Photopolymerized self-assembly microlens arrays based on phase separation

Li-Chen Huang,* Tzu-Chieh Lin, Chiu-Chang Huang and Chih-Yu Chao*

Received 17th September 2010, Accepted 22nd November 2010 DOI: 10.1039/c0sm01013h

In the past decades, there has been much effort in developing and improving new techniques for the production of microlens arrays. Here a low-temperature self-assembly method using phase separation is demonstrated for the first time for the fabrication of polymer microlens arrays. In this paper, we present a simple method for producing microlens arrays based on liquid crystal/photopolymer blends via phase separation. The morphology of the microlens arrays has been measured by SEM, AFM and scanning white light interferometry. Our results show that the microlens arrays obtained from our experiments have a comparable light-gathering capability and can be applied in optical systems.

1. Introduction

The ability to develop micro-optics for use in devices, such as communication performance, display technologies, and photo- voltaic devices, has been of considerable interest over the past few decades.¹Making the fabrication technique faster and more efficient requires that optical systems be produced simply and parallel, and as a result the low-cost fabrication of microlenses is becoming necessarily and even plays an important role in many optics-based applications. Several fabrication techniques for microlens array have been demonstrated such as the photo-resist reflow method,²the gray-scale photolithography,³the micro-jet fabrication,⁴the LIGA process,⁵and so on. However, the reflow method has many drawbacks. For example, the high processing temperature and the need for an etch-transfer process, to produce stable optical components, is not convenient in microlens production. As for the gray-scale photolithography, it is difficult to fit the desired shape precisely and distinguish the gray levels in a sharp edge so that the lens surface is also rough. In addition, micro-jet fabrication suffers from limitations in the minimum lens size and alignment accuracy. Similarly, the modified LIGA method is also quite complex, especially given its time-consuming processes using expensive facilities. Although these above-mentioned techniques can produce micro-optic devices, their fabrication requires multiple sophisticated processes and long timescales for mass production.

To date, many techniques have been developed for making arrayed microlenses with a variety of materials. For example, swellable polymer microlenses upon exposure to solvents create a tunable range of focal lengths.⁶Due to the hydrophobic effect in this technique, the well-defined boundary of the microlenses in the solvent vapors would either expand or contract, resulting in a variation of the focal lengths. In addition, the stimuli-

responsive hydrogel aperture undergoes reversible volume change in response to environmental stimuli by absorbing and releasing water in order to function as an adjustable focusing lenses.⁷ Herein, this paper describes a novel technique for fabricating polymeric microlens arrays based on liquid crystal (LC)/photopolymer blend phase separation and self-assembled process owning to the surface tension. First, the sample cell is irradiated through a holes-patterned photomask by UV light and then the photocurable polymer, under the exposure area, is polymerized which leads to the formation of the polymer pillar arrays. In forming a pillar structure, several factors, such as UV light intensity, exposure time, and material can influence the morphologies simultaneously in the phase separation process.

Second, the uncured polymer around the polymer pillars is gradually accumulated on the exposed area which exhibits lower surface energy, and then self-assembled to form a hemisphere shape covering each polymer pillar at room temperature. Finally, the plano-convex lens arrays are formed and cured by the second UV irradiation. Our method does not need heating or cooling treatment, and possesses a simple production process for the fabrication of microlens arrays. To the best of our knowledge, this low-temperature self-assembly method is demonstrated for the first time to fabricate polymeric microlens arrays. We also show that the microlens arrays fabricated by this method have a comparable light-gathering capability and can be applied in optical systems.

2. Experiments and discussion

A schematic diagram of the fabrication process of this study is shown in Fig. 1, which comprises of several steps. In Fig. 1(a), a mixture of LC, a photocurable polymer and a photo-initiator was confined within a packing cell which is composed of two glass substrates, and its cell gap was controlled by a13 mm aluminium spacer. In this procedure, UV light was irradiated onto the photopolymer in areas that are not covered with a chrome-on-quartz photomask.
