Synthesis and Characterization of Metal Complexes
Possessing the 5-(2-Pyridyl) Pyrazolate Ligands: The
Observation of Remarkable Osmium-Induced Blue
Phosphorescence in Solution at Room Temperature
Pei-Chi Wu,
†Jen-Kan Yu,
‡Yi-Hwa Song,
†Yun Chi,*
,†Pi-Tai Chou,*
,‡Shie-Ming Peng,
‡and Gene-Hsiang Lee
‡Department of Chemistry, National Tsing Hua University, 300, Hsinchu, Taiwan, Republic of China, and Department of Chemistry and Instrumentation Center,
National Taiwan University, 106, Taipei, Taiwan, Republic of China Received July 13, 2003
A total of three distinctive main group and transition metal complexes containing the 2-pyridyl pyrazolate (pypz) ligand were prepared, namely, [B(C6F5)2(pypz)] (1), [Ru(CO)2 -(pypz)2] (2), and [Os(CO)2(pypz)2] (3), where (pypz)H ) 3-trifluoromethyl-5-(2-pyridyl)pyrazole. Single-crystal X-ray diffraction studies were carried out on complexes 2 and 3, revealing octahedral coordination geometry with two CO ligands located at cis dispositions. While the pypz ligand arrangement for complex 2 is in cis-(Npy,Npy) and trans-(Npz,Npz), complex 3 reveals a different configuration, cis-(Npz,Npz) and trans-(Npy,Npy) (Npy for pyridine-N and Npzfor pyrazolate donor sites). Similar to that of the in-situ-prepared pypz anion, the boron complex [B(C6F5)2(pypz)] (1) exhibits a strong emission centered at 380 nm, which is unambiguously assigned to fluorescence derived from the S1(ππ*) f S0transition. In contrast to the nonluminescent behavior for Ru complex 2, the Os complex 3 displays unique, strong room-temperature phosphorescence, showing vibronic progressions at 430, 457, and 480 nm. The remarkable differences in photophysical properties were rationalized by a combination of π-electron accepting CO ligand, relative pypz orientation, and heavy-atom-enhanced spin-orbit coupling effects.
1. Introduction
Third-row transition metal complexes incorporating simple polypyridine ligands,1 such as 2,2′-bipyridine (bpy) or 1,10-phenanthroline (phen), and cyclometalated ligands,2such as 2-phenylpyridine and benzoquinoline, have attracted a great deal of interest in recent years. Research in this area was principally motivated by the use of these complexes in the study of excited-state electron and energy transfer3 as well as the potential applications in the fabrication of organic light-emitting diodes (OLEDs).4 Isoelectronic transition metal ions such as Re(I), Os(II), and Ir(III), possessing a unique d6-electron configuration, are particularly attractive because of their strong metal-ligand interaction,
long-lived excited states, and high luminescence efficiencies, which significantly improve the likelihood of energy transfer prior to radiative or nonradiative relaxation. The strong spin-orbit coupling expected for these heavy metal ions, with atomic numbers Z ) 75-77, would lead to an efficient intersystem crossing from the singlet excited state to the triplet manifold. Furthermore, mixing singlet and triplet excited states via spin-orbit coupling, to a great extent, would also remove the spin-forbidden nature of the T1 f S0 radiative relaxation, resulting in highly intense phosphorescent emission. On the basis of these concepts, polypyridine and cyclom-etalated types of ligands tend to form rigid molecular frameworks with the aforementioned metal ions and then give rise to desirable absorption and emission characteristics. More specifically, they normally display intense ligand-centered π-π* chromophores in the ultraviolet region and a weaker metal-to-ligand charge transfer (MLCT) transition in the lower energy, visible region. The strong absorption and emission character-istics derived from the π-π* and MLCT energy levels †National Tsing Hua University.
‡National Taiwan University.
(1) (a) Juris, A.; Balzani, V.; Barigelletti, F.; Campagna, S.; Belser, P.; Von Zelewsky, A. Coord. Chem. Rev. 1988, 84, 85. (b) Constable, E. C.; Steel, P. J. Coord. Chem. Rev. 1989, 93, 205. (c) Balzani, V.; Juris, A. Coord. Chem. Rev. 2001, 211, 97. (d) Serroni, S.; Campagna, S.; Puntoriero, F.; Di Pietro, C.; McClenaghan, N. D.; Loiseau, F. Chem. Soc. Rev. 2001, 30, 367.
(2) (a) Beeby, A.; Bettington, S.; Samuel, I. D. W.; Wang, Z. J. Mater. Chem. 2003, 13, 80. (b) Colombo, M. G.; Guedel, H. U. Inorg. Chem.
1993, 32, 3081. (c) Lu, W.; Mi, B.-X.; Chan, M. C. W.; Hui, Z.; Zhu, N.;
Lee, S.-T.; Che, C.-M. Chem. Commun. 2002, 206. (d) Song, D.; Wu, Q.; Hook, A.; Kozin, I.; Wang, S. Organometallics 2001, 20, 4683.
(3) (a) Treadway, J. A.; Loeb, B.; Lopez, R.; Anderson, P. A.; Keene, F. R.; Meyer, T. J. Inorg. Chem. 1996, 35, 2242. (b) Fleming, C. N.; Maxwell, K. A.; DeSimone, J. M.; Meyer, T. J.; Papanikolas, J. M. J. Am. Chem. Soc. 2001, 123, 10336. (c) Chardon-Noblat, S.; Deronzier, A.; Hartl, F.; Van Slageren, J.; Mahabiersing, T. Eur. J. Inorg. Chem.
2001, 613.
(4) (a) Lamansky, S.; Djurovich, P.; Murphy, D.; Abdel-Razzaq, F.; Lee, H.-E.; Adachi, C.; Burrows, P. E.; Forrest, S. R.; Thompson, M. E. J. Am. Chem. Soc. 2001, 123, 4304. (b) Lamansky, S.; Djurovich, P.; Murphy, D.; Abdel-Razzaq, F.; Kwong, R.; Tsyba, I.; Bortz, M.; Mui, B.; Bau, R.; Thompson, M. E. Inorg. Chem. 2001, 40, 1704. (c) Brooks, J.; Babayan, Y.; Lamansky, S.; Djurovich, P. I.; Tsyba, I.; Bau, R.; Thompson, M. E. Inorg. Chem. 2002, 41, 3055. (d) Carlson, B.; Phelan, G. D.; Kaminsky, W.; Dalton, L.; Jiang, X. Z.; S., L.; Jen, A. K.-Y. J. Am. Chem. Soc. 2002, 124, 14162.
10.1021/om034037e CCC: $25.00 © 2003 American Chemical Society Publication on Web 10/24/2003
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
make them suitable for use as the luminescent phos-phors for future light-harvesting and OLED applica-tions, respectively.5
In this paper, we wish to report the synthesis and characterization of a new series of 5-(2-pyridyl) pyra-zolate (pypz) metal complexes with formula [M(CO)2 -(pypz)2] where M ) Ru (2) or Os (3-5) (see Figure 1). The structural and chemical characteristics of the 2-pyridyl pyrazole (pypz)H are akin to those of 2,2′ -bipyridine and 2-phenylpyridine ligands in that 2-py-ridyl pyrazole is capable of using two of its nitrogen atoms to generate a five-membered ring metal chelate interaction.6 Moreover, due to its strong acidity,7 the pyrazole site will readily lose a proton from the NH fragment to form a stable anionic ligand, subsequently producing neutral chelate complexes which, in sharp contrast to typical bipyridine ruthenium and osmium
complexes reported in the literature, have a high tendency to form ionic metal complexes. The strong σ-donor property of the pyrazolate, together with the
π-accepting ability of the second pyridyl fragment,8may
provide a synergism of the electron delocalization so that the electron density is transferred from the pyrazolate to the metal ion and back to the pyridyl side of the ligand, enhancing the metal chelate interaction. For another comparison, although 2-phenylpyridine is ef-fective in forming stable cyclometalated complexes with Rh(III), Ir(III), and Pt(II) ions,9 it was rather inert to the Ru(II) and Os(II) metal ions and particularly, to our knowledge, failed to afford any Os(II) complexes.10 Alternatively, 2-pyridyl pyrazole is expected to extend the chemistry of 2-phenylpyridine, providing a great potential to isolate the respective Ru(II) and Os(II) complexes. On the basis of this strategic design, the resulting new series of 2-pyridyl pyrazoles incorporating Os(II) and Ru(II) complexes revealed remarkably dif-ferent photophysical properties from previously reported analogues in that a strong ligand phosphorescence was resolved for [Os(CO)2(pypz)2] complexes in room-tem-perature solution phase. Detailed results and discussion are elaborated in the following sections.
2. Experimental Section
2.1. General Information and Materials. Mass spectra
were obtained on a JEOL SX-102A instrument operating in electron impact (EI) mode or fast atom bombardment (FAB) mode. 1H and 13C NMR spectra were recorded on Varian Mercury-400 or INOVA-500 instruments; chemical shifts are quoted with respect to the internal standard tetramethylsilane for1H and13C NMR data. Elemental analyses were carried out at the NSC Regional Instrumentation Center at National Chao Tung University, Hsinchu, Taiwan. The pyrazole chelate ligands, 3-trifluoromethyl-5-(2-pyridyl)pyrazole, (pypz)H, 3-pen-tafluoroethyl-5-(2-pyridyl)pyrazole, (pypz2)H, and 3-trifluo-romethyl-5-(4-methyl-2-pyridyl)pyrazole, (pypz3)H, were pre-pared according to the methods reported in the literature.11 All reactions were performed under a nitrogen atmosphere using anhydrous solvents or solvents treated with an ap-propriate drying reagent.
Synthesis of Complex 1. A 50 mL reaction flask was
charged with 200 mg of B(C6F5)3(0.38 mmol) and 30 mL of anhydrous THF solvent. To this solution was added 70 mg of 3-trifluoromethyl-5-(2-pyridyl)pyrazole, (pypz)H (0.34 mmol), and the mixture was stirred at room temperature for 12 h. After that, the solution was concentrated to dryness and the resulting oily residue was purified by recrystallization from a mixed solution of CH2Cl2 and methanol, giving a colorless crystalline solid, [B(C6F5)2(pypz)] (1) (90 mg, 0.16 mmol, 48%). Spectral data of 1: MS (EI), m/z 557, M+; 538, (M - F)+; 390, (M - C6F5)+.1H NMR (400 MHz, CDCl3, 294 K): δ 8.59 (dd,3J
HH) 6.0 Hz,4JHH) 1.2 Hz, 1H, CHpy), 8.28 (ddd,3JHH
(5) (a) Baldo, M. A.; Lamansky, S.; Burrows, P. E.; Thompson, M. E.; Forrest, S. R. Appl. Phys. Lett. 1999, 75, 4. (b) Wang, Y.; Herron, N.; Grushin, V. V.; LeCloux, D.; Petrov, V. Appl. Phys. Lett. 2001, 79, 449. (c) Adachi, C.; Kwong, R. C.; Djurovich, P.; Adamovich, V.; Baldo, M. A.; Thompson, M. E.; Forrest, S. R. Appl. Phys. Lett. 2001, 79, 2082. (d) Jiang, X.; Jen, A. K.-Y.; Carlson, B.; Dalton, L. R. Appl. Phys. Lett.
2002, 80, 713.
(6) (a) Jeffery, J. C.; Jones, P. L.; Mann, K. L. V.; Psillakis, E.; McCleverty, J. A.; Ward, M. D.; White, C. M. Chem. Commun. 1997, 175. (b) Chadghan, A.; Pons, J.; Caubet, A.; Casabo, J.; Ros, J.; Alvarez-Larena, A.; Piniella, J. F. Polyhedron 2000, 19, 855. (c) Pons, J.; Chadghan, A.; Casabo, J.; Alvarez-Larena, A.; Piniella, J. F.; Ros, J. Inorg. Chem. Commun. 2000, 3, 296.
(7) Tjiou, E. M.; Fruchier, A.; Pellegrin, V.; Tarrago, G. J. Heterocycl. Chem. 1989, 26, 893.
(8) (a) Hage, R.; Haasnoot, J. G.; Reedijk, J.; Vos, J. G. Chemtracts: Inorg. Chem. 1992, 4, 75. (b) Hage, R.; Haasnoot, J. G.; Reedijk, J.; Wang, R.; Vos, J. G. Inorg. Chem. 1991, 30, 3263.
(9) (a) Sprouse, S.; King, K. A.; Spellane, P. J.; Watts, R. J. J. Am. Chem. Soc. 1984, 106, 6647. (b) Chassot, L.; Von Zelewsky, A. Inorg. Chem. 1987, 26, 2814. (c) Grushin, V. V.; Herron, N.; LeCloux, D. D.; Marshall, W. J.; Petrov, V. A.; Wang, Y. Chem. Commun. 2001, 1494. (10) The 5-(2-pyridyl)phenyl ligand can coordinate to the Os atom, forming a five-membered chelate interaction. However, its parent compound was not prepared from oxidative addition, but from the metal exchange involving bis(2-pyridyl)phenylmercury and OsHCl-(CO)(PPh3)3; see: Clark, A. M.; Rickard, C. E. F.; Roper, W. R.; Wright, L. J. Organometallics 1999, 18, 2813.
(11) (a) Thiel, W. R.; Eppinger, J. Chem. Eur. J. 1997, 3, 696. (b) Singh, S. P.; Kumar, D.; Jones, B. G.; Threadgill, M. D. J. Fluorine Chem. 1999, 94, 199.
Figure 1. Structures of various B(III), Ru(II), and Os(II) complexes in this study.
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
) 8.0 Hz,3J HH) 7.7 Hz,4JHH) 1.2 Hz, 1H, CHpy), 7.92 (dd, 3J HH) 8.0 Hz,4JHH) 1.2 Hz, 1H, CHpy), 7.60 (ddd,3JHH) 7.7 Hz,3J HH) 6.0 Hz,4JHH) 1.2 Hz, 1H, CHpy), 6.99 (s, 1H, CHpz). 19F NMR (470 MHz, CDCl 3): δ -61.8 (s, 3F, CF3), -133.7 (s, 4F, CF), -154.1 (s, 2F, CF), -161.9 (s, 4F, CF). Anal. Calcd for C21H5BF13N3: N, 7.54; C, 45.28; H, 0.90. Found: N, 7.41; C, 45.21; H, 1.12.
Synthesis of Complex 2.
3-Trifluoromethyl-5-(2-pyridyl)-pyrazole, (pypz)H (620 mg, 2.91 mmol), Ru3(CO)12 (300 mg, 0.47 mmol), and hexane solvent (50 mL) were added to a 160 mL stainless steel autoclave. The autoclave was sealed and slowly brought up to 185 °C for 36 h. After that, the autoclave was cooled, the solvent was evaporated to dryness, and the solid residue was purified by column chromatography on SiO2, eluting with a 1:1 mixture of ethyl acetate and hexane. Only one major component was obtained. Removal of excess solvent produced a light yellow solid, which was purified by sublima-tion (150 mTorr/165 °C), followed by crystallizasublima-tion from a mixture of CH2Cl2/hexane, giving the ruthenium complex [Ru-(CO)2(pypz)2] (2) as colorless rectangular crystals (191 mg, 0.33 mmol, 70%).
Spectral data of 2: MS (EI, 70 eV), observed m/z (actual) [assignment]{relative intensity}: 582 (582) [M+]{2.88}, 526 (526) [M+- 2CO]{12.5}. IR (CH 2Cl2): ν(CO), 2076 (s), 2017 (s) cm-1.1H NMR (500 MHz, d 6-acetone, 294 K): δ 8.07-8.03 (m, 4H, Hpy), 7.38 (d, JHH) 1 Hz, 2H, Hpz), 7.32 (ddd, JHH) 6, 6, and 3 Hz, 2H, Hpy), 7.09 (dd, JHH) 6 and 1 Hz, 2H, Hpy). 13C NMR (125 MHz, d 6-acetone, 294 K): δ 194.7 (CO), 154.4 (Cpy), 150.7 (Cpz), 148.9 (CHpy), 146.7 (q,2JCF) 36.6 Hz, Cpz), 141.7 (CNpy), 124.5 (CHpz), 123.1 (q, 1JCF) 266.3 Hz, CF3), 121.7 (CHpy), 104.3 (CHpy).19F NMR (470 MHz, d6-acetone, 294 K): δ -60.2 (s). Anal. Calcd for C20H10F6N6O2Ru: C, 41.372; N, 14.68; H, 1.85. Found: C, 41.32; N, 14.46; H, 1.73.
Synthesis of Complex 3.
3-Trifluoromethyl-5-(2-pyridyl)-pyrazole (220 mg, 1.03 mmol) and finely pulverized Os3(CO)12 (150 mg, 0.165 mmol) were loaded in a 20 mL Carius tube and degassed. This mixture/solution was then sealed under vacuum and placed in an oven maintaining temperatures of 180-185 °C for 2.5 days, during which time its color changed gradually from light yellow to red-brown and finally to orange-yellow. After the reaction was stopped, the tube was cooled and opened, and the contents were dissolved in acetone. The insoluble material was filtered off, the filtrate dried under vacuum, and the residue sublimed (300 mTorr/185 °C). The product was then subjected to recrystallization in CH2Cl2and hexane, giving [Os(CO)2(pypz)2] (3) as colorless needlelike crystals (43 mg, 0.043 mmol) with a 39% yield.
Spectral data of 3: MS (EI, 70 eV), observed m/z (actual) [assignment]{relative intensity}: 672 (672) [M+]{2.88}, 616 (616) [M+- 2CO]{12.5}. IR (CH2Cl2): ν(CO), 2043 (s), 1973 (s) cm-1.1H NMR (400 MHz, d 6-acetone, 294 K): δ 9.17 (ddd, JHH) 6.0, 1.5, and 1.0 Hz, 2H, Hpy), 8.20 (ddd, JHH) 8.0, 8.0, and 1.5 Hz, 2H, Hpy), 8.10 (ddd, JHH) 8.0, 1.5, and 1.0 Hz, 2H, Hpy), 7.48 (ddd, JHH) 8.0, 6.0, and 1.5 Hz, 2H, Hpy), 7.10 (s, 2H, Hpz).13C NMR (125 MHz, d6-acetone, 294 K): δ 177.6 (CO), 157.1 (CNpy), 155.8 (Cpy), 151.7 (Cpz), 144.1(q,2JCF) 35.5 Hz, Cpz), 141.3 (CHpy), 125.2 (CHpy), 123.1 (q,1JCF) 265.7 Hz, CF3), 121.6 (CHpy), 103.4 (CHpz). 19F NMR (470 MHz, d6 -acetone, 294 K): δ -60.2 (s). Anal. Calcd for C20H10F6N6O2 -Os: C, 35.82; N, 12.53; H, 1.50. Found: C, 35.67; N, 12.84; H, 1.78.
Synthesis of Complex 4. The procedures were identical
to those of complex 3, with the exception that 150 mg of Os3 -(CO)12 (0.165 mmol) and 270 mg of 3-pentafluoroethyl-5-(2-pyridyl)pyrazole (pypz2)H (1.03 mmol) were used. After being heated for 3 days, the crude product was purified by sublima-tion (0.38 Torr, 210 °C) and recrystallizasublima-tion from CH2Cl2and hexane, giving a colorless crystalline solid, [Os(CO)2(pypz2)2] (4, 55 mg, 0.071 mmol), with a 43% yield.
Spectral data of 4: MS (EI, 70 eV), observed m/z (actual) [assignment]{relative intensity}: 772 (772) [M+]{1.96}, 716
(716) [M+- 2CO]{9.74}. IR (CH 2Cl2): ν(CO), 2043 (s), 1973 (s) cm-1.1H NMR (500 MHz, d 6-acetone, 294 K): δ 9.17 (ddd, JHH) 6.0, 1.5, and 1.0 Hz, Hpy), 8.19 (ddd, JHH) 8.0, 8.0, and 1.5 Hz, Hpy), 8.11 (ddd, JHH) 8.0, 1.5, and 1.0 Hz, 2H, Hpy), 7.47 (ddd, JHH) 8.0, 6.0, and 1.5 Hz, 2H, Hpy), 7.08 (s, 2H, Hpz).13C NMR (125 MHz, d6-acetone, 294 K): δ 177.8 (CO), 157.1 (CNpy), 155.9 (Cpy), 152.0 (Cpz), 142.4 (t,2JCF) 27.2 Hz, Cpz), 141.2 (CHpy), 125.1 (CHpy), 121.6 (CHpy), 119.9 (qt,1JCF ) 283.5 Hz,2J CF) 38.9 Hz, CF3), 112.4 (tq,1JCF) 247.0 Hz, 2J CF ) 38.3 Hz, CF2), 104.3 (CHpz).19F NMR (470 MHz, d6 -acetone, 294 K): δ -84.4 (s, CF3), -109.1 (d,3JFF) 276.8 Hz, CF), -111.4 (d, 3J
FF ) 276.8 Hz, CF). Anal. Calcd for C22H10F10N6O2Os: C, 34.31; N, 11.07; H, 1.51. Found: C, 34.29; N, 10.91; H, 1.31.
Synthesis of 5. In a fashion similar to the synthesis of
complex 3, 150 mg of Os3(CO)12(0.165 mmol) and 240 mg of 3-trifluoromethyl-5-(4-methyl-2-pyridyl)pyrazole, (pypz3)H (1.04 mmol), were used. After being heated for 4 days, the crude product was purified by sublimation (0.24 Torr, 220 °C), followed by recrystallization with CH2Cl2and hexane, giving a colorless crystalline solid [Os(CO)2(pypz3)2] (5, 34 mg, 0.048 mmol) with a 29% yield.
Spectral data of 5: MS (EI, 70 eV), observed m/z (actual) [assignment]{relative intensity}: 700 (700) [M+]{3.33}, 644 (644) [M+- 2CO]{14.9}. IR (CH 2Cl2): ν(CO), 2041 (s), 1970 (s) cm-1.1H NMR (400 MHz, d 6-acetone, 294 K): δ 8.97 (d, JHH) 6.0 Hz, 2H, Hpy), 7.95 (s, 2H, Hpy), 7.31 (d, JHH) 6.0 Hz, 2H, Hpy), 7.06 (s, 2H, Hpz), 2.58 (s, 6H, Me).13C NMR (125 MHz, d6-acetone, 294 K): δ 177.8 (CO), 156.2 (CNpy), 155.2 (Cpy), 153.7 (Cpy), 151.8 (Cpz), 144.0 (q,2JCF) 35.4 Hz, Cpz), 126.2 (CHpy), 122.3 (q,1JCF ) 241.8 Hz, CF3), 122.1 (CHpy), 103.1 (CHpz), 21.2 (Me).19F NMR (470 MHz, d6-acetone, 294 K): δ -59.8 (s). Anal. Calcd for C22H14F6N6O2Os: C, 37.82; N, 12.03; H, 2.02. Found: C, 37.69; N, 12.01; H 2.08.
2.2. Measurements. Single-crystal X-ray diffraction data
were measured on a Nonius Kappa or a Bruker SMART CCD diffractometer using λ(Mo KR) radiation (λ ) 0.71073 Å). The data collection was executed using the SMART program. Cell refinement and data reduction were made with the SAINT program. The structure was determined using the SHELXTL/ PC program and refined using full-matrix least squares. All non-hydrogen atoms were refined anisotropically, whereas hydrogen atoms were placed at the calculated positions and included in the final stage of refinements with fixed param-eters. Crystallographic refinement parameters of complexes
2 and 3 are summarized in Table 1, and the selective bond
distances and angles of these complexes are listed in Tables 2 and 3, respectively.
Steady-state absorption and emission spectra were recorded with a Hitachi (U-3310) spectrophotometer and an Edinburgh (FS920) fluorimeter, respectively. Nanosecond-microsecond lifetime studies were performed with an Edinburgh FL 900 photon-counting system with a hydrogen-filled lamp or a nitrogen lamp as the excitation source. The emission decays were analyzed by the sum of exponential functions, which allows partial elimination of instrument time broadening and thus renders a temporal resolution of∼200 ps. Occasionally, for the long-lived (.µs) emission species the lifetime was measured with the laser photolysis technique in which the third or fourth harmonic of an Nd:YAG laser (8 ns, Continuum Surlite II) was used as the excitation source, coupled with a fast response photomultiplier (Hamamatsu model R5509-72) operated at -80 °C. Typically, an average of 512 shots were acquired for each measurement. The transient absorption signal was recorded by a laser flash photolysis system (Edin-burgh LP920), in which an Nd:YAG laser (355 nm) pumped optical parametric oscillator and a white-light square pulse were used as pump and probe beams, respectively. The temporal resolution was limited by the excitation pulse dura-tion of∼8 ns.
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
3. Results
3.1. Preparation and Spectroscopic Character-ization. 2-Pyridyl pyrazole, (pypz)H, can readily react with various metal source reagents, affording metal chelate complexes in high yields. The first example is represented by the direct treatment of B(C6F5)3 and (pypz)H at room temperature, giving a tetrahedrally coordinated boron complex, [B(C6F5)2(pypz)] (1) (eq 1).
Characterization of this boron complex was achieved using the routine spectroscopic methods as well as the previously determined crystal structural data of the phenyl-substituted boron complex [B(C6H5)2(pypz)].12It was found that the pyridyl nitrogen atom (Npy) and the nearby nitrogen atom of the pyrazolate were both
coordinated to the boron atom, forming a five-membered C2N2B chelate interaction. A similar bonding arrange-ment was observed in other tetrahedrally arranged BPh2 complexes with chelating ligands, such as (2-pyridyl)-7-azaindole and (2-pyridyl)-7-indole.13
A similar straightforward route was applied to the synthesis of the transition metal carbonyl complexes involving Ru(II) and Os(II) cations. For the complex [Ru-(CO)2(pypz)2] (2), the reaction was best carried out in hexane, using a stainless steel autoclave to raise the reaction temperature to 185 °C. It is possible that the reaction proceeds in multistep processes involving prior cluster fragmentation14to afford mononuclear interme-diates such as Ru(CO)x, 4 e x e 2, together with
pyrazole addition, H2elimination, and CO displacement. The overall transformation is thus depicted as
The Ru complex 2 was isolated in ∼70% yield after conducting column chromatography and recrystalliza-tion. The electron impact mass spectrometry revealed molecular ion M+with the expected composition C20H10 -F6N6O2Ru, providing evidence for the incorporation of two pyridyl pyrazolate ligands. For the respective reac-tion with the heavy congener Os3(CO)12, due to its higher thermal stability and lower reactivity, the con-densation reaction was best carried out using a tech-nique of direct solid-state pyrolysis and employing a much longer reaction time of∼2.5 days. The osmium analogue complex [Os(CO)2(pypz)2] (3) was then ob-tained in 39% yield, after vacuum sublimation and recrystallization from a mixture of CH2Cl2and hexane at room temperature.
(12) Cheng, C.-C.; Chou, P.-T.; Peng, S.-M.; Lee, G.-H.; Wu, P.-C.; Song, Y.-H.; Chi, Y. Chem. Commun. 2003, 2628.
(13) (a) Liu, S.-F.; Wu, Q.; Schmider, H. L.; Aziz, H.; Hu, N.-X.; Popovic, Z.; Wang, S. J. Am. Chem. Soc. 2000, 122, 3671. (b) Liu, Q.; Mudadu, M. S.; Schmider, H.; Thummel, R.; Tao, Y.; Wang, S. Organometallics 2002, 21, 4743.
(14) (a) Johnson, B. F. G. Inorg. Chim. Acta 1986, 115, L39. (b) Bogdan, P. L.; Weitz, E. J. Am. Chem. Soc. 1990, 112, 639. Table 1. Crystal Data and Structure Refinement Parameters for Complexes 2 and 3
2 3
empirical formula C20H10F6N6O2Ru C20H10F6N6O2Os
fw 581.41 670.54
diffractometer Nonius KappaCCD Bruker SMART APEX
temperature 295(2) K 295(2) K
cryst syst orthorhombic monoclinic
space group Pbca P2/c
a 17.3441(2) Å 13.2724(7) Å b 13.4557(1) Å 13.5524(7) Å c 18.4594(2) Å 12.9716(7) Å β 109.229(1)° volume, Z 4308.00(8) Å3, 8 2203.1(2) Å3, 4 density (calcd) 1.793 Mg/m3 2.022 Mg/m3 abs coeff 0.811 mm-1 5.870 mm-1 F(000) 2288 1272 cryst size (mm3) 0.40× 0.40 × 0.30 0.28× 0.15 × 0.07 θ ranges 2.21 to 27.50° 2.21 to 27.50°
no. of reflns collected 22 777 17 612
no. of indep reflns 4940 [R(int) ) 0.0483] 5072 [R(int) ) 0.0290]
no. of data/restraints/params 4940/0/317 5072/0/372
goodness-of-fit on F2 1.063 1.026
final R indices [I>2σ(I)] R1) 0.0456, wR2) 0.1212 R1) 0.0240, wR2) 0.0550 R indices (all data) R1) 0.0825, wR2) 0.1403 R1) 0.0307, wR2) 0.0582
largest diff peak and hole 1.163 and -0.686 e Å-3 1.160 and -0.694 e Å-3
Table 2. Selected Bond Lengths [Å] and Angles [deg] for Complex 2
Ru-N(1) 2.136(3) Ru-N(2) 2.058(3) Ru-N(4) 2.140(3) Ru-N(5) 2.047(3) Ru-C(1) 1.892(4) Ru-C(2) 1.876(5) O(1)-C(1) 1.121(5) O(2)-C(2) 1.128(5) N(2)-N(3) 1.344(4) N(5)-N(6) 1.351(4) ∠N(1)-Ru-C(1) 174.4(1) ∠N(4)-Ru-C(2) 173.6(2) ∠N(1)-Ru-N(2) 77.5(1) ∠N(4)-Ru-N(5) 77.1(1) ∠N(2)-Ru-N(5) 163.7(1) ∠C(1)-Ru-C(2) 91.8(2) Table 3. Selected Bond Lengths [Å] and Angles
[deg] for Complex 3
Os(1)-N(1) 2.013(3) Os(1)-N(2) 2.087(3) Os(1)-C(1) 1.881(3) O(1)-C(1) 1.136(4) N(2)-N(3) 1.342(4) N(1)-C(6) 1.364(4) N(2)-C(7) 1.354(4) N(3)-C(9) 1.350(4) C(6)-C(7) 1.442(5) C(7)-C(8) 1.383(5) C(8)-C(9) 1.388(5) ∠N(1)-Os(1)-N(2) 77.3(1) ∠N(1)-Os(1)-N(1A) 169.0(1) ∠N(1)-Os(1)-N(2A) 94.7(1) ∠N(2)-Os(1)-C(1) 92.6(1) ∠N(2)-Os(1)-C(1A) 173.2(1) B(C6F5)3+ (pypz)H f [B(C6F5)2(pypz)] (1) + C6F5H (1) Ru3(CO)12+ 6(pypz)H f
3[Ru(CO)2(pypz)2] (2) + 3H2+ 6CO (2)
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
For Os complex 3, 1H, 13C, and 19F NMR studies confirmed the presence of 2-pyridyl pyrazolate and CO ligands in an expected ratio of 2:2 within the ligand sphere. An extension of preparing analogues of this Os complex is available by the variation of substituents on the 2-pyridyl pyrazolate ligand. This modification gave two additional derivative complexes, [Os(CO)2(pypz2)2] (4) and [Os(CO)2(pypz3)2] (5), pypz2 ) 3-pentafluoroet-hyl-5-(2-pyridyl) pyrazolate and pypz3 ) 3-trifluorom-ethyl-5-(4-methyl-2-pyridyl) pyrazolate. Their corre-sponding analytical and spectroscopic data as well as detailed spectral assignments are shown in the Experi-mental Section.
All three Os(II) complexes 3-5 show excellent ther-mal stability at temperatures∼200 °C as well as good photochemical stability upon exposure to intensive UV irradiation. Another unique feature is that the introduc-tion of a stronger electron-withdrawing substituent, such as CF3or C2F5, at the C(3) position of the pyrazole segment is indispensable to the successful preparation of the more robust third-row Os metal complexes. In this study, numerous attempts have been made to synthesize other [Os(CO)2(pypz)2] analogues based on methyl, tert-butyl, and phenyl substitution at the C(3) position, but unfortunately all failed, demonstrating the feasibility of synthesizing 3-5 mainly due to the greater reactivity of perfluoroalkyl-substituted pyrazole ligands.
3.2. Structural Characterization. Single-crystal X-ray diffraction studies were carried out to resolve the exact molecular structures. As depicted in Figure 2, the structure of 2 shows an octahedral coordination around the Ru atom. The 2-pyridyl pyrazolate ligands form five-membered chelate ring structures with the pyrazolate nitrogen atoms N(2) and N(5) located at trans disposi-tions, while the cis carbonyl fragments occupy the sites trans to the 2-pyridyl nitrogen atoms N(1) and N(4), which are also arranged in the cis (N,N) fashion. The coordination sequence of the pairs of donor centers CO, Npy, and Npz determines the observed cis-cis-trans conformation. The corresponding bond length and bond angle data are listed in Table 2. Metal-ligand bond angles found in this complex are within the range expected for typical octahedral Ru(II) complexes. The major deviation from a perfect octahedral coordination is caused by the smaller bite angles observed for the 2-pyridyl pyrazolate chelating interactions (∠ N(1)-Ru-N(2) ) 77.5(1)° and∠N(4)-Ru-N(5) ) 77.1(1)°), while the overall ligand arrangement in complex 2 resembles that of the structurally characterized Ru(II) complexes such as [Ru(CO)2(hfac)2],15[Ru(CO)2 (1,2-naphthoquinone-1-oximate)2],16and [Ru(CO)2(2-pyridylcarboxylate)2],17 possessing a pair of cis carbonyl ligands and the donor atoms of the bidentate chelates located in the remainder of the coordination sites. Moreover, the pyrazolate nitrogen atoms exhibit a much stronger donor interac-tion with the Ru(II) center than the dative interacinterac-tion
from the 2-pyridyl nitrogen atoms. Evidence for this viewpoint is provided by the significantly shorter N(pz) bond distances (N(2) ) 2.058(3) Å and Ru-N(5) ) 2.047(3) Å) versus those of the Ru-N(py) distances (Ru-N(1) ) 2.136(3) Å and Ru-N(4) ) 2.140-(3) Å). This deviation could result from a combination of (i) the stronger donor character of the pyrazolate nitrogen atoms due to its -1 charge nature and (ii) the relatively stronger trans influence exerted by the car-bonyl ligands, which significantly weaken the N(py)fRu dative interaction. In good agreement with this postula-tion, the long Ru-N(py) distances in complex 2 compare well with those observed in the related Ru(II) metal complexes such as [Ru(CO)(py)(TTP)] (2.193(4) Å), TTP ) tetraphenylporphinate) and [Ru(bpy)(CO)2Cl2] (2.10-(1) Å),18showing the pyridine group located trans to the strong π-accepting carbonyl ligand.
A perspective view of the Os complex 3 together with the atomic numbering scheme is illustrated in Figure 3, and selected bond lengths and angles are listed in Table 3. To our surprise, the coordination environment around the Os atom, which shows an ideal C2symmetry, displays a notable distinction from that established for the previous Ru analogue 2. This is revealed by the detection of pyrazolate nitrogen atoms N(1) and N(1A) being located at the position trans to the cis-oriented carbonyl ligands. Although this subtle change of ligand orientation on the ligand sphere has had almost no effect on the chelate bite angle, cf.∠N(1)-Os(1)-N(2) ) 77.3(1)°, the nitrogen to osmium dative bonding interaction has turned substantially stronger, as is evident from the observation of unusually short Os-N distances (Os(1)-N(1) ) 2.013(3) Å and Os(1)-N(2) ) 2.087(3) Å). The latter is very close to the Os-N(bpy) distances (2.036-2.076 Å) observed in the related Os-(II) complexes such as [Os(bpy)2(Cl)(NCMe)][PF6] and [Os(bpy)3][PF6]2.19The results may be rationalized by the fact that the third-row transition metal elements tend to have stronger ligand-to-metal interactions
com-(15) Lee, F.-J.; Chi, Y.; Hsu, P.-F.; Chou, T.-Y.; Liu, C.-S.; Peng, S.-M.; Lee, G.-H. Chem. Vap. Deposition 2001, 7, 99.
(16) Lee, K. K.-H.; Wong, W.-T. J. Chem. Soc., Dalton Trans. 1997, 2987.
(17) Xu, L.; Sasaki, Y. J. Organomet. Chem. 1999, 585, 246.
(18) (a) Little, R. G.; Ibers, J. A. J. Am. Chem. Soc. 1973, 95, 8583. (b) Haukka, M.; Kiviaho, J.; Ahlgren, M.; Pakkanen, T. A. Organome-tallics 1995, 14, 825.
(19) (a) Constable, E. C.; Raithy, P. R.; Smit, D. N. Polyhedron 1989, 8, 367. (b) Demadis, K. D.; Meyer, T. J.; White, P. S. Inorg. Chem.
1998, 37, 3610.
Os3(CO)12+ 6(pypz)H f
3[Os(CO)2(pypz)2] (3) + 3H2+ 6CO (3)
Figure 2. ORTEP diagram of complex 2 with thermal ellipsoids shown at 30% probability; the fluorine atoms of the CF3 substituent on the pyrazolate fragments were removed for clarity.
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
pared with their second-row congeners. In addition, the -1 charged pyrazolate nitrogen atoms are located at the positions trans to the good π-acceptor CO ligand, which can effectively remove the excess charge density that may accumulate at the metal center. As a result, the N(pz)fOs dative interaction is strengthened, resulting in a reduction of bond distances. IR ν(CO) spectral studies of Os complex 3 in CH2Cl2solution revealed two CO stretching bands at 2043 and 1973 cm-1, which are at lower frequencies than those (2076 and 2017 cm-1) observed for the respective Ru complex 2. The results are in good agreement with the delineation, suggesting the occurrence of a stronger π-acceptor interaction within the Os complexes. For comparison, a reverse trend was observed in their parent carbonyl complexes, in which the ν(CO) stretching bands of Os3(CO)12 occurred at least 4-8 cm-1 higher in frequency than those of the Ru3(CO)12counterpart.20
3.3. Photophysical Properties. Figure 4 shows UV-visible absorption spectra of the 2-pyridyl pyra-zolate complexes in acetonitrile. For metal complexes 2 and 3, the dominant absorption bands in the 245-316 nm region were ascribed to the ligand-centered π-π* transitions. These spectral assignments were based on the absorption spectra of the related boron complex 1, as well as the corresponding free ligands (shown later in Figure 6). Attempts have also been made to examine any lower energy absorption at >360 nm, presumably associated with typical MLCT transitions. However, no absorption bands could be resolved in the region of 380-700 nm, suggesting that all MLCT transitions in complexes 2 and 3 are hidden in the UV region of the strong intra-ligand π-π* transitions (vide infra). Ab-sorption spectra similar to those for complex 3 were observed for Os(II) complexes 4 and 5, and their relevant photophysical data are listed in Table 4.
Taking complex 3 as a prototype, a typical emission spectrum of 5-(2-pyridyl) pyrazolate Os complexes is depicted in Figure 4. Despite the diffusive S0f S1 (π-π*) absorption band, the corresponding emission
spec-trum exhibits a distinct vibronic feature with peak maxima at 430, 457, and ∼480 nm in CH3CN. The luminescence intensity is linearly proportional to the increase of concentrations, eliminating the emissions associated with any high-order aggregation. The entire emission band originating from a common ground-state species is ascertained by the same fluorescence excita-tion spectra throughout the monitored wavelengths of 420-600 nm. The excitation spectra, within the range of experimental error, are also effectively identical to the absorption spectrum, indicating that the entire emission results from a common Franck-Condon ex-cited state. From comparison of the corresponding absorption and emission spectra, we can make several remarks regarding complex 3. First of all, there is a significantly large energy gap of∼4000 cm-1for the 0-0 vibronic onsets between absorption and emission spec-tra. In comparison, complex 1 exhibits an emission band (20) (a) Johnson, B. F. G.; Lewis, J. Inorg. Synth. 1972, 13, 92. (b)
Battiston, G. A.; Bor, G.; Dietler, U. K.; Kettle, S. F. A.; Rossetti, R.; Sbrignadello, G.; Stanghellini, P. L. Inorg. Chem. 1980, 19, 1961.
Figure 3. ORTEP diagram of complex 3 with thermal ellipsoids shown at 30% probability; the fluorine atoms of the CF3 substituent on the pyrazolate fragments were removed for clarity.
Figure 4. Room-temperature UV-vis absorption and emission spectra of the pypz complexes 1 (s), 2 (-2-), and 3 (-O-) in CH3CN, in which the emission of 2 is not detectable. Inset: Relaxation dynamics of emission for 3 in room-temperature degassed CH3CN.
Figure 5. Temporal evolution of transient absorption spectra for complex 3 at a delay time of (a) 0.36, (b) 6, (c) 11.7, (d) 17.4, (e) 28.8, and (f) 40 µs in degassed CH3CN; (g) transient absorption spectrum of 3 acquired at a delay time of 2 µs in aerated CH3CN. Inset: Decay profile of the transient signal at 550 nm (in degassed CH3CN). λex: 355 nm.
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
maximized at 380 nm, in which the 0-0 onset overlaps with that of the S0f S1(π-π*) absorption band. Second, the Stokes shift, defined as the peak-to-peak frequency between absorption and emission, is as large as 9000 cm-1. Since the emission peak wavelength revealed a slightly hypsochromic shift from cyclohexane (460 nm) to acetonitrile (457 nm), the anomalously large Stokes shifted emission resulting from the solvent dipolar relaxation also can be discarded. Alternatively, these observations, in combination with the relaxation dy-namics, O2 quenching effect, and transient absorption spectra elaborated as follows, lead us to propose that the emission, more plausibly, originates from a triplet manifold.
The inset of Figure 4 shows the relaxation dynamics of emission for complex 3 in room-temperature degassed CH3CN. The logarithm plot of the time-dependent emission intensity is apparently linear and thus can be well fitted straightforwardly by the first-order relax-ation dynamics. A best linear least-squares fit gave the lifetime of complex 3 as 18.3 µs. The same method was applied for complexes 4 and 5 with corresponding lifetimes of 13.4 and 6.3 µs, respectively (see Table 4). Upon aeration of the solution, the lifetime of complex 3 was drastically reduced to 310 ns, accompanied by the decrease of the steady-state emission intensity (not shown here). Taking an O2concentration of 1.9× 10-3
M in the aerated CH3CN solvent,21 a quenching rate constant of∼1.7 × 109M-1s-1was thus deduced, which is nearly 1/9 of the diffusion-controlled rate of 1.8× 1010 M-1s-1calculated from the Stokes-Einstein equation22 in CH3CN. The result is consistent with the O2 quench-ing triplet state accordquench-ing to the theory of electron-exchange type energy transfer expressed as
The overall spin must be conserved upon forming a collisional complex. Accordingly, the possibility of each collision generating1O
2is statistically 1/9.
Another key support for the triplet-state population was rendered by the transient absorption experiment. Figure 5 shows the temporal spectral evolution of the transient absorption for complex 3, consisting of a well-resolved band maximized at 520 nm and the other one at <370 nm that was irresolvable due to spectral interference with the ground-state absorption. As shown in the inset of Figure 5, a plot of the transient absor-bance versus the delay time reveals a biexponential feature. In other words, the logarithm plot of the transient absorbance does not reveal a straight line (not shown here) and thus cannot be simply fitted by first-order decay kinetics. With an increase in the laser intensity the non-single-exponential decay behavior became more obvious, indicating that the bimolecular quenching process, i.e., the triplet-triplet annihilation, plays a role in the relaxation dynamics. In a degassed solution where O2 has been completely removed, the decay pathways of a triplet-state species incorporating triplet-triplet annihilation can be expressed as
By solving the associated kinetic equations, the time-dependent triplet-state concentration [T] is depicted as
where [T]0 is the concentration of the triplet-state species prepared right after the laser excitation. Under the experimental condition of 1 cm excitation path length, the time-dependent transient absorbance ∆A should theoretically be proportional to [T] by ∆A ) TT -[T], where TTis the extinction coefficient of the triplet-triplet absorption. Letting b ) kTT/TT, eq 3 can thus be rewritten as
where ∆A0 is the signal intensity right after the laser pulse. The decay of the transient absorbance depicted in the inset of Figure 5 was well fitted by eq 4, and the (21) Murov, S. L.; Carmichael, I.; Hug, G. L. Handbook of Photo-chemistry, 2nd ed.; Marcel Dekker: New York, 1993.
(22) For example, see: Birks, J. B. Photophysics of Aromatic Molecules; Wiley: New York, 1970; p 313.
Figure 6. (a) Roomtemperature UVvis absorption ( -) and fluorescence (-O--) spectra of pypz anionic species (pypzK) in CH3CN containing 1 M KOH. (b) Phosphores-cence spectrum of pypz anion (s) in the 77 K solid (CH3 -CN) matrix acquired at a delay time of 1 µs. * denotes Raleigh scattering.
Table 4. Photophysical Properties of Complex 1-5 in Room-Temperature CH3CNa
complex absorption (S0-S1) emission Q.Y. τobs
1 319 ( ) 14 250)b 380 0.88 6.4 ns 2 300 ( ) 14 000) 462c 50.5 µsc 3 311 ( ) 16 500) 430 0.14 18.5 µs 457 480 4 314 ( ) 16 120) 430 8.69× 10-2 13.4 µs 455 480 5 306 ( ) 17 200) 428 4.06× 10-2 6.3 µs 455 480
aAll samples were degassed via three freeze-pump-thaw cycles.bUnits in M-1cm-1.cData were obtained at 77 K.
T +3O298 kO2 S0+ 1 O2 T 98kT S0 T + T 98 kTT S1+ S0 [T] ) kT[T]0 (kT+ kTT[T]0)ekTt- k TT[T]0 (3) ∆A ) kT∆A0 (kT+ b∆A0)ekTt- b∆A 0 (4)
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
lifetime was deduced to be 17.2 µs, which, within the range of experimental error, is identical to the one (18.3 µs) derived from the emission relaxation dynamics. Note that due to the rather small triplet-state population, the triplet-triplet annihilation is negligible in the emission study using the time-correlated single-photon-counting technique. The transient absorption originating from the triplet-triplet transition was also confirmed by its nearly 1/9 diffusion-controlled O2 quenching rate, as indicated by the negligible transient absorbance in aerated solution acquired at a delay time of, for ex-ample, 2 µs (see Figure 5g). Similar emission properties such as spectral features, long lifespan (>µs), and O2 quenching dynamics were observed for complexes 4 and 5, and the corresponding photophysical data are listed in Table 4.
Upon unambiguously determining the dominant emis-sion in Os(II) complexes 3-5 to be of phosphorescent nature, our next task focuses on the origin of the phosphorescence. The appearance of phosphorescence with vibronic progression has provided a clue to the3 π-π* configuration, which plausibly originates from the ligand-center chromophore. To validate this assignment, we have carried out a series of comparative studies focusing on the photophysics of the ligand 5-(2-pyridyl) pyrazole (pypzH). Due to the deprotonation of pypzH in forming the corresponding Os(II) complex, a fair comparison should be with its anion species. Figure 6a shows the room-temperature absorption and emission spectra of the pypz anion (pypzK), in which the room-temperature emission consists of a unique, normal Stokes-shifted fluorescence maximized at 372 nm (τf≈ 4.38 ns). No longer wavelength emission ascribed to phosphorescence could be resolved in room-temperature CH3CN. Figure 6b shows the emission of pypz-anion in a 77 K solid matrix (CH3CN) acquired after a delay time of 1 µs to eliminate the fluorescence interference. Apparently, a structured phosphorescence maximized at∼460 nm was resolved, of which the spectral feature resembles that observed in complex 3. This result unambiguously indicates that the room-temperature phosphorescence in the title Os complexes originates from the ligated pypz chromophore. Note that the main difference in phosphorescence properties between the free pypz anion and complex 3 lies in the τp > 1 s phosphorescence lifetime (at 77 K) in the pypz anion, which is longer than that in complex 3 by∼5 orders of magnitude, manifesting the unusually strong spin-orbit coupling in complex 3. Similar phosphorescence proper-ties can be ascribed to compounds 4 and 5. However, due to the relatively small radiative decay rate, the radiationless decay pathway induced by methyl (or CF3) torsional motion may play a key role in the quenching of phosphorescence. Accordingly, among compounds 3-5 the smallest phosphorescence quantum yield for com-plex 5 can be rationalized because of its bearing two methyl-like rotors (-CH3 and -CF3). Likewise, the phosphorescence quantum yield of complex 4 with C2F5 substituent, being smaller than that of complex 3 with CF3, is plausibly due to the more torsional degrees of freedom in C2F5.
Another key comparison was made via the study of complex 2, containing a Ru(II) metal ion. Intriguingly, under the detection limit of∼10-5quantum efficiency
no detectable emission can be resolved in room-temper-ature, degassed CH3CN solution. The transient absorp-tion measurement was also performed for Ru complex 2. Under the same experimental conditions, a transient absorbance of∼1/10 that of Os complex 3 with similar spectral features (λmax≈ 520 nm, not shown here) was obtained for Ru complex 2. Upon cooling to 77 K, a weak, structural phosphorescence maximized at∼460 nm (τp ≈ 50 µs) was resolved, and it clearly possesses a pypz
3π-π* character, confirming the deactivation of the
initial1π-π* excited states to the lowest3π-π* triplet state via intersystem crossing. However, as the ligand field strength associated with the second-row Ru(II) atom is much weaker than that of the third-row Os(II) analogues, the d-d levels of the Ru complexes would be significantly lowered and become thermally acces-sible from the3π-π* level, as the latter is somewhat independent of the variation of the central metal atom.23 In such cases, the 3LC (π-π*) state is expected to internally relax to the d-d states through a thermally activated process, followed by a rapid, dominant radia-tionless pathway to give negligible room-temperature phosphorescence. In contrast, due to the greater ligand field strength, the d-d levels in Os complexes are thermally inaccessible from the3LC (π-π*) state, so the competing radiationless deactivation no longer plays a major role in quenching the3LC (π-π*) state, resulting in a strong intra-ligand3π-π* phosphorescence in the room-temperature solution phase.
Discussion
Based on the above results, the photophysical proper-ties of these new series of [M(CO)2(pypz)2] complexes may be rationalized through their structural unique-ness. The strong π-accepting ancillary CO ligands are capable of removing the electron density from the cationic metal center and hence lead to a higher oxida-tion potential for the current M(II) metal center as well as the destabilization of the M(III) metal center. This electron-withdrawing characteristic, being much greater than those observed for the phosphine and arsine chelates,24 would substantially increase the relative energy of the typical low-lying metal-to-ligand (Os-(dπ)f(π*)) charge transfer transition and make the pypz ligand-centered π-π* energy level the lowest singlet excited state. Evidence has been found from the elec-tronic absorption spectroscopy, in which the MLCT transitions were obscure and possibly hidden inside the strong ligand-centered π-π* transition. It should be noted that the relatively different ligand-versus-CO orientation, to a certain extent, seems to influence the spectral properties as well. For example, Os(II) complex 3 shows a bathochromic shift of the absorption spectrum and relatively higher peak extinction coefficient (see Table 4) than that of Ru complex 2, consistent with different extents of the N(pz)-metal dative interaction. Upon electronic excitation, the strong spin-orbit coupling expected for Os(II) complexes 3-5 would lead to an efficient intersystem crossing from the singlet excited state to the triplet manifold of the ligands. The
(23) Demas, J. N.; DeGraff, B. A. Anal. Chem. 1991, 63, 829A. (24) (a) Johnson, S. R.; Westmoreland, T. D.; Caspar, J. V.; Barqawi, K. R.; Meyer, T. J. Inorg. Chem. 1988, 27, 3195. (b) Kober, E. M.; Caspar, J. V.; Sullivan, B. P.; Meyer, T. J. Inorg. Chem. 1988, 27, 4587.
Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009
fast rate of intersystem crossing is supported by the lack of the 2-pyridyl pyrazolate fluorescence in the region of 370 nm, as well as the system-response-limit rise time for the phosphorescence (<200 ps). The strong orbit coupling, to a great extent, also removes the spin-forbidden nature of the T1 f S0 radiative relaxation. As a result, a dominant blue-green phosphorescent emission can be clearly observed in the room-tempera-ture solution phase. For complex 3, the phosphorescence yield (Φp) was measured to be 0.14 in the degassed CH3 -CN solvent. Assuming unitary efficiency for the inter-system crossing and neglecting the emission loss due to the triplet-triplet annihilation, the T1f S0radiative decay rate constant krcan be derived from a relationship expressed as kr ) Φpkobs, where kobswas measured to be 5.46× 104s-1. Accordingly, a k
rvalue of 7.64× 103 s-1 was deduced. In comparison to the <1.0 s-1 phos-phorescence radiative decay rate of the corresponding free ligand anion (i.e., pypz-anion), the vast enhance-ment of the T1 f S0 radiative decay rate through the spin-orbit coupling in complexes 3-5 is supportive. On the other hand, as indicated by the lack of fluorescence and small T1-Tntransient absorbance, the rapid
excited-state relaxation in complex 2 seems to be dominated by two additional factors. First, the small difference in energy between the3π-π* and the metal-centered d-d states would promote facile thermal deactivation through population of the d-d-states, followed by radiationless, vibrational relaxation. Second, the enhanced nonradia-tive decay observed in complex 2 may also be rational-ized via a ligand orientation effect. This is evidenced by the fact that the spatial separation between the cis pyridyl fragments in complex 2, estimated by the center-to-center distance between two pyridyl ring systems, is approximately 4.76 Å. This would then promote the inter-ligand electron transfer and give a fast nonradia-tive decay process. In contrast, complex 3 shows pyridyl sites located at the trans disposition and having a much longer intramolecular spatial separation of 6.9 Å, so that the inter-ligand through-space interaction is less effec-tive than that expected in complex 2. Further support of this viewpoint is given by a recent study on the luminescent properties of a series of tris-cyclometalated Ir(III) complexes, which have shown an approximate 10-fold reduction of the emission quantum efficiency for the meridional isomers with respect to the alternative facial
isomers.25It is suggested that the weaker Ir-C bonds observed in the meridional isomers would provide a much greater bond distortion in the excited state, and this could be the more likely reason for the effective quenching of the phosphorescent emission.
4. Conclusion
In conclusion, we report the syntheses and charac-terization of a new family of thermal and photochemical robust Os(II) and Ru(II) metal complexes. While the respective boron complex 1 exhibits strong fluorescent emission derived from the singlet π-π* chromophore, our results clearly demonstrate for the first time that Os(II) complexes 3-5 are capable of displaying a high-energy ligand-centered phosphorescence in the room-temperature solution phase, despite the fact that Os(II) complexes typically exhibit lower energy MLCT emis-sion in the regions of green, red, and even infrared. The presence of strong π-accepting ancillary CO ligands as well as the Os(II) heavy atom effect makes the as-synthesized pyridyl pyrazolate complexes unique in their photophysical properties. Taking into account knowledge that current interest in the blue- and red-color emitter has recently been focusing on the Ir(III) type of π-π* or MLCT phosphorescence, future applica-tions of the title Os(II) complexes and/or relevant derivatives may be motivated by the strategy of using these complexes in the fabrication of organic light-emitting diodes (OLEDs). The strong metal-ligand bonding interaction and high phosphorescence quantum efficiencies with ca. microsecond lifetimes may improve OLED performance. Focus on this approach is currently in progress.
Acknowledgment. We thank the National Science Council of Taiwan for financial support (NSC 91-2119-M-002-016 and NSC 91-2113-M-007-006).
Supporting Information Available: X-ray crystallo-graphic file (CIF and PDF) for complexes 2 and 3. This material is available free of charge via the Internet at http://pubs.acs.org.
OM034037E
(25) Tamayo, A. B.; Alleyne, B. D.; Djurovich, P. I.; Lamansky, S.; Tsyba, I.; Ho, N. N.; Bau, R.; Thompson, M. E. J. Am. Chem. Soc. 2003, 125, 7377.
