摘 要
主動矩陣液晶顯示器﹙AMLCDs﹚因為其輕、薄、低輻射量及低
耗電量的種種優點，近年來已經漸漸地取代了傳統的陰極射線管
﹙CRT﹚顯示器。主動矩陣液晶顯示器以往都是利用非晶矽薄膜電晶
體來當作畫素開關元件。然而如果要把週邊驅動電路一起整合到主動
矩陣的玻璃基板上，低溫覆晶矽薄膜電晶體肯定是唯一的選擇，這也
是近幾年來低溫覆晶矽薄膜電晶體一直被廣為研究的主要原因。
在本論文中，我們提出利用四氟化碳﹙CF
4﹚電漿處理來改善低
溫覆晶矽薄膜電晶體的電特性及可靠度。在電特性的改善方面，四氟
化碳電漿中的氟能修補界面處的不完全鍵結，減少界面處及覆晶矽通
IV
道中的缺陷，進而提高了覆晶矽薄膜電晶體的導通電流及場效遷移
率，並使得關閉態的漏電流及次臨限擺幅﹙Subthreshold-Swing﹚降低。
在可靠度的提昇方面，在受到熱載子應力測試﹙Hot-carrier stress﹚及
自我加熱應力測試﹙Self-heating stress﹚後，經過四氟化碳電漿處理
的低溫覆晶矽薄膜電晶體會有較輕微的特性衰退，這是因為氟與矽原
子的強鍵結取代了原本較弱的氫與矽原子以及矽與矽原子鍵結。
最後，我們利用了不同的電應力測試﹙Stress﹚條件來觀察熱載
子﹙Hot-carrier﹚所引發的元件衰退，進一步提出元件劣化的機制。
我們發現導通電流與關閉電流的變異會隨電應力測試條件以及量測
之汲極電壓﹙V
DS﹚改變而不同，這是因為不同的電應力測試條件會
造成不同數量的閘極絕緣層捕捉電荷或覆晶矽通道缺陷。
V
Performance and Reliability Improvements in
Low-Temperature Polysilicon Thin-Film Transistors
with CF
4Plasma Treatment
Student: Wei-Hsiang Lo
Advisor: Dr. Tan-Fu Lei
Department of Electronics Engineering &
Institute of Electronics
National Chiao Tung University
ABSTRACT
In the past few years, traditional cathode-ray tube (CRT) displays have been
being replaced gradually by active matrix liquid crystal displays (AMLCDs) because
of their diverse advantages such as lightweight, flimsy, low radiation and low power
consumption. Hydrogenated amorphous thin- film transistors (a-Si:H TFTs) were
utilized for the pixel-switching devices in AMLCDs. However, low temperature
polycrystalline silicon thin- film transistor (LTPS TFT), undoubtedly, is the only
candidate for integrating the peripheral driver circuits onto the glass substrates of the
active matrix. It is the major reason that the LTPS TFTs have been studied widely in
VI
In this thesis, we proposed that the electrical characteristics and reliability of the
LTPS TFTs can be improved significantly by utilizing the CF4 plasma treatment. The
incorporated fluorine can replace the dangling bonds and strain bonds in the poly-Si
channel and SiO2/poly-Si interface and thus reduce the interface states and trap states
in poly-Si, further increase the ON current and field effect mobility and decrease the
OFF current and subthreshold-swing. For the reliability issue, less degradation have
been found in the LTPS TFTs with CF4 plasma treatment after hot-carrier stress or
self-heating stress. That is due to the stronger Si-F bonds instead of weaker Si-H and
Si-Si bonds.
Finally, the mechanism of hot-carrier induced device degradation ha s been
proposed by applying a various static stress conditions. We found that the on and off
current variation are strongly influenced by the applied static stress conditions and
drain voltage. This is due to different amount of charges trapping in gate insulator or
VII
誌謝
論文的完成，首先要向我的指導教授雷添福博士至上最高的敬意。感謝雷添 福博士在我這二年的碩士生涯中給予學業研究的鼓勵與支持，並且在我報告實驗 進度與想法時，提供了很多寶貴的意見，使我獲益匪淺。 再者，我要特別地感謝王獻德學長，學長在觀念上、實驗操作上、量測分析 上及論文寫作上都很熱心地幫助我，令我受益良多。另外還有實驗室的李名鎮學 長、表哥學長、李介文學長、柏儀學長、哲麒學長、李宗霖學長、謝明山學長、 小強學長、建豪學長、楊紹明學長、小賢學長、小野柳學長與美錡學姊，感謝你 們這段日子以來的關心與指導。此外，感謝這陣子來一起同甘共苦的松齡、久盟、 國誠、余俊，我永遠不會忘記因為計測實驗熬夜量 Charge Pumping 所以連續一 個禮拜都看到日出的那段日子。也要感謝實驗室的學弟們任逸、志仰與家文，尤 其在我做完實驗很累的時候，桑學弟的冷笑話往往都會讓我精神為之一振。感謝 半導體中心的徐秀鑾小姐與黃月美小姐在這陣子以來的關心與實驗上的協助，也 感謝彭兆光先生對實驗機台的維護與整修。 最後，我要向我的父母羅瑞焜先生與程秀蘭小姐表達我最深的感謝，感謝他 們無怨無悔的犧牲奉獻及在我低潮時扶持我繼續向前，沒有你們的支持與鼓勵， 就不會有現在的我，僅以此論文獻給你們。VIII
