Geometrically Consistent Stereoscopic Image Editing using Patch-based Synthesis

Sheng-Jie Luo, Ying-Tse Sun, I-Chao Shen, Bing-Yu Chen, Senior Member, IEEE , and Yung-Yu Chuang, Member, IEEE

Abstract—This paper presents a patch-based synthesis framework for stereoscopic image editing. The core of the proposed method builds upon a patch-based optimization framework with two key contributions: First, we introduce a depth-dependent patch-pair similarity measure for distinguishing and better utilizing image contents with different depth structures. Second, a joint patch-pair search is proposed for properly handling the correlation between two views. The proposed method successfully overcomes two main challenges of editing stereoscopic 3D media: (1) maintaining the depth interpretation, and (2) providing controllability of the scene depth. The method offers patch-based solutions to a wide variety of stereoscopic image editing problems, including depth-guided texture synthesis, stereoscopic NPR, paint by depth, content adaptation, and 2D to 3D conversion. Several challenging cases are demonstrated to show the effectiveness of the proposed method. The results of user studies also show that the proposed method produces stereoscopic images with good stereoscopics and visual quality.

Index Terms—stereoscopic images, patch-based synthesis

✦

1 I

NTRODUCTION

A

^S stereoscopic 3D media is becoming popular, manipulating stereoscopic 3D images and videos becomes an important demand. Unlike conventional 2D media, editing stereoscopic 3D media allows the depth of the scene to be controllable (e.g., depth adjustment of an object) while maintaining stereopsis.

Therefore, the main issues of editing stereoscopic 3D media are twofold. Firstly, the editing results should maintain depth interpretation established through stereopsis by human, which indicates that the corre- sponding points in the left and right views should be adjusted jointly. Secondly, objects with different depths should be handled separately so that they do not affect each other, implying the needs for depth- aware processing.

It is challenging to faithfully maintain the depth interpretation and provide controllability of the scene depth while editing stereoscopic 3D media. Recently, warping-based approaches [1], [2] have been intro- duced for editing stereoscopic images, especially for adapting the depth and the size of an image. These approaches place a pair of quad meshes onto the two views and then compute a pair of deformed meshes for satisfying editing constraints. They suc- cessfully maintain consistent depth interpretation by incorporating stereopsis constraints into the warping procedure. However, they could suffer from distortion

• S.-J. Luo, Y.-T. Sun, B.-Y. Chen, and Y.-Y. Chuang are with National Taiwan University.

E-mail: {forestking, night533, robin, cyy}@cmlab.csie.ntu.edu.tw

• I-C. Shen is with Academia Sinica, Taipei, Taiwan.

E-mail: [email protected]

artifacts when there are significant depth variations within a quad, because all pixels in a quad have to undergo the same transformation despite their depth discrepancy. Therefore, these methods are ineffective for 3D editing problems which involves depth ad- justment especially where there are multiple elements with different depths.

In this paper, we propose StereoSyn - a versa- tile and robust stereoscopic image synthesis method which synthesizes the stereoscopic images according to editing operations. To achieve this, patch-based approaches are chosen as the basis of the synthesis algorithm because they have been proven success- ful for image editing [3], [4]. Existing patch-based algorithms divide the source image into a collec- tion of overlapping patches, and copy the patches to construct the target image while maintaining the coherence of nearby pixels. However, applying these algorithms to synthesize the left and right views indi- vidually would unlikely establish a consistent depth interpretation of the resultant stereoscopic image. In addition, these algorithms measure patch similarity using only color appearance. Therefore, they can only synthesize patches similar to the ones in the source image. However, due to occlusion and disocclusion after depth adjustment, it is often necessary to synthe- size patches which are not similar to any of the input image for correctly modeling the spatial relationship change between objects.

This leads to two key observations of our method.

Firstly, the correspondence information should be embedded into the synthesis process, and the re- gions that are visible in both views should be jointly synthesized for guaranteeing a consistent depth in-

terpretation of the scene. Secondly, it is important to be aware of depth edges when measuring patch similarity and contributing to the final color. It is because a local window (i.e., the patch) often con- tains multiple elements with different depths. Without considering depth discrepancies within a patch, it is likely to mix up contributions from different elements.

Based upon these observations, we develop a depth- dependent patch-pair similarity measurement which takes local depth discrepancies into consideration.

Two patch-pairs are similar only if the correspond- ing pixels with similar depth structures have similar colors. Therefore, the proposed method is capable of dealing with the spatial relation change and objects occlu- sion/disocclusion caused by depth modification during stereoscopic image editing. Furthermore, to guarantee the depth interpretation of the stereoscopic images, a joint nearest-neighbor patch-pair search method is introduced to jointly synthesize the left and right views.

We successfully applied our algorithm to an ex- tensive set of stereoscopic image editing applications which provide users with flexibility in specifying different configurations for adjusting the depths and layouts of the stereoscopic images. We also compared our results of depth/size adaptation to warping-based methods, and demonstrated that our method per- forms better than the state-of-the-art methods specif- ically designed for individual problems.

2 R

ELATED

W

ORK

Stereoscopic media editing. Recently, editing of stereoscopic media has attracted lots of attentions.

Many techniques have been proposed for specific editing applications. Stereoscopic image inpainting techniques have been proposed by Wang et al. [5]

and Morse et al. [6]. Koppal et al. [7] proposed a technique that enables the manipulation of stereo parameters such as the interocular distance and loca- tion. The problem of stereoscopic copy and paste has been addressed by using a segmentation-based tech- nique [8] and a gradient-domain technique [9]. Wang and Sawchuck [10] proposed a framework for dispar- ity manipulation of stereoscopic media. Lang et al. [1]

proposed a novel spatially varying warping technique to enable manipulation of the disparity range of stereoscopic videos. The warping-based approach is also applied to resolve stereoscopic image retargeting problem [2]. Basha et al. [11], [12] also addressed the stereoscopic image retargeting problem but used a geometrically consistent seam-carving algorithm with the concept of seam coupling for preserving the depth interpretation. More recently, Lee et al.

proposed a layer-based stereoscopic image resizing method [13]. They adopted the layer-based idea from scene carving [14] but used warping to adjust layers with different depths separately for resizing a stereo- scopic image. Niu et al. [15] proposed a method for

applying the user-specified warping on stereoscopic images. Northam et al. [16] proposed a stereoscopic 3D stylization method that guarantees consistency between the left and right views. However, their method would produce visible layering artifacts in the stylized results because it stylizes different depth layers separately.

Our patch-based method is versatile and can be used in a broader set of interesting stereoscopic image editing problems, such as transferring the stereoscopic texture and editing object shapes by manipulating their depths.

Patch-based image synthesis.Patch-based technique has become popular for image and video synthesis.

They were branched from non-parametric texture syn- thesis [17], [18], [19], [20], [21], [3] which samples patches from the input texture example and pastes them into the output image while maintaining the coherence of nearby pixels in the synthesized result.

Recently, the patch-based methods have also been applied to image editing problems, and we will next review some of them.

In early period of patch-based technique develop- ment, researchers focused on the texture synthesis problem due to large interests in computer graphics community. Efros and Leung [17] proposed a non- parametric texture synthesis method. The structure preservation problem was later addressed by modi- fying the search and sampling strategies [18]. Then, Kwatra et al. [3] developed a synthesis procedure based on global optimization for obtaining more con- sistent synthesized results with respect to the in- put textures. Patch-based methods have also been proven effective for many 2D natural image editing problems, such as image inpainting [22], [23], [24].

Simakov et al. [25] introduced a bidirectional similar- ity distance for summarizing an input natural image.

Barnes et al. [26] introduced a randomized patch- search method to accelerate the synthesis procedure.

Darabi et al. [27] proposed a generalized method for combining two or more images with inconsistent structures.

Although patch-based methods are effective for 2D image editing, they cannot be directly applied to stereoscopic 3D image editing because neither joint synthesis nor local depth discrepancies were addressed in these methods. Therefore, the synthe- sized results are not guaranteed to maintain a con- sistent depth interpretation of the scene (Fig. 1(b)).

In contrast, our approach samples patch-pairs jointly from both views and can synthesize the result with a satisfactory depth interpretation (Fig. 1(c)). Moreover, existing methods cannot handle local layout changes caused by depth adjustments. Our approach exploits a depth-dependent patch-pair similarity measure, and thus can deal with the cases in which pixels within a patch undergo different transformations after depth

(a) source images (b) individual synthesis (c) our approach

Fig. 1. A comparison to individual synthesis. The source stereoscopic image pair (a) is enlarged using [25] for each view individually (b) and our joint synthe- sis approach (c).

adjustment.

3 S

^TEREO

S

^YN

A

^LGORITHM

Our StereoSyn framework is designed for manipulat- ing the depth and layout of a pair of stereoscopic im- ages. To address the above-mentioned issues of stereo- scopic image editing, the objectives of our algorithm are to maintain a consistent depth interpretation of the stereoscopic images, and to separately synthesize objects with different depths in the scene.

The input is a pair of rectified source stereoscopic images. In order to obtain the depth information and to associate corresponding pixels in the two views, we first construct the disparity maps for the source image pair, and then generate a pair of visibility maps indicating whether a pixel is visible in both views or in only one view. Depending on the editing goals, the target disparity maps could be manually specified by users or automatically constructed via synthesis [25]

for guaranteeing that the layouts of the target dispar- ity maps are similar to those of the source disparity maps. Specifically, for applications in which the target depth information is based on user intention, such as depth-guided texture synthesis, paint by depth, and 2D to 3D conversion, the target disparity map is specified by users and given as the input. On the other hand, for applications where the target depth information can be inferred from the source depth information, such as content adaptation, the target disparity map is automatically generated using a 2D synthesis method [25].

Based on the target disparity maps, the target vis- ibility maps are constructed accordingly. The four pairs of maps (source images, source disparity, visi- bility and target disparity) are used in the synthesis procedure, which performs patch-based optimization taking into account the disparity and visibility maps.

Based on the visibility maps, a joint nearest-neighbor patch-pair search method is introduced so that the regions visible in both views can be synthesized jointly to maintain a consistent depth interpretation

L B R

(a) (b) (c)

Fig. 2. An illustration of visibility maps. (a) The left disparity map. (b) & (c) the left and right visibility maps.

The blue (L) / green (R) regions are the pixels only visible in the left / right view, and the yellow regions (B) are visible in both views.

of the two views. In addition, a depth-dependent patch-pair similarity measure is incorporated into the optimization process such that each patch performs self-segmentation according to its local depth discrep- ancies while contributing to the final results.

Here we first describe how we obtain the disparity and visibility maps (Sec. 3.1). Then we introduce our optimization-based stereoscopic image synthesis process (Sec. 3.2) and depth-dependent patch-pair similarity measure (Sec. 3.3). Finally we describe the solver used to obtain the final results and also the joint nearest-neighbor patch-pair search mechanism (Sec. 3.4).

3.1 Disparity and visibility map construction Given a rectified stereoscopic image pair (I^l, I^r), in this step, their associated disparity map pair and visibility map pair are constructed.

Disparity map. To generate the disparity map pair (D^l, D^r), we begin with estimating the disparity map D^lassociated with the left view I^lusing stereo match- ing [28], where the disparity value d is defined as d = p⁰_x − px for a pixel pair (p, p⁰) ∈ (I^l, I^r). To avoid potential inconsistency between the left and right views, instead of estimating the disparity map for the right view, we directly map the disparity values in the left disparity map to the right one, and fill the missing disparities due to occlusions using a segmentation-based disparity filling approach [5].

Note that, although the estimated disparity maps may not be perfect, experiments show that our method can tolerate modest inaccuracy within disparity maps and still produce visually plausible results.

Visibility map.Analysis of visibility is critical in our framework. Although there exist more sophisticated approaches such as the learning-based occlusion anal- ysis technique proposed by Humayun et al. [29], we adopt a light-weight rule-based approach to analyze the visibility for stereoscopic images.

The objective of the visibility maps (V^l, V^r) is to indicate whether a pixel is visible in both views or

only in a specific view. A visibility map V classifies every pixel p into one of the three classes {L, R, B}

which indicates that p is visible from the left, right, or both views, respectively (Fig. 2). A pixel p = (px, py) in the left image is marked as B if satisfying the following two criteria:

0 ≤ px+ D^l(p) < w and

∀q|(qx> px) ∧ (qy= py),px+ D^l(p) 6= qx+ D^l(q), (1) where w denotes the width of the image, and q = (qx, qy) represents a pixel on the right of p on the same horizontal line. The first condition verifies that p stays within the image bound, and the second one ensures that p is not occluded in the right view. If p is labeled as B, its corresponding pixel in the right view is also labeled as B. The remaining pixels in the left and right images are marked as L and R, respectively. According to the visibility maps, we can partition the stereoscopic image pair into four non- overlapping regions: Ω^L / Ω^R represents the pixels in the left / right image labeled as L / R; Ω^Bl / Ω^Br represents the pixels in the left / right image labeled as B, where I^l= Ω^L∪ Ω^Bl and I^r= Ω^R∪ Ω^Br.

3.2 Optimization-based stereoscopic image syn- thesis

Given a pair of source stereoscopic images (I_S^l, I_S^r), our goal is to synthesize a pair of target stereoscopic images (I_T^l, I_T^r) while observing the user-specified editing properties. The objective of our stereoscopic image synthesis is to minimize the appearance dif- ferences of regions with similar local depth geometry between the result and input images. Therefore, the disparity and visibility maps are associated together to formulate the optimization problem via an energy function. Formally, the stereoscopic image pair and its associated maps are denoted by I^p = (I^l, I^r), where I^l = (I^l, D^l, V^l) and I^r = (I^r, D^r, V^r). As a result, for synthesizing the target stereoscopic images, we need to solve for I_T^l, I_T^l, D_T^l, D^r_T, V_T^l, and V_T^r. The problem is complicated because these variables have dependencies which cannot be expressed as closed- form formulas: (1) D^r_T and (V_T^l, V_T^r) can be inferred from D^l_T as described in Sec. 3.1 and (2) D_T^l can be estimated from (I_T^l, I_T^r). Furthermore, it is often preferable if users can have direct control to the target disparity map. Therefore, we opt to fix the target disparity maps after they are either manually provided by the users or automatically generated.

Specifically, the algorithm synthesizes the target stereo image pair (I_T^l, I_T^r) given the source stereo image pair, the computed disparity and visibility maps and the target disparity and visibility maps by minimizing an energy function:

arg min

(I_T^l,I_T^r)E(I^p_S, I^p_T). (2)

The energy function E(I^pS, I^p_T) is defined as:

E(I^p_S, I^p_T) = E_L(I^lS, I^lT) + E_R(I^rS, I^rT) + E_B(I^p_S, I^p_T), (3) where EL, ER and EB are the similarities of the regions labeled as L, R, and B, respectively. Pixels within different regions are measured and synthesized separately to better preserve the depth interpretation of the synthesized image.

In Eq.(3), EL(I^l_S, I^l_T) and E_R(I^r_S, I^r_T) measure the similarity of the regions only visible in one view. We define EL(I^l_S, I^l_T) as the sum of a completeness term and a coherence term:

EL(I^lS, I^lT) = 1

|Ω^L_S| X

ps∈Ω^L_S

min

pt∈I_T^l s(n(ps), n(pt)) + 1

|Ω^L_T| X

qt∈Ω^L_T

min

qs∈I_S^ls(n(qt), n(qs)), (4)

where p and q are the sampled pixels; n(p) denotes the spatial neighborhood around a sample p, which is called a patch; and s(n(·), n(·)) defined in Eq.(6) is the distance between the two patches that will be discussed in Sec. 3.3. The completeness term en- courages that all patches in the region Ω^L_S should be represented in the output image I_T^l, and the coherence term encourages that all patches in the region Ω^L_T should look similar to those in the input image I_S^l. To compute the similarity metric, for each input sample ps∈ Ω^L_S, we find the corresponding sample ptwith the most similar neighborhood in the output left image I_T^l and cumulate their distances, and vice versa. ER

is defined in a similar way.

For the regions labeled as B, since they are visible in both views, we should perform a joint patch-pair search for maintaining the depth interpretation as:

EB(I^p_S, I^p_T) = 1

|Ω^B_S^l| X

(ps,p⁰_s)∈ ¯Ω^B_S

min

(pt,p⁰_t)∈ ¯Ω^B_T¯s(¯n(ps, p⁰_s), ¯n(pt, p⁰_t))

+ 1

|Ω^B_T^l| X

(qt,q_t⁰)∈ ¯Ω^B_T

(q_s,qmin⁰_s)∈ ¯Ω^B_Ss(¯¯n(qt, q⁰_t), ¯n(qs, q_s⁰)), (5) where (p, p⁰) and (q, q⁰) stand for corresponding pixels in the left and right views, ¯n(p, p⁰) = (n(p), n(p⁰)) denotes the pair of corresponding patches, and

¯s(¯n(·, ·), ¯n(·, ·)) defined in Eq.(8) is the distance be- tween the two patch-pairs that will be discussed in Sec. 3.3. Specifically, Eq.(5) sums the local patch-pair distances. That is, for every local patch-pair ¯n(ps, p⁰_s) in ¯Ω^B_S = (Ω^B_S^l, Ω^B_S^r), we search for the most similar patch-pair ¯n(pt, p⁰_t) in ¯Ω^B_T = (Ω^B_T^l, Ω^B_T^r) and accumu- late their distances, and do the same vice versa.

3.3 Depth-dependent patch/patch-pair similarity The patch similarity metric is a core component for patch-based texture synthesis algorithms [30]. In con- ventional texture synthesis algorithms, the similarity

(a) (b) (c) (d) (e)

Fig. 3. The illustration of the depth-dependent color similarity term between patches n(p) and n(q). In this example, we compress the disparity range of the source image to synthesize the target image. (a) We focus on the two patches n(p)andn(q) from the source and target stereoscopic images. (Only one view is shown here.)D_n(p)andD_n(q)are their disparity maps. Note that the textures on the wall are different in the two images.

(b) We obtain Dˆ_n(q) by shifting D_n(q) so that the disparity value of the central pixel ofn(q) equals to that of the central pixel ofn(p). (c) The distance betweenD_n(p)and Dˆ_n(q),|D_n(p)− ˆD_n(q)|measures the local depth structure similarity for each pixel pair. (d) The depth-dependent weighting kernel wpq is obtained according to

|D_n(p)− ˆD_n(q)|. (e) The comparison of color distances with and without the depth-dependent weighting kernel.

of two patches is defined as the sum of squared distances (SSD) of corresponding pixels’ colors within a window (i.e., the patch). For stereoscopic image synthesis, in addition to colors, we need to take 3D geometry differences between patches into account. A naive extension has been proposed by Morse et al. [6], which directly sums the SSD of both colors and depths together (we call it the simple 4D metric). However, it does not work well because a window could contain multiple layers of depths, and it does not model the depth adjustment.

In order to separately synthesize contents with different depths and enable depth modification, we present a depth-dependent weighted patch similarity met- ric. The key idea is to separate the pixels in a patch into several regions according to their depths and pay more attention to color differences of the pixels with similar depth structures. Specifically, the pix- els’ color differences in two patches are weighted by the differences of their own relative depths to their center pixels. Therefore, our depth-dependent similarity metric consists of two terms. (1) The depth structure resemblance termmeasures the distance be- tween their local depth structures (geometry), where two patches are similar if their local depth structures are similar. (2) The depth-dependent color similarity termmeasures the color distance between pixels but emphasizes more on the pixels with similar relative depths, where two patches are similar if the corre- sponding pixels with similar depth structures have similar colors. Fig. 3 illustrates the idea.

Formally, the depth-dependent patch similarity

metric is defined as:

s(n(p), n(q)) = X

k∈n(p)

(λ|D_n(p)(k) − ˆD_n(q)(k)|² + w_n(p)n(q)(k)|I_n(p)(k) − I_n(q)(k)|²),

(6) where k is the relative position within a patch, and I_n(·)(k) and D_n(·)(k) denote the colors and disparity values at position k in the patch n(·), respectively¹.

With the above notations, D_n(p)(0) denotes the disparity value of the central pixel p of the patch n(p). Thus, in the former term (the depth structure resemblance term) of Eq.(6), ˆD_n(q)(k) = D_n(q)(k) + (D_n(p)(0)−D_n(q)(0)) is the globally-shifted version of D_n(q)(k) such that the disparity values of the central pixels p and q in the two patches are the same (i.e., D_n(p)(0) = ˆD_n(q)(0)) (Fig. 3(b)). Fig. 3(c) demonstrates the distance between the two patches, D_n(p) and Dˆ_n(q).

In the latter term (the depth-dependent color sim- ilarity term) of Eq.(6), w_n(p)n(q)(k) is the depth- dependent weighting kernel for penalizing the color discrepancy more at the pixels with more similar depth structures (Fig. 3(d)). It is formally defined as:

w_n(p)n(q)(k) = exp(−|D_n(p)(k) − ˆD_n(q)(k)|/σ²). (7) With such a kernel, the pixels in a patch will con- tribute less if their relative depth structures are differ- ent from those of the other patch. Fig. 3(e) shows the comparison of color distances with and without the depth-dependent weighting kernel. In this example, we pay more attention to the pillar and less to the

1. Note that, when defining patch similarity, the patches n(p) and n(q) can come from either the source or the target image pair.

Thus, instead of S or T , we use n(p) and n(q) as the subscripts to indicate the disparity maps D associated with them. Similar for I.

(a) Source image (b) Source disparity map (c) Target disparity map

(d) Simple 4D [6] (e) without kernel (f) Our method

detail of (d) detail of (e) detail of (f)

Fig. 4. Comparison of stereoscopic image synthesis using two simpler similarity metrics and the proposed depth-dependent similarity metric. (a) Given a stereo- scopic image pair, assume that we want to narrow down its depth range. (b) The estimated source dis- parity map. (c) The remapped target disparity map.

(d) The result using the simple 4D metric [6]. (e) The result of the proposed similarity metric without the depth-dependent weighting kernel. (f) The result using the proposed depth-dependent similarity metric, which does not suffer from blurry artifacts.

wall since the central pixel p is part of the pillar. The proposed kernel shares similarity with the popular bilateral kernel used for edge-preserving filtering [31].

The main difference is that our kernel weights inten- sity differences by the differences of relative depth structures while the bilateral kernel weights them by differences on locations and intensity values. Finally, the weight λ strikes a good balance between the color similarity and the depth structure resemblance (λ = 1 in our implementation).

For guaranteeing plausible depth interpretation, we need to synthesize both views jointly. In other words, when putting a patch from the left source image into the synthesized left view, we would like to place its corresponding patch in the right source image into a proper location (specified by the target disparity map) of the synthesized right view at the same time.

Therefore, a patch-pair should be formed by asso- ciating two corresponding patches centered at the two corresponding pixels in the left and right views together. Assume that a pixel p = (px, py) ∈ I^l is labeled as B in the visibility map V^l, so it has a corresponding pixel p⁰ = (px+ D^l(p), py) ∈ I^r. Thus, we can couple the patches n^l(p) and n^r(p⁰) together and denote it as a patch-pair ¯n(p, p⁰). Based on Eq.(6), the depth-dependent patch-pair similarity metric is

defined as:

¯s(¯n(p, p⁰), ¯n(q, q⁰)) =

s(n^l(p), n^l(q)) + s(n^r(p⁰), n^r(q⁰)). (8) Fig. 4 shows a comparison of the proposed depth- dependent similarity metric with two simpler metrics:

simple 4D, and our metric without the depth-dependent weighting kernel. Given a source stereoscopic image pair (Fig. 4(a)), we compressed its depth range to syn- thesize the results. Fig. 4(b) shows one of its estimated disparity maps. Then, we remap it using a global remapping function to obtain the target disparity map (Fig. 4(c)) with a narrower depth range. Fig. 4(d), (e), and (f) show the synthesized results using the simple 4D metric, our metric without the depth-dependent weighting kernel, and the proposed depth-dependent similarity metric, respectively. The detail views show that the two simpler metrics often produce blurry results. The simple 4D metric does not model the depth adjustment. Thus, two patches with similar color appearances and local depth structures yet at different depths are regarded as different patches.

It would produce very blurry results as less simi- lar patches could be used for synthesis (Fig. 4(d)).

Without the depth-dependent weighting kernel, the pixels from different layers could be mixed up. As a result, it would produce blurry artifacts at the places with depth discontinuity (Fig. 4(e)). In contrast, with the proposed depth-dependent similarity metric, the foreground pillars and the background wall can be synthesized separately. Therefore, it generates the results without blurry artifacts (Fig. 4(f)).

3.4 Optimization for stereoscopic image synthe- sis

Our stereoscopic image synthesis process is achieved by optimizing Eq.(3). Similar to [4], we applied a multi-resolution iterative algorithm to optimize the objective function by refining the target images from lower to higher resolutions.

Our goal is to synthesize a target stereoscopic image pair I^pT that minimizes Eq.(3). The problem is com- plicated because these variables have dependencies which cannot be expressed as closed-form formulas:

(1) D_T^r and (V_T^l, V_T^r) can be inferred from D^l_T as described in Section 3.1 and (2) D_T^l can be estimated from (I_T^l, I_T^r). Furthermore, it is often preferable if users can have direct control to the target disparity map. Therefore, we opt to fix the target disparity maps after they are manually provided by the users or automatically generated by [25].

For each resolution, our iterative algorithm alter- nates between two steps: patch search and color refinement. In the search step, we fix the output pixels in (I_T^l, I_T^r), and solve the nearest-neighbor search problem, i.e., for all overlapping patches in the source/target images, we retrieve the most similar

patches and patch-pairs in the target/source images.

In the refinement step, we fix the set of matching patches and patch-pairs, and determine the pixel col- ors in the target images by weighted averaging the overlapping pixels. The two steps are iterated until convergence. The process is similar to previous work [4], [25], but requires several modifications to the patch search and color refinement steps.

Patch/patch-pair search.To find the nearest-neighbor for all the patches and patch-pairs to update the re- sult while maintaining the depth interpretation, joint search of the nearest-neighbor patch-pair is critical for our synthesis process. We separate all the patches into two categories. For each patch in Ω^L_S and Ω^R_S, we use the distance metric described in Eq.(4) to search for the most similar patch in the I_T^l or I_T^r, respectively.

For each patch-pair in (Ω^B_S^l, Ω^B_S^r), the most similar patch pair in (Ω^B_T^l, Ω^B_T^r) is found using the patch- pair similarity metric (Eq.(5)). Similarly, for each patch in the target image, we need to find its nearest- neighbor patch/patch-pair in the source image. To find the most similar patch-pair, we modified the randomized search technique [26] that is an efficient method for constructing nearest-neighbor fields for all patches, consisting of three steps: initialization, propagation, and random search. Every pair of cor- responding patches in both views is assigned a pair of corresponding patches in each step. The details of the patch/patch-pair randomized search algorithm is described in the supplemental document for repro- ducibility.

Pixel color refinement. In this step, we minimize Eq.(3) by fixing the set of matching patches/patch- pairs and updating a new pair of target images. Let I_T^l(p) denote the color of a pixel p ∈ I_T^l, the energy function is minimized by solving ∂E(I^p_S, I^p_T)/∂I_T^l(p) = 0. To derive it, we first isolate the contribution of I_T^l(p) to the image distance E(I^pS, I^pT) of Eq.(3).

We take the pixels in the left target image as an example. In the coherence term, let {ni}i=1...m ∈ I_T^l denote the m patches that contain the pixel p, {N (ni)}i=1...m ∈ I_S^l denote their nearest-neighbor patches obtained from the search step, and the pixels in {N (ni)}i=1...m corresponding to the position of p are denoted as {qi}i=1...m. We assume that the first k patches are located in Ω^L_T, while the remaining patches are located in Ω^B_T^l. Then the contribution of I_T^l(p) to the coherence term is

Ecoh(I_T^l(p)) = 1

|Ω^L_T| Xk i=1

w_{niN (ni)}(p)(I_S^l(qi) − I_T^l(p))²

+ 1

|Ω^B_T^l| Xm i=k+1

w_{niN (ni)}(p)(IS^l(qi) − IT^l(p))², (9) where w_niN (ni)(p) is the depth-dependent weighting kernel introduced in Sec. 3.3, and I_S^l(qi) is the color of pixel qi∈ I_S^l.

In the completeness term, assume there are ˆm

patches {N (ˆnj)}j=1... ˆm ∈ I_T^l that contain the pixel p; and they could be matched by the patches {ˆnj}j=1... ˆm ∈ I_S^l; and ˆqj ∈ ˆnj is the pixel at the same relative position as p ∈ N (ˆnj). We also assume that the first ˆk patches are located in Ω^L_T, while the remaining patches are located in Ω^B_T^l. The contribution of I_T^l(p) to the completeness term is

Ecom(IT^l(p)) = 1

|Ω^L_S|

kˆ

X

j=1

w_ˆnjN (ˆn_j)(p)(IS^l(ˆqj) − IT^l(p))²

+ 1

|Ω^B_S^l|

ˆ

Xm j=ˆk+1

w_ˆnjN (ˆn_j)(p)(IS^l(ˆqj) − IT^l(p))². (10) Therefore, the contribution of the color of pixel I_T^l(p) to the image similarity of Eq.(3) is

E(I_T^l(p)) = Ecoh(I_T^l(p)) + Ecom(I_T^l(p)). (11) To refine the color I_T^l(p) for minimizing the image distance, we solve ∂E(I_T^l(p))/∂I_T^l(p) = 0, and the op- timal solution for I_T^l(p) is obtained via the following formula:

I_T^l(p) =(

Pkˆ

j=1wnjˆ N (ˆnj )(p)I_S^l(ˆqj)

|Ω^L_S| +

Pmˆ

j=ˆk+1wnjN (ˆˆ nj )I_S^l(ˆqj)

|Ω^Bl_S |

+ Pk

i=1w_{niN (ni )}(p)I^l_S(qi)

|Ω^L_T| + Pm

i=k+1w_{niN (ni )}(p)I_S^l(qi)

|Ω^Bl_T | )/

( Pkˆ

j=1wnjˆ N (ˆnj )(p)

|Ω^L_S| + Pmˆ

j=ˆk+1wnjN (ˆˆ nj )(p)

|Ω^Bl_S |

+ Pk

i=1w_{niN (ni )}(p)

|Ω^L_T| + Pm

i=k+1w_{niN (ni )}(p)

|Ω^Bl_T | ).

(12)

The pixel color I_T^r(p) can be refined in the same way.

The details and the derivation of the update rules of I_T^l(p) and I_T^r(p) are described in the supplemental document.

4 R

^{ESULTS AND}

D

^ISCUSSION

We applied our method to a wide variety of stereo- scopic image editing applications. All the results were produced with the patch size 7 × 7. Please notice that the results are presented as red(left)-cyan(right) anaglyph images. The original left and right images are included in the supplemental materials.

We encourage readers to watch them on stereoscopic displays for better visual quality.

4.1 Results

Depth-guided texture synthesis.Fig. 5 shows that our method can successfully synthesize the stereoscopic textures according to user-provided depths. Given an input texture sample and a target disparity map, our method synthesizes a larger stereoscopic texture pair whose depth interpretation is conformed to the given disparity map. To achieve the synthesis, the source texture sample is taken as both the left and right source images of our algorithm. As for disparity

Fig. 5. Examples of stereoscopic texture synthesis for given disparity maps. The intensity levels in the disparity maps are proportional to the disparity values. (The image resolution of both middle and right images are 1200×1200.)

(a) (b) (c) (d)

Fig. 6. An example for stereoscopic NPR. (a) The source stereoscopic image. (b) The estimated disparity map. (c) The reference ink brush texture image. (d) The result.

maps, we treat the source disparity map as a flat map with zero disparity values everywhere while the target disparity map is specified by the user. When there are multiple textures in the input texture sample, a guided image can be optionally taken as the initial guess to explicitly guide the synthesis. Taking Fig. 5 Left as an example, there are two types of textures, sky and cloud, in the input. The guided image has two regions: white (a rabbit) and blue (the sky). Guided by it, the proposed method synthesized cloud texture into the white region and sky texture into the blue region.

Stereoscopic NPR. Fig. 6 gives an example of NPR- stylized stereoscopic images. Given a source stereo- scopic image, we first estimated its disparity map, and then transferred the reference ink brush texture to the source image to generate a non-photorealistic stereoscopic image. In this application, the reference ink brush texture is taken as both the left and right source images, and the source disparity map is again flat with zeros. The input stereoscopic image and its estimated disparity map are used to initialize the tar- get images and disparity map and guide the synthesis.

Paint by depth.Fig. 7 shows that our method is able to synthesize a plausible stereoscopic image according to users’ editing on the disparity map. Given a source stereoscopic image and its disparity map, a user pro- vides the target disparity map by manually painting the desired shape of the tree on the disparity map. Our

(a) (b) (c) (d)

Fig. 7. Disparity map editing. (a) The source stereo- scopic image. (b) disparity map. (c) The edited dispar- ity map. (d) The result.

(a) (b) (c)

Fig. 8. Stereoscopic image retargeting results: “Tree”

(upper) and “City” (lower). (a) The source stereoscopic images. (b) The results of changing the image width.

(c) The original and retargeted disparity maps.

method then synthesized the tree with the painted shape according to the modified disparity map.

Stereoscopic content adaptation.Our technique can also be applied to adapt the content of stereoscopic images. Fig. 8 shows that our technique can be used for stereoscopic image retargeting, where the widths were reduced by 22% and increased by 24% in the two examples, respectively. To resize a stereoscopic image, the target disparity map is first obtained by resizing the source disparity map using a 2D synthesis algorithm [25]. Although there is no guarantee that the synthesized target disparity map is a feasible

(a) (b) (c) (d) (e) Fig. 9. A comparison of stereoscopic image retargeting using our approach with a warping-based method [2], scene warping [13], and stereo seam carving [12]. The source stereocopic image (482 × 286) (a) is resized to 400 × 286using our method (b), Chang et al. [2] (c), Lee et al. [13] (d), and Basha et al. [12] (e), respectively.

(a) (b) (c) (d) (e)

Fig. 10. A comparison of stereoscopic image retargeting using our approach and a warping-based method [2].

(a) The source stereoscopic image (304×351). (b)&(c) The enlarged results (500×351) of Chang et al. [2] and ours, respectively. (d)&(e) The reduced results (194 × 351) of Chang et al. [2] and ours, respectively. Our method synthesizes the flowers according to the image resolutions, and thus better preserves the shapes and details. In contrast, the warping-based method stretches the images to satisfy the image dimension, thus producing visible shape distortion especially in the cases where the images have rich textures.

one, we found it works well in many cases. Fig. 9 shows a comparison of image resizing using our method (a), Chang et al. [2] (c), Lee et al. [13] (d), and Basha et al. [12] (e). Compared to the algorithms specifically designed for this application, our method can generate equally good results on this example.

Fig. 10 shows a comparison of our approach to a representative warping-based method [2] for more dramatic resizing. The warping-based approach stretched the flowers and leafs and unavoidably pro- duced shape distortion while our method better re- tained the shapes and sharp details by synthesizing new contents. One thing to note is that our method is usually less efficient compared to those warping- based methods [2], [13]. However, our method offers several advantages. First, it is more versatile and can be used for a set of editing tasks while those methods are specifically designed for image resizing and depth remapping. Second, for image resizing, our results have very different characteristics compared to the results of warping-based methods as shown in Fig. 10.

Thus, our method and those methods can be suitable for different situations.

Fig. 11 shows that our patch-based approach can also be used for remapping the disparity range, which is important for stereoscopic content production and display. To achieve this, users can specify the target disparity map via a disparity mapping operator dt= f (ds) to guide the synthesis process, where f is a map-

ping function maps the input disparity value dsto the output disparity value dt. Fig. 12 shows a comparison of our method to a warping-based method [1]. The warping-based approach leads to visible distortion if there are significant disparity variations within quads.

It is because the pixels with different disparity values in the same quad usually need to undergo different transforms, which is impossible for warping-based methods. In contrast, our method allows each patch to contribute only to the regions with similar local depth structures. As a result, our method better preserves the straight lines as shown in Fig. 12(d).

Stereoscopic image inpainting and reshuffling. By specifying the search constraints and/or match con- straints for some regions on the source stereoscopic image, our system can also be used for stereo- scopic image inpainting and content reshuffling. In this application, the users paint the region(s) to be erased or make layout rearrangements on the source stereoscopic image. They only need to paint on one view of the stereoscopic image. The painted pixels are mapped to the other view automatically based on the disparity map. Note that the completeness terms are removed when performing stereoscopic image inpainting. Fig. 13 shows an example of the constrained synthesis. Given a source stereoscopic image (Fig. 13(a)), and the user-specified region(s) to erase (Fig. 13(b)) and/or layout rearrangement(s) (Fig. 13(d)), our system synthesizes the results with

Near Far

-98 -11 -20

30

Source

Target Result

Error: | ɡ | Err.Max

Err.Min 1.81

0px px

(a) (b) (c)

Fig. 11. Disparity remapping results. (a) The source stereoscopic image whose disparity range is too large (−11 ∼ −98) for human to fuse. (b) The result stereo- scopic image after adapting the disparity range to the comfortable zone. (c) The source disparity map (green), the target disparity map (blue), the final voted disparity map (red), and the error map showing the differences between the final voted and target disparity maps.

the search and/or match constraint(s). The results are shown in Fig. 13(c) for inpainting and (e) for reshuffling.

2D to 3D conversion. Given a 2D image and a user-provided target disparity map (which can be obtained by drawing a dense depth map or using a sparse-scribble propagation technique, e.g., [32]), our method can synthesize the stereoscopic 3D images by regarding the target disparity map as D^lT and duplicating the input image as both I_S^l and I_S^r. Fig. 14 shows three examples with our method. The disparity maps used in the “moon” and “building” examples were manually drawn by users, and the disparity map used in the “cave” example was generated using a propagation technique [32].

4.2 Performance

We implemented our method in C++ and executed it on a desktop PC equipped with an Intel i7 3.5GHz CPU, 16GB RAM, and an Nvidia GeForce GTX 580 GPU. The patch/patch-pair search needs to handle both the left and right views, and is the most time- consuming step. We used OpenMP and GPU to utilize the parallelism for accelerating this step. Overall, for a pair of 0.4-megapixel images (the total pixel number is 0.4×2 megapixels) , it took 435.6 seconds in average with our CPU implementation to synthesize images.

With the GPU version, the time was reduced to 2 minutes.

Our current implementation aims for pursuing the output quality and thus the computation cost is high.

There are some possible ways toward more efficient computation. Firstly, currently we sample patches for all pixels. The computation time could be reduced if we sample patches every k pixels along x and y directions, where k is the sample step. Secondly, the patch/patch-pair search is the bottleneck of the com- putation time. A multiscale strategy can be adopted to accelerate the step. Specifically, the stereoscopic

image is firstly downscaled to a coarse level, and the patch/patch-pair search is performed on that level.

Then the matching result is propagated back to the finer level and is further refined within a local region.

4.3 Evaluation

To validate the stereoscopic quality and the effec- tiveness of disparity remapping of our synthesized stereoscopic images, we conducted two experiments using a 22-inch 120Hz 3D LCD monitor with active shutter glasses. We recruited 30 participants, and 4 of them had no experience on watching stereoscopic con- tents before. Participants passing the depth perception ability test were asked to perform the following tasks.

Stereoscopic quality evaluation.In this task, we ran- domly selected 10 natural stereoscopic images and ad- justed their contents with one of the above-mentioned applications². These 20 images (both source and syn- thesized images) were displayed to the participants in a random order. The participants were asked to watch each image and rate it in 30 seconds on (1) how convincing its stereoscopic effect is, and (2) how natural it is from 1(Bad) to 5(Good). In total, we received 300 pairs of ratings for each question. Fig. 15 shows the average scores for the two questions on all ratings and the ratings for each editing application.

For stereoscopic 3D quality, there are 74% ratings showing that the synthesized results have equal or higher score than the source images; and for natural- ness, there are 83% ratings showing the same result.

Disparity remapping. In the second task, we eval- uated whether the disparity remapping is effective.

We randomly selected 4 natural stereoscopic images and enhanced their depth ranges by a factor of 1.5 using the proposed method. The remapped results and the original images were placed side-by-side with randomized orders. Participants were asked to perform pairwise comparisons. For each comparison, the participants had to answer the following question:

“Which image has a larger depth range?”. We totally received 120 valid votes on this task. Overall, 87.3%

correctly recognized the images with larger dispar- ity ranges. Kendall’s coefficient of agreement was adopted to measure the interobserver variability for the pairwise comparison tests and the p-value < 0.01.

Therefore, the disparity remapping results with our method are perceptually effective.

4.4 Discussion

Our method requires disparity maps in order to sep- arately synthesize contents with different depths. The target disparity maps can be either synthesized us- ing a 2D patch-based approach (e.g.[25]) or specified

2. Some of the images are presented in the paper, including Fig. 8 Upper, Fig. 8 Lower, Fig. 10(a)(c), Fig. 11, and Fig. 13(a)(e). For all left and right images, please refer to supplemental materials.

c

Disney Enterprises

(a) source (b) Lang et al. [1] (c) our method (d) detail

Fig. 12. A comparison of disparity remapping using our approach and a warping-based method [1]. (a) The source stereoscopic image. (b)&(c) The disparity remapping results using Lang et al. [1] and ours, respectively.

(d) A detail view of our result shows that our technique can preserve the straight lines in the regions with significant disparity variations. The warping-based method bends the straight lines because the disparity values of the pigeon and the building are very different. It thus produces visible distortions.

(a) (b) (c) (d) (e)

Fig. 13. Results of stereoscopic image inpainting and reshuffling. (a) The source stereoscopic image. (b) The region to be erased is painted by red color. (c) The stereoscopic image inpainting result. (d) The layout rearrangements specified as red, green, and yellow rectangles. (e) The stereoscopic image reshuffling result.

Moon Cave Building

Fig. 14. Examples of 2D to 3D conversion. Upper:

The source images and given disparity maps (inset).

Lower: The 2D to 3D results.

by users. Synthesized disparity maps often lead to reasonable results because they are guaranteed to be similar to the source disparity maps. However, for user-specified disparity maps, if they are too different from the source, the synthesized results could be less meaningful.

We have also evaluated how well the depth in- terpretations of the synthesized stereoscopic images are conformed to the target disparity maps. Although stereo matching algorithms can be applied to estimate the result disparity map by analyzing the synthesized images, existing stereo matching algorithms are still

Fig. 15. The average ratings of the synthetic images and the original images. (The error bars indicate the standard deviations.)

far from perfect and could contain errors. Therefore, instead of applying stereo matching algorithms, we adopt the refinement rule described in Eq.(12) to vote the result disparity map by substituting the color information with depth information. The disparity maps obtained in this way are closer to what we perceive from the synthesized images. As shown in Fig. 11(c), the voted disparity maps (red outlined) are

(a) (b) (c)

Fig. 16. A failure case due to the inaccurate dispar- ity map. (a) The source stereoscopic image. (b) The enlarged result. (c) The disparity maps. Note that the disparity values of the sky at the up-left corner are not accurate. They should be further back but mis- estimated as the same as the tree.

consistent to the target disparity maps (blue outlined).

The errors between the voted disparity maps and the target disparity maps are shown in the lower right corner of Fig. 11(c), in which the maximal error is less than 2 pixels. It shows that the proposed framework can synthesize stereoscopic images whose depth inter- pretations are very close to the target disparity maps.

Limitation. Although the proposed method can be applied to a wide variety of applications, it suffers from a few limitations. Firstly, the current computa- tion cost is still very high. The method certainly ben- efits from faster nearest neighbor search algorithms.

Additionally, the method can also be accelerated by more aggressive sampling of patches as discussed in Sec. 4.2.

Secondly, the patch-based approaches do not guar- antee to preserve global structures. As presented in Fig. 1 (c), the lower part of the new tree is not synthesized, and thus the tree looks floating. This is inherited from the patch-based synthesis approaches that lack the knowledge of global structures, and could be improved by incorporating semantic object detection algorithms.

Finally, although with some degree of tolerance, the proposed method suffers from bad quality of disparity maps. Fortunately, existing stereo methods can produce good disparity maps for plausible results in most cases. Fig. 16 shows a failure case, in which the bee is separated into two parts because most of the disparity values are inaccurate. In addition, the proposed method synthesizes the results by utilizing only existing patches in the source images. When there are significant view changes in the target, the existing patches in the source need to be re-projected and warped according to the depth structure changes between the original view and the novel view. The current method cannot handle such cases.

5 C

ONCLUSION AND FUTURE WORK

We have presented a stereoscopic patch-based syn- thesis framework that handles the corresponding in-

formation in two views and separately synthesizes contents with different depth structures. The combina- tion of depth-dependent patch/patch-pair similarity metric and joint nearest-neighbor search contributes to the realism of the synthesized stereoscopic images and plausibility of their depth interpretations. The method has potential to be useful for many stereo- scopic image processing applications as demonstrated in the experiments. A few interesting research di- rections are worth of exploration. First, the current method only compensates the local depth structures of patches by global depth shifts. To accommodate for large perspective changes, the depth structures of patches should be compensated by proper rigid transforms before evaluating patch similarity. Second, to synthesize results with large view changes, view interpolation or depth-image-based rendering could be combined with our approach.

R

^EFERENCES

[1] M. Lang, A. Hornung, O. Wang, S. Poulakos, A. Smolic, and M. Gross, “Nonlinear disparity mapping for stereoscopic 3D,”

ACM TOG, vol. 29, no. 4, pp. 75:1–75:10, 2010.

[2] C.-H. Chang, C.-K. Liang, and Y.-Y. Chuang, “Content-aware display adaptation and interactive editing for stereoscopic images,” IEEE TMM, vol. 13, no. 4, pp. 589–601, 2011.

[3] V. Kwatra, I. Essa, A. Bobick, and N. Kwatra, “Texture op- timization for example-based synthesis,” ACM TOG, vol. 24, no. 3, pp. 795–802, 2005.

[4] Y. Wexler, E. Shechtman, and M. Irani, “Space-time completion of video,” IEEE TPAMI, vol. 29, no. 3, pp. 463 –476, 2007.

[5] L. Wang, H. Jin, R. Yang, and M. Gong, “Stereoscopic inpaint- ing: Joint color and depth completion from stereo images,” in Proc. IEEE CVPR ’08, 2008.

[6] B. Morse, J. Howard, S. Cohen, and B. Price, “Patchmatch- based content completion of stereo image pairs,” in Proc.

3DIMPVT ’12, 2012, pp. 555–562.

[7] S. Koppal, C. L. Zitnick, M. Cohen, S. B. Kang, B. Ressler, and A. Colburn, “A viewer-centric editor for 3D movies,” IEEE CG&A, vol. 31, no. 1, pp. 20–35, 2011.

[8] W.-Y. Lo, J. van Baar, C. Knaus, M. Zwicker, and M. Gross,

“Stereoscopic 3D copy & paste,” ACM TOG, vol. 29, no. 6, pp.

147:1–147:10, 2010.

[9] S.-J. Luo, I.-C. Shen, B.-Y. Chen, W.-H. Cheng, and Y.-Y.

Chuang, “Perspective-aware warping for seamless stereo- scopic image cloning,” ACM TOG, vol. 31, no. 6, pp. 182:1–

182:8, 2012.

[10] C. Wang and A. A. Sawchuk, “Disparity manipulation for stereo images and video,” in Proc. SPIE, vol. 6803, 2008, p.

68031E.

[11] T. Basha, Y. Moses, and S. Avidan, “Geometrically consistent stereo seam carving,” in Proc. IEEE ICCV ’11, 2011, pp. 1816–

1823.

[12] T. Dekel Basha, Y. Moses, and S. Avidan, “Stereo seam carving a geometrically consistent approach,” IEEE TPAMI, vol. 35, no. 10, pp. 2513–2525, 2013.

[13] K.-Y. Lee, C.-D. Chung, and Y.-Y. Chuang, “Scene warping:

Layer-based stereoscopic image resizing,” in Proc. IEEE CVPR

’12, 2012, pp. 49–56.

[14] A. Mansfield, P. Gehler, L. Van Gool, and C. Rother, “Scene carving: scene consistent image retargeting,” in Proc. ECCV

’10: Part I, 2010, pp. 143–156.

[15] Y. Niu, W.-C. Feng, and F. Liu, “Enabling warping on stereo- scopic images,” ACM TOG, vol. 31, no. 6, pp. 183:1–183:7, 2012.

[16] L. Northam, P. Asente, and C. S. Kaplan, “Consistent styliza- tion and painterly rendering of stereoscopic 3D images,” in Proc. NPAR ’12, 2012, pp. 47–56.

[17] A. Efros and T. Leung, “Texture synthesis by non-parametric sampling,” in Proc. IEEE ICCV ’99, vol. 2, 1999, pp. 1033–1038.
