Energy dependent carrier relaxation

in self-assembled InAs/GaAs quantum dots

H. S. Ling*, 1

, C. P. Lee1

, S. Y. Wang2

, and M. C. Lo1

1 _{Department of Electronic Engineering, National Chiao Tung University, Hsinchu 300, Taiwan} 2 _{Institute of Astronomy and Astrophysics, Academia Sinica, P.O. Box 23-141, Taipei, Taiwan}

Received 5 October 2007, 24 October 2007, accepted 13 December 2007 Published online 2 June 2008

PACS 78.55.Cr, 78.67.Hc

*_{Corresponding author: e-mail}_{[email protected]}

1 Introduction Self-assembled quantum dots (QDs) grown on lattice mismatched material systems using Stran-ski-Krastanov growth mode have found applications in many optoelectronic devices, such as quantum dot lasers [1] and quantum dot infrared photodetectors [2]. For these applications, it is important to understand the relaxation mechanism of carriers in such system with discrete energy levels. A lot of efforts have been made on the study of car-rier relaxation mechanisms for self-assembled QDs by va-rious spectral techniques [3-12].

It is well known that energy relaxation of carriers in QDs cannot be achieved by simply interaction with acous-tic phonons due to large separation in quantized energy levels. Other channels such as Auger-type scattering [13] and/or multi-phonon scattering [14] are needed to facilitate the relaxation.

Carrier relaxation assisted by phonon scattering is based on the principle of weak coupling between carrier and phonon. In the weak coupling regime, phonons do not contribute to the energy states of the QD but only cause carrier scattering between states. So when inhomogeneous QDs are probed by selective excitation PL (SEPL) or PL-excitation (PLE) technique, the multi-LO-phonon filtered transition could be observed [8-12]. On the other hand, if the correlation between carriers and phonons becomes so

strong that the energy spectrum of QD is enormously modified, strong coupling should be considered. In this re-gime, the new set of eigen-states associated with polaron is treated in the QD system. The relaxation mechanism of po-larons, different from the principle of scattering, is a co-herent flopping (Rabi flopping) between eigen-states [15]. In this case, the feature of anti-crossing has also been ob-served under magnetic fields [16-17].

Among the previous published results, carrier relaxa-tions with or without multi-phonon filtering were both re-vealed [3-12]. These two types of behavior can be distin-guished by the relaxation energy. When different QD sub-sets in a sample are selectively excited with energies smaller than the wetting layer (WL) absorption edge, the resonant electronic transitions should reveal the size de-pendent relaxation peaks due to the quantization. If the transitions undergo multi-phonon filtering, the relaxation spectra reveal the characteristic of certain LO-phonon rep-lica. The possible reason for samples showing separately these two features has been attributed to the existence of competing non-radiative recombination channel [12].

In this study, with a single sample, both features were observed with different regions of excitation energies. This energy dependent relaxation mechanism is investigated and explained.

We performed the selective excitation photoluminescence (SEPL) spectroscopy studies on InAs/GaAs self-assembled quantum dots (QDs). Under different excitation energies, dif-ferent groups of QDs are selected and emit light. The excited carriers relax to the ground state through different mecha-nisms when excited at different energies. Three distinct gions with different mechanisms in carrier excitation and

laxation are identified in the emission spectra. These three re-gions can be categorized, from high energy to low energy, as continuum absorption, electronic state excitation, and multi-phonon resonance. The QDs’ special joint density-of-state tail extending from the wetting layer peak facilitates the carrier relaxation and was suggested to explain these spectral results.

(2)

2710 H. S. Ling et al.: Energy dependent carrier relaxation in self-assembled InAs/GaAs QDs

physica

p s s

status

solidi

c

2 Samples and experiments The QD samples used in this study were grown by molecular beam epitaxy with valved cracker As source on (001) semi-insulating GaAs substrates. Single InAs QD layer with 150nm GaAs barrier layers and an additional QD layer with the same growth condition for atomic force microscope (AFM) measure-ment was grown in each sample. Two samples with differ-ent sizes were prepared. For sample A, 2.6MLs of InAs was deposited at 520 oC. It results in lens shaped QDs with average height of 9 nm and a diameter of 47 nm. For sam-ple B, only 2.4MLs were used at 480 oC. The average height was only 1.5nm, and the base diameter was about 17nm. The SEPL and the PLE spectra of the QDs were measured at 13 K. Because of the different QD sizes, the two samples exhibit different transition energies. At 13 K, the ground-state emission peak of sample A is at 1.168 eV, while for sample B the transition energy is about 1.269 eV.

Figure 1 SEPL spectra of sample A taken at 13K. The cross on the right hand side of each spectrum shows the position of excita-tion energy.

3 Discussions The SEPL spectra for sample A is shown in Fig. 1. The excitation energy varied from 1.378 eV to 1.211 eV with the corresponding spectra arranged from top to bottom. The position of excitation energy is in-dicated by the cross on the right hand side. They were all below the WL ground state energy (around 1.45 eV deter-mined from the high power PL spectrum shown in the in-set) to ensure that only the QD layer could absorb the pumping photons. Note that all spectra in Fig. 1 were ex-cited with low power (~1 W/cm2) to exclude any excited-state emission and also to suppress Auger scattering. When Eex > 1.34 eV, the luminescence spectra show a broad peak indicating all QDs were excited. As the excitation energy

decreased, fine structures with narrower peaks were ob-served in the spectra, because only certain sub-ensembles were resonantly excited due to the discrete density of states.

If we plot the spectra versus the relaxation energy, i.e., Eex - Edet , detailed information about these peaks emerges. The result is shown in Fig. 2. The sharp peaks line up ver-tically in the same positions. The peak values of Eex - Edet correspond exactly to the multi-LO-phonon energies. Only the QDs with the excited states at multiple phonon energies above the ground state are selectively excited. When the excitation energy increases above a certain value, a differ-ent excitation scheme was observed. Both the emission peak energy and Eex - Edet varied with the excitation energy. Three distinct regions in the PL spectra under different ex-citation energies are designated as regions I, II and III re-spectively.

Figure 2 The SEPL spectra in Fig. 1 were plotted versus Eex -

Edet here, with intensity normalized to 1 for better clarity.

The broad emission spectra with peaks denoted by filled circles in region I indicate the whole QDs can absorb light and also have efficient carrier relaxation. For a self-assembled QD, the joint density of states between bound states and delocalized states [18] give rise to a quasi-continuous absorption region extending downward from the WL bandedge [19]. Therefore, when Eex is lower than the WL peak but higher than the QD bound states, the ex-cited carriers can relax energy to the ground state through the continuous tail, cascaded by multi-LO-phonon emis-sion. The mechanism of energy rolling down can be pri-marily due to the interaction with acoustic phonons. In this excitation regime, although Eex is lower than the WL band-edge, no selective excitation will occur because the excited electron and hole are not both localized. Thus the emission spectrum is basically the same as that from conventional PL measurement.

(3)

phys. stat. sol. (c) 5, No. 9 (2008) 2711

Article

The density of states for such continuum decreases gradually towards the lower energy. Once the excitation energy of the pumping photons is low enough to reach the discrete levels of the QDs, the sharp levels enhance the ab-sorption through resonant excitation. Note that the reso-nantly absorbed QDs still have a distribution in ground-state energy due to the fluctuations in shape, strain, and composition. At low excitation energies, when the carriers are resonantly excited to states below the continuum tail, the only way for them to relax to the ground state is through the multi-phonon process. The sharp peaks in the bottom few emission spectra are therefore signatures of va-rious multi-phonon processes. Three phonon lines marked as vertical straight lines in Fig. 2 were clearly observed, and they were assigned as, from left to right, 2LO WL phonon peak (56 meV), 3LO WL phonon peak (83 meV) and 3LO QD phonon peak (100 meV). This assignment gi-ves the energy for the WL phonon to be ~27.8 meV and the QD phonon to be ~33.3 meV. These values are very close to that in ref. 9. The strong phonon confinement in the thin WL lowers the energy of LO phonons, but in QDs, the strain effect dominates and increases the LO phonon energy [10].

The spectra in region II showed different characteris-tics due to a different carrier relaxation scheme. With such excitation energy, the QDs are still selectively excited through resonant excitation to the discrete states of the QDs. These states, however, are high in energy and are within the continuum tail of the joint density-of-states. The relaxation of the excited carriers can therefore still be achieved by the help of the continuum states in addition to the multi-LO-phonon scattering. With the help of the con-tinuum states, the energy separation of the excited state and the ground state does not have to be exactly the same as the multi-LO-phonon energies. Because the states are within the continuum tail, the excited electron-hole pairs can change their discrete natures in density-of-state by part with energy conserved, say, the electron can transfer en-ergy to the hole and push the hole to the continuous hole states. The efficiency of this electron-hole scattering has been confirmed [20-22]. As soon as the hole is pushed to the continuous states, the efficient relaxation channel men-tioned in region I works. Therefore, the process of elec-tron-hole scattering cascaded by phonon scattering ex-cludes phonon bottleneck and explains the spectra in re-gion II in Fig. 2. The difference between the excitation en-ergy and the emission enen-ergy, therefore, reflect the size dependent excited-state separations in the QDs. We notice that the emission peaks become narrower as we enter the resonant excitation regions (region II and III). This is be-cause the resonant excitation selects certain QDs with spe-cific energy levels. The narrowest peaks belong to those at very low excitation energies because the selected QDs need to satisfy not only the resonant excitation condition but also an additional requirement of multi-phonon reso-nance.

As described above, if the excited states of QDs are high enough in energy and are within the continuum tail, the resonantly excited carriers have efficient channels to relax energy to give ground-state emission. The spectra under selective excitation technique will thus not be fil-tered by LO-phonon energies. To further prove this idea, the sample with ultra small InAs QDs was studied. The reason for choosing small QDs is: the closeness of the high energy quantized states to the WL state ensures the pres-ence of the continuum tail, which assist carrier relaxation to the ground state.

Figure 3 SEPL spectra of sample B taken at 13 K. The x-axis re-fers to E_ex - E_det.

The SEPL spectra of sample B, which has small QDs, are shown in Fig. 3. Each spectrum was plotted versus Eex - Edet , and the intensity was normalized to 1 for better clarity. All excitation energies were also below the WL bandedge, which was 1.43 eV in this case (determined by the PLE spectrum shown in the inset). The excitation scheme of the highest few curves in Fig. 3 belongs to region I as previ-ously mentioned. When Eex is lower than around 1.41eV, two peaks associated with resonant excitation emerge, and they become prominent when Eex is even lower. These two peak series are labeled by (1) and (2) in Fig. 3. It is clear that the two peaks do not line up vertically, although they are within the energy range achievable by triple of com-mon LO-phonons. This indicates that they have high effi-ciency in relaxation without suffering any phonon bottle-neck. The result agrees with our previous assumption that the excited-states of QDs in sample B, of which the dot size is very small, are high enough in energy to touch the continuum tail. For the sharp peaks that are located rigidly at 35 meV, because of this characteristic energy, they were tentatively attributed to the Raman process associated with the interface phonons in the QD structure [10, 23].

4 Conclusions The energy spectra of InAs/GaAs self-assembled QDs have been studied using selective excita-tion photoluminescence. The dependence of the emission

(4)

2712 H. S. Ling et al.: Energy dependent carrier relaxation in self-assembled InAs/GaAs QDs

physica

p s s

status

solidi

c

spectra on the excitation energy provides fruitful informa-tion on the carrier relaxainforma-tion mechanism. Three distinct re-gions can be identified as the excitation energy changes. At high excitation energies, all quantum dots are excited and participate in the emission with the help of the continuum states. At low excitation energies, because of the absence of the continuum states, carrier relaxation has to be facili-tated by a multi-LO-phonon process. So only the QDs with excited states at certain multi-LO-phonon energies above the ground state can absorb and emit light. At medium en-ergy, the QDs are resonantly excited through discrete elec-tronic states. But the relaxation of the carriers does not need to satisfy the multi-phonon resonance condition with the help of continuum tail. The electron-hole scattering provides an efficient channel for the electron to lose its large quantized energy first and then the hole can release energies in cascade to the ground state by emitting pho-nons.

Acknowledgments This work was financially supported by the National Science Council under contract No. NSC 94-2215-E-009-010 and the ATU program of the Ministry of Educa-tion under contract No. 95W803.
