Performance of ejector cooling system with thermal pumping effect using R141b and R365mfc

Performance of ejector cooling system with thermal pumping effect

using R141b and R365mfc

Jin Hua Wang, J.H. Wu, S.S. Hu, B.J. Huang

a r t i c l e

i n f o

Received 30 March 2008 Accepted 20 August 2008 Available online 31 August 2008 Keywords:

Ejector cooling system Ejector

R365mfc R141b

a b s t r a c t

The ejector cooling system (ECS) is suitable for solar cooling application due to its simple design and low cost. An ECS using a multi-function generator (ECS/MFG) as a thermal pumping device without rotating machines for refrigerant circulation has been designed and tested. The experiment of an ECS/MFG oper-ating at full-cycle while using R141b has shown that the COPocan reach 0.225 and cooling capacity of 0.75 kW at generator temperature 90 °C, condenser temperature 37 °C, and evaporator temperature 8.5 °C. The present study also redesigned the ejector for working fluid R365mfc in order to replace R141b. This study has shown that R365mfc can replace R141b as the working fluid of ECS/MFG at no pay-off of system performance as long as the ejector design is optimized.

Ó 2008 Elsevier Ltd. All rights reserved.

1. Introduction

The ejector cooling system (ECS) is suitable for solar cooling application due to its simple design and low cost. Many research-ers were devoted to the study of ejector design to improve the COP. Huang et al.[1,2]has shown that the COP of an ECS, with a proper design in ejector and system structure, can reach 0.54 at generator temperature 84 °C, condenser temperature 28 °C, and evaporator temperature 8 °C. This makes the ECS may become competitive to the sorption (absorption and adsorption) system that is much more complicated in design and more expensive.

In the ECS, the condenser temperature must be lower than the critical condenser temperature (critical point). Fig. 1 shows the typical performance curve of ECS[1,2]. As the condenser tempera-ture is below the critical point, Tc < Tc, the ejector performance is under the critical mode and COP remains constant. However, when the condenser temperature is increased higher than critical point, T

c < Tc < Tc0, the ejector performance then enters into the sub-critical mode and COP decreases with increasing condenser tem-perature. If the condenser temperature is further increased, Tc> Tc0, the ejector performance enters into the back-flow mode which is not workable. Therefore, the ejector needs to be operated at critical mode in order to obtain a better performance.

The only rotating machine in the ECS is the mechanical pump for circulating the working fluid from the condenser back to the generator. The mechanical pump is usually inefficient and easy to break down since it operates near the saturated-liquid state.

Pump-less technology is thus very important for the commerciali-zation of the ECS.

Nguyen et al.[3]developed a pump-less ECS using a barometric siphon for pumping the working fluid from the low pressure side, condenser, to the high pressure side, generator. This system has minimal maintenance requirement, the potential for a long life time, and a low danger of breakdown. The experimental results show that the system COP was 0.32 and cooling capacity was 7 kW at generator temperature 76.7 °C, condenser temperature 26.7 °C, and evaporator temperature 1.5 °C. In this ECS, the con-denser has to be raised up to a high enough level, 7 m, to induce a sufficient gravitational force for return of the working fluid back to the generator. This restricts many applications due to the allow-able height limit of the machine.

Aphornratana et al.[4]developed a heat-power ECS which em-ployed the workless-generator-feeding (WGF) to replace the mechanical pump. The WGF operated alternately between filling phase and feeding phase. The working fluid was then pumping from condenser to generator via gravity and thermal energy. The prototype using R141b as a working fluid was constructed and tested. The experimental results show that this system was feasi-ble, but it needed more power consumption into the generator to driver the WGF. The generator input power is about 10–15% great-er than the ECS using the mechanical pump. Hence, as the WGF operated, it interchanged frequently, the COP of this system was comparatively lower.

The ECS can also use a heat-driven pump (HDP) to replace the mechanical pump. Extensive studies related to the HDP were car-ried out by many researches[5–18]. The HDP requires no rotating machines and no electric power for operation. However, the direct use of HDP in ECS has some problems since the HDP needs some 1359-4311/$ - see front matter Ó 2008 Elsevier Ltd. All rights reserved.

doi:10.1016/j.applthermaleng.2008.08.015

* Corresponding author. Tel.: +886 2 2363 4790; fax: +886 2 2364 0549. E-mail address:[email protected](B.J. Huang).

Contents lists available atScienceDirect

Applied Thermal Engineering

specially-designed parts to generate mechanical work in order to drive the working fluid. The energy efficiency of the HDP is also very low.

Huang et al.[19]combined the concept of HDP with the design of ECS to come up with the new ejector cooling system without a mechanical pump. The system utilized a multi-function generator (MFG) to eliminate the mechanical pump. This new ECS uses a MFG that acts as a generator for vapor generation and as a feed pump for returning liquid to the generator. The schematic diagram of the ejector cooling system with a multi-function generator (ECS/ MFG) is shown inFig. 2.

There are two MFGs (generators) in the ECS/MFG. Each MFG consists of a vapor generator (boiler) and an evacuation chamber. The vapor generator is a heat exchanger like a conventional boiler for heating the liquid in order to pressurize the whole generator and generate vapor. The evacuation chamber is composed of a cooling jacket and a liquid tank. The cooling jacket provides a cool-ing effect to depressurize the whole generator in order to intake the liquid from the condenser.

The two MFGs (MFG A and B) operate interchangeably through the control switching valves and check valves. The operation of each MFG can be divided into four phases: pressurizing, vapor dis-charge, depressurizing, and liquid intake. While MFG A is operating at depressurizing, liquid intake, and pressurizing phases, MFG B is operating at the vapor discharge phase. The cooling effect of the ECS/MFG is generated only at the vapor discharge phase. So, the

design of a MFG thus requires the total time duration for depres-surizing, liquid intake and pressurizing phases shorter than the period of discharge phase. The processes of the pressure variation of two MFGs are shown inFig. 3.

Huang et al.[19]built a prototype of the ECS/MFG using only one MFG (generator) for studying the feasibility of the new design concept. This machine is similar to absorption cooling system with half effect working model. The measured COPofor the half-cycle run with R141b was 0.218 and the cooling capacity was 0.786 kW at generator temperature 90 °C, condenser temperature 32.4 °C, and evaporator temperature 8.2 °C. It was shown that a continuous operation for the generation of cooling effect in the ECS/MFG could be achieved.

According to the working principle, one MFG can only produce a half-cycle cooling effect. Therefore, two MFGs need to be coupled together to generate a continuous cooling effect which is namely full cycle operation. The switching valves would be suitably manipulated to synchronize between the two MFGs. The present study continues this research to develop a proper switching tech-nique for the ECS/MFG to run in full cycle and carry out the perfor-mance test in full cycle.

Although the refrigerant R141b used in the experiment although has good performance, it still needs to be replaced with a low ODP working fluid. This requires modification of the ejector design in order to maintain a high COP. The R365mfc with zero ODP is a relatively new working fluid and has never been tested in the ECS. Bobbo et al.[20]described some its thermodynamic behavior. Table 1 lists some relevant properties of R141b and R365mfc. The present study also investigates the design of the ejector using R365mfc, in order to obtain a good performance of ECS/MFG.

2. Design of ejector cooling system with multi-function generator (ECS/MFG)

The prototype design of the ECS/MFG is basically the same as those described in [19], but with an automatic controller and two MFGs to obtain a full-cycle continuous operation as shown inFig. 4.

Table 2shows the design of the ejectors used in the experi-ments. For refrigerant R141b, the ejector area ratio, Ar= (Dt/Dc)2, is 7.73 which gives a good performance according to the previous study[1,2]. The nozzle and constant-area sections were selected for the ejector operated at critical-model. For R365mfc, the ejector needs to be magnified since its latent heat is lower than R141b (

Ta-Nomenclature Symbols

Ar ejector area ratio, Ar= (Dt/Dc)2 COP coefficient of performance Cp specific heat of water, kJ/kg °C Dt nozzle throat diameter, mm Dc constant-area diameter, mm M mass flow rate of water, kg/sec Pe evaporator pressure, MPa PMFGA MFG A pressure, MPa PMFGB MFG B pressure, MPa

Qc total heat output from the condenser, kW Qe cooling capacity, kW

Qh total heat input at pressurizing phase, kW Qg total heat input to the generator, kW Tc condenser temperature, °C

Tc0 condenser temperature of limiting condition, °C

T

c critical condenser temperature, °C Te evaporator temperature, °C Tex water exit temperature, °C Tin water inlet temperature, °C Tg generator temperature, °C

Wmec mechanical pump input energy, kW

Dt operation time of the vapor discharge phase, minute

Subscripts c condenser e evaporator g generator i intercooler max maximum

set set point

CO P

T

T

T

ble 1). Hence, we designed another ejector with area ratio of 9.10 and 11.03 to compare the performance.

The automatic controller was utilized to obtain a full-cycle con-tinuous operation and a constant evaporator temperature. The two MFGs operate interchangeably between pressurizing, vapor dis-charge, depressurizing, and liquid intake phases by an automatic controller to control the six solenoid valves (VA, VB, HA, HB, CA and CB) according to the algorithm shown inTable 3.

The automatic controller of ECS/MFG needs to measure evapo-rator pressure (Pe), two MFG pressures (PMFGA and PMFGB), and the operating time of the vapor discharge phase (DtMFGA and DtMFGB). Fig. 5shows sequence diagram of the ECS/MFG. As the MFG A is at the pressurizing phase, the vapor generator is heated with only the HA opened. At this time, the MFG B is operating at

Ejector Condenser Evaporator Expansion valve Check valve Check valve Solenoid valve (VB) MFG B Vapor generator Evacuation chamber Heat source Liquid tank Cooling jacket Check valve Solenoid valve (HB) Solenoid valve (VA) MFG A Solenoid valve (HA) Solenoid valve (CA) Solenoid valve (CB)

Fig. 2. Flow diagram of ejector cooling system with multi-function generator (ECS/MFG).

Pressure Time heating cooling Vapor discharge phase Pressurizing phase Depressurizing phase Liquid intake phase Liquid intake phase Depressurizing phase Vapor discharge phase Pressurizing phase MFG A MFG B

Fig. 3. Pressure variation of two MFGs.

Table 1

Thermodynamic property of R141b and R365mfc Working fluid Formula Molecular weight Normal boiling point temperature at 1atm (°C) Latent heat at 1 atm(kJ/kg) ODP relative to R11 R141b CH3CCl2F 117 32 222.7 0.11 R365mfc CF3CH2CF2CH3 148 40 192.8 0

a vapor discharge phase with the VB and HB opened. In the vapor discharge phase of either MFGs, the cooling effect of the ECS/MFG is generated. The vapor discharge phase of the MFG B is terminated when the evaporator pressure is higher than the set point (Pe_set) at 0.004 MPa, at which the cooling effect will be unstable.

MFG B enters into the depressurizing phase with the CB opened, the HB and VB closed to cool down the evacuation chamber. At this moment, the pressure in the MFG A rises to a level that can drive the ejector. MFG A then enters into the vapor discharge phase with the VA opened. The vapor is discharged to activate the ejector to produce a cooling effect. As the MFG B pressure is lower than the condenser, the check valve is opened to induce the liquid refrigerant return from the condenser. The MFG B enters into the liquid intake phase with the evacuation chamber still being cooled. In the initial three minutes when the MFG A enters into the vapor dis-charge phase, the MFG A pressure has some fluctuation since the system is not steady yet. In the vapor discharge phase, the MFG pressure has a maximum value. Once the MFG A pressure is lower than the maximum value at 0.004 MPa, the MFG A is nearly empty and the MFG B then enters into the pressurizing phase with the CB closed and the HB opened. An-other switch condition is the operating time of the vapor dis-charge phase for about six minutes which is related the volume of the liquid tank. As the evaporator pressure is high-er than the set point 0.004 MPa, the MFG A and MFG B are interchanged again. According to the sequence diagram, the ECS/MFG can operate sequentially and produce a stably cool-ing effect.

The system was installed with twenty-six T-type thermo-couples with an uncertainty of ± 0.7 °C, and five pressure transducers within a ±1% uncertainty (see Fig. 4). Thermocou-ples and transducers were installed at different locations [19]. The power consumption of the electrical heater was measured by a power meter within a ±1.5% uncertainty. The water flow rate of the evaporator, condenser, and cooling of the MFG were measured using water flow meters within a ±4% uncertainty. MFG B T T T T T T T T T T T T T T T Solenoid valve (VB) Expansion valve Precooler Evaporator Check valve Receiver Ejector Condenser Vapor generator P T T P T P P Tair Theater Check valve Evacuation chamber Solenoid valve (HB) Solenoid valve (CB) MFG A T T T T Solenoid valve (VA) Check valve Check valve Cooling jacket P T T Liquid tank Solenoid valve (HA) Solenoid valve (CA)

Fig. 4. Schematic description of experimental setup.

Table 2

Design of nozzle and constant-area section

Nozzle Constant-area section Ejector specification Throat diameter (mm) Exit diameter (mm) Constant-area diameter (mm) Inlet converging angle (°) Ejector area ratio 2.64 4.50 7.34 60 7.73 2.93 4.46 8.84 67 9.10 2.80 5.10 9.30 65 11.03 Table 3

Working states of two MFGs (O: open; X: close) MFG_A Pressurizing phase Vapor discharge phase Vapor discharge phase Depressurizing phase and liquid intake phase MFG_B Vapor

discharge phase

Depressurizing phase and liquid intake phase Pressurizing phase Vapor discharge phase HA O O O X VA X O O X CA X X X O HB O X O O VB O X X O CB X O X X

3. Experimental results and discussion

3.1. Continuous full-cycle operation of ECS/MFG using R141b The COP of an ejector cooling system is defined as

COP ¼ Qe

Qgþ Wmec

ð1Þ

The pumping power, Wmec, is neglected here since the system utilizes a multi-function generator (MFG) to eliminate the mechan-ical pump. Therefore, the COP of the ECS/MFG is defined as the ratio of the cooling capacity at the evaporator, Qe, to the total heat input to the generator (MFG), Qg. Two COPs are further defined and determined[19]. The system COP at vapor discharge phase, COPo, is defined as:

Time

MFG A

(P

)

P MFGA< P MFGA_max- 0 .004 MPa or Δt MFGA > 6 minutes Pe > Pe_set + 0.004 MPa ΔtMFGA> 3 minutes

Evaporator

(P

)

MFG B

(P

)

t

t

HA

O

O

O

O

X

X

O

VA

X

O

O

O

X

X

X

CA

X

X

X

X

O

O

X

HB

O

X

X

O

O

O

O

VB

O

X

X

X

O

O

O

CB

X

O

O

X

X

X

X

HA

O

O

O

O

X

X

O

VA

X

O

O

O

X

X

X

CA

X

X

X

X

O

O

X

HB

O

X

X

O

O

O

O

VB

O

X

X

X

O

O

O

CB

X

O

O

X

X

X

X

P

P

P

I

I

II

II

IV

IV

III

III

Hint

I : Pressurizing phase

II : Vapor discharge phase

III : Depressurizing phase

IV : Liquid intake phase

O : Open

X : Close

Δ

COPo ¼

Total cooling energy obtained at vapor discharge phase Total heat input at vapor discharge phase ¼ Qe

Qg

¼ Qe

Qc Qe

ð2Þ The cooling capacity, Qe, and total heat output from the con-denser, Qc, are determined by an energy balance using the water flow rate and water temperature difference between the inlet and outlet.

Qe¼MeCpðTex TinÞe ð3Þ

Qc¼McCpðTex TinÞc ð4Þ

COPtis another COP taking into account the extra heat needed for liquid pumping process in the MFG. The total system COP, COPt, is defined as:

COPt ¼

Total cooling energy obtained at vapor discharge phase Total heat input per cycle

¼ Qe

Qhþ Qg

¼ Qe

Qhþ Qc Qe

ð5Þ The main objective of this experiment was to study the contin-uous full-cycle operation of the ECS/MFG. The ECS/MFG was tested by R141b and ejector area ratio of 7.73 at an ambient temperature around 25 °C. A preliminary test for adjusting a suitable amount of filling refrigerant was done first. The experimental result is shown inFig. 6. Each temperature line was converted from pressure mea-surement using R141b thermodynamic chart. The ECS/MFG can be manipulated to synchronize between the two MFGs. While MFG A

was operating at the depressurizing phase, liquid intake phase, and pressurizing phase, MFG B was operating at the vapor discharge phase. The total time period of depressurizing, liquid intake, and pressurizing phase is less than the vapor discharge time. The experimental results show that the ECS/MFG can produce continu-ous cooling effect. The generator temperature, condenser tempera-ture, and evaporator temperature remained almost constant. The

0 0.2 0.4 0.6 0.8 1 C ooling c a pacity ( k W) 1616 1716 1916 2016 2116 Time (sec) 0 0.1 0.2 0.3 0.4 0.5 COP o 0 20 40 60 80 100 T e m perature ( oC) Evaporator temperature MFG_B temperature MFG_A temperature Generator temperature Condenser temperature 1816 2216 2316

Fig. 6. Continuous full-cycle operation of ECS/MFG using R141b and ejector area ratio with 7.73. 10 15 20 5 0 25 Evaporator temperature (o_C) 0 0. 1 0. 2 0. 3 0.4 COP 0 0.4 0.8 1.2 1.6 2 C ooling c a p a c ity ( k W ) Tg = 90 o_C R141b and Ar =7.73 COPo COPt Qe

Fig. 7. COP and cooling capacity of ECS/MFG using R141b and ejector area ratio with 7.73. 0 0.2 0.4 0.6 0.8 1 C o oli n g c a pac it y ( k W ) 1730 1830 1930 2030 2130 2230 2330 Time (sec) 0 0.1 0.2 0.3 0.4 0.5 COP o 0 20 40 60 80 100 T e m p erature ( oC) Evaporator temperature MFG_A temperature MFG_B temperature Generator temperature Condenser temperature

Fig. 8. Continuous full-cycle operation of ECS/MFG using R365mfc and ejector area ratio with 7.73.

average COPois 0.225 and cooling capacity is 0.75 kW at average generator temperature 89.1 °C, condenser temperature 37.0 °C, and evaporator temperature 8.5 °C.

A variation of the COPt and cooling capacity with evaporator temperature at generator temperature around 90 °C are shown in

Fig. 7. The COPochanges from 0.140 to 0.392, COPtchanges from 0.118 to 0.329, and the cooling capacity changes from 0.46 kW to 1.27 kW, when the evaporator temperatures are varied between 0.3 and 20.4 °C. Both COP and cooling capacity increase almost lin-early with the evaporator temperature.

3.2. Continuous full-cycle operation of ECS/MFG using R365mfc The ejector of the ECS/MFG system uses the same ejector with area ratio (Ar= 7.73) to run with the R365mfc to study the

feasibil-ity of continuous operation and system performance. The experi-mental result is shown inFig. 8. Similarly, each temperature line was converted from pressure measurement.Fig. 8indicates that the system can continuously operate in full-cycle but with poor performance. The average COPo is 0.074 and cooling capacity is 0.23 kW at generator temperature 90.8 °C, condenser temperature 39.6 °C, and evaporator temperature 7.6 °C. Variation of COPo, COPt, and cooling capacity with evaporator temperature at generator temperature around 90 °C are shown inFig. 9. The trends in COP and cooling capacity variation with evaporator temperature are similar to those of Fig. 7. However, the COPo, COPt, and cooling capacity are much lower than that of the experiment using R141b (Fig. 7). The ejector design needs to be optimized for the R365mfc. 12 8 4 16 20 24 Evaporator temperature (o_C) 0 0.1 0.2 0.3 0.4 COP 0 0.4 0.8 1.2 1.6 2 C ooling c a p a c ity ( k W ) Tg = 90 o_C R365mfc and Ar =7.73 COPo COPt Qe

Fig. 9. COP and cooling capacity of ECS/MFG using R365mfc and ejector area ratio with 7.73. 30 20 10 0 Evaporator temperature (o_C) 0 0.2 0.4 0.6 0.8 COP o Tg = 90 o_C R141b and Ar = 7.73 R365mfc and Ar = 7.73 R365mfc and Ar = 9.10 R365mfc and Ar =11.03

Fig. 10. COPofor different ejector designs.

30 20 10 Evaporator temperature (o_C) 0 0.2 0.4 0.6 0.8 COP t Tg = 90 o_C R141b and Ar = 7.73 R365mfc and Ar = 7.73 R365mfc and Ar = 9.10 R365mfc and Ar =11.03 0

Fig. 11. COPtfor different ejector designs.

Evaporator temperature (o_C) 0 0 10 20 30 0.4 0.8 1.2 1.6 2 Cooling capacity (kW) Tg = 90 o_C R141b and Ar = 7.73 R365mfc and Ar = 7.73 R365mfc and Ar = 9.10 R365mfc and Ar =11.03

The ECS/MFG used ejector area ratio of 9.10 and 11.03 for replacing the original ejector (Ar= 7.73). Figs. 10–12 show the COPo, COPt, and cooling capacity curves for different operation con-ditions at the generator temperature 90 °C, respectively. For an ejector with ejector area ratio of 9.10 to run with R365mfc, the system performance is improved significantly. At generator tem-perature 90 °C, COPovaries from 0.182 to 0.371, COPtvaries from 0.137 to 0.298, and cooling capacity varies from 0.56 kW to 1.20 kW for evaporator temperatures varied between 6.7 and 21.3 °C. As can be seen from the ejector area ratio of 7.73 for R141b and ejector area ratio of 9.10 for R365mfc, COPo, COPtand cooling capacity are nearly identical with each other at the same operating conditions. This result has shown that R365mfc can re-place R141b at no payoff of system performance, as long as the ejector design is optimized.

For an ejector with ejector area ratio of 11.03 to run with R365mfc, COPovaries from 0.137 to 0.608, COPtvaries from 0.102 to 0.446, and cooling capacity varies from 0.42 kW to 1.71 kW, for evaporator temperatures varied between 7.6 and 25.7 °C at generator temperature 90 °C.

4. Discussions and conclusion

The ejector cooling system (ECS) is suitable for solar cooling application due to its simple design and low cost. In the present study, the ejector cooling system using a multi-function generator (ECS/MFG) as a thermal pumping was constructed and tested. Some important results are obtained as follows:

(1) The experimental result has shown that the ECS/MFG can operate continuously at full cycle by a switching control of the two MFGs. This system can be very reliable since there is no circulation pump.

(2) The ECS/MFG operating at full-cycle and using R141b as the refrigerant can achieve a COPoof 0.225 and cooling capacity of 0.75 kW at generator temperature 90 °C, condenser tem-perature 37 °C and evaporator temtem-perature 8.5 °C. The experimental results are similar to the half-cycle of Huang et al.[19]under the same operating conditions.

(3) The present study also redesigned the ejector for working fluid R365mfc in order to replace R141b which was phased out. We have shown experimentally that R365mfc can replace R141b at no payoff of system performance as long as the ejector design is optimized.

(4) In the solar-powered ejector air conditioner [21–26], the ejector cooling cycle and vapor compression cycle would be combined together as shown in Fig. 13. The common component of the two cycles was the intercooler which was a heat exchanger. In this case, the ejector bottom cycle needed to operate at higher evaporator temperatures. Soko-love et al.[21–23]had shown that the evaporator tempera-ture was about 31 °C. The ECS/MFG which used R365mfc as a working fluid with ejector area ratio of 11.03 can be oper-ated at evaporator temperature 25.7 °C with COPo up to 0.608 and COPtup to 0.446. It is more suitable for solar-pow-ered ejector air conditioner.

Acknowledgement

The present study was supported by Energy Bureau, Ministry of Economic Affairs, Taiwan.
