ISSN 1560-1587 81 7.18 11.51 9.21 72.84 4.94 22.22

(2)

edge and incisive papilla in Taiwanese population

Sheau-Jiuan Huang1_{, Tsau-Mau Chou}1_{, Huey-Er Lee}1_{, Yu-Chi Wu}1_{, Yi-Hsin Yang}2_,

Cheng-Don Ho1_{, Pei-Sheng Huang}1 1_{Department of Prosthodontics, Kaohsiung Medical University}

2_{Graduate Institute of Oral Health Sciences, Kaohsiung Medical University}

Incisive papilla is a significant anatomical landmark in locating upper anterior teeth position in partial or complete and implant prosthetic denture fabrication procedure. The objective of this study is to find the relationship of central incisor and canine to incisive papilla of Taiwanese population.

Eighty-one study casts are selected. All selected study casts are analyzed. The distance from the center of incisive papilla to the labial incisal one-third of central incisor is between 7.18 to 11.51 mm, with the mean of 9.21 mm; the line drawn between canines pass middle of the incisive papilla is 72.84%, and pass posterior of the incisive papilla is 4.94%, and 22.22% between middle and posterior of incisive papilla. The result of this study can be used as a guide line in fabrication of the maxillary occlusion rim in Taiwanese population.

Keywords: incisive papilla, complete denture, partial denture, overdenture, implant denture, occlusion rim

Correspondence: Tsau-Mau Chou

Address: 100, Shih-Chuan 1st Road, San Ming District, 807 Kaohsiung City, Taiwan. TEL: 07-3121101-7003

FAX: 07-3210637

Submitted: January, 20, 2004 Accepted: February, 21, 2004

(3)

Introduction

In 1948, Harper suggested that the incisal edges of the upper central incisors should be 5 to 8 mm in front of the center of the papilla. He also discovered that the papilla cannot be depended upon as a guide in marking the mid-line in edentulous cases. In only 58% of the cases was the center of the papilla lined up with the center of the face. One of his conclu-sions was that the incisive papilla is a depend-able basis for a technique designed to repro-duce the horizontal and vertical position of the maxillary central incisor, today we still use the papilla to determine the horizontal posi-tion of the maxillary central incisor. Harper didn't give the number of cases that he used in his study. He also related the center of the in-cisive papilla to the canines. He drew a line from the center of the incisive papilla to the canines. He felt that if the line passed within the anterior half of the canines, the anterior arch will have a normal contour and when it passes through the distal half of the canine, then the arch will be flat 1_.

In 1960, McGee notes that the incisive papilla remains in a constant position after tooth loss. The lingual surface of natural max-illary central incisors touch the incisive pa-pilla or is just anterior to it. The bucco-lingual measurement of the maxillary centrals ranged from 6.8 mm to 8.6 mm with an average of 7. 7 mm. Since the centrals are slightly anterior to the center of the incisive papilla, he used 8 mm as the position of the labial surface for the

average patient. "This position may be altered in an anterior or posterior direction to meet the requirements of the individual patient 2_."

In 1964, Schiffman found that a line drawn through the center of the papilla to the canines, passed through the cusp tips 78% of the time. If you included an area of 1 mm ante-rior and 1 mm posteante-rior to the center of the papilla you crossed the canine cusps 92% of the time 3_.

In 1979, Ortman and Taso collected 38 casts in the sample. The average distance be-tween the most anterior point of the maxillary central incisors and the most posterior point of the incisive papilla was 12.454 mm with a standard deviation of 3.867 mm. This distance was measured when these two points were pro-jected on a plane parallel to the reference plane formed by the tips of three symmetrically lo-cated interdental papillae 4_.

In 1987, Grave et al. founded that the in-cisive papilla provides a reference point on the edentulous cast that may be helpful in deter-mining the anteroposterior position of the ar-tificial incisors. The results of their study sug-gest that the labial surface of the maxillary incisors should be 12 to 13 mm from the pos-terior border of the incisive papilla 5_.

In 2004, Aaron cited Eckert, who stated that the labial surfaces of the central incisors are usually 8 to 10 mm in front of the papilla

6_.

The objective of this study is to find the relationship of central incisor and canine to

(4)

ese population, and it can be used as a guide line in fabrication of maxillary occlusion rim in Taiwanese population.

Material and method

The study is composed of 81 dental casts both jaws with an average age of 22 years old. Subjects are currently dental school stu-dents of Kaohsuing Medical University. Casts were done in a standard way used by dentists. Because of the young age of the participants,

lems that could disfigure or affect the face and dentition. They were from all around the Tai-wan representing no specific region. Each sub-ject was asked to keep the mouth half open as the impression material alginate on tray sets in for a few minutes. The cast was imme-diately filled with the Type III stone Fig. 1 . We measure the distance of from the cen-ter of incisive papilla to the labial incisal one-third of central incisors Fig. 2 by Digimatic

Fig1. Study cast Fig2. measure the distance of from the center of inci-sive papilla to the labial incisal one-third of cen-tral incisor

Fig3. Digimatic caliper (Mitutoyo corporation, Japan, sensitive to 0.01 mm)

Fig4. measure the line drawn between the canines pass middle, posterior, or between middle and poste-rior of the incisive papilla

(5)

caliper Mitutoyo corporation, Japan, sensi-tive to 0.01 mm Fig. 3 . We also measure the lines drawn between the canines pass middle, posterior, or between middle and pos-terior of the incisive papilla Fig. 4 , all measurements were done by the same authors, to assess intraobserver error. All data were ana-lyzed with Excell 2000.

Results

The distance from the center of incisive papilla to the labial incisal one-third of cen-tral incisors is between 7.18 to 11.51 mm, with the mean of 9.21 mm Table 1 ; the line drawn between canines pass middle of the in-cisive papilla is 72.84%, pass posterior of the incisive papilla is 4.94%, and 22.22% between middle and posterior of the incisive papilla Table 2 . The result of this study can be used

as a guideline in fabrication of maxillary oc-clusal rim for Taiwanese population.

Discussion

A common average position of the max-illary anterior teeth to constant landmarks has been found by measuring hundreds of casts of natural healthy teeth. Measurement of the dis-tance from the incisal labial one-third of the maxillary central incisors to the center of in-cisive papilla can help us decided the upper anterior teeth position during denture fabrication. Incisive papilla is a pad of fibrous connective tissue overlying bony exit of naso-palatine blood vessels and nerves. It should not be compressed or displaced during impres-sion making. Denture pressure on this can cause paresthesia or pain. During denture fabrication, central incisors should be 8-10

(6)

The incisive papilla was simply consid-ered as a protective covering for the incisive foramen. By considering preextraction and postresorption casts of the same person, Harper concluded that there is no change in the posi-tion or dimensions of the papilla from the den-tate stage to the edentulous stage1_{. The}

inci-sive papilla provides a reference point on the edentulous cast that may be helpful in deter-mining the anteroposterior position of the ar-tificial incisors. It is common to use the poste-rior border of the papilla as the part likely to be least affected by the changes in anatomy of the region 5_.

Watt stated that "The average distance from the middle of the incisive papilla to the middle of the labial surface of the upper cen-tral incisor is approximately 10 mm; it is sel-dom less than 8 mm 8_.

Alan said that the bases which carry the occlusion rims should be rigid and stable. The upper rim is modified to give correct lip support. The incisive papilla provides a use-ful biometric guide to the prominence of the rim, its center lying 8-10mm palatal to the la-bial surfaces of the maxillary central incisors in the natural dentition . Patients' wishes, or previous satisfactory dentures, may dictate otherwise 9_.

Many studies find that the distance from the center of incisive papilla to the labial in-cisal one-third of the central incisors is

be-the line drawn between be-the canines pass middle of the incisive papilla, it means that the line drawn through the center of the papilla out to the canines, passed through the cusp tips of the time, and central incisors should be 8-10 mm anterior to the midpoint of the incisive papilla. Therefore, the dentists in Taiwan can use this result as a guide line in fabrication of the complete denture.

Conclusions

The fundamental results of this experi-ment can be served as the standards for the production and teeth selection of the complete denture, removable partial denture, overdenture and implant supported overdenture, the selected group of this experi-ment are Taiwanese youngsters between aged 21 to 24, and the results of this experiment are almost identical with the results gained from experiments testing on Caucasian group, the most plausible explanation is that after the World War II the Taiwanese are well-nourished, and nutrition is grate correlation with arch development. The further research is necessary on account that posterior arch width and anterior-posterior arch length are closely related with this experiment.

References

1. Harper, R.N., The incisive papilla. J Dent Res 1948; 27: 661-8.

2. McGee, G.F., Tooth placement and base con-tour in denture construction. J Prosthet Dent

(7)

1960; 10:651-7.

3. Schiffman, P. Relation of the maxillary ca-nines to the incisive papilla. J Prosthet Dent 1964; 14:469-72.

4. Ortman, H.R. and Tsao, D.H. Relationship of the incisive papilla to the maxillary cen-tral incisors. J Prosthet Dent 1979; 42: 492-6.

5. Grave A.M.H. Evaluation of the incisive papilla as a guide to anterior tooth position. J Prosthet Dent 1987; 57: 712-4.

6. Fenton A.H. Selecting and arranging pros-thetic teeth and occlusion for the edentulous patient. In: Eckert. Jacob. Fenton A.H. Mericske-Stern, editors. Prosthodontic treat-ment for edentulous patients. 12th ed. St. Louis: Mosby; 2004. p. 310.

7. Board review: Removable prosthodontics/ complete dentures

http://dental.columbia.edu/class_sites/ sdos2006/class/prostho/removable/ prosboard.pdf

8. Watt, M.D. Designing Complete Dentures. Philadelphia: W.B. Saunders Co.; 1976. 9. Alan Ogden Honorary Curator . Guidelines

in Prosthetic and Implant Dentistry. London: Quintessence Publishing; 1996.
