Guest Editorial: Networking Challenges in Cloud Computing Systems and Applications

IEEE JOURNAL ON SELECTED AREAS IN COMMUNICATIONS, VOL. 31, NO. 12, DECEMBER 2013 2593

Guest Editorial:

Networking Challenges in Cloud Computing

Systems and Applications

David S. L. Wei, Sarit Mukherjee, Kshirasagar Naik, Amiya Nayak, Yu-Chee Tseng, and Li-Chun Wang

C

LOUD computing is an innovative Internet-based

com-puting paradigm that offers users a scalable, elastic, and

cost-effective computing environment. On the other hand, this

promising computing paradigm also poses various challenges

to cloud service providers, and the associated research

is-sues have attracted numerous researchers. This research work

can be classified into research on computational aspects of

cloud computing and research on networking aspects of cloud

computing. While research on computational aspects of cloud

computing is actively being conducted, studies on networking

challenges in cloud computing have been lagging behind. In

the following we will explain the urgency for addressing the

research on networking aspects. The goal of this special issue

is to feature recent research in this area.

Network performance is the key to cloud computing

per-formance as cloud networks are the infrastructure for cloud

services. A cloud network connects servers and storage in

multiple locations to create a pool of resources, and contains

a set of routers and switches that transport traffic between

the servers and to the outside world. Due to the complexity

of interconnection networks, large number of users, user’s

mobility, and a large variety of application services, cloud

networks pose several challenges. The key challenges include

the data casting and routing problem, cost-effective data

center scalability, unpredictable traffic patterns and variable

demand, dynamic network resource allocation, workload and

IP mobility, to name a few. These challenges can be addressed

by, for example, traffic control, novel interconnection networks

with scale-out property, protocols for supporting live migration

of VMs, as well as using emerging technologies such as

network virtualization and novel network addressing schemes

to tackle service and VM migration. The papers that appear

in this special issue address these important issues in cloud

computing systems and applications.

Though research on cloud networking is still in its nascent

stage, this special issue still attracted 35 submissions of

high-D. S. L. Wei is with the Dept. of Computer and Information Sciences, Fordham University, Bronx, NY 10458, USA (e-mail: [email protected]). S. Mukherjee is with the Center for Networking Research, Alcatel-Lucent Bell Labs, Holmdel, NJ 07733, USA.

K. Naik is with the Dept. of Electrical and Computer Engineering, University of Waterloo, Ontario N2L 3G1, Canada.

A. Nayak, SITE, University of Ottawa, Ontario K1N 6N5, Canada. Y.-C. Tseng is with the Dept. of Computer Science, National Chiao-Tung University, Hsinchu 300, Taiwan, R.O.C.

L .-C. Wang is with the Dept. of Electrical Engineering, National Chiao-Tung University, Hsinchu 300, Taiwan, R.O.C.

A. Leon-Garcia is the J-SAC board representative for this issue of IEEE Journal on Selected Areas in Communications.

Digital Object Identifier 10.1109/JSAC.2013.131201

quality works from around the world. Due to limited slots,

only the following 11 papers were selected for publication

after a rigorous review process. These papers present results of

analysis, experimentation, simulation, and system

implementa-tion. They cover the topics of Network Virtualization and VM

Placement, Data Casting and Routing, Traffic Management,

Resource Management, Distributed Storage System, Big Data,

and Cloud Applications. We summarize these papers in the

order of the listed topics in what follows.

I. N

V

VM P

The first three papers are about network virtualization

or VM placement. In the paper “SR-IOV Based Network

Interrupt-Free Virtualization with Event Based Polling,” Guan,

Dong, Tian, and Li propose a network interrupt-free

virtual-ization mechanism to improve the network throughput of a

datacenter. Their approach eliminates interrupts in the critical

I/O handling path, and instead replaces them by a smart

event-based polling model. Their proposed mechanism can be

im-plemented either at the guest OS kernel level or at the Virtual

Machine Monitor level. In the paper “Enhancing Survivability

in Virtualized Data Centers: A Service-aware Approach,” Xu,

Tang, Kwiat, Zhang, and Xue propose to use a service-aware

approach to enhance survivability in virtualized data centers.

They consider the optimization problem of Survivable Virtual

Infrastructure Mapping and present a general optimization

framework. They then propose an efficient algorithm for VM

Placement (VMP), a polynomial-time optimal algorithm for

Virtual Link Mapping (VLM), and an effective heuristic

algo-rithm that jointly solve VMP and VLM problem. In the paper

“Automating Cloud Network Optimization and Evolution,”

Wu, Zhang, Singh, Jiang, and Wang present a cloud network

performance optimization framework, a topology independent

resource allocation and optimization approach, to achieve

continuous and cost effective data center maintenance. Based

on a swarm intelligence optimization model, their approach

improves the scalability of the cloud network by relocating

VMs and matching resource demand and availability.

II. D

C

R

The next two papers are about data casting and routing.

In the paper “Datacast: A Scalable and Efficient Reliable

Group Data Delivery Service for Data Centers,” Cao, Guo,

Lu, Xiong, Zheng, Zhang, Zhu, Chen, and Tian propose a

data casting protocol, named Datacast, for Reliable Group

Data Delivery (RGDD), a pervasive traffic pattern in data

centers. Datacast explores two design spaces: 1) Datacast uses

2594 IEEE JOURNAL ON SELECTED AREAS IN COMMUNICATIONS, VOL. 31, NO. 12, DECEMBER 2013

multiple edge-disjoint Steiner trees for data delivery

acceler-ation, and 2) Datacast leverages in-network packet caching

and introduces a simple soft-state based congestion control

algorithm to address the scalability and efficiency issues of

RGDD. In the paper “A Unified Unicast and Multicast Routing

and Forwarding Algorithm for Software-Defined Datacenter

Networks,” Jia and Wang propose a multiple membership

query algorithm based on the prime theory, such as Chinese

Remainder Theorem, for the scalability problem associated

with software-defined datacenter. Their approach outperforms

the Bloom filter approach in terms of memory consumption,

hardware cost and delivery accuracy in a large-scale datacenter

networks.

III. T

M

The next two papers are about traffic management. In the

paper “Data Centers as Software Defined Networks: Traffic

Redundancy Elimination with Wireless Cards at Routers,”

Cui, Xiao, Liao, Stojmenovic, and Li present a mechanism

for traffic redundancy elimination in data center networks.

Their proposed mechanism adds wireless network cards to

both servers and routers to achieve the ‘logically centralized’

control over the physically distributed states in emerging

software defined networks (SDN) paradigm. In the paper

“Scalable Multi-Class Traffic Management in Data Center

Backbone Networks,” Ghosh, Ha, Crabbe, and Rexford

in-vestigate two alternative traffic management designs for large

online service providers. Their work achieves scalability by

distributing computation across multiple tiers of optimization

machinery. Using optimization, they show that their designs

provably maximize the aggregate utility over all traffic classes.

IV. R

M

The next paper addresses the issue of resource management.

In the paper “A Framework for Cooperative Resource

Man-agement in Mobile Cloud Computing,” Kaewpuang, Niyato,

Wang, and Hossain propose a decision making framework for

mobile cloud service providers in a mobile cloud computing

environment. The proposed framework is composed of

meth-ods for resource allocation to mobile applications, revenue

management, and cooperation formation among the providers.

The objective of the framework is to obtain the best decisions

for the mobile cloud service providers given that they are

rational and interested in maximizing their own benefits.

V. D

S

S

The next paper is about Distributed Storage Systems. In the

paper “Capacity and Security of Heterogeneous Distributed

Storage Systems,” Ernvall, Rouayheb, Hollanti, and Poor

study distributed heterogeneous storage systems, whose nodes

in these systems can have different storage capacities and

different repair bandwidths. They prove an upper bound on the

capacity that depends on the average resources available per

node, and develop an expression for the system capacity when

all the nodes’ parameters are known. They also investigate

the case in which the system is compromised by an active or

passive adversary, and provide bounds on the system secure

capacity.

VI. B

D

The next paper “Moving Big Data to The Cloud: An Online

Cost-Minimizing Approach,” Zhang, Wu, Li, Guo, Chen,

and Lau study timely, cost-minimizing upload of massive,

dynamically-generated, geo-dispersed data into the cloud, for

processing using a MapReduce-like framework. A

polynomial-time optimal offline algorithm is proposed based on dynamic

programming, and two online algorithms are designed to

practically guide data migration in an online fashion.

VII. C

A

The next paper is about cloud computing applications. In

the paper “Dynamic Request Splitting for Interactive Cloud

Applications,” Hajjat, Shankaranarayanan, Maltz, Rao, and

Sripanidkulchai present a system, named Dealer, that helps

geo-distributed, interactive and multi-tier applications meet

their stringent requirements on response time despite the

high variability in performance of cloud services. Dealer

can enable applications to meet their SLA requirements by

dynamically splitting requests for each component among its

replicas in different data-centers.

In conclusion, we sincerely hope that this special issue

provides an up-to-date and valuable research information

for the researchers currently conducting research in cloud

networking. We would also like to take this opportunity to

thank the authors who submitted their quality work to this

special issue, and thank all reviewers for their efforts and

valuable reviews. We are grateful to Dr. Martha Steenstrup

for her advice and encouragement in the initial stage of our

proposal. Our special thanks go to Dr. Alberto Leon-Garcia

who rendered prompt advice and assistance in the preparation

of this special issue. We also thank Laurel Greenidge and Sue

Lange for their quick responses to our various queries and the

timely processing of the final manuscripts.
