國 立 交 通 大 學
統 計 學 研 究 所
碩 士 論 文
考量半導體製程能力限制下
之晶圓圖隨機性辨識法及應用
Automatic Detection of Patterned Wafer Sort Maps
with Process Baseline
研 究 生：莊銘弘
指導教授：洪志真 博士
凃凱文 博士
考量半導體製程能力限制下
之晶圓圖隨機性辨識法及應用
Automatic Detection of Patterned Wafer Sort Maps
with Process Baseline
研 究 生： 莊銘弘
Student：
Ming-Hong Chuang
指導教授： 洪志真 博士
Advisor：
Dr. Jyh-Jen Horng Shiau
凃凱文 博士
Dr. Kai-Wen Tu
國 立 交 通 大 學
統 計 學 研 究 所
碩 士 論 文
A Thesis
Submitted to Institute of Statistics
College of Science
National Chiao Tung University
In Partial Fulfillment of the Requirements
for the Degree of Master
in
Statistics
June 2010
Hsinchu, Taiwan
i
考量半導體製程能力限制下
之晶圓圖隨機性辨識法及應用
學生：莊銘弘 指導教授：洪志真 博士
凃凱文
博士
國立交通大學統計學研究所碩士班
摘
要
半導體產業是一種高投資產業，每間公司在製程上所投資的成本都很高。由於半導體產業 製程相當複雜，因此，對每間公司而言，如何使製程穩定與良率提升便是一個很重要的目標。 晶圓圖是半導體產業中偵測製程異常的重要參考依據。當非隨機性的異常晶圓圖發生時， 常代表製造過程發生異常。藉由這些異常晶圓圖的圖形，也可幫助工程師找出可能發生的原因， 例如機台發生問題或哪個製程步驟有異常等。對於分辨隨機與非隨機晶圓圖的議題已有很多相 關研究，分別提出一些可以取代人工目視判斷方式的方法，以減少由於人為主觀的因素所導致 的圖形判斷結果不一致。 然而在半導體廠製造技術水準與機台能力或產品特性等限制下，常導致晶圓圖上某些區域 容易產生故障品，此種原因所形成的異常晶圓圖形並非是特殊的製程異常所引起，而是基於半 導體廠製造技術水準與機台能力或產品特性的根本限制。此種「異常」和真正有歸屬原因的「異 常」，一般電腦自動辨識方法是分不出來的。在本篇論文中，在分辨晶圓圖形是否隨機，我們針 對此種製程能力的限制提出一個修正方法，期能正確判定真正的晶圓圖異常。此方法將可協助 工程師快速掌握製程異常的發生並加以排除，使製程穩定並提升良率。
Automatic Detection of Patterned Wafer Sort Maps
with Process Baseline
Student: Ming-Hong Chuang
Advisor: Dr. Jyh-Jen Horng Shiau
Dr. Kei-Wen Tu
Institute of Statistics
National Chiao Tung University
Abstract
The semiconductor industry is a very competitive and high-investment industry. The manufacturing process is one of the areas that are heavily invested. Semicon-ductor manufacturing are so complex that improving the process stability and yield is essential for each company to stay competitive.
The wafer sort map (WSM) is a useful tool for detecting abnormal processes. Non-random patterns on a WSM usually provides clues about process problems. With particular patterns, WSMs can help engineers to identify possible causes, such as problems in equipments or process steps. Some automatic methods were proposed to distinguish between random and non-random WSMs in the literature, attempting to replace the labor-intensive human recognition operations for cost saving as well as to reduce the inconsistency due to subjective human judgements. In practice, however, almost all WSMs exhibit some regions of inherent failures, which generally are due to process limitations caused by, say, layouts, equipments, process technologies, etc. This kind of failures are inevitable at the present technol-ogy level; thus, in the view of statistical process control, they should be considered as caused by common causes instead of process problems caused by special causes. Thus, in fab, such failures are often accepted and referred to as the “baseline” of the process. Unfortunately, without accounting for, the baseline, most of the existing automatic methods will classify these baseline patterns as non-random patterns. In
this thesis, we propose a new approach to detecting WSMs with “genuine” non-random WSM by taking the baseline into account. Three effective schemes are developed and studied. Effective detection of patterned WSMs can help engineers to trace process failures of particular patterns back to their root causes and then improve the process stability and yield by eliminating these causes.
誌 謝
兩年的研究生生涯隨著這篇論文的結束即將告一段落，在這兩年
裡，讓我成長了許多，獲得很多的經驗等等。而在這段日子裡，我要
感謝我的指導教授洪志真教授與凃凱文學長。在凃凱文學長的指導
下，讓我清楚知道統計應用的價值，也了解學術與實務上的差異，讓
我在面對事情時多了一份不一樣思維。此外，也感謝洪志真老師的幫
忙，在與老師討論的過程中，讓我學習到了做研究應有的態度與細
心。再來要感謝交大的每一位老師，在求學過程中給予我很多的幫
助，此外，也要特別感謝所上的郭小姐，除了常聽我們發牢騷外，還
常常給予了我們許多的幫助，你就像是我們統研所的保母，真的很謝
謝你。除此之外，還要感謝跟我一起度過這兩年生活的統研所同學
們，能和樂的相處做學問，晚上的宵夜聊天時間，共同奮鬥與生活，
讓我每一天都可以過得很開心。最後要感謝我的家人與女友，你們真
的辛苦了，也因為你們的支持讓我能度過這壓力大的碩二生活，也能
讓我專心的在學業上發展，謝謝你們。有了大家的支持，在即將踏出
社 會 的 我 ， 一 定 會 努 力 的 ， 絕 不 會 辜 負 大 家 對 我 的 期 望 。
莊銘弘 瑾 誌于
國立交通大學統計學研究所
中華民國九十九年六月
Contents
1 Introduction 1
1.1 Background . . . 1
1.2 Motivation . . . 4
1.3 Overview . . . 5
2 Introduction of Semiconductor Process and Packaging Technologies 7 2.1 Front-End Process Steps . . . 7
2.2 Back-End Process . . . 9
2.2.1 Wafer Sort . . . 10
2.2.2 Assembly . . . 10
2.2.3 Final Test . . . 11
2.3 Advanced Packaging Technologies — System-In-Packaging . . . 12
2.4 Wafer Sort Map Pattern . . . 13
3 Literature Review 18 3.1 Related Studies . . . 18
3.2 Spatial Randomness Tests . . . 19
3.2.1 Log Odds Ratio Test . . . 20
3.2.2 HNF Test . . . 21
3.2.3 HNF Method Under Cluster . . . 24
3.3 Mode Estimation Via Kernel Density Estimation . . . 26
4 Proposed Schemes 27 4.1 Data Encoding . . . 27
4.2 Proposed Method . . . 27
4.2.1 Mode Odds Ratio Method . . . 29
4.2.2 Mode HNF Method . . . 30
4.2.3 Empirical HNF Method . . . 31
5 Simulation Studies 34 5.1 Simulation Settings . . . 34
5.2 Generating Patterned Wafer Sort Maps . . . 35
5.3.1 False-alarm Rate . . . 37
5.3.2 Detecting Power vs. Yield . . . 38
5.3.3 Detecting Power vs. Patterned Area . . . 39
6 Conclusion 42
References 44
List of Tables
1 An example for wafer creation. . . 35
2 Counts of false alarm’s of the two existing methods and three proposed
methods among 150 random WSMs under various yield levels. . . 48
3 Counts of detection among 150 WSMs with the linear scratch pattern under
various yield. . . 50
4 Counts of detection among 150 WSMs with the ring pattern under various
yield. . . 52
5 Counts of detection among 150 WSMs with the bottom pattern under
various yield. . . 54
6 Counts of detection among 150 WSMs with the moon pattern under various
yield. . . 56
7 Counts of detection among 150 WSMs with the linear scratch pattern under
various patterned areas. . . 58
8 Counts of detection among 150 WSMs with the ring pattern under various
patterned areas. . . 60
9 Counts of detection among 150 WSMs with the bottom pattern under
various defect areas. . . 62
10 Counts of detection among 150 WSMs with the moon pattern under various
patterned areas. . . 64
11 Counts of detection among 150 WSMs with the linear scratch pattern under
various patterned areas. . . 66
12 Counts of detection among 150 WSMs with the ring pattern under various
patterned areas. . . 68
13 Counts of detection among 150 WSMs with the bottom pattern under
various patterned areas. . . 70
14 Counts of detection among 150 WSMs with the moon pattern under various
List of Figures
1 System predicted yield as a function of the number of dies assembled for
various die yields. . . 2
2 The left panel is a WSM with the code and the right panel is the corre-sponding visual figure of bad dies. . . 3
3 Some random and patterned wafer sort maps with the baseline limitation. . 5
4 Flow chart for semiconductor manufacturing. . . 7
5 Flow chart for generic IC process sequence. . . 8
6 Mark the bad dies on the wafer after wafer sort. . . 10
7 IC assembly process sequence. . . 10
8 Final test process sequence. . . 11
9 Scope of System-in-Packaging. . . 12
10 The graph of SiP structure viewed by a scanning electron microscope. . . . 13
11 Random defects of various defect level. . . 14
12 Examples of systematic defects. . . 14
13 Random defects plus systematic defects to form a mixed defects. . . 15
14 Bottom pattern . . . 15
15 Ring pattern . . . 16
16 Linear scratch pattern . . . 16
17 Crescent moon pattern . . . 17
18 The king-move neighborhood. . . 20
19 An example to depict the calculation of the four joint-count statistics. . . . 21
20 An example to depict the calculation of the pair T statistics. . . 22
21 Data encoding. . . 27
22 Generating a sequence of pseudo-inside WSMs from a WSM. . . 29
23 Generating a sequence of pseudo-outside WSMs from a WSM. . . 29
24 Mode estimation of Zj values . . . 30
25 Mode estimation of Dj values . . . 31
26 The flow chart of the proposed schemes. . . 33
27 Simulation parameters for wafer. . . 34
28 Illustration for generating a linear scratch pattern. . . 35
30 4 different patterns with a central-disc baseline region. . . 36
31 False-alarm rate of the two existing method and three proposed methods
for various yield level. . . 37
32 Detecting power for various patterns under a fixed patterned area size. . . 38
33 Detecting power for various patterns under middle yield level. . . 40
1
Introduction
1.1
Background
The semiconductor industry has emerged as one of the most important industries in many countries such as the USA, Germany, South Korea, Japan, and Taiwan. Semiconductor devices are absolutely essential for almost all electronic products and systems in the sense that most of the electronic products and systems cannot be produced or operated without them. Their influences over human society are enormous. In recent years, the mainstream evolution of the electronic products, such as computers, cell phones, digital cameras/camcorders, and portable audio/video players, has continually striving people toward designing/manufacturing products to be faster in operation, smaller in size, lighter in weight, and of more value-added functionalities. Therefore, how to cope these desirable features has become major challenges in ensuing competitiveness in the semiconductor industry. Needless to say, advanced semiconductor packaging technologies play a very important role in such efforts.
One major goal in advanced semiconductor packaging technologies is to increase the density of devices in a fixed packaging size. To achieve this, the multi-chip module (MCM) was developed and a widely application of the MCM is system-in-package (SiP), which consists of multiple dies stacked vertically and connected within package. Each of these dies, such as a specialized processor, DRAM, or FLASH memory, usually has one sin-gle functionality. Dies are then combined with passive components to form a system or subsystem. Various dies can be manufactured separately in different semiconductor man-ufacturing companies, and then assembled together. However, the cost, as well as the quality and production yield, highly depends on the cost and the quality of the individual dies. Illustrating this with a simplified case that ignores assembly defects and different yield levels of parts in an assembly, Figure 1 shows that the predicted yield of an assembly decreases exponentially as a function of the number of devices used. A SiP consists of various types of dies packaged together in an IC. Any of these dies failed will cause the system not working properly. So, to drive up the yield of a SiP is more difficult than a traditional single-chip IC.
In the final product, if one die fails, the whole module is typically useless or so reduced in performance that it cannot be sold for its intended purpose or at a price that can cover
the cost. Thus, there is no doubt that the high quality of dies is playing an important role for an MCM in the aspect of reducing the cost and enhancing the quality/yield. This leads to the demands for high-quality dies, which are called “known good dies (KGD)” in the die market. A KGD is a bare die (i.e., without package) with high quality and reliability that can assure the functionality in the integrated circuit (IC) level. Because of that, KGD has become an imperative for component manufacturers who provide various types of dies for the multi-chip module business.
Dies
Figure 1: System predicted yield as a function of the number of dies assembled for various die yields.
However, the semiconductor manufacturing process is more complicate than those of traditional manufacturing industries. It takes about 30–60 days to complete the process of making bare silicon wafers into integrated circuits, such as microprocessors or memory chips. In general, several wafers are processed simultaneously as a “lot”, typically of 25 wafers, and the size of each wafer ranges from 3 to 12 inches in diameter. Each wafer would contain thousands of dies depending on the size of the dies being produced.
After wafer fabrication, all dies on a wafer must go through a process called the wafer sort (WS). The purpose of the wafer sort is to examine the electrical functions of each die and to prevent from packaging bad dies into a multi-chip package. The results of the wafer sort give each die a binary code that denotes it as either a good die (0) or bad
die (1). These wafer sort data then are used to generate the wafer sort map (WSM). A WSM displays the locations of bad dies on the wafer. Figure 2 presents an example of WSMs. The white squares and black squares on the map denote the good dies and bad dies, respectively.
Figure 2: The left panel is a WSM with the code and the right panel is the corresponding visual figure of bad dies.
Since the occurrences of any quality excursions can induce WS failures, WSM analysis can help determine the possible causes of failures and help devise solutions to prevent such failures from reoccuring. For example, uneven temperatures or chemical aging often lead to spatial clusters on the WSM. Clustering also can be the result of crystalline nonuniformity, photo-mask misalignment, or particles caused by mechanical vibration. Improper material shipping and handling also can leave scratch lines on a WSM (see, for example, Cunningham and McKinnon [1], Hansen and Tyregod [2], Hansen et al. [3], and Taam and Hamada [4]).
Because WSMs contain important information that might guides quality engineers to trace back to the source of process failures, WSMs has been considered as one of the most important analysis tools in the semiconductor industry.
On the other hand, more important issues for KGD vendors to consider are (i) how to provide quality assurance to their customers and (ii) what sale strategies to take to make more profits. One possible solutions for that is to examine WSMs. If a WSM is of
some patterns, it implies process problems exist. Furthermore, the general market has a common view that the good dies on a wafer with no patterns have better quality than the good dies on a wafer with patterns in the semiconductor manufacturing industry. To determine whether a wafer is of some patterns or not, spatial randomness tests are a useful tool. Some tests are available in the literature, see, for example, Taam and Hamada [4] and Hansen et al. [3].
Ideally, a completely random mechanism for dies can be defined as “bad dies on the wafer are randomly distributed under the spatial homogeneous Bernoulli process (SHBP).” This means the probability of each die being bad is the same. In practice, however, almost all WSMs exhibit some regions of inherent failures, which generally are due to process limitations caused by, say, layouts, equipments, process technologies, etc. These types of failures are inevitable at the present technology level; thus, in the view of statistical process control, they should be considered as caused by common causes instead of process problems caused by special causes. Thus, in fab, they are often accepted and referred to as the “baseline” of the process. Simply speaking, “common causes” induce usual, historical, and quantifiable variations in a system, whereas “special causes” lead to unusual, not previously observed, and non-quantifiable variations. Figure 3 presents some WSM examples: the top panel shows four “random” wafer sort maps with a baseline of a central disc pattern and the bottom panel exhibits four WSMs with patterns such as linear scratch, ring, bottom, and crescent moon patterns in addition to a central disc baseline.
However, the currently available spatial randomness tests can not distinguish between the wafer patterns induced by common causes or special causes. Because of this reason, semiconductor companies usually hire engineers to classify these WSMs visually based on their own experiences. This approach is subjective as well as time-consuming. It would be desirable to develop an automatic detecting procedure for classifying the wafer patterns induced by common causes or special causes and this is the main objective of this study.
1.2
Motivation
As the technology evolves and advances, KGDs start playing an important role in ad-vanced packaging technologies such as SiP. Because the yield of SiP devices highly de-pends on the internal dies, KGDs are widely used to obtain higher yield of SiP devices.
(a) Random wafer sort maps with a baseline of a central disc.
(b) Patterned wafer sort maps with a baseline of a central disc.
Figure 3: Some random and patterned wafer sort maps with the baseline limitation. Furthermore, for KGD suppliers, one of the quality assurance is from inspecting WSMs. In general, KGDs on WSMs with common-cause patterns are better than those on WSMs with special-cause patterns. So, KGD suppliers do classify wafers into random (i.e., better grade) wafers or patterned (i.e., lower grade) wafers after wafers pass through the wafer sort.
However, to classify wafers, many companies still rely on the visual inspection of experienced engineers. The manual sorting is not only time-consuming but also full of inconsistency, restricted by the capability of human recognition. By providing a ran-domness test that takes the baseline of the process into account, this study will help fab engineers to automatically determine whether a WSM is random or not. For simplicity, in this paper, we assume the baseline regions are pre-determined by engineers based on their experiences.
1.3
Overview
The remainder of this thesis is organized as follows. In Section 2, we give a brief overview on the semiconductor manufacturing process and advance packaging technologies. More-over, some WSM patterns that often occur in the process with their probable causes
are reviewed. In Section 3, we give a literature review including some related studies in semiconductor manufacturing, spatial randomness tests, and a tool we use for mode estimation. In Section 4, we present the proposed schemes, which extend three existing spatial randomness tests to cope with baseline regions. Our proposed schemes can easily adapt to any kind of baselines set by engineers. In Section 5, we evaluate and compare the three proposed schemes via simulation studies. Finally, we conclude the thesis in Section 6.
2
Introduction of Semiconductor Process and
Pack-aging Technologies
The processes involved in semiconductor manufacturing have been grouped by many re-searchers into four stages, which are termed wafer fabrication, wafer sorting, device assem-bly, and final testing. Wafer fabrication is an extremely sophisticated and complex process that manufactures silicon dies. Assembly is a highly precise and automated process that packages silicon dies for protection and providing users a practical way of handling. For detailed descriptions of semiconductor manufacturing processes, see, for example, Uzsoy et al. [5] and Knutson et al. [6]. The following descriptions are taken from May and Spanos [7].
The four stages of semiconductor manufacturing system are carried out separately in different work centers. These four stages are further grouped into two categories: front-end manufacturing operations consist of wafer fabrication and back-front-end manufacturing operations include wafer sorting, device assembly, and final testing (see Figure 4). We will discuss these two categories in the following subsections.
Wafer
Fabrication
Wafer
Sort
Assembly
Final Test
Figure 4: Flow chart for semiconductor manufacturing.
2.1
Front-End Process Steps
Semiconductor manufacturing consists of a series of sequential process steps including crystal preparing, wafer preparation, lithograph, etching, ion implantation, metallization, and cleaning to produce ICs. Figure 5 illustrates the interrelationship between the major process steps in IC fabrication. The main steps are summarized as follows.
• Crystal Preparing
Crystal Preparing Wafer Preparation and Input 1. Oxidation 2. Lithograph 3. Etching 4. Ion Implantation 5. Metallization 6. Cleaning
Wafer Acceptance Test
Figure 5: Flow chart for generic IC process sequence.
crystal of silicon into a solid cylindrical shape. The silicon is first purified and heated into a bath of molten liquid, into which a small crystal of silicon, called a seed, is dipped. As the seed is slowly withdrawn, the surface tension between the seed and the molten silicon causes some liquid to rise with the seed. The liquid solidifies around the seed to form a single crystal ingot.
• Wafer Preparation
The solid cylinder of silicon, typically 150-mm (6 in.), 200-mm (8 in.), and 300-mm (12 in.) in diameter, is then cut with a diamond saw blade to wafers about 0.5– 0.7 mm thick. Each wafer is cleaned, smoothed, and polished through a series of machines.
• Oxidation
Generally, the step in semiconductor device fabrication involves the oxidation of the
wafer surface in order to grow a thin layer of silicon dioxide (SiO2). This oxide is
used to provide insulating and passivation layers. • Lithograph
The lithography is the process for pattern definition by applying a thin uniform layer of viscous liquid (photo-resist) on the wafer surface. The photo-resist is hardened
by baking and then selectively removed by projecting light through a reticle that contains mask information.
• Etching
This step selectively removes unwanted material from the surface of the wafer. The pattern of the photo-resist is transferred to the wafer by means of etching agents. • Ion Implantation
Ion implantation is a material-engineering process, by which ions of a material can be implanted into another solid, thereby changing the physical properties of the solid. Ion implantation is used in semiconductor device fabrication and in metal finishing, as well as in various applications of materials science research.
• Metallization
Wafer metallization is the deposition of a thin film of conductive metal onto the wafer surface.
• Cleaning
A number of wafer cleaning techniques or steps are employed to remove the contam-inants from the wafer surface and to control chemically grown oxide on the wafer surface.
At the end of these process steps, several test sites located on the fixed locations of each wafer are selected to perform the wafer acceptance test (WAT) with 100-500 electrical test items sequentially. The objective of the WAT is to perform the device characteristic analysis.
2.2
Back-End Process
After the wafer fabrication is completed, the wafers go through the back-end process, which includes wafer sort, assembly, and final test. During the back-end process, the good dies are put through a series of processes to create the electrical connections necessary for device to function. The following is a brief description of the three back-end stages.
2.2.1 Wafer Sort
After wafer fabrication is completed, each finished wafer undergoes the wafer sort process. The wafer sort test with 50–100 test items is performed sequentially to each die. The
objective of WS is to perform the die functionality sorting. Then, the bad dies are
automatically marked with a black dot so they can be separated from the good dies after the wafer is cut (see Figure 6).
Figure 6: Mark the bad dies on the wafer after wafer sort.
2.2.2 Assembly
Assembly is the process after wafer sort that enables dies to be packaged for system use. Each good die which goes through the process is usually called an integrated circuit. The following are the main steps of the assembly process (see Figure 7).
Wafer Grinding
and Sawing
Die
Bonding
Wire
Bonding
Molding
Final Test
Appearance
Packing
Figure 7: IC assembly process sequence.
• Wafer Grinding and Sawing
Wafer Grinding and Sawing is the process to saw the wafer to dies.
• Die Bonding
Die Bonding is the process of attaching the die either to its package or to some substrate such as tape carrier for tape automated bonding. The die is first picked from a separated wafer or from a waffle tray, aligned to a target pad on the carrier or substrate, and then permanently attached, usually by means of a solder or epoxy bond.
• Wire Bonding
Wire Bonding is the process of providing electrical connections between the die and the external leads of the semiconductor device using very fine bonding wires. • Molding
Molding is the process of encapsulating the device in plastic material. Transfer molding is one of the most widely used molding processes in the semiconductor industry because of its capability to mold small parts with complex features.
2.2.3 Final Test
In this stage, final test is the final arbiter of process quality and yield at the completion of manufacturing. A description is in the following (see Figure 8).
Wafer Grinding
and Sawing
Die Bonding
Wire Bonding
Molding
Final Test
Appearance
Check
Packing
Figure 8: Final test process sequence.
• Final Test
During the packaging process, dies may be damaged or packaging may not be cor-rectly performed. Final test is a 100% test performed on each packaged IC prior to shipment to insure that any ICs improperly packaged are not shipped. The purpose of final testing is to ensure that the product performs to the specifications it was designed for.
• Appearance Check
Appearance check is to examine the surface for defects. • Packing
Packing is to stamp QC label and seal the product in vacuum bags.
2.3
Advanced Packaging Technologies — System-In-Packaging
As the semiconductor technology advances, the process technology improves from .35um to 90nm and further to 45nm. Thus, in recent year, the electronics industry has experi-enced a great enhancement in development of new materials and processes to support the demand for “smaller, lighter, faster, and better” products. At the same time, it is seen that packaging technologies are also shifted toward achieving these requirements through the use of high-density packaging. One of these high-density packaging, system-in-packaging, is an ideal solution in markets to support the demand. By stacking multiple silicon dies vertically inside the same package, the technology effectively increases the functionality and capacity of the electronic devices. (See Figures 9 and 10.)
SiP helps surpass the limits
of the conventional system-on-chip (SoC) designs.
CPU User Logic SiP Digital IP Analog IP Memory High-Density System (Smaller and Thinner)
Traditional System
SiP is an advanced technology to incorporate multiple components into a single package. You can mix a variety of components such as CPU, logic, analog and memory functions, reducing overall system size.
Market Needs for SiP
1. Reducing system board space 2. Reducing board mounted height
● The evolution of mobile electronic devices such as cell phones, digital cameras, digital camcorders and portable audio players is driving the demand for SiP solutions.
What is System-in-Pacakge (SiP)?
Figure 9: Scope of System-in-Packaging.
There are several reasons why the market demand seems to be growing strongly for SiP solutions. These include:
12
9-Layer MCP. (5 Die Stacked Die)
For space-constrained applications…
For height-constrained applications…
Toshiba’s SiP solution fully leverages its advanced die backgrinding technology to allow up to 9 die stack.
Low Loop Wire Bonding
Chip thickness: 60 µm
Ultra-Thin Stacked SiP
2-Layer Stacked SiP: Max. Thickness = 0.55 mm
High-Density Packaging Technology
(a) 9-layer 5 dies stacked (Front View)
12
9-Layer MCP. (5 Die Stacked Die)
For space-constrained applications…
For height-constrained applications…
Toshiba’s SiP solution fully leverages its advanced die backgrinding technology to allow up to 9 die stack.
Low Loop Wire Bonding
Chip thickness: 60 µm
Ultra-Thin Stacked SiP
2-Layer Stacked SiP: Max. Thickness = 0.55 mm
High-Density Packaging Technology
(b) 9-layer 5 dies stacked (Lateral View)
Figure 10: The graph of SiP structure viewed by a scanning electron microscope. 1. Size: The size of sub-system can be reduced by integrating multiple dies and other
components in a SiP.
2. Performance advantages: Power reduction by minimizing line lengths (capacitive loads) between dies in a SiP.
3. Lower System Cost: An optimized SiP solution usually results in an overall system cost reduction compared to discrete IC packages.
4. SiP solutions reduce the complexity of the motherboard by moving the routing complexity to the package substrate. This often results in a reduced layer count in the motherboard and simplifies the product design.
More advantages were discussed in Scanlan and Karim [8], Lin [9], Buck [10], and Aguirre [11].
2.4
Wafer Sort Map Pattern
As mentioned early, the wafer sort is a process that examines the functionalities of each die by specific test conditions. One can color each die black (fail) or white (pass) from the test results for a wafer, and the resulting map is called a “wafer sort map”. By incorporating various plotting features into these maps, spatial patterns for passing and failing dies become readily apparent. Since the occurrence of any quality inferiority can usually be attributed to some specific causes, WSM analysis can help determine the possible causes of process failures and help devise solutions to prevent the reoccurrence of these failures. Usually the failure patterns of WSM can be classified into three major categories as follows: (Kaempf [12])
1. Random patterns:
No spatial clustering and pattern exist, and the defective dies randomly distributed in the two-dimensional map. Figure 11 is an example. Random defects are usually caused by manufacturing environment factors. Even in a near sterile environment, particles cannot be removed completely. Nevertheless, reducing the level of random defects can improve the overall productivity of wafer fabrication.
Figure 11: Random defects of various defect level.
2. Systematic patterns:
As examples, Figure 12 shows some patterns of systematic defects. The positions of defective dies in the wafer show the spatial correlation. Therefore, one may be able to trace back to the assignable cause from the problematic process steps or mechanism by analyzing the spatial distribution of failed dies. Systematic defects usually give an analyst some clues to find problematic steps and ways to eliminate them.
Figure 12: Examples of systematic defects.
3. Mixed pattern:
systematic defects in one map. Figure 13 gives an example.
Figure 13: Random defects plus systematic defects to form a mixed defects.
The following are four patterns occurring most often and some potential causes asso-ciated with them. A baseline of a central disc is included as an example in the illustrative figures.
• Bottom
The bottom pattern (Figure 14) could be the result of uneven heating during a diffusion process or the probe card itself failed.
• Ring
The ring pattern (Figure 15) appears on the WSM as a result of non-uniformities created in the thin film deposition process or an uneven temperature distribution during the rapid thermal annealing process.
Figure 15: Ring pattern
• Linear Scratch
The linear scratch pattern (Figure 16) on the WSM could be a result of material shipping and handling during the manufacturing or testing.
Figure 16: Linear scratch pattern
• Crescent Moon
The crescent moon pattern (Figure 17) could be the result of defective wafer ma-terials or adverse processes. For example, a fab engineer who notices this pattern might decide to immediately look at the rapid thermal anneal (RTA) process.
3
Literature Review
In this section, we review some areas of research related to wafer maps, two spatial randomness tests for testing the spatial randomness of wafer maps, and the kernel density estimation that we use as a tool in our proposed schemes.
3.1
Related Studies
These areas in semiconductor manufacturing related to wafer maps are briefly described here, including decision systems, yield models, and pattern recognition.
1. Decision System
Decision system is namely the application of various kinds of knowledge systems to failure analysis. It integrates parameter analysis and engineering experiments to help engineers effectively find the assignable causes and make decisions.
Two early examples of knowledge systems used in semiconductor manufacturing are PIES (Pan and Tenenbaum [13]) and SMART (Mary [14]) that diagnose problems in semiconductor fabrication processes by analyzing parametric test data. Maly et al. [15] recommended using a hierarchical methodology for the interpretation of test data. Methods such as CART (Breiman et al. [16]) and decision tree (Venkat [17]) would be useful in developing a decision system.
2. Yield Models
Yield in many ways is the most important financial factor in producing ICs. This is because yield is inversely proportional to the total manufacturing cost. The higher the yield is, the lower is the cost.
A yield model that provides good estimates of manufacturing yield can help predict product cost, determine optimum equipment utilization, or be used as a metric for supporting decisions involving new technologies and the identification of problematic products or processes. Cunningham [18] provided a good historical review of yield models.
Yield prediction of semiconductor dies can be used to: • determine the cost of a new chip before fabrication,
• identify the cost of defect types for a particular chip or a range of chips, • estimate the number of wafer starts required,
• show which defect types accounted for the most yield loss,
• identify when a fabrication process is not performing as expected,
• determine the extent of parametric problems (in both design and process), • monitor the fabrication process.
3. Pattern Recognition
Since wafer maps contain important information that could be used to trace the process failures back to their root causes for quality engineers, how to recognize wafer patterns is an important issue.
Gleason et al. [19] employed an automated clustering algorithm using artificial intelligence. Chen and Liu [20] and Liu et al. [21] used neural networks for pattern recognition. Lee et al. [22] adopted a self-organized feature map for advanced process controls. Chao and Tong [23] used multi-class support vector machines with a novel defect cluster index for pattern recognition. The above methods need a large number of good training samples in order to successfully recognize defect patterns.
In the process of pattern recognition, performing a spatial randomness test is an important step to classify raw WSMs into two categories, patterned or random. If the spatial randomness test is too sensitive, the frequency of false alarms would be large. Conversely, if the spatial randomness test is not powerful enough, process failures may not be detected and opportunities of quality improvement are lost. In the following, we describe two existing spatial randomness tests.
3.2
Spatial Randomness Tests
In this subsection, we review two existing spatial randomness tests, respectively, pro-posed by Tamm and Hamada [4] and Hansen, Nair, and Friedman [3], for semiconductor manufacturing applications. Both methods use the joint-count statistics to measure the adjacencies between good and bad dies (Weszka et al. [24]). The basic idea is based on
comparing the number of good dies around a bad die and the number of bad dies are around a good die.
3.2.1 Log Odds Ratio Test
Given a WSM and its site map, let Yi = 0 and Yi = 1 denote the die at site i being good
or bad, respectively.
A neighboring relationship is formed when two dies are located in the neighborhood of each other. In general, the king-move neighborhood that consists of a central die and its eight surrounding neighbors, as depicted in Figure 18, is the most popular construction rule.
Figure 18: The king-move neighborhood.
In this study, we adopting the king-move neighborhood rule. Denote the set of all neighboring relationships of a wafer by H , that is, the notation (i, j) ∈ H implies that two dies i and j are neighbors. Let N denote the total number of dies per wafer. Then, the following four statistics can be computed:
NGG= X X i<jδij(1 − Yi)(1 − Yj), (3.2.1a) NGB = X X i<jδij(1 − Yi)Yj, (3.2.1b) NBG = X X i<jδijYi(1 − Yj), (3.2.1c) NBB = X X i<jδijYiYj, (3.2.1d) where δij = 1, (i, j) ∈ H, 0, otherwise.
Take Figure 19 as an illustrative example. If the ith die is a good die, then the
summand is 0 for NBG and NBB, 1 for NGG, and 3 for NGB, corresponding to the
king-move neighborhood rule and (3.2.1).
Figure 19: An example to depict the calculation of the four joint-count statistics.
To measure spatially associative effects on the WSM, Tamm and Hamada [4] proposed the following log odds ratio
ˆ
θ = log((NGG+ 0.5)(NBB+ 0.5)
(NGB + 0.5)(NBG+ 0.5)
), (3.2.2)
by employing the king-move neighborhood rule.
When the total number of dies on a wafer N is large, ˆθ is approximately normal
distributed with mean 0 and variance (Agresti [25])
σ2 = ( 1 NGG+ 0.5 + 1 NBG+ 0.5 + 1 NGB + 0.5 + 1 NBB + 0.5 ). (3.2.3)
Thus, when | ˆθ | is greater than the critical point determined by the above approximate
normal distribution, there is significant evidence to claim that the WSM is non-random; otherwise, claim that the WSM is random.
3.2.2 HNF Test
For convenience, the test developed by Hansen et al. [3] is referred to as the HNF test here after. In the test, two weighted “joint-count” statistics are computed, one counts the number of bad neighbors of bad dies and the other counts the number of good neighbors of good dies. To make this intuitive formulation mathematically precise, we introduce some notation.
Let N represent the collection of die locations on a given wafer and N denote the
a wafer and N1 = |N1|, the number of bad dies. Similarly, let N0 = N \ N1, the locations
of the good dies and N0 = |N0|. Hence, N = N1+ N0. Next, for i ∈ N , let IN1(i) be the
indicator function of the event that the die at site i is bad, and set IN0(i) = 1 − IN1(i).
Finally, we let pi = EIN1(i), the probability that the die at site i is bad, and set qi = 1−pi,
the probability that the same die is good.
In the absence of any non-random patterns, assume that bad dies are distributed
randomly across the wafer. More specifically, we assume that the variables IN1(i)’s are
independent and identically distributed as Bernoulli random variables with constant
prob-ability pi = p, i ∈ N . In other words, we have an SHBP over the die locations in N (Cliff
and Ord [26]).
After the wafer sort, the proportion of bad dies on a wafer, ˆp, can be computed.
Consider the statistic T = (TN0, TN1)
0 to test the null hypothesis that there is no
non-random pattern, where
TN0 = N −1X i∈N X j∈N wi(j)IN0(i)IN0(j), (3.2.4) TN1 = N −1X i∈N X j∈N wi(j)IN1(i)IN1(j), (3.2.5)
and, for each i ∈ N , {wi(j), j ∈ N } denotes a set of nonnegative weights normalized so
that P j∈Nwi(j) = 1. 1/5 1/5 1/5 1/5 ● 0 1/5 0 0 1/5 1/5 1/5 1/5 ● 0 1/5 0 0 ii 1/8 1/8 1/8 1/8 ● 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8 ● 1/8 1/8 1/8 1/8
(a) an interior die
1/5 1/5 1/5 1/5 ● 0 1/5 0 0 1/5 1/5 1/5 1/5 ● 0 1/5 0 0 ii 1/8 1/8 1/8 1/8 ● 1/8 1/8 1/8 1/8 1/8 1/8 1/8 1/8 ● 1/8 1/8 1/8 1/8 (b) a boundary die
Figure 20: An example to depict the calculation of the pair T statistics.
for each neighboring site. In the examples, weights are equally distributed among all the neighbors for each die. Let
TN0(i) = N −1X j∈N wi(j)IN0(i)IN0(j) and TN1(i) = N −1X j∈N wi(j)IN1(i)IN1(j). Then TN0 = P i∈N TN0(i) and TN1 = P i∈N TN1(i).
For Figure 20(a), we have TN1(i) = 0 and TN0(i) = N
−1(1
8 · 1 · 1 +
1
8 · 1 · 1); and for
Figure 20(b), TN1(i) = 0 and TN0(i) = N
−1 · 1
5 · 1 · 1, corresponding to the king-move
neighborhood and the associated weights of neighbors.
The following are the exact first and second moments of the pair T statistic conditional
on ˆp = N1/N . Note that N is fixed, so being conditional on ˆp is equivalent to being
conditional on N0 or on N1. Thus, the exact first moments are
E (TN0|N0) = N0(N0 − 1) N (N − 1) (3.2.6) and E (TN1|N1) = N1(N1− 1) N (N − 1) , (3.2.7)
assuming that wj(j) = 0 for all j ∈ N (Cliff and Ord [26]). Next, the second moments of
the pair T are
E TN20|N0 = α1 N0 N + α2 N0(N0− 1) N (N − 1) + α3 N0(N0− 1)(N0 − 2) N (N − 1)(N − 2) + α4 N0(N0− 1)(N0− 2)(N0− 3) N (N − 1)(N − 2)(N − 3) (3.2.8) and E TN21|N1 = α1 N1 N + α2 N1(N1− 1) N (N − 1) + α3 N1(N1− 1)(N1 − 2) N (N − 1)(N − 2) + α4 N1(N1− 1)(N1− 2)(N1− 3) N (N − 1)(N − 2)(N − 3) , (3.2.9)
where α1+ α2+ α3+ α4 = 1 and α1 = 0 if wj(j) = 0 for all j ∈ N . Note the symmetry
αk = N−2 X i∈N X j∈N X i0∈N X j0∈N wi(j)wi0(j0)Ik(i, j, i0, j0), (3.2.10)
where Ik returns the value of 1 if there are only k different elements among its four
arguments and 0 otherwise. Roughly speaking, quantities αk’s are obtained by computing
the proportions of the terms in the expansion of the second moment that involve two, three, and four unique indicators, respectively, and hence must be computed separately
for every different die layout N . Finally, if wj(j) = 0 for all j ∈ N as one would usually
set, then the covariance between TN0 and TN1 can be computed by
E (TN0TN1|N0, N1) = α4
N1(N1− 1)N0(N0− 1)
N (N − 1)(N − 2)(N − 3). (3.2.11)
Assume that N1/N dose not go to 0 as N → ∞. Then, with the theory of U statistics
(Lee [27]), it can be shown that, the statistic T under null hypothesis has a bivariate
normal limiting distribution as N (and N1) tends to infinity (Hansen et al. [3]). This
implies T = TN0 TN1 N0, N1 ∼ BN (µ1, Σ1) as N → ∞, (3.2.12)
and the exact conditional expectation (µ1) and conditional variance and covariance matrix
(Σ1) can be obtained by (3.2.6) – (3.2.11). Thus, conditional on N0, N1, the test statistic
D = (T − µ1)0Σ1(T − µ1)
follows the chi-square distribution with degrees of freedom 2. Accordingly, the critical value of the test can be determined.
3.2.3 HNF Method Under Cluster
As mentioned in Section 1, the bad dies being distributed randomly across the wafer is the ideal situation for a wafer. Unfortunately, almost all wafer sort maps exhibit some regions of inherent failures in practice. Hansen et al. [3] also considered a clustered alternative hypothesis and derived the exact distribution of the T statistic conditional on a cluster
C and ˆp = N1/N .
To describe more precisely, let C0, C1 ⊂ N denote the set of good and bad die sites,
be the number of the good dies and bad dies in C, respectively. For any sets I, J ⊂ N , we define T (I, J ) = N−1X i∈N X j∈N wi(j)II(i)IJ(j), (3.2.13)
where II(i) = 1 if i ∈ I; 0 otherwise.
Then the exact mean of T conditional on the event that C0 contains all the good dies
in C can be computed by:
E (TN0|N0, N1, C0, C1) = T (C0, C0) + [T (C0, C c) + T (Cc, C 0)]NN − C0 − C0+ T (Cc, Cc)(N0− C0)(N0− C0− 1) (N − C)(N − C − 1) (3.2.14) and E (TN1|ˆp = N0, N1, C0, C1) = T (C1, C1) + [T (C1, C c) + T (Cc, C 1)]NN − C1− C1 +T (Cc, Cc)(N1− C1)(N1− C1− 1) (N − C)(N − C − 1) , (3.2.15)
where Cc= N \C, the complement of C.
The expressions for second moments are complicated and not presented here. These
expressions also depend on the αk’s defined in (3.2.10). Recall that αk’s vary with the
wafer layout. In addition, when there exists a baseline C, these αk’s depend not only on
the set C but also on C0 and C1.
The joint distribution of the pair T = (TN0, TN1) conditional on (N0, N1, C0, C1) is
approximately bivariate normal when N − C is large, that is
T = TN0 TN1 N0, N1, C0, C1 ∼ BN (µ2, Σ2) as N − C → ∞, (3.2.16)
where µ2 given in (3.2.14) and (3.2.15) and Σ2 can be found in Ooi et al. [28]. With
(3.2.16), the critical value of the randomness test can be determined.
However, the computation of the exact second moments are too extensive to carry out
in practice, we will propose an alternative method to compute µ2 and Σ2 by constructing
3.3
Mode Estimation Via Kernel Density Estimation
In this subsection, we give a brief description on kernel density estimation, a tool we use to estimate the mode of a distribution in proposed schemes.
Kernel density estimation has a long tradition of estimating the probability density function of a random variable in nonparametric way. With the kernel density estimate, the mode of the distribution can be estimated by the maximizer of the kernel density estimate. Parzen [29] gave consistency, asymptotic normality, and mean squared error evaluation of the kernel sample mode, and his results have been extended in several directions by Chernoff [30], Eddy [31], and Romano [32].
Given the random sample x1, x2, . . . , xn, which follow a continuous, univariate
proba-bility density function f , the kernel density estimator is
ˆ fh(x) = 1 nh n X i=1 K x − xi h , (3.3.1)
where K is some kernel function and h is a smoothing parameter called the bandwidth. The bandwidth controls the smoothness of the estimated curve (Silverman [33], Chen [34], Shi and Zhang [35], and Gasser and Muller [36]). Small values of h force the expected
value of the estimate ˆfh(x) to be close to the true value f (x), but the price to pay is the
high variability of the estimate, since it is based on comparatively few observations. On the other hand, variability can be decreased by increasing h. Quite often K is taken to be a standard Gaussian function with mean 0 and variance 1. That is,
K x − xi h = √1 2π e −(x − xi) 2 2h2 . (3.3.2)
Given the parameter h and kernel K, we take the maximizer of the estimated kernel
4
Proposed Schemes
4.1
Data Encoding
The WS data are three-dimensional data with the (x, y) position and the binary test result value for each die. Figure 21 illustrates how to transform WS data (left panel) to a one-dimensional binary sequence according to the ordering shown in the site map (right panel).
{1,1,1,1,1,1,1,1,1,1,1,1,1,0,1,1,1,1,0,...}
WS Data
Site Map
Figure 21: Data encoding.
4.2
Proposed Method
Loosely speaking, the baseline is a region treated by engineers as an accepted flaw in practice. When they judge a wafer to be random or patterned, they simply ignore whether the situation is inside the baseline. Therefore, to them, an automatic classification method should also ignore whether within the baseline. Also, baselines have various shapes and they will definitely change as the manufacturing process improves/changes over time. So desirable automatic pattern detection method should be able to adapt to any kind of baselines set by engineers.
Unfortunately, the odds ratio test and HNF test described in the previous section can-not distinguish between the baseline and the “genuine” non-random patterns. The HNF method under cluster dose take the baseline into account, but it is too computationally intensive to be feasible for practice use. To meet engineers’ need, we modify these three randomness tests with a simple approach that takes the baseline into account. The idea is fairly simple: masking the unwanted area, e.g., the baseline, with a randomly generated Bernoulli sequence to remove the unwanted patterns so that the existing methods are applicable.
Two types of pseudo wafers, called pseudo-inside and pseudo-outside WSMs, are con-sidered. For the WSM under test, a pseudo-inside WSM is generated by replacing the die data in the baseline with a set of generated variates that follows an SHBP with the probability of {Y = 0} to be the yield outside the baseline. If the dies outside the base-line indeed follow an SHBP, then the whole pseudo WSM also follows the same SHBP approximately. Then the first two randomness tests can be applied to the pseudo WSM. Similarly, a pseudo-outside WSM is generated by replacing the binary die data outside the baseline with a sequence of SHBP data. The procedure for generating a sequence of pseudo-inside (pseudo-outside) is as follows.
1. Given the baseline region, calculate youtside, the yield outside the baseline region.
2. Generate a Bernoulli sequence with the parameter 1 − youtside and the length is the
total number of dies inside (outside) the baseline region.
3. Replace the inside-baseline (outside-baseline) data with the Bernoulli sequence ac-cording to the site map.
4. Repeat steps 2–3 n times.
Figure 22 and 23 illustrate the generation of pseudo-inside and pseudo-outside WSMs, respectively. The left-hand-side of the arrow is the original WSM with a central-disc baseline and the right-hand-side are n pseudo WSMs obtained by the above procedure.
The purpose of generating n pseudo-inside WSMs is to find a “good” substitute for the original WSM. We could have simply generated just one pseudo WSM and apply the odds ratio or HNF test to it. But we are concerned about getting not-so-good substitute due to sampling. With n replicates, one could use the sample mean of n test statistics for
Generating Inside Repeat n times Generating Inside Repeat n times Generating Outside Repeat n times Generating Outside Repeat n times
Figure 22: Generating a sequence of pseudo-inside WSMs from a WSM.
Generating Inside Repeat n times Generating Inside Repeat n times Generating Outside Repeat n times Generating Outside Repeat n times
Figure 23: Generating a sequence of pseudo-outside WSMs from a WSM.
reducing the sampling error, or the sample median for robustness, or the sample mode for the high likelihood. Here we describe the sample mode approach because it is slightly complicated than using mean and median.
With this generating procedure, we now are ready to describe the proposed schemes.
4.2.1 Mode Odds Ratio Method
Note that, for the same original WSM, the approximate variance (3.2.3) of the test statistic ˆ
θ of a pseudo-inside WSM depends on the statistics obtained from the pseudo WSM, hence
each pseudo WSM has its own value of σ2. By normalizing ˆθ, we have
Z = ˆ θ σ approx. ∼ N (0, 1). (4.2.1)
To describe the proposed mode odds ratio method, we use the WSM shown in Figure 22 as an illustrative example. Generate 100 pseudo WSMs. For the jth pseudo WSM,
j = 1, 2, . . . , 100, obtain ˆθj then Zj. Applying the kernel density estimation method to
{Zj, j = 1, . . . , 100} to obtain the kernel density estimate and then its mode. The mode
represents the most probable Z value for the WSM under study when pretending that the baseline region is random. Figure 24 presents the kernel density estimate of the 100
Zj’s in this case. At the significance level α = 0.01, the mode estimate is Z∗ = 11.7558 >
z.005 = 2.576, hence we reject the null hypothesis of randomness, i.e., special patterns
other than the baseline exist for this WSM, which indeed is the case.
z*
z*
Figure 24: Mode estimation of Zj values
4.2.2 Mode HNF Method
Generate n pseudo-inside WSMs from the WSM to be tested as described earlier in subsection 2. For the jth pseudo-inside WSM data, j = 1, . . . , n, carry out the following statistic
Dj = (Tj− µj)
0
Σ−1j (Tj− µj), (4.2.2)
where µj and Σj can be obtained from (3.2.6)–(3.2.9). By the result given in Hansen et al.
[3], Dj follows χ2(2) asymptotically, the chi-square distribution with 2 degrees of freedom.
Apply the the kernel density estimation method to these Dj values and obtain the mode of
the kernel density estimate, denoted by D∗. Then we can judge whether there exist special
patterns by comparing the mode with the critical value χ2
α(2), the 100(1 − α)% percentile
of χ2(2). Take the same example as described in the last subsection as an example. The
same 100 pseudo-inside WSMs given a kernel density estimate and its mode D∗ = 147.02
critical value χ20.01(2) = 9.21034, we reject the null hypothesis of randomness, and claim that the original WSM exhibits special patterns other than the baseline.
D*
D*
Figure 25: Mode estimation of Dj values
4.2.3 Empirical HNF Method
The method described in Subsection 3.2 does take the baseline into account, but the computation is too intensive to be feasible for online testing. For example, it took almost 30 minutes on a regular PC to complete the randomness test for one single wafer. In this subsection, we propose an alternative method by estimating the mean and covariance matrix empirically with pseudo-outside WSMs.
For a given WSM, we first generate n pseudo-outside WSMs as described earlier. As
in Subsection 3.2, compute the statistic Tj for the jth pseudo WSM, j = 1, . . . , n, and
obtain a pseudo sample of size n. Compute the sample mean ¯T and sample covariance
matrix S of this sample. Consider the statistic
F = n(n − p)
(n2− 1)p(T − ¯T )
0
S−1(T − ¯T ), (4.2.3)
where T is the statistic of the original WSM and p = 2 is the dimension of T . Recall that
asymptotically. Therefore, if Tj’s are independent and identically distribution (i.i.d.), then
the test statistic F in (4.2.3) has an F distribution with degrees of freedom 2 and n − 2 asymptotically and the critical value would be its 100(1 − α)th percentile accordingly.
However, Tj’s are not independent because all the pseudo WSMs have the same
base-line. Fortunately, this loop hole can be mended with the following argument. Let C be
the set of dies in the baseline and Cc = N \C, the complement of C. We say a die is
in the boarder of C and Cc if it has a neighbor from the other set. Denote the boarder
by B. First note that, the contribution of all the dies in the boarder to TN0 and TN1,
P
i∈B
TN0(i) and
P
i∈B
TN1(i), can be neglected because |B|/|N | → 0 as N → ∞. Next,
without involving neighbors in Cc, we have P
i∈C\B
TN0(i) = c0 and
P
i∈C\B
TN1(i) = c1 for all
pseudo-outside WSMs, where c0and c1 are two constants. On the other hand, the statistic
P
i∈Cc\B
TN0(i) for each pseudo WSM are i.i.d. by their construction. The same argument
of Hansen et al. [3] would imply that P
i∈Cc\B TN0(i), P i∈Cc\B TN1(i) !0 follows a bivariate
normal asymptotically. Combining all these terms, (TN0, TN1)
0
also follows a bivariate
normal asymptotically. Thus we conclude that conditional on (N0, N1, C0, C1), statistic F
in (4.2.3) follows F distribution with degrees of freedom 2 and n − 2 asymptotically. For the same example as before, we generate 100 pseudo-outside WSMs to obtain 100
Tj’s. For these Tj’s, T = 0.4723 0.1350 , ¯T = 0.4519 0.1148 , and S = 2.16e − 05 −5.84e − 06 −5.84e − 06 5.54e − 06 .
Let α = 0.01. Then by (4.2.3), F = 380.1747 > F2,98(0.01) = 4.8285. Thus, the example
shows that the Empirical HNF test rejects the null hypothesis of being random and claim the WSM has some patterns other than the baseline.
Finally, we summarize these three proposed schemes in the following flow chart (Figure 26).
Encode Data
Determine Baseline
Calculate Yield Outside the Baseline
Generate Pseudo-Inside Wafers Generate Pseudo-Inside Wafers Generate Pseudo-Outside Wafers
Calculate Z-values by Log Odds Ratio
Calculate D-values
by HNF Estimate Parameter
Estimate Mode by Kernel Density Estimation
Decide Random/Patterned Calculate F-value by Emp. HNF Encode Data Determine Baseline Calculate Yield Outside the Baseline
Generate Pseudo-Inside Wafers Generate Pseudo-Inside Wafers Generate Pseudo-Outside Wafers
Calculate Z-values by Log Odds Ratio
Calculate D-values
by HNF Estimate Parameter
Estimate Mode by Kernel Density Estimation
Decide Random/Patterned
Calculate F-value by Emp. HNF
Input data
5
Simulation Studies
We first discuss how to create the platform of the WSM. In this part, the total number of dies on a wafer is determined by the simulation parameters. After the simulation parameters are set, we then focus on how to generate various patterns on a wafer. Finally, we evaluate the performances of the three proposed schemes in terms of the false alarm rate and detection power under various yield levels and patterns.
5.1
Simulation Settings
In our simulation, the number of rows and columns and total number of dies are deter-mined by the 5 spatial parameters. The 5 parameters are as follows and illustrated in Figure 27: k r k k k h l w
Figure 27: Simulation parameters for wafer.
• r denotes the radius of the wafer
• h denotes the interval between two dies
• k denotes the length of the retained wafer edge • l denotes the length of each die
• w denotes the width of each die
For example, the simulation parameters (r, h, k, l, w) = (8, 0.5, 0.8, 1.2, 1) would corre-spond to a wafer with 9 rows and 8 columns, and the total number of dies is 52. Figure 27 and Table 1 illustrate the details of the wafer layout under this setting.
Table 1: An example for wafer creation.
row ] of dies x-cordinate y-cordinate
start end 1 2 −0.85 0.85 6.0 2 6 −4.25 4.25 4.5 3 6 −4.25 4.25 3.0 4 8 −5.95 5.95 1.5 5 8 −5.95 5.95 0.0 6 8 −5.95 5.95 −1.5 7 6 −4.25 4.25 −3.0 8 6 −4.25 4.25 −4.5 9 2 −0.85 0.85 −6.0
5.2
Generating Patterned Wafer Sort Maps
After the wafer layout is set, we focus on how to generate patterned wafer sort maps. In this study, we pick four wafer patterns, the linear scratch, ring, bottom, and crescent moon. Here, we explain how to generate the linear scratch pattern as an illustrative example.
For the linear scratch pattern, the wafer is separated into two disjoint areas, the linear scratch (B) area and its complement (A), as illustrated in Figure 28. To generate a linear scratch pattern, simply generate a Bernoulli variate for each die with a “success” probability to be a bad die higher for dies in patterned area B than in A. That is, the yield in A is higher than in B.
B A
A
5.3
Comparisons
In this simulation, the wafer layout parameters are (r, h, k, l, w) = (8, 0.01, 0.15, 0.24, 0.18) and the total number of dies per wafer is 3913. Assume the baseline is the centered disc of radius 3.47 as shown in Figure 29. The area of the baseline is almost 20% of a wafer.
baseline
3.47
Figure 29: Baseline setting.
For patterned wafers with the baseline, Figure 30 illustrates four different patterns in our simulation studies. Divide a wafer into three areas, the baseline, the patterned area,
and the random area. Let the yield in the random area be yr, the yield in the baseline
be 0.8yr, and the yield in the patterned area be 0.6yr. Denote the proportion of the
patterned area is a wafer by b. Then the wafer yield is y = (0.96 − 0.4b)yr.
Figure 30: 4 different patterns with a central-disc baseline region.
In order to study and compare the performances of the proposed schemes under various conditions, we conduct the following three simulation studies.
The first simulation study compares the false-alarm rate of the three proposed methods and two existing methods with wafers of no special patterns. The second study compares the detecting power of the three methods under various yield level. The third study compares the detection power of the three methods under various sizes of the patterned area when the yield level is fixed. Two yield levels, including middle and high wafer
yield, are considered. For each case under study, we generate 150 WSMs and the level of significance is α = 0.01.
5.3.1 False-alarm Rate
We generate 150 random WSMs with the baseline for each yield level yr, for yr =
0.01(0.05)0.95. We apply the existing odds ratio test and HNF tests as well as our three methods to the generated WSMs. The false-alarm counts are listed in Table 2 and the corresponding false-alarm rates are plotted in Figure 31.
From Figure 31, the two existing methods that do not take the baseline into account lead to a higher false-alarm rate, especially when the yield y is high. A high false-alarm rate will make engineers lose confidence in the auto detection method. On the other hand, our proposed schemes take the baseline into account and the resulting false-alarm rates are controlled at an about right level.
0.0 0.2 0.4 0.6 0.8 1.0 0.0 0.2 0.4 0.6 0.8 1.0 Type 1 error α=0.01 Yield
False Alarm Rate
Odds HNF Mode Odds Mode HNF Empirical HNF
Figure 31: False-alarm rate of the two existing method and three proposed methods for various yield level.
5.3.2 Detecting Power vs. Yield
It is interesting to evaluate the performance in detecting various patterns. Because the size of the patterned area affects the performance, we fix the size at 20% of the wafer in this study.
Figure 32 and Tables 3–6, show the simulation results. It is observed that these methods have the same trend—the higher yield, the larger power. The detecting power of the mode odds ratio test is greater than the other two tests; and the mode HNF test seems performing slightly better than empirical HNF test. When the yield (y) is higher than 0.6, all three methods have 100% detecting power for all the patterns.
For the comparison of various patterns, it is observed that the linear scratch pattern is the hardest to detect. The bottom pattern is the easiest, followed by the crescent moon and edge ring pattern.
0.0 0.2 0.4 0.6 0.8 1.0 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Yield
Power
Mode Odds Mode HNF Empirical HNF
(a) Linear Scratch
0.0 0.2 0.4 0.6 0.8 1.0 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Yield Power Mode Odds Mode HNF Empirical HNF (b) Edge Ring 0.0 0.2 0.4 0.6 0.8 1.0 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Yield Power Mode Odds Mode HNF Empirical HNF (c) Bottom 0.0 0.2 0.4 0.6 0.8 1.0 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Yield Power Mode Odds Mode HNF Empirical HNF (d) Crescent Moon
5.3.3 Detecting Power vs. Patterned Area
In Subsection 5.3.2, we have seen that the yield level has a great impact on the detecting power for all three proposed methods, and the higher the yield is, the better is the detecting power. This is very intuitive because it is easier to spot unusual patterns when the yield is high. Conversely, for a wafer with a very low yield, the bad dies in the random area will mask the patter so that it would be hard to detect patterns, if they exist. We remark that detecting patterns has no practical meaning when the yield level is low, because it would be a time of emergency and engineers must stop the process to take necessary actions to find the root cause of the low yield.
Therefore, in studying how the proposed methods would react to the size of the
pat-terned area, we consider two yield levels, yr = 0.75 (middle) and 0.95 (high). In our
simulation study, for each pattern, we start with almost no pattern and then gradually increase the size of the patterned area to about 20% of the wafer. For 20 area size con-sidered in the simulation, the wafer yield is in the range of 0.7 ± 0.03 and 0.9 ± 0.03 for the middle and high yield levels, respectively.
For the middle and high yield level, Figure 33 and Figure 34 display the detecting power of the three methods over the size of the patterned area with panel (a) for linear scratch, (b) for edge ring, (c) for bottom, and (d) for crescent moon pattern, respectively. Table 7–14 show the simulation results.
From these figures, we observe
• Except for the edge ring pattern, the detecting power of all three methods increases as the area size increases. This is quite intuitive since the non-random pattern gets more apparent as the size gets larger.
• Except for the edge ring pattern, the mode odds ratio method performs the best and the two HNF methods perform very similar with the mode HNF method slightly better.
• In general, the bottom pattern is the easiest and the linear scratch pattern is the hardest to detect.
• The performances of the three methods behave quite differently from the other patterns. For this pattern, the mode odds ratio method performs the worst, but not
0 5 10 15 20 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Patterned Area (%)
Power
Mode Odds Mode HNF Empirical HNF
(a) Linear Scratch
0 5 10 15 20 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Patterned Area (%) Power Mode Odds Mode HNF Empirical HNF (b) Edge Ring 0 5 10 15 20 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Patterned Area (%) Power Mode Odds Mode HNF Empirical HNF (c) Bottom 0 5 10 15 20 0.0 0.2 0.4 0.6 0.8 1.0
The power curve under α=0.01
Patterned Area (%) Power Mode Odds Mode HNF Empirical HNF (d) Crescent Moon
Figure 33: Detecting power for various patterns under middle yield level.
too far from the empirical HNF method. The behavior of the mode HNF method is worth mentioning. The detecting power increases very rapidly at low area, which is somewhat against the general impression that a small patterned area would be harder to detect than a lower patterned area. This could be due to some kind of edge effect. The edge ring pattern generates more bad dies at the edge than other patterns. A bad die at the edge has fewer neighbors so that each of its neighbors
has a larger weight wi(j) than that of the interior dies. This may lead to a larger
statistic TN1 and hence higher power. This finding makes the mode HNF method a
