Storage Systems

(1)

Storage Systems

郭大維教授

ktw@csie.ntu.edu.tw

嵌入式系統暨無線網路實驗室

(Embedded Systems and

Wireless Networking Laboratory)

國立臺灣大學資訊工程學系

Reading:

Kam-yiu Lam and Tei-Wei Kuo, “Real-Time Database Systems: Architecture and Techniques”, Kluwer Academic Publishers, 2000

Krishna and Kang, “Real-TimeSystems,” McGRAW-HILL, 1997.

(2)

Storage Systems

Real-Time Disk Scheduling

Flash-Memory Storage Systems

(3)

2010/12/14 Embedded Systems and Wireless Networking Lab. 3

Real-Time Disk Scheduling

Motivation: Disparity between CPU and disk speed.

access time = queuing time + seek time + latency delay + transfer time

Strategies to improve the performance of disk service:

First-come-first-served (FCFS) algorithm ^* :

Poor because of no consideration in deadlines and arm movements.

Earliest-deadline-first (EDF) algorithm:

Not optimum in minimizing the number of transaction deadlines missed.

Track

1 4 380 390

Requests Deadlines Track

1 20 390

2 40 1

3 60 380

4 80 4

(4)

2010/12/14 Embedded Systems and Wireless Networking Lab. 4

Real-Time Disk Scheduling

Scan (or elevator) algorithm ^* :

Start at one end of the disk, and moves toward the other end, servicing requests as it reaches each track, until it gets to the other end of the disk.

At the other end, the direction of head movement is reversed and servicing continues.

Bad for service requests at either end of a disk.

C-Scan (Circle Scan) algorithm ^* :

Goal: Provide a more uniform wait time.

As does Scan scheduling, servicing requests as it goes. However, when the head reaches one end, it immediately returns to the beginning of the disk.

Track

queue=295, 30, 150

30 295

queue=5, 70, 225

150 225 399

70

5

(5)

2010/12/14 Embedded Systems and Wireless Networking Lab. 5

Real-Time Disk Scheduling

Shortest-seek-time-first (SSTF)algorithm ^* :

A greedy algorithm which always selects the request with the minimum seek time from the current request queue.

Starvation of some requests...

A variation of SCAN:

Classify requests into classes.

Service requests in the same class in terms of SCAN.

Service classes in order of their priorities.

Q: How many priority levels are enough, and how to partition them?

* It means no consideration of deadlines.

Track

queue=305, 30, 5, 225 30 70 150 225 305 399

5 queue=305, 150

(6)

2010/12/14 Embedded Systems and Wireless Networking Lab. 6

Real-Time Disk Scheduling

A weighted scheduling algorithm:

Sort requests in the waiting queue in the increasing order of their deadlines.

Each request is assigned a weight w _i depending on their order in the queue.

Let d _i be the distance the arm has to move from its current position to serve the request.

Consider q requests at a time to reduce the algorithm complexity.

Service the request with the highest priority p _i = 1/ (w _i d _i ) Q: How to assign processes weights w _i ?

A variation of the weighted scheduling algorithm:

Motivation: Consider deadline instead of deadline order!

Service the request with the highest priority p _i = f(d _i , d _i ) = a d _i + (1-a) d _i . a is a design factor, and choosing a in the range 0.7 to 0.8 looks good.

Reading: A. Silberschatz and P.B. Galvin, “Operating System Concepts,” 4th Ed., Addison-Wesley Publishing Company, 1994.

C.M. Krishna and K.G. Shin, “Real-TimeSystems,” McGRAW-HILL, 1997.

S. Chen, J.A. Stankovic, J.F. Kurose, and D.F. Towsley, “Performance Evaluation of Two New disk scheduling Algorithms for Real-Time Systems,”

J. of Real-Time Systems, 3(3):307-336, 1991.

(7)

2010/12/14 Embedded Systems and Wireless Networking Lab. 7

Real-Time Disk Scheduling

Another paper for discussion:

A.L. N. Reddy and J.C. Wyllie, “I/O Issues in

Multimedia System,” IEEE Transactions on

Computers, March 1994.

(8)

Flash-Memory Storage Systems

郭大維教授

ktw@csie.ntu.edu.tw

嵌入式系統暨無線網路實驗室 (Embedded Systems and Wireless

Networking Laboratory)

國立臺灣大學資訊工程學系

(9)

2010/12/14 Embedded Systems and Wireless Networking Lab. 9

Agenda

Introduction

Management Issues

Performance vs Overheads

Other Challenging Issues

Conclusion

(10)

2010/12/14 Embedded Systems and Wireless Networking Lab. 10

Introduction – Why Flash Memory

Diversified Application Domains

Portable Storage Devices Consumer Electronics

Industrial Applications

SoC and Hybrid Devices

Critical System Components

(11)

2010/12/14 Embedded Systems and Wireless Networking Lab. 11

Trends in VLSI Technology

Source: www.icknowledge.com

* This slide was from the ASP-DAC’06 talk delivered by Prof. Sang L. Min from the Seoul National University.

(12)

December 14, 2010 12

Trends in Flash Memory Development

IBM Journal of Research and Development, Nov 2008 Source: IDC, Jun 2007

• Significant dropping of the price per GB – More than 40% per year

• Exponential increasing in the density and capacity

(13)

13

December 14, 2010 13

Trends in Flash Memory Development

Market size: More than 15 billions US dollars in 2008 Revenue growth: More than 10% in 2008

Source: iSuppli, Apr 2008

IC Technology, NAND Flash CostTrend, 2008

(14)

2010/12/14 Embedded Systems and Wireless Networking Lab. 14

Introduction – Trends in Storage Technology

Source: Using multilevel cell NAND flash technology in consumer applications, Electronic Engineering Times, July ,2005

Samsung 2GB USB 2.0 Flash Drive

Price: $49.99

Less Rebate: - $25.00 Final Price: $24.99*

T-One 2GB

Microdrive/3600RPM

$144.99

September 2006

(15)

2010/12/14 Embedded Systems and Wireless Networking Lab. 15

Introduction – Trends in Storage Technology

Source: Using multilevel cell NAND flash technology in consumer applications, Electronic Engineering Times, July ,2005. Amazon.com

Transcend 8GB

CompactFlash Card

Price: $84.85

Microdrive 4GB Compact Flash Type II

Price: $116 ScanDisk 4GB

CompactFlash Card

Price: $55.99

March 2007

(16)

Trends – Storage Media

2008/1/30 Embedded Systems and Wireless Networking Lab. 16

Source: Using multilevel cell NAND flash technology in consumer applications, Electronic Engineering Times, July ,2005 Component Times, Nov 2007.

* Parts of this slide was from the ASP-DAC’06 talk delivered by Prof. SangLyul. Min from the Seoul National University.

Transcend 32GB SSD, 2.5- Inch, SATA, MLC (USD343.30)

Transcend 8GB SDHC SD CARD (USD30.30)

HITACHI 6GB

Microdrive MD6GBBP (USD169.95)

Seagate

ST302504FDA1E1-RK FreeAgent Desktop 250 GB USB

External Hard Drive (USD79.99)

March 2008

(17)

Trends – Storage Media

2008/11/11

All Rights Preserved, Tei-Wei Kuo, National Taiwan University 17 Source: Using multilevel cell NAND flash technology in consumer applications, Electronic Engineering Times, July ,2005, and

Component Times, Nov 2007.

The first commercial flash chip was presented by Toshiba in 1985 as a 256Kbit chip, where 1Mb DRAM was introduced in 1986.

* Parts of this slide was from the ASP-DAC’06 talk delivered by Prof. SangLyul. Min from the Seoul National University.

20Gb IBM HDD

Transcend 32GB SSD, 2.5- Inch, SATA, MLC (USD92.24)

Transcend 8GB SDHC SD CARD (USD19.95)

HITACHI 6GB

Microdrive MD6GBBP (USD149.99)

Seagate FreeAgent 500GB 3.5-Inch USB 2.0 Hard Drive ST305004FDA1E1-RK (USD85.99)

October 2008

(18)

Trends – Storage Media

2010/12/14

All Rights Preserved, Tei-Wei Kuo, National Taiwan University

Source: Using multilevel cell NAND flash technology in consumer applications, Electronic Engineering Times, July ,2005, and Component Times, Nov 2007.

The first commercial flash chip was presented by Toshiba in 1985 as a 256Kbit chip, where 1Mb DRAM was introduced in 1986.

* Parts of this slide was from the ASP-DAC’06 talk delivered by Prof. SangLyul. Min from the Seoul National University.

Transcend 2.5" SSD 64 GB SATA-II

(USD144.12) Transcend 16GB

SDHC SD CARD (USD39.50)

4GB HITACHI MICRODRIVE CF+

TYPE II TRAVEL KIT (MD4GB/

A HMS360604D5CF00) (USD25.00)

Seagate FreeAgent Desk 1 TB

USB 2.0 Hard Drive ST310005FDA2E1-RK

(USD119.99)

May 2009

18

(19)

Trends – Storage Media

2010/12/14

All Rights Preserved, Tei-Wei Kuo, National Taiwan University

Source: Using multilevel cell NAND flash technology in consumer applications, Electronic Engineering Times, July ,2005, and Component Times, Nov 2007.

The first commercial flash chip was presented by Toshiba in 1985 as a 256Kbit chip, where 1Mb DRAM was introduced in 1986.

* Parts of this slide was from the ASP-DAC’06 talk delivered by Prof. SangLyul. Min from the Seoul National University.

Transcend 128 GB SATA-2 2.5-inch Solid State

(USD283.99) Transcend 16GB

SDHC SD CARD (USD36.49)

4GB HITACHI MICRODRIVE CF

(USD19.00)

Seagate FreeAgent Desk 1.5 TB

USB 2.0 Hard Drive ST315005FDA2E1-RK

(USD145.77)

November 2009

19

(20)

Trends – Storage Media

2010/12/14

All Rights Preserved, Tei-Wei Kuo, National Taiwan University

Source: Using multilevel cell NAND flash technology in consumer applications, Electronic Engineering Times, July ,2005, and Component Times, Nov 2007.

The first commercial flash chip was presented by Toshiba in 1985 as a 256Kbit chip, where 1Mb DRAM was introduced in 1986.

* Parts of this slide was from the ASP-DAC’06 talk delivered by Prof. SangLyul. Min from the Seoul National University.

Kingston SSDNow V Series 128 GB

SATA 2.5- Inch Solid State Drive

(USD224.35) Transcend 32GB

SDHC SD CARD (USD50.99)

Western Digital WD Elements 2 TB USB 2.0 Desktop External Hard Drive

WDBAAU0020HBK-NESN

(USD109.99)

November 2010

20

(21)

2010/12/14 Embedded Systems and Wireless Networking Lab. 21

The Ultimate Limit on Mechanical Devices

Fly By Night

Boeing 747

2,000,000 Miles Per Hour

1/100” Flying Height

Source: Richard Lary, The New Storage Landscape: Forces shaping the storage economy, 2003.

Source:

http://www.hitachigst.com/

* This slide was from the ASP-DAC’06 talk delivered by Prof. Sang L. Min from the Seoul National University.

A Microdrive Example

(22)

Flash Makers – NAND Flash Memory

Embedded Systems and Wireless Networking Lab. 22

http://hugoleijtens.spaces.live.com/blog/cns!4B94B7453D4BFD9E!988.entry Source: iSuppli Corp (Unit: Million Dollars)

[EE Times,11/30/2007]

For years, NAND prices have dropped by an

average of 40 percent

or more per year.

(23)

Flash Stories – Solid-State Disks

< 50% Heat, Ultra

Silence, Light Weight, MTTF – 200M hours (HDD – 30M hours), Energy Efficiency

Embedded Systems and Wireless Networking Lab. 23

IDC, SanDisk - Component Times, Nov 2007

(24)

Flash Stories – Flash Wars

Fab

300mm Wafer Fab by Toshiba and SanDisk at Yokkaichi, Japan

80,000 Wafers per Month (2008) 210,000 Wafers per Month

300mm Wafer Fab by IM Flash

Technologies (Intel & Micron) at Utah

Joint Venture: Sony and Qimonda, Hynix and Sandisk

Technology

32nm (Samsung, Intel), 43nm (Toshiba), 50nm (IM)

2008/1/30 Embedded Systems and Wireless Networking Lab. 24

(25)

Introduction – The

Characteristics of Storage Media

Reference Devices/Modules: DRAM: DDR-400. NOR FLASH: Silicon Storage Technology SST39LF010.

NAND FLASH: Samsung K9K8G08U0M. Disk: Seagate ST31000333AS

Media

Access time

Read Write Erase

DRAM ^{5ns (1B)}

2.56us (512B)

5ns (1B) 2.56us (512B)

-

NOR FLASH ^{45ns (1B)} 23us (512B)

14us (1B) 7.2ms (512B)

18ms (128KB)

NAND FLASH ^{20us (1B)} 32.8us (512B)

200us (1B) 212us (512B)

1.5ms (128KB)

DISK 12.7ms (512B) (average)

14.2 ms(512B) (average)

-

13X 83X

390X 67X

(26)

Non-Volatile Memory

2008/1/30 Embedded Systems and Wireless Networking Lab. 26

Macronix International Co., Component Times, Nov. 2007

(27)

All Rights Preserved, Tei-Wei Kuo, National Taiwan University 27

Introduction – Single-Level Cell (SLC)

Selected cell I _DS

Control Gate

Drain

Source Each Word Line is connected to control gates.

Each Bit Line is connected to the drain.

Cell

NOR Flash

(28)

Introduction – Single-Level Cell (SLC)

NAND accesses each cell through adjacent cells, while NOR allows for individual access to each cell. ¹

The cell size of NAND is almost half the size of a NOR cell.

All Rights Preserved, Tei-Wei Kuo, National Taiwan University 28

*

"Flash Memory Moves from Niche to

Mainstream," Chip Design Magazine, April/May 2006.

NOR Flash NAND Flash

(29)

2010/12/14 Embedded Systems and Wireless Networking Lab. 29

Introduction – Multi-Level Cell (MLC) vs SLC

64 MB

SLC Flash

1 0

V

_T

LOGIC STATE

N U M B E R O F C E L L S

a) BILEVEL (1 BIT/CELL)

11 00

V

_T

LOGIC STATE

N U M B E R O F C E L L S

b) MULTILEVEL (2 BIT/CELL)

10 01

128 MB

MLC Flash

(30)

2010/12/14 Embedded Systems and Wireless Networking Lab. 30

1-bit/Cell SLC NAND Flash

100,000 Program/Erase cycles (with ECC) _[1]

10 years Data Retention _[1]

2-bits/Cell MLC NAND Flash

10,000 Program/Erase cycles (with ECC) _[2]

10 years Data Retention _[2]

4-bits/Cell MLC NAND FLASH Developers (2006)

M-systems, Intel, Samsung, and Toshiba

[1] ST Micro-electronics NAND SLC large page datasheet (NAND08GW3B2A) [2] ST Micro-electronics NAND MLC large page datasheet (NAND04GW3C2A)

* USD34.65 per GB for NOR, USD6.79 per GB for NAND (March 2007)

Comparison of SLC and MLC

(31)

2010/12/14 Embedded Systems and Wireless Networking Lab. 31

Introduction – Consumer Applications

Electronic Engineering Times, July 2005

(32)

2010/12/14 Embedded Systems and Wireless Networking Lab. 32

Bandwidth Requirements – Video

ˇ ˇ

Electronic Engineering Times, July 2005

(33)

2010/12/14 Embedded Systems and Wireless Networking Lab. 33

Bandwidth Requirements – Audio

ˇ ˇ

Electronic Engineering Times, July 2005

(34)

2010/12/14 Embedded Systems and Wireless Networking Lab. 34

Introduction – Challenges in Flash- Memory Storage Designs

Requirements in Good Performance Limited Cost per Unit

Strong Demands in Reliability

Increasing in Access Frequencies

Tight Coupling with Other Components

Low Compatibility among Vendors

(35)

2010/12/14 Embedded Systems and Wireless Networking Lab. 35

Agenda

Introduction

Management Issues

Performance vs Overheads

Other Challenging Issues

Conclusion

(36)

2010/12/14 Embedded Systems and Wireless Networking Lab. 36

Management Issues – System Architectures

AP

File-System Layer

AP AP

Block Device Layer (FTL emulation)

Flash Memory MTD drivers

AP

(37)

2010/12/14 Embedded Systems and Wireless Networking Lab. 37

Management Issues – Flash-Memory Characteristics

……

Block 0 Block 1 Block 2 Block 3

Erase one block 1 Page = 512B

1 Block = 32 pages(16KB)

……

Write one

page

(38)

2010/12/14 Embedded Systems and Wireless Networking Lab. 38

Management Issues – Flash-Memory Characteristics

Write-Once

No writing on the same page unless its residing block is erased!

Pages are classified into valid, invalid, and free pages.

Bulk-Erasing

Pages are erased in a block unit to recycle used but invalid pages.

Wear-Leveling

Each block has a limited lifetime in erasing counts.

(39)

2010/12/14 Embedded Systems and Wireless Networking Lab. 39

Management Issues – Flash-Memory Characteristics

Example 1: Out-place Update

Live pages Free pages A B C D

Suppose that we want to update data A and B…

(40)

2010/12/14 Embedded Systems and Wireless Networking Lab. 40

Dead pages

A B C D A B

Management Issues – Flash-Memory Characteristics

Example 1: Out-place Update

(41)

2010/12/14 Embedded Systems and Wireless Networking Lab. 41

A live page A dead page A free page This block is to be recycled.

(3 live pages and 5 dead pages)

L D D L D D L D L L D L L L F D L F L L L L D F F L L F L L F D

Management Issues – Flash-Memory Characteristics

Example 2: Garbage Collection

(42)

2010/12/14 Embedded Systems and Wireless Networking Lab. 42

L L D L L L D L F L L L L D

L L F L L F D L

L

D D D D

A live page A dead page A free page

Live data are copied to somewhere else.

L

D D D

D

Management Issues – Flash-Memory Characteristics

Example 2: Garbage Collection

(43)

2010/12/14 Embedded Systems and Wireless Networking Lab. 43

A live page A dead page A free page

The block is then erased.

Overheads:

•live data copying

•block erasing.

L L D L L L D L F L L L L D

L L F L L F D L

L F F F F F F F F

L

Management Issues – Flash-Memory Characteristics

Example 2: Garbage Collection

(44)

2010/12/14 Embedded Systems and Wireless Networking Lab. 44

Management Issues – Flash-Memory Characteristics

Example 3: Wear-Leveling

L D D L D D L D L L D L L L F D L F L L L L D F F L L F L L F D

100

10

20

15 Erase cycle counts

Wear-leveling might interfere with the

decisions of the block- recycling policy.

A live page A dead page A free page

A

B

C

D

(45)

2010/12/14 Embedded Systems and Wireless Networking Lab. 45

Management Issues – Challenges

The write throughput drops significantly after garbage collection starts!

The capacity of flash-memory storage systems increases very quickly such that memory space requirements grows quickly.

Reliability becomes more and more critical when the manufacturing capacity increases!

The significant increment of flash-memory access rates seriously exaggerates the

Read/Program Disturb Problems!

(46)

2010/12/14 Embedded Systems and Wireless Networking Lab. 46

Agenda

Introduction

Management Issues

Performance vs Overheads – FTL vs NFTL

Other Challenging Issues

Conclusion

(47)

2010/12/14 Embedded Systems and Wireless Networking Lab. 47

System Architecture

Garbage Collection

Address Translation

FTL/NFTL Layer File system (FAT, EXT2, NTFS...)

Device Driver fwrite(file,data)

Block write (LBA,size)

Flash I/O Requests

Control signals

File Systems process process

process Applications

Flash-Memory Storage System

Physical Devices

(Flash Memory Banks)

process

(48)

48 48

D e v ic e

Flash Media

H o s t

Applications

Operating System

File System (e.g. DOS FAT)

FTL MTD

Applications

Operating System

File System (e.g. DOS FAT)

H o s t D e v ic e

FTL

Flash Media MTD

*FTL: Flash Translation Layer, MTD: Memory Technology Device xD,

SmartMedia

SD,

Memory Stick, Compact Flash

Management Issues – Flash-

Memory Characteristics

(49)

2010/12/14 Embedded Systems and Wireless Networking Lab. 49

Policies – FTL

FTL adopts a page-level address translation mechanism.

The main problem of FTL is on large memory space

requirements for storing the address translation information.

User data

. . .

Logical Block Address (array index)

Physical Block Address (block,page)

Access LBA = 3

Address Translation

Table (in main-memory) Flash memory

0,0 0,1 0,2 0,3 0,4 0,5 0,6 0,7 1,0 1,1 1,2 1,3

(0,3) (0,1) (0,6) (0,4) (4,7) (1,0) (2,1) (1,2) (1,3)

0 1 2 3 4 5 6 7 8 9 10 11

. . .

Spare data

Spare data LBA=3;

ECC=. . .;

Status=. . .;

(50)

2010/12/14 Embedded Systems and Wireless Networking Lab. 50

Policies – NFTL (Type 1)

. . .

(9)

Write data to LBA=1011

. . .

NFTL

Address Translation Table (in main-memory)

Free Free Free Used

Free Free Free Free

Free Free Free Free Free Free Free Free

A Chain Block Address = 9

A Chain Block Address = 23

VBA=126

Block Offset=3

If the page has been used Write to the page with block

offset=3

A logical address under NFTL is divided into a virtual block address and a block offset.

e.g., LBA=1011 => virtual block address (VBA) = 1011 / 8 = 126 and block offset = 1011 % 8 = 3

Free Free Free Free Free Free Free Free

A Chain Block Address = 50

Used

Write to the page with block

offset=3

(51)

2010/12/14 Embedded Systems and Wireless Networking Lab. 51

Policies – NFTL (Type 2)

A logical address under NFTL is divided into a virtual block address and a block offset.

e.g., LBA=1011 => virtual block address (VBA) = 1011 / 8 = 126 and block offset = 1011 % 8 = 3

. . .

(9,23)

Write data to LBA=1011

. . .

NFTL

Address Translation Table (in main-memory)

Free Free Free Used

Free Free Free Free

Used Used Used Free Free Free Free Free A Primary Block

Address = 9

A Replacement Block Address = 23

VBA=126

Block Offset=3

If the page has been used

Write to the

first free page

(52)

2010/12/14 Embedded Systems and Wireless Networking Lab. 52

Policies – NFTL

NFTL is proposed for the large-scale NAND flash storage systems because NFTL adopts a block-level address translation.

However, the address translation

performance of read and write requests

might deteriorate, due to linear searches of address translation information in primary and replacement blocks.

(53)

Policies – BL

BL adopts a block-level address translation mechanism.

The main problem of BL is on low space utilization and significant write overhead

e.g., LBA=1011 => virtual block address (VBA) = 1011 / 8

= 126 and block offset = 1011 % 8 = 3

53 Address Translation Table (in main-memory)

. . .

9 Write data to LBA=1011

. .

VBA=12 .

6 Used Free Used

Free Free Used Used Free

Physical block = 9

Block Offset=3

Write

Free Free Free Free Free Free Free Free

Physical block = 10

10 Write

Copy

(54)

2010/12/14 Embedded Systems and Wireless Networking Lab. 54

Policies – FTL or NFTL

FTL NFTL

Memory Space Requirements Large Small Address Translation Time Short Long Garbage Collection Overhead Less More

Space Utilization High Low

The Memory Space Requirements for one 1GB

NAND (512B/Page, 4B/Table Entry, 32 Pages/Block) FTL: 8,192KB (= 4(10241024*1024)/512)

NFTL: 256KB (= 4(102410241024)/(51232))

Remark: Each page of small-block(/large-block) SLC NAND can store 512B(/2KB) data, and there are 32(/64) pages per block.

Each page of MLCx2 NAND can store 2KB, and there are 128 pages per block.

(55)

2010/12/14 Embedded Systems and Wireless Networking Lab. 55

Address Translation Time - NFTL

The address translation performance of read and write requests can be deteriorated, due to linear searches of physical addresses.

A

A Primary Block A Replacement Block

B C D E

A B A B A A B B

The most-recent content of the write request of

LBA F=105

The most-recent content of the write request of

LBA B=101

The most-recent content of the write request of

LBA A=100

1. Assume that each block contains 8 pages.

2. Let LBA A, B, C, D, and E be written for 5, 5, 1, 1, and 1 times,

respectively. Their data distribution could be like to what in the left figure.

3. For example, it might need to scan 9

spare areas for LBA B.

(56)

2010/12/14 Embedded Systems and Wireless Networking Lab. 56

Garbage Collection Overhead - NFTL

A

A Primary Block A Replacement Block

B C D E

A B A B A A B B

A B C D E

A New Primary Block

3. Overhead is 2 block erases and 5 page writes.

1. Copy the most-recent content to the new primary block.

2. Erase the old primary block and the replacement block.

(57)

2010/12/14 Embedded Systems and Wireless Networking Lab. 57

A

A Primary Block A Replacement Block

B C D E

A B A B A A B B

A B C D E

A New Primary Block

Space Utilization - NFTL

3 free pages are wasted.

(58)

2010/12/14 Embedded Systems and Wireless Networking Lab. 58

Agenda

Introduction

Management Issues

Performance vs Overheads – An Adaptive Two-Level Mapping Mechanism

Other Challenging Issues

Conclusion

(59)

2010/12/14 Embedded Systems and Wireless Networking Lab. 59

Motivation

An adaptive two-level management design of a flash translation layer, called AFTL.

Exploit the advantages of the fine-grained address

mechanism and the coarse-grained address mechanism.

FTL NFTL AFTL Memory Space

Requirements

Large Small A little larger than NFTL

Address Translation Time

Short Long Much Better than NFTL

Garbage Collection Overhead

Less More Much Better than NFTL

Space Utilization High Low Much Better than

NFTL

(60)

2010/12/14 Embedded Systems and Wireless Networking Lab. 60

AFTL – Coarse-to-Fine Switching

A Fine-Grain Hash Table

A Coarse-Grain Hash Table

. . .

A A Primary Block

( )

B C D E

A

A Replacement Block ( )

B A B A A B B .

. .

. . .

AFTL

PPBA RPBA

) , ,

(VBA PPBA RPBA

1. AFTL doesn’t erase the two blocks immediately.

2. AFTL moves the

mapping information of the replacement block to the fine-grained hash

table by adding fine- grained slots.

(A, ) (B, )

5 RPBA

7 RPBA

) 1 , , (VBAPPBA

3. The RPBA field of the corresponding mapping information is nullified.

Chin-Hsien Wu and Tei-Wei Kuo, 2006, “An Adaptive Two-Level Management for the Flash Translation Layer in Embedded Systems,”

IEEE/ACM 2006 International Conference on Computer-Aided Design (ICCAD), November 5-9, 2006.

(61)

2010/12/14 Embedded Systems and Wireless Networking Lab. 61

AFTL – Fine-to-Coarse Switching

The number of the fine-grained slots is limited.

Some least recently used mapping information of fine-grained slots should be moved to the coarse-grained hash table.

A Fine-Grain Hash Table

A Coarse-Grain Hash Table

. . .

A A Primary Block

( )

B C D E

A

A Replacement Block ( )

B A B .

. .

. . .

AFTL

PPBA RPBA

) , ,

(VBAPPBARPBA (A, ) (B, )

5 RPBA

7 RPBA

1. Assume that this fine-grained slot is to be replaced.

2. Data stored in the page with the given (physical) address are

copied to the primary or replacement block of the

corresponding coarse-grained slot, as defined by NFTL.

3. If there dose not exist any corresponding coarse-grained slot, a new one is created.

(F, PBAE)

(62)

2010/12/14 Embedded Systems and Wireless Networking Lab. 62

AFTL – Fine-to-Coarse Switching

Coarse-to-fine switches would introduce fine-to- coarse switches and overhead in valid page

copying.

It is because the number of the fine-grained slots is limited.

Stop any coarse-to-fine switch when some

frequency bound in coarse-to-fine switches is reached.

We set a parameter in the experiments to control the

frequency of switches to explore the behavior of the

proposed mechanism.

(63)

2010/12/14 Embedded Systems and Wireless Networking Lab. 63

The Advantages of AFTL

Improve the address translation performance.

It is because the moving of their mapping information to the fine-grained hash table.

Improve the garbage collection overhead.

The delayed recycling of any replacement block reduces the potential number of valid data

copyings and blocks erased.

Improve the space utilization.

The delayed recycling of any primary block lets free pages of a primary block be likely used in the future.

. . .

A A Primary Block

( )

B C D E

A A Replacement Block

( )

B A B A A B B .

. .

. . .

(A, ) (B, )

AFTL

cg.PPBA

d d_cg.RPBA

) , , . (

RPBA PPBA VBA

cg cg cg

d d d

5 .RPBA dcg

7 .RPBA dcg

Chin-Hsien Wu and Tei-Wei Kuo, 2006, “An Adaptive Two-Level Management for the Flash Translation Layer in Embedded Systems,”

IEEE/ACM 2006 International Conference on Computer-Aided Design (ICCAD), November 5-9, 2006.

(64)

2010/12/14 Embedded Systems and Wireless Networking Lab. 64

Agenda

Introduction

Management Issues

Performance vs Overheads –

Performance Evaluation

Other Challenging Issues

Conclusion

(65)

2010/12/14 Embedded Systems and Wireless Networking Lab. 65

Performance Evaluation

Performance Setup

The characteristics of the experiment trace was over a 20GB disk.

CPU Intel Celeron 750MHz

RAM 320 MB

OS Windows XP

File Systems NTFS

Applications Web Applications, E-mail Clients, MP3 Player, MSN Messenger, Word, Excel, PowerPoint, Media, Player,

Programming, and Virtual Memory Activities

Durations One week

Total Write / Read Requests 13,198,805 / 2,797,996 sectors

Different LBA’s 1,669,228

(66)

2010/12/14 Embedded Systems and Wireless Networking Lab. 66

Performance Evaluation

Performance Setup

The maximum number of fine-grained slots is controlled by a parameter MFS.

A parameter ST controls the frequency of

switches between the two address translation mechanisms – n/ST.

ST=0 => No constraint on the number of switches.

Smaller ST => More switches.

Larger ST => Less switches.

(67)

2010/12/14 Embedded Systems and Wireless Networking Lab. 67

Memory Space Requirements

1. MFS ranged from 2,500, 5,000, 7,500, 10,000, 12,500, to 15,000.

2. AFTL uses a little more memory space than NFTL.

0 200 400 600 800 1000 1200

M FS =2 ,5 00

M FS =5 ,0 00

M FS =7 ,5 00

M FS =1 0, 00 0

M FS =1 2, 50 0

M FS =1 5, 00 0

N FT L

M em o ry S p ac e( K )

AFTL NFTL

(68)

2010/12/14 Embedded Systems and Wireless Networking Lab. 68

Address Translation Performance

600000 650000 700000 750000 800000 850000 900000 950000 1000000

M FS =2,5 00

M FS =5,0 00

M FS =7,5 00

M FS =10, 000

M FS =12, 500

M FS =15,

000 N FT L

A ddr es s T ra ns la ti on T im e (m s)

ST=64 ST=32 ST=16 ST=0 NFTL

1 . Larger MFS => smaller address translation time

- More address translations going through the fine-grained address translation mechanism.

2. Smaller ST => longer address translation time

- More coarse-to-fine switches

(69)

2010/12/14 Embedded Systems and Wireless Networking Lab. 69

Garbage Collection Overhead

4 5 6 7 8 9 10

M F S = 2, 50 0

M F S = 5, 00 0

M F S = 7, 50 0

M F S = 10 ,00 0

M F S = 12 ,50 0

M F S = 15 ,00 0

N F T L

Average Number of Valid Pages Copied

ST=64 ST=32 ST=16 ST=0 NFTL

350000 370000 390000 410000 430000 450000 470000 490000 510000 530000 550000

M F S= 2, 50 0

M F S= 5, 00 0

M F S= 7, 50 0

M F S= 10 ,0 00

M F S= 12 ,5 00

M F S= 15 ,0 00

N FT L

Number of Blocks Erased

ST=64 ST=32 ST=16 ST=0 NFTL

AFTL outperforms NFTL.

- Coarse-to-fine switches can avoid immediate recycling of their primary and replacement blocks and related valid data copyings.

(70)

2010/12/14 Embedded Systems and Wireless Networking Lab. 70

Space Utilization

0 0.5 1 1.5 2 2.5 3

M FS =2 ,5 00

M FS =5 ,0 00

M FS =7 ,5 00

M FS =1 0, 00 0

M FS =1 2, 50 0

M FS =1 5, 00 0

N FT L

A v er ag e N u m b er o f F re e P ag es L ef t ST=64 ST=32 ST=16 ST=0 NFTL

The Space utilization might be better under AFTL.

- Coarse-to-fine switches can delay the recycling of replacement blocks.

- Free pages of primary blocks might be used in the future..

(71)

2010/12/14 Embedded Systems and Wireless Networking Lab. 71

Summary

AFTL is proposed to

exploit the advantages of fine- grained/coarse-grained address translation mechanisms, and to

switch dynamically and adaptively the mapping information between the two address translation mechanisms.

AFTL does provide good performance in address mapping and space

utilization and have garbage collection overhead and memory space

requirements under proper management.

. . .

A A Primary Block

( )

B C D E

A A Replacement Block

( )

B A B A A B B .

. .

. . .

(A, ) (B, )

AFTL

cg.PPBA

d dcg.RPBA

) , , . (

RPBA PPBA VBA

cg cg cg

d d d

5 .RPBA dcg

7 .RPBA dcg

Chin-Hsien Wu and Tei-Wei Kuo, 2006, “An Adaptive Two-Level Management for the Flash Translation Layer in Embedded Systems,”

IEEE/ACM 2006 International Conference on Computer-Aided Design (ICCAD), November 5-9, 2006.

(72)

2010/12/14 Embedded Systems and Wireless Networking Lab. 72

Agenda

Introduction

Management Issues

Performance vs Overheads

Other Challenging Issues

Conclusion

(73)

2010/12/14 Embedded Systems and Wireless Networking Lab. 73

Challenging Issues – Reliability

Selected cell I _DS

Control Gate

Drain

Source

Each Word Line is connected to control gates.

Each Bit Line is connected to the drain.

Cell

(74)

2010/12/14 Embedded Systems and Wireless Networking Lab. 74

Challenging Issues – Reliability

Read Operation

When the floating gate is not charged with electrons, there is current I _D (100uA) if a reading voltage is

applied. (“1” state)

5V

1V

Program Operation

Electrons are moved into

the floating gate, and the

threshold voltage is thus

raised.

(75)

2010/12/14 Embedded Systems and Wireless Networking Lab. 75

Challenging Issues – Reliability

Over-Erasing Problems

Fast Erasing Bits  All of the cells connected to the same bit line of a depleted cell would be read as “1”, regardless of their values.

Read/Program Disturb Problems

DC erasing of a programmed cell, DC programming of a non-programmed cell, drain disturb, etc.

Flash memory that has thin gate oxide makes disturb problems more serious!

Data Retention Problems

Electrons stored in a floating gate might be lost such that

the lost of electrons will sooner or later affects the charging

status of the gate!

(76)

2010/12/14 Embedded Systems and Wireless Networking Lab. 76

Program Disturb Example - DC Erasing of a Programmed Cell

Electrons might be tunneled from floating gate to control gate through interpoly oxide in all the

programmed cells.

E.g., 12V applied to the control gate and 0V applied to both source and drain

Cell A was programmed.

Programming Cell B also erases Cell A at the same time.

(77)

2010/12/14 Embedded Systems and Wireless Networking Lab. 77

Program Disturb Example – Drain Disturb

Cells sharing the BL are to be programmed, since electrons are tunneled from the floating gate through gate oxide to the drain.

Cell D was programmed.

Programming Cell B also erases Cell D at the same time.

(78)

2010/12/14 Embedded Systems and Wireless Networking Lab. 78

Challenging Issues – Observations

The write throughput drops significantly after garbage collection starts!

The capacity of flash-memory storage systems increases very quickly such that memory space requirements grows quickly.

Reliability becomes more and more critical when the manufacturing capacity increases!

The significant increment of flash-memory access rates seriously exaggerates the Read/Program

Disturb Problems!

Wear-leveling technology is even more critical when

flash memory is adopted in many system components

or might survive in products for a long life time!

(79)

2008/1/30 Embedded Systems and Wireless Networking Lab. 79

Wear Leveling versus Product Lifetime

Settings

File system: FAT16 file system with 8KB cluster size

Flash memory: 256MB small-block flash memory with 100K erase cycles

Updating of a 16MB file repeatedly with the throughput:

0.1MBs

The file requires 2K clusters = 16MB ÷ 8KB(cluster size) The FAT size of this file is 4KB (2K(clusters) x 2 bytes)

The 20% of blocks in flash memory joins the dynamic wear leveling Data of a 16MB file is stored in 1K blocks (16MB ÷ 16KB(block size)) Suppose flash memory is managed in the block level

File systems update the FAT in each cluster writing so that FAT is updated 2K times for a 16MB file

Writing of a 16MB incurs 1K block erases because of the reclaiming of invalid

space.

(80)

2008/1/30 Embedded Systems and Wireless Networking Lab. 80

Wear Leveling versus Product Lifetime

Ways in Data Updates

In-Place-Updates: Rewriting on the Same Page

Dynamic Wear Leveling: Rewriting over Another Free Page with Erasing over Blocks with Dead Pages

Static Wear Leveling: Rewriting over Another Free Page with Erasing over Any Blocks

Expected Lifetime of

) days ( 5 . 987 60

60 24 ) 1 2

(

100 0%

0 1 (blocks) 16

ond) 0.1(MB/sec

16(MB) Leveling

Wear Static

) days ( 5 . 197 60

60 24 ) 1 2

(

100 20%

(blocks) 16

ond) 0.1(MB/sec

16(MB) Leveling

Wear Dynamic

) days ( 09 . 0 60 60 24 2

100 ond)

0.1(MB/sec 16(MB) update)

place - (in Leveling Wear

NO

 







 



 







 



 



 



K K

K

(81)

81 Comparison of Different Technologies

Physical Block Addresses (PBA)

Eras e Cy cles

0 20 40 60 80 100

0 1000 2000 3000 4000 5000

Perfect SWL

Physical Block Addresses (PBA)

0 20 40 60 80 100

0 1000 2000 3000 4000 5000

Intuitive SWL

Eras e Cy cles

0 20 40 60 80 100

0 1000 2000 3000 4000 5000

No Wear Leveling

0 20 40 60 80 100

0 1000 2000 3000 4000 5000

Dynamic Wear Leveling

(82)

2008/1/30 Embedded Systems and Wireless Networking Lab. 82

Use a counter for each block

The garbage collector always finds the block with the least erase count.

Some heuristic approach erases a block to maintain 2 free blocks when the garbage collector finds the erase count of the block is over a given threshold.

Problems:

High extra block erases and live-page copyings

High main-memory consumption High computation cost

Wear Leveling versus Product Lifetime

Static Wear Leveling – Block-Level Mapping

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

Flash Memory

Counter

: free block : dead block : block contains (some) valid data : index in the selection of a victim block

: index to the selected free block

₅ ₅ ₅ ₄ ₅ ₅ ₄ ₄ ₄ ₅ ₅ ₅ ₄ ₄ ₄ ₅

Update data in block 3 Write new data to block 4 GC starts find a victim block

5

Update block 15 GC starts

5 5 5 5

(83)

83 An Efficient Static Wear Leveling Mechanism

A modular design for compatibility considerations

A SWL mechanism

Block Erasing Table (BET)

bit flags

SW Leveler

SWL-Procedure SWL-Update

Allocator

Address Translation / Block Assignment

Memory Technology Device (MTD) Layer SW Leveler Static Wear Leveling

Cleaner Garbage Collection File Systems (e.g., DOS FAT)

Flash Translation Layer (such FTL and NFTL)

Flash Memory

(84)

84 The Block Erasing Table (BET)

A bit-array: Each bit is for 2

^k

consecutive blocks.

Small k – in favor of hot-cold data separation Large k – in favor of small RAM space

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

Flash

BET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

1 1 1 1

k=0 k=2

e _cnt =0 f _cnt =0

e _cnt =0 f _cnt =0 e _cnt =1

f _cnt =1 e _cnt =2 f _cnt =2 e _cnt =3 f _cnt =2

e _cnt =1 f _cnt =1 e _cnt =2 f _cnt =2 e _cnt =3 f _cnt =2 e _cnt =4 f _cnt =2

: a block that has been erased in the current resetting interval

: an index to a block that the Cleaner wants to erase f _cnt : the number of 1’s in the BET

e _cnt : the total number of block erases done since the BET is reset

(85)

85 e _cnt =1998 f _cnt =2

An unevenness level (e _cnt / f _cnt ) >= T

 Triggering of the SW Leveler

Resetting of BET when all flags are set.

The SW Leveler

0 0 0 0

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

: A block that has been erased in the current resetting interval

1 1 k=2

: An index to a block that the Cleaner wants to erase

f

_cnt

: The number of 1’s in the BET

e

_cnt

^{: the} total number of block erases since the BET is erased

T : A threshold, T=1000 in this example

: An index in the selection of a block set

e _cnt =1999 f _cnt =2 e _cnt =2000

f _cnt =2

2000 / 2 = 1000 >= 1000 (E _{cnt /} f _cnt >= T)

: An index that SW Leveler triggers the Cleaner to do garbage 1

collection

The Cleaner is triggered to

1. Copy valid data of selected block set to free area, 2. Erase block in the selected block set, and 3. Inform the Allocator to update the address mapping

between LBA and PBA

After a period of time, the total erase count reaches 2998.

e _cnt =2004 f _cnt =3 e _cnt =2998

f _cnt =3 e _cnt =2999

f _cnt =3 e _cnt =3000

f _cnt =3

3000 / 3 = 1000 >= 1000 (E _{cnt /} f _cnt >= T)

1 e _cnt =3004 f _cnt =4

After a period of time, the total erase count reaches 3999.

e _cnt =3999 f _cnt =4 e _cnt =4000

f _cnt =4

4000 / 4 = 1000>=1000 (e _cnt / f _cnt >=1000) , but all flags in BET are 1 reset BET

Reset to a randomly selected block set

(flag)

e _cnt =0

f _cnt =0

(86)

86 Main-Memory Requirements

512MB 1GB 2GB 4GB 8GB

k=0 256B 512B 1024B 2048B 4096B

k=1 128B 256B 512B 1024B 2048B

k=1 64B 128B 256B 512B 1024B

k=3 32B 64B 128B 256B 512B

MLC _x2 (1 page = 2 KB, 1 block=128 pages)

(87)

87 Performance Evaluation

Metrics

Endurance Enhancement (First Failure Time) Additional Overheads (Extra Block Erases)

Experiment Setup

The FTL Layer

FTL (Flash Translation Layer protocol)

NFTL (NAND Flash Translation Layer protocol)

Traces:

A mobile PC with a 20GB hard disk Duration: One month.

Daily activities

The average number of Operations: 1.82 writes/sec, 1.97 reads/sec The percentage of accessed LBA’s: 36.62%

Storage Systems

Storage Systems

郭大維 教授

ktw@csie.ntu.edu.tw

(Embedded Systems and

Wireless Networking Laboratory)

Reading:

Kam-yiu Lam and Tei-Wei Kuo, “Real-Time Database Systems: Architecture and Techniques”, Kluwer Academic Publishers, 2000

Krishna and Kang, “Real-TimeSystems,” McGRAW-HILL, 1997.

Storage Systems

2010/12/14 Embedded Systems and Wireless Networking Lab. 3

Real-Time Disk Scheduling

Motivation: Disparity between CPU and disk speed.

access time = queuing time + seek time + latency delay + transfer time

Strategies to improve the performance of disk service:

First-come-first-served (FCFS) algorithm * :

Poor because of no consideration in deadlines and arm movements.

Earliest-deadline-first (EDF) algorithm:

Not optimum in minimizing the number of transaction deadlines missed.

Track

1 4 380 390

Requests Deadlines Track

1 20 390

2 40 1

3 60 380

4 80 4

2010/12/14 Embedded Systems and Wireless Networking Lab. 4

Real-Time Disk Scheduling

Scan (or elevator) algorithm * :

Start at one end of the disk, and moves toward the other end, servicing requests as it reaches each track, until it gets to the other end of the disk.

At the other end, the direction of head movement is reversed and servicing continues.

Bad for service requests at either end of a disk.

C-Scan (Circle Scan) algorithm * :

Goal: Provide a more uniform wait time.

As does Scan scheduling, servicing requests as it goes. However, when the head reaches one end, it immediately returns to the beginning of the disk.

Track

queue=295, 30, 150

30 295

queue=5, 70, 225

150 225 399

70

5

2010/12/14 Embedded Systems and Wireless Networking Lab. 5

Real-Time Disk Scheduling

Shortest-seek-time-first (SSTF)algorithm * :

A greedy algorithm which always selects the request with the minimum seek time from the current request queue.

Starvation of some requests...

A variation of SCAN:

Classify requests into classes.

Service requests in the same class in terms of SCAN.

Service classes in order of their priorities.

Q: How many priority levels are enough, and how to partition them?

* It means no consideration of deadlines.

Track

queue=305, 30, 5, 225 30 70 150 225 305 399

5

queue=305, 150

2010/12/14 Embedded Systems and Wireless Networking Lab. 6

Real-Time Disk Scheduling

A weighted scheduling algorithm:

Sort requests in the waiting queue in the increasing order of their deadlines.

Each request is assigned a weight w i depending on their order in the queue.

Let d i be the distance the arm has to move from its current position to serve the request.

Consider q requests at a time to reduce the algorithm complexity.

Service the request with the highest priority p i = 1/ (w i d i ) Q: How to assign processes weights w i ?

A variation of the weighted scheduling algorithm:

Motivation: Consider deadline instead of deadline order!

Service the request with the highest priority p i = f(d i , d i ) = a d i + (1-a) d i . a is a design factor, and choosing a in the range 0.7 to 0.8 looks good.

2010/12/14 Embedded Systems and Wireless Networking Lab. 7

Real-Time Disk Scheduling

A.L. N. Reddy and J.C. Wyllie, “I/O Issues in

Multimedia System,” IEEE Transactions on

Computers, March 1994.

Flash-Memory Storage Systems

2010/12/14 Embedded Systems and Wireless Networking Lab. 9

Agenda

Introduction

Management Issues

Performance vs Overheads

Other Challenging Issues

郭大維教授

First-come-first-served (FCFS) algorithm ^* :

Scan (or elevator) algorithm ^* :

C-Scan (Circle Scan) algorithm ^* :

Shortest-seek-time-first (SSTF)algorithm ^* :

Each request is assigned a weight w _i depending on their order in the queue.

Let d _i be the distance the arm has to move from its current position to serve the request.

Service the request with the highest priority p _i = 1/ (w _i d _i ) Q: How to assign processes weights w _i ?

Service the request with the highest priority p _i = f(d _i , d _i ) = a d _i + (1-a) d _i . a is a design factor, and choosing a in the range 0.7 to 0.8 looks good.
