticles can be obtained through chemical reduction [4], vapor synthesis [5], or laser ablation method [6]. Generally, crystalline ZnSe exhibits two structural phases, that is, zinc blende and wurtzite [7]. However, the studies on wurtzite phase ZnSe nanoparticles are few [8–10] owing to that the wurtzite struc-ture is thermodynamically unstable in ambient environ-ments and requires the critical growth conditions. Recently, the femtosecond (fs) laser ablation has been extensively used for material processing [11–15]. Because of the unique

features, in fs time-scale pulse duration and high power den-sity (∼GW/cm2_{), the high quality nanosized materials can}

be obtained without thermal eﬀects. For instance, nanospike [12], nanowire [14], and nanoparticle [13, 15] have been produced through this approach. In this study, we present a handy way to fabricate pure ZnSe nanoparticles in metastable wurtzite structure through femtosecond laser ablation tech-nique. The structural phase transition from zinc blende to wurtzite takes place during the processing and the size of nanoparticles is controllable by adjusting the laser fluences. Additionally, the characteristics and formation mechanism of ZnSe nanoparticles was investigated.

The fs laser pulses used in this study were provided by a Ti: sapphire regenerative amplifier with 800 nm and 80 fs at a repetition rate of 5 kHz. The linearly polarized laser pulses were focused by a planoconvex fused silica cylindrical lens with the focal length of 100 mm at normal incidence. The spot size on the surface of samples is 2270μm×54μm. The pulse energy was varied from 0 to 260 mJ/cm2 _{by using}

(2)

0 20 40 60 80 100 120 140 160 0 100 200 0 200 400 600 800 0 100 200 300 Diameter of nanoparticles (nm) 0 1 2 3 4 N o rmaliz ed c ount Energy (keV) Zn Se (a) (b) (c) N umber of nanopar ticles 50 nm 220 mJ/cm2 198 mJ/cm2 135 mJ/cm2 1101 0111 1010 1010 0111 1101

Figure 1: (a) TEM images of ZnSe nanoparticles fabricated by the fluence of 220 mJ/cm2_{. Inset: the EDS spectrum shows the composition}

of ZnSe nanoparticles. (b) TEM diﬀraction patterns of ZnSe nanoparticles in (a). (c) Size distribution of ZnSe nanoparticles at various laser fluences corresponding to the TEM images in (a) with an area of 3.2μm×2.6μm. The solid lines are the log-normal fitting.

metallic neutral density filters with OD0.1–OD2 (Thor-labs ND series). A double-side polished (100) ZnSe wafer (5 mm ×5 mm ×0.5 mm) was mounted on a motorized

x-y-z translation stage with the scanning speed of 100μm/s.

After laser irradiation, a pale yellow powder, that is, ZnSe nanoparticles, was observed on the surface of a processed ZnSe crystal. Depending on the experimental purpose, the nanoparticles were preserved in two diﬀerent ways, that is, dissolved in ethanol with ultrasonic waves or picked up with Scotch tape. After removing the ZnSe powder, there were many subwavelength ripples shown on the surface of a laser ablated ZnSe wafer. The direction of ripples was perpendic-ular to the polarization of laser beam and laser scanning path which is consistent with the scenario of the interference between incident beam and scattering laser light [16]. The morphology of ZnSe single crystals, before and after laser

ablation, was examined using a scanning electron micro-scope (SEM). Moreover, the X-ray diﬀraction, the Raman scattering spectra, transmission electron microscopy (TEM), and the selected area electron diﬀraction were applied to identify the structure and characteristics of laser-induced ZnSe nanoparticles.

Figure 1(a) shows a typical TEM image of ZnSe

nanopar-ticles with the smooth spherical shape. The diameters of ZnSe nanoparticles are in the range of tens nanometer. In the selected area electron diffraction (SAED) pattern, a six-fold symmetry was clearly observed inFigure 1(b). Through the analysis of distance and angles between the nearest diffrac-tion points and the center biggest point, the crystal struc-ture of ZnSe nanoparticles was identified as a hexagonal (wurtzite) and the orientation of each diffraction point was marked in Figure 1(b). Furthermore, the energy dispersive

(3)

220 mJ/cm2 198 mJ/cm2 172 mJ/cm2 135 mJ/cm2 ZB(400) ZB(200) ZnSe wafer 20 30 40 50 60 70 2θ (deg) In te nsit y (a.u.) W(112) W(103) W(110) W(102) W(002) W(101) W(100) x1/55 (a) 220 mJ/cm2 135 mJ/cm2 220 mJ/cm2 198 mJ/cm2 172 mJ/cm2 ZnSe wafer 200 210 180 240 270 250 300 350 Wavenumber (cm−1₎ Wavenumber (cm−1₎ N o rmaliz ed int ensit y (a.u.) TO LO S (b)

Figure 2: (a) X-ray diﬀraction patterns of ZnSe wafer and ZnSe nanoparticles fabricated at various laser fluences. W: Wurtzite. ZB: Zinc blende. (b) Raman spectra of ZnSe wafer and ZnSe nanoparticles fabricated at various fluences. The 633.0 nm laser was used as the excitation light. Inset: the Raman spectra of ZnSe nanoparticles fabricated at fluence of 220 mJ/cm2_{on a large scale with Lorentz peak fitting. TO:}

trans-verse optical phonon mode. LO: longitudinal optical phonon mode.S: surface phonon mode.

X-ray spectra (EDX) showed that Zn and Se are the only elements detected in the laser fabricated nanoparticles and the molar ratio of zinc and selenium is close to 1 : 1 (see the inset ofFigure 1(a)). During the femtosecond laser irradia-tion, the dense plasma is formed on the sample surface via multiphoton absorption [17]. The ablated plume was con-fined near the laser focused region by surrounding air which prevents other ingredients of air, such as nitrogen, oxygen, and carbon dioxide, to get involved in the formation process of ZnSe nanoparticles under ambient environment. The size distribution of ZnSe nanoparticles fabricated at various fluences was analyzed inFigure 1(c). By fitting with the log-normal function, the average diameter of ZnSe nanoparticles was determined to be approximately 16 nm in the case of 135 mJ/cm2_{. With an increase in the laser fluence to 198 mJ/}

cm2_{and 220 mJ/cm}2_{, the average size of the ZnSe}

nanopar-ticles slightly increased to 20 nm and 22 nm, respectively. Although the variation of average size (∼6 nm) is smaller than the statistic bar width of 10 nm inFigure 1(c) (deter-mined by the variation of average size of ZnSe nanoparticles under same fluences, which is caused by the fluctuations of laser fluences, pulse durations, spectra, and so on.), the

higher fluence indeed generate more ZnSe nanoparticles with larger size. This indicates that the size distribution of ZnSe nanoparticles can be controlled by adjusting laser flu-ence and increases as the laser fluflu-ence rises. Furthermore, the generation rate of ZnSe nanoparticles using fs laser pulses is approximately 3.63×1010_s−1_{(or 7.26}_×₁₀6_{per pulse) with}

a fluence of 135 mJ/cm2_{. For the higher fluence of 220 mJ/}

cm2_{, the generation rate of ZnSe nanoparticles increased by}

one order of magnitude to 3.63×1011_s−1_{(or 7.26}_×₁₀7_per

pulse).

In Figure 2(a), X-ray diﬀraction patterns revealed the

structures of a ZnSe single-crystal wafer and the ZnSe nanoparticles fabricated under various laser fluences are zinc blende and wurtzite, respectively, according to the JCPDS card no. 80-0021 (a = 5.618 ˚A) and no. 80-0008 (a =

b = 3.974 ˚A, c = 6.506 ˚A) for ZnSe. It can be clearly seen that the zinc blende phase of a ZnSe single-crystal wafer has been transferred to the wurtzite phase in the ZnSe nanoparticles. Because wurtzite ZnSe is a metastable phase under ambient conditions, it can only be observed under high pressure and high temperature conditions. However, wurtzite ZnSe nanoparticles can be easily and reliably

(4)

achieved using femtosecond laser ablation as demonstrated in this study. Additionally, the room-temperature Raman scattering spectra of samples was measured by micro-Raman system as shown inFigure 2(b). The typical Raman scattering peaks of ZnSe nanoparticles were clearly observed from 200 to 250 cm−1 _{which are rather di}_{ﬀerent from that of ZnSe}

single crystal wafer. Moreover, there was no vibration mode due to impurities observed in the Raman spectra which is consistent with the above EDX results. A look at the Raman spectra in the case of 220 mJ/cm2_{can be fitted well by three}

Lorentzian lines located at 250, 232, and 203 cm−1_{. The peaks}

at 203 and 250 cm−1 _{are attributed to the transverse optical}

(TO) phonon mode and longitudinal optical (LO) phonon mode of ZnSe, respectively [18,19]. Another peak located at 232 cm−1_{between the LO and TO phonons is assigned to be}

the surface phonon mode (S) of nanoparticles. This phe-nomenon, appearance of surface phonon mode, can be decidedly observed in small-sized material [9,20] due to the high surface to volume ratio and the dominant surface prop-erties. In order to figure out the relation between TO phonon mode and surface phonon mode, the theoretical expression was used as follows [20]:

ω2 S ω2 T = ε0+εm((1/L)−1) ε∞+εm((1/L)−1), (1) where ω_S and ω_T represent the surface phonon and TO phonon frequency, respectively;ε0andε∞are static and high-frequency dielectric constant, respectively;ε_mis the dielectric constant of surrounding medium andL indicates the depo-larization factor which is related to the particle shape. In the case of ZnSe,ω_T =203 cm−1_,_ε

0 =8.6, ε∞ =5.7, and εmis equal to 1 for air surrounding condition [18]. Because the laser-fabricated ZnSe nanoparticles are in spherical shape, according to the TEM image shown inFigure 1(a), the depo-larization factor (L) is 1/3. Using (1), the calculated surface phonon mode is located at 238 cm−1_{which is consistent with}

the measured value of 232 cm−1_{. It is worth to note that}

the LO, TO, and surface phonon modes are strongly fluence dependent. As the laser fluence decreases, the LO and TO peaks gradually shrink; meanwhile, the surface phonon mode increases. In the case of 135 mJ/cm2_{, the surface}

phonon mode almost dominates the Raman spectra, which is due to the smaller average size and more uniform size dis-tribution as shown inFigure 1(c). Additionally, the small-size nanoparticles also result in the red shift of surface phonon mode.

According to the early researches, ZnSe transforms from a zinc blende structure to the wurtzite structure when the temperature is above the transition temperature (Ttr) of

1698 K [7]. When ZnSe crystals are irradiated by the fem-tosecond laser pulses, the temperature of electrons and lattice in ZnSe crystals increases according to the two-temperature model [21]. Because of the much smaller heat capacity in electron subsystem, the increase of electron temperature is dramatically larger than that of lattice. The electron temper-atureTecan be described by [22]

Te= T2 i +2(1_l−R)F sγ e −z/ls , (2)

where R is the reflectivity at 800 nm and F is the laser fluences and γ is the linear coeﬃcient of heat capacity due to the electronic subsystem. The mean value is taken for the depth

z going from the crystal surface down to the skin depth ls∼1.87 μm (it was estimated from the nonlinear absorption coeﬃcient β [23]). In this study, takingT_i =295 K, R= 0 (which is assumed to be totally absorbed by ZnSe), F =

220 mJ/cm2_{, and}_γ₌₂₉_{.4 mJ mol}−1_K−1_[₂₄_{], we obtain}_T e∼

1200 K. However, for the structure transition in materials, the key factor is the lattice temperature rather than the elec-tron temperature. Thus, we further consider the increase in the transient temperatureΔTin materials can be estimated according to the relationship ofΔT = W/(C×V), where W is the pulse energy, C is the heat capacity, and V is the

illuminated volume. For ZnSe at 300 K, C is ∼1.89 × 106_J/m3_{K [}₇_], _{V is 2.29} _× ₁₀−13_m3 _{(absorption depth}

1.87μm estimated from the nonlinear absorption coeﬃcient

β [23]), andW is in the order of 0.243 mJ (which is assumed to be totally absorbed by ZnSe). Thus, the ΔT is approx-imately 560 K, which is far below the structural transition temperature of 1698 K. Therefore, a structural transition could not be induced by the increase in temperature. To identify the mechanism underlying the phase transition of ZnSe from zinc blende to wurtzite, we further analyzed the influence of “ablation pressure” [25], which has been studied from various perspectives over the past few decades [26, 27]. When solids are irradiated by laser pulses, high-density plasma is formed on the surface of the samples [17]. The compressed plasma in laser driven implosions has been char-acterized as the ablating or exploding pusher according to the surface ablation pressure and bulk pressure due to the preheating through electrons.

In 2003, Batani et al. [25] derived the shock pressure with the laser and target parameters expressed as

P(Mbar)=11.6 _I 1014 3/4 λ−1/4A 2Z 7/16_Z_×_t 3.5 −1/8 , (3) whereI is the irradiance on target with the unit of W/cm2_;

λ is the laser wavelength in μm; A and Z are, respectively,

the mass number and the atomic number of the target; t is the time in ns. Figure 3 shows the eﬀective pressure in the irradiated region with the laser peak power density of 0∼3.0×1012_W/cm2_{. In this study, the maximum pressure}

induced by the laser reached approximately 1.5 Mbar. Accor-ding to the studies of Greene et al. in II–VI compounds [28], the solid-solid transition point, that is, the zinc blende-wurtzite phase transition, of ZnSe is approximately 0.55 Mbar. In our experiments, the ablation pressure induced by the femtosecond laser pulses on the ZnSe single crystals was in the range of 1.0 Mbar to 1.5 Mbar as shown in the shadow area ofFigure 3. This exceeds the solid-solid transi-tion pressure 0.55 Mbar (the dashed line inFigure 3). There-fore, the wurtzite-phase ZnSe nanoparticles transferred from the zinc blende phase may be caused by high ablation pressure resulting from the femtosecond laser pulses, and the accompanied increase in surface to volume ratio in the nanoparticles.

(5)

5×1011 ₁_×₁₀12 ₁_.5_×₁₀12₂_×₁₀12 ₂_.5_×₁₀12₃_×₁₀12 0 0 0.5 1 1.5 2 A b lation pr essur e (Mbar)

Ablation pressure of fs laser pulses

Structure transition pressure

Power density (W/cm2₎

Figure 3: Simulated ablation pressure as a function of the laser peak power density according to (3). The shadow area indicates the range of laser peak power density in this study and corresponding ablation pressure. The dashed line represents the pressure of zinc blende-wurtzite phase transition, that was obtained from [28].

In summary, we demonstrated a simple and reliable approach to obtain the thermally metastable and pure ZnSe nanoparticles. The spherical-shape wurtzite ZnSe nanopar-ticles with the average diameter of <25 nm can be well produced through the femtosecond laser ablation technique. While the femtosecond laser pulses are focused on the surface of a ZnSe wafer in air, the ablated plume cannot expand as rapidly as those in vacuum chamber and then causes an instantaneous high-energy and high-pressure region around the laser focused point; meanwhile, a large amount of ZnSe nanoparticles was fabricated on the surface of a ZnSe wafer. During the formation of ZnSe nanoparticles, the structural phase further changes from the zinc blende phase to the metastable wurtzite phase due to the ultrahigh localized ablation pressure caused by the rapid injection of high laser energy within a femtosecond time scale.

Acknowledgments

The authors would like to express their sincere appreciation and gratitude to W. T. Chen and Professor Y. J. Hsu for their technical support. This work was supported by the MOE-ATU program at NCTU and National Science Council of Taiwan, under Grant no. NSC 98-2112-M-009-008-MY3.

References

[1] M. Bruchez, M. Moronne, P. Gin, S. Weiss, and A. P. Alivisatos, “Semiconductor nanocrystals as fluorescent biological labels,” Science, vol. 281, no. 5385, pp. 2013–2016, 1998.

[2] R. S. Friedman, M. C. McAlpine, D. S. Ricketts, D. Ham, and C. M. Lieber, “Nanotechnology: high-speed integrated nano-wire circuits,” Nature, vol. 434, no. 7037, p. 1085, 2005. [3] W. C. W. Chan and S. Nie, “Quantum dot bioconjugates for

ultrasensitive nonisotopic detection,” Science, vol. 281, no. 5385, pp. 2016–2018, 1998.

[4] J. Che, X. Yao, H. Jian, and M. Wang, “Application and pre-paration of ZnSe nanometer powder by reduction process,” Ceramics International, vol. 30, no. 7, pp. 1935–1938, 2004. [5] D. Sarigiannis, J. D. Peck, G. Kioseoglou, A. Petrou, and T.

J. Mountziaris, “Characterization of vapor-phase-grown ZnSe nanoparticles,” Applied Physics Letters, vol. 80, no. 21, pp. 4024–4026, 2002.

[6] K. V. Anikin, N. N. Melnik, A. V. Simakin, G. A. Shafeev, V. V. Voronov, and A. G. Vitukhnovsky, “Formation of ZnSe and CdS quantum dots via laser ablation in liquids,” Chemical Physics Letters, vol. 366, no. 3-4, pp. 357–360, 2002.

[7] P. Rudolph, N. Sch¨afer, and T. Fukuda, “Crystal growth of ZnSe from the melt,” Materials Science and Engineering R, vol. 15, no. 3, pp. 85–133, 1995.

[8] Y. P. Leung, W. C. H. Choy, I. Markov, G. K. H. Pang, H. C. Ong, and T. I. Yuk, “Synthesis of wurtzite ZnSe nanorings by thermal evaporation,” Applied Physics Letters, vol. 88, no. 18, Article ID 183110, 2006.

[9] C. X. Shan, Z. Liu, X. T. Zhang, C. C. Wong, and S. K. Hark, “Wurtzite ZnSe nanowires: growth, photoluminescence, and single-wire Raman properties,” Nanotechnology, vol. 17, no. 22, article 006, pp. 5561–5564, 2006.

[10] L. Jin, W. C. H. Choy, Y. P. Leung, T. I. Yuk, H. C. Ong, and J.-B. Wang, “Synthesis and analysis of abnormal wurtzite ZnSe nanowheels,” Journal of Applied Physics, vol. 102, no. 4, Article ID 044302, 2007.

[11] A. P. Joglekar, H. Liu, G. J. Spooner, E. Meyh¨ofer, G. Mourou, and A. J. Hunt, “A study of the deterministic character of optical damage by femtosecond laser pulses and applications to nanomachining,” Applied Physics B, vol. 77, no. 1, pp. 25– 30, 2003.

[12] M. Y. Shen, C. H. Crouch, J. E. Carey, and E. Mazur, “Fem-tosecond laser-induced formation of submicrometer spikes on silicon in water,” Applied Physics Letters, vol. 85, no. 23, pp. 5694–5696, 2004.

[13] C. W. Luo, C. C. Lee, C. H. Li et al., “Ordered YBCO sub-micron array structures induced by pulsed femtosecond laser irradiation,” Optics Express, vol. 16, no. 25, pp. 20610–20616, 2008.

[14] T. Jia, M. Baba, M. Huang et al., “Femtosecond laser-induced ZnSe nanowires on the surface of a ZnSe wafer in water,” Solid State Communications, vol. 141, no. 11, pp. 635–638, 2007. [15] Y. Nakata, T. Okada, and M. Maeda, “Fabrication of dot

matrix, comb, and nanowire structures using laser ablation by interfered femtosecond laser beams,” Applied Physics Letters, vol. 81, no. 22, pp. 4239–4241, 2002.

[16] C. Wang, H.-I. Wang, W.-T. Tang, C.-W. Luo, T. Kobayashi, and J. Leu, “Superior local conductivity in self-organized nano-dots on indium-tin-oxide films induced by femtosecond laser pulses,” Optics Express, vol. 19, no. 24, pp. 24286–24297, 2011.

[17] A. De Giacomo, M. Dell’Aglio, A. Santagata, and R. Teghil, “Early stage emission spectroscopy study of metallic titanium plasma induced in air by femtosecond- and nanosecond-laser pulses,” Spectrochimica Acta B, vol. 60, no. 7-8, pp. 935–947, 2005.

[18] W. Martienssen and H. Warlimont, Springer Handbook of Con-densed Matter and Materials Data, Springer, Berlin, Germany, 2005.

[19] Z. D. Hu, X. F. Duan, M. Gao, Q. Chen, and L.-M. Peng, “ZnSe nanobelts and nanowires synthesized by a closed space vapor transport technique,” Journal of Physical Chemistry C, vol. 111, no. 7, pp. 2987–2991, 2007.

(6)

[20] S. Hayashi and H. Kanamori, “Raman scattering from the surface phonon mode in GaP microcrystals,” Physical Review B, vol. 26, no. 12, pp. 7079–7082, 1982.

[21] S. I. Anisimov, B. L. Kapeliovich, and T. L. Perelman, “Electron emission from metal surfaces exposed to ultrashort laser pulses,” Soviet Physics JETP, vol. 39, pp. 375–377, 1974. [22] C. W. Luo, I. H. Wu, P. C. Cheng et al., “Quasiparticle

dynam-ics and phonon softening in FeSe superconductors,” Physical Review Letters, vol. 108, no. 25, Article ID 257006, 2012. [23] K. Y. Tseng, K. S. Wong, and G. K. L. Wong, “Femtosecond

time-resolved Z-scan investigations of optical nonlinearities in ZnSe,” Optics Letters, vol. 21, no. 3, pp. 180–182, 1996. [24] J. A. Birch, “Heat capacities of ZnS, ZnSe and CdTe below

25K,” Journal of Physics C, vol. 8, no. 13, Article ID 013, pp. 2043–2047, 1975.

[25] D. Batani, H. Stabile, A. Ravasio et al., “Ablation pressure scaling at short laser wavelength,” Physical Review E, vol. 68, no. 6, Article ID 067403, pp. 674031–674034, 2003.

[26] M. H. Key, P. T. Rumsby, R. G. Evans, C. L. S. Lewis, J. M. Ward, and R. L. Cooke, “Study of ablatively imploded spher-ical shells,” Physspher-ical Review Letters, vol. 45, no. 22, pp. 1801– 1804, 1980.

[27] J. S. De Groot, K. G. Estabrook, W. L. Kruer, R. P. Drake, K. Mizuno, and S. M. Cameron, “Distributed absorption model for moderate to high laser powers,” Physics of Fluids B, vol. 4, no. 3, pp. 701–707, 1992.

[28] R. G. Greene, H. Luo, and A. L. Ruoﬀ, “High pressure X-ray and Raman study of ZnSe,” Journal of Physics and Chemistry of Solids, vol. 56, no. 3-4, pp. 521–524, 1995.
